Salient technology V-mouse vm-203 User manual

STI2006-2x3ML-v1p2

V-Mouse VM-203/VM-223 User Manual

Multi-language Pack

- English

- 中文

- Français

- Deutsch

- Español

- Italiano

- Nederlands

- Português

Salient Technology Inc., U.S.A.

1/97

STI2006-2x3ML-v1p2

V-Mouse VM-203/VM-223 User Manual

STI2006-200EN

Salient Technology Inc., U.S.A.

2/97

STI2006-2x3ML-v1p2

Before operating the unit, please read this instruction manual thoroughly, and retain it for

future reference. Paragraphs marked with [VM-223] are for Model VM-223 only.

This product contains an internal rechargeable Lithium battery and is not

user- serviceable. Please observe the following safety guide to avoid

potential harm to the user, the surroundings, and the product:

Do not expose the product to extreme heat or flame. The built-in battery may

leak or even explode when exposed to extreme heat.

Keep the product dry and never immerse it into water or any liquid.

Use the product in the temperature between 10 °C and 40 °C (50 °F and 104

°F). The built-in battery will be permanently damaged if exposed to extreme

heat (over 45 °C / 113 °F) or extreme cold (under 5 °C / 40 °F).

Use only the supplied USB charging cable to charge the battery.

Do not disassemble the product under any circumstances.

Stop using the product immediately in the event that the product feels hot or

battery leakage occurs. Call the service center immediately if any of these

conditions occur.

Please observe the radio device regulation of the local authority and turn off

the power (put the device in Hibernation Mode) in places where radio

transmission is not allowed. (Refer to the Hibernation Mode On/Off Section in

the Operation Section for detail.)

[VM-223] This product contains a low-power laser component and is not

intended to be used by a minor without adult supervision. When

operating the laser function please use caution and never point the laser

beam at a person or live animal, either directly or indirectly. Misusing the

device or allowing minors to operate the device without adult supervision

may violate the local law.

3/97

STI2006-2x3ML-v1p2

FCC Compliance (FCC ID: TDGVM200RF)

The equipment has been tested and found to comply with the limits for a

Class B Digital Device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in

accordance with the instruction, may cause harmful interference to radio

communication. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment dose causes harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

The user should not modify or change this equipment without written

approval from Salient Technology. Modification could void authority to

use this equipment.

The changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate the

equipment.

To comply with the FCC RF exposure compliance requirements, this

device and its antenna must not be co-located or operating to conjunction

with any other antenna or transmitter.

CE This device complies with the essential requirements of the European

Council Directive listed below:

99/5/EC Radio & Telecommunication Terminal Equipment (R&TTE)

Directive

Art.3.1a) EN 60950

Art.3.1b) EN 301 489 -1/-3

Art.3.2) EN 300 440

4/97

STI2006-2x3ML-v1p2

Canada - Low Power License-exempt Radio Communication Device

(RSS-210)

a. Common Information

Operation is subject to the following two conditions:

1. This device may not cause interference, and

2. This device must accept any interference, including interference that

may cause undesired operation of the device.

b. Operation in 2.4 GHz band

To prevent radio interference to the licensed service, the device is

intended to be operated indoors and installed outdoor is subject to

licensing.

5/97

STI2006-2x3ML-v1p2

PARTS IDENTIFICATION

6/97

STI2006-2x3ML-v1p2

USB Connector Plug into the USB port of the computer.

Transmission Status Light Displays the wireless transmission status.

Channel Select Button A Press down once to activate wireless channel selection.

Hold down the Channel Select Button B and press down

the Right Mouse Button once to set wireless channel.

Channel Select Button B

[VM-223] Press down with the Laser Pointer Button

together to toggle between the Mouse Mode and the

Presenter Mode.

Performs the mouse right button function.

Double-click to enter the Scrolling Mode.

V-Mouse Right Button

[VM-223] Performs the Page Up function in the

Presenter Mode.

Performs the mouse left button function.

V-Mouse Left Button

[VM-223] Performs the Page Down function in the

Presenter Mode.

Battery Status Light Battery status indicator.

Battery Low: Flashing

Battery Charging: On

Battery Full: Off (Remark A)

Connector A Connects to the USB port to charge battery.

Connector B Connects to the Battery Charging Jack to charge battery.

Battery Charging Jack Receptacle of Connector B.

Press down in the Presenter Mode to turn on the Laser

Pointer.

[VM-223] Laser Pointer Button

Press down with the Channel Select Button B together to

toggle between the Mouse Mode and the Presenter

Mode.

Remark A: When the battery power is extremely low the Battery Status Light will

be turned off.

7/97

STI2006-2x3ML-v1p2

HARDWARE SETUP

A. Charging Up the Battery

For safety reasons, the battery was partially charged in the factory before

packing. You should fully charge up the battery before using the device

the first time.

1. Insert Connector B of the USB Charging Cable into the Battery

Charging Jack.

2. Insert Connector A of the USB Charging Cable into a USB port.

When the battery is charging the Battery Status Light stays on.

3. Wait until the Battery Status Light turns off and remove the USB

Charging Cable. The normal charging time should be 2 to 3 hours

if a dedicated USB port is used. Charging time will be longer if a

non-powered USB hub is used. (Remark B)

4. Repeat Steps 1 to 3 when the battery is flashing. You can keep on

using the device during charging; however, the charging time will

be extended. (Remark C)

Remark B: Use a dedicated USB port or a powered USB Hub for fastest charging.

Remark C: Lithium batteries do not have memory effect and can be partially

charged.

B. Installing the Device

1. Turn on your computer, if it is not already on.

2. Turn on your V-Mouse by pressing down both the left button and

the right button for 10 seconds, if it is not already on. (Remark D)

3. Connect the Dongle Receiver to a USB port. A message “wireless

pen mouse (2.4 GHz)” should appear on your computer screen.

Allow the automatic set up process to complete and the messages

to disappear. (Remark E)

4. Press down the Channel Select Button A on the Dongle Receiver

once and the Transmission Status Light should start flashing.

5. Hold down the Channel Select Button B and press down the Right

Mouse Button once and then release both buttons. Wait for the

Transmission Status Light to turn off, the installation is

completed.

6. After the first successful installation, your Dongle Receiver and

V-Mouse are permanently matched. You DO NOT need to repeat

Steps 4 and 5 even when you take your V-Mouse to a different

computer.

7. Repeat steps 4 and 5 to re-establish the transmission channel

setting when needed.

Remark D: For safety reasons, your V-Mouse was shipped with the power turned

off. Please turn on the power before using it the first time.

Remark E: The series of messages will appear on each computer only once,

when it receives the V-Mouse dongle the first time.

8/97

STI2006-2x3ML-v1p2

OPERATION

A. Adjusting the Mouse Speed Setting

On Windows Computer:

Click on Start/Settings/Control Panel from the root Window Frame to bring

up the Control Panel and click on the Mouse icon to bring up the Mouse

Setting Pane. Adjust the Speed Setting (using the slider) to the ¼ position

from the slow end. Turn off the Acceleration function if it is available.

Save the setting and exit the Control Panel.

On Apple/Mac Computer:

Open the System Preferences and bring up the Keyboard And Mouse pane.

Adjust the Mouse Tracking Sensitivity to a slower setting as needed. Save

the setting and exit the System Configurations.

B. Using the Device

1. We suggest first-time users start with the “lap-style”. That is, hold

the V-Mouse like a pen and put your holding fist on your lap.

2. Keep the bottom of your fist on your lap and rest your elbow firmly

against your body or a stable object. Use the device as if you were

making a drawing on your lap to control the pointer movement on

the computer screen.

3. Adjust the mouse speed setting as needed (Refer to subsection A

of the OPERATION Section) to make the pointer control operation

as comfortable as possible.

4. Once you are used to the operation, you can try the V-Mouse on

the desk top or any other surfaces.

5. Double-click the Right Mouse Button in rapid succession will put

the mouse in the Scrolling Mode and change the Mouse Pointer

into a round “scrolling icon”. The movement of the mouse now

controls the scroll bars of the active window. (Remark F)

6. Click or press down any button in the Scrolling Mode will bring the

mouse back to the Mouse Mode.

Remark F: This “Third Mouse Button” scroll function does not work in all software

applications. Some software vendors and older software may use a

different protocol and therefore does not behave like the Internet

Explorer Browser. You should not assume that the V-Mouse Scrolling

Function works in a specific software until you have tried it.

C. 3-Stage PowerSave Feature

Your V-Mouse has a built-in 3-stage power save feature to maximize the

9/97

STI2006-2x3ML-v1p2

battery usage. If it stays idle for more than a second, the LED dims and

the V-Mouse goes into Stage One Power Save Mode. In Stage One, the

motion sensor and the buttons remain operational. If the V-Mouse

remains idle for 5 minutes in Stage One Power Save Mode, the LED starts

flashing and the V-Mouse enters Stage Two Power Save Mode. In this

mode, the motion sensor and the buttons remain operational.

If the V-Mouse remains idle for 60 minutes in Stage Two Power Save

Mode, the LED turns off and the V-Mouse enters Stage Three Power

SaveMode. In this mode the motion sensor is turned off but the buttons

remains operational. (Remark G)

Remark G: Clicking the mouse button in any Power Save mode will bring the

V-Mouse to the normal Mouse Mode immediately.

D. Turning Power On/Off

To turn off the power of the handheld unit, press down the Left Button

and the Right Button at the same time for 10 seconds and wait for the

Blue LED to turn off.

To turn on the power of the handheld unit, press down the Left Button

and the Right Button at the same time for 10 seconds and wait for the

Blue LED to turn on.

You DO NOT have to reinstall the device or reset the communication

channel between the handheld device and the receiver after turning off

the power.

E. Using the Laser Presenter Function [VM-223]

Hold down the Channel Select Button B and press down the Laser Pointer

Button once will put the V-Mouse into the Presenter Mode. In the

Presenter Mode, the Blue LED is turned off, the Right Button becomes the

Page Up button, and the Left Button becomes the Page Down button.

Hold down the Channel Select Button B and press the Laser Pointer

Button once again will switch the V-Mouse back to the Mouse Mode.

For safety reasons, the VM-223 comes with an automatic Laser Shut-off

function. The Laser Pointer will automatically turn off when the laser

button is pressed down for 4 minutes.

To avoid confusion, the VM-223 returns to the Mouse Mode when the

device is unattended for 1 hour in the Presenter Mode.

PRODUCT CARE

There are no user-serviceable parts in this product and you should not

disassemble it under any circumstances without proper training/

authorization. Following the safety guidelines in the Safety Caution

Section and this product should last for a long time. Occasional cleaning

with a slightly damped soft towel on the outside will help keep its

appearance in good condition.

10/97

STI2006-2x3ML-v1p2

PRODUCT SPECIFICATIONS

2.4 GHz RF technology based, rechargeable, 2 button, pen-style, USB

wireless, 1000-DPI optical mouse with scrolling function.

Laser presenter with Page Up and Page Down functions. [VM-223]

System Requirements

Windows 98 SE, ME, 2000 or XP with a USB port,

Mac OS 6.8 or higher with a USB port,

Linux OS with a USB port,

Dongle Receiver

USB 1.1 interface

Dimension: 57mm x 18mm x 9mm

V-Mouse

1000 true optical Dot-Per-Inch resolution

Blue LED

2 independent mouse buttons

Scrolling function

Built-in rechargeable Li battery

10 meter / 30 feet transmission distance

Built-in 3-stage power-save feature

Laser presenter with Page Up and Page Down functions. [VM-223]

Automatic Laser Shut-off function [VM-223]

11/97

STI2006-2x3ML-v1p2

TROUBLESHOOTING

Symptom Cause/Solution

System does not recognize the USB

Receiver. •System does not meet product requirement. ->

Upgrade system or move to a different computer.

•USB port is malfunction. -> Use a different USB

port.

V-Mouse does not light up. •Battery power is too low. -> Charge up the

battery.

•V-Mouse is still in Presenter Mode. -> Hold down

the Channel Select Button B and press the Laser

Pointer Button once to switch back to the Mouse

Mode then try again. [VM-223]

•V-Mouse is in Stage Three Power Save Mode. ->

Click on the button once.

•Power is turned off -> Press down both buttons

for 10 seconds to turn power on.

Mouse Pointer does not move. •Work surface is reflective. -> Use a

non-reflective work surface.

•Battery power is too low. -> Charge up the

battery.

•Communication setting on the V-Mouse may be

changed. -> Reset the transmission setting. (See

Hardware Setup, Sec. B)

•V-Mouse LED is off. -> Fix the LED problem.

(Symptom 2)

•V-Mouse tilt angle is too big. -> Make sure the

focus line is in contact with the work surface.

Battery does not charge. •Charging cable is not properly connected. ->

Reconnect the cable.

•USB port is malfunctioning. -> Use a working

USB port.

Power does not turn on. •Battery power is too low. -> Charge up the

battery first.

Power does not turn off. •Mouse is in Presenter Mode. -> Hold down the

Channel Select Button B and press the Laser

Pointer Button once to switch back to the Mouse

Mode then try again. [VM-223]

WARRANTY

This product comes with a 1-year warranty on the rechargeable battery

and a 2-year limited warranty covering all other parts and craftsmanship

from the day of purchase. This warranty does not cover normal wear and

tear, theft, loss or damages caused by intentional or unintentional

negligence from the user, by foreign violence or by nature. Battery failure

due to exposure to extreme heat or cold or other negligence is not

covered.

ENVIRONMENTAL AWARENESS

Please dispose of the packing material properly. Please dispose of the

device properly when the product life is over. Littering is bad for the

environment and may violate the local law.

12/97

STI2006-2x3ML-v1p2

HEALTH AWARENESS

Your health is important. Prolong use of any muscle in a repetitive fashion

is likely to cause health problem and may develop permanent injuries.

Experts suggest that frequent change of positions and taking

micro-breaks may reduce your risk of developing repetitive stress

injuries.

CONTACT INFORMATION

Salient Technology Inc.

1140 Vista Monte Drive,

San Ramon, CA 94582

U.S.A.

Hotline: 1-866-721-6122 / 925-829-5654

www.pen-mouse.com

Waste Electrical and Electronic Equipment

(WEEE-Directive)

Following information is only for EU-member states:

The use of the symbol indicates that this product may not be treated

as household waste. By ensuring this product is disposed of correctly,

you will help prevent potential negative consequences for the

environment and human health, which could otherwise be caused by

inappropriate waste handling of this product. For more detailed

information about recycling of this product, please contact your local city

office, your household waste disposal service or the shop where you

purchased the product.

13/97

STI2006-2x3ML-v1p2

V-Mouse VM-203/VM-223 使用手冊

STI2006-200CN

Salient Technology Inc., U.S.A.

14/97

STI2006-2x3ML-v1p2

使用本產品前請詳閱本使用手冊,並請妥善保管以便日後參考。含[VM-223]標記

之章節與段落只適用於 VM-223 產品型號。

本產品採用內建式充電鋰電池，不宜自行修護。請注意以下安全指南以避免對己

身、周遭環境和產品造成可能的傷害：

勿將產品暴露於極高溫或接近火焰以避免電池漏液及其他危險。

保持產品乾燥，切勿浸水或浸泡於任何液體內。

請保持產品溫度在 10°C和40°C (華氏 50 至104 度) 之間。如暴露在極

熱(45°C /113°F)或極冷 (在 5°C /40°F)溫度下，內建電池將會受損。

充電時只可使用本公司提供之USB充電電線。

在任何情況下不得拆卸產品。

如果產品有異常發熱或電池漏液異狀時，請即刻停止使用並儘速聯絡服務中

心取得協助。

請遵守當地政府的無線電設備管理規章，在禁止無線電器材使用的地方關閉

電源。(請參見電源開關部分操作細節。)

[VM-223] 本產品採用一個低功率雷射 (Laser) 組件，禁止未成年人在無成人監

督時使用。當操作雷射時請勿直接或間接地把雷射光束指向人或動物。誤用本產

品或在無成人監督下允許未成年人操作本產品，可能觸法。

15/97

STI2006-2x3ML-v1p2

交通部電信總局低功率電波輻射性電機管理辦法 (930322)

根據交通部低功率管理辦法規定：

第十二條經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得

擅自變更頻率、加大功率或變更原設計之特性及功能。

第十四條低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現

象時，應立即停用，並改善至無干擾時方得繼續使用。前項合法通信，指依

電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信或工業、科

學及醫療用電波輻射性電機設備之干擾。
