Ryobi EMS216L User manual

FRONT PAGE
EMS216L

2
Original Instructions
IMPORTANT!
It is essential that you read the instructions in this manual
before assembling, operating, and maintaining the
product.
Subject to technical modication.
Safety, performance, and dependability have been given top
priority in the design of your mitre saw.
INTENDED USE
The mitre saw is intended for sawing solid and bonded
wood, materials similar to wood, with or without glued veneer
and plastics.
The mitre saw is intended to be used only by adult operators
who have read the instruction manual and understand the
risks and hazards.
The mitre saw is designed to be xed at the base to a
solid bench top. If the base is not securely xed, the
whole machine may move during cutting operations, which
increases the possibility of serious personal injury.
The mitre saw is designed to make bevel and mitre cuts. The
capacities for the various cuts are provided in the product
specications in this manual.
The mitre saw is to be used in dry conditions, with excellent
ambient lighting and adequate ventilation.
The mitre saw is intended for consumer use and should only
be used as described above and is not intended for any
other purpose.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING
Read all safety warnings, instructions, illustrations
and specifications provided with this power tool.
Failure to follow all instructions listed below may result in
electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
WORK AREA SAFETY
■Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
■Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases
or dust. Power tools create sparks which may ignite the
dust or fumes.
■Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
■Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk
of electric shock.
■Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
■Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
■Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electric shock.
■When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
■If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
PERSONAL SAFETY
■Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
■Use personal protective equipment. Always wear
eye protection. Protective equipment such as a dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
■Prevent unintentional starting. Ensure the switch
is in the off -position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invites accidents.
■Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
■Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpected situations.
■Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can
be caught in moving parts.
■If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
■Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
POWER TOOL USE AND CARE
■Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.

3
Original Instructions
■Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
■Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting
the power tool accidentally.
■Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
■Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused
by poorly maintained power tools.
■Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
■Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a hazardous
situation.
■Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
SERVICE
■Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
SAFETY INSTRUCTIONS FOR MITRE SAWS
■Mitre saws are intended to cut wood or wood-like
products, they cannot be used with abrasive cut-off
wheels for cutting ferrous material such as bars,
rods, studs, etc. Abrasive dust causes moving parts
such as the lower guard to jam. Sparks from abrasive
cutting will burn the lower guard, the kerf insert and other
plastic parts.
■Use clamps to support the workpiece whenever
possible. If supporting the workpiece by hand, you
must always keep your hand at least 100 mm from
either side of the saw blade. Do not use this saw to
cut pieces that are too small to be securely clamped
or held by hand. If your hand is placed too close to
the saw blade, there is an increased risk of injury from
blade contact.
■The workpiece must be stationary and clamped or
held against both the fence and the table. Do not
feed the workpiece into the blade or cut “freehand”
in any way. Unrestrained or moving workpieces could
be thrown at high speeds, causing injury.
■Push the saw through the workpiece. Do not pull the
saw through the workpiece. To make a cut, raise the
saw head and pull it out over the workpiece without
cutting, start the motor, press the saw head down
and push the saw through the workpiece. Cutting on
the pull stroke is likely to cause the saw blade to climb
on top of the workpiece and violently throw the blade
assembly towards the operator.
■Never cross your hand over the intended line of
cutting either in front or behind the saw blade.
Supporting the workpiece “cross handed” i.e. holding
the workpiece to the right of the saw blade with your left
hand or vice versa is very dangerous.
■Do not reach behind the fence with either hand
closer than 100 mm from either side of the saw
blade, to remove wood scraps, or for any other
reason while the blade is spinning. The proximity of
the spinning saw blade to your hand may not be obvious
and you may be seriously injured.
■Inspect your workpiece before cutting. If the
workpiece is bowed or warped, clamp it with the
outside bowed face toward the fence. Always make
certain that there is no gap between the workpiece,
fence and table along the line of the cut. Bent or
warped workpieces can twist or shift and may cause
binding on the spinning saw blade while cutting. There
should be no nails or foreign objects in the workpiece.
■Do not use the saw until the table is clear of all
tools, wood scraps, etc., except for the workpiece.
Small debris or loose pieces of wood or other objects
that contact the revolving blade can be thrown with high
speed.
■Cut only one workpiece at a time. Stacked multiple
workpieces cannot be adequately clamped or braced
and may bind on the blade or shift during cutting.
■Ensure the mitre saw is mounted or placed on a
level, firm work surface before use. A level and firm
work surface reduces the risk of the mitre saw becoming
unstable.
■Plan your work. Every time you change the bevel or
mitre angle setting, make sure the adjustable fence
is set correctly to support the workpiece and will
not interfere with the blade or the guarding system.
Without turning the tool “ON” and with no workpiece
on the table, move the saw blade through a complete
simulated cut to assure there will be no interference or
danger of cutting the fence.
■Provide adequate support such as table extensions,
saw horses, etc. for a workpiece that is wider or
longer than the table top. Workpieces longer or wider
than the mitre saw table can tip if not securely supported.
If the cut-off piece or workpiece tips, it can lift the lower
guard or be thrown by the spinning blade.
■Do not use another person as a substitute for a table
extension or as additional support. Unstable support
for the workpiece can cause the blade to bind or the
workpiece to shift during the cutting operation pulling
you and the helper into the spinning blade.
■The cut-off piece must not be jammed or pressed
by any means against the spinning saw blade. If
confined, i.e. using length stops, the cut-off piece could
get wedged against the blade and thrown violently.
■Always use a clamp or a fixture designed to properly
support round material such as rods or tubing. Rods
have a tendency to roll while being cut, causing the
blade to “bite” and pull the work with your hand into the

4
Original Instructions
blade.
■Let the blade reach full speed before contacting the
workpiece. This will reduce the risk of the workpiece
being thrown.
■If the workpiece or blade becomes jammed, turn
the mitre saw off. Wait for all moving parts to stop
and disconnect the plug from the power source and/
or remove the battery pack. Then work to free the
jammed material. Continued sawing with a jammed
workpiece could cause loss of control or damage to the
mitre saw.
■After finishing the cut, release the switch, hold the
saw head down and wait for the blade to stop before
removing the cut-off piece. Reaching with your hand
near the coasting blade is dangerous.
■Hold the handle firmly when making an incomplete
cut or when releasing the switch before the saw head
is completely in the down position. The braking action
of the saw may cause the saw head to be suddenly
pulled downward, causing a risk of injury.
SAFETY INSTRUCTIONS FOR WOOD CUTTING
BLADE
■Please read the manual and instructions carefully before
using the saw blade and the machine.
■The product must be in good condition, the spindle
without deformation and vibration.
■Do not use the product without the guards in position.
Keep guards in good working order and properly
maintained.
■Ensure the operator is adequately trained in safety
precautions, adjustment and operation of the product.
■Always wear goggles and ear protection when using the
product. It is recommended to wear gloves, sturdy non
slipping shoes and apron.
■Before using any accessory, consult the instruction
manual. The improper use of an accessory can cause
damage and increase the potential for injury.
■Use only blades specified in this manual, complying with
EN 847-1.
■Observe the maximum speed marked on the saw blade.
Ensure the speed marked on the saw blade is at least
equal to the speed marked on the saw.
■Always use blades with correct size and shape of arbour
holes. Blades that do not match the mounting hardware
of the saw will run eccentrically, causing loss of control.
■Do not use blades of larger or smaller diameter than
recommended. Do not use any spacers to make the
blade fit onto the spindle.
■Check the tips of the saw blade for damage or abnormal
appearance before each use. Tips that are damaged or
loose can become flying objects in use and increase the
chance of personal injury.
■Do not use cracked or distorted saw blades. Do not use
saw blades that are damaged or deformed.
■Scrap the saw blade if damaged, deformed, distorted or
cracked, repairing is not permitted.
■Do not use HSS blades.
■Ensure the saw blade is mounted correctly, tighten the
arbor nut securely before use (tightening torque approx.
12-15 Nm).
■Fastening screw and nuts shall be tightened using the
appropriate spanner, etc.
■Extension of the spanner or tightening using hammer
blows is not permitted.
■Make sure the blade and flanges are clean and the
recessed sides of the collar are against the blade.
■Make sure the blade rotates in the correct direction.
■Before work, make a dummy cut without the motor turned
on so the position of the blade, operation of the guards
with respect to other machine parts and workpiece may
be checked.
■Never leave the product unattended.
■Do not apply lubricants on the blade when it is running.
■Never perform any cleaning or maintenance work when
the machine is still running and the head is not in the
rest position.
■Never attempt to stop a machine in motion rapidly by
jamming a tool or other means against the blade, serious
accidents can be caused unintentionally in this way.
■Disconnect the product from the mains supply or remove
battery pack before changing blades or carrying out
maintenance.
■Pay attention to blade packing and unpacking, it is easy
to be injured by the sharp blade tips.
■Use a blade holder or wear gloves when handling a saw
blade.
■Keep and store the blade in original packaging or other
suitable packaging, keep in dry conditions and away
from chemicals which may damage the blade.
ADDITIONAL SAFETY WARNINGS
■Always clamp the workpiece safely and securely.
■Ensure that the product is always stable and secure
(e.g., fixed to a bench).
■Always wear ear protectors. Exposure to noise can
cause hearing loss.
■Always wear safety goggles when using the product.
It is recommended to wear gloves for handling blades
and rough material, plus sturdy non slip shoes to protect
the feet from workpieces which may fall from the cutting
area.
■Disconnect the product from the mains supply or remove
battery pack before carrying out any maintenance or
cleaning the product.
■Only connect to the mains supply when the product is
switched off.
■Keep the mains lead clear from the working range of the
machine. Keep it out of the area the operator stands in.
■Never reach into the area near the blade unless the
blade has completely stopped.
■Before use, thoroughly check the product, cable, and
plug for any damage or material fatigue. Repairs to the
whole machine, including the power cable should only
be carried out by authorised service agents.
■Always use the guards on the product. Do not use
the product if the guards are not in place and working
correctly.
■The lower blade guard should only open when the blade
is lowered to the workpiece and must always be able to
move freely and close automatically.

5
Original Instructions
■Always fix and use extension bars for workpiece support
during operation.
■Never alter of modify the product or its function. Your
safety may be compromised.
■Do not use saw blades which are cracked, damaged or
deformed.
■Do not use saw blades made of high-speed steel.
■Only use blades that are sharp. Replace dull blades.
■Always use blades with correct size and shape of arbour
holes. Blades that do not match the mounting hardware
of the saw will run eccentrically, causing loss of control.
■Use only woodworking blades specified in this manual,
which comply with EN 847-1.
■Do not use any flanges, washers and nuts to secure the
saw blade other than those supplied or indicated in the
instruction manual.
■It is necessary to select a saw blade which is suitable
for the material being cut. Never use the product to cut
materials other than those specified in the intended use
section in this manual.
■It is important to avoid overheating the blade and melting
the plastic when cutting.
■It is essential to adhere to the maximum speed specified
on the saw blade, only use saw blade that are marked
with a speed equal or higher than the speed marked on
the tool.
■Replace the table insert when worn or damaged.
■Before work, make a dummy cut without the motor turned
on so the position of the blade, operation of the guards
with respect to other machine parts, and workpiece may
be checked.
■When performing mitre, bevel or compound mitre cuts,
adjust the sliding fence or sub-fence to ensure the
correct clearance from the blade.
■Avoid uncontrolled release of the saw unit from the fully
down position.
■The handle lock must always be engaged when
transporting the product.
■Keep the floor area free of loose materials, such as chips
and cut-offs.
■Refrain from removing any cut-offs or other parts of the
workpiece from the cutting area whilst the product is
running and the saw head is not in the rest position.
■Long workpieces must be adequately supported. The
working area of the saw includes the whole extent of the
workpiece. The operator should secure this area from
accidental contact from other persons or objects which
may move the workpiece during operation.
■The dust produced when using the product may be
harmful to health. Use a dust suction system and wear
a suitable dust protection mask. Remove deposited dust
thoroughly with a vacuum cleaner.
■Do not replace the laser or LED with a different type. Any
repairs must only be carried out by the manufacturer or
authorised service agent.
■The unit should be connected to a power circuit
protection device (fuse or circuit breaker).
■When using the mitre saw outdoors, the manufacturer
recommends the use of an RCD device with a trip set
at 30mA.
■When using this tool, voltage fluctuations may affect
other electrical products or lighting on the same
power circuit. Connect the tool to a power source with
an impedance equal to 0.180 Ω to minimise voltage
fluctuations. Contact your electric power supplier for
further clarification.
LASER SAFETY RULES
■The laser radiation used in this saw is Class 2 with
maximum ≤1mW and 650nm wavelengths. Do not stare
into the laser beam. Failure to comply with the rules
could result in serious personal injury.
■Do not stare into beam during operation.
■Do not project the laser beam directly into the eyes of
others. Serious eye injury could result.
■Do not place the laser in a position that may cause
anyone to stare into the laser beam intentionally or
unintentionally.
■Do not use optical tools to view the laser beam.
■Do not operate the laser around children or allow
children to operate the laser.
■Do not attempt to repair the laser device by yourself.
■Do not attempt to change any parts of the laser device
by yourself.
■Any repairs must only be carried out by the laser
manufacturer or authorised service agent.
■Do not replace the laser with a different type.
RESIDUAL RISKS
Even when the product is used as prescribed, it is still
impossible to completely eliminate certain residual risk
factors. The following hazards may arise and the operator
should pay special attention to avoid the following:
■Risk of contact with uncovered parts of the rotating saw
blade
■Kick-back of workpieces or parts of workpieces due to
improper adjustment or handling
■Catapulting of faulty carbide tips from the saw blade
■Damage to the respiratory system
NOTE: Wear respiratory protection masks containing
filters appropriate to the materials being worked. Ensure
adequate workplace ventilation. Do not eat, drink or
smoke in the work area.
■Damage to hearing if effective hearing protection is not
worn.
WARNING
Dust from certain paints, coatings and materials may
cause irritation or allergic reactions to the respiratory
system. Dust from wood such as oak, beech, MDF and
others are carcinogenic. Material containing asbestos
should only ever be worked or processed by qualied
specialist operators.
WARNING
Injuries may be caused, or aggravated, by prolonged
use of a tool. When using any tool for prolonged periods,
ensure you take regular breaks.

6
Original Instructions
KNOW YOUR PRODUCT
See page 10-11.
1. Handle, insulated gripping surface
2. Power switch
3. Safety lock handle
4. Upper guard
5. Saw blade
6. Lower guard
7. Main fence
8. Turntable
9. Base
10. Table insert
11. Turntable lock handle
12. Balancing foot
13. Extending bar
14. Laser switch
15. LED switch
16. Top handle
17. Bracket stop
18. Lower guard cover
19. Bevel angle lock knob
20. Clamp
21. Sliding fence
22. Mounting hole
23. Extension bar
24. Screws for adjusting the bevel angle limit stop
25. Spindle lock knob
26. Dust bag
27. Cutting depth adjustment knob
28. Maximum cutting depth stop
29. Linear rod stop knob
30. Winding support
31. Screws for adjusting mitre angle
OPERATION
The product features a moving saw blade that can be set at
various angles by the operator when cutting a work piece
which is securely xed to the base of the product. It must
be operated by only one person to prevent unintentional
contact with the moving saw blade.
The principles for safe operation of the product are as
follows:
■Maintain saw, blades and work area in good condition.
■Secure the mitre saw base to a sturdy work bench. The
product may move and tip if it is not adequately secured.
■Set up and lock the cutting angles and depth before
making the cut.
■Secure the work piece to the mitre saw base. Use the
clamp provided and, where necessary, use additional
clamps or holding mechanisms to prevent unintentional
movement of the work piece while cutting.
●Check that the operation of the blade guards are not
restricted by the position of the work piece.
●Ensure that the fence and other parts of the product
will not be cut as the blade lowers to the cutting
position.
■Start the motor and allow the blade to reach full speed
before slowly lowering it to cut the work piece. Slide the
blade assembly backwards and/or forwards to complete
the cut as necessary.
■Allow the blade assembly to rise to its upper position
where the blade guards are fully closed. Switch off the
motor and allow the blade to come to a complete stop
before removing the work piece or off-cuts, or before
reaching into the area of the blade.
Before rst use, ensure that the angle of the bevel or mitre
set on the product matches the angle to be produced on
the work piece. Check this on a discarded piece of wood by
using a carpenter’s set or mitre square.
WARNING
The manufacturer strongly recommends that the product
is always securely mounted to a bench top.
When the base of the product is rmly secured to a bench
top by the four nuts, bolts and washers provided, the product
can be used at maximum bevel and mitre setting without
the possibility of it tipping over. If the product is not secured
properly, the product may over balance when large bevel
angles are selected.
At the front of the mitre saw base there is an extending bar
which should be pulled out to its furthest extent. This will
help prevent the mitre saw from over balancing.
There is also an adjustable screw (balancing foot) that
extends from the bottom of the extension turntable. This
screw should be adjusted so that it touches the at surface
that the product is resting upon. This will also prevent the
product from over balancing when cutting at the full extent
of the slide and bevel. Beware, this part of the saw table
moves when di󰀨erent mitre angles are selected, so the
screw needs to be frequently adjusted and reset.
MAINTENANCE
■Do not modify the product in any way or use accessories
not approved by the manufacturer. Your safety and that
of others may be compromised.
■Do not use the product if any switches, guards or
other functions does not work as intended. Return to
an authorised service centre for professional repair or
adjustment.
■Do not make any adjustments whilst the saw blade is
in motion.
■Always make sure the power plug has been removed
from the mains power source before making
adjustments, lubricating or when doing any maintenance
on the product.
■Before and after each use, check the product for
damage or broken parts. Keep the product in top
working condition by immediately replacing parts with
spares approved by the manufacturer.
■The blade has sharp edges and may also remain hot
after cutting operations. Exercise extreme caution when
cleaning an exposed blade. Wear gloves to protect
yourself from personal injury.
■Clean the saw and its accessories from dust regularly,
especially moving parts including the blade guard.
Use a hand brush or vacuum cleaner to remove dust
effectively. Do not use compressed air.
■To assure safety and reliability, all repairs, including
changing brushes, should be performed by an authorised
service centre.
■If the power cord is damaged, it must be replaced by
an authorised service center in order to avoid a hazard.

7
Original Instructions
WARNING
Do not attempt to disassemble the blade guard assembly
for cleaning or repair. Damaged guards should not be
used. Return to an authorised service centre for repair
or replacement.
WARNING
For greater safety and reliability, all repairs should be
performed by an authorised service centre.
Maximum cutting depth stop
The maximum cutting depth stop is to prevent the saw blade
from cutting into the metal base of the unit.
WARNING
The maximum cutting depth stop is not user adjustable.
Do not adjust the maximum cutting depth stop.
TRANSPORTATION AND STORAGE
■When storing the product, disconnect the power cord.
Store the product in a secure place that is not accessible
to children. Store the power cord as shown in the
illustration on page 217 - 218 of this manual.
■Clean the product using a brush and vacuum cleaner
before storage.
■If you remove the saw blade or keep spares with the
unit, ensure they are in the original packaging to prevent
injury.
To secure the product prior to movement:
■The product should be stored at the zero degree mitre
and bevel angle and locked in position. The slide should
be locked. The handle should be locked in the lower
(safe) position with the guards closed.
■One or both sides of the work piece supports can be
removed for ease of carrying.
To move or transport in a vehicle:
■Secure the product prior to movement as described in
the manual.
■Remove the product from the bench top by releasing the
4 bolts, one at each corner. Secure the bolts for future
use. Lift the product using the handle at the top.
■When lifting to a height, two persons wearing heavy
gloves are needed to lift the base of the product.
■When transporting in a vehicle, set the product on its
base and secure against movement.
ENVIRONMENTAL PROTECTION
Recycle raw materials instead of disposing
of as waste. The machine, accessories
and packaging should be sorted for
environmental-friendly recycling.
SYMBOL
Safety alert
European Conformity Mark
British Conformity Mark
Ukraine Conformity Mark
EurAsian Conformity Mark
Please read the instructions
carefully before starting the
machine.
Class II tool, double insulation
Wear ear protection
Always wear eye protection.
Keep hands away from the cutting
area and sharp blade.
Wear safety gloves
Blade rotation direction (shown on
saw blade)
Blade rotation direction (shown on
blade guard)
Blade width of cut (Kerf)
Number of teeth on this saw blade
For cutting wood and analogous
material
Not for cutting metals
LASER
2
Laser radiation.
Do not stare into beam.
Class 2 laser product

8
Original Instructions
Waste electrical products should
not be disposed of with household
waste. Please recycle where
facilities exist. Check with your
Local Authority or retailer for
recycling advice.
SYMBOLS IN THIS MANUAL
Plug in the product.
Unplug the product.
Lock
Unlock
Locking mechanism is not working
A sound is heard
Waiting time for blade to reach full speed
or stop completely.
Parts or accessories sold separately
Note
Warning
The following signal words and meanings are intended to
explain the levels of risk associated with this product:
DANGER
Indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not
avoided, may result in minor or moderate injury.
CAUTION
(Without Safety Alert Symbol) Indicates a situation that may
result in property damage.

5 mm 10 mm
x 1 x 2
x 1
x 1
x 1 x 2
x 2
x 2
x 2
x 1
x 3x 1 x 1
x 1
6 mm
9

1
15
16
23
17
18
20
21
14
19
22
2
3
4
5
6
9
8
7
13
12
11
10
10

30
25
31
26
29
27
24
28
11

12
x 2
1
7
2
8
3
9

13
x 2
1
2
3
4
10
5
11
6
12
7

1
1
2
2
14

1
1
2
1
3
2
15

2
16

17

2
1
1
3
0˚/15˚/22.5˚/
30˚/45˚
2
4
5
18

7
5s
6
8
9
19

10s
10
11
2
1
1
3
0˚/15˚/22.5˚/
30˚/45˚
2
20
