Safety 1st Summit Deluxe User manual

CUT ON DOTTED LINE
Replacement Parts List
NOTE: If requested color is not available, similar color will be
substituted. Prices are subject to change.
Part..................... Cost ................ Qty...................Total Cost
Crotch Strap/
Buckle................... $4.99 ............... ___ ................... $_______
Harness Strap ....... $2.00 ............... ___ ................... $_______
Seat Pad................ $39.99 ............. ___ ................... $_______
(Includes headrest, harness covers, and pillow)
Chest Clip.............. $1.50 ............... ___ ................... $_______
Top Anchorage
(Tether) Kit ............ $9.99 ............... ___ ................... $_______
LATCH Kit.............. $24.99 ............. ___ ................... $_______
Instructions ........... $0.00 ............... ___ ................... $_______
Merchandise Total...................... ......................$_______
Shipping and handling:.............. ......................$_______
Sales Tax ..........................................................$_______
(Arizona, California, Georgia, Indiana, Missouri, South Carolina, and Texas
residents add applicable sales tax.)
Grand Total .................................... ..................$_______
No shipping and handling on instructions for quantities under 6. Add $.50 for each
instruction over 6, then add applicable shipping and handling.
Fill Out For Credit Card
qVisa qMastercard
Card Exp. Date:______________________________
Cardholder’s Name:___________________________
Card Number:________________________________
Signature__________________________________
Up to $25.00.............$5.95
$25.01 to $50.00...... $6.95
$50.01 to $75.00...... $8.95
$75.01 to $100.00....$9.95
$100.01 to $150.00..$10.95
$150.01 to $200.00..$11.95
$200.01 and up .......$13.95
Outside Continental USA $10.00
51

©2013 Cosco Management Inc. All Rights Reserved.
A. Before You Begin................................ Pages 3-6
A-1 Thank You...
A-2 Registration and Safety Notices
A-3 Understanding Your Child Restraint
B. Safety Information.............................Pages 7-8
B-1 Vehicle Seating Position
B-2 Installation in Vehicle
B-3 Child Restraint Use
C. Basic Use ...............................................Pages 9-27
C-1 Preparing Child Restraint
C-2 Preparing Child Restraint to Fit Your Child
C-3 Securing Child in Child Restraint
C-4 Removing Child from Child Restraint
C-5 Accessories
C-6 Reclining Child Restraint
C-7 Removing Harness System
C-8 Installing Harness System
C-9 Removing Seat Pad for Cleaning
E. Installing Forward-Facing.......... Pages 34-41
D. General Vehicle Installation .... Pages 19-21
D-1 Understanding Your Vehicle
D-2 Vehicle Seating Position
D-3 Knowing Your Vehicle Belts
D-4 Aircraft Information
12
F-1 Preparing Belt-Positioning Booster
F-2 Installing Using the Lap and Shoulder Belts
F. Belt-Positioning Booster Use..... Pages 42-46
E-1 Preparing to Install Forward-Facing
E-2 Adjusting Top Anchorage Strap (Tether)
E-3 Preparing to Install LATCH Forward-Facing
E-4 Install Forward-Facing With LATCH
E-5 Install Forward-Facing with Vehicle Belts
General Information.......................... Pages 47-51
Using a Locking Clip
Warranty
Replacement Parts Order Form

Thank you for choosing this car seat, referred to throughout
this manual as a child restraint. The DJG family is committed
to creating a child restraint with the most comfort and
convenience available today.
Remember, parents are a child’s first teachers and examples.
If you always buckle your seat belt, your child will think it is
the natural thing to do. Make it a firm rule that the vehicle
does not go until everyone is buckled up. Make no exceptions.
No one can predict if use of a child restraint will prevent injury
or death in a particular crash. However, combined with careful
driving, proper use of a child restraint can lower a child’s risk
of injury or death in most crashes.
Your child’s safety is worth the time it will take to read and
follow these instructions. After reading, if you still have
questions or have any problems with this child restraint,
please contact our Consumer Relations Department at:
Dorel Juvenile Group, Inc.
Website: www.djgusa.com
Fax: [phone]
Mailing Address: Dorel Juvenile Group, Inc.
P.O. Box 2609
Columbus, IN 47202-2609
Telephone: [phone]
8 A.M. to 6 P.M. EST M-TH
8 A.M. to 4:30 P.M. EST FRI
On the back of the shell there is an expiration date for use of
this child restraint. Do not use this child restraint after the
expiration date.
A-1 Thank You...
Para recibir las instrucciones en español, llame al
1-800-544-1108 o solicitarse por escrito al dirección por arriba.
Please complete the postage-paid registration card that
came with your child restraint, and send it to us. Child
restraints could be recalled for safety reasons. You must
register this restraint to be reached in a recall. Send
your name, address, email address if available, and the
restraint’s model number and manufacturing date to:
Dorel Juvenile Group, Inc.
PO Box 2609, Columbus, IN 47202-2609
Attn: Consumer Relations
or call 1-800-544-1108 or register online at www.djgusa.
com/registration/carseat/us.
For recall information, call the U.S. Government’s Vehicle
Safety Hotline at 1–888–327–4236 (TTY: 1–800–424–
9153), or go to http://www.NHTSA.gov
If you don’t have the card or if your
address changes, you will find the
model number and manufactured date
on the label located on side of plastic
shell.
A-2 Registration and Safety Notices
A. Before You Begin
Model
Number
Manufacture
Date
34
Example of model number and manufacture date.

A. Before You Begin
56
A-3 Understanding Your Child Restraint
Front Back
A. Pillow
(on select models)
B. Shoulder Belt
Positioning Guide
C. Adjustable Headrest
D. Harness Covers
(on select models)
E. Chest Clip
F. Harness Straps
G. Armrest
H. Buckle Plate
I. Buckle
J. Harness Release Lever
(under flap)
K. Harness Adjustment
Strap
L. Recline Handle
M. Base
N. Cup Holder
A.
C.
B.
D.
G.
E.
F.
O.
R.
P.
Q.
H.
I.
J.
L.
K. N.
O. Top Anchorage
(Tether) Strap & Hook
P. Splitter Plate
Q. Instruction Storage
R. LATCH Belt
(may be between pad
and shell)
M.

78
B-3 Child Restraint Use
Never take your child out of the child restraint
while the vehicle is moving. Never leave child
unattended.
Placing your child in a hot child restraint may
result in burns.
Do not use a child restraint with damaged or
missing parts.
Do not use cut, frayed or damaged harnesses.
Do not lubricate buckles and fasteners.
Do not substitute parts or try to modify the
child restraint in any way.
Do not use any child restraint accessory
except those approved by Dorel Juvenile Group.
Never allow any child to play with this child
restraint; it is not a toy.
Do not remove or cover up any of the warning
labels or other labels on the child restraint.
Read all instructions for additional warnings.
B-1 Vehicle Seating Position
According to accident statistics, children
are safer when properly restrained in the rear
seating positions than in the front seating
positions.
Check the vehicle owner’s manual for more
information about air bag/child restraint use.
For vehicles without a back seat, refer to your
vehicle owner’s manual.
B. Safety Information
Failure to follow these warnings can result in the
serious injury or death of your child. To help you
recognize instructions which are most critical to
your child’s safety, we use this symbol:
B-2 Installation in Vehicle
Check the vehicle belt or LATCH belt before
each use. Use only if the belt is tightened
properly and securely.
This child restraint should be securely belted
in the vehicle even when not in use. In a crash
or sudden stop, an unsecured child restraint
could injure occupants.
Do not use a child restraint that has been in a
crash. You must get a new child restraint.

10
C. Basic Use
C-1 Preparing Child Restraint
9
Make Sure LATCH Belt
Packaging Is Out From
Behind Seat Pad
1.
Loosen Harness
Push down on the harness
release lever (under flap
on the front of restraint)
while pulling out on the
harness.
2.
Release Chest Clip
Press on chest clip
release button and pull
apart.
3.
continued on next page.
Your child’s height, weight and age determine how your child
restraint should be placed in the vehicle.
40-100 lbs (18.1-45.4 kg)
and 43-52 in.
(110.1-1 32.1 cm) and at
least 4 Years Old
Belt-positioning booster
using vehicle lap/shoulder
belt combination
Child and child restraint are
placed in the back seat,
facing the front of the vehicle.
5-point harness is removed.
22-40 lbs (10.1-18 kg)
and 34-43 in.
(85.1-132.1 cm) and
Over 1 Year Old
Forward-Facing using
5-point harness
Child and child restraint are
placed in the back seat,
facing the front of the vehicle.
Unbuckle Harness
Press red button. Pull
buckle tongues out. Place
harness straps out of
the way.
4.
C-2 Preparing Child Restraint to Fit
Your Child
You MUST make these adjustments with your child
before you install the child restraint in the vehicle.

Place Child in Child
Restraint
Place the child’s bottom
and back flat against
the restraint. This will
increase comfort and allow
the harness straps to be
properly tightened.
5.
12
C. Basic Use
11 continued on next page.
Check Buckle
Position
Determine which of the
available buckle positions
will be comfortable and
provide a snug fit for
your child.
6.
To Change Buckle
Position
Fully recline the child
restraint. Reach under the
seat between base and shell
and locate buckle’s metal
retainer under the shell.
Rotate metal retainer, then
insert retainer up through
the shell and pad.
From the top, pull buckle
free from shell and pad.
a.
b.
Reposition buckle location.
Insert the buckle’s metal
retainer through the
desired slot. Make sure
buckle is facing forward.
Reach under seat between
base and shell. Pull
buckle’s metal retainer
completely through pad
and shell.
Pull up on buckle to make
sure it is secured. The
buckle must not pull out.
Failure to place buckle’s metal retainer
completely through pad and shell can result
in serious injury or death.
c.
d.
e.

14
C. Basic Use
13
Check Harness/Headrest
Height
With child in the seat, check
the location of the harness
guide.
Follow the guidelines below
to determine the correct
harness/headrest height.
7.
Forward-Facing Position
Harness guide must be even
with or just above the
shoulders.
If the harness is below the
child’s shoulders with the
headrest in the highest
position and the child weighs
at least 40 lbs. (18.1 kg)
and is at least 4 years old,
convert the seat to a belt-
positioning booster.
To Adjust Harness/
Headrest Height
Squeeze the metal bar on
the back of the seat. Move
harness/headrest adjuster
up or down to the position
that correctly fits your child.
Release bar into slot to lock.
8.
Make sure metal
bar is locked into
position. Failure to
do this can result
in serious injury or
death.
Do not use this child restraint
forward-facing if the midpoint of
your child’s head is above the top of
the child restraint’s headrest.
Make sure the harness height is correct for
your child’s size.
Failure to follow these steps can result in
serious injury or death.
4
3
2
1

16
C. Basic Use
15
C-3 Securing Child in Child Restraint
Position Harness
Straps Over the
Child’s Shoulders.
1.
Buckle Harness
Push each buckle tongue
into buckle until you hear
a “click”. Remember to
always pull up on harness
straps to make sure buckle
is locked.
2.
Close Chest Clip
Insert right half of chest
clip into left half and
snap together.
3.
Tighten Harness
Pull on harness
tightening strap to tighten
harness snugly.
NOTE: A snug strap
should not allow any
slack. It lies in a relatively
straight line without
sagging. It does not press
on the child’s flesh or
push the child’s body into
an unnatural position.
4.
Position Chest Clip
The chest clip must be
placed at mid-chest (even
with armpits) and away
from the child’s neck.
6.
Failure to fasten and tighten the harness
system correctly and snugly can result in
serious injury or death.
Check Harness
Tightness
Try to pinch the harness
at the shoulders. If you
can pinch the harness
strap, tighten more. If your
fingers slip off, the harness
is tight enough.
5.

17 18
C. Basic Use
C-4 Removing Child From Child Restraint
Loosen Harness
Press on harness release
lever while pulling on
harness straps above the
buckle to loosen.
1.
Release Chest Clip
Press on release button and
pull apart.
2.
Unbuckle
Press red button on buckle
to release the buckle
tongues. Move harness
away from child and
remove child.
3.
C-5 Accessories
Harness Covers
(on select models)
Harness covers help
provide comfort to the
neck. To remove the
covers, unthread the
harness from harness
bracket (see belt-
positioning booster
section), remove covers,
and rethread harness.
Reverse to replace insert.
Cup Holder
The cup holder is built into
the base. To use the cup
holder, slide cup holder
away from the seat. Push
it back in to store it.

19 20
C. Basic Use
C-6 Reclining Child Restraint
This child restraint has 3
positions: Upright, Semi-
reclined, and fully reclined.
Forward-Facing - Reclined,
semi-reclined or upright.
Belt-Positioning Booster -
Must be fully-upright.
NOTE: When forward-facing,
the recline position is to be
used only to install the child
restraint flush against the
back of vehicle seat back.
To Recline
Pull out on handle and
push to the top of the child
restraint back.
For upright position, pull out
on handle and position the
child restraint upright.
Harness system MUST be removed to use this
child restraint as a Belt-Positioning Booster.
Remove Harness
Straps from Splitter
Plate
Fully loosen harness
straps. Locate splitter
plate on the back of the
seat and unfasten the
harness straps.
1.
Store Splitter Plate
Raise headrest all the way
up. Store splitter plate
by pushing it through one
opening and out the other.
2.
Remove Harness
Straps
Pull harness through the
slots from the front (1).
Unthread harness from the
chest clip (2).
Unthread harness from the
buckle tongues (3).
Pull harness out of shell
(4).
3.
C-7 Removing Harness System
1
2
3
4
continued on next page.

21 22
C. Basic Use
Remove Buckle
Fully recline the child
restraint. Reach under the
seat between base and shell
and locate buckle’s metal
retainer under the shell.
Rotate metal retainer, then
insert retainer up through
the shell and pad.
From the top, pull buckle
free from shell and pad.
4.
5.
Store the harness straps, chest clip, buckle tongues and
buckle for future use.
C-8 Installing Harness System
Install Buckle
Fit the buckle’s metal
retainer through the slot in
the seat. Red button must
face out.
Reach under seat between
base and shell. Pull
buckle’s metal retainer
completely through pad
and shell.
Check Buckle
Pull up on buckle to make
sure it is secured. The
buckle must not pull out.
Failure to place buckle’s metal retainer
completely through pad and shell can result
in serious injury or death.
1.
2.
3.
continued on next page.

23 24
C. Basic Use
4. Thread Harness Strap
Thread the harness down
through slot on left side
of plastic shell (1) and up
through slot on right side (2).
NOTE: Make sure sewn end
of the harness strap loop
faces the buckle before
starting.
Take both ends of the
harness and make them
even in length.
NOTE: Make sure harness
tightening strap is between
the harness strap and shell
as shown.
1
2
Thread Harness OVER
Metal Bar
Pull harness through the
back. Make sure the
harness goes OVER the
metal bar, BETWEEN metal
bar and plastic handle of the
harness/headrest adjuster.
6.
Attach Harness Straps
to Splitter Plate
Fit loops on harness ends
completely on the splitter
plate.
7.
3
4
5Thread harness straps
through each buckle tongue
(3). Thread the chest clip
(4). Do the same to the other
harness end. Do Not twist
harness.
Push harness ends through
slots in headrest (5).
5. Harness system must be reattached correctly.
Failure to follow these warnings can result in
serious injury or death.
Failure to place harness over the metal bar,
between the metal bar and plastic handle, can
result in serious injury or death.

25 26
C. Basic Use
C-9 Removing Seat Pad for Cleaning
You must remove the harness system to remove the pad.
Remove the Elastic
Straps
Release the elastic straps on
the back and under side of
the seat.
1.
Remove Harness Guides
Adjust headrest to lowest
position. Locate harness
guides.
2.
Upper Harness Guides
Lower Harness Guides
Remove Lower Harness
Guides
Remove both lower harness
guides in bottom of seat by
reaching between the base
and shell from the back.
Push harness guide lip
toward outside of shell
with one hand while pulling
harness guide from the front
with the other to remove.
3.
Back of shell
Back of base
Remove Pad From Shell
From the top, pull pad off
shell and over headrest.
At the bottom, unsnap pad
off shell at one corner,
working pad out from
harness adjustment cover
and unsnap other side.
Remove pad from shell.
4.
Remove Upper Harness
Guides
From the back, use a
screwdriver to press in
on lip of upper harness
guides and pop guides
through the front. Pull
cover off headrest.
5.
Cleaning Seat Pad
Hand wash pad with warm sudsy water, rinse clean and air
dry. Spot clean the harness straps. Do not use bleach or
other harsh cleaners. Do not dry clean.
continued on next page.

27 28
Replace the Seat Pad
Replace seat pad by
reversing order:
Put pad on headrest and
replace harness guides.
Make sure harness
guides tabs go over
metal bar.
Starting from bottom of child
restraint, snap pad on shell;
tuck in pad around harness
adjuster; pull pad up and
over headrest. Attach the
elastic straps. Make sure
pad is under headrest and
replace lower harness
guides. Rethread harness
(see section C-8).
1.
continued on next page.
Do not use child restraint without the seat pad.
Failure to do this can result in serious injury or
death.
Your vehicle’s features may be considerably different than
those pictured here. Consult your vehicle owner’s manual to
help identify your vehicle’s specific features and locations.
D-1 Understanding Your Vehicle
Anchor Brackets
For Top Anchorage
Strap (Tether)
(Forward-Facing Only)
LATCH Anchors
Located in the seat
bight.
Air Bags
Consult your vehicle
owner’s manual for
all air bag locations.
Seat Bight
Vehicle Seat Belts
Consult your vehicle
owner’s manual for
vehicle belt use.
Safety Tip:
To help protect your vehicle seat’s upholstery from
damage, use a single layered towel underneath and
behind child restraint.
To avoid your child being seriously burned,
take the following precautions:
1. Park in the shade or where sun does not directly
hit the child restraint.
2. Cover the child restraint with a sheet or blanket
when not in use.
3. Check for hot seat and buckles before placing
child in child restraint.
D. General Vehicle Installation

30
D-2 Vehicle Seating Position
Some seating positions in your vehicle may not be safe for
this child restraint. Some vehicles do not have a seating
position that can be used safely with this child restraint. If
you are not sure where to place the child restraint in your
vehicle, consult your vehicle owner’s manual or contact Dorel
Juvenile Group Consumer Relations Department.
D. General Vehicle Installation
Use the child restraint only on vehicle seats
that face forward. Do not use on seats that face
the sides or rear of the vehicle.
Safety Tip:
Children are safer when
properly restrained in
rear seating positions
than in the front seating
positions.
According to National Highway Traffic Safety
Administration information, children in rear
seating positions are statistically safer,
whether you have air bags, advanced air
bags, or no air bags at all.
29
Vehicle Belts
If LATCH is not an option,
you must use the vehicle
seat belt system to install
the child restraint. There
are some vehicle belts that
will not work with a child
restraint or will require special attention.
See next page and check your vehicle’s owner’s manual
for specific instructions.
The LATCH System
LATCH (Lower Anchors and
Tethers for CHildren) is a
universal system for installing
child restraints without using
vehicle seat belts.
The LATCH system can ONLY
be used in vehicles that have
the LATCH anchor bars installed and designated LATCH seating
positions. Most vehicles manufactured after September 2002 are
equipped with LATCH.
Check your vehicle owner’s manual to see which seating
positions may be equipped with the LATCH system.
D-3 Choosing LATCH or Vehicle Belts
LATCH Anchor Bars
Do not use both the LATCH belt and vehicle
belt at the same time.

31 32
D-4 Knowing Your Vehicle Belts
Review your vehicle’s owner manual for vehicle seat belt use
with child restraints. This is your best source for information
concerning your vehicle.
Not all vehicle belts will work with this child restraint. This
child restraint must be tightly locked in place at all times,
during travel. You must determine if your vehicles belts are
compatible with this child restraint.
Vehicle Belts
• Automatic/Passive vehicle seat belts
You MUST have a lap belt to install any child restraint. An
automatic (passive) shoulder belt may or may not have a
separate lap belt. Consult your vehicle owner’s manual.
• Vehicle belts in center of the door
or side panel
You must move the child restraint to
another seating location. Consult your
vehicle owner’s manual.
• Vehicle belts that are in front of
the seat bight
You may need to move the child
restraint to another seating location.
Consult your vehicle owner’s manual.
• Do Not Use with inflatable seat belts
You may need to move the child restraint to another seating
location or use LATCH belts only.
• ELR (Emergency Locking Retractor) vehicle belts
These lap and shoulder belts only lock
in a sudden stop or crash, and do not
properly secure a child restraint alone.
Consult your vehicle owner’s manual.
To learn if you have this type of belt,
gently pull the belt all the way out of the retractor (spool), let it
return several inches, then pull on it again. If it moves freely,
it is an ELR belt. If it is locked and will not allow any more
belt to come out, it is a switchable retractor.
ELR lap-only belts MUST NOT be used with
this child restraint.
• Switchable retractor
These belts switch from ELR to ALR (Automatic Locking
Retractor). You must have the vehicle belts in the locking
mode to use them. Follow the instructions in the
installation sections.
• ALR (Automatic Locking Retractor)
These belts lock after pulling the webbing out and letting the
belt go back into the retractor an inch or two. Follow the
instructions in the installation sections.
Vehicle Latch Plates
• Check the Latch Plates
Grasp the tongue portion of
the latch plate (the part that
goes inside the buckle) and
pull straight out, inline with
the lap belt. If the latch
plate does not slide up and
down the vehicle belt, you
have a locking latch plate.
You should not need to use
a locking clip. Consult your
vehicle owner’s manual.
If the latch plate slides up and down on the belt, and you have
an ELR retractor, you MUST use a locking clip to install the
child restraint. You may not need to use the locking clip with
a switchable or ALR retractor. Consult your vehicle owner’s
manual.
Locking
Latch
Plate
Sliding
Latch
Plate
D. General Vehicle Installation
If you have an ELR lap and shoulder belt, review the “Vehicle
Latch Plate” section to see if you need a locking clip.

33
E. Installing Forward-Facing
34
This restraint is certified for
aircraft use only when used
with the internal harness.
This child restraint is
NOT certified for use in
aircraft when used as a
belt-positioning booster,
because aircraft seats do not have shoulder belts.
Use only on forward-facing aircraft seats. Follow instructions
for vehicle installation.
Contact the airline their specific policies.
D-6 Installing on Aircraft E-1 Preparing to Install Forward-Facing
Lap Belt
LATCH Belt
Lap/Shoulder Belt
22-40 lbs (10.1-18 kg) and 34-43 in. (85.1-110 cm) and
at least 1 Year Old.
Forward-Facing using 5-point harness
Never place a child less than one-year old or
weighing less than 22 lbs. forward-facing.

35
E. Installing Forward-Facing
36
The top anchorage strap (tether) is used for the
forward-facing position only.
Note: We strongly recommend that you use the top
anchorage strap (tether) in the forward-facing position.
If your vehicle does not have an anchor bracket, please
see your dealer or a qualified mechanic and have one
installed. The top anchorage strap can greatly improve the
performance of this child restraint.
Storage of Top Anchorage Strap:
When the top anchorage
strap is not in use, tuck the
top anchorage hook (tether)
under the base as shown.
E-2 Adjusting Top Anchorage Strap
(Tether)
Lift up to
loosen
To loosen; Lift up on top
anchorage lock and push
lock toward top
anchorage hook.
To tighten; After the child
restraint is locked into place
with LATCH or vehicle belt,
put knee in child restraint
and push down. Pull on free
end of top anchorage strap.
Pull loose
end to
tighten
To Adjust Top Anchorage Strap (tether):
E-3 Preparing to Install
LATCH Forward-Facing
Routing LATCH Belt
Insert the LATCH hook
through the forward-
facing belt path.
1.
Thread LATCH Across
Pull the LATCH hook
across the back and out
the other side as shown.
Do not twist the belt.
2.
E-4 Install Forward-Facing
With LATCH
Note: Review your vehicle’s owner manual for LATCH belt use.
Do not use the LATCH system along with the
vehicle belt.
Check LATCH belt before each use. Use only if
the belt can be tightened properly and securely.
Failure to follow these warnings can result in
serious injury or death.

E. Installing Forward-Facing
38
37
1. Place Child Restraint in
the Back Seat
Forward-Facing
Place child restraint flush
against the vehicle seat back
forward-facing.
Only use the recline position
to install the child restraint
flush against the back of the
vehicle seat.
Hook LATCH to
Vehicle Anchor
Fasten one LATCH belt hook
to the anchor in the vehicle
seat bight. Repeat for other
side of child restraint.
2.
Installation Tip:
Loosely attach the
tether hook before
attaching the
LATCH belt. Consult
vehicle’s owner
manual for specific
location.
Tighten LATCH Belt
Place knee in the child
restraint. Push down firmly
while pulling up on the loop
to tighten belt.
3.
Tighten Top
Anchorage Strap
Push firmly on the back of
the seat and tighten top
anchorage strap.
4.
Check Belt Tightness
Grasp the child restraint at
the belt path with one hand.
Push and pull the child
restraint from side to side,
forward and back. The child
restraint should not move
more than 1 inch.
NOTE: If it moves more than
1 inch, try reinstalling the
child restraint or try another
seating location.
5.
To Remove LATCH Belt
From Vehicle Anchor
Press down firmly on
adjuster side of child
restraint and press release
button to release tension.
Unhook LATCH from bar
by squeezing spring lever
and twist hook.
7.
6. Place Child in the
Restraint
After checking for hot seat
and buckles, place your
child in the child restraint.
See section C-3.
