Sailfish 2100 BB Owner’s Manual
03/04/2019

Table of Contents
FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
2. BoatSpecications
3. TrailerMeasurementChart
4. BoatLayout
5. BoatSafety&WarningLabels
6. BoatSafety&WarningLabelLocations
9. BoardingLadder&UnassistedBoarding
Situations
10. BayBoatWiringHarness
11. AdapterHarness
12. BreakerPanelSchematic
13. SwitchPanel
14. BatterySwitchWiring
15. FuelSystemLayout
16. PlumbingDiagram
17. UFLEXSTEERING
18. IgnitionSwitches,EngineShut-O󰀨Cord/Lanyard
19. Fuel-WaterSeparator-Yamaha&VeradoOnly
19. PlugandPlayWiring
20. ConsoleArea
21. BilgePump
22. RawWaterWashdownSystem
23. LivewellOperation
24. TrimTabMaintenance
25. VinylCareandCleaning
26. AluminumCosmeticCorrosion(Pitting)
27. CaringforAluminum
28. CaringforStainlessSteel
29. Windshield,WindowandHatchCareInstructions
30. GelCoat
1

Sailfish 2100 BB Specifications
FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
2
SPECIFICATIONS
LOA Hull Only........................ 21’ 0”
Length Rigged......................23’ 0”
Beam .....................................8’ 6”
Fuel Capacity .....................63 gal.
Approx. Rigged Weight.. 3,625 lbs.
Max. HP Single....................200hp
Draft - Hull................................13”
Deadrise.................................. 18°
Battery Capacity ........................4
Rod Holders (Standard) .............14
Bridge Clearance....................5’ 5”
STANDARD FEATURES
Boat
• Anchor Locker
• Built In Rigging Tubes
(From Bilge to Helm with pull
tapes)
• Carbon Fiber & Kevlar ®
Reinforced Deck & Hull
• Closed Cell Foam Flotation
• Exclusive Dot Matrix Non-Skid
• Hydraulic Steering w/ Stainless
Steel Tilt Wheel & Power Knob
• Mercury Verado Fuel Filter /
Water Separator
• Recessed SST Cup Holders (1)
• SailTech Composite Full
Length Transom
• SailTech Foam Filled Fiberglass
Stringer System
• Yamaha 10 Micron Fuel Filter /
Water Separator w/ SS Base
Electrical
• 12 Volt DC Accessory Plug
• Accessory Switch Panel w/
Circuit Breakers
• Compass
• Dual Battery Switch
• Electric Horn
• Full Digital Instrumentation
• LED Interior Cockpit Lighting
• LED Navigational Bow &
Anchor Light
Fishing
• Baitwell (20 gal. Aft)
• Built-In Tackle Storage (2
Forward)
• Insulated Bow Fish Box (5’) -
Drains Overboard
• Release Livewell (30 gal. Port
Aft)
Hardware
• Flush Mount Hinges and
Latches & Deck Plates
• Heavy Duty Stainless Steel Bow
& Stern Eyes
• Heavy Duty Stainless Steel
Rub Rail
• Marine Grade Stainless Steel
Hardware
• Sailsh Engraved Transom
Plate
• Stainless Steel Flush Mount
Pull-Up Cleats (4)
• Stainless Steel Over Composite
& Bronze Thru Hull Fittings
• Stainless Steel Propeller
• Stainless Steel Rod Holders (8)
• Wind Screen w/ Stainless Steel
Grab Rail
Helm
• Large Dash Area (Capable of
ush mounting 7” Screen)
Plumbing
• Automatic Bilge Pump (1100
GPH)
• High Speed Livewell Pickup
• Raw Water Wash Down
• Self Bailing Cockpit
Seating
• Baitwell (16 gal. Console w/
Seat Cushions)
• LP2 (Leaning Post w/ Rod
Holders & Removable
Backrest)
Storage
• Battery Storage (Aft Starboard)
• Casting Deck Storage Box
• In-Floor Storage (Forward of
Console)
• Recessed Rod Storage - Port &
Starboard
OPTIONS
Boat Options
• Poling Platform
• Powder Coated Leaning Post
& T-Top
• Swim Platform w/ Ladder
• T-Top W. Spreader Light
• Trim Tabs w/ Indicator Switch
& Built in Retractor
• Underwater LED Lights (2)
Electrical Options
• Built-In 2 Bank Battery Charger
• Garmin 742xs w/o Transducer
• Garmin B60 Airmar Thru Hull
Transducer w/o CHIRP
• Garmin EchoMap 64cv US Blue
Chart w/ P79 Transducer
• Garmin VHF Radio & Antenna
• Jensen Stereo w/2 Speakers
• Trolling Motor Panel
• Wet Sounds LED Lighted
Speakers Upgrade
Seating Options
• Deluxe Fish Seat & Pedestal
• Front Jump Seat Cushions
• Rear Jump Seat Cushions
Optional Packages
• Sport Pack
Trolling Motor Panel, 2
Additional Rod Holders & Rear
Jump Seat Cushions
• Pro Fish Pack
(Includes Sport Pack), LP2 w/
Removable Backrest & Front
Jump Seat Cushions
• Inshore Tournament Pack
Built-In Battery Charger,
Deluxe Fish Seat & Pedestal
Engine Options
Yamaha
• F150XB
• F150XCA
• F200XB
• F200XCA
Mercury
• 150XL
• 200XL
• 200XL DTS
• Single Mercury White Motor
Upgrade (Only Available on 200
HP and Up)

SAILFISH BOAT TRAILER
MEASUREMENT CHART:
Boat Models B C D E F G H I
208CC 78 in. 53 in. 28 in. 11 in. 82 in. 218 in. 235 in. 27 in.
1900BB 88 in. 66 in. 37 in. 10.5 in. 99.5 in. 198 in. 217 in. 24 in.
2100BB 88 in. 66 in. 37 in. 10.5 in. 99.5 in. 220 in. 240 in. 24 in.
220CC & 220WAC 87 in. 59 in. 31 in. 14.5 in. 102.5 in. 216.5 in. 243 in. 32 in.
236CC & 241CC & 245DC 91 in. 57.5 in 30 in. 14 in. 103 in. 250 in. 273 in. 36 in.
240CC & 240WAC & 242CC 92 in. 59 in. 31 in. 15 in. 107 in. 241 in. 272 in. 30 in.
270CC & 270WAC & 275DC 94 in. 59 in. 31 in. 15 in. 107 in. 268 in. 302 in. 30 in.
290CC 94.5 in. 61 in. 32 in. 15.5 in. 107 in. 301 in. 336 in. 30 in.
320CC & 320EXP & 325DC 105 in. 65 in. 33 in. 16.5 in. 115 in. 315 in. 349 in. 38 in.
360CC 119 in. 72 in. 36 in. 20.1 in. 135 in. 383.34 in. 417.49 in. 48.19 in.
3

4
Sailfish 2100 BB Boat Layout
FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
q
u u
e
ri
y
wt
o
a
s
s
d
d
Key Description
1FishboxorReleaseWell
235GallonLivewell
3BatteryAccessandStorageCompartment
4LeaningPost
5Console/HelmArea
6FrontHelmSeatwithLivewell
Key Description
7StorageCompartments
8InsulatedFishBox
9OptionalTrollingMotorPanel
10 HangingAnchorLocker
11 Built-InTackleTrays
12 RodStorage

FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
5
Boat Safety & Warning Labels
Warning Labels
The safety for you and everyone on board, as a boat owner, you need to become familiar with and the locations of the Caution,
Warning and Danger Labels found on your boat.
Below are images of the labels to help you maintain and operate your boat safely.

FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
6
Boat Safety & Warning Labels
Warning Labels Continued
The safety for you and everyone on board, as a boat owner, you need to become familiar with and the locations of the Caution,
Warning and Danger Labels found on your boat.
Below are images of the labels to help you maintain and operate your boat safely.

FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
7
Boat Safety & Warning Label Locations

FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
8
Boat Safety & Warning Labels
Replacement Warning Labels
If any of your Boating Safety or Warning Labels become damaged, please call Sailsh Boats’
parts department for replacement stickers at 229-377-2125

FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
9
Boarding Ladder & Unassisted
Boarding Situations
Unassisted Boarding Instruction
When using the ladder in an unassisted boarding situation, reach over the swim platform and pull ladder towards you, by picking up the
ladder by the steps, release the Velcro strap, deploy the ladder by rotating it to the down position. Use you hand or foot to fully extend
the ladder in the down position. Use the grab handle and ladder to board your boat. When fully onboard, be sure to place the ladder back
in the storage position by reversing the deployment process.

2100 BB Wiring Harness
FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
10
DownloadHighResolutionDiagram

FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
11
Adapter Harness
DownloadHighResolutionDiagram

FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
12
Breaker Panel Schematic
DownloadHighResolutionDiagram

Switch Panel
FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
13

Battery Switch Wiring
FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
14
Battery 1
Battery 2

Fuel System Layout
FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
15
qw
e
e
e
Key Description
1PrimerBulb-Yamaha&VeradoOnly
2FuelFilterAccess-Yamaha&VeradoOnly
3FuelTankLocation
4Inspectionplateislocatedunderthe
Driver’sSeat
5FuelFill
6FuelPickup
7FuelSender
r
t
e
y
u

Plumbing Diagram
FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
16
2100 Plumbing Diagram
ropelockerbulkhead
trolling motor routing
fwd lockers drain
fuel vent
fuel fill
rigging pipe
livewell drain
opt. livewell
livewell
deck drain
deck drain washdown
fuel feed
option release well fuel filter
option aft release well overflow
aft well drain bilge hose
bilge pump
livewell pump/seacock
Aft
shelf
f uel
tank
board
oil
tank

FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
17
Sailfish 2100 BB
UFLEX Steering
System
UFLEXhasbeenthechoiceforsteering
forSailshboatsforthelastthreeyears
becauseofthequalityoftheUSAbuilt
products.
Everyhelmcomesstandardwithafull
stainlesssteelshaft;cylindersarebuilt
withcarbonsteelpistons,coupledwith
extra-largeendcapstopreventleakage.
All of their connection materials are
304stainlesssteelthathasbeenelec-
tro-polishedandpassivated.
Formoreinformationontheserviceand
maintenance of your UFLEX system
please refer to your UFLEX owner’s
manualorviewitelectronicallyathttp://
uexusa.ultraexgroup.com/public/File/
UFLEX2013_USA.pdf

Sailfish 2100 BB
FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
18
Ignition Switches, Engine
Shut-off Cord/Lanyard
EachSailshboatwillbeequippedwithaYama-
haorMercuryignitionswitchwithanemergency
engineshuto󰀨cord/lanyard.
This lanyard should be worn at all times while
operatingthevessel,ifthevesseloperatorfalls
ormovesaunsafedistanceawayfromthehelm
controlsthelanyardwillpulloutcausingtheen-
ginetoshutdown.
Makesurethelanyardisnotattachedtoapartof
yourclothingthatcouldbeeasilytornfreecaus-
ingtheswitchnottopull.SeeyourYAMAHAor
MERCURYowner’smanualformoreinformation
onthissafetyfeature.
Engine Break-In Period
Eachnewoutboardmotorwillneedtogothrough
abreakinperiodtomakesurealloftheinternal
movingpartsandcomponentshaveachanceto
correctlymate.
Formoreinformationonthebreakinperiodspe-
cictoyourenginepleaserefertoyourYAMAHA
orMERCURYOwner’smanual.

Sailfish 2100 BB
FISHING FOCUSED. FAMILY FRIENDLY.™ | www.SailfishBoats.com
03/04/2019
19
Fuel-Water Separator - Yamaha
& Verado Only
SailshhasriggedeitherYamahaorMercury,(Verado
Only),waterfuelseparatorsinthebilgecompartment.
Eachenginewillhaveitsownlter.Theselterscanbe
accessedthroughthebilgeaccessdoors,inthebackof
theboat.Formoreinformationontheselters,please
reviewyourYamahaorMercuryOwner’sManuals.
Plug and Play Wiring
DeutschConnectorsarequickdiscon-
nectplugsusedfordurabilityandease
ofreplacingcomponentsinyourSailsh
Boat.
Thesewaterresistantplugsareforuse
inelectricalsystemswheremoisture,
saltspray,dirtanddustcoulda󰀨ectthe
electricalconnectionsorsystems.
