7-1/4 in. COMPOUND MITER SAW
MODEL NUMBER TS1143L
REPAIR SHEET

2
RYOBI 7-1/4 in. COMPOUND MITER SAW – MODEL NUMBER TS1143L
45
30
42
46 48
47
37
31
55
18
53
19
23
22
21
52
25
20 54
63
61
2
52
51
1
17
14
15
16
24
41
40
38
49
50
57
56
43
60 3
10
58
59
64 65
4
5
33
44
11 12
13
26
27
28 29
67
8
9
39 36
35
32
34
62
31
25 24 23
30
30
FIGURE A

3
RYOBI 7-1/4 in. COMPOUND MITER SAW – MODEL NUMBER TS1143L
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
7-1/4 in. COMPOUND MITER SAW or when ordering parts.
PARTS LIST FOR FIGURE A
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
1 089240006087 Screw (M5 x 20 mm, Pan Hd.) ................................ 2
2 089240006088 Bearing Cover .......................................................... 1
3 089041014010 Laser Bracket ........................................................... 1
4 089041014011 Laser Diode .............................................................. 1
5 089041014012 Compression Spring (B) ........................................... 1
6 089041014013 Wire Cover................................................................ 1
7 089041014014 Washer (D4).............................................................. 2
8 089041014015 Screw (M4 x 8 mm, Pan Hd.) ................................... 2
9 089041014902 Aperture Warning Label............................................ 1
10 089041014701 Upper Blade Guard w/Bearing Assembly ................ 1
11 089240006097 Compression Spring ................................................ 1
12 089240006098 C-Ring ...................................................................... 1
13 089240006099 Spindle Lock Pin ...................................................... 1
14 089240006100 Ball Bearing (6200Z)................................................. 1
15 089240006711 Armature Assembly (Inc. Key Nos. 14 and 16)......... 1
16 089240006102 Ball Bearing (608) ..................................................... 1
17 089240006103 Baffle ........................................................................ 1
18 089240006104 Screw (M4 x 45 mm) ................................................ 2
19 089240006105 Field.......................................................................... 1
20 089041014705 Motor Housing w/Labels (Inc. Key Nos. 54-55) ....... 1
21 089240006107 Screw (M5 x 35 mm, Pan Hd.) ................................. 4
22 089240006108 Screw (M5 x 8 mm, Hex. Soc. Hd.).......................... 2
23 089240006109 Brush Holder ............................................................ 2
24 089240006110 Brush Assembly ....................................................... 2
25 089240006111 Brush Cover ............................................................. 1
26 089240006112 Trigger Lock Button.................................................. 1
27 089240006113 Inner Trigger Lock Button ........................................ 1
28 089240006114 Screw ....................................................................... 1
29 089240006115 Compression Spring ................................................ 1
30 089240006116 Screw ....................................................................... 7
31 089041014704 D-Handle Assembly ................................................. 1
32 089240006118 Trigger ...................................................................... 1
33 089041014016 Screw (M4.2 x 18 mm) ............................................. 2
34 089240006120 Switch ...................................................................... 1
35 089240006121 Trigger Button Spring ............................................... 1
36 089240006122 Screw (M5 x 10 mm, Pan Hd.) ................................. 1
37 089240006123 Screw (M5 x 25 mm, Pan Hd.) ................................. 2
38 089240006124 Screw ....................................................................... 2
39 089240006125 Cord Clamp.............................................................. 1
40 089240006126 Screw (M2.9 x 10 mm) ............................................. 1
41 089240006127 Terminal Cover ......................................................... 1
42 089240006715 Terminal Plate Assembly .......................................... 1
43 089100207051 Screw Direction Label .............................................. 1
44 089240001907 Screw Warning Label ............................................... 1
45 089240006131 Screw (M4 x 10 mm, Pan Hd.) ................................. 1
46 089240006132 Battery Box Cover.................................................... 1
47 089240006133 Laser Switch............................................................. 1
48 089240006134 Screw (M5 x 30 mm, Pan Hd.) ................................. 2
49 089240006135 Bend Relief............................................................... 1
50 089240006710 Power Cord Assembly (Inc. Key No. 57).................. 1
51 089240006137 Spring Washer (D7) .................................................. 2
52 089240006138 Washer (D9).............................................................. 6
53 089240006139 Washer (D8).............................................................. 2
54 089240001902 Warning Label .......................................................... 1
55 089041014901 Data Label ................................................................ 1
56 089240001905 Logo Label ............................................................... 1
57 080006014904 Cord Label................................................................ 1
58 089041014005 Laser Cover.............................................................. 1
59 089041014006 Screw (M4 x 20 mm, Pan Hd.) ................................. 1
60 089041014007 Screw (M4 x 25 mm, Pan Hd.) ................................. 1
61 089240006706 Spindle Assembly (Inc. Key Nos. 3-8)...................... 1
62 089240006140 AAA Batteries ........................................................... 2
63 089041014708 Motor Housing Assembly
(Inc. Key Nos. 18-20, 22-25 and 52-55)................... 1
64 089041014008 Compression Spring ................................................ 1
65 089041014009 Spring Clip................................................................ 1

4
RYOBI 7-1/4 in. COMPOUND MITER SAW – MODEL NUMBER TS1143L
FIGURE B
41
59
40
52
62
1
2
3
4
5
9
10
11
58 12
26
25 10
7
6
8
39
38
31
30
25
37 36
35
34
42
32
33
43 44
45
29
28
22 21 20 19
14
13
61
15
16 17 18
27
60
24
23
47 48
49
50
46 53
55 56 57
51
See Figure A
54
60
48
63

5
RYOBI 7-1/4 in. COMPOUND MITER SAW – MODEL NUMBER TS1143L
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
7-1/4 in. COMPOUND MITER SAW or when ordering parts.
PARTS LIST FOR FIGURE B
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
1 089240006061 Rear Handle (Upper) .............................................. 1
2 089240003002 Rear Extension Bar ................................................ 1
3 089240006003 Rear Handle (Lower) .............................................. 1
4 089240003004 Screw (M3.9 x 12 mm, Hex. Soc. Hd.) .................. 3
5 089240003005 Screw (M5 x 8 mm, Pan Hd.)................................. 2
6 089240006006 Bolt (M8 x 20 mm, Hex Hd.) .................................. 1
7 089240006007 Steel Ball (8 mm).................................................... 1
8 089240006008 Detent Spring......................................................... 1
9 089240006009 Lock Nut (M10) ...................................................... 1
10 089240006010 Washer (OD8 x ID5 x 1.5t) ..................................... 5
11 089240006011 Washer (OD25.5 x ID10.5 x 1.9t) ........................... 1
12 089240006012 Miter Pad ............................................................... 8
13 089240006703 Base Assembly (Inc. Key No. 60)........................... 1
14 089240006014 Miter Lock Pad....................................................... 1
15 089240006015 Miter Lock Screw................................................... 1
16 089240006016 Miter Lock Lever .................................................... 1
17 089240006017 Compression Spring .............................................. 1
18 089240006018 Screw (M5 x 17 mm, Pan Hd.)............................... 1
19 089240006019 Screw (M3 x 10 mm, Pan Hd.)............................... 2
20 089240006020 Washer (OD6.5 x ID3 x 0.8t) .................................. 2
21 089240006021 Miter Pointer .......................................................... 1
22 089240006084 Dust Bag Assembly ............................................... 1
23 089240006023 Throat Plate............................................................ 1
24 089240006024 Screw (M4 x 8 mm, Flat Hd.) ................................. 5
25 089240006025 Lock Washer (OD12.5 x ID8.3 x 2.2t)..................... 5
26 089240006026 Bolt (M8 x 30 mm, Cap Soc Hd.)........................... 4
27 089240006027 Screw (M6 x 12 mm).............................................. 1
28 089240006028 Miter Fence............................................................ 1
29 089240006029 Grommet................................................................ 1
30 089240001904 Bevel Scale Label .................................................. 1
31 089240006031 Screw (M8 x 10 mm, Cap Soc. Hd.) ...................... 1
32 089240006032 Bevel Pointer.......................................................... 1
33 089240006143 Screw (M4 x 10 mm, Pan Hd.)............................... 1
34 089240006034 Screw (M8 x 48 mm, Soc. Hd.).............................. 2
35 089041014001 Knuckle .................................................................. 1
36 089240006036 Washer (OD22 x ID8.5 mm x 1.3t) ......................... 1
37 089240006037 Washer (OD18 x ID8.5 x .4t) .................................. 1
38 089240006038 Screw (M8 x 48 mm, Cap Soc. Hd.) ...................... 1
39 089240006039 Washer (OD22 x ID8.2 x 2.3t) ................................ 1
40 089240006040 Bevel Knob ............................................................ 1
41 089240006041 Screw (M5 x 12 mm, Pan Hd.)............................... 1
42 089240006042 Stop Block ............................................................. 1
43 089041014018 Spindle Lock Pin.................................................... 1
44 089240006053 O-ring..................................................................... 1
45 089041014019 Lock Pin Cap ......................................................... 1
46 089240006086 Washer (OD7.8 x ID4 x 1.0t) .................................. 1
47 089240006059 Blade Bolt .............................................................. 1
48 089240006060 Blade Washer......................................................... 2
49 089240006001 Blade (24t).............................................................. 1
50 089240006063 Screw (M4 x 10 mm, Pan Hd.)............................... 1
51 089240006064 Guard Stop Block .................................................. 1
52 089240006085 Hex Key (5 mm) ..................................................... 1
53 089240006067 Dust Chute............................................................. 1
54 089240006066 Screw (M4 x 20 mm, Pan Hd.)............................... 1
55 089240006068 Torsion Spring........................................................ 1
56 089240006069 Spring Spacer ........................................................ 1
57 089240006070 Pivot Pin................................................................. 1
58 089041014707 Miter Table Assembly (Inc. Key No. 30) ................. 1
59 089041014702 Lower Blade Guard Assembly ............................... 1
60 089100207097 No Hands Label ..................................................... 3
61 089240006708 Work Clamp Assembly........................................... 1
62 089240006702 Carry Handle Assembly ......................................... 1
63 089240006065 Screw (M4 x 8 mm, Soc. Hd.)................................ 2
NOT SHOWN:
990000955 Operator’s Manual
9-10-15
(Rev:04)

6
RYOBI 7-1/4 in. COMPOUND MITER SAW – MODEL NUMBER TS1143L
MOTOR
YELLOW
LEAD
YELLOW
LEAD
BRUSH
ASSEMBLY
BRUSH
ASSEMBLY
SLEEVE
SWITCH
POWER
CORD
YELLOW
LEAD
BROWN
LEAD
BLACK
LEAD
WHITE
LEAD
WIRING DIAGRAM

7
RYOBI 7-1/4 in. COMPOUND MITER SAW – MODEL NUMBER TS1143L
LASER MODULE
BLACK
LASER SWITCH
RED
WIRING DIAGRAM
