Samoa LARIUS DALI' Manual

www.larius.com
English
OPERATING AND MAINTENANCE INSTRUCTIONS
DALI'
Electric diaphragm pump
ED. 008 - 02/2020
Cod. 150101

Due to a constant product improvement programme, the factory reserves the right to modify
technical details mentioned in this manual without prior notice.
This manual is to be considered as an English language translation of the original manual in Italian.
The manufacturer shall bear no responsibility for any damages or inconveniences that may arise due to
the incorrect translation of the instructions contained within the original manual in Italian.

www.larius.com
1
DALI'
ED. 008 - 02/2020 - Cod. 150101
DALì
Electric diaphragm pump
A
C
D
B
E
H
G
F
I
M
N
J
K
L
O
P
Q
R
S
T
AVVERTENZE ......................................................................................................................................................... p. 3
WORKING PRINCIPLE ........................................................................................................................................... p. 4
TECHNICAL DATA .................................................................................................................................................. p. 4
DESCRIPTION OF THE EQUIPMENT .................................................................................................................... p. 5
TRANSPORT AND UNPACKING ............................................................................................................................ p. 8
CONDITIONS OF GUARANTEE ............................................................................................................................. p. 6
SAFETY RULES...................................................................................................................................................... p. 6
SETTING-UP .......................................................................................................................................................... p. 8
WORKING .............................................................................................................................................................. p.10
CLEANING AT THE END OF THE WORK .............................................................................................................. p.11
ROUTINE MAINTENANCE ..................................................................................................................................... p.12
WARNING PLATE ................................................................................................................................................... p.13
CORRECT PROCEDURE OF DECOMPRESSION ................................................................................................. p.14
PROBLEMS AND SOLUTIONS .............................................................................................................................. p.15
SPARE PARTS
COMPLETE HYDRAULIC BODY............................................................................................................................ p.16
PETROL ENGINE.................................................................................................................................................... p.18
COMPLETE COLOUR BODY ................................................................................................................................. p.20
SUCTION SYSTEM ................................................................................................................................................ p.23
TROLLEY................................................................................................................................................................ p.24
ACCESSORIES....................................................................................................................................................... p.26
WE ADVISE THE USE OF THIS EQUIPMENT ONLY BY PROFESSIONAL OPERATORS.
ONLY USE THIS MACHINE FOR USAGE SPECIFICALLY MENTIONED IN THIS MANUAL.
Thank you for choosing a LARIUS S.R.L. product.
As well as the product purchased, you will receive a range of support services
enabling you to achieve the results desired, quickly and professionally.

Intentionally blank page

www.larius.com
3
DALI'
ED. 008 - 02/2020 - Cod. 150101
A
The table below provides the meaning of the symbols used in this manual in relation to using, earthing,
operating, maintaining, and repairing of this equipment.
WARNINGS
A
• Read this operator’s manual carefully before using the equipment.
• An improper use of this machine can cause injuries to people or things.
• Do not use this machine when under the inuence of drugs or alcohol.
• Do not modify the equipment under any circumstances.
• Use products and solvents that are compatible with the various parts of the equipment, and read the manufacturer’s warnings carefully.
• See the Technical Details for the equipment given in the Manual.
• Check the equipment for worn parts once a day. If any worn parts are found, replace them using ONLY original spare parts.
• Keep children and animals away from work area.
• Comply with all safety standards.
• It indicates an accident risk or serious damage to equipment if this warning is not followed.
FIRE AND EXPLOSION HAZARD
• Solvent and paint fumes in work area can ignite or explode.
• To help prevent fire and explosion:
- Use equipment ONLY in well ventilated area.
- Eliminate all ignition sources, such as pilot lights, cigarettes and plastic drop cloths (potential static arc).
- Ground equipment and conductive objects.
- Use only grounded hoses.
- Do not use trichloroethane, methylene chloride, other halogenated hydrocarbon solvents or uids containing such solvents in
pressurized aluminium equipment. Such use can cause serious chemical reaction and equipment rupture, and result in death,
serious injury, and property damage.
- Do not form connections or switch light switches on or off if the air contains inammable fumes.
• If electrical shocks or discharges are encountered the operation being carried out using the equipment must be stopped immediately.
• Keep a re extinguisher at hand in the immediate vicinity of the work area.
• It indicates wound and nger squashing risk due to movable parts in the equipment.
• Tenersi lontano dalle parti in movimento.
• Do not use the equipment without the proper protection.
• Before any inspection or maintenance of the equipment, carry out the decompression procedure explained in this manual, and prevent
any risk of the equipment starting unexpectedly.
• Report any risk of chemical reaction or explosion if this warning has not been given.
• (IF PROVIDED) There is a risk of injury or serious lesion related to contact with the jet from the spray gun. If this should occur, IMME-
DIATELY contact a doctor, indicating the type of product injected.
• (IF PROVIDED) Do not spray before the guard has been placed over the nozzle and the trigger on the spray gun.
• (IF PROVIDED) Do not put your ngers in the spray gun nozzle.
• Once work has been completed, before carrying out any maintenance, complete the decompression procedure.
• It indicates important recommendations about disposal and recycling process of products in accordance with the environmental
regulations.
• Mark any clamps attached to earth cables.
• Use ONLY 3-wire extension cords and grounded electrical outlets.
• Before starting work make sure that the electrical system is grounded and that it complies with safety standards.
• High-pressure uid from gun, hose leaks, or ruptured components will pierce skin.
• To help prevent injection, always:
- (IF PROVIDED) Engage trigger lock when not spraying.
- (IF PROVIDED) Do not put your hand over the spray tip. Do not stop or deect leaks with your hand, body or other.
- (IF PROVIDED) Do not point gun at anyone or at any part of the body.
- (IF PROVIDED) Never spray without tip guard.
- Do pressure relief if you stop spraying or being servicing sprayer and before any maintenance operations.
- Do not use components rated less than sprayer Maximum Working Pressure.
- Never allow children to use this unit
- (IF PROVIDED) Brace yourself; gun may recoil when triggered.
If high pressure fluid pierces your skin, the injury might look like “just a cut”, but it is a serious wound!
Get immediate medical attention.
• It is obligatory to wear suitable clothing as gloves, goggles and face shield.
• Wear clothing that complies with the safety standards in force in the country in which the equipment is used.
• Do not wear bracelets, earrings, rings, chains, or anything else that may hinder the operator’s work.
• Do not wear clothing with wide sleeves, scarves, ties, or any other piece of clothing that could get tangled up in moving parts of the
equipment during the work, inspection, or maintenance cycles.

www.larius.com
4
DALI'
ED. 008 - 02/2020 - Cod. 150101
B
C
C
B
A
*N.B. Available on request with special voltages
WORKING PRINCIPLE
The LARIUS DALÍ unit is dened as an “electric diaphragm pump”.
An electric diaphragm pump is used for high pressure paint
spraying without air (known as “airless”).
The pump is powered by an electric (internal combustion) motor
coupled with a cam shaft. The shaft acts on the hydraulic piston
as it pumps oil from the hydraulic case and sends the suction
diaphragm into brillation. When the diaphragm moves, it cre-
ates a vacuum. The product is sucked up, pushed towards the
pump outlet and sent to the guns through the exible hose . A
hydraulic valve on the hydraulic case head allows setting and
checking the pressure of the paint product at the pump outlet.
A second hydraulic safety valve to avoid over-pressure, ensures
total equipment reliability.
DATI TECNICI
DALI'
Max. delivery 4 lt./m
Supply (single-phase, three-phase internal combustion supply,
petrol-diesel)* 220V 50Hz/110V 60Hz/380V 50Hz
Motor power
mono-threephase 1,1 kW
internal combustion 3 HP
Max. working pressure 200 bar 2900 psi
Material outlet M16 x 1,5 (M)
Weight 38 kg
Level of the sound pressure ≤ 65dB (A)
Length (A) 1100 mm
Width (B) 500 mm
Height (C)min. 710 mm
max. 1000 mm
PARTS OF THE PUMP IN CONTACT WITH THE MATERIAL: Stainless Steel AISI 420B, PTFE, Aluminium.

www.larius.com
5
DALI'
ED. 008 - 02/2020 - Cod. 150101
D
Fig. 1D
16
54
1
1211
7
17
13
2
15
14
10
4
6
2
3
8
10
9
Pos. Description
1 Carriage
2 Electric / combustion motor
3 Feed tube connection
4 Setting valve
5 Hydraulic oil filling cap
6 Hydraulic body
7 Colour body
8 Suction and recirculation tube
9 High pressure feed tube
DESCRIPTION OF THE EQUIPMENT
Pos. Description
10 LARIUS AT 250 gun
11 Fast clean
12 Tools box
13 Recirculation valve
14 Recirculation pipe connection
15 Product suction tube connection
16 Adjustable handle
17 Tank (for "vertical Dalì" version)

www.larius.com
6
DALI'
ED. 008 - 02/2020 - Cod. 150101
EG
TRANSPORT AND UNPA-
CKING
• The packed parts should be handled as indicated in the
symbols and markings on the outside of the packing.
• Before installing the equipment, ensure that the area to
be used is large enough for such purposes, is properly
lit and has a clean, smooth oor surface.
• The user is responsible for the operations of unloading
and handling and should use the maximum care so as
not to damage the individual parts or injure anyone.
To perform the unloading operation, use only qualied
and trained personnel (truck and crane operators, etc.)
and also suitable hoisting equipment for the weight of
the installation or its parts.
Follow carefully all the safety rules.
The personnel must be equipped with the necessary
safety clothing.
• The manufacturer will not be responsible for the unlo-
ading operations and transport to the workplace of the
machine.
• Check the packing is undamaged on receipt of the
equipment. Unpack the machine and verify if there has
been any damage due to transportation.
In case of damage, call immediately LARIUS and the
Shipping Agent. All the notices about possible damage
or anomalies must arrive timely within 8 days at least
from the date of receipt of the plant through Registered
Letter to the Shipping Agent and to LARIUS.
• The disposal of packaging materials is a customer’s
competence and must be performed in accordance with
the regulations in force in the country where the plant is
installed and used.It is nevertheless sound practice to
recycle packaging materials in an environment-friendly
manner as much as possible.
SAFETY RULES
•THE EMPLOYER SHALL TRAIN ITS EMPLOYEES ABOUT
ALL THOSE RISKS STEMMING FROM ACCIDENTS, ABOUT
THE USE OF SAFETY DEVICES FOR THEIR OWN SAFE-
TY AND ABOUT THE GENERAL RULES FOR ACCIDENT
PREVENTION IN COMPLIANCE WITH INTERNATIONAL
REGULATIONS AND WITH THE LAWS OF THE COUNTRY
WHERE THE PLANT IS USED.
•THE BEHAVIOUR OF THE EMPLOYEES SHALL STRICTLY
COMPLY WITH THE ACCIDENT PREVENTION AND ALSO
ENVIRONMENTAL REGULATIONS IN FORCE IN THE
COUNTRY WHERE THE PLANT IS INSTALLED AND USED.
• KEEP YOUR WORK PLACE CLEAN AND TIDY. DISORDER
WHERE YOU ARE WORKING CREATES A POTENTIAL RISK
OF ACCIDENTS.
• ALWAYS KEEP PROPER BALANCE AVOIDING UNUSUAL
STANCE.
• BEFORE USING THE TOOL, ENSURE THERE ARE NOT
DAMAGED PARTS AND THE MACHINE CAN WORK PRO-
PERLY.
• ALWAYS FOLLOW THE INSTRUCTIONS ABOUT SAFETY
AND THE REGULATIONS IN FORCE.
• KEEP THOSE WHO ARE NOT RESPONSIBLE FOR THE
EQUIPMENT OUT OF THE WORK AREA.
• NEVER EXCEED THE MAXIMUM WORKING PRESSURE
INDICATED.
• NEVER POINT THE SPRAY GUN AT YOURSELVES OR AT
OTHER PEOPLE. THE CONTACT WITH THE CASTING CAN
CAUSE SERIOUS INJURIES.
• IN CASE OF INJURIES CAUSED BY THE GUN CASTING,
SEEK IMMEDIATE MEDICAL ADVICE SPECIFYING THE
TYPE OF THE PRODUCT INJECTED. NEVERUNDERVALUE
A WOUND CAUSED BY THE INJECTION OF A FLUID.
• ALWAYS DISCONNECT THE SUPPLY AND RELEASE
THE PRESSURE IN THE CIRCUIT BEFORE PERFOR-
MING ANY CHECK OR PART REPLACEMENT OF THE
EQUIPMENT.
Read carefully and entirely the following
instructions before using the product. Please
save these instructions in a safe place.
The unauthorised tampering/replacement of one
or more parts composing the machine, the use
of accessories, tools, expendable materials other
than those recommended by the Manufacturer
can be a danger of accident.
The Manufacturer will be relieved from tort and
criminal liability.
F
The conditions of guarantee do not apply in the
following situations:
- improper washing and cleaning of components
causing malfunction, wear or damage to the
equipment or any of its parts;
- improper use of the equipment;
- use that does not conform with applicable na-
tional legislation;
- incorrect or faulty installation;
- modifications, interventions and maintenance
that have not been authorised by the manu-
facturer;
- use of non-original spare parts or parts that do
not correspond to the specific model;
- total or partial non-compliance with the instruc-
tions provided.
CONDITIONS OF GUARANTEE

www.larius.com
7
DALI'
ED. 008 - 02/2020 - Cod. 150101
• NEVER MODIFY ANY PART IN THE EQUIPMENT. CHECK
REGULARLY THE COMPONENTS OF THE SYSTEM.
REPLACE THE PARTS DAMAGED OR WORN.
• TIGHTEN AND CHECK ALL THE FITTINGS FOR CONNEC-
TION BETWEEN PUMP, FLEXIBLE HOSE AND SPRAY GUN
BEFORE USING THE EQUIPMENT.
• ALWAYS USE THE FLEXIBLE HOSE SUPPLIED WITH
STANDARD KIT.
• THE USE OF ANY ACCESSORIES OR TOOLING OTHER
THAN THOSE RECOMMENDED IN THIS MANUAL, MAY
CAUSE DAMAGE OR INJURE THE OPERATOR.
• THE FLUID CONTAINED IN THE FLEXIBLE HOSE CAN BE
VERY DANGEROUS. HANDLE THE FLEXIBLE HOSE CARE-
FULLY. DO NOT PULL THE FLEXIBLE HOSE TO MOVE THE
EQUIPMENT. NEVER USE A DAMAGED OR A REPAIRED
FLEXIBLE HOSE.
• NEVER SPRAY OVER FLAMMABLE PRODUCTS OR SOL-
VENTS IN CLOSED PLACES.
• NEVER USE THE TOOLING IN PRESENCE OF POTENTIALLY
EXPLOSIVE GAS.
The high speed of travel of the product in the
hose can create static electricity through
discharges and sparks. It is suggested to earth
the equipment.
The pump is earthed through the earth cable of
the supply. The gun is earthed through the high
pressure flexible hose. All the conductors near
the work area must be earthed.
Always check the product is compatible with
the materials composing the equipment (pump,
spray gun, flexible hose and accessories) with which
it can come into contact. Never use paints or
solvents containing Halogen Hydrocarbons (as
the Methylene Chloride).
If these products come into contact with
aluminium parts can provoke dangerous chemical
reactions with risk of corrosion and explosion.
If the product to be used is toxic, avoid inhalation
and contact by using protection gloves, goggles
and proper face shields.
Take proper safety measures for the protection
of hearing in case of work near the plant.
ELECTRICAL SAFETY PRECAUTIONS
• Check the "ON/OFF" switch is on the "OFF" position before
connecting the cable to the mains.
• Never carry a plugged-in equipment.
• Disconnect the equipment before storing it and before perfor-
ming any maintenance operation or replacing of accessories.
• Do not carry the equipment neither unplug it by pulling the
electric cable.
Protect the cable from heat, oil and sharp edges.
• When the tool is used outdoors, use only an extension cable
suited for outdoor use and so marked.
• Take care when the pumping rod is moving.
Stop the machine whenever someone is within its vicinity.
• Repairs of the electrical equipment should only be carried
out by skilled personnel, otherwise considerabledanger to
the user may result.
Never attempt to tamper with the calibre of
instruments.

www.larius.com
8
DALI'
ED. 008 - 02/2020 - Cod. 150101
H
Fig. 1H
Fig. 2H
Fig. 3H
Fig. 4H
Fig. 5H
H1
H2
H3
SETTING-UP
COLLEGAMENTI DI TUBO FLESSIBILE E PISTOLA
• Connect the high pressure flexible hose to the pump and
to the gun, ensuring to tighten the fittings (the use of two
wrenches is suggested).
• It is recommended to use the hose provided with the standard
kit (ref. 35017).
COLLEGAMENTO DELL'ALIMENTAZIONE ELETTRICA
• Check the plant is earthed.
NEVER use sealants on fittings’ threads.
NEVERusea damagedor a repairedflexible hose.
• The supply cable (H2) is provided without plug.
Use a plug which guarantees the plant earthing.
Only a technician or a skilled person should perform the
connection of the plug to the electric cable.
• Check the mains voltage corresponds to the equipment’s
rating (H1).
Should anyone use an extension cable between
the tooling and the socket, it must have the same
characteristics as the cable supplied (minimum
diameter of the wire 2.5 mm2) with a maximum
length of 50 mt. Higher lengths and lower dia-
meters can provoke excessive voltage falls and
also an anomalous working of the equipment.
CONNECTION OF THE TOOLING TO THE POWER SUPPLY
• Check the ON/OFF switch (H3) is on the "OFF" position
before connecting the cable to the mains.
• Place the pressure control knob (H4) on the “MIN” position
(turn counterclockwise).

www.larius.com
9
DALI'
ED. 008 - 02/2020 - Cod. 150101
Fig. 6H
Fig. 7H
Fig. 8H
Fig. 9H
H4
H5
H6
H7
H4
+
H3
-
WASHING OF THE NEW EQUIPMENT
• The equipment has already been adjusted at our factory with
light mineral oil left inside the pumping group as protection.
Therefore, wash with diluent before sucking the product.
• Lift the suction pipe and dip it into the solvent tank (H5).
• Ensure the gun (H6) is without nozzle.
• Open the re-circulation tap (H7). Turn the unit ON-OFF switch
(H8) on the "ON"position.
• Rotate the pressure setting knob (H4) slightly clockwise so
that the machine operates at minimum power.
• Point the gun at a container keeping the trigger pressed (so
as to drain the oil inside) till a clean solvent comes out. Now,
release the trigger.
• Remove the suction pipe and take away the solvent tank.
• Point the gun at the solvent tank and press the trigger so as
to recover the residual solvent.
• As the pump idles, press the ON/OFF switch (H3) on the
position "OFF" to stop the tooling.
Absolutely avoid to spray solvents indoors. In
addition, it is recommended to keep away from
the pump in order to avoid the contact between
the solvent fumes and the electric motor.
• Now the machine is ready. Should you use water paints,
besides the solvent wash, a wash with soapy and then clean
water is suggested.
• Insert the gun trigger lock and assemble the nozzle.
PREPARATION OF THE PAINT
• Make sure the product is suitable to be used with a spray
gun.
• Mix and lter the product before using it. For ltration, use
CLOSE-MESH (ref.214) and LARGE-MESH (ref.215) LA-
RIUS METEX braids.
Make sure the product to be used is compatible
with the materials employed for manufacturing
the equipment (stainless steel and aluminium).
Because of that, please contact the supplier of
the product.
Never use products containing halogen hydrocarbons (as
methylene chloride). If these products come into contact with
aluminium parts of the equipment, can provoke dangerous
chemical reactions with risk of explosion.

www.larius.com
10
DALI'
ED. 008 - 02/2020 - Cod. 150101
I
Fig. 2I Fig. 3I
Fig. 1I
I2
I4
I1
-I3
WORKING
START OF THE PAINTING OPERATIONS
• Use the tooling after performing all the SETTING UP ope-
rations above described.
• Dip the suction pipe (I1) into the product tank.
• Open the re-circulation valve (I2).
• Press the ON/OFF switch of the equipment and turn a little
the pressure control knob (I3), so as the machine works at
the idle speed.
• Make sure the product recycles from the return tube (I4).
• Close the re-circulation valve.
• At this point the machine will continue to suck the paint
product until the delivery hose is completely full. Afterwards,
the product will re-circulate automatically.
SPRAY ADJUSTMENT
• Slowly turn clockwise the pressure control knob to reach
the pressure value in order to ensure a good atomization of
the product.
• An irregular and marked spray on the sides indicates a low
working pressure. On the contrary, a too high pressure
causes a high fog (“overspray”) and waste of product.
• In order to avoid overthickness of paint, let the gun advance
sideways (right-left) when spraying.
• Always paint with regular parallel bands coats.
• Keep a safety and constant distance between the gun and
the support to be painted and also keep yourselves perpen-
dicular to it.
NEVER point the spray gun at yourselves or at
other people. The contact with the casting can
use serious injuries. In case of injuries caused by
the gun casting, seek immediate medical advice
specifying the type of the product injected.
Thedrain valveisasafetyvalvetoo.Whenworking
at the maximum pressure available, releasing
the gun trigger sudden increases of pressure
can occur. In this case, the drain valve opens
automaticallyeliminatingpart ofthe productfrom
the recirculating tube. Then it closes so as to go
back to the first working conditions.

www.larius.com
11
DALI'
ED. 008 - 02/2020 - Cod. 150101
J
Fig. 1J
Fig. 3J
Fig. 2J
J1
J3
OPEN
OPEN
-
CLOSE
CLOSE
J2
CLEANING AT THE END WORK
• Reduce pressure to the minimum (turn counterclockwise the
pressure control knob (J1) ).
•Press the ON/OFF switch (J2) placed on the box of the electric
motor, to stop the equipment.
• First release the residual pressure from the gun by holding
it pointed down towards the paint container, then open the
re-circulation valve (J3).
• Lift the suction pipe and replace the product tank with that
of the solvent (ensure it is compatible with the product being
used).
• Unscrew the gun nozzle (do not forget to clean it with solvent!).
•Turn the ON-OFF switch (J2) on the ON position and rotate
the pressure setting knob (J1) slightly clockwise.
• Make sure the solvent recycles the washing uid from the
return tube (J4).
• Close the re-circulation valve (J3) .
• Point the gun at the product tank and, keeping the trigger
pressed, release the remaining product till a clean solvent
comes out. Now, release the trigger.
• Lift again the suction pipe and remove the solvent tank.
• Now point the gun at the solvent tank and press the trigger
so as to recover the residual solvent.
• As the pump starts idling, press the ON/OFF switch to stop
the equipment.
• In case of long storage, we recommend you to suck and
to leave light mineral oil inside the pumping group and the
exible hose.
Follow the washing procedure before using again
the equipment.

www.larius.com
12
DALI'
ED. 008 - 02/2020 - Cod. 150101
K
Fig. 1K
Fig. 2K
Fig. 3K
Fig. 4K
K3
K2
K1
K3
ROUTINE MAINTENANCE
TOP UP HYDRAULIC OIL
With each start up, check the hydraulic oil level by looking through
the gauge (K1) on the side of the hydraulic body. If necessary,
use “AGIP OSO 46 type hydraulic oil” to top up the level.
RELEASE THE SUCTION VALVE
If the pump malfunctions, release the suction valve tted on the
head of the pump in the following way:
• Remove the suction hose tting and release the valve by
inserting a rigid rod (K2) with a diameter of no more than
15 mm.
REPLACING HYDRAULIC OIL
After operating for 100 hours, replace the oil in the pump;
• Discharge the waste oil through the plug (K4) tted at the
bottom of the pump casing.
• Clean the seals on the cap and replace it if worn.
• Remove and clean the lter (K5) on the side of the pump
casing; if necessary, replace the lter and the respective
seals.
• Clean and, if necessary, replace the worn seals (K5).
• Replace the plug (K4).
• Fill the pump with the recommended oil until it reaches the
maximum level.
• Then, substitute the oil every 250 hours.
Assemble the components in the correct order.
CLEANING THE COMPRESSION VALVE
When the compression valve (K3) must be removed, clean it with
specic solvents depending on the type of paint used and ret
all parts by inverting the removal order.

www.larius.com
13
DALI'
ED. 008 - 02/2020 - Cod. 150101
L
Apparecchi per verniciatura
ATTENZIONE
UTILIZZARE GRUPPI ELETTROGENI
CON ALTERNATORE ASINCRONO
http: www.larius.com
Paint spraying units
WARNING
USE POWER UNITS WITH
ASYNCHRONOUS ALTERNATOR
e-mail [email protected]
Fig. 5K
Fig. 6K
Fig. 7K
Fig. 8K
Fig. 1L
K5
K4
K6
WARNING PLATE
CLEANING THE MOTOR COOLING FAN GUARD
Clean the motor cooling fan protection guard (K6) periodically
to ensure the best cooling.

www.larius.com
14
DALI'
ED. 008 - 02/2020 - Cod. 150101
M
Fig. 1M Fig. 2M Fig. 3M
Fig. 4M Fig. 5M Fig. 6M
M2 M3
M4
M1
M5
M6
-
CORRECT PROCEDURE OF DECOMPRESSION
• Release the gun clamp (M5). Point the gun at the tank of
the product and press the trigger to release pressure. At the
end of the operation, insert the gun clamp.
• Open the re-circulation valve (M6) to release residual pressure.
If the equipment is still under pressure after performing the operations above described because of the nozzle
or the flexible hose clogged, proceed as follows:
• Loosen very slowly the gun nozzle.
• Release the clamp.
• Point the gun at the container of the product and press the trigger to release pressure.
• Loosen very slowly the tting of connection from the exible hose to the gun.
• Clean or replace the exible hose and the nozzle.
• Insert the gun clamp (M1).
• Move the ON/OFF switch (M2) to the OFF position to stop
the equipment.
• Set the valve (M3) at its minimum pressure setting (turn
counterclockwise).
• Disconnect the power supply cable (M4).

www.larius.com
15
DALI'
ED. 008 - 02/2020 - Cod. 150101
N
PROBLEMS AND SOLUTIONS
Problem Cause Solution
The equipment does not start Lack of voltage; Check the correct connection to the
power supply;
Considerable drops in mains voltage; Check the extension cable;
ON-OFF switch disconnected; Ensure the ON-OFF switch is on the
“ON” position and turn clockwise the
pressure control knob;
Setting valve faulty pressure; Verify and replace it, if necessary;
Breakdown of motor electric control box; Verify and replace it, if necessary;
The product is solidied inside the pump; Open the drain valve to release pressure
in the circuit and stop the machine.
Remove the compression valve and
clean it;
The equipment does not suck the
product
Suction lter clogged; Clean or replace it;
Suction lter too ne; Replace it with a larger-mesh lter (with
very dense products, remove the lter);
The equipment sucks air; Check the suction pipe;
The equipment suck but does not
reach the pressure desired
Lack of product; Add the product;
The equipment sucks air; Check the suction pipe;
The drain valve is open; Close the drain valve;
Suction or delivery valve dirty; Disassemble the colour body group;
When pressing the trigger, the pres-
sure lowers considerably
Nozzle too big or worn; Replace it with a smaller one;
The product is too dense; Dilute the product, if possible;
The lter of the gun-butt is too ne; Replace it with a larger-mesh lter;
The pressure is normal but the pro-
duct is not atomized. Leakage from
the seal-tightening screw
The nozzle is partially clogged; Clean or replace it;
The product is too dense; Dilute the product, if possible;
The lter of the gun-butt is too ne; Replace it with a larger-mesh lter;
The atomization is imperfect The nozzle is worn; Replace it;
Always close the air compressed supply and unload the plant pressure before performing any check or repla-
cement of pump parts (see "correct procedure of decompression").

www.larius.com
16
DALI'
ED. 008 - 02/2020 - Cod. 150101
O
46
47
48
49
52 23
24
45 22
20
19
26
27
28
29
44
39
40
42
41
43
765456 55 3
17
16
15
14
13
12
11
10
54 53
25
57
18
21
9
8
38
25V
30
31
26V
34
32
35
36 37
33
1A
1B 1C 50 51
Fig. 1O
COMPLETE HYDRAULIC BODY

www.larius.com
17
DALI'
ED. 008 - 02/2020 - Cod. 150101
Pos. Code Description
1A 18925 Electric motor mono-phase 220V 50Hz
complete
1B 18926 Electric motor mono-phase 110V 60Hz
complete
1C 18924 Electric motor three-phases 380V 50Hz
complete
2** 18901 Hydraulic body
3** 32018 Cylinder liner
4 32033 Piston insert
5** 33002/5 Nut
6** 33002/3 Spring
7** 18937 Oil distributor
8** 33002/1 Diaphragm
9 18936 Diaphragm insert
10** 31125 Bearing
11** 81020 Elastic ring
12 18906 Bushing
13 32026 Bearing
14 32027 Cover
15 32029 Screw
16 18908 OR
17 18907 Cover
18** 32041 Check nut
19 32019 Piston
20 32022 Spring
21 32021 Spring cap
22 32020 Elastic ring
23 96031 Screw
24 32024 Washer
25 32108 Plug
25V* 32108 Plug
26 33010 Washer
26V* 33010 Washer
27 18910 Identification plate 220V 50Hz
27 18931 Identification plate 110V 60Hz
Pos. Code Description
27 18932 Petrol identification plate
27 18933 Identification plate 380V 50Hz
28 34020 Rivet
29 32007 Oil inspection window
30 32108 Plug
31 81012 Spline
32 18909/1 Corteco
33 18947 Eccentric flywheel
34 81009 Dowel
35 18919 Tab
36 33005 Washer
37 18903 Nut
38 32150 Complete pressure regulation valve
39 32017 Knob
40 32017/2 Spring
41 32016 Retainer
42 32155 Valve body
43 32014 OR
44 32017/1C Dowel
45 12475 Oil filter assembly
46 12461 Filter
47 32010 Copper washer
48 258 Filter sieve 60 MESH
49 32012 OR
50 18928 Motor condenser 220V 50Hz
50 18929 Motor condenser 110V 60Hz
51 18938 Switch
52 32032 Screw
53* 5059 Washer
54* 18567 Screw
55* 91915 Ball
56 18946 Dowel
57 32028 Washer (Typ Grower)
*
*
*
*
* Only in the vertical configuration
**Pos. 2-3-10-11-18 spare supplied complete (recommended) - Ref. 18952
**Pos. 5-6-7-8 complete diaphragm - Ref. 18904
*

www.larius.com
18
DALI'
ED. 008 - 02/2020 - Cod. 150101
P
1
2
5
6
3
7
3
9
29
3
11
9
14
15 4
8
10
3
17
12
18
13
16
19
A
B
Fig. 1P
PETROL ENGINE
