Sagem MYC2-3 User manual

ENGLISH
252211278_myC2-3_en.book Page 1 Vendredi, 12. août 2005 1:27 13

You have just purchased a SAGEM mobile phone, and we congratulate you on your choice.
Your phone can be used internationally in the various dual band networks (GSM 900 MHz and DCS 1800 MHz) depending
on the roaming arrangements with your operator.
This user guide presents the SAGEM myC2-3 and myC2-3m mobile phones range.
Depending on the models, the following options are present or not in your phone: MMS, GPRS, data/fax/modem. You can
check with your operator or dealer the options supported by your phone.
We remind you that this phone is approved to meet European standards.
We recommend that you read this handbook carefully before using your phone efficiently and in the best conditions.
WARNING
Depending on the configuration of the networks and the associated subscriber cards, some functions may not be available.
Ensure that your SIM card is a 3 V (Volt) SIM type that is compatible with your phone. Inserting an incompatible card will be
indicated by a message when your phone is switched on. Contact your operator.
SAGEM™ is a trademark of SAFRAN.
AT® is a registered trademark of Hayes Microcomputer Products Inc.
Hayes® is a registered trademark of Hayes Microcomputer Products Inc.
T9™ Text Input is a registered trademark of ©Tegic Communications Inc.
T9 is protected by one or more of the following US patents: 5,818,437, 5,953,541, 5,187,480, 5,945,928, 6,011,554 and other
patents are being applied for worldwide.
The WAP navigator and the softwares included are the exclusive property of Openwave. For this reason, it is forbidden to
modify, translate, disassemble or even decompile all or part of these softwares.
Wellphone™ and SmartCom™ are registered trademarks owned by SmartCom SARL France.
252211278_myC2-3_en.book Page 2 Vendredi, 12. août 2005 1:27 13

Contents 3
Contents
Menus............................................................................................................................................ 7
Your phone package - Accessories ........................................................................................... 8
Description ................................................................................................................................... 9
Principles of navigation............................................................................................................. 10
Home page.................................................................................................................................. 11
Activating your phone ............................................................................................................... 12
Information on the SIM card................................................................................................................. 12
Installing the SIM card and installing the battery ................................................................................. 13
Increase the efficiency of your phone .................................................................................................. 13
Charging the battery ............................................................................................................................ 14
My phone in 5 minutes .............................................................................................................. 15
Getting started ..................................................................................................................................... 15
PIN Number ......................................................................................................................................... 15
Setting time and date ........................................................................................................................... 16
Network................................................................................................................................................ 16
First call................................................................................................................................................ 16
Receiving a call.................................................................................................................................... 17
Switching off......................................................................................................................................... 17
Volume and ring tone........................................................................................................................... 18
Phonebook.................................................................................................................................. 19
Using the phonebook ........................................................................................................................... 19
Options from a contact saved .............................................................................................................. 20
Phonebook menu................................................................................................................................. 21
Call groups........................................................................................................................................... 22
Sending a vCard .................................................................................................................................. 23
Receiving a vCard................................................................................................................................ 23
252211278_myC2-3_en.book Page 3 Vendredi, 12. août 2005 1:27 13

4Contents
Messages .................................................................................................................................... 24
Composing messages ......................................................................................................................... 24
Compose MMS (depending on model) ................................................................................................27
Receiving messages............................................................................................................................ 28
Inbox .................................................................................................................................................... 28
Outbox (depending on model) ............................................................................................................. 28
Drafts ................................................................................................................................................... 29
Sending options ................................................................................................................................... 29
Memory................................................................................................................................................ 29
Local info (depending on model) ......................................................................................................... 30
WAP ............................................................................................................................................. 31
The WAP Menus.................................................................................................................................. 31
Configuring WAP parameters .............................................................................................................. 32
WAP Logging on.................................................................................................................................. 33
Downloading objects............................................................................................................................ 33
WAP Logging off.................................................................................................................................. 33
GPRS (depending on model)............................................................................................................... 33
Games ......................................................................................................................................... 34
Sounds ........................................................................................................................................ 35
Volume and ring tone........................................................................................................................... 35
Vibrate ................................................................................................................................................. 35
Silent mode.......................................................................................................................................... 35
Beeps................................................................................................................................................... 36
Background ................................................................................................................................ 37
Colours ................................................................................................................................................ 37
Wallpapers........................................................................................................................................... 37
Greeting message ............................................................................................................................... 37
Settings ....................................................................................................................................... 38
Date / Time .......................................................................................................................................... 38
My objects............................................................................................................................................ 38
252211278_myC2-3_en.book Page 4 Vendredi, 12. août 2005 1:27 13

Contents 5
Languages ........................................................................................................................................... 38
Networks .............................................................................................................................................. 39
Contrast ............................................................................................................................................... 39
Short cuts............................................................................................................................................. 39
Active flip.............................................................................................................................................. 39
Calls............................................................................................................................................. 40
Forward calls........................................................................................................................................ 40
View last calls ...................................................................................................................................... 40
Counters .............................................................................................................................................. 40
Display numbers .................................................................................................................................. 41
Call waiting........................................................................................................................................... 41
Automatic redial ................................................................................................................................... 41
Blacklist................................................................................................................................................ 42
Answer phone number......................................................................................................................... 42
Security ....................................................................................................................................... 43
PIN number.......................................................................................................................................... 43
PIN number 2....................................................................................................................................... 43
Phone code.......................................................................................................................................... 44
Confidentiality ...................................................................................................................................... 44
Operator code ...................................................................................................................................... 44
Call barring........................................................................................................................................... 45
Fixed dialling ........................................................................................................................................ 45
Costs.................................................................................................................................................... 45
Accessories ................................................................................................................................ 46
Calendar .............................................................................................................................................. 46
Calculator............................................................................................................................................. 46
Converter ............................................................................................................................................. 47
Alarm.................................................................................................................................................... 47
Timer.................................................................................................................................................... 47
Car kit................................................................................................................................................... 48
Data ..................................................................................................................................................... 48
252211278_myC2-3_en.book Page 5 Vendredi, 12. août 2005 1:27 13

6Contents
Services ...................................................................................................................................... 49
Technical features...................................................................................................................... 51
Care and safety information...................................................................................................... 52
SAR ..................................................................................................................................................... 52
Advice for limiting exposure to radiofrequency (RF) fields .................................................................. 52
Safety................................................................................................................................................... 53
Environment......................................................................................................................................... 54
Warranty...................................................................................................................................... 55
End User Licence Agreement (EULA), for the software ......................................................... 58
Troubleshooting ......................................................................................................................... 62
Customer care ............................................................................................................................ 65
Index ............................................................................................................................................ 66
252211278_myC2-3_en.book Page 6 Vendredi, 12. août 2005 1:27 13

Menus 7
Menus
Phonebook
Phonebook menu
Messages
Compose
Inbox
Outbox (*)
Drafts
Options
Memory
Local info. (*)
WAP
Games
Sounds
Ring tones
Vibrate
Silent mode
Beeps
Background
Colours
Wallpapers
Greeting msg
Settings
Date / Time
My objects
Languages
Networks
Contrast
Short cuts
Active flip
Calls
Calls forwarded
View last calls
Counters
Display numbers
Call waiting
Auto redial
Blacklist
Answ. phone nb.
Security
PIN number
PIN number 2
Phone code
Confidentiality
Operator
Call barring
Fixed dialling
Cost (*)
Accessories
Calendar
Calculator
Converter
Alarm
Timer
Car kit
Data
Services
(*) Depending on model
252211278_myC2-3_en.book Page 7 Vendredi, 12. août 2005 1:27 13

8Your phone package - Accessories
Your phone package - Accessories
When you open the box, check that all the items are present:
1 - Phone
2 - Mains charger
3 - Battery
4 - User manual
Accessories
We advise you the use of SAGEM brand accessories for an optimal operating of your phone and of your accessories.
You can also find (as an option) or order the following accessories:
-Hands-free kit
-Extra battery
-Extra charger
-USB cable (with associated drivers) and serial cable to connect your phone to a PC
-Cigar lighter adapter
-Strap
For more information: www.planetsagem.com
4
2
3
1
252211278_myC2-3_en.book Page 8 Vendredi, 12. août 2005 1:27 13

Description 9
Description
Programmable keys and
Shortcut keys
Hold down: Switch on/off
Press briefly: In a call context: Rejects a call - hangs up
In menus: Return to home page
In call context: Call - reception of a call - hands-free mode
Left programmable key:
In home page: Access to certain functions (shortcuts)
In menus: Access to the selection shown on screen in the tab (*)
During a call: Reduces the volume
(*) In this manual, when a function is chosen by pressing on this key,
square brackets are used (e.g.: [ Save ]).
Right programmable key:
In home page: Access to certain functions (shortcuts)
In menus: Access to the selection shown on screen in the tab (*)
During a call: Increases the volume
In a call context: Rejects a call - hangs up
@ In initial screen: direct access to WAP function
S Previous choice/increase value/top
T Down choice/reduce value/down
W Up input field/move left
X Down input field/move right
Hold down: In home page: Silent mode
In call reception mode: Short press stops ring tone
In ring tone setting mode: Activates/deactivates ring tone
When composing a message:
Short press: Upper case/lower case
Zoom mode (see Messages and WAP menus)
When composing a message:
Short press: Access to the symbol table
252211278_myC2-3_en.book Page 9 Vendredi, 12. août 2005 1:27 13

10 Principles of navigation
Principles of navigation
These basic principles bring a great deal of intuitiveness to your phone
All the active areas on a white background (icon selector, programmable keys, menu selector, choice list)
Accept by pressing the key.
Cancel by pressing the key.
The tabs on the sides at the bottom of the screen refer to the
Programmable keys (and not to the left/right keys).
In the menus a title bar indicates the down higher level.
The
S T arrows are used to navigate from a menu to the other (or from one a sub-menu to the other).
The key is used to go from a menu to a sub-menu.
The key is used to go from a sub-menu to a menu.
The first menu level can be identified by a large animated icon in the centre of the screen.
The second menu level can be identified by a large static icon in the centre of the screen.
The lowest sub-menus are lists.
The key (press briefly) is used to return to the home page (current function is abandoned).
252211278_myC2-3_en.book Page 10 Vendredi, 12. août 2005 1:27 13

Home page 11
Home page
The home page contains the following
1 - The title bar icons:
Battery
Calls forwarded
Call (establishing the call)
Call (hands free)
SMS (reception of an SMS)
Silent mode
Message in answer phonebox
WAP (@)
GPRS (depending on model)
Home zone
HPLMN / roaming
Protected WAP logon
Protected WAP logon icon with certificate
Signal strength level (5 bars).
2 - Date and time, in digital or analogue mode
3 - Network provider
4 - Tab centred on down line:
the main "menu" tab shows that the menu can be accessed via the T S keys.
The following information may also be displayed: "1 message received"; or "1 call". They can be deleted by pressing the
key briefly.
252211278_myC2-3_en.book Page 11 Vendredi, 12. août 2005 1:27 13

12 Activating your phone
Activating your phone
Information on the SIM card
To use your phone, you have a smart card called a SIM card. It contains all the
information needed by the network as well as other information unique to you and
that you can modify:
Secret codes (PIN(s): Personal Identification Numbers), these codes allow you
to restrict access to your SIM card.
Phonebook,
Messages,
How special services work.
Your phone is compatible with the different SIM cards offered by operators.
It is also compatible with the SIM/WIM cards (cards containing the WIM module
in addition (WIM = Wireless Identity Module) that is used for secure WAP
communications.
WARNING
This card must be handled and stored with care to avoid damaging it by scraping or bending it. If you should lose your
SIM card, contact your operator or your SMC (Services Marketing Company) immediately.
Comment: do not leave your SIM card within the reach of young children.
252211278_myC2-3_en.book Page 12 Vendredi, 12. août 2005 1:27 13

Activating your phone 13
Installing the SIM card and installing the battery
Switch off your phone and disconnect the charger.
The SIM card is inserted beneath the phone’s battery.
Turn your phone over and slide the backcatch up.
Take off the back cover, starting from the top.
Slide the card along the base beneath the retaining plate, with the gold coloured
sections facing towards the phone and the cut-off corner lined up to match the
drawing on the phone.
Replace the back cover, clicking in first the lower part then the upper one.
Push the backcatch downwards into the locked position.
Increase the efficiency of your phone
-Don't press the keys when not necessary: each keypress activates the backlight, and uses much power.
1
2
3
4
1
2
3
4
252211278_myC2-3_en.book Page 13 Vendredi, 12. août 2005 1:27 13

14 Activating your phone
Charging the battery
Your phone is powered by a rechargeable battery. A new battery must be
charged for at least 4 hours before being used for the first time. It reaches its
optimum capacity after a few cycles of use.
When your battery has been discharged, the phone displays the state (empty
battery icon flashes). In this case recharge your battery for at least 15 minutes
before making any more calls so as to avoid being cut off mid-call.
To recharge the battery
Connect the charger to a mains socket.
Plug the end of the cable into the connector at the base of the phone.
The phone starts to charge up. Charging stops by itself. Disconnect the cable.
It is possible that the battery may heat up slightly during charging; this
phenomenon is normal.
WARNING
There is danger of explosion if the battery is placed in an incorrectly way or if it is exposed to fire.
Do not short circuit it.
The battery does not have any part that you can change.
Do not try to open the battery casing.
Use only the appropriate chargers and batteries as shown in the phone manufacturer's catalogue.
The use of other types of chargers or batteries may be dangerous or invalidate the warranty.
Used batteries must be disposed of in the appropriate places.
We advise you to take the battery out if you plan not to use the phone for extended periods.
You are strongly advised not to connect your phone to the charger if it doesn’t contain a battery.
The charger is a safety step-down transformer, it is forbidden to modify, alter or replace it by another component (power
supply plug, etc.).
252211278_myC2-3_en.book Page 14 Vendredi, 12. août 2005 1:27 13

My phone in 5 minutes 15
My phone in 5 minutes
Getting started
You are now ready to use your phone for the first time.
Switch on the phone by pressing the key. A short display appears.
PIN Number
This is your SIM's secret code.
If access to the SIM card is protected, the phone prompts you to enter the PIN number:
Enter the code between 4 and 8 digits given to you when the SIM card was issued. These digits do not appear on the screen
for security reasons.
Press the key to accept.
If your phone indicates that the SIM is missing, press the key to switch off your phone and check that the SIM card is
correctly installed.
WARNING
If a wrong PIN number is entered three times in succession, your SIM card is blocked. You must then:
-Enter "**05*".
-Enter the PUK (Personal Unblocking Key) code provided by your operator, and accept.
-Enter your PIN number and accept.
-Enter your PIN number again and accept.
After 5 or 10 failed attempts (depending on the type of SIM card), the SIM card is definitely locked. You must then
contact your operator or your SMC to obtain a new card.
252211278_myC2-3_en.book Page 15 Vendredi, 12. août 2005 1:27 13

16 My phone in 5 minutes
Setting time and date
When you use your phone for the first time, you need to set the date and time.
In due course, when the battery is completely discharged, or if it has been removed, you will be prompted systematically to
confirm date and time.
Setting the date
Set the date by entering it directly in numerical form or by using the T S keys to decrease or increase the default values.
Use the
X key (or W key) to access the next (or last) data input field.
Once the date is correct, press the key to
accept .
Setting the time
Same procedure as for setting the date.
Network
From now on the phone hunts for a network on which it can make calls. If it finds one, it displays the name of the network on
the screen. You are then ready to send or receive a call.
First call
Dial the number of your correspondent.
Press the key.
During the call, the call in progress icon flashes on screen and tones may indicate the establishment of the call.
Once communication has been established, the call icon stops flashing.
You can adjust the sound level (volume) using the and keys.
At the end of the conversation press the key to hang up.
If the network icon appears, calls are possible on your operator's network.
If the letter
R and a network name are displayed, calls are possible on the network of a different operator.
If the letter R is displayed without any network name, only the emergency services are accessible (ambulance, police,
fire brigade).
If the network icon flashes, the phone is in permanent search mode. There is no network available. The signal strength
indicator received allows you to display the quality of reception. If it indicates less than three bars, search for better
reception in order to call in good conditions.
252211278_myC2-3_en.book Page 16 Vendredi, 12. août 2005 1:27 13

My phone in 5 minutes 17
Receiving a call
When you receive a call, the number of your correspondent is displayed when it is presented by the network.
Press the key or the key to answer, and speak.
To refuse the call, press the key or the key.
To stop the ring tone or the vibrate, without refusing the call, press the key.
All the numbers corresponding to incoming and outgoing calls are logged in the list of recent calls.
Switching off
Press the key for one second.
The end message is displayed. The phone switches off.
International call
Press 0 (hold down) to display "+", then dial the country code without waiting for the dial tone, then the number of the
called party.
Emergency services
Depending on the operators you can obtain the emergency service with or without SIM card or when the keypad is
locked. It is enough to be in an area served by a network.
To obtain the international emergency service, dial
112 then press the key.
Hands-free mode
To change to hands-free mode during a call:
-press and hold the key (the green key) for a moment, then press [ Yes ] to confirm activation of the amplified mode,
-or press [ Menu ] then select Amplified mode ON .
WARNING: when in this mode, do not put the phone to your ear.
252211278_myC2-3_en.book Page 17 Vendredi, 12. août 2005 1:27 13

18 My phone in 5 minutes
We want to familiarise you with the interface of your new phone, using a simple setting: choosing a ring tone and adjusting
the volume.
Volume and ring tone
This menu allows you to allocate a ring tone to each type of event.
In the
home page , press the T key to access the main menus.
The first menu offered is
Phonebook .
Press the
T key four times to access the Sounds menu.
Enter this menu by pressing the key.
You can access the
second level of the menu that contains four sub-menus: Ring tones, Vibrate, Silent mode, beeps.
The first sub-menu offered is
Ring tones .
Enter by pressing the key.
With the help of the
T S keys select the type of function where you want to change the ring tone from the proposed list
(Alarm, Calls, Messages and Local Infos) and accept.
Enter by pressing the key.
Using the
T S keys select the ring tone from the list offered.
Enter by pressing the key.
For every new selection, you will hear the corresponding ring.
If required, press the
Silent mode key to cancel the sound.
Adjust the volume using the
T S keys.
The volume is adjusted over a scale of 1 to 4.
The ring tone is played at the chosen level whenever a change is made.
You can select "+"
volume to choose a ring that starts quietly and rises to a crescendo.
Accept by pressing the key.
252211278_myC2-3_en.book Page 18 Vendredi, 12. août 2005 1:27 13

Phonebook 19
Phonebook
The phonebook allows you to store numbers that you call regularly. These numbers can be stored in the SIM card or in the
phone.
The list of numbers in the phonebook of the SIM card varies in relation to the capacity of the card: the supplier company will
tell you what this is.
Different icons inform you of the position of the phonebook where the number is stored (depending on model):
Your SIM card phonebook
Your phone phonebook
Your SIM card's fixed directory.
Using the phonebook
The phonebook menu allows you to create new contacts, to create call groups (depending on model) and to check the
memory available to store new contacts.
In the home page press the
T key to access the main menus. The first menu offered is Phonebook .
Press the key corresponding to the accept tab to enter the menu.
The list of your correspondents appears, by default, the cursor is positioned on the first name in alphabetical order.
If you are using your phone and SIM card for the first time, the phonebook list will be empty, only the
Phonebook menu
function will be available.
252211278_myC2-3_en.book Page 19 Vendredi, 12. août 2005 1:27 13

20 Phonebook
Options from a contact saved
Select a contact from the list using the T S keys. Then press the key.
Choose from the options offered:
See contact
The first menu offered is See contact . [ OK ].
The detail of the store appears (location, call group [depending on model], name, number).
Call
Several ways:
-Select a contact. Press the key to start the call.
-Select a contact, press [ Options ]/ Call then [ OK ] to start the call.
-Direct call from the initial screen: type the number with which the contact was saved then (example: 21 ) or the
number then , the number is displayed, confirm in pressing the
key.
Modify contact
Modify contact . [ OK ]. Using the T key.
Modify the fields wanted and [
OK ].
Delete
Select Delete . [ OK ].
Confirm deletion of entry with [
Yes ].
Send message
Select Send message . [ OK ].
Select SMS or MMS (depending on model).
Text editor opens automatically.
Copy to SIM/Copy to mobile
This allows you to copy your phonebook entries from one memory to the other. Only the name and the first phone number
will be copied.
252211278_myC2-3_en.book Page 20 Vendredi, 12. août 2005 1:27 13
