Safran MA SIGMA User manual

COPYRIGHT© 2014 Morpho
Osny, France
MorphoAccess® SIGMA Series –Installation Guide May 2014
2014_0000000606-V2
MorphoAccess® SIGMA Series
Installation Guide

MorphoAccess® SIGMA Series –Installation Guide
Warning
2
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
2014_0000000606-V2
May 2014
Warning
COPYRIGHT© 2014 Morpho. All rights reserved.
Information in this document is subject to change without notice and do not
represent a commitment on the part of Morpho. No part of this document may be
reproduced or transmitted in any form or by any means, electronic or mechanical,
including photocopying or recording, for any purpose without the express written
permission of Morpho.
This legend is applicable to all pages of this document.
This manual makes reference to names and products that are trademarks of their
respective owners.

MorphoAccess® SIGMA Series –Installation Guide
Revision History
2014_0000000606-V2
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
3
May 2014
Revision History
The table below contains the history of changes made to the present document.
Version
Date
Reference
Description
01
December 2013
SSE-0000100543-1
Document creation
02
February 2014
2014_0000000606-V1
Minor updates, GPIO wiring update
03
May 2014
2014_0000000606-V2
Precision on installation for UL294
conformity
Warning on space reservation in the wall
for cable passage
Warning on POE module connection
SDAC schematic correction
Recommendation on proximity of radio
product

MorphoAccess® SIGMA Series –Installation Guide
Table of Content
4
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
2014_0000000606-V2
May 2014
Table of Content
Warning ........................................................................................................................................ 2
Revision History ............................................................................................................................ 3
Section 1 : Introduction ................................................................................................................ 9
MorphoAccess® SIGMA Series Terminal ................................................................................. 10
Scope of the document............................................................................................................ 11
Safety Instructions................................................................................................................... 12
Wiring Recommendations ................................................................................................... 12
Caution with battery usage ................................................................................................. 13
Caution with Power over Ethernet (POE) usage.................................................................. 13
Europe information ............................................................................................................. 13
USA information .................................................................................................................. 13
Canada information............................................................................................................. 14
Recommendations for terminal implementation.................................................................... 15
Section 2 : General Description .................................................................................................. 18
Box opening............................................................................................................................. 19
Components of the initial package ......................................................................................... 20
Terminal's front view description............................................................................................ 21
Terminal's rear view description ............................................................................................. 22
MorphoAccess® SIGMA Series Technical Characteristics........................................................ 23
Section 3 : Installation Procedure............................................................................................... 25
Before proceeding to the installation ..................................................................................... 26
Installation .............................................................................................................................. 27
Required tools (not supplied)............................................................................................... 27
Equipment from the initial package to use ......................................................................... 27
Step by step procedure ........................................................................................................ 28
Section 4 : Electrical Interface .................................................................................................... 32
Wiring overview ...................................................................................................................... 33
Power Supply........................................................................................................................... 35
External Power supply ......................................................................................................... 35
POE (Power Over Ethernet) ................................................................................................. 36
Output Relay ........................................................................................................................... 37
Nominal characteristics of relay.......................................................................................... 37

MorphoAccess® SIGMA Series –Installation Guide
Table of Content
2014_0000000606-V2
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
5
May 2014
Example of connection for electrical door locks.................................................................. 37
Tamper Switch......................................................................................................................... 38
Operating principle for the switch....................................................................................... 38
Nominal characteristics of switch block .............................................................................. 38
Wiegand input wiring.............................................................................................................. 39
Wiegand output wiring ........................................................................................................... 40
The controller supports neither LED1 nor LED2 signals....................................................... 40
The controller supports only LED1 signal ............................................................................ 40
The controller supports LED1 and LED2 signals .................................................................. 41
Serial port wiring..................................................................................................................... 42
DataClock Input ................................................................................................................... 42
DataClock Output ................................................................................................................ 43
RS485................................................................................................................................... 43
RS422................................................................................................................................... 44
GPIO wiring ............................................................................................................................. 45
Single Door Access Control (SDAC) implementation ........................................................... 46
Ethernet connection ................................................................................................................ 47
Default Ethernet configuration ........................................................................................... 47
Recommendations for RJ45 wiring...................................................................................... 47
External USB connection ......................................................................................................... 48
Wi-Fi™ / 3G dongle installation .............................................................................................. 49
Micro SD connection ............................................................................................................... 50
Battery..................................................................................................................................... 51
Section 5 : User Interface ........................................................................................................... 52
Modes for controlling access rights ........................................................................................ 53
Introduction ......................................................................................................................... 53
Identification mode ............................................................................................................. 53
Authentication (verification) mode ..................................................................................... 53
Multi-factor mode ............................................................................................................... 54
Proxy mode.......................................................................................................................... 54
External database mode (also called polling mode) ........................................................... 54
Configuring the terminal ......................................................................................................... 56
MorphoAccess® 500 or J Series legacy mode ...................................................................... 56
Bioscrypt 4G Series legacy mode......................................................................................... 56
MorphoAccess® SIGMA Series native mode........................................................................ 57
Anti-tamper / anti-pulling switches ........................................................................................ 58
Section 6 : Accessories, Software Licenses and PC Applications................................................ 59

MorphoAccess® SIGMA Series –Installation Guide
Table of Content
6
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
2014_0000000606-V2
May 2014
Compatible Accessories, Licenses and Software ..................................................................... 60
Compatible PC applications .................................................................................................... 61
Section 7 : Recommendations .................................................................................................... 62
Notice................................................................................................................................... 63
General precautions ............................................................................................................ 63
Areas containing combustibles............................................................................................ 63
Specific precautions for terminals equipped with a contactless smartcard reader ............ 63
Ethernet connection ............................................................................................................ 63
Date / Time synchronization ............................................................................................... 64
Cleaning precautions ........................................................................................................... 64
Legacy mode........................................................................................................................ 64
Micro SD card ...................................................................................................................... 66
Lighting conditions for face detection................................................................................. 66
Main principles........................................................................................................................ 68
Most useful areas for biometric data...................................................................................... 69
Position of finger ..................................................................................................................... 70
Finger height........................................................................................................................ 70
Finger angle ......................................................................................................................... 70
Finger inclination ................................................................................................................. 71
Finger rotation..................................................................................................................... 71
Troubleshooting ...................................................................................................................... 72
How to get the latest versions of documents ......................................................................... 74
Documents concerning the MorphoAccess® terminal ............................................................ 75
Documents about installing the terminal............................................................................ 75
Documents about administrating / using the terminal....................................................... 75
Documents for the developer .............................................................................................. 75
Release note ........................................................................................................................ 76
Troubleshooting ...................................................................................................................... 78
The terminal IP address is unknown or it is not possible to connect to the terminal.......... 78
The sensor is switched off.................................................................................................... 78
The terminal returns erratic responses to Ping commands ................................................ 78
Contacts .................................................................................................................................. 79
Customer service ................................................................................................................. 79
Hotline ................................................................................................................................. 79
Annex 1 : Finger Placement Recommendations...................................................................... 67

MorphoAccess® SIGMA Series –Installation Guide
Table of Content
2014_0000000606-V2
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
7
May 2014
Annex 2 : Bibliography ............................................................................................................. 73
Annex 3 : Support .................................................................................................................... 77

MorphoAccess® SIGMA Series –Installation Guide
Table of Figures
8
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
2014_0000000606-V2
May 2014
Table of Figures
Figure 1: Implementation Recommendations.............................................................................16
Figure 2: Box Opening..................................................................................................................19
Figure 3: Box Content ..................................................................................................................20
Figure 4: MorphoAccess® SIGMA Series terminal front view .....................................................21
Figure 5: MorphoAccess® SIGMA Series terminal rear view.......................................................22
Figure 6: Removing wall frame and screw...................................................................................26
Figure 7: Face camera viewing angle...........................................................................................28
Figure 8: Drilling template ...........................................................................................................29
Figure 9: Wall plate preparation for water tightness..................................................................30
Figure 10: Wall plate fixing ..........................................................................................................30
Figure 11: Cabling preparation ....................................................................................................31
Figure 12: Ground wiring .............................................................................................................33
Figure 13: Cabling layout .............................................................................................................34
Figure 14: Power supply wiring ...................................................................................................35
Figure 15: Output relay wiring.....................................................................................................37
Figure 16: Example of electric latch connection .........................................................................37
Figure 17: Tamper switch wiring .................................................................................................38
Figure 18: Wiegand input wiring .................................................................................................39
Figure 19: Wiegand output wiring...............................................................................................40
Figure 20: Serial port wiring –DataClock ....................................................................................42
Figure 21: Serial port wiring –DataClock ....................................................................................43
Figure 22: Serial port wiring –RS485...........................................................................................43
Figure 23: Serial port wiring –RS422...........................................................................................44
Figure 24: GPIO wiring .................................................................................................................45
Figure 25: SDAC wiring.................................................................................................................46
Figure 26: RJ45 wiring..................................................................................................................47
Figure 27: External USB connection ............................................................................................48
Figure 28: Wi-Fi™ / 3G dongle installation ..................................................................................49

MorphoAccess® SIGMA Series –Installation Guide
Section 1 : Introduction
2014_0000000606-V2
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
9
May 2014
Section 1 : Introduction

MorphoAccess® SIGMA Series –Installation Guide
Section 1 :Introduction
10
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
2014_0000000606-V2
May 2014
MorphoAccess® SIGMA Series Terminal
Congratulations for choosing a MorphoAccess® SIGMA Series Automatic Fingerprint
Recognition Terminal.
MorphoAccess® SIGMA Series provides an innovative and effective solution for access
control applications using Fingerprint Verification or/and Identification.
Among a range of alternative biometric technologies, the use of finger imaging has
significant advantages: each finger constitutes an unalterable physical signature,
developed before birth and preserved until death. Unlike DNA, a finger image is
unique to each individual - even identical twins.
MorphoAccess® SIGMA Series integrates Morpho image processing and feature
matching algorithms. This technology is based on lessons learned during 25 years of
experience in the field of biometric identification and the creation of literally millions
of individual fingerprint identification records.
We believe you will find the MorphoAccess® SIGMA Series fast, accurate, easy to use
and suitable for physical access control.
The MorphoAccess® SIGMA Series offers the following advantages:
high quality optical sensor (IQS quality sensor),
supports multiple input/output interfaces used in the physical access control
industry,
Local Area Network interface for easy interaction with other host systems ; LAN
and WLAN possibilities (Wi-Fi™ and 3G as an option),
compact size for easy installation and integration into your available office space,
intuitive man machine interface with touch panel and display, that is easy to use in
both setup and operational modes,
open architecture, with dedicated applications implemented via MorphoAccess®
SIGMA Series Software Development Kit.
To ensure the most effective use of your MorphoAccess® SIGMA Series terminal, we
recommend that you read this Installation Guide completely.

MorphoAccess® SIGMA Series –Installation Guide
Section 1 : Introduction
2014_0000000606-V2
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
11
May 2014
Scope of the document
This guide deals with the installation of MorphoAccess® SIGMA Series, which is made
up of following list of products:
Biometrics
Contactless smartcard
reader
Water
Resistant
iCLASS®
MIFARE®
DESFire®
NFC
Prox®
MA
SIGMA
Series
MA SIGMA

MA SIGMA WR


MA SIGMA iClass


MA SIGMA iClass
WR



MA SIGMA Multi


MA SIGMA Multi
WR



MA SIGMA Prox


MA SIGMA Prox
WR



NOTA : MA means MorphoAccess®
WR means Water Resistant

MorphoAccess® SIGMA Series –Installation Guide
Section 1 :Introduction
12
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
2014_0000000606-V2
May 2014
Safety Instructions
The installation of this product should be made by a qualified service Person and
should comply with all local regulations.
It is strongly recommended to use a class II power supply at 12V-24V and 1A. min (at
12V) in conformity with Safety Electrical Low Voltage (SELV). The power supply cable
length should not exceed 10 meters.
This product is intended to be installed with a power supply complying with
IEC60950-1, in accordance with the NEC Class 2 requirements; or supplied by a listed
IEC60950-1 external Power Unit marked Class 2, Limited Power source, or LPS and
rated 12VDC, 1A minimum or 24VDC, 0,5A minimum.
In case of building-to-building connection it is recommended to connect 0V to
ground. Ground cable must be connected with the terminal block Power Ground.
Note that all connections of the MorphoAccess® SIGMA Series terminal described
hereafter are of SELV (Safety Electrical Low Voltage) type.
For UL294 installation, length of communication (RS422-RS485/Wiegand) and I/Os
(GPI/GPO) cables must not exceed 30 meters.
Wiring Recommendations
Morpho recommends using a gauge AWG20 for 12V power supply when POE supply
is not used.
The voltage specified is the one measured on the product block connector: 12V-24V (-
15% / +10%)
For information, this table shows the maximum drop voltage voltage observed on the
terminal MorphoAccess® SIGMA Series:
Gauge
AWG
Diameter
(mm)
Maximum
drop
voltage
@ 1m (V)
Maximum
drop
voltage
@ 5m (V)
Maximum
drop
voltage
@ 10m
(V)
20
0.81
0.03
0.17
0.33
22
0.64
0.05
0.26
0.53
24
0.51
0.08
0.42
0.84
V1
V2
L

MorphoAccess® SIGMA Series –Installation Guide
Section 1 : Introduction
2014_0000000606-V2
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
13
May 2014
Drop voltage = loss of power due to wire resistance and its length : V2 = V1 –Drop
voltage
Caution with battery usage
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
Battery must be an UL certified reference.
Caution with Power over Ethernet (POE) usage
After use, the temperature of the POE module (optional) may be high :
after power cut off, wait 5mn before working on connectors area.
Europe information
Morpho hereby declares that the MorphoAccess® SIGMA Series terminal has been
tested and found compliant with following listed standards:
EMC Directive 2004/108/CE.
R&TTE Directive (1999/5/CE).
ROHS Directive 2011/65.
USA information
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Responsible Party:
SAFRAN Morpho,
11, boulevard Gallieni
92130 Issy-les-Moulineaux –France
NOTA : This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy

MorphoAccess® SIGMA Series –Installation Guide
Section 1 :Introduction
14
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
2014_0000000606-V2
May 2014
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Shielded cables must be used with this unit to ensure compliance with category B FCC
restrictions.
Canada information
WARNING TO USERS IN THE CANADA / ATTENTION POUR LES UTILISATEURS AU
CANADA
This device complies with Industry Canada licence-exempt RSS standard(s), and with
ICES 003 standard for version(s) without RFID reader. Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired
operation of the device.
Under Industry Canada regulations, this radio transmitter may only operate using an
antenna of a type and maximum (or lesser) gain approved for the transmitter by
Industry Canada.
To reduce potential radio interference to other users, the antenna type and its gain
should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not
more than that necessary for successful communication.

MorphoAccess® SIGMA Series –Installation Guide
Section 1 : Introduction
2014_0000000606-V2
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
15
May 2014
Recommendations for terminal implementation
Every installation is unique. Sometimes the issues are well defined and can be
handled in a standard fashion; sometimes the issues are very specific and may not be
immediately recognizable.
Morpho recommends following these steps for a successful installation:
Plan the installation - Choose the type of hardware required, decide if a network is
required, and decide on the location and number of required terminals.
Unpack all items - Unpack all items and check against the packing list.
Install network hardware components - Install the cabling and components
needed to run the system.
Install software - Install the software needed to set up the terminals.
Pre-configure device - Connect the terminals to the Ethernet, supply power to the
terminals, and pre-configure the terminals.
Mount devices - Mount the terminals in their final locations
Power distribution and device hook up - Connect the terminals wiring via the back
panel.
Power-up procedure - Check the power connections, verify if battery is attached
and then start the system safely. First Boot Assistant screen is displayed, where
you can perform fundamental configuration.

MorphoAccess® SIGMA Series –Installation Guide
Section 1 :Introduction
16
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
2014_0000000606-V2
May 2014
To secure properly an access, Morpho recommends installing the MorphoAccess®
SIGMA Series terminal as a part of the typical Access Control environment, described
in the figure below.
Figure 1: Implementation Recommendations
This environment comprises:
The MorphoAccess® SIGMA Series terminal itself
Its role is to perform one-to-many biometric identification or one-to-one biometric
verification, i.e. to identify the individual who is presenting his finger on the terminal
sensor by comparing his biometric data with the references previously stored in the
terminal database (in the form of biometric templates) or to verify his identity using
the reference stored in a contactless card presented to the terminal.
An Access Controller (3rd party product)
The Controller is the element which controls the access rights of the individuals to the
secured area. For that reason, it must be located in the secured area.
ACCESS CONTROL
SYSTEM
(*) OR EQUIVALENT
NON SECURED
AREA
ACCESS
CONTROLLER
TCP/IP, Wiegand, Dataclock, RS485 or RS422
ELECTRIC
LATCH (*)
SECURED
AREA
Dry Contact
MorphoAccess®
Sigma Terminal
Dry Contact
ALARM

MorphoAccess® SIGMA Series –Installation Guide
Section 1 : Introduction
2014_0000000606-V2
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
17
May 2014
The individuals who are authorized to access the secured area have their User ID
listed in a so-called "White List" (in contrast with a black list).
The MorphoAccess® SIGMA Series terminal and the Controller are communicating
according to one of the TCP/IP, Wiegand, Dataclock or RS485 protocols:
The MorphoAccess® SIGMA Series terminal sends User ID to the Controller
The Controller sends its decision to the MorphoAccess® SIGMA Series terminal
(which displays access granted or access denied depending on the answer)
The MorphoAccess® SIGMA Series terminal sends an alarm signal to the Controller
as soon as a malicious operation is detected (terminal pulled out from the wall or
opened for maintenance operations); refer the paragraph dealing with anti-
pulling and anti-tamper switches for more explanations.
The Controller is part of the global Access Control System of the secured area, which
for instance can administrate the White List of the Controller and receive diaries of
the decisions taken by the Controller.
An Alarm (3rd party product)
This element is connected to the MorphoAccess® SIGMA Series terminal through a
dry contact.
The MorphoAccess® SIGMA Series terminal sends the command to activate the Alarm
as soon as a malicious operation (terminal pulled out from the wall or having its
bottom cover opened out of maintenance operations) is detected; refer the
paragraph dealing with anti-pulling and anti-tamper switches for more explanations.
A Door Electric Latch or equivalent (3rd party product)
This element once activated opens the access. The Controller is the one which sends
the command to activate the latch if access is granted (i.e. if the individual's User ID is
listed in the Controller White List). Connection between these two elements is done
through a dry contact.

MorphoAccess® SIGMA Series –Installation Guide
Section 2 :General Description
18
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
2014_0000000606-V2
May 2014
Section 2 : General
Description

MorphoAccess® SIGMA Series –Installation Guide
Section 2 : General Description
2014_0000000606-V2
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
19
May 2014
Box opening
At the box opening, components shall be extracted from the protection casing as
depicted in the pictures below.
Extract the wall plate (which is not screwed to the terminal) and keep it separate until
the installation of the terminal is completed. The screwing of the product to the wall
plate is the last stage of the installation.
The protection accessory provided is optional: it is recommended for outside
installation (to protect biometric module against water)
Figure 2: Box Opening
2
1

MorphoAccess® SIGMA Series –Installation Guide
Section 2 :General Description
20
MORPHO DOCUMENT –REPRODUCTION AND DISCLOSURE FORBIDDEN
2014_0000000606-V2
May 2014
Components of the initial package
Figure 3: Box Content
1. One (1) Terminal’s body
2. One (1) Wall frame
3. One (1) Battery
4. One (1) Protection accessory (for WR products only, which usage is optional)
+
+
