Ryobi RACPWS4 User manual

RACPWS4

2
Original Instructions
Safety, performance, and dependability have
been given top priority in the design of your
electric high pressure cleaner.
INTENDED USE
The electric high pressure cleaner is intended
only for outdoor use. For safety reasons, the
product must be adequately controlled by a
two-handed operation.
The product is designed for home or domestic
use. It is intended to clean machines, vehicles,
buildings, oors, tools, facades, terraces,
oors, and concrete walkways by removal of
stubborn dirt using clean water with or without
cleaning detergent.
The product should be used in well-illuminated
conditions.
Do not use the product for any other purpose.
WARNING! The product is designed for
use with a neutral cleaning agent supplied or
recommended by the manufacturer. The use
of other cleaning agents or chemicals may
adversely a󰀨ect the safety of the product.
GENERAL SAFETY WARNINGS
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, re,
and/or serious injury.
■The product is not intended for use by
children or persons with reduced physical,
sensory, or mental capabilities, or lack of
experience and knowledge. Children should
be adequately supervised to ensure they do
not play with the product.
■Wear a complete personal protective
equipment when operating the product,
such as boots, safety gloves, safety helmets
with visor, and hearing protection. Use
high-impact visors only with liquid splash
protection.
WARNING! Do not use the product when
people are within range unless they wear
protective clothing.
■To reduce the risk of injury, keep children
and visitors away. All visitors should wear
safety glasses and be kept at a safe
distance from the work area.
■Ensure that the safety devices are in a good
working condition. Make sure that all safety
devices are operating properly before each
use.
■Do not use the product if important parts,
such as safety devices, high-pressure
hoses, or trigger gun, are damaged.
■Exercise caution when opening the trigger.
Hold the trigger handle firmly with two hands
to avoid injury when the trigger handle kicks
back.
WARNING! During use of high pressure
cleaners, aerosols may be formed. Inhalation
of aerosols can be hazardous to health.
Depending on the application, shielded nozzles
can be used for high pressure cleaning, which
will reduce the emission of hydrous aerosols.
However, not all applications allow the use
of such a device. If shielded nozzles are not
applicable for the protection against aerosols,
a respiratory mask of class FFP 2 or equivalent
may be needed, depending on the cleaning
environment.
■Always stop the product when you leave it
unattended.
■High pressure jets can be dangerous if
misused. Do not direct the jet to people, live
electrical equipment, or the product itself.
■To avoid a risk of explosion, do not spray
flammable liquids.
■Do not direct the jet against yourself or
others to clean clothes or footwear.
■Do not use the product to clean electronic
devices, clothes, or footwear.
■High pressure hoses, fittings, and couplings
are important for the safety of the product.
Use only hoses, fittings, and couplings
recommended by the manufacturer.
■Injuries may be caused, or aggravated, by
prolonged use of a tool. When using any
tool for prolonged periods, ensure to take
regular breaks.
CAUTION! Always install a backow
preventer that complies with EN 12729 Type
BA when connecting the product to a drinking
water supply. Water that has owed through
a backow preventer is considered non-
drinkable. Always observe the regulations
of your local water utility company when
connecting the product to a water supply line.
ELECTRICAL SAFETY WARNINGS
■The plug must match the outlet. Never
modify the plug in any way. Unmodified
plugs and matching outlets reduce the risk
of electric shock.

3
Original Instructions
■Do not use the product if the power cord
or other important parts, such as safety
devices, are damaged.
■Check the power cord and the extension cord
for damage before each use. If the power
cord or the extension cord is damaged, it
must be replaced by the manufacturer, its
service agent, or similarly qualified persons
in order to avoid a hazard.
■Before every use, examine the supply cord
for damage. If there are signs of damage,
it must be replaced by a qualified person
at an authorised service centre to avoid a
hazard.
■Keep the power cord away from heat, oil,
and sharp edges.
■Never touch the mains plug and the socket
with wet hands.
■Inadequate extension cords can be
dangerous. If an extension cord is used,
it shall be suitable for outdoor use, and
the connection has to be kept dry and off
the ground. Use a cord wheel to keep the
socket at least 60 mm above the ground.
■The electric supply connection shall
be made by a qualified electrician. It is
recommended that the electric supply to
this product should include either a residual
current device that will interrupt the supply
if the leakage current to earth exceeds 30
mA for 30 ms or a device that will prove the
earth circuit.
ADDITIONAL SAFETY WARNINGS
■Some regions have regulations that restrict
the use of the product in some operations.
Check with your local authority for advice.
■Before each use, check the product for
damage. A damaged high-pressure hose
must be replaced immediately. Ensure that
all connections, such as high-pressure hose
and nozzle, are secure. Unwind the hose
properly so that they may not get twisted or
kinked.
■Do not allow children or untrained individuals
to use the product.
■Before starting any cleaning operation,
close doors and windows. Clear the area to
be cleaned of debris, toys, outdoor furniture,
or other objects that could create a hazard.
■Never pick up or carry the product while the
motor is running.
■Do not use the product in temperatures
below 0°C.
■Do not use acids, alkalines, solvents,
flammable material, bleaches, or industrial
grade solutions in the product. These
products can cause physical injuries to the
operator and irreversible damage to the
product.
■Always operate the product on a level
surface.
WARNING! High pressure jet can be
dangerous if subject to misuse. The jet must
not be directed to people, animals, electrical
devices, or the product itself.
■Hold the trigger handle securely with both
hands. Expect the trigger handle to move
when the trigger is pulled due to reaction
forces. Failure to do so could cause loss of
control and injury to yourself and others.
■Make sure that the air in the hose and pump
is released before you turn on the product.
To remove the air in the hose and pump,
connect the water supply to the pump using
a garden hose, connect the trigger handle
to the pump using the high-pressure hose,
disengage the trigger handle lock, and
press the trigger until there is a steady flow.
■Exercise caution to avoid slipping or falling.
■Keep firm footing and balance. Do not
overreach. Overreaching can result in loss
of balance.
■Use only accessories that are recommended
by the manufacturer. The use of improper
accessories may cause injury.
■Never leave the product running unattended.
Turn off the product. Do not leave the
product until it comes to a complete stop.
■Be familiar with the controls. Know how to
turn off the product and bleed the pressure
quickly.
■Stay alert, and exercise control. Watch what
you are doing, and use common sense.
■Do not use the product while tired, ill, or
under the influence of drugs, alcohol, or
medication. A moment of inattention while
operating the product may result in serious
personal injury.
■Do not use the product if the switch does not
turn it on and off. Any product that cannot
be controlled with a switch is dangerous
and must be repaired.

4
Original Instructions
■Keep a minimum distance of 30 cm when
cleaning vehicles. The high pressure jet
may damage or burst vehicle tires and/or
tire valves.
■Use a garden hose with a maximum length
of 15 m and compatible with a 12 mm hose
connector.
■Before each use, ensure that the accessory
is securely attached to the trigger gun.
OVERLOAD PROTECTION
The product has an overload protection device
that is activated when overheating or when a
current spike occurs, automatically shutting
down the power within the product. To resume
operation, disconnect the product from the
power supply, wait for about 15 minutes, and
reconnect the product to the power supply.
TRANSPORTATION AND STORAGE
CAUTION! Mind the weight of the product
when selecting the storage location and during
transportation to prevent accidents or injuries.
■Turn off the product, disconnect from the
power supply, and allow the product to
cool down. Disconnect the product from the
water supply before storing or transporting.
Never place the product in any position
other than upright.
■Clean all foreign materials from the
product. Storing the product in an area with
temperature below 0°C will damage the
product Store the product in a cool, dry, and
well-ventilated place that is inaccessible
to children. Keep the product away from
corrosive agents such as garden chemicals
and de-icing salts. Store the product indoors
only.
■Remove water from all hoses and the pump,
and empty the detergent tank before storing
the product.
■For transportation in a vehicle, secure the
product against movement or falling to
prevent injury to persons or damage to the
product.
■Store the product indoor only. Storing the
product in an area with temperature below
0°C will damage the product.
MAINTENANCE
■Use only original manufacturer’s
replacement parts, accessories, and
attachments. Failure to do so can cause
possible injury, can contribute to poor
performance, and may void your warranty.
■Servicing requires extreme care and
knowledge and should be performed only
by a qualified service technician. Have the
product serviced by an authorised service
centre only.
■Turn off the product, disconnect the product
from the power supply, and allow the
product to cool down. Make sure that all
moving parts have come to a complete stop:
●before cleaning the product
●before maintaining the product
●before replacing spare parts
■You may make adjustments or repairs
described in this manual. For other repairs,
have the product serviced by an authorised
service centre only.
■Regularly inspect and maintain the product
for safe operation. RYOBI recommends
inspecting the product every 6 months.
■Check all nuts, bolts, and screws at frequent
intervals for proper tightness to ensure that
the product is in safe working condition. Any
part that is damaged should be properly
repaired or replaced by an authorised
service centre.
SAFETY DEVICES
■On/Off switch
–The on/off switch prevents unintentional
operation of the product.
■Trigger handle lock
–The trigger handle lock locks the trigger
and prevents unintentional opening of
the high-pressure jet.
■Pressure switch
–The overflow valve prevents the
permissible working pressure from being
exceeded. If the lever on the trigger gun
is released, the pressure switch turns
off the pump and the high-pressure jet
stops. If the lever is pulled, the pump
turns on again.
■Overload protection
–A thermal sensor protects the product
from overloading. The product will
automatically shut the power down while
overheating.

5
Original Instructions
SYMBOLS ON THE PRODUCT
Read and understand
all instructions before
operating the product. Follow
all warnings and safety
instructions.
Wear a complete personal
protective equipment when
operating the product.
IPX5
Degree of protection.
Wear eye protection.
Never point the gun to
human, animals, the product,
power supply, or any electric
appliances.
Do not spray ammable liquids
to avoid the risk of explosion.
Flammable liquids and their
vapors are explosive and can
cause severe burns or death.
Kickback. To reduce the risk of
injury from kickback, hold the
trigger handle securely with
both hands when the product
is on.
Failure to use the product in
dry conditions and to observe
safe practices can result in
electric shock.
Do not point the spray directly
at any person or animal to
avoid the risk of injection or
severe injury.
The product is not suitable
for connection to the drinking
water supply without backow
preventer.
Regulatory Compliance
Mark (RCM). Product
meets applicable regulatory
requirements.
93
Guaranteed sound power level
Waste electrical products
should not be disposed of with
household waste. Recycle
where facilities exist. Check
with your local authority or
retailer for recycling advice.
SYMBOLS IN THIS MANUAL
Parts or accessories sold
separately
Note
Warning
Connect to the power outlet.
Disconnect from the power
outlet.
