Samson XPDm User manual

XPDm Digital Wireless System
Owner’s Manual

XPDm Digital Wireless
Important Safety Information
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
This lightning flash with arrowhead
symbol within an equilateral
triangle is intended to alert the user
to the presence of non-insulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance instructions in the literature
accompanying the appliance.
ATTENTION
RISQUE D’ÉLECTROCUTION !
NE PAS OUVRIR !
WARNING
TO PREVENT FIRE OR SHOCK HAZARD. DO NOT USE THIS PLUG WITH AN EXTENSION
CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED
TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE. TO PREVENT ELECTRICAL SHOCK, MATCH WIDE
BLADE PLUG TO WIDE SLOT AND FULLY INSERT.
Copyright 2020, Samson Technologies Corp. v1.1
Samson Technologies Corp.
278-B Duffy Ave
Hicksville, NY 11801
www.samsontech.com
If you want to dispose this product, do not mix it with general household waste. There is
a separate collection system for used electronic products in accordance with legislation
that requires proper treatment, recovery and recycling.
Private households in the 28 member states of the EU, in Switzerland and Norway may
return their used electronic products free of charge to designated collection facilities or to a
retailer (if you purchase a similar new one).
For Countries not mentioned above, please contact your local authorities for a correct method of
disposal.
By doing so you will ensure that your disposed product undergoes the necessary treatment,
recovery and recycling and thus prevent potential negative effects on the environment and
human health.

Owner’s Manual
3
Important Safety Information
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose of
the polarized or grounding type plug.
A polarized plug has two blades with
one wider than the other. A grounding
type plug has two blades and a third
grounding prong. The wide blade or the
third prong are provided for your safety.
If the provided plug does not fit into
your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked
on or pinched particularly at the plugs,
convenience receptacles, and at the
point where they exit from the apparatus.
11. Only use attachments/accessories
specified by the manufacturer.
12. Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
13. Unplug the apparatus during lightning
storms, or when unused for long periods
of time.
14. Refer all servicing to qualified personnel.
Service is required when the apparatus
has been damaged in any way, such as
power supply cord or plug is damaged,
liquid has been spilled or objects have
fallen into the apparatus, has been
exposed to rain or moisture, does not
operate normally, or has been dropped.
15. This appliance shall not be exposed to
dripping or splashing water and no object
filled with liquid such as vases shall be
placed on the apparatus.
16. Caution-to prevent electrical shock,
match wide blade plug wide slot fully
insert.
17. Please keep a good ventilation
environment around the entire unit.
18. The direct plug-in adapter is used as
disconnect device, the disconnect device
shall remain readily operable.
19. Batteries (battery pack or batteries
installed) shall not be exposed to
excessive heat such as sunshine, fire or
the like.

XPDm Digital Wireless
4
Important Safety Information
FCC Notice
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may
cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio com-
munications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
RF Exposure Statement (SAR)
This device is designed and manufactured not to exceed the emission limits for exposure to
radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Gov-
ernment.
Hereby, Samson Technologies Corp., declares that this XPDm Digital Wireless System is in com-
pliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.
The declaration of conformity may be consulted at:
http://www.samsontech.com/site_media/support/manuals/XPDm_DOC.pdf

Owner’s Manual
5
Introduction
Congratulations on purchasing the Samson XPDm Digital Wireless System.
The XPDm Digital Wireless System, available in Handheld, Lavalier, and Headset
configurations, operates in the license free 2.4GHz frequency range.This system is a
unique wireless microphone solution that is ideal for presenters, fitness instructors,
educators, interviewers and more.
The RXD1M tabletop receiver is compact enough to fit in any carry bag and includes
XLR, 1/4”, and 1/8” outputs for easy connection to mixers and PA systems. One-
touch pairing allows for straight forward connection between transmitter and receiver.
Samson’s XPDm Digital Wireless Systems have a range of 100’ and offer up to 20
hours of operation using two AA batteries.
In these pages, you’ll find a detailed description of the features of the XPDm Digital
Wireless System, instructions for its setup and use, and specifications. If your
wireless system was purchased in the United States, you’ll also find a registration
card enclosed—don’t forget to follow the instructions so that you can receive
technical support and so that we can send you updated information about this and
other Samson products in the future. Also, be sure to check out our website (www.
samsontech.com) for complete information about our full product line.
We recommend you keep the following records for reference, as well as a copy of your
sales receipt.
Transmitter & Receiver Serial number: _________________________________
Date of purchase: ___________________________________________________
If you have any questions or comments regarding the XPDm Digital Wireless
Microphone System or any other products from Samson, do not hesitate to contact us
at [email protected].
With proper care and maintenance, your XPDm Digital Wireless System will operate trouble-
free for many years. Should your XPDm Digital Wireless System ever require servicing, a
Return Authorization (RA) number must be obtained before shipping your unit to Samson.
Without this number, the unit will not be accepted. Please visit www.samsontech.com/ra for
an RA number prior to shipping your unit. Please retain the original packing materials and,
if possible, return the unit in its original carton. If your XPDm Digital Wireless System was
purchased outside of the United States, contact your local distributor for warranty details
and service information.

XPDm Digital Wireless
6
RXD1M Receiver Features
1. VOLUME/Power Control - This rotary knob controls the level of the receiver
output and powers the RXD1m on and off. Turn clockwise to power on and
counterclockwise to power off. The light ring around the VOLUME/Power Control
will illuminate white when powered on.
2. PAIR button - Press and hold for more than three seconds to enter pairing mode,
the READY LED will begin flashing. NOTE - the system is paired at the factory
prior to shipment.
3. READY Indicator - This LED displays the operation mode. Solid AMBER means
normal operation, flashing AMBER means pairing, no light means not paired or
that the transmitter is either out of range or powered off.
1
2
3

Owner’s Manual
7
1. DC Input - Connect the suplied adapter here. WARNING: Do not substitute any
other kind of power adapter. Doing so can cause severe damage to your RXD1m
and void your warranty.
2. Unbalanced Outputs - Use these unbalanced 1/4” and 1/8” jacks when
connecting the RXD1m to consumer (-10 dBV) audio equipment. Wiring is as
follows: tip hot, sleeve ground
3. Balanced Output - Use this electronically balanced low impedance (600
Ohm) XLR jack when connecting the RXD1m to professional (+4 dBu) audio
equipment. Pin wiring is as follows: Pin 1 ground, Pin 2 high (hot), and Pin 3
low (cold)
RXD1m Receiver Features Rear Panel
1 2 2 3

XPDm Digital Wireless
8
1. Status Indicator - This LED displays the operation
mode. Amber: Normal Operation
Flashing Amber: Pairing / Low Battery
2. Power/Pair Switch - Press <5 seconds to turn the
unit on or off. Press >5 seconds to enter pairing
mode.
3. Battery Cover - Unscrew the battery cover and
slide down to open the HXD1 Handheld battery
compartment.
4. Battery Holder - Open the battery holder by
pressing the tab and lifting the cover. Insert two
standard AA (LR6) batteries here, being sure to
observe the plus and minus polarity markings
shown.
WARNING: Do not insert the batteries backwards;
doing so can cause severe damage to the
transmitter and will void your warranty.
5. Input GAIN Control - This control adjusts the
transmitter input sensitivity. This input sensitivity
control has been factory preset to provide
optimum level for the particular microphone
capsule provided with the XPDm system and
so we recommend that this not be adjusted
manually. If necessary, however, you can use the supplied screwdriver to raise or
lower the input level.
6. Screwdriver - Used to adjust the input GAIN control.
HXD1 Handheld Transmitter Callouts

Owner’s Manual
9
PXD1 Beltpack Transmitter Callouts
1. Input Connector - Connect
the input device via this
mini-XLR input jack.
The PXD1 is supplied
with either a lavalier or
headset microphone that is
wired to a P3 connector.
2. Status Indicator - This LED
displays the operation mode.
Amber: Normal Operation
Flashing Amber: Pairing / Low
Battery
3. Power/Pair Switch - Press <5
seconds to turn the unit on or
off. Press >5 seconds to enter
pairing mode.
4. Input GAIN Control - This
control adjusts the transmitter
input sensitivity.
5. Battery Holder - Open the battery holder by pressing the tab and lifting the cover.
Insert two standard AA (LR6) batteries here, being sure to observe the plus and
minus polarity markings shown.
WARNING: Do not insert the batteries backwards; doing so can cause severe
damage to the transmitter and will void your warranty.
6. Screwdriver - Used to adjust the input GAIN control.

XPDm Digital Wireless
10
In order for the XPDm Digital Wireless System to work correctly, both the RXD1m
receiver and HXD1 handheld or PXD1 beltpack transmitter must be paired together.
(NOTE: The XPDm Digital Wireless System will come paired from the factory).
Follow this basic procedure for setting up and using your XPDm Digital Wireless
System:
1. Physically place the RXD1m receiver where it will be used. We suggest you keep
receiver and transmitter within line of sight for optimal performance, meaning
the performer using or wearing the transmitter can see the receiver.
2. Connect the included power adapter to the RXD1m receiver before turning the
power on. Turn the RXD1m on momentarily to confirm that it is receiving power,
then turn it off (figure 1).
3. With your amplifier or mixer powered off and
volume control down connect the RXD1m
receiver output jack to the mic or line input
using the balanced XLR output, unbalanced
1/4” or 1/8” output jacks. Turn the RXD1m
power on but keep the volume at minimum
level (figure 2).
4. Place a fresh set of AA (LR6) batteries in the
transmitter’s battery compartment being sure to observe polarity markings (figure
3).
Quickstart
Figure 2
Figure 3
Figure 1
