Salvador Escoda CROD User manual

•Do not use the equipment more than 15 minutes at a time
•Do not share power source with other equipment
(e.g. connect it to a power strip)
Export Department:
nd
Provenza, 392 2 floor. 08025 Barcelona
Phone: [phone]
Fax: [phone]
[email protected]

- 2 -
Safety Cautions
This is a high temperature generating device. Make sure that you fully understand this manual before using it.
Do not touch power points with wet hands.
Use rated power
Do not share power source with other devices (e.g. connect it to a power strip)
To prevent danger from damaged power cord, it must be replaced by a manufacturer or an authorized person from
a dealer
Do not disassemble or modify the device without permission from a manufacturer
Keep it away from children.
The device may be overheated if it is used continuously without interruption
(Do not use the equipment more than 15 minutes at a time)
Steam coming from the device is very hot and may cause burn. Do not spray to people or animals.
The nozzle spraying steam is very hot and may cause burn
Do not supply any chemicals other than water.
If it is directly applied to wall paper, coated floor, leather sofa and other no waterproofing materials,
they are likely to be distorted. Be careful when applying it to such materials.
Do not spray liquid or steam from the device directly to electric equipment such as oven.
Make sure that electric wires and cords are disconnected with wall sockets before starting cleaning or maintenance
after completing use of the device.
Features of Product
Product Specification
•Spraying high pressure/temperature steam
•Environment friendly cleaning without chemicals use and sterilization effect with high temperature cleaning.
•As it uses an instant heating method without a hot water generator, there is no possibility of explosion and no
precipitation of harmful materials.
•Adjusting water and stream amount – three levels; strong, medium and weak
•Anti-Overheating device – Dual safety adopting temperature sensor and bimetal
•Remote control
Applicable Areas
•Cleaning Air-conditioner
•Cleaning and Defrosting Refrigerator
•Cleaning Water Purifier and Cooler/Heater
•Removing Slime from Toilet and Bathroom
•Cleaning Body and Wheel of Car
•Cleaning Sink and Plate
•Rated Voltage: 230V/50Hz
•Maximum Output: 2400W
•Spray Pressure: 4.5 bar
•Spray Temperature: 105℃
•Spray Amount: 200㎖/min.
•The Length of Steam Nozzle Hose: 3m
•Weight: kg
•Inside Water Tank Capacity: 4ℓ
•Product Dimension: 211mm(W) x 345mm(L) x 257mm(H))
This environment friendly steam cleaner only uses water and does not use any chemicals with high pressure/
high temperature fine steam spraying technology. The equipment can be applicable to various areas.

Name of Each Part
Contents
The Body of Steam Cleaner (Including Hose, Handle and Nozzle), 2 Cleaning Brush(small, big), remote control
How to Use Product
Open the package and make sure that no content is missing.
[How to Supply Water]
Make sure that the power switch is off and the power plug is disconnected before supplying water.
Open the top cover by rotating it 90 degree anti-clockwise.
Supply approx. 4ℓof clean water slowly to prevent overflow and close the cover.
[Power Connection]
Connect the power cable of the main body to a rated power source. (check if the LED on the front display is on)
-Make sure that only the rated power is used.
-Do not share power source with other equipment
Water Tank Cover
Handle
Control Panel
<Details of Control Panel> <Cleaning Brush>
<Remote control>
<Drain cap>
Steam Nozzle
Inner Water Tank
Body
- 3 -

- 4 -
[How to Operate Steam Cleaner]
In the very initial stage of operation, it discharges water rather than steam.
Place a steam nozzle to an additional water tank or drain (prepare a spare water tank)
Press the steam button to start working.
Pushing the steam button starts warming up. The steam lamp is blinking until the warm up process is completed.
It takes approximately 1 minute 30 seconds to complete the warm up process.
The steam lamp is on and normal steam is discharged once the warm up process is completed.
-Strong/Medium/Weak is cycled when pushing the steam button.
Strong: Steam 60% Water Drop 40%
Medium: Steam 70% Water Drop 30%
Weak: Steam 80% Water Drop 20%
Once steam is sprayed, start cleaning process.
To remove stubborn stain, add a cleaning brush to the front of the nozzle.
※ Do not use the equipment more than 15 minutes at a time – the machine may stop because of heater overheated.
※ Steam coming from the device is very hot and may cause burn. Do not spray to people or animals
※ The nozzle spraying steam is very hot and may cause burn
[Lack of Water]
When there is no water in the inner water tank or lack of water coming from the water induction hose,
alarm sounds and the machine stops.
At this time, the steam lamp starts blinking. The steam button does not work until the heater is cooled.
If you hear alarm sound, supply water for the inner water tank or the water induction hose.
Then, press the cooling/stop button to cool the heater until the lamp stops blinking by discharging water.
When the steam lamp stops blinking after heat is cooled, continue cleaning by pressing the steam button
(strong/medium/weak).
※ No idling for a long time when there is no water. It is dangerous due to rapid overheat of the heater.
[Completion of Work]
When cleaning is completed, press the cooling/stop button to stop the machine.
Press the cooling/stop button again to cool the machine for 20-30 seconds by discharging water.
Press the cooling/stop button to stop the cooling.
Remove water from the machine by opening drain cap at the bottom of machine, and unplug the power cable.
[Maintenance]
Strange materials can be generated inside the machine if it is used for a long time.
Clean compounds and strange materials when amount of steam is significantly reduced or pressure is decreased.
Amount of steam can be restored to the original steam amount and the life of the machine can be extended after
removing such compounds and strange materials.
※How to remove strange materials from the inside (for complete cleaning, water induction method is recommended)
1. Make sure that the power cable is unplugged and power switch is off.
2. Add water to water tank and mix 10 spoons of citric acid.
3. Supply power and pressing the cooling/stop button to induce and discharge the citric acid mixture for more than
15minutes.
4. Turn the power of the main body off by pressing the cooling/stop button and discharge the citric acid mixture
from the inside by opening drain cap at the bottom of machine
5. Repeat above procedure with cool water instead of citric acid mixture three times to completely remove strange
materials from the inside.
