CORNER CAT SANDER
MODEL NO. CFS1503
REPAIR SHEET

RYOBI CORNER CAT SANDER – MODEL NUMBER CFS1503
2
Key Part
No. Number Description Qty.
PARTS LIST
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your CORNER CAT SANDER or when ordering repair parts.
1 CFS1501-01 * SCREW (M4.2 x 8 mm) ...........................................................4
2 039065005001 PLATEN ...................................................................................1
3 CFS1501-32 PAPER PUNCH .......................................................................1
4 039065005022 DUST BAG ASSEMBLY...........................................................1
5 CFS1501-36 HEAVY SCRUB PAD................................................................1
6 CFS1501-37 LIGHT SCRUB PAD.................................................................1
7 CFS1501-38 POLISHING SCRUB PAD........................................................1
8 CFS1501-33 * SANDING SHEET 60-grit ........................................................1
CFS1501-34 * SANDING SHEET 120-grit ......................................................1
CFS1501-35 * SANDING SHEET 240-grit ......................................................1
9 039065005023 TOOL BAG (NOT SHOWN) .....................................................1
987000149 OPERATOR’S MANUAL (NOT SHOWN) .................................1
07-26-07
(REV:00)
* Standard Hardware Item – May Be Purchased Locally
