Salamander Designs SYNERGY DOUBLE-WIDTH SHELF SA/DS User manual

SYNERGY DOUBLE-WIDTH SHELF - SA/DS
4x
(300-490)
Low Head Screw
4x
(300-560) - Flat Nut
Installing the Double-Width Shelf to Assembled Units
Without Removing Top:
Remove center connector bolt and loosen all other top bolts.
Unscrew the foot below the center post and CAREFULLY
remove the post.
Use the Drop-In Nuts in place of the Flat-Nuts in step 2.
Removing Top (Recommended):
Remove top connector bolts and set aside for step 5.
4x
1x
(300-565)
Drop In Nuts
Hardware Bag - PHK-510
1/8” Hex Key (400-070)
Parts
1 - Center Post
1 - Double-Width Shelf
2 - Shelf Brackets
2x
(301-280)
Plastic Cap Plug
4x
(300-610)
Shelf Tabs 1x
(300-265)
Post End Cap
1
A.Connect Post
Install short post front and center. Square the
post to the bottom shelf and screw foot with
metal washer through to the extruded post.
Hand tighten fully and use wrench to tighten
nut onto underside of shelf.
B.Post Cover
Press post cover onto the center post to protect the center shelf.
Connect Post to Bottom Shelf
Leveler Foot
Hex Nut
Washer
1x (PHK-380)
Shelf Peg “A” 1x (PHK-370)
Shelf Peg “B”
WARNING:
Tighten by screwing the leveler foot NOT the post.
!!
90O
©2005 Salamander Designs Ltd.. Doc# 500-950 / v6.05 / 1 of 2

2Shelf Brackets
3Place Shelf 4Final Assembly
©2005 Salamander Designs Ltd.. Doc# 500-950 / v6.05 / 2 of 2
Limited Warranty
For five full years Salamander Designs Ltd. will repair or replace, at our option, any product defective in materials or craftsmanship. Salamander Designs Ltd. will not be responsible for any
damage to or destruction of other equipment consequential to our equipment failure. Defective product must be given Return Authorization and is to be returned to the factory prepaid, in the
original carton and packing material. Any damage incurred in a shipment not in original packaging shall be the responsibility of the owner. Warranty repairs will be returned prepaid, via
UPS within the continental U.S.A. only. Salamander Designs Ltd. • 800-535-5659 • www.SalamanderDesigns.com
SALAMANDER DESIGNS
SALAMANDER DESIGNS
A. Place the low head screws through the 2 holes of
each shelf bracket and attach loosely to *Flat Nuts.
* If you are installing the shelf to an assembled unit
use the Drop-In-Nuts in place of the Flat Nuts.
B. Insert 2 rubber shelf tabs though the top of each bracket.
C. Slide the flat nuts/bracket down the post channels.
D. Position the brackets close to the top of the center post.
Note:
If installing Doors below the Double-Width Shelf slide
shelf pegs down both sides of center post as door stops.
Shelf rests securely onto rubber tabs and center post. Secure top with connector bolts.
Use the plastic cap plugs to
conceal center hole.
B A
