SAINT-FUN MC-AT1 User manual


      

1
Bowling shot
Special Note
We want to thank you for choosing our products, and hope
you read these instructions first to insure the security of the
user before this product is used.
This manual contains the characteristics, special notes, and
a simple breakdown of the product.

2
Bowling shot
INSPECTION
Chapter 1 Product Introduction
1-1 Parts list ………………………
1-2 Specification …………………
P.3
P.3
Chapter 2 Setup Requirement
Space setup requirement………… P.4
Chapter 3 How to Play
Single mode …………………………
P.4
Chapter 4 Inspection
4-1 Booting Display…………………
4-2 Testing Mode Display…………
P.5
P.5
Chapter 5 Function
Function Adjustment…………………
P.6
Chapter 6 Billing
Billing Setup…………………………
P.7
Chapter 7 Setup
Inside setup………………………… P.8
Chapter 8 Ticket
Ticket Calculation………………… P.8
Chapter 9 Trouble Shooting
Trouble Shooting list……………… P.10
Chapter 10 Caution
Betting……………………………… P.10
Chapter 11 Parts List
Main Parts List………………………
P.11

3
Bowling shot
Chapter 1 P ro d u c t I n tro d u c ti o n
1-1 Parts list
Before product use, please confirm the product content first, if anything is
missing, please contact us right away.
Items Spec. Total Quantity
Bowling shot 1
Wooden Ball 3
Manual 1
1-2 Specification
Machine Size
Total Size (Main part
and bowing lane)
W660mm Surface width
L3000mm Length
H1800mm Height
Main part
(Monitor, Strike lighting,
Speaker)
W660mm Surface width
L810mm Length
H1800mm Height
Rear section including
bowling lane
W660mm
L2380mm
H640mm +35mm (Left and Right control
panel)
Power supply
Product power supply equipped short circuit protection
Voltage AC110V / 60HZ
Watts 260W
Current 2A

4
Bowling shot
Chapter 2 Setu p req u i rem en t an d
Spac e req u i rem en t
Ambient requirement
Product is to be use in indoor only, please avoid the following
1. Do not store the product in high moisture place, for example water
leak or bath room
2. Do not place product under direct sunlight or high ambient temp.
3. Do not place it close to emergency exit
4. Do not place it close to flammable or fugacity chemical
5. The Best Temp. range 
6. The product must Completed the setup before connect the power
supply
7. Place product on flat sure face, adjust level and secure
machine with 6 screws.
Chapter 3 H o w to pl ay ( Si n g l e g am e)
l .Insert token and press start button, pick up 2 pieces of wooden ball
2. When screen displays “1
st
ball”, roll the ball toward the screen Pin display at
the end of the bowling lane.
3. When screen displays “2nd ball”, then roll the last ball. The machine will
display strike or spare depends on the screen.
Setup requirement
Environment Indoor only
Ambient Temp. 0 ~40 
Humidity 10~70

5
Bowling shot
Chapter 4 B o o ti n g I n pec ti o n
4-1 Booting Display
ROM VERSION 1.20
PROGRAM
LOCAL  
EXTENDED
VIDEO 
PALETTE
ROM
RAM
RAM
RAM
RAM
OK
OK
OK
OK
OK
SINGLE GAME
Above image will display for 5 seconds, when booting and access to game play
screen. If screen displays “error”, please call Saint-FUN for help.
4-2 Testing display
TEST MODE
SENSOR
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
SENSOR Test
BALL
SWITCH
COIN-IN GUTTER-L
Coin selector testLeft alley test
SERVICE GUTTER-R
Service testRight alley test
START
Start button test
KEY
Setup button test
CLEAR
Clear button best

6
Bowling shot
Chapter 5 F u n c ti o n A d j u tm en t
Icon 1 2 3 4 Function
ON
Dispense Tickets
OFF
Do not dispense tickets
ON
Background Music
OFF
No background music
ON
No function (Always ON)
OFF
No function (always ON)
ON
Testing Mode (for repairing
mode)
SW2
SW2
OFF
Game Mode
Icon 1 2 Function
ON
No function (always OFF)
SW3
OFF
No function (always OFF)

7
Bowling shot
ON
Difficulty middle
OFF
Difficulty advance
Chapter 6 B i l l i n g o perati o n an d etu p
Please switch the setup button to ON after access the game to enter billing
operation
BOOK KEEPING
TOTAL GAMES : 0
TOTAL CREDIT IN : 0
TOTAL TICKET OUT : 0
BONUS WIN TIMES : 0
BONUS TICKET OUT : 0
EMERGENCY TIMES : 0
ST – ST : 0 TOTAL 9 : 0
ST – ANY : 0 TOTAL 8 : 0
ANY – SP : 0 ANY : 0
Game total : 0
Played total : 0
Total tickets out : 0
Lottery dispense time : 0
Lottery dispense, tickets : 0
Number of error: 0
2 consecutive strike record : 0 Hit 9 pins record : 0
Strike once record : 0 Hit 8 pins record : 0
Spare strike record : 0 Hit Under 7 pins record : 0
 press reset button to return to default number as above

8
Bowling shot
Chapter 7 Setu p & I n i d e etu p
Press ON and Reset (red) button, then turn on the power, into inside setup
function.
DATA SETTING MODE
GAME MODE SINGLE GAME
MULTIPLE GAME
COIN RATE 1 COIN 1 CREDIT / 1 COIN 2 CREDIT
1 COIN 3 CREDIT / 1 COIN 4 CREDIT
1 COIN 5 CREDIT / 2 COIN 1 CREDIT
3 COIN 1 CREDIT / 4 COIN 1 CREDIT
5 COIN 1 CREDIT
MIN. CREDIT 1 , 2, 3, 4 CREATE
BONUS START 0, 100 , 200, 300, 400 , 500 POINT
BONUS Max. 1000 ,2000,3000,4000,5000,6000,7000, 8000,
9000,10000,20000,30000,40000,50000 POINT
BONUS
UPRATE
1 CREDIT 1 UP 1 CREDIT 2 UP
2 CREDIT 1 UP 3 CREDIT 1 UP
BONUS RIGHT 1, 2, 3, 4, 5 , 6, 7, 8 CREDIT
TICKET RATE 30T/10 , 35T/10, 38T/10, 40T/10, 42T/10, 45T/10,
48T/10, 50T/10, 55T/10, 60T/10, 70T/10, 80T/10,
90T/10, 100
90T/10, 100T/10, 110T/10, 120T/10
JACKPOT RATE
1/3 , 1/4, 1/5, 1/6, 1/7, 1/8, 1/9, 1/10 1/12, 1/15, 1/20,
1/25, 1/30, 1/50, 1/70, 1/100,
TIMER 5 ,10,15,20,25,30 SEC
 
  
  Box value is the default value
Lottery (Bonus) only dispense in single mode

9
Bowling shot
Chapter 8 T i c k et c al c u l ati o n
YOUR SCORE
HIP PIN POINT X CREDIT TICKETS
Token number represents betting value: increase betting value in order to
win more lottery tickets
ANY
ANY
TOTAL
9
TOTAL
8ANY
Down
Pins
Insert
Tokens
2 strikes
spare and
under 8
pins
under 8
pins and
spare
9 pins 8 pins 1~7pins
1 25 tickets 10 tickets
5 tickets 3 tickets
2 tickets
1 tickets
2 50 tickets 20 tickets
10 tickets
6 tickets
4 tickets
2 tickets
3 75 tickets 30 tickets
15 tickets
9 tickets
6 tickets
3 tickets
4 100 tickets
40 tickets
20 tickets
12 tickets
8 tickets
4 tickets
5 125 tickets
50 tickets
25 tickets
15 tickets
10 tickets
5 tickets
6 150 tickets
60 tickets
30 tickets
18 tickets
12 tickets
6 tickets
7 175 tickets
70 tickets
35 tickets
21 tickets
14 tickets
7 tickets
8 200 tickets
80 tickets
40 tickets
24 tickets
16 tickets
8 tickets
9 225 tickets
90 tickets
45 tickets
27 tickets
18 tickets
9 tickets
10 250 tickets
100 tickets
50 tickets
30 tickets
20 tickets
10 tickets
11 275 tickets
110 tickets
55 tickets
33 tickets
22 tickets
11 tickets
12 300 tickets
120 tickets
60 tickets
36 tickets
24 tickets
12 tickets
13 325 tickets
130 tickets
65 tickets
39 tickets
26 tickets
13 tickets
14 350 tickets
140 tickets
70 tickets
42 tickets
28 tickets
14 tickets
15 375 tickets
150 tickets
75 tickets
45 tickets
30 tickets
15 tickets
16 400 tickets
160 tickets
80 tickets
48 tickets
32 tickets
16 tickets
17 425 tickets
170 tickets
85 tickets
51 tickets
34 tickets
17 tickets
18 450 tickets
180 tickets
90 tickets
54 tickets
36 tickets
18 tickets
19 475 tickets
190 tickets
95 tickets
57 tickets
38 tickets
19 tickets
20 500 tickets
200 tickets
100 tickets
60 tickets
40 tickets
20 tickets

10
Bowling shot
Chapter 9 T ro u b l e ho o ti n g
trouble shooting list
Error Code Meaning Trouble shutting
APPEND COIN
1.COIN SW Error
2.Coin selector error
1. Check if token is valid. Replace
for a valid token or contact
customer service department.
2. Check if coin is stocked. If it’s
not, replace the coin selector.
TICKET ERROR!
1. Tickets jam
2. No ticket
3. Ticket dispenser
error
1. Clear tickets Jam
2. Add tickets
3. Replace the Ticket dispenser
POWER DOWN
COIN 
CREDIT 
TICKET 
Abnormal shut
down
Press reset button
back to standby
function.
Chapter 10 B etti n g A tten ti o n


Betting maximum: CREDIT 20
Ex. 1Setup 1 COIN / 1 CREDIT
Betting 20 credits, needs to insert 20 tokens, number of credits will
display on the top right side of screen.
Credit 20, (In the same time) the coin counter will add 20 as well.




Insert token after credit reach 20, token will be consider as no value
but in counter will continue adding
Ex. 2Setup 2 COIN / 1 CREDIT
Betting 20 credits, needs to insert 40 tokens, number of credits will display
on the top right side of screen.
Credit 20, (In the same time) the coin counter will add 40 as well. 


Insert token after credit reach 20, token will be consider as no value but
in counter will continue adding

11
Bowling shot
Chapter 11 P art n am e
Strike lights
Speaker
Left Right Control Panel
Screen (Monitor)
Bowling lane
Bowling dispenser
Coin selector
Start button
Tickets dispenser
