Sagem MY C2-2 User manual

Mobile Phones Division
Tel. [phone] - Fax [phone] - www.sagem.com
Le Ponant de Paris - 27, rue Leblanc - 75512 PARIS CEDEX 15 - FRANCE
SAGEM SA - Société anonyme à directoire et conseil de surveillance
capital : 36 405 229 € - 562 082 909 RCS PARIS
ENGLISH
*251521609*
SAGEM SA
251521609_myC-x_couv-en.qxd 25/03/04 16:19 Page 1

This model is a dual band phone (GSM 900 MHz and
DCS 1800 MHz) and therefore can be used abroad, in
accordance with the roaming agreements between
networks.
We remind you that this phone has been approved to meet
European standards.
We recommend that you read this handbook carefully
before using your phone efficiently.
WARNING
Depending on the configuration of your network and the
type of subscription/SIM card, some functions may not be
available.
Your telephone is only compatible with 3 V SIM cards.
Make sure your SIM card is compatible with your phone:
otherwise, you will see the message "SIM LOCKED" when
switching the phone on.
The brand name SAGEM forms part of SAGEM SA.
AT is a brand registered by Hayes Microcomputer Products Inc.Hayes is
a brand registered by Hayes Microcomputer Products Inc.T9™ Text input
is a brand registered by © Tegic Communications Inc.
T9 is protected by one or more of the following US patents: 5,818,437,
5,953,541, 5,187,480, 5,945,928, 6,011,554 and others are pending
worldwide.
The WAP navigator is the exclusive property of Openwave. For this
reason, it is forbidden to modify, translate, disassemble or even decompile
all or part of the software that makes up the navigator.
251521609_myC2-2_lu_2e-3ecouv_en.fm Page 1 Lundi, 26. avril 2004 4:17 16

1
Conformance Document
251521609_myC2-2_lu_en.book Page 1 Vendredi, 21. mai 2004 1:18 13

2
Menus
Phonebook
Phonebook menu
Messages
Compose
Inbox
Drafts
Options
Memory
WAP
Arcade Box
Sounds
Ring tones
Vibrate
Silent mode
Beeps
Background
Colours
Wallpapers
Greeting msg
Settings
Date/Time
My objects
Languages
Networks
Contrast
Shortcuts
Active flip
Calls
Calls forwarded
View last calls
Counters
Display number
Call waiting
Auto redial
Blacklist
Answer phone number
Local info
Security
PIN number
Phone code
Confidentiality
Operator
Accessories
Calculator
Converter
Alarm
Timer
Data
Services
251521609_myC2-2_lu_en.book Page 2 Vendredi, 21. mai 2004 1:18 13

3
Contents
Page 2 MENUS
Page 7 DESCRIPTION
Page 8 NAVIGATION PRINCIPLES
Page 9 HOME PAGE
Page 10 ACTIVATING YOUR PHONE
Information on the SIM card
Installing the SIM card and the battery
Charging the battery
Page 13 MY PHONE IN 5 MINUTES
Getting started
PIN Number
Setting time and date
Network
First call
Receiving a call
Switching the phone off
Page 17 FIRST SETTING: RING TONE
Volume and ring tone
Page 19 PHONEBOOK
Using the phonebook
Phonebook menu
Call groups
Page 24 MESSAGES
Composing messages
Receiving messages
Inbox
Drafts
Sending options
Memory
251521609_myC2-2_lu_en.book Page 3 Vendredi, 21. mai 2004 1:18 13

4
Contents
Page 30 WAP
The WAP Menus
Configuring WAP parameters
WAP Logging on
Downloading objects
WAP Logging off
Page 33 GAMES
Arcade Box
Page 34 SOUNDS
Volume and ring tone
Vibrate
Silent mode
Beeps
Page 36 BACKGROUND
Colours
Wallpapers
Greeting message
Page 38 SETTINGS
Date / Time
My Objects
Languages
Networks
Contrast
Short cuts
Active flip
Page 42 CALLS
Calls forwarded
View last calls
Counters
Display number
Call waiting
Automatic redial
Blacklist
Voice mail number
Local info
251521609_myC2-2_lu_en.book Page 4 Vendredi, 21. mai 2004 1:18 13

5
Contents
Page 48 SECURITY
PIN number
PIN number 2
Phone code
Confidentiality
Operator code
Page 51 ACCESSORIES
Calculator
Converter
Alarm
Timer
Data
Page 55 SERVICES
Page 56 CARE AND SAFETY INFORMATION
Safety
SAR
Advice for limiting exposure to radiofrequency (RF) fields
Page 58 WARRANTY
Page 61 END USER LICENCE AGREEMENT (EULA), FOR THE
SOFTWARE
Page 65 TROUBLESHOOTING
Page 68 INDEX
251521609_myC2-2_lu_en.book Page 5 Vendredi, 21. mai 2004 1:18 13

6
Your phone package - Accessories
When opening the box, please check that all following items are included:
1 - Phone
2 - Mains charger
3 - Battery
4 - User guide
Accessories
The following accessories are available and can be ordered:
Hands-free kit
Additional battery
Additional charger
Data Cable
For more information: www.planetsagem.com
4
2
3
1
251521609_myC2-2_lu_en.book Page 6 Vendredi, 21. mai 2004 1:18 13

7
Description
Programmable keys and Shortcut keys
Stop key:
Hold down: Switch the phone off
Press briefly:
During a call: Reject a call - Hang up
Inside the menus: Return to the home page.
Start key: Press briefly: Switch the phone on
In call context: Call - Answer a call - Hands-free mode
Left programmable key:
From the home page: Gives access to some functions (short cuts)
Inside the menus: Cancel (or go back) as shown on the screen
During a call: Reduce the volume
Right programmable key:
From the home page: Gives access to some functions (short cuts)
Inside the menus: Accept, choose as shown on the screen
During a call: Increase the volume
Up key: Previous menu / increase the value / increase the volume level
during a call
Down key: Next menu / reduce the value / decrease the volume level
during a call
∗ Key :
Previous input field
Hold down: From the home page: Silent mode
When receiving a call:A short press will cancel the ring tone
When setting the ring tone: Activates or deactivates the ring tone
# Key:
Next input field
251521609_myC2-2_lu_en.book Page 7 Vendredi, 21. mai 2004 1:18 13

8
Navigation principles
These basic principles bring a great deal of intuitiveness to your phone
All the active areas are on a white background (icon selector,
programmable keys, menu selector, list of choices)
Accept by pressing the right programmable key .
Cancel by pressing the left programmable key .
The thumbnails shown on the bottom of your screen refer to the
Programmable keys (and not to the left/right keys).
When navigating inside the menus, a title always reminds you of the
previous level.
The up / down arrows are used to navigate from one menu to
another.
The right programmable key is used to go from a menu to a sub-
menu.
The left programmable key is used to go from a sub-menu to a
menu.
The first menu level is represented by a large animated icon, shown in
the middle of the screen.
The second menu level is represented by a large static icon, shown in the
middle of the screen.
The lowest sub-menus are lists.
The Stop key (press briefly) is used to go back to the home page (the
function in progress will be given up).
2nd level
3nd level
1st level
251521609_myC2-2_lu_en.book Page 8 Vendredi, 21. mai 2004 1:18 13

9
Home page
The home page shows following information
1 - The title bar icons:
Battery level
Calls forwarded
Call (making the call)
Call (hands free)
SMS (receving a SMS - the inbox memory is full))
Silent mode
You have received a voice mail
WAP (@)
Home zone
HPLMN / roaming
Protected WAP logon
Protected WAP logon icon with certificate
Signal strength level (5 bars).
2 - Date and time , in digital or analogue mode
3 - Network provider
4 - The thumbnail indicates that the menus can be
accessed by pressing the up and down arrows:
the main "menu" tab shows that the menu can be accessed via
the
up / down arrows.
The following information may also be displayed:
"1 message received"; or "1 call".
They can be deleted by pressing the Stop key briefly.
Menu
fri 9 APR
251521609_myC2-2_lu_en.book Page 9 Vendredi, 21. mai 2004 1:18 13

10
Activating your phone
To use your phone, you will need a card called "SIM
Card". It contains all the information needed by the
network, as well as personal information that can not be
modified.
Secret codes (PIN(s): Personal Identification Numbers),
these codes allow you to protect the access to your SIM
card.
Phonebook,
Messages,
How special services work.
Your phone is compatible with the different SIM cards
offered by operators.
It is also compatible with the SIM/WIM cards (cards
containing the WIM module in addition (WIM = Wireless
Identity Module) that are used for secure WAP
connections.
Information on the SIM card
WARNING
This card must be handled and kept carefully so that it does not get damaged. Should you loose your SIM card,
please contact your network provider.
Please keep your SIM card out of reach of young children.
251521609_myC2-2_lu_en.book Page 10 Vendredi, 21. mai 2004 1:18 13

11
Activating your phone
The SIM card is inserted under the phone's battery.
Please make sure that the phone is switched off and the
charger disconnected.
Turn your phone over. Pull the back catch up (1) and take
the battery out (2).
Remove the back cover by lifting bottom end first.
Slide the SIM card, with cut corner as shown on the
phone, into the card holder with fold face down.
Place the battery by positioning first the top of it, as shown
on the battery.
Press to lock.
Installing the SIM card and the battery
2
1
2
1
3
4
5
1
2
3
4
5
251521609_myC2-2_lu_en.book Page 11 Vendredi, 21. mai 2004 1:18 13

12
Activating your phone
Your phone is powered by a rechargeable battery. A new
battery must be charged for at least 4 hours before being
used for the first time. It reaches its optimum capacity
after a few cycles of use.
If the battery has run down, you will have an icon (empty
battery) flashing on the screen of your phone. Put it on
charge for at least 15 minutes before making any calls, in
order not to be cut off in the middle of a call.
Charging the battery
Connect the charger to a mains socket.
Plug the end of the cable into the bottom connector of the
phone.
The battery is charging up, the battery charging light
flashes to indicate charging. When the battery is fully
charged, the charging stops on its own. Disconnect the
cable.
When charging, the battery may warm up slightly.
Charging the battery
WARNING
There is danger of explosion if the battery is placed in an incorrectly way or if it is exposed to fire.
Do not short circuit it.
The battery does not have any part that you can change.
Do not try to open the battery casing.
Use only the appropriate chargers and batteries as shown in the phone manufacturer's catalogue.
The use of other types of chargers or batteries may be dangerous or invalidate the warranty.
Used batteries must be disposed of in the appropriate places.
We advise you to take the battery out if you plan not to use the phone for extended periods.
You are strongly advised not to connect your phone to the charger if it doesn’t contain a battery.
The charger is a safety step-down transformer, it is forbidden to modify, alter or replace it by another component
(power supply plug, etc.).
251521609_myC2-2_lu_en.book Page 12 Vendredi, 21. mai 2004 1:18 13

13
My phone in 5 minutes
Switch the phone on by pressing the Start key. A short display
appears.
Your phone may ask for the PIN code whenever you switch it on, if such
an option has been activated.
Enter the 4-8-digit code , which your network provider has given you.
These numbers do not appear on the screen for security reasons.
Press the right programmable key to confirm.
If the screen shows "SIM MISSING", hold down the Stop key to
switch your phone off and check that your SIM card is correctly
positioned.
Getting started
You are now ready to use your phone for the first time.
PIN Number
This is your PIN code of your SIM card.
WARNING
If a wrong PIN number is entered three times, your SIM card will be blocked. You must then:
- Enter **05*.
- Enter the PUK (Personal Unblocking Key) code provided by your operator, and confirm .
- Enter your PIN number and confirm .
- Enter your PIN number again and confirm .
After 5 or 10 (depending on the type of SIM card) incorrect entries, the SIM card will be definitely blocked. You
must then contact your network provider to get a new one.
Delete OK
PIN number?
****
251521609_myC2-2_lu_en.book Page 13 Vendredi, 21. mai 2004 1:18 13

14
My phone in 5 minutes
If the battery has completely run down or been taken out, you will be
asked to confirm the time and date.
Setting the date:
Set the date either by typing it in numerically or by using the up / down
arrows to alter the display.
Use the key (or key ) to access the next (or previous) data input
field.
Once the date is correct, press the right programmable key to
confirm .
Setting the time: Same procedure as above.
From now on, the phone will search for a network on which calls can be
made. When one has been found, its name will be displayed on the
screen. You are then ready to make or receive a call.
Setting time and
date
The first time the phone is used, the time and date will need to be set.
Network
If your provider's icon (or logo) is displayed on the screen, calls can be made on its network.
If the letter R and a network name are displayed, calls can be made on that particular network.
If the letter R is displayed without any network name, only the emergency services can be called (ambulance,
police, fire brigade).
If the network icon flashes, the phone is permanently searching for the network. There is no network available.
The signal strength symbol, shown on the top right-hand corner, displays the quality of the reception. If it
indicates less than three bars, please search for better reception in order to call in good conditions.
251521609_myC2-2_lu_en.book Page 14 Vendredi, 21. mai 2004 1:18 13

15
My phone in 5 minutes
Please dial the number.
Press the Start key.
During the call, an icon (a phone) will be flashing on the screen, and
dialling tones may inform you of the making of the call.
When the person you have called answers, the call icon stops flashing.
You can set the sound level (volume) using the left and right
programmable
, keys .
At the end of the conversation press the Stop key to hang up.
First call
International call
Press 0 (long press) to display "+", dial the country code without waiting for the dialling tone and then the number
you require.
Emergency services
Depending on the network providers, you may contact the emergency services with or without your SIM card.
You will need to be in an area covered by the network.
To call the international emergency services, please dial
112 and then press the Start key.
251521609_myC2-2_lu_en.book Page 15 Vendredi, 21. mai 2004 1:18 13

16
My phone in 5 minutes
When you receive a call, the number of the caller is displayed on the
screen if such an option has been activated.
Press the Start key or the right programmable key to answer,
and speak.
To reject a call, press the Stop key or the left programmable
key .
To stop the ring tone or the vibrate, without rejecting the call,
press the key.
All the numbers corresponding to incoming and outgoing calls are
displayed in the list of recent calls.
Press the Stop key for one second.
The end message is displayed. The phone switches off.
Receiving a call
WARNING:
By pressing the Start key twice, you will be using the speaker phone
mode facility. Please do not put the phone to your ear.
Switching the phone off
251521609_myC2-2_lu_en.book Page 16 Vendredi, 21. mai 2004 1:18 13

17
First setting: Ring tone
In the home page , press the down arrow to access the main
menus.
The first menu displayed is Phonebook .
Press the down arrow four times to access the Sounds menu.
Enter this menu by pressing the right programmable key .
You can access the second level of the menu which is made up of:
Ring tones, Vibrate, Silent mode, beeps.
The first sub-menu offered is Ring tones .
Enter the menu by pressing the right programmable key .
Volume and ring
tone
This menu allows you to allocate a ring tone to each type of event.
251521609_myC2-2_lu_en.book Page 17 Vendredi, 21. mai 2004 1:18 13

18
First setting: Ring tone
You can assign a particular ring tone to each type of event: for the calls,
for the messages or for the alarm. Select one of them by pressing the
up / down arrows, and confirm.
Enter the menu by pressing the right programmable key .
Using the up / down arrows select the ring tone from the list
given.
Enter by pressing the right programmable key .
For every new selection, you can listen to the ring tone while you are
selecting or you can mute the phone by pressing the
Silent mode key
to cancel the sound.
Adjust the volume using the up / down arrows .
The volume is adjusted over a scale of 1 to 4.
The ring tone is played at the chosen level whenever a change is made.
If you select the "+", the volume of the ring tone will increase in volume.
Confirm by pressing the right programmable key .
251521609_myC2-2_lu_en.book Page 18 Vendredi, 21. mai 2004 1:18 13
