Samcon ExCam XI80 User manual

ExCam®XI80
User Manual

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 2 of 28
Table of contents
1Introduction ..............................................................................................................4
2Technical data ..........................................................................................................4
2.1 Explosion protection............................................................................................4
2.2 Illustration of the model key.................................................................................5
2.3 Electrical parameters of the camera....................................................................6
2.4 System cable SKDP03-T.....................................................................................6
2.5 Optical specifications...........................................................................................6
2.6 Video-technical characteristics............................................................................8
2.7 Other technical data............................................................................................8
3Safety Instructions...................................................................................................9
4Installation ..............................................................................................................11
5Electrical connection .............................................................................................13
5.1 Potential equalization........................................................................................13
5.2 Variants of cable termination.............................................................................14
5.3 Connection work at the device (terminal box) ...................................................14
5.4 Plug-assignment (RJ45)....................................................................................17
5.4.1 Appropriate cables & cable entries..........................................................................................19
5.4.2 Fusing......................................................................................................................................19
5.4.3 Tests prior to switching on voltage ..........................................................................................19
6Network access and visualization ........................................................................20
6.1 Minimum system requirements..........................................................................20
6.2 Set up installation / first use ..............................................................................20
6.3 Allocating IP adress...........................................................................................20
7Visualization/ Analysis Software PIX Connect.....................................................24
7.1 General information about PIX Connect............................................................24
7.2 Focusing the thermal image..............................................................................24
7.3 Adjustment of temperature range......................................................................24
7.4 User interface....................................................................................................25
8Cleaning..................................................................................................................26
9Maintenance / Modification....................................................................................26
10 Disposal / Recycling...........................................................................................26
11 Drawings & 3D models.......................................................................................27

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 3 of 28
Table of Figures and Charts
Table 2-1 Model key..........................................................................................................5
Figure 2-3 Sectional view of SKDP03-T ............................................................................6
Table 2-2 Measurement field and pixel size ......................................................................7
Table 2-3 Other technical data ..........................................................................................8
Table 4-1 Mounting accessories......................................................................................12
Figure 5-1 ExCam XI80 Potential equalization................................................................13
Table 5-1 Potential equalization ......................................................................................13
Figure 5-2 ExCam XI80 T08-VA0.4.K1.GER-N.N-xxx.N-P..............................................14
Figure 5-3 ExCam XI80 T08-VA0.4.K1.GER-N.N-xxx.N-T..............................................14
Figure 5-4 Video Tutorial ExTB-3....................................................................................15
Figure 5-5 Pin assignment of the cable SKDP03-T.........................................................15
Table 5-2 Wire assignment of terminal box ExTB-3(SKDP03-T).....................................15
Figure 5-6 Wired terminal box ExTB-3 ............................................................................16
Figure 5-7 ExTB-3 -> Safe area ......................................................................................17
Figure 5-8 Plug assignment RJ45 ...................................................................................17
Figure 5-9 Plug assignment, RJ45 ..................................................................................18
Figure 7-1 Motorized focus settings in PIX Connect Software.........................................24
Figure 7-2 Adjust temperature range...............................................................................24
Figure 7-3 User interface.................................................................................................25
History of revisions
Product: ExCam® XI80
Title: User Manual for ExCam®XI80
Doc. -Id. 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx
Author: Eva Schneider, Grad. Eng. (UAS)
Created on: 07.10.2021
Rev.
Index
Date
Name
Comment
Approved by
0
07.10.2021
E. Schneider
Compilation of the document
Digital unterschrieben von Steffen
Seibert
DN: cn=Steffen Seibert,
o=SAMCON Prozessleittechnik
GmbH, ou,
Datum: 2022.03.11 15:48:27
+01'00'

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 4 of 28
1 Introduction
The ExCam XI80 is a powerful thermographic camera with an integrated infrared ther-
mometer and autofocus for use in potentially explosive areas. It delivers excellent infra-
red images (80x80p) in a temperature range from -20°C to 900°C. In addition, the ther-
mal imaging camera has extensive analysis functions (e.g. thermal analysis with hot and
cold spots). The ExCam XI80 cannot only see where it is hot, it can also measure the
temperature exactly; and all that in an 8 millisecond interval (Real Time Recording).
When designing the ExCam XI80, our main focus was on safety, mechanical precision
and high quality of stainless steel.
Like all cameras of the ExCam series, it is certified according to European regulations
(ATEX) as well as international ones (IECEx). The explosion-protected housing is ap-
proved for the ATEX group II for zones 1, 2, 21 and 22 including the explosion groups
IIC / IIIC. For more information please visit our website at www.samcon.eu/en
2 Technical data
2.1 Explosion protection
Identification marks
acc. to Directive 2014/34/EU: II 2G (zone 1 and 2)
II 2D (zone 21 and 22)
Explosion protection (gas): Ex db IIC T6 Gb
Explosion protection (dust): Ex tb IIIC T80°C Db
Protection class camera: IP66/68 (IEC /EN 60529)
Protection class terminal box: IP66 (IEC /EN 60529)
Transport/storage temperature: -40°C…+70°C
Ambient temperature (EX): -10°C…+50°C
Named testing laboratory: TÜV Rheinland (number 0035)
EU type approval certificate: TÜV 18 ATEX 8218X (2021)
IECEx Certificate of Conformity: TUR 18.0023X (2021)
Other certificates see: https://www.samcon.eu/en/products/network/excam-xi80/
Attention!
The instructions stated on the type plates have to be observed!

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 5 of 28
2.2 Illustration of the model key
1)
Ex product-
name
2)
Type
3)
Housing-
combination
4)
Temp.-
range
5)
Cable
length [m]
6)
Cable
termin.
7)
Optic
ExCam XI80
T08-
VA0.4.K1.GER-
N.N-
005.N-
P-
012/030/0
55/080
T08-
VA0.4.K1.GER-
N.N-
005.N-
T-
012/030/0
55/080
Table 2-1 Model key
Explanations:
1) ExCam XI80 = Functional camera description of the ExCam Series (technical data/
specification of the individual camera module)
2) T08 = SAMCON Production- Type 08
3) VA0.4.K1.GER = T07 ex d housing (stainless steel 1.4404) with small diameter
ØVA0=48mm)
VA0.4.K1.GER = T07 VA0.4 housing with maximum body length (L.R = 171.2mm)
VA0.4.K1.GER = K1 cable gland flange
VA0.4.K1.GER = Germanium sight glass, suitable for thermographic applications (MIR/ FIR)
4) N.N= Normal ambient temperature range (Tamb > 0°C)
N.N= No high temperature battery installed (Tamb < +50°C)
5) 005.N = Length of the connection line in meter at delivery; 5m is the
standard cable length, max. cable length is: 005…100 [m]
005.N= Non armoured cable
6) P= Plug- termination (standard)
CAT6, RJ-45 plug, AWG 26-22,
TD = Terminal Box Ex-e termination (optional)
7) 0XX = Different optics available:
12°, 30°, 55° and 80°

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 6 of 28
2.3 Electrical parameters of the camera
Power supply of the camera:
Voltage supply: 24 V DC
Reference voltage: 10 - 30 V DC
Maximum power consumption: 2.5 W
Typical power consumption: < 2.0 W
2.4 System cable SKDP03-T
Outside diameter: 12.40 ± 0.3 mm
Bending radius: 8 x Dawhen installed and 4 x Daafter relocation
Data line: 4 x 2 x AWG23/1 CAT.6
Performance elements: 3G1.5 (BK-BU-GN/YE)
Properties: PUR halogen-free, flame-retardant, UV-
resistant, chemical resistance, shielded
Quick link:
https://www.samcon.eu/fileadmin/documents/en/60-Assembling%26mounting/SKDP03-T_Datasheet.pdf
Figure 2-3 Sectional view of SKDP03-T
2.5 Optical specifications
A selection of lenses offers the possibility to precisely measure objects in different dis-
tances; we offer lenses for close, standard and large distances. Please note that the
ExCam XI80 has a fixed optic. A change of optics is not possible. The following table
shows a relationship between the measurement object distance and the pixel size on the
object level.
HFOV: Horizontal field of view
VFOV: Vertikal field of view
DFOV: Diagonal field of view
IFOV: Instantaneous field of view (size of the single pixel on object level)

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 7 of 28
55°-optic
0,05 0,1 0,2 0,3 0,5 1 2 4 6 10 30 100
HFOV 0,057 0,11 0,218 0,325 0,539 1,07 2,14 4,27 6,41 10,7 32 106,7
VFOV 0,057 0,11 0,218 0,325 0,539 1,07 2,14 4,27 6,41 10,7 32 106,7
DFOV 0,08 0,156 0,308 0,459 0,762 1,52 3,02 6,04 9,06 15,1 45,3 150,9
Size of the
single pixel
[mm]
IFOV 0,6 1,2 2,3 3,4 5,6 11,2 22,4 44,6 66,9 111,5 334,5 1114,8
Distance to measurement object [m]
Enlargement of
total measuring
field at object
level [m]
12°-optic
0,05 0,1 0,2 0,3 0,5 1 2 4 6 10 30 100
HFOV 0,022 0,043 0,065 0,11 0,21 0,43 0,85 1,28 2,1 6,4 21,3
VFOV 0,022 0,043 0,065 0,11 0,21 0,43 0,85 1,28 2,1 6,4 21,3
DFOV 0,031 0,061 0,092 0,15 0,3 0,6 1,2 1,81 3 9 30,1
Size of single
pixel [mm]
IFOV 0,3 0,5 0,8 1,3 2,7 5,3 10,6 15,9 26,6 79,7 265,6
Enlargement of
total measuring
field at object
level [m]
Distance to measurement object [m]
30°-optic
0,05 0,1 0,2 0,3 0,5 1 2 4 6 10 30 100
HFOV 0,028 0,056 0,111 0,167 0,279 0,557 1,115 2,23 3,346 5,6 16,7 55,8
VFOV 0,028 0,056 0,111 0,167 0,279 0,557 1,115 2,23 3,346 5,6 16,7 55,8
DFOV 0,039 0,079 0,158 0,24 0,39 0,79 1,58 3,15 4,7 7,9 23,7 78,9
Size of single
pixel [mm]
IFOV 0,33 0,67 1,33 2 3,33 6,67 13,33 26,67 40 66,67 200 666,67
Enlargement of
total measuring
field at object
level [m]
Distance to measurement object [m]
80°-optic
0,05 0,1 0,2 0,3 0,5 1 2 4 6 10 30 100
HFOV 0,09 0,174 0,343 0,509 0,884 1,682 3,357 6,708 10,058 16,8 50,3 167,5
VFOV 0,09 0,174 0,343 0,509 0,884 1,682 3,357 6,708 10,058 16,8 50,3 167,5
DFOV 0,127 0,246 0,483 0,72 1,19 2,38 4,75 9,49 14,2 23,7 71,1 236,9
Size of single
pixel [mm]
IFOV 0,08 1,6 3,2 4,7 7,8 15,5 31 61,9 92,8 154,6 463,7 154,5
Enlargement of
total measuring
field at object
level [m]
Distance to measurement object [m]
Table 2-2 Measurement field and pixel size
For distances smaller than the minimum measuring distance (0.3m@12°;
0.2m@30°/55°/80°), the measuring accuracy can be outside the specification.
As an alternative to the table, you can use the Optris GmbH opticcalculator:
https://www.optris.de/optikkalkulator-fuer-waermebildkameras
Or the free optris Optikkalkulator App:
Optris calculator –Apps bei Google Play

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 8 of 28
2.6 Video-technical characteristics
We use the Optris Xi80 Spot-finder IR-Camera in a pressure-resistant enclosure. For de-
tails, please refer to the Product Documentation, video-technical data of optris®:
https://www.optris.com/optris-xi-80
2.7 Other technical data
Table 2-3 Other technical data
Camera
Terminal box
Permissible ambient temperature
-10°C … +50°C
-60°C … +55°C
Protection class as per EN
60529/IEC 529
IP66/68
(Test conditions: 0.5h/8m
water column 5°C)
IP66
Housing material
Stainless steel, mat. no. 1.4404
Polyester resin
Weight
About 0.93 kg
1 kg
Dimensions
D48mm x 171.2mm
145mmx145mmx71mm

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 9 of 28
3 Safety Instructions
Please absolutely observe the installation instruction’s
safety directions of the T08 ExCam series!
Quick link:
https://www.samcon.eu/fileadmin/documents/en/22-Ex-Network-Cameras/ExCam-Series-T08-EX-Installation-Manual-2020.pdf
It is absolutely mandatory to adhere to the national safety regulations and regula-
tions for prevention of accidents, as well as to the safety instructions given below
in this User Manual!
Attention!
Cameras of type T08 ExCam are not suitable for use in zones 0 and 20.
The ambient temperature, temperature class and explosion group writ-
ten on the enclosure nameplate must be absolutely adhered to! The
customer is not allowed to make any alterations of the camera! The
camera must be operated in a proper and sound condition and only in
the way intended.
Attention!
Repairs may only be carried out by using original parts from the man-
ufacturer. Repairs which affect the explosion protection may only be
carried out in accordance with the nationally applied regulations and
exclusively by the manufacturer.
Attention!
The alignment of the camera to intensive energy sources (e.g. devices
which emit laser radiation or reflections of such equipment) can cause
an irreparable defect of the infrared detector. This is also valid if the
camera is switched off.
Attention!
Devices of type T08-VA0.x.K1.GER may not be used in mining/ fire-
damp hazard (ATEX group 1) or in areas with high risk of mechanical
stress (ATEX group 2).
Attention!
Prior to installation, take external sources of heat or cold into account!
The temperature ranges prescribed for storage, transport and operat-
ing must be adhered to!

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 10 of 28
Attention!
Adhere to the warnings given on the nameplate:
“WARNING –DO NOT OPEN IN HAZARD AREAS“
Using the camera in explosion-protected areas with regard to tempera-
ture and dust layers is defined in the respective national regulations.
When installing the ExCam, adhere to the requirements of the EN/IEC
60079-14.

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 11 of 28
4 Installation
For commissioning and operating the camera, the relevant national regulations, as well
as the generally accepted rules of technology shall prevail. Before mounting the camera,
thoroughly check it for any transport damage regarding the housing and cable. Installa-
tion, electrical connection and the first commissioning must only be carried out by quali-
fied specialists.
Work preparation:
Attention!
Prepare your work carefully and in accordance with the relevant
regulations.
Attention!
Depending on classification of hazard areas, it is imperative to obtain
a work approval first!
When you open the pressure-resistant enclosure under voltage, it is
absolutely necessary to prevent potentially explosive atmosphere!
To ensure the best image quality delivered by the network camera, plan the installation
site carefully (consider object distance or size, angle and minimum object distance to the
focus).
Use appropriate tools and aids.
When working, ensure a safe stand.
Make sure that any static charge is avoided.
Attention!
Please observe the national security, installation and accident preven-
tion regulations (e.g. DIN EN 60079-14) and the safety instructions in
this User Manual, as well as the ones in the Installation Guidelines!
Attention!
Adhere to the provisions of the IECEx, ATEX and
EX installation instructions for mounting and starting up!
The ExCam®XI80 consists of a flame-proof camera housing (T08 Ex-d) and an ex-e ter-
minal box (VA0.4-…-T) or a Plug (VA0.4-…-P). The camera is equipped with a system-
cable (5 to 100 m). Mount the camera according to the desired field of view. Install the
terminal box so that a good accessibility is given, in order to facilitate the electrical con-
nection.

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 12 of 28
Drawings for drill hole patterns and further information can be viewed on our product
page:
Quick link:
https://www.samcon.eu/en/products/network/excam-xi80/
Optional mounting accessories
Wall bracket
WMB-...
WALL MOUNT BRACKET WMB-VA0.x/VA1.x
Wall bracket for devices of T08-VA0-series
Suitable for hanging the camera on walls.
Material: stainless steel 1.4404
Weight: 0.68 kg
Dimensions: 80 x 100 x 205 mm
Pole adapter
PMB-…
POLE MOUNT EXCAM VA1.x (-)
Pole apter for VA wall mount
Material: stainless steel 1.4404
Suitable for pole diameters
between 50 and 105 mm
Load-bearing capacity: 45 kg
Dimensions:120x180x130 at masts of Ø 60 mm)
Hinge
attachment
SCH-…
Hinge attachment SCH-VAx.x
Hinge attachment for easy mounting on round
sight glasses acc. to DIN 28120/28121 or similar
for VA
Material: stainless steel AISI 316L/1.4404
Weight: ca. 0.04 kg
Dimensions WxHxD [mm]: 29.2x40x73.1
Table 4-1 Mounting accessories

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 13 of 28
5 Electrical connection
Attention!
The electrical connection of the equipment may only be carried out by
qualified and skilled personnel!
Attention!
It is absolutely necessary to ground the ExCam®series’housing via
the PA connection.
Attention!
Please observe the national security, installation and accident preven-
tion regulations (e.g. DIN EN 60079-14) and the safety instructions in
this User Manual, as well as the ones in the Installation Guidelines!
The delivered ExCam®XI80 is equipped with an electrical connection cable of the type
SKDP03-T. The maximum transmission range from the camera to the next active network
interface is 100 m and can be specified by the client. The user is NOT authorised to carry
out any electrical connection work inside the pressure-resistant enclosure (T08).
5.1 Potential equalization
Figure 5-1 ExCam XI80 Potential equalization
Potential equalization/grounding of the camera housing is absolutely necessary, in order
to avoid static charges and thus the formation of sparks. For this purpose, a screw termi-
nal is provided at the rear side’s bottom (see Figure 5-1). The cross-section of the poten-
tial equalization has to comply with the National Ground Rules (at least 4mm2).
Wiring table:
Potential
Colour (IEC 60757)
Cross-
section
Comment
PA
GN/YE
4 mm2(rigid)
Terminal: Slotted screw M3x0.5x5 (DIN 84)
with washer Ø3,2mm (DIN 125A),
Keep 1.2 Nm tightening torque!
Table 5-1 Potential equalization

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 14 of 28
5.2 Variants of cable termination
Figures 5.2 and 5.3 illustrate the cable termination of the ExCam XI80.
Figure 5-2 ExCam XI80 T08-VA0.4.K1.GER-N.N-xxx.N-P
Figure 5-3 ExCam XI80 T08-VA0.4.K1.GER-N.N-xxx.N-T
5.3 Connection work at the device (terminal box)
Attention!
Never open the Ex-e terminal box under voltage!
Attention!
Adhere to the international installation regulations for connection
chambers with increased safety (Ex-e).
Attention!
Adhere to attached separate User Manual for the Ex-e terminal box.
Video Tutorial:
Observe our video tutorial:
“SAMCON 01 Wiring the cable SKDP03-T to the junction box ExTB-3”
https://go.samcon.eu/v01

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 15 of 28
Figure 5-4 Video Tutorial ExTB-3
The pin assignment of the SKDP03-T is executed in accordance with the standard
EIA/TIA-568B for 24VDC, as follows:
Figure 5-5 Pin assignment of the cable SKDP03-T
Camera (Ex-d)
(T568B)
Colour
SKDP03-T
(IEC60757)
Terminal
ExTB-3
Cross-
sectional
surface
Comment
SHIELD
PE
1.5 mm2
Shield
Tx+
WH / OG
1
0.26 mm2
Solid conductor
Tx-
OG
2
0.26 mm2
Solid conductor
Rx+
WH / GN
3
0.26 mm2
Solid conductor
Rx-
GN
4
0.26 mm2
Solid conductor
(GND ISO)
WH / BU
5
0.26 mm2
Solid conductor
(AO / RS485 B)
BU
6
0.26 mm2
Solid conductor
(AI/DI/RS485 A)
BN
7
0.26 mm2
Solid conductor
(n.c.)
WH / BN
8
0.26 mm2
Solid conductor
(n.c.)
PE
VCC
BK
9
1.5 mm2
24VDC
GND
BU
10
1.5 mm2
0VDC
PE/PA
YE / GN
PE
1.5 mm2
PE
Table 5-2 Wire assignment of terminal box ExTB-3(SKDP03-T)

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 16 of 28
Figure 5-6 Wired terminal box ExTB-3
Particularly in EMC critical environments, it is necessary to make sure that the cable
shield is grounded on side of the terminal block! The maximum cable length is 100 m.
Attention!
Finally, check your network installation.
Attention!
Cables and wires must comply with the requirements of the
IEC 60079-0/1/7 & 14.
Attention!
The supply line must have a sufficient cross-section. The cable pro-
tection must comply with national and international regulations.

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 17 of 28
Example: Direct routing from ExTB-3 to safe area
Figure 5-7 ExTB-3 -> Safe area
5.4 Plug-assignment (RJ45)
Figure 5-8 Plug assignment RJ45
If the cable termination uses a plug, the latter should be plugged into the RJ45 PoE slot
of the network device (PSE). Prior to connecting it to the camera, the network device
PIF
(24 VDC/IO)

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 18 of 28
(PSE) can already be supplied with power, hence there is no „power ON“ priority which
has to be observed.
Attention!
Use appropriate RJ45 plugs! Check the cable shielding, cross-section
and the outside diameter!
Attention!
It is imperative to ensure a correct routing of the individual wires ac-
cording to the EIA/TIA-568B"
Detailed instructions on how to connect an RJ45 plug are available in our video tutorial:
“SAMCON 03 Mounting and installing the RJ45 jack to SAMCON cables”
https://go.samcon.eu/v03
Figure 5-9 Plug assignment, RJ45

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 19 of 28
5.4.1 Appropriate cables & cable entries
An integral part of the device safety is the correct selection of the cables, wires and cable
entries.
Attention!
Cables and wires must comply with the requirements of the IEC 60079-
0/1/7 & 14.
Attention!
The supply line must have a sufficient cross-section. The cable pro-
tection must comply with national and international regulations.
For non-binding configuration and planning guidelines, please visit
our website:
5.4.2 Fusing
The power supply fusing depends on the cable cross-section and length. 300 mA mT-
fuse is recommended.
Attention!
Please pay attention to the national and international regulations regarding
selectivity and line protection.
5.4.3 Tests prior to switching on voltage
Attention!
Prior to starting the device, perform all tests as indicated by the na-
tional regulations. Furthermore, check the correct function and instal-
lation of the device in accordance with this User Manual and other ap-
plicable regulations.
Attention!
Incorrect installation or operation of the camera may lead to a loss of
warranty!
Attention!
Do not switch on the camera at temperatures below 0°C!

Doc.-ID: 211007-PT08BA-ES-ExCam XI80_en_rev.00.docx, Page 20 of 28
6 Network access and visualization
The most important procedures of initially starting the camera are described below. A
detailed software description can be found on the supplied USB stick and in the Help
menu in the PIX Connect software under Help → Documentation. Alternatively, the
software can also be downloaded from the Optris website at the following link:
https://www.optris.global/pix
6.1 Minimum system requirements
• Windows 7, 8 or 10
• USB port
• Hard disk with min. 30 MByte free storage
• Minimum 128 MByte RAM
6.2 Set up installation / first use
All drivers are loaded automatically by the Windows operating system. No driver installa-
tion is necessary. The software starts automatically in the installed language.
1. Connect the supplied USB stick to your PC
2. Start the Setup.exe. Follow the instructions of the wizard until the installation is fin-
ished. After installation, you will find the software on your desktop (as a program icon)
and in the start menu: Start \ Programs \ Optris GmbH \ PIX Connect
3. Select the desired language in the menu Tools → Language
6.3 Allocating IP adress
The ExCam XI80 is designed for use in an Ethernet network and requires an IP address
for access and control.
Software configurations
based on OEM operating instructions (Optris)
Ethernet setup (point-to-point connection)
After you have connected the Ethernet cable to the camera and the PC, you first have to
make the network settings on the PC.
The devices are delivered with the following factory settings:
IP-address camera: 192.168.0.101
IP-address PC: 192.168.0.100
Port-number: 50101
1.
Table of contents
Other Samcon Digital Camera manuals
