Samsung ProXpress C306x series User manual

BASIC
User Guide
BASIC
User Guide
This guide provides information concerning the installation, basic operation
and troubleshooting on Windows.
ADVANCED
This guide provides information about installation, advanced configuration, operation and
troubleshooting on various OS environments.
Some features may not be available depending on models or countries.

2
BASIC
1. Introduction
Key benefits 5
Features by model 7
Useful to know 9
About this user guide 10
Safety information 11
Machine overview 17
Control panel overview 21
Turning on the machine 23
Installing the driver locally 24
Reinstalling the driver 26
2. Menu Overview and Basic Setup
Menu overview 28
Machine’s basic settings 41
Media and tray 42
Basic printing 57
Basic copying 64
Basic scanning 69
Basic faxing 70
Using USB memory device 74
3. Maintenance
Ordering supplies and accessories 81
Available supplies 82
Available accessories 83
Available maintenance parts 84
Storing the toner cartridge 85
Redistributing toner 87
Replacing the toner cartridge 89
Replacing the waste toner container 92
Installing accessories 94
Monitoring the supplies life 96
Setting the toner low alert 97
Cleaning the machine 98
Tips for moving & storing your machine 104
4. Troubleshooting
Tips for avoiding paper jams 106
Clearing paper jams 107
Understanding the status LED 120
Understanding display messages 122

3
BASIC
5. Appendix
Specifications 130
Regulatory information 140
Copyright 153

1. Introduction
This chapter provides information you need to know before using the machine.
•Keybenefits 5
• Features by model 7
• Useful to know 9
• About this user guide 10
• Safety information 11
• Machine overview 17
• Control panel overview 21
• Turning on the machine 23
• Installing the driver locally 24
• Reinstalling the driver 26

Key benefits
Environmentally friendly
• To save toner and paper, this machine supports Eco feature (see "Eco
printing" on page 61).
• To save paper, you can print multiple pages on one single sheet of paper
(see "Using advanced print features" on page 261).
• To save paper, you can print on both sides of the paper (double-sided
printing) (see "Using advanced print features" on page 261).
• To save electricity, this machine automatically conserves electricity by
substantially reducing power consumption when not in use.
• We recommend using recycled paper for saving energy.
Fast high resolution printing
• You can print in a full range of colors using cyan, magenta, yellow, and black.
• You can print with a resolution of up to 9,600 x 600 dpi effective output (600
x 600 x 4 bit).
• Fast, on-demand printing.
- For single-side printing, up to 30 ppm (A4) or up to 31 ppm (Letter).
Convenience
• You can print on the go from your smartphone or computer using Samsung
Cloud Print apps (see "Samsung Cloud Print" on page 204).
• Simply touch your mobile device on the NFC tag on your printer and get the
print job done (see "Using the NFC feature" on page 191).
• You can print on the go from your smartphone or computer using Google
Cloud Print™ enabled apps (see "Google Cloud Print™" on page 209).
• Easy Capture Manager allows you to easily edit and print whatever you
captured using the Print Screen key on the keyboard (see "Easy Capture
Manager" on page 302).
• Samsung Easy Printer Manager and Printing Status is a program that
monitors and informs you of the machine’s status and allows you to
customize the machine’s settings (see "Using Samsung Printer Status" on
page 312 or "Using Samsung Easy Printer Manager" on page 309).
• Samsung Easy Document Creator is an application to help users scan,
compile, and save documents in multiple formats, including .epub format.
These documents can be shared via social networking sites or fax (see
"Using Samsung Easy Document Creator" on page 305).

Key benefits
• Smart Update allows you to check for the latest software and install the
latest version during the printer driver installation process. This is available
only for Windows.
• If you have Internet access, you can get help, support application, machine
drivers, manuals, and order information from the Samsung website,
www.samsung.com > find your product > Support or Downloads.
Wide range of functionality and application support
• Supports various paper sizes (see "Print media specifications" on page 132).
• Print watermark: You can customize your documents with words, such as
“Confidential” (see "Using advanced print features" on page 261).
• You can print in various operating systems (see "System requirements" on
page 136).
• Your machine is equipped with a USB interface and/or a network interface.
Supports various wireless network setting method
• Using the WPS (Wi-Fi Protected Setup™)
- You can easily connect to a wireless network using the WPS menu on the
machine and the access point (a wireless router).
• Using the USB cable or a network cable
- You can connect and set various wireless network settings using a USB
cable or a network cable.
• Using the Wi-Fi Direct
- You can conveniently print from your mobile device using the Wi-Fi or
Wi-Fi Direct feature.
See "Wireless network setup" on page 176.

Features by model
Some features and optional goods may not be available depending on
model or country.
Operating System
(●: Supported, Blank: Not supported)
Software
You can install the printer driver and software when you insert the software
CD into your CD-ROM drive. For windows, select the printer driver and
software in the Select Software to Install window.
(●: Supported, Blank: Not supported)
Operating
System C306xND series C306xFR series C306xFW series
Windows ● ● ●
Mac ● ● ●
Linux ● ● ●
Unix ● ● ●
Software C306xND
series
C306xFR
series
C306xFW
series
SPL printer driver ●●●
PCL printer driver ●●●
PS printer drivera●●●
XPS printer drivera●●●
Direct Printing Utilitya●●●
Samsung Printer Center ●●●
Samsung
Easy
Printer
Manager
Scan to PC
Settings
● ● ●
Fax to PC
Settings
● ●
Advanced
Setting
● ● ●
Samsung Printer Status ● ● ●
Samsung AnyWeb Printa● ● ●
Samsung Easy
Document Creator
● ● ●
Easy Capture Manager ● ● ●
Samsung Eco Driver Pack
b
● ● ●
Samsung Stylish Driver
Pack
c
● ● ●
SyncThru™ Web Service ●●●
Fax Samsung
Network PC
Fax
● ●
Scan Scan driver ● ● ●
a. Download the software from the Samsung website and install it: (http://
www.samsung.com > find your product > Support or Downloads). Before installing,
check whether your computer’s OS support the software.
b. To use the Easy Eco Driver features, the Eco Driver Pack must be installed.
c. The printer driver includes a user interface that is optimized for touchscreens. To use this
UI, click Samsung Printer Center > Device Options and then select Stylish User
Interface (see "Using Samsung Printer Center" on page 306).
Software C306xND
series
C306xFR
series
C306xFW
series

Features by model
Variety feature
(●: Supported, ○: Optional, Blank: Not supported)
Features C306xND
series
C306xFR
series
C306xFW
series
Hi-Speed USB 2.0 ● ● ●
Network Interface
Ethernet 10/100/1000
Base TX wired LAN
●●●
Network Interface
802.11b/g/n wireless
LANa
○ ○ ●
NFC (Near Field
Communication)
○ ○ ●
Google Cloud Print™ ● ● ●
Samsung Cloud Print ● ● ●
PrinterOn ● ● ●
Mopria ● ● ●
Eco printing ●●●
Duplex (2-sided)
printing
● ● ●
USB memory interface ● ● ●
Optional tray (Tray2,
Tray3)
○ ○ ○
Docum
ent
Feeder
Automatic
Document
Feeder (ADF)
●
Reversing
Automatic
Document
Feeder
(RADF)
● ●
a. Depending on your country, wireless LAN card may not be available. For some countries,
only 802.11 b/g can be applied. Contact your local Samsung dealer or the retailer where
you bought your machine.
Features C306xND
series
C306xFR
series
C306xFW
series

Useful to know
The machine does not print.
• Open the print queue list and remove the document from the
list (see "Canceling a print job" on page 58).
• Remove the driver and install it again (see "Installing the driver
locally" on page 24).
• Select your machine as your default machine in your Windows
(see "Setting your machine as a default machine" on page 261).
Where can I purchase accessories or supplies?
• Inquire at a Samsung distributor or your retailer.
• Visit www.samsung.com/supplies. Select your country/region
to view product service information.
The status LED flashes or remains constantly on.
• Turn the product off and on again.
• Check the meanings of LED indications in this manual and
troubleshoot accordingly (see "Understanding the status LED"
on page 120).
A paper jam has occurred.
• Open and close the cover (see "Front view" on page 18).
• Check the instructions on removing jammed paper in this
manual and troubleshoot accordingly (see "Clearing paper
jams" on page 107).
Printouts are blurry.
• The toner level might be low or uneven. Shake the toner
cartridge (see "Redistributing toner" on page 87).
• Try a different print resolution setting (see "Opening printing
preferences" on page 59).
• Replace the toner cartridge (see "Replacing the toner
cartridge" on page 89).
Where can I download the machine’s driver?
• You can get help, support application, machine drivers,
manuals, and order information from the Samsung website,
www.samsung.com > find your product > Support or
Downloads.

10
1. Introduction
About this user guide
This user guide provides information for your basic understanding of the
machine as well as detailed steps to explain machine usage.
• Do not discard this manual, and keep it for future reference.
• Read the safety information before using the machine.
• If you have a problem using the machine, refer to the troubleshooting
chapter.
• Terms used in this user guide are explained in the glossary chapter.
• All illustrations in this user guide may differ from your machine depending
on its options or model you purchased.
• The screenshots in this user guide may differ from your machine depending
on the machine’s firmware/driver version.
• The procedures in this user guide are mainly based on Windows 7.
1
Conventions
Some terms in this guide are used interchangeably, as below:
• Document is synonymous with original.
• Paper is synonymous with media, or print media.
• Machine refers to printer or MFP.
2
General icons
Icon Text Description
Warning Used to alert users to the possibility of personal injury.
Caution Gives users information to protect the machine from
possible mechanical damage or malfunction.
Note Provides additional information or detailed
specification of the machine function and feature.

11
1. Introduction
Safety information
These warnings and precautions are included to prevent injury to you and
others, and to prevent any potential damage to your machine. Be sure to read
and understand all of these instructions before using the machine. After reading
this section, keep it in a safe place for future reference.
3
Important safety symbols
Explanation of all icons and signs used in this chapter
4
Operating environment
Warning
Warning Hazards or unsafe practices that may result in severe
personal injury or death.
Caution Hazards or unsafe practices that may result in minor
personal injury or property damage.
Do not attempt.
Do not use if the power cord is damaged or if the electrical outlet is
not grounded.
This could result in electric shock or fire.
Do not place anything on top of the machine (water, small metal or
heavy objects, candles, lit cigarettes, etc.).
This could result in electric shock or fire.
• If the machine gets overheated, it releases smoke, makes
strange noises, or generates an odd odor, immediately turn off
the power switch and unplug the machine.
• The user should be able to access the power outlet in case of
emergencies that might require the user to pull the plug out.
This could result in electric shock or fire.
Do not bend, or place heavy objects on the power cord.
Stepping on or allowing the power cord to be crushed by a heavy
object could result in electric shock or fire.
Do not remove the plug by pulling on the cord; do not handle the
plug with wet hands.
This could result in electric shock or fire.

Safety information
12
1. Introduction
Caution
5
Operating method
Caution
During an electrical storm or for a period of non-operation,
remove the power plug from the electrical outlet.
This could result in electric shock or fire.
Be careful, the paper output area is hot.
Burns could occur.
If the machine has been dropped, or if the cabinet appears
damaged, unplug the machine from all interface connections and
request assistance from qualified service personnel.
Otherwise, this could result in electric shock or fire.
If the machine does not operate properly after these instructions
have been followed, unplug the machine from all interface
connections and request assistance from qualified service
personnel.
Otherwise, this could result in electric shock or fire.
If the plug does not easily enter the electrical outlet, do not
attempt to force it in.
Call an electrician to change the electrical outlet, or this could
result in electric shock.
Do not allow pets to chew on the AC power, telephone or PC
interface cords.
This could result in electric shock or fire and/or injury to your pet.
Do not forcefully pull the paper out during printing.
It can cause damage to the machine.
Be careful not to put your hand between the machine and paper
tray.
You may get injured.
Be careful when replacing paper or removing jammed paper.
New paper has sharp edges and can cause painful cuts.
When printing large quantities, the bottom part of the paper
output area may get hot. Do not allow children to touch.
Burns can occur.
When removing jammed paper, do not use tweezers or sharp metal
objects.
It can damage the machine.
Do not allow too many papers to stack up in the paper output tray.
It can damage the machine.

Safety information
13
1. Introduction
6
Installation / Moving
Warning
Do not block or push objects into the ventilation opening.
This could result in elevated component temperatures which can
cause damage or fire.
Use of controls or adjustments or performance of procedures other
than those specified herein may result in hazardous radiation
exposure.
This machine's power reception device is the power cord.
To switch off the power supply, remove the power cord from the
electrical outlet.
Do not place the machine in an area with dust, humidity, or water
leaks.
This could result in electric shock or fire.
Place the machine in the environment where it meets the
operating temperature and humidity specification.
Do not use the machine when it is below freezing temperature or
has recently been moved from a location below freezing
temperature. Doing so may damage the machine. Only operate the
machine when the internal temperature of the machine is within
the operating temperature and humidity specifications.
Otherwise, quality problems can occur and cause damage to the
machine.
See "General specifications" on page 130.

Safety information
14
1. Introduction
Caution
Before moving the machine, turn the power off and disconnect all
cords. The information below are only suggestions based on the
units weight.
If you have a medical condition that prevents you from lifting, do
not lift the machine. Ask for help, and always use the appropriate
amount of people to lift the device safely.
Then lift the machine:
• If the machine weighs under 20 kg (44.09 lbs), lift with 1 person.
• If the machine weighs 20 kg (44.09 lbs) - 40 kg (88.18 lbs), lift
with 2 people.
• If the machine weighs more than 40 kg (88.18 lbs), lift with 4 or
more people.
The machine could fall, causing injury or machine damage.
Choose a flat surface with enough space for ventilation to place
the machine. Also consider the space required to open the cover
and trays.
The place should be well-ventilated and be far from direct light,
heat, and humidity.
When using the machine for a long period of time or printing a
large number of pages in a non-ventilated space, it could pollute
the air and be harmful to your health. Place the machine in a well-
ventilated space or open a window to circulate the air periodically.
Do not place the machine on an unstable surface.
The machine could fall, causing injury or machine damage.
Use only No.26 AWGaor larger, telephone line cord, if necessary.
Otherwise, it can cause damage to the machine.
Make sure you plug the power cord into a grounded electrical
outlet.
Otherwise, this could result in electric shock or fire.
Use the power cord supplied with your machine for safe
operation. If you are using a cord which is longer than 2 meters (6
feet) with a 110V machine, then the gauge should be 16 AWG or
larger.
Otherwise, it can cause damage to the machine, and could result
in electric shock or fire.
Do not put a cover over the machine or place it in an airtight
location, such as a closet.
If the machine is not well-ventilated, this could result in fire.
Do not overload wall outlets and extension cords.
This can diminish performance, and could result in electric shock
or fire.
The machine should be connected to
the power level which is specified on the label.
If you are unsure and want to check the power level you are using,
contact the electrical utility company.
a. AWG: American Wire Gauge

Safety information
15
1. Introduction
7
Maintenance / Checking
Caution
8
Supply usage
Caution
Unplug this product from the wall outlet before cleaning the
inside of the machine. Do not clean the machine with benzene,
paint thinner or alcohol; do not spray water directly into the
machine.
This could result in electric shock or fire.
When you are working inside the machine replacing supplies or
cleaning the inside, do not operate the machine.
You could get injured.
Keep cleaning supplies away from children.
Children could get hurt.
Do not disassemble, repair or rebuild the machine by yourself.
It can damage the machine. Call a certified technician when the
machine needs repairing.
To clean and operate the machine, strictly follow the user's guide
provided with the machine.
Otherwise, you could damage the machine.
Keep the power cable and the contact surface of the plug clean
from dust or water.
Otherwise, this could result in electric shock or fire.
• Do not remove any covers or guards that are fastened with
screws.
• Fuser units should only be repaired by a certified service
technician. Repair by non-certified technicians could result in
fire or electric shock.
• The machine should only be repaired by a Samsung service
technician.
Do not disassemble the toner cartridge.
Toner dust can be dangerous if inhaled or ingested.
Do not burn any of the supplies such as toner cartridge or fuser
unit.
This could cause an explosion or uncontrollable fire.

Safety information
16
1. Introduction
When storing supplies such as toner cartridges, keep them away
from children.
Toner dust can be dangerous if inhaled or ingested.
Using recycled supplies, such as toner, can cause damage to the
machine.
In case of damage due to the use of recycled supplies, a service
fee will be charged.
For supplies that contain toner dust (toner cartridge, waste toner
bottle, imaging unit, etc.) follow the instructions below.
• When disposing of the supplies, follow the instructions for
disposal. Refer to the reseller for disposal instructions.
• Do not wash the supplies.
• For a waste toner bottle, do not reuse it after emptying the
bottle.
If you do not follow the instructions above, it may cause machine
malfunction and environmental pollution. The warranty does not
cover damages caused by a user’s carelessness.
When toner gets on your clothing, do not use hot water to wash
it.
Hot water sets toner into fabric. Use cold water.
When changing the toner cartridge or removing jammed paper,
be careful not to let toner dust touch your body or clothes.
Toner dust can be dangerous if inhaled or ingested.

17
1. Introduction
Machine overview
9
Components
The actual component may differ from the illustration below. Some components may change depending on the configuration.
Machinea
a. This illustration may differ from your machine depending on your model. There are various types of machine.
Power cord Quick installation guide
Software CDb
b. The software CD contains the print drivers, user’s guide, and software applications.
Misc. accessoriesc
c. Miscellaneous accessories included with your machine may vary by country of purchase and specific model.
Toner
MUST READ
INSTALLATION
GUIDE
INSTALLINGTHE
TONER CARTRIDGE
AND IMAGING
UNIT
PREPARING
Samsung Multifunction Xpress
c267xFX series
Thankyou for purchasing a Samsung product.
SAMSUNG.
PRINTING INNOVATION.

Machine overview
18
1. Introduction
10
Front view
• This illustration may differ from your machine depending on your model.
There are various types of machine.
• Some features and optional goods may not be available depending on
model or country (see "Features by model" on page 7).
C306xND series
17
16
2
1
4
7
5
3
6
18
19
20
21
22
9
8
15
13
14
10
11
12
1 Automatic Document Feeder (ADF)
cover
12 USB memory port
2 Automatic Document Feeder (ADF)
width guide
13 Output tray
3 Automatic Document Feeder (ADF)
input tray
14 Output support tray
4 Automatic Document Feeder (ADF)
output tray
15 Front cover handle
5 Control panel 16 Scanner lid
6 Control board cover 17 Scanner glass
7Front cover 18 Paper width guides on a multi-
purpose tray
8 Tray 1 19 Multi-purpose support tray
9Optional traya
a. Install the optional tray if it is necessary.
20 Toner cartridges
10 Push-release of Multi-purpose tray 21 Toner cartridge handle
11 Multi-purpose tray 22 Intermediate Transfer Belt (ITB)

Machine overview
19
1. Introduction
C306xFR series/ C306xFW series
17
18
19
23
20
16
15
2
1
4
7
5
6
10
11
22
21
14 13
12
3
8
9
24
1 Reversing Automatic Document
Feeder (RADF)
13 Output tray
2 Reversing Automatic Document
Feeder (RADF) width guide
14 Output support tray
3 Reversing Automatic Document
Feeder (RADF) input tray
15 Front cover handle
4 Reversing Automatic Document
Feeder (RADF) output tray
16 Scanner lid
5 Control panel 17 Scanner glass
6Control board cover 18 Paper width guides on a multi-
purpose tray
7 Front cover 19 Multi-purpose support tray
8 Tray 1 20 Toner cartridges
9Optional traya
a. Install the optional tray if it is necessary.
21 Toner cartridge handle
10 Push-release of Multi-purpose
tray
22 Intermediate Transfer Belt (ITB)
11 Multi-purpose tray 23 Duplex jam cover
12
USB memory port
24 NFC (Near Field Communication)
tagb
b. C306xFW only.

Machine overview
20
1. Introduction
11
Rear view
• This illustration may differ from your machine depending on your model.
There are various types of machine.
• Some features and optional goods may not be available depending on
model or country (see "Features by model" on page 7).
1
2
3
4
5
8
6
9
1
7
1 Waste toner container
2 Rear cover
3 Rear cover handle
4Powerreceptacle
5 USB memory port
6USBport
7 Network port
8Telephone line socket (LINE)a
a. C306xFR and C306xFW only.
9Extension telephone socket (EXT.)a
