Sagem myX-1 twin User manual

Mobile Phones Division
www.sagem.com/mobiles
Le Ponant de Paris - 27, rue Leblanc - 75512 PARIS CEDEX 15 - FRANCE
SAGEM SA - Société anonyme à directoire et conseil de surveillance
capital : 35 500 000 € - 562 082 909 RCS PARIS
SAGEM SA
myX-1_twin_courte.qxd 21/12/2004 9:55 Page 1

1
You have just bought a mobile phone and we congratulate you on your choice.
Your phone will allow you to use different international networks (GSM 850 MHz
and PCS 1900 MHz) depending on the roaming agreements between the
operators.
We would like to remind you that this phone is approved to European standards.
To get the most out of using your phone, we recommend that you read this
manual carefully and keep it handy for future reference if needed.
WARNING
According to the configuration of the networks and associated subscriptions,
certain functions may not be available (usually indicated by *).
Make sure your SIM card is compatible with your phone. If an incompatible SIM
card is inserted, a message will be displayed when switching on your phone. For
further information, contact your Operator.
The SAGEM logo and trademark are the property of SAGEM SA.
AT is a registered trademark of Hayes Microcomputer products Inc.
Hayes is a registered trademark of Hayes Microcomputer Products Inc.
T9™ Text Input is a registered trademark of ©Tegic Communications Inc.
T9 is licensed under one or more of the following U.S. Patents: 5,818,437, 5,953,541,
5,187,480, 5,945,928, 6,011,554 and additional patents are pending worldwide.
Compatibility of your SIM
card
Your phone is compatible
with SIM 3V cards only.
251873962_myX-1a Twin_lu_en.book Page 1 Vendredi, 7. janvier 2005 3:00 15

2
Conformance Document
SAGEM SA declare under its sole responsibility that the product Dual Band GSM/PCS Type A2005 conforms
to the requirements of the following EEC directives:
EEC Directive 1999/5/CE
Safety EN 60950: 2001
Low voltage directive 73/23/CEE
Network 3GPP TS 51.010-1
TBR 19 Edition 5
TBR 20 Edition 3
EN 301511 v7.0.1
Health EN 50360
EN 50361
FCC Conformance Document
FCC Part 24
Network NAPRD03 v3.1.2
Health IEEE P1528/D1.2
251873962_myX-1a Twin_lu_en.book Page 2 Vendredi, 7. janvier 2005 3:00 15

3
Safety Information for Wireless handled phones
Use of your phone is subject to safety rules designed to protect the user and his or
her environment.
- Your wireless handheld portable phone is a low power radio transmitter and
receiver. When it is ON, it receives and also sends out frequency (RF) signals.
- In August, 1996, the Federal Communications Commissions (FCC) adopted RF
exposure guidelines with safety levels for handheld wireless phones. Those
guidelines are consistent with the safety standards previously set by both U.S.
and international standards bodies:
ANSI C95.1 (1992) (*)
NCPR Report 86 (1986) (*)
ICNIRP (1996) (*)
- Those standards were based on comprehensive and periodic evaluations of the
relevant scientific literature. For example, over 120 scientists, engineers, and
physicians from universities, government health agencies, and industry
reviewed the available body of research to develop the ANSI Standard (C95.1).
- The design of your phone complies with the FCC guidelines (and those
standards).
- For body worn operation, this phone has been tested and meets FCC RF
exposure guidelines when used with an accessory that contains no metal and
that positions the handset a minimum of 1.5 cm from the body.
Use of other accessories may not ensure compliance with FCC RF exposure
guidelines.
Exposure to Radio Frequency Signals
(*) American National Standards Institute; National Council on Radiation Protection and Measurements; International
Commission and Non-Ionizing Radiation Protection.
251873962_myX-1a Twin_lu_en.book Page 3 Vendredi, 7. janvier 2005 3:00 15

4
Safety Information for Wireless handled phones
- Normal position: hold the phone as you would any other phone with the upper
zone (back of the LCD display) pointed up and over your shoulder.
- Tips on efficient operation: for your phone to operate most efficiently: do not
touch cover unnecessarily the top part of the phone with your hand. This would
cover the integrated antenna and affect call quality and may cause the phone to
operate at a higher power level than otherwise needed.
- Check the laws and regulations on the use of wireless telephones in the areas
where you drive. Always obey them. Also, if using your phone while driving while
driving please:
• Give full attention of driving, driving safely is your first responsibility
• Use hands-free operation, if available
• Pull off the road and park before making or answering a call if driving
conditions so require.
- Most modern electronic equipment is shielded from RF signals. However,
certain electronic equipment may not be shielded against the RF signals from
your wireless phone.
- Some phone accessories allow to reduce the radiation interferences of the
phone. Please contact your distributor.
Pacemakers The Health Industry Manufacturers Association recommends that a minimum
separation of six (6”) inches be maintained between a handheld wireless phone
and a pacemaker to avoid potential interference with the pacemaker. These
recommendations are consistent with the independent research by and
recommendations of Wireless Technology Research.
Phone Operation
Driving
Electronic Devices
251873962_myX-1a Twin_lu_en.book Page 4 Vendredi, 7. janvier 2005 3:00 15

5
Safety Information for Wireless handled phones
Persons with pacemakers:
- Should ALWAYS keep the phone more than six inches from their pacemaker
when the phone is turned ON
- Should not carry the phone in the breast pocket
- Should use the ear opposite to the pacemaker to minimize the potential for
interference
- If you have any reason to suspect that interference is taking place, turn your
phone OFF immediately.
Hearing Aids Some digital wireless phones may interfere with some hearing aids. In the event of
such interference, you may want to consult your service provider.
Other Medical Devices If you use any other personal medical device, consult the manufacturer of your
device to determine if they are adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this information.
Turn your phone OFF in health care facilities when any regulations posted in these
areas instruct you to do so.
Hospitals or health care facilities may be using equipment that could be sensitive to
sensitive external RF energy.
Vehicles RF signals may affect improperly installed or inadequately shielded electronic
systems in motor vehicles. Check with the manufacturer or its representative
regarding your vehicle. You should also consult the manufacturer of any equipment
that has been added to your vehicle.
Posted Facilities Turn your phone OFF in any facility where posted notices so require.
FCC regulations prohibit using your phone while in the air. Switch OFF your phone
before boarding an aircraft.
Aircraft
251873962_myX-1a Twin_lu_en.book Page 5 Vendredi, 7. janvier 2005 3:00 15

6
Safety Information for Wireless handled phones
To avoid any interfering with blasting operations, turn your phone OFF when in a
“blasting area” or in areas posted: “Turn off two-way radio”. Obey all signs and
instructions.
- Turn your phone OFF when in any area with a potentially explosive atmosphere
and obey all signs and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even death.
- Areas with a potentially explosive atmosphere are often but not always clearly
marked. They include fueling areas such as gasoline stations; below deck on
boats, fuel or chemical transfer or storage facilities; vehicles using liquefied
petroleum gas (such as propane or butane); areas where the air contains
chemicals or particles, such as grain, dust, or metal powders; and any other area
where you would normally be advised to turn off your vehicle engine.
An air bag inflates with great force. DO NOT place objects, including both installed
or portable wireless equipment, in the area over the air bag or in the air bag
deployment area. If in-vehicle wireless equipment is improperly installed and the air
bag inflates, serious injury could result.
- Only us the appropriate chargers recommended in the manufacturer’s catalog.
Using another charger may prove dangerous and could invalidate the warranty
of your phone.
- The main power socket should be easily accessible.
- Make sure that the main voltage corresponds to the level marked on the charger
identification plate.
Blasting Areas
Potentially Explosive Atmospheres
For Vehicles equipped with Air Bag
Electrical Safety
251873962_myX-1a Twin_lu_en.book Page 6 Vendredi, 7. janvier 2005 3:00 15

7
Safety Information for Wireless handled phones
- Do not try to open your phone and repair it yourself. The manufacturer cannot be
held liable for any resulting damage.
- Any work done by an unqualified and unauthorized person will invalidate your
warranty.
- Do not use your phone in humid places (bathroom, swimming pool, etc.). Protect
it from splashing water and other liquids.
- Do not expose your phone to extreme temperatures.
- Keep your phone out of reach of small children. Do not allow them to play with
it, it is not a toy.
- Only use your phone with original accessories. Failure to comply with these rules
will invalidate your warranty.
- Remember to disconnect the charger before removing the battery.
- The physical and chemical processes used in rechargeable batteries mean that
temperature limits must be followed during rapid charging. Your terminal
automatically protects the batteries from extreme temperatures.
- If the phone is disconnected from the battery for an extended period of time, it
will lose the time and the recorded voice messages.
General Precautions
WARNING
- The manufacturer cannot be held
liable for any failure to comply with
the above recommendations or for
any misuse.
- The software program developed
by SAGEM SA remains the
exclusive property of SAGEM SA.
It is therefore highly prohibited to
modify, translate, decompile or
disassemble this software program
or any part thereof.
- SAGEM SA may not be held
responsible for the contents of
messages, software or objects
downloaded and/or for any direct or
indirect consequential damage to
the phone itself.
251873962_myX-1a Twin_lu_en.book Page 7 Vendredi, 7. janvier 2005 3:00 15

8
Safety Information for Wireless handled phones
IMPORTANT
- This phone, like any PCS phone, operates using radio signals, PCS and landline
networks, and user-programmed functions. As a consequence a connection in
all conditions cannot be guaranteed. Therefore you should never rely solely
upon any PCS phone for essential communications (e.g. medical emergencies).
- To make or receive any calls, this phone must be switched on and in service area
with adequate PCS signal strength. Emergency calls may not be possible on all
PCS networks or when certain network services and/or phone features are in
use. Check with local Service Providers.
- When making an emergency call, remember to give all the necessary
information as accurately as possible. Remember that your PCS phone may be
the only means of communication at the scene of an accident - do not terminate
the call until given permission to do so.
- If certain features are in use (such as Keyguard), you may first need to turn those
features off before you can make an emergency call. Consult this manual and
your local PCS Service Provider.
- If the phone is not on, press .
- Key in emergency number for your present location (e.g. 911 or other official
emergency number).
- Press .
- If you dial 911 during a call, the phone terminates the current call and
attempts to make a call to the emergency number 911.
Your phone may cause TV or radio interference (e.g. when using telephone in close
proximity of receiving equipment). The FCC/INDUSTRY Canada can require you to
stop using your telephone if such interference cannot be eliminated. If you need
assistance, contact your local dealer.
This device complies with parts 15 and 68 of the FCC rules. Operation is subject to
the condition that this device does not cause harmful interferences.
Emergency Calls
Emergency Calling
FCC/INDUSTRY CANADA NOTICE
251873962_myX-1a Twin_lu_en.book Page 8 Vendredi, 7. janvier 2005 3:00 15

9
Functions at a glance
Switch on
Press .
Call
Dial the number then press .
Answer
Press .
Hang up
Press .
Switch off
Press (long press).
Hands-free
To communicate, press .
Lock and unlock the keyboard from the standby screen
Press ∗ then OK .
Redial last number
Press twice .
Make a call from a number stored in the directory
- By name: enter the first letter of the name, press , scroll down the list to
find your correspondent, then press to call.
- By location in the directory: enter the location number then press
∗ to call.
251873962_myX-1a Twin_lu_en.book Page 9 Vendredi, 7. janvier 2005 3:00 15

10
Menus at a glance
Enter using S or T
Navigate using S or T
Validate using OK
Quit or return to the previous
menu using C
According to the model of your
phone, to the configuration of the
networks and associated
subscriptions, certain functions
may not be available (indicated
by *).
Depending on the model, the
phone menus will appear as
listed below:
Services
Directory
Directory menu
Sort by location
Create record
Call groups
Available memory
Personal numbers
Quit
Text messages
Write new...
Call services
Call forwarding
View last numbers
Duration and cost of calls (*)
Display numbers
Double call
Automatic redial
Blacklist
Voice mail number
Local information (*)
Ringing and beeps
Volume and choice of music
Call groups
Personalised ringing
tone (*)
Vibrate (*)
Silent mode
Beeps
Controls
Customization
Select language
Automatic response
Network selection
Setting time/date
Display contrast
Currency converter
Security
Keyboard locking
PIN number
PIN number 2 (*)
Phone code
Confidentiality messages
Operator password (*)
Limit incoming calls (*)
Limit outgoing calls (*)
Pre-set directory (*)
Costs (*)
Accessories
Calculator
Alarm
Timer
Car kit (*)
Data parameters (*)
Games
251873962_myX-1a Twin_lu_en.book Page 10 Vendredi, 7. janvier 2005 3:00 15

11
Glossary
Outgoing call A call made from your phone.
Incoming call A call received by your phone.
SIM card The card containing your subscription and access
rights to services. The detachable part is the
“micro-SIM”.
PIN The personal code linked to your SIM card.
PIN2 The second personal code linked to your SIM card to
access certain functions (*).
Phone code The phone code is a secret code intended to protect
the phone in case of theft.
IMEI The identification number of your phone.
SMS or EMS Short Message Service or Extended Message
Service: sending and receipt of text messages,
icons, animated screen savers and melodies.
Service provider Company which manages the network subscription.
251873962_myX-1a Twin_lu_en.book Page 11 Vendredi, 7. janvier 2005 3:00 15

12
Contents
Safety Information for Wireless handled phones .............................................................. 3
Exposure to Radio Frequency Signals ......................................................................................... 3
Phone Operation........................................................................................................................... 4
Driving........................................................................................................................................... 4
Electronic Devices ........................................................................................................................ 4
Aircraft .......................................................................................................................................... 5
Blasting Areas............................................................................................................................... 6
Potentially Explosive Atmospheres...............................................................................................6
For Vehicles equipped with Air Bag..............................................................................................6
Electrical Safety ............................................................................................................................ 6
General Precautions ..................................................................................................................... 7
Emergency Calls........................................................................................................................... 8
Emergency Calling........................................................................................................................ 8
FCC/INDUSTRY CANADA NOTICE ............................................................................................ 8
Presentation of the phone ................................................................................................. 16
Function keys.............................................................................................................................. 18
Alphanumeric keyboard .............................................................................................................. 19
Key 1........................................................................................................................................... 19
Key ∗........................................................................................................................................... 19
Display ........................................................................................................................................ 20
Exchanging the front and back panel ......................................................................................... 21
Getting started .................................................................................................................... 22
Information on the SIM card ....................................................................................................... 22
Installing the SIM card and the battery ....................................................................................... 23
Charging the battery ................................................................................................................... 24
Switching on/switching off, starting up........................................................................................ 25
Setting Time and Date ................................................................................................................ 26
Searching for a network.............................................................................................................. 26
Switching off ............................................................................................................................... 27
Recommendation........................................................................................................................ 27
Menu access............................................................................................................................... 28
251873962_myX-1a Twin_lu_en.book Page 12 Vendredi, 7. janvier 2005 3:00 15

13
Contents
Deleting characters..................................................................................................................... 28
Initial communication - Hands-free mode ........................................................................ 29
Making a call ............................................................................................................................... 29
Receiving a call........................................................................................................................... 29
Volume control............................................................................................................................ 30
Hands-free mode ........................................................................................................................ 30
Ending a call ............................................................................................................................... 30
Directory.............................................................................................................................. 31
Directory display ......................................................................................................................... 31
Storing a number ........................................................................................................................ 31
Deleting a number ...................................................................................................................... 32
Call groups.................................................................................................................................. 32
Sorting ........................................................................................................................................ 33
Sending a short message to a stored number............................................................................ 34
Directory memory space............................................................................................................. 34
Displaying personal numbers .....................................................................................................34
Making a call with a stored number ............................................................................................ 34
Messages............................................................................................................................. 35
Receiving a message ................................................................................................................. 35
Editing a message using Easy Message T9™ ........................................................................... 40
Options for messages in the list.................................................................................................. 44
Calls ..................................................................................................................................... 45
Forwarding calls.......................................................................................................................... 45
Viewing the list of the last numbers used ................................................................................... 46
Monitoring the duration and cost of calls (*) ............................................................................... 47
Displaying the numbers .............................................................................................................. 48
Authorising double call................................................................................................................ 49
Configuring automatic redial ....................................................................................................... 49
Blacklist....................................................................................................................................... 49
Voice mail number ...................................................................................................................... 50
251873962_myX-1a Twin_lu_en.book Page 13 Vendredi, 7. janvier 2005 3:00 15

14
Contents
Local information distribution ...................................................................................................... 50
Replacing the international prefix ............................................................................................... 50
Placing calls on hold ................................................................................................................... 51
Multi-conferencing (*).................................................................................................................. 51
Ringing tones...................................................................................................................... 53
Selecting the volume and the type of ringing tone...................................................................... 53
Call groups.................................................................................................................................. 54
Personalising the ringing tone .................................................................................................... 55
Setting the vibrator...................................................................................................................... 55
Selecting silent mode.................................................................................................................. 56
Setting the beeps........................................................................................................................ 56
Deleting DTMF tones.................................................................................................................. 57
Settings................................................................................................................................ 58
Customizing your phone ............................................................................................................. 58
Selecting the display language ................................................................................................... 60
Select the type of response ........................................................................................................ 60
Selecting the network ................................................................................................................. 61
Setting the time and date............................................................................................................ 62
Controlling screen contrast ......................................................................................................... 62
Converting currencies ................................................................................................................. 62
Security................................................................................................................................ 63
Locking the keyboard.................................................................................................................. 63
Changing the PIN number .......................................................................................................... 63
Changing the PIN2 number (*) ................................................................................................... 64
Changing the phone code........................................................................................................... 65
Changing the operator password (*)........................................................................................... 66
Limiting incoming calls (*) ........................................................................................................... 66
Limiting outgoing calls (*)............................................................................................................ 67
Setting up the pre-set directory (*) .............................................................................................. 67
Charge checking (*) .................................................................................................................... 68
Confidentiality messages............................................................................................................ 68
251873962_myX-1a Twin_lu_en.book Page 14 Vendredi, 7. janvier 2005 3:00 15

15
Contents
Accessories......................................................................................................................... 69
Calculator.................................................................................................................................... 69
Setting the alarm......................................................................................................................... 70
Setting the timer.......................................................................................................................... 70
Configuring your phone with a car kit ......................................................................................... 71
Data parameters ......................................................................................................................... 71
WAP (depending on model)............................................................................................... 72
The WAP menus......................................................................................................................... 72
Configuration of parameters ....................................................................................................... 73
Connection.................................................................................................................................. 74
Downloading objects................................................................................................................... 74
Disconnection ............................................................................................................................. 75
Exit from the WAP function ......................................................................................................... 75
Icons ........................................................................................................................................... 75
Games.................................................................................................................................. 76
Available accessories ........................................................................................................ 77
Upkeep ....................................................................................................................................... 77
Battery ........................................................................................................................................ 78
Maintenance menu ..................................................................................................................... 78
Technical Characteristics .................................................................................................. 79
Care and safety information .............................................................................................. 80
Safety.......................................................................................................................................... 80
SAR ............................................................................................................................................ 81
Warranty .............................................................................................................................. 82
End User Licence Agreement (EULA), for the software.................................................. 85
Troubleshooting .................................................................................................................89
Customer care..................................................................................................................... 92
Index .................................................................................................................................... 93
251873962_myX-1a Twin_lu_en.book Page 15 Vendredi, 7. janvier 2005 3:00 15

16
Presentation of the phone
(Depending on model)
1 - Ear phone/Speaker
2 - High definition graphics screen
3 - Programmable lefthand key
4 - Central key
5 - Programmable righthand key
6 - Scrolling arrows
7 - Stop/End call
8 - Operate/Call - Activation of hands-free
9 - Cancel
10 - Validate
11 - Battery charging and accessories socket
12 - Microphone
WARNING!
During a call, mind you do not obstruct the microphone with your hand.
4
1
OKC
s
my X-1
ghi
23
6mno
9
5jkl
tuv
+
7pqrs
abc
def
wxyz
8
0
1
2
3
4
710
6
12 11
8
5
9
251873962_myX-1a Twin_lu_en.book Page 16 Vendredi, 7. janvier 2005 3:00 15

17
Presentation of the phone
(Depending on model)
1 - Ear phone/Speaker
2 - High definition graphics screen
3 - Programmable lefthand key
4 - Central key
5 - Programmable righthand key
6 - Scrolling arrows
7 - Stop/End call
8 - Operate/Call - Activation of hands-free
9 - Cancel
10 - Validate
11 - Battery charging and accessories socket
12 - Microphone
WARNING!
During a call, mind you do not obstruct the microphone with your hand.
1
2
3
4
710
6
12 11
8
5
9
251873962_myX-1a Twin_lu_en.book Page 17 Vendredi, 7. janvier 2005 3:00 15

18
Presentation of the phone
Function keys
Switch off – Reject a call – Hang up
Switch on – Call a number – Receive a call – Hands-free
mode (*)
C Short press: Return to the previous menu – Delete a character
Long press: Exit menu mode – Complete deletion of the entry
OK Validate
- Programmable keys for direct access to the functions that
you have selected (depending on model)
- Volume control during conversation (lefthand key : lower,
righthand key : louder)
- Contextual action
@ Mobile Internet access key (depending on model)
T and S Entry and scrolling through the menus.
251873962_myX-1a Twin_lu_en.book Page 18 Vendredi, 7. janvier 2005 3:00 15

19
Presentation of the phone
Made up of 12 keys: 0 to 9, ∗ and # .
To obtain a letter, press successively on the relevant key until the desired
number or letter appears.
Letters with accents are obtained by a long press on ∗ after entering the letter
with no accent.
Punctuation marks and special symbols are obtained by a long press on the
# key.
A long press on key 1 allows you to access the voicemail service (depending
on model).
A long press on key ∗ allows you to activate or deactivate the silent mode.
Alphanumeric keyboard
Key 1
Key ∗
251873962_myX-1a Twin_lu_en.book Page 19 Vendredi, 7. janvier 2005 3:00 15
