SAGEM F@stTM 1201/1241
Reference Manual
288 110 393-01
Edition of October 2006

SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Sagem Communication document. Reproduction and disclosure prohibited Page 0-1
Sagem Communication assiduously monitors technical developments and is constantly
seeking to improve its products in order to let its clients take full advantage of them. It therefore
reserves the right to modify its documentation accordingly without notice.
All brands mentioned in this guide are registered by their respective owners:
•SAGEM F@st™ is a registered brand of Sagem Communication.
•SAGEM F@st™ is a registered brand of Sagem Communication.
•WindowsTM and Internet ExplorerTM are registered brands of Microsoft Corporation.
•Apple®and Mac®OS are registered brands of Apple Computer Incorporation.
The purpose of the present reference manual is to give users the functions for operating and
managing the equipment. The only access level required (Administrator) is protected by a
password and allows one to access these functions in read and write mode for all the user and
network parameters (Standard values: Login: admin, password: admin).
Configuration of the router by HTTP is described in detail (cf. section 5).
For better legibility of the reference manual, the term "router" will be used throughout the
document to designate SAGEM F@stTM 1201 and SAGEM F@stTM 1241 equipment. When
description is addressed to a type of quite precise equipment, the name of this equipment will
be mentioned.
By defect all the functions described on the SAGEM F@stTM 1201 are also available on the
SAGEM F@stTM 1241.
Convention of symbols used in this manual
Warns you not to do an action, or commit a serious omission.
Gives you important information which you must take into account

SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Page 0-2 Sagem Communication document. Reproduction and disclosure prohibited
How should the document be used?
The present reference manual is organised into sections and annexes. These sections and
annexes cover the following subjects.
Section 1 Presentation of SAGEM F@stTM 1201 equipment
Section 2 Presentation of SAGEM F@stTM 1201 equipment
Section 3 Presentation of SAGEM F@stTM 1201 equipment
Section 4 Configuration of network parameters
Section 5 Configuration of the residential platform by HTTP
Section 6 Description of Internet access service
Section 7 Updating the application
Annex A Troubleshooting
Annex B CE compliance declaration
Annex C Environment
Annex D Technical Characteristics
Annex E Default configuration
Annex F Glossary
Annex G Connection technology

SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Sagem Communication document. Reproduction and disclosure prohibited Page 0-3
Contents
Pages
Contents 0-3 to 0-6
1. Introduction 1-1
1.1 Presentation 1-2
1.2 Composition of router pack 1-4
1.3 Minimum prerequisite 1-5
2. Description and connection of router 2-1
2.1 Description 2-2
2.1.1 "Connectors" side view 2-3
2.1.2 "LEDs" view 2-4
2.2 Connecting the ports of your router 2-5
2.2.1 Connecting to a power socket 2-6
2.2.2 Connection of the ADSL cable to the router 2-7
2.2.3 Connecting to your computer 2-8
2.2.3.1 Connection of the USB interface of your router to your computer 2-8
2.2.3.2 Connecting the Ethernet interface of your router to your computer 2-9
2.3 Installation instructions 2-10
3. Installing and configuring the router 3-1
3.1 Installing and configuring your Router with the network card of
your computer (Ethernet) 3-4
3.2 Installing and configuring your Router in the USB port of your computer 3-8
3.3 Installing and configuring an additional computer 3-12
4. Configuration of network parameters 4-1
5. Information / Configuration 5-1
5.1 Accessing the welcome screen 5-2
5.2 Recommendations 5-4
5.3 ADSL connection status 5-5
5.4 Display frame 5-5

SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Page 0-4 Sagem Communication document. Reproduction and disclosure prohibited
5.5 Status 5-6
5.5.1 Summary 5-6
5.5.2 Diagnostics 5-7
5.6 Internet Connection 5-9
5.7 NAT 5-10
5.7.1 Port forwarding 5-10
5.7.2 DMZ Host 5-15
5.8 Advanced Setup 5-16
5.8.1 WAN 5-16
5.8.2 LAN 5-38
5.8.3 Security 5-40
5.8.3.1 Outgoing 5-40
5.8.3.2 Incoming 5-42
5.8.4 Routing 5-45
5.8.4.1 Default Gateway 5-45
5.8.4.2 Static Route 5-46
5.8.5 DNS 5-48
5.8.6 DSL 5-49
5.9 Advanced Status 5-52
5.9.1 WAN 5-52
5.9.2 Statistics 5-53
5.9.2.1 LAN 5-53
5.9.2.2 WAN 5-54
5.9.2.3 ATM 5-55
5.9.2.4 ADSL 5-56
5.9.3 Route 5-57
5.9.4 ARP 5-58
5.9.5 DHCP 5-59
5.10 Management 5-60
5.10.1 Settings 5-60
5.10.1.1 Backup 5-61
5.10.1.2 Update 5-63
5.10.1.3 Restore Default 5-64
5.10.2 System Log 5-65
5.10.3 Access Control 5-70
5.10.3.1 Services 5-70
5.10.3.2 IP Address 5-71
5.10.3.3 Passwords 5-73
5.10.4 Update Software 5-74
5.10.5 Save/Reboot 5-75
6. Internet access service 6-1
6.1 Introduction 6-2
6.2 Connection for Internet access 6-3

SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Sagem Communication document. Reproduction and disclosure prohibited Page 0-5
7. Updating the application 7-1
A. Annex A - Troubleshooting A-1
A.1 Checking the attribution of an IP address A-2
A.1.1 In Windows A-2
A.1.2 On a Mac (for example MacOS X) A-2
A.2 Front Face LEDs A-3
A.3 Supervising your router A-4
A.4 "Diagnostics" tool A-5
A.5 Interpreting the LEDs A-7
A.5.1 The "ADSL" LED blinks slowly A-7
A.5.2 All LEDs are off A-7
A.6 Reinitialising your router A-8
A.7 Re-establishing the factory configuration A-8
A.8 Offline mode A-9
B. Annex B - Warnings for safety B-1
B.1 Warnings for safety B-2
B.1.1 Safety levels in relation to the case B-2
B.2 CE compliance declaration B-3
C. Annex C - Environment C-1
C.1 Directive E 2002/96/CE C-2
D. Annex D - Technical Characteristics D-1
D.1 Mechanics; Display D-2
D.2 Characteristics of the different interfaces D-3
D.3 Environmental characteristics D-4
D.4 Application and protocols D-5
E. Annex E - Default configuration E-1
E.1 Default username and password E-2
E.2 Default configuration for the local network(LAN) E-2
E.3 Default configuration for the remote network (WAN) E-2

SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Page 0-6 Sagem Communication document. Reproduction and disclosure prohibited
F. Annex F - Glossary F-1
G. Annex G - Connector Technology G-1
G.1 Pinouts of the "LINE" connector G-2
G.2 Pinouts of the "PWR" connector G-2
G.3 Pinouts of the "ETH" connector G-3
G.4 Pinouts of the "USB" connector G-4

SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Sagem Communication document. Reproduction and disclosure prohibited Page 1-1
1. Introduction
This section covers ¾presentation of the SAGEM F@stTM 1201/1241 equipment § 1.1
¾composition of the packaging § 1.2
¾required hardware and software § 1.3

1 - Introduction
SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Page 1-2 Sagem Communication document. Reproduction and disclosure prohibited
1.1 Presentation
The present reference manual is dedicated to the SAGEM F@stTM 1201 and
SAGEM F@stTM 1241 product ranges. These products are routers which give users, via an
ADSL/ADSL2/ ADSL2+ network, broadband Internet access from their computer or their games
console by various Ethernet (10 or 100 BASE-T) or USB interfaces.
SAGEM F@stTM 1201 and SAGEM F@stTM 1241 products adapt the ADSL
function respectively for POTS (UIT G.992.1/3/5 - Annex A) and for ISDN
(UIT G.992.1/3/5 - Annex B).
Figure 1.1 - Supervising your router

1 - Introduction
SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Sagem Communication document. Reproduction and disclosure prohibited Page 1-3
Its principal characteristics and functions are as follows:
¾High-performance secure Bridge/Router with ADSL/ADSL2/ADSL2+ interface,
¾User access:
•1 10/100BT Ethernet port,
•1 USB1.1 Slave port,
¾DHCP Client/Server/Relay,
¾DNS Server/Relay,
¾FTP Client/Server,
¾TFTP Client/Server,
¾HTTP Client/Server,
¾NAT/PAT router - FTP Compatibility, IRC, Net2Phone, Netbios, DNS, Netmeeting, SIP,
VPN passthrough (IPSec, IKE, PPTP, L2TP), CUSeeMe, RealAudio, Microsoft IM and
others,
¾Firewall,
¾Spanning tree,
¾HTTP server for easy configuration,
¾Manual update of the application version locally.

1 - Introduction
SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Page 1-4 Sagem Communication document. Reproduction and disclosure prohibited
1.2 Composition of router pack
The router is supplied in a pack with the following contents:
¾1 SAGEM F@stTM 1201 or SAGEM F@stTM 1241,
¾1 mains adapter unit,
¾1 grey ADSL RJ11/RJ11 FDT line cord (length = 3 m),
¾1 yellow Ethernet RJ45/RJ45 linking cord (length = 1.75 m),
¾1 blue USB Type A male/Type B male cable (length = 1.5 m),
¾1 Quick Installation Guide,
¾1 Installation CD-ROM,
¾microfilter(s) (option),
¾1 filter/splitter (option).

1 - Introduction
SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Sagem Communication document. Reproduction and disclosure prohibited Page 1-5
The CD ROM contains:
•the application for installing the USB interface.
•the present Reference Manual (SAGEM F@st™ 1201/1241) in PDF format file.
•the CE declaration of the chosen router.
Incomplete or damaged supply. If on its receipt the equipment is damaged or
incomplete, contact the Supplier of your router.
1.3 Minimum prerequisite
Using a router requires at minimum:
¾a computer equipped:
•a type A USB interface
or
•an Ethernet interface (10BASE-T or 10/100BASE-T),
¾a WEB browser (Internet Explorer version 5 or higher recommended).
The minimum configuration of your computer must be:
¾for Windows: Pentium II, 400 MHz, RAM: 128 MB,
¾for MacOS: Power PC G3, 233 MHz, RAM: 128 MB,
¾a monitor of minimum resolution: 1024 x 768.
Before installing the router, we advise you to uninstall any modem or other router
(for example, an ADSL router).

1 - Introduction
SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Page 1-6 Sagem Communication document. Reproduction and disclosure prohibited

SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Sagem Communication document. Reproduction and disclosure prohibited Page 2-1
2. Description and connection
of router
This section covers ¾the description of your router § 2.1
¾connecting the ports of your router § 2.2
¾connecting to a power socket § 2.2.1
¾connecting the line cable § 2.2.2
¾connecting your computer § 2.2.3
¾installation instructions § 2.3

2 - Description and connection of router
SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Page 2-2 Sagem Communication document. Reproduction and disclosure prohibited
2.1 Description
Figure 2.1 gives an overview of a router SAGEM F@stTM 1201 or SAGEM F@stTM 1241.
Figure 2.1 - Overview of case
This case consists principally of a lid and a base in which a printed circuit equipped with
electronic components is located.
The front face has four display LEDs (cf.§ 2.1.2).
The base has the LEDs ideograms, SAGEM's mark and logo or the operator's marking as well.
Below the base a label is glued on which the product's identification code, the series number
and a barcode are shown.

2 - Description and connection of your router
SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Sagem Communication document. Reproduction and disclosure prohibited Page 2-3
2.1.1 "Connectors" side view
Marking Meaning
LINE RJ11 connector - 6 pts. This grey connector is used for the connection to an
ADSL line (WAN interface).
USB Type B USB female connector. This blue connector is used for connection to
a computer (USB interface).
ETH RJ45 connector - 8 pts (10/100BASE-T Ethernet Interface). This yellow
connector is is used for connection to a computer (10/100BASE-T ETH
interface).
REG This button allows the router to be reset to the factory configuration
(see § A.7).
Note: It is set back relative to the other elements to prevent an accidental
loss of configuration.
On/Off switch.
PWR Miniature jack fixed connector.
This connector enables the router to be supplied with direct current from a
mains adapter unit.

2 - Description and connection of router
SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Page 2-4 Sagem Communication document. Reproduction and disclosure prohibited
2.1.2 "LEDs" view
The different LEDs of the figure below are described in the following table:
Marking Abbreviation Meaning
PWR Alarm LED (bicolour LED Green/Red):
•lits green if power is present,
•lits red in the case of failure detected at the time of starting.
•goes out if there is no power
ADSL Green ADSL LED:
•blinks slowly when the ADSL is not detected,
•blinks quickly when the ADSL line is being synchronised,
•stays lit when the ADSL line is detected.
LAN Green local network (LAN) LED:
This LED indicates data traffic between the router and the different
USB and Ethernet (ETH) interfaces.
•This LED is off if no interface (Ethernet or USB) is detected.
•This LED blinks when traffic is detected on one of the interfaces.
•This LED is lit when an Ethernet or USB interface is detected and
if no traffic is detected.
Internet Internet connection LED (bicolour LED Green/Red):
•remains lit when the "PPP" connection is established or when the
router is in "Bridge" mode,
•lits green when the "PPP" connection is established,
•lits red when the "PPP" connection is not established,
•blinks when traffic is detected on the WAN interface.

2 - Description and connection of your router
SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Sagem Communication document. Reproduction and disclosure prohibited Page 2-5
2.2 Connecting the ports of your router
Figure 2.2 - Interconnection of ports of SAGEM F@st
TM
1201/1241

2 - Description and connection of router
SAGEM F@st™ 1201/1241 Reference Manual - 288110393-01
Page 2-6 Sagem Communication document. Reproduction and disclosure prohibited
2.2.1 Connecting to a power socket
¾First connect the end of the mains cord, supplied with the equipment, to the PWR base of
your router.
¾Connect the mains adapter to a nearby mains wall socket.
¾Set the "On/Off" switch to On.
