Sami WEARABLE WS-2334 User manual

WEARABLE
User Manual
WS-2334
Thank you for purchasing the Sami wearable WS-2334. Read the instructions carefully to obtain optimum results and preserve it for future
reference. Sami has developed wearable devices since 2015 and we use the best components possible for the product.
DESCRIPTION OF THE WEARABLE
CONTENTS
Wearable, USB Magnetic cable, instruction manual.
CHARGING
Connect the device to a computer or laptop with the USB Magnetic cable for charging. Put in contact the magnetic end of the usb cable
with the charging points positioned in the back of your device. Kindly use only the USB cable included with the wearable. If you use a
power adapter for charging, the output of the power adapter should be 5V, 1A. Charging time: 2 hours. Please charge the device fully
before using it. Take care of the magnet side of the cable, if connect to AC and you have contact with a metal surface, you may
damage the charging cable.
HOW TO POWER ON / POWER OFF?
1) To turn ON the smart band, on the screen, long press the touch button (fixed-point touch control) for a few seconds. The touch
button is situated on the bottom of the screen.
2) To turn OFF the smart band, press the touch button until you get in the MORE menu, then long press the touch button to enter.
Tap again the touch button until the Power Off icon displays in the screen( ) , long press the touch button for a few seconds and
the device will turn off.
HOW TO CONTROL?
On the display screen , short press the touch button to change between the different menus. Long press the touch button to achieve the
different functions.
RIGHT UPPER ANGLE
DISPLAY SCREEN
FIXED-POINT TOUCH CONTROL
LEFT LOWER ANGLE CHARGING POINTS
HEALTH SENSOR
CHARGING
PONTS

GETTING STARTED:
- For Android
1) How to obtain the BT Connection APK (JYOUPRO)
Search for the JYOUPRO APP in the Play Store; download it and install it in your Android smartphone, or go to our website www.sami.es and
download the application.
2) Installation of the JYOUPRO APK.
When installing the JYOUPRO application on your Android, you must allow all the Application Permissions, allow this JYOUPRO app auto run.
The first time you run this JYOUPRO, it will ask you to Enable Notifications, please tap OK and tap the JYOUPRO and confirm OK. You must
tap OK/Allow for any pop-up request. On your Android permission management, allow all application permissions.
3) How to make the wearable pair with your Android smart phone?
*Firstly, turn on the Bluetooth of your Phone.
*Secondly, run the JYOUPRO app on your Phone, on the home page of JYOUPRO, select “Scanning device”, the APP will search for new
Bluetooth device(s), when the available Bluetooth device displays, please select F16 or WS-2334 (the BT name of this device) to make it
pair. The pairing will be finished in a few seconds. When you pair for the first time, the app JYOUPRO will ask you to fill some personal
information such as gender/age/height/weight. When you finish select OK/Confirm/Allow for any pop-up request.
Important: To enable all notifications of different softwares such as WhatsAPP, Facebook, Skype, Twitter, you will need to turn on the
notifications on the APP manually. On the home page of JYOUPRO, select the icon ‘’Device’’ (situated on the bottom of the screen), and
turn on all the APP notifications you want to active.
- For iPhone
1) How to obtain the BT Connection APP? (JYOUPRO)
On iPhone, please go to APP Store and search JYOUPRO and install the app.
2) How to make the wearable pair with your iPhone?
*Firstly, turn on the Bluetooth of iPhone
* Secondly, run the JYOUPRO app on your Phone, on the home page of JYOUPRO, tap “Scanning device”, the APP will search for new
Bluetooth device(s), when the available Bluetooth device displays, please tap F16 or WS-2334 (the BT name of this device) to make it pair.
The pairing will be finished in a few seconds. When you pair for the first time, the app JYOUPRO will ask you to fill some personal information
such as gender/age/height/weight. When you finish select OK/Confirm/Allow for any pop-up request.
Important: To enable all notifications of different softwares such as WhatsAPP, Facebook, Skype, Twitter, you will need to turn on the
notifications on the APP manually. On the home page of JYOUPRO, select the icon ‘’Device’’ (situated on the bottom of the screen), and
turn on all the APP notifications you want to active.
PRODUCT FEATURES.
BLUETOOTH (V 4.0)
TOUCH BUTTON (Fixed-point touch control). This model is not FULL touch control.
TOUCH SCREEN. touch screen 1.3"
BUILT IN VIBRATING MOTOR
BUILD IN HEART RATE SENSOR
BUILD IN GRAVITY SENSOR
GESTURE CONTROL TO LIGHT UP THE DISPLAY SCREEN
DISPLAY SCREEN INTERFACE
1) Time/Date/Battery/Steps/Heart rate displaying
2) Heart rate
3) ECG+PPG Test
4) Sleep monitor
5) Sports (different sport mode) –Walking/ Running / Bicycling / Climbing
6) More functions –Steps / Calories / Distance / Blood pressure / Blood oxygen (SPO2) /Information(Message) Find phone / Stopwatch/
Power Off
Data can be sync from the wearable to the smart phone on the JYOUPRO APK/APP.
Your smart phone will synchronize when the Bluetooth is paired with this device.

FUNCTIONS
PHONE CALL NOTIFICATION - vibrating reminder for incoming phone calls
MESSAGE NOTIFICATION - vibrating reminder for incoming messages, including SMS, WhatsApp, Facebook, Twitter, Skype messages, etc.
CLOCK SCREENS –(Different home digital clocks) –In the home screen of the smart band, long press the fixed-point for a few seconds to
change the style of the digital clock.
SLEEP MONITOR - supported on the JYOUPRO APK/APP
ALARM CLOCK - supported on the JYOUPRO APK/APP
REMOTE SELFIE - (remote control your smartphone’s camera.)
Automatic Heart Rate test –supported at JyouPro APP
STOPWATCH
POWER SAVING MODE –SUPPORTED AT JYOUPRO APP
SEDENTARY REMIDER (INACTIVITY REMINDER/REMIND TO MOVE) - supported on the JYOUPRO APK/APP
FIND THE DEVICE(Looking for the SMART BAND) - supported on the JYOUPRO APK/APP
GESTURE CONTROL (Raise your hand to light up the screen) supported on the JYOUPRO APK/APP
GPS MAP TRACE (view it on the BT APP/APK JYOUPRO). On the home page of the JYOUPRO, tap in the Exercise icon ,then select the flag
icon and select Continue to view the GPS map. On the home page of the JYOUPRO, tap in the Exercise icon, then select the icon situated
in the right top to view the GPS map trace history record. The trace history can be shared in Facebook, Twitter, Instagram, etc.
ECG & PPG - Test and Report generates
1) How to test ECG + PPG?
To start directly at the smart band
Wear the smart device on your wrist on the ECG+PPG test interface of the smart device display screen, long press touch button for few
seconds to start testing; once it is start, use your other hand two fingers to touch the Left Lower Angle and to touch the Right Upper Angle
respectively, at the same time. Keep still and the testing will be done in approx 45 seconds. Your left hand and your right hand should not
touch each other while in testing.
FitPro APP/APK to start
Wear the smart device on your wrist on FITPRO APP tap Home tap ECG tap Enter tap Start; once it is start, use your other hand
two fingers to touch the Left Lower Angle and to touch the Right Upper Angle respectively, at the same time. Keep still and the testing will
be done in approx 45 seconds. Your left hand and your right hand should not touch each other while in testing.
2) Where I can read the test result and test report of ECG/PPG?
At the Fitpro APK/APP, tap Home tap Healthtap ECG tap Health Report tap and select the test history to view Health Report roll
down to find the ECG report, tap it to enter to view the report. The report can be shared to Facebook, Twitter, etc.
If the report does not appear you must sync the data tapping on the sync icon on the top right.
MULTIPLE LANGUAGES
**** THIS IS NOT A MEDICAL INSTRUMENT, SO THE VALUES ARE APPROXIMATE
TECHNICAL SPECIFICATIONS:
Display screen: Capacitive touch screen 1.3".
Screen resolution: 240x240pixels
Internal Memory: RAM 96KB, ROM 128KB
System: Nucleus
CPU: Dialog14585
Charge I/O port : USB Magnetic charging.
Battery: Built in Li-Polymer 170 mAh
Stand by time: 7~10 DAYS
Working time: 5 DAYS
Bluetooth: v4.0
Water-resist Rating: IP68 30 meters waterproof, OK for swimming, but not for professional diving.Please use only in cold water, do not use for
bath with hot water as the vapor can enter in the unit and damage it.
NET Weight: 35 g
Exterior Dimensions: device 43*37.5*13.5mm; with straps 255*37.5*13.5mm.

Declaration of Conformity
Hereby we,
Name of manufacturer:
SANTOSHI SL
Address:
CALLE FELIPE ASENJO N.56
Zip code & City:
28947 - FUENLABRADA ( MADRID )
Country:
SPAIN
declare that this DoC is issued under our sole responsibility and that this product:
Product description:
Smart Band
Type designation(s):
WS-2334
Trademark:
SAMI WEARABLE
is in conformity with the relevant Union harmonization legislation:
DIRECTIVE EMC 2014/30/EU
DIRECTIVE LVD 2014/35/EU
Standard CE (RED): DIRECTIVE 2014/53/EU
Standard RoHS: 2011/65/EU: (RoHS) Restriction of Hazardous Substance.
with reference to the following standards applied:
EN 60950-1: 2006+A11:2009+A1:2010+A12:2011+A2:2013
EN 62479:2010
EN 301 489-1 V2.1.1 (2017-02)
EN 301 489-17 V3.1.1 (2017-02)
EN 300 328 V2.1.1 (2016-11)
Signature
Full name: VISHAL MIRPURI
Position: ADMINISTRATOR
Date: 05/ 12 / 2019
