Salind 11 4G User manual

Read the instructions carefully before using the
GPS tracker for the first time. Keep the instruc-
tions somewhere safe in case you may need it
in the future. However, do not hesitate to con-
tact us if you have any problem or doubt via
WhatsApp, Chat or Email.
... for ordering our GPS tracker!
1
Thank you very much,

2
Contents
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Scope of delivery ..................................
Product description ............................
Charging ....................................................
Activation .................................................
Start-UP ......................................................
Use ..................................................................
Meaning of the LED lights ................
Technical details .....................................
Safety instructions ................................
Instructions for disposal of used
batteries ......................................................
Instructions for disposal of
electrical devices ....................................
3
4
5
6
7
8
9
10
11
16
18

Scope of delivery:
• GPS tracker Salind 11 4G
• M2M SIM Card (already in place, not interchangeable)
• USB charging cable
1.
3
Scope of delivery

LED lights
SIM Card
(already in place,
not interchangeable)
Charger port
Protective flap
4
Product description
2.
On-off switch

5
The Salind GPS Tracker 11 4G offers you approxi-
mately 60 days of operation without any in-bet-
ween charging! However, it should be noted that
the duration depends on the load. The more the
GPS tracker is moved and the more alerts are
sent, the higher the utilization.
Before using the GPS tracker for the first time,
fully charge it. Connect the supplied charging
cable to the charging port on the GPS tracker.
Then, connect the USB end of the charging
cable to the wall plug adapter and plug it into
a power outlet. Once the GPS tracker is con-
nected to the power source, please charge it
until the red LED turns off.
3.
ActivationCharging

6
ActivationCharging
4.
In order to start using your GPS tracker first
you will have to activate it online. Please
enter the following link and follow the
instructions:
www.start.finder-portal.com
NOTE!
To activate you need the device ID. Please make a note
before installing your GPS tracker.

Switch on
5.
For the initial start-up, open spaces, such as the
garden or the terrace, are recommended
(i.e. not indoors, in a garage, a cellar, or anything
similar).
When activation is successful, turn on the
GPS tracker by sliding the switch located un-
der the protective rubber to the right. The LED
lights then activate. To switch off, move the
switch to the left.
On-off switch
7

8
6.
Use
Once the start-up of the GPS tracker was suc-
cessful, you can attach the tracker to a location
of your choice and view the position of the
tracker using a smartphone, tablet or PC. Plea-
se use our app or go to the following website:
v2.finder-portal.com

Is the red LED on?
The GPS tracker is charging.
Is the red LED off?
The GPS tracker is fully charged
(please note that this may not be the case
after the first charge).
All LED lights are off?
The GPS tracker is in Standby mode or
rather off.
The blue LED is fixed?
The GPS reception is available.
The blue LED is blinking?
There is no available GPS reception.
The GPS tracker is looking for a signal.
9
Meaning of the
LED lights
7.
The orange LED is fixed?
The GSM signal is available.
The orange LED is blinking?
There is no available GSM signal.
The GPS tracker is looking for a signal.

10
Technical details
8.
Dimensions 109 mm x 76 mm x 26 mm
GPS accuracy Up to 10 meters
Battery 7500 mAh Li-ion
Time to start Cold start: 60 s
Standby: 30 s
In operation: 10 s
Weight 256 g
Network GSM/GPRS
Band LTE/4G
LTE-FDD: B1/B3/B5/B7/B8
B20
(max. 2W / min. 0,07W)
GPRS/2G
GSM 900 MHz. (max. 2W)
DCS 1800 MHz. (max. 1W)
GPS Chip MT2503
GPRS / LTE Modul SIMCOM A7670E
GPS reception -162 dBm
Storage temperature From -30°C to +75°C
Operating environment From -10°C to +55°C

Safety Instructions
The following signal words are used in these
operating instructions:
NOTE!
This signal word is used to draw your attention
to an issue or situation. It also serves as a recom-
mendation for proper use. Possible damage to
property or personal injury can be prevented if
this is observed.
WARNING!
This classifies a hazard of medium risk level.
Failure to observe the warning may result in
serious injury or damage.
11
9.
Safety Instructions

Proper use
Read these safety instructions for this GPS tracker carefully before using
it for the first time in order to use it properly. The intended use of the GPS
tracker to locate an object or a living being is only that described in this
manual. Please note that it is a criminal offence to monitor third parties
using a GPS tracker without their consent. If you use it in any other way,
it will be considered improper and may result in damage to property or
even personal injury. Please note that the GPS tracker is not a child‘s toy.
In other countries and regions there are different laws concerning digi-
tal positioning and tracking of people, animals and/or objects. Salind UG
cannot be held responsible if such laws or regulations are violated. The
user is held solely responsible for this.
NOTE!
The manufacturer and dealer accept no liability for damage
caused by improper or incorrect use.
A faulty electrical installation or a mains voltage that is too high can lead
to an electric shock. Before use, check the mains voltage of the socket
with the information on the rating plate. To ensure that you can disconnect
the charging cable from the mains as quickly as possible in the event of a
fault, connect the mains adapter so that it is easily accessible. If you notice
any visible damage to your GPS tracker or the charging cable, do not use it.
Only use the original parts supplied to charge the GPS tracker. If the char-
ging cable is damaged, replace it only with original accessories from the
manufacturer. Never place the GPS tracker near flames or hot surfaces. The
GPS tracker isn‘t waterproof. However, we recommend that you use it in dry
environments if possible. The charging cable should only be used indoors.
Keep it away from moisture and do not bend it. Do not open the housing
of the GPS tracker. Leave the repair work to qualified specialists. However, if
you carry out repairs yourself, connect the GPS tracker improperly or operate
it incorrectly, liability and warranty claims are excluded.
Safety
WARNING! RISK OF ELECTRIC SHOCK!
12

Hereafter, you will find information and notes regarding the handling of the
battery: The GPS tracker is powered by a lithium polymer battery. This is not
replaceable and must not be removed or opened. Keep the GPS tracker away
from heat sources and high temperatures, such as direct sunlight in a vehicle
(even when charging the battery). Failure to beware of this warning may re-
sult in the destruction of the battery, overheating, explosion and fire. These
hazards also exist if you use non-original accessories to charge your device. Do
not burn or punch the GPS tracker. Protect it from mechanical damage. Do
not remove, drop, disassemble or modify the battery with pointed or sharp
objects. If a child swallows the battery, seek medical help immediately! If you
need to have the battery replaced, please contact our support team.
WARNING! EXPLOSION AND FIRE HAZARD!
The battery
WARNUNG! VERÄTZUNGSGEFAHR!
Batteries that leak due to damage can cause burns if they come into
contact with the skin. Therefore, never open the battery. However, if the
battery leaks, please wear protective gloves.
Hazards for children and vulnerable people
Please do not allow the GPS tracker to be used unsupervised by people
(including children) with reduced physical, sensory or mental capabilities.
The exception is if they have been instructed beforehand by the person
responsible for their safety of how to use the appliance. Make sure that
your child does not handle small parts (e.g. accessories, etc.). These can
be swallowed and lead to suffocation.
13
NOTE!
Inform your child about the dangers and use of the GPS
tracker.

Electromagnetic compatibility
Please observe all prohibitions and switch off the GPS tracker immedia-
tely in dangerous areas and if it can cause interference. It should not be
used near, for example, medical equipment, fuels and chemicals, or in
blasting areas. Mobile devices may cause interference that can affect
performance. Transformers and very strong magnetic fields must be
avoided. Otherwise, deviations in the transmission may occur.
NOTE!
Failure to observe these recommendations may result in mal-
functions or damage to the GPS tracker.
Cleaning
WARNING! RISK OF DAMAGE!
In the following you will find information and instructions on how to clean
the GPS tracker. Do not use aggressive cleaning agents or brushes. Do
not clean the GPS tracker with cleaning objects (e.g. knives, metal spon-
ges). This can damage the surface. Never put the GPS tracker into water,
in a dishwasher (or similar) and do not use a steam cleaner. The surface
can be wiped with a slightly damp cloth. The GPS tracker should be wiped
completely dry afterwards.
Storage
If you are not going to use the GPS tracker for a long period of time, switch
it off. Place the tracker in its original packaging or in a same size box. Pro-
tect the tracker from dirt and moisture.
NOTE!
Keep the GPS tracker away of children’s reach in order to
avoid possible damage to property or personal injury.
14

Declaration of conformity
Packaging disposal
Hereby, Salind UG (haftungsbeschränkt) decla-
res that the tracker, Salind 11 4G, is in conformi-
ty with the Directive 2014/53/EU. The complete
text of the EU Declaration of Conformity can be
found at the following Internet address:
www.salind-gps.de/konformitaetserklaerung/
Dispose of the packaging according to type.
Throw cardboard and paper to the correspon-
ding container. Foil belongs in the recyclables
collection.
15

The following note is addressed to those who use batteries or
products with products with built-in batteries and who will not
resell them in the form in which they were supplied to them
(end users).
Free recall of used batteries
Batteries must not be disposed of with waste. You are legally
obliged to return used batteries so that proper disposal can be
guaranteed. You can return used batteries to a local collection
point or to your local retailer. As a distributor of batteries, we
are also to take back used batteries, although our obligation
to take back used is limited to the type which we carry or have
carried as batteries in our range. Used batteries of the afore-
mentioned type can therefore either be returned to us with
sufficient postage or handed in directly to our dispatch ware-
house at the following address free of charge:
Salind UG (haftungsbeschränkt)
Auf der Fuhr 3
51570 Windeck
Germany
E-Mail: [email protected]
16
Disposal of used
batteries
10.

Meaning of the battery symbols
Batteries are marked with the symbol of a crossed-out dustbin
(see illustration). This symbol indicates that batteries must not
be disposed of in household waste. Batteries containing more
than 0.0005% mercury by mass, more than 0.002% cadmium by
mass or more than 0.004% lead by mass are also marked with
the chemical name of the pollutant below the dustbin symbol.
The abbreviation „Cd“ stands for cadmium, „Pb“ for lead and „Hg“
for mercury.
17

The Electrical and Electronic Equipment Act (ElektroG) con-
tains a large number of requirements for the handling of
electrical and electronic equipment. The most important
ones are summarised here:
1. Separate collection of WEEE
Waste Electrical and Electronic Equipment that has become waste is re-
ferred to as WEEE. Owners of WEEE must dispose of it separately from
unsorted local waste. In particular, WEEE does not belong in household
waste, but in special collection and return systems.
2. Batteries and accumulators
As a rule, owners of WEEE must separate spent batteries and accumu-
lators that are not enclosed in the WEEE before handing them over at a
collection point. This does not apply if the WEEE is handed over to public
waste management authorities and separated from other WEEE there
for the purpose of preparation for reuse.
3. Options for returning old appliances (WEEE)
Owners of WEEE from private households can hand it in to public waste
management authorities or at the collection points set up by manufac-
turers or distributors as defined by the ElektroG. An online directory of
collection and collection points can be found here:
https://www.stiftung-ear.de/de/startseite
18
Disposal of
electrical devices
11.

4. Data Protection
Old equipment often contains sensitive personal data. This applies in par-
ticular to information and telecommunication technology devices such
as computers and smartphones. For your own sake, please note that each
end-user is responsible for deleting the data on the old equipment to be
disposed of.
5. Meaning of the „crossed-out dustbin“ symbol
The symbol of a crossed-out dustbin regularly displayed on elec-
trical and electronic equipment indicates that the respective de-
vice must be separated from unsorted local waste at the end of
its service life.
6. Manufacturer registration number
As a manufacturer, within the meaning of the ElektroG, we are regis-
tered with the responsible foundation Elektro-Altgeräte Register (Benno-
Strauß-Str. 1, 90763 Fürth) under the following registration number:
DE 58373021
19
