Saje AROMA RISE CASCADE User manual

1
ultrasonic diuser
diuseur ultrasonique
Please read and save this manual
AROMA RISE
cascade

Infuse your air with the vitality
and well-being of nature
ultrasonic diuser
diuseur ultrasonique
AROMA RISE
cascade

TABLE OF CONTENTS
   1
  2
 3
   5
  6
  9
 11
   13
s15

1
BENEFITS OF DIFFUSING
Diffusing is an easy, heat-free way to enjoy Saje’s 100%
natural diffuser blends.
This ultrasonic technology, combined with water and
essential oils, produces negative ions and aromas that
elevate your well-being.
When used with your favorite Saje diffuser blend, the
ultrasonic diffuser's refreshing mist brings nature's
goodness into your space, supporting balance and
harmony.
Transform your surroundings with revitalizing air
that's reminiscent of fresh mist off a waterfall. Add
the Saje diffuser blend of your choice and enjoy fresh,
inviting aromas any time.

2
PRODUCT FEATURES
 Uses an ultrasonic, heat-free system to disperse
essential oil molecules into the air.
 Gently humidifies your space.
 Whisper-quiet operation and auto shut-off.
 Continous and intermittent output setting.
 Operates with light on or off.
 Textured cement cover.

3
SPECIFICATIONS
product name Aroma Rise Cascade
input voltage AC100-240V
output voltage DC24V
rating power 12W max.
water tank capacity 4.05 fl oz | 120 ml
misting duration
approx. 4 hours continuous |
approx. 8 hours intermittent
(30 sec on/30 sec off)
mist output
approx. 0.84 fl oz (25 ml) per
hour on continuous;
approx. 0.4 fl oz (12.5 ml) per
hour on intermittent
settings light on/off control; continuous
mist or intermittent mist; off
light options white LED light on/off control
during any setting

4
coverage area up to approx. 500 sq ft
dimensions approx. (D) 3.5” x (H) 7.3” or
(D) 90 mm x (H) 185 mm
net weight 20.1 oz | 570 g
main materials cover: cement; base: ABS;
water tank: PP; o-ring: silicone

5
DIAGRAM OF PARTS
.  
.  
.   
.    
.  
.  
.  
.  -
.  / 
.   / 
.   
.  
.  
. 














6
OPERATING INSTRUCTIONS
1. Remove the cement cover from the
base, then remove the water tank
cover from the water tank.
2. Connect power adaptor to DC
power jack on bottom side of unit.
3. Fill water tank with room
temperature tap water to no
higher than max. water level line
(120 ml/4.05 fl oz). Tilting the unit
can cause water to run into the
diffuser’s ventilation system and
out the bottom. To ensure correct
usage, always bring water to your
ultrasonic diffuser and not the
other way around.
4. Add 10-15 drops (depending on
preference) of your favourite Saje
diffuser blend to the water.

7
5. Replace the water tank cover and
then the cement cover, ensuring that
they fit properly onto the water tank
and the base.
6. Plug the power adaptor into the
electrical outlet.
7. Press the on/off button (right
button) and select the mist setting.
button indicators:
=
=


st stage-continuous misting:
 : Mist emits contin-
uously and automatically turns
o after 4 hours of operation
nd stage-misting intervals of
 seconds:    :
Mist emits at intervals of 30 sec-
onds and automatically turns
o after 8 hours of operation
rd stage-power off:
   : Mist o
Optional (left button):
LED light on/LED light o

8
8. Unit will shut off automatically after 4 hours
(continuous setting) and 8 hours (intermittent setting).
Note that the water level remaining in the tank after
shut-off will vary. For next use, fill up water level to the
max. water level line with new water supply.
9. A filled unit should never be moved. Always wait until
water reaches minimum levels to change diffuser’s
location; this will deter water from entering the
ventilation system.
10. Use only Saje diffuser blends; using other oils may
result in malfunction.
please note: run times and amount of water left in
the tank after auto shut-off will vary due to climate,
environment and other factors.
for optimal operation, ensure mist is unobstructed by
overhanging objects.

9
CARE & MAINTENANCE
 If the unit is knocked over while in operation, water
could leak into the internal mechanism of the unit;
if this occurs, unplug from power, empty water and
let unit dry out in well-ventilated area for at least
three days.
 Turn off unit and unplug from the power adaptor
prior to cleaning.
 Remove cover and empty water from the water tank,
carefully avoiding the air outlet.
 To clean exterior of unit, wipe outer lid with a dry
cloth. Do not allow essential oils to spill on outer lid.
 Clean inner lid with a damp cloth. Do not submerge
or wash entire lid under water.
 If oils are spilled on the diffuser’s surface, clean
immediately to prevent surface damage.
 Frequency of water tank necessary cleaning is
dependent upon usage and types of diffuser blends

10
used (i.e. how thick the essential oils are in the
diffuser blend).
 To clean inside water tank, pour a few drops of
rubbing alcohol or Saje Multi Clean All Purpose
Cleaner into tank and wipe with a clean, soft cloth.
Do not use vinegar or dish soap.
 To clean ceramic disc at bottom of water tank,
dispense a few drops of rubbing alcohol onto a clean
cotton swab and wipe clean.
 The top of the ceramic disc should be gently
wiped of mineral deposits and other debris for
optimal misting. Never use any sharp objects to
clean the ceramic disc as this will damage the disc
permanently.
 For optimum results, clean the water tank before
changing diffuser blends.
 Do not disassemble or attempt to repair the disc
or unit; in the event of a problem, please contact
1-877-ASK-SAJE.

11
CAUTIONS
 Only use the power adaptor supplied. Never operate
the unit if the power adaptor or any part of the unit
is damaged or broken.
 To reduce the risk of electric shock, do not attempt to
service the device in any way other than as described
in the “Care & Maintenance” section of this manual. Do
not plug the unit into the wall socket with wet hands.
 Do not attempt to empty, refill, move or clean unit
while in use or plugged in. When moving the device,
hold securely by the base. Always place the unit on a
stable, level surface.
 Do not touch the highly sensitive ceramic disc with
bare fingers when the ultrasonic diffuser is in use
or plugged in. To prevent clogging or damaging the
ceramic disc when operating, use clean tap water at
room temperature.
 Do not fill water tank directly from tap as water
could spill into the internal mechanism and cause

12
damage. Fill only to the water level line and do not
overfill or immerse the unit in water. Do not pour
water or other liquid into the air outlet.
 After each use, remove any liquid left in the water tank.
 Ensure that the power adaptor is not covered or
blocked when plugged in; it must be able to dissipate
the heat properly.
 Use only Saje diffuser blends in device: other oils may
contain fragrances, base oils or synthetics that could
result in malfunction. Some single note essential oils
are also too thick or heavy for use in the ultrasonic
diffuser. See FAQs for more information.
 In case of smoke, unusual aromas, noises or other
malfunctions, unplug the unit immediately and
discontinue use. Further use may result in fire or
electric shock.
 Always keep unit out of reach of small children and pets.

13
FCC & IC STATEMENTS
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
1) This device may not cause harmful interference,
and
2) This device must accept any interference
received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,

14
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
 Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Changes or modifications not expressly approved by
Saje Natural Wellness Canada could void the user’s
authority to operate this equipment. This device
complies with Part 18 of the FCC Rules and ICES 001.
Although this product is tested and complies with FCC,
it may interfere with other devices. If this product
is found to interfere with another device, separate
the other device and this product. Conduct only the
user maintenance found in this instruction manual.
Other maintenance and servicing may cause harmful
interference and can void the required FCC compliance.

15
FAQs
q: what if my unit does not turn on?
The power adaptor may not be properly plugged in;
ensure that the power adaptor is properly plugged into
the DC power jack and the electrical source.
q: what if my unit does not mist or there is almost no mist?
. There may not be enough water in the water tank;
ensure that the water tank is filled to the maximum
water level line.
. The water level may be too high (higher than the
maximum water level line); turn off unit, pour out
excess water and try again.
. The ceramic disc may require cleaning. Please see
“Care & Maintenance” instructions.

16
q: what type of water should go into my ultrasonic
diffuser?
To prevent clogging or damage to the unit or disc,
it’s recommended to use clean tap water at room
temperature.
q: what can i put in my ultrasonic diffuser?
We recommend using 100% natural Saje diffuser
blends, as they have been carefully blended for safe
and easy use in your ultrasonic diffuser. Other blends
and oils may contain fragrances, base oils or synthetics
that have a thick and heavy consistency and could
result in your unit’s malfunction.
All Saje 100% Pure Single Note Essential Oils may be
diffused, except the following:
 Ylang Ylang
 Patchouli
 Sandalwood
 Jasmine
 Rose

Imported and distributed by / Importé et distribué par :
saje natural wellness
22 east 5th ave vancouver, bc canada
v5t 1g8 | saje.com | 1-877-ask-saje | @sajewellness
made by our friends in china. fabriqué en chine
i'm made from recycled paper. please recycle where possible
