Ryobi RGL18 User manual

RGL18

2
Original Instructions
IMPORTANT!
It is essential that you read the instructions in this manual
before assembling, operating, and maintaining the product.
Subject to technical modications.
Safety, performance, and dependability have been given top
priority in the design of your
glue gun .
INTENDED USE
The glue gun is intended for applying hot glue adhesives.
Do not use the product for any other purpose. Use of the
product for operations different from intended could result in
a hazardous situation.
GLUE GUN SAFETY WARNINGS
■This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
■If the product is to be stored unused for a long period,
the batteries should be removed.
■The supply terminals are not to be short-circuited.
ADDITIONAL BATTERY SAFETY WARNINGS
■To reduce the risk of fire, personal injury, and product
damage due to a short circuit, never immerse your
tool, battery pack or charger in fluid or allow a fluid to
flow inside them. Corrosive or conductive fluids, such
as seawater, certain industrial chemicals, and bleach
or bleach-containing products, etc., can cause a short
circuit.
TRANSPORTING LITHIUM BATTERIES
Transport the battery in accordance with local and national
provisions and regulations.
Follow all special requirements on packaging and labelling
when transporting batteries by a third party. Ensure that
no batteries can come in contact with other batteries
or conductive materials while in transport by protecting
exposed connectors with insulating, non-conductive caps or
tape. Do not transport batteries that are cracked or leaking.
Check with the forwarding company for further advice.
KNOW YOUR PRODUCT
See page 3.
1. Nozzle
2. Glue stick chamber
3. LED on/off indicator
4. Mode selector
5. Trigger
6. Handle
7. Drip tray
8. Battery port
9. Replaceable nozzle
10. Glue stick
11. Operator's manual
12. Battery pack
13. Charger
LED INDICATOR
Colour Status
Red Warming up
Green Ready to use
MAINTENANCE
■Use only original accessories and spare parts. Should
components need to be replaced which have not been
described, please contact an authorised service centre.
All repairs should be performed by an authorised service
centre.
■Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to various types of commercial
solvents and may be damaged by their use. Use clean
cloths to remove dirt, carbon dust, etc.
■Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc., come in contact
with plastic parts. Chemicals can damage, weaken or
destroy plastic which may result in serious personal
injury.
SYMBOLS ON THE PRODUCT
Safety alert
V Volts
Direct current
European Conformity Mark
British Conformity Mark
Ukraine Conformity Mark
EurAsian Conformity Mark
Please read the instructions carefully
before starting the machine.
To reduce the risk of injury or damage,
avoid contact with any hot surface.
Hot surface
Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check with
your local authority or retailer for recycling
advice.
SYMBOLS IN THIS MANUAL
Note
Off
Parts or accessories sold separately

3
13
12
11
10
9
8
7
5
6
4
2
3
1

4
1
2
4
Ø 11-12 mm
1
1
2
1 2 3
4

5
4
2
1
2
3
1
2
3
1
2
2
1
3

6
2
1
2
3
1
2
1
2
20210311v1

PRODUCT SPECIFICATIONS
Glue gun
Model RGL18
Voltage 18 V
Nozzle hole 3.0 mm
Long Reach Nozzle Hole 2.5 mm
Glue stick diameter 11 - 12 mm
Approximate heat up time (minutes) 3
High Temperature Mode 200 °C
Low Temperature Mode 130 °C
Weight - excluding battery pack 0.4 kg
Weight - according to EPTA Procedure 01/2014 0.9 kg (1.3Ah) -
1.7 kg (9.0Ah)
BATTERY AND CHARGER
Model Compatible battery
pack (not included)
Compatible charger
(not included)
Lithium-Ion RB18.. BCL1418..H
RC18..
RYOBI
®
WARRANTY APPLICATION CONDITIONS
In addition to any statutory rights resulting from the purchase, this product is covered
by a warranty as stated below.
1. The warranty period is 24 months for consumers and commences on the
date the product was purchased. This date has to be documented by an
invoice or other proof of purchase. The product is designed and dedicated to
consumer and private use only. So there is no warranty provided in case of
professional or commercial use. This warranty applies only on new products.
2. There is a possibility to extend for a part of the range of power tools
(AC/DC) the warranty period over the period described above using the
registration on the www.ryobitools.eu website. The eligibility of products for
extended warranty is clearly displayed in stores and / or on packaging and
is contained within the product documentation. The end user is required to
register his/her newly-acquired products online within 30 days from the date
of purchase. The end user may register for the extended warranty in his/her
country of residence if listed on the online registration form where this option
is valid. Furthermore, end users must give their consent to the storage of
their personal data that is required to be entered online. They must also
accept the terms and conditions. The registration confirmation receipt, which
is sent out by e-mail, and the original invoice showing the date of purchase
will serve as proof of the extended warranty.
3. The warranty covers all defects of the product during the warranty period
due to faults in workmanship or material at the purchase date. The warranty
is limited to repair and/or replacement and does not include any other
obligations including but not limited to incidental or consequential damages.
The warranty is not valid if the product has been misused, used contrary to
the instruction manual, or has been incorrectly connected to a power supply.
This warranty does not apply to:
–any damage to the product that is the result of improper or lack of maintenance
–any product that has been altered or modified
– any product where original identification (trade mark, serial number) markings
have been defaced, altered or removed
– any damage caused by non-observance of the instruction manual
– any product not displaying the CE approval mark on the rating plate
– any product that has been attempted to be repaired by a non-authorised
warranty service centre or without prior authorisation by Techtronic Industries
– any product connected to improper power supply (amps, voltage, frequency)
– any damage caused by external influences (water, chemical, physical, shocks)
or foreign substances
– normal wear and tear spare parts
– inappropriate use, overloading of the tool
– use of non-approved accessories or parts
– Power tool accessories provided with the tool or purchased separately,
including but not limited to screw driver bits, drill bits, abrasive discs, sand
paper and blades, lateral guide, etc.
– Components (parts and accessories) subject to natural wear and tear, including
but not limited to service & maintenance kits, carbon brushes, bearings, chuck,
SDS drill bit attachment or reception, power cord, auxiliary handle, transport
carry case, sanding plate, dust bag, dust exhaust tube, felt washers, impact
wrench pins & springs, etc.
4. For servicing, the product must be sent or presented to a RYOBI authorised
service station listed for each country in the following list of service station
addresses. In some countries your local RYOBI dealer undertakes to send
the product to the RYOBI service organisation. When sending a product
to a RYOBI service station, the product should be safely packed without
any dangerous contents such as petrol, marked with sender’s address and
accompanied by a short description of the fault.
5. A repair / replacement under this warranty is free of charge. It does not
constitute an extension or a new start of the warranty period. Exchanged
parts or products become our property. In some countries delivery charges
or postage will have to be paid by the sender. Your statutory rights arising
from the purchase of the product remain unaffected
6. This warranty is valid in the European Community, Switzerland, Iceland,
Norway, Liechtenstein, Turkey and Russia. Outside these areas, please
contact your authorised RYOBI dealer to determine if another warranty
applies.
RYOBI is a trade mark of Ryobi Limited,
and is used under license.
© 2021 Techtronic Cordless GP.
AUTHORISED SERVICE CENTRES
Any request or issue with the product can be addressed to your local authorised
service centres (visit www.ryobitools.eu) or directly to: Techtronic Industries GmbH,
Max Eyth Straße 10, 71364 Winnenden, Germany. Please state the serial number
and product type printed on the label.
