Samsung AX041HCVAUW Series User manual

QUESTIONS OR COMMENTS?
COUNTRY CALL OR VISIT US ONLINE AT
SINGAPORE 1800-SAMSUNG (726 7864) www.samsung.com/sg/support
MALAYSIA 1800-88-9999
603-77137477 (Overseas contact) www.samsung.com/my/support
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 2 2015-08-03 오전 9:26:20

AX041HCVAUW Series
AX022HCVAND Series
Air Purifier
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
This manual is made with 100% recycled paper.
EN
DB68-04616A-02
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 3 2015-08-03 오전 9:26:20

Product Features
TOTAL AIR CARE!! Purication and sterilization at the same time!!
 Air purication via a dual cleaning system with 3-step ltering and ion-sterilization
Improves the indoor air quality through a 3-step ltering system that consists of a Pre lter (removes dust) HEPA lter
(removes particles) deodorization lter (removes harmful gases and odors) and a Virus Doctor that directly emits ions
for sterilization.
 The amazing air purication technology of the Virus Doctor:
Samsung Electronics’proprietary Virus Doctor emits active hydrogen (H) and oxygen (O2-) ions which combine into
Hydroperoxy Radicals (HOO-) surrounding harmful particles oating in the air and destroy the hydrogen connections of
the protein structure.
High-performance purication system
 Eective dust collecting:
The HEPA lter collects invisible ne particles including dust in the air.
 Eective deodorization:
The high-performance activated carbon lter quickly removes odor from food and cigarette.
 Virus Doctor:
Emits active hydrogen and oxygen ions to remove oating germs, viruses and allergens from the air.
 Sensitive sensor:
Each of the dust and odor sensors detects dust and odors, shows the current air pollution level and operates the unit in
the optimal mode.
Contents
Preparation
Safety precautions ....................................................................................................... 3
Check before use ....................................................................................................... 10
Check the name of the components .................................................................................... 12
Basic function
Air purication operation ............................................................................................... 15
Pre lter cleaning alarm function ........................................................................................ 15
Integrated HEPA/deodorization lter replacement alarm function ....................................................... 16
Button lock function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Sleep mode ............................................................................................................. 16
Others
Cleaning and maintenance ............................................................................................. 17
Troubleshooting ........................................................................................................ 22
ENGLISH-2
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 2 2015-08-03 오전 9:26:20

Safety precautions
These safety precautions are for owner’s safety and preventions of
property damage. Therefore, please read this manual thoroughly before
using your air purier.
WARNING Hazards or unsafe practices that may result in severe
personal injury or death.
CAUTION Hazards or unsafe practices that may result in minor
personal injury or property damage.
Follow directions.
Do NOT attempt.
Make sure the machine is grounded to prevent
electric shock.
Unplug the appliance.
Do NOT disassemble.
FOR INSTALLATION WARNING
Plug the power cord into a wall socket with the power
specications of the product or higher and use the socket for this
appliance only. In addition, do not use an extension cord.
 Sharing a wall socket with other appliances using a multi outlet
power strip or extending the power cord may result in electric
shock or re.
 Do not use an electric transformer. It may result in electric shock
or re.
 If the voltage/frequency/rated current condition is dierent, it
may cause electric shock or re.
PREPARATION
ENGLISH-3
01 PREPARATION
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 3 2015-08-03 오전 9:26:21

Safety precautions
FOR INSTALLATION WARNING
Do not install this appliance near a heater, inammable material.
Do not install this appliance in a humid, oily or dusty location, in
a location exposed to direct sunlight and water (rain drops). Do
not install this appliance in a location where gas may leak.
 Failure to do so may result in electric shock or re.
FOR INSTALLATION CAUTION
The appliance should be installed in a place where the power
cord of the product can be easily pulled out.
 Failure to do so may result in electric shock or re due to electric
leakage.
Install your appliance on a level and hard oor that can support
its weight.
 Failure to do so may result in abnormal vibrations, noise, or
problems with the product.
There should be over 15cm space around the appliance.
 If space for air intake is not enough, humidication capacity may
decrease.
 If the appliance is too near wall side, the wall paper may get
damaged.
When installing the product, make sure that no heavy objects are
on the power cord.
 Failure to do so may result in electric shock or re.
ENGLISH-4
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 4 2015-08-03 오전 9:26:21

FOR POWER SUPPLY WARNING
Unplug the product, and then remove foreign substances
(dust, moisture, etc.) of the power plug terminal or power plug
connection part with a dry cloth on a regular basis.
 Otherwise, electric shock or re may occur.
When the product, power plug or power cord is damaged,
contact your nearest service center.
Plug the power plug into the wall socket rmly. Do not use a
damaged power plug, damaged power cord or loose wall socket.
 Failure to do so may result in electric shock or re.
When unplugging the product, do not pull the power cord. Grip
the power plug, and then pull the power plug.
 Otherwise, electric shock or re may occur.
Do not pull or excessively bend the power cord. Do not twist or
tie the power cord.
Do not hook the power line over a metal object, place a heavy
object on the power cord, insert the power line between objects,
or push the power cord into the space behind the appliance.
 This may result in electric shock or re.
FOR POWER SUPPLY CAUTION
When the air purier will not be used for a long period of time
or during a thunder or lightning storm, disconnect the power
supply.
 Failure to do so may result in electric shock or re.
It is dangerous when the power cable gets damaged, therefore
contact a service center or qualied experts for the repair.
ENGLISH-5
01 PREPARATION
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 5 2015-08-03 오전 9:26:21

Safety precautions
FOR OPERATION WARNING
If the appliance is ooded, turn o the appliance and contact a
service center.
If the appliance generates a strange noise, a burning smell or
smoke, disconnect the power supply immediately and contact a
service center.
 Failure to do so may result in electric shock or re.
When gases (city gas, profane gas, etc.) leak, do not touch the
power cord. Immediately ventilate the area and contact a service
center or a qualied technician.
 Do not use a ventilating fan.
 If there is a spark, explosion or re may occur.
Do not unplug the appliance during operation.
 When plugging the appliance in again, ame may occur and it
may result in electric shock or re.
When a repair is needed, contact the service center.
 Failure to do so may result in a product malfunction, water
leakage, electric shock or re.
Do not touch the power plug with wet hands.
 This may result in electric shock.
Do not apply a force to or pull the product using excessive force.
 This may result in re, injury, or a problem with the product.
After unpacking the air purier, keep all packaging materials out
of the reach of children.
 If a child places a bag over its head, it may suocate.
Do not insert your ngers or a foreign substance into the air inlet
or outlet.
 Take special care that children do not injure themselves by
inserting their ngers into the product.
ENGLISH-6
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 6 2015-08-03 오전 9:26:21

Do not place an object near the outdoor unit that makes it
possible for children to climb onto the machine.
 The child could fall and injure themselves or the product may fall
over and injure the child.
Do not put other foreign materials such as metal into the
product.
 This may result in electric shock or injury.
If water has entered the power supply module, unplug the power
cable and dry the product completely before use.
 Failure to do so may result in electric shock or re.
Do not place heavy objects on the product.
 Failure to do so may result in a product malfunction or noise.
Do not attempt to repair, disassemble, or modify the product
yourself.
 Do not use a fuse (such as copper, steel wire, etc.) other than a standard
fuse.
 Failure to do so may result in electric shock, re, a product
malfunction or injury.
If a foreign substance such as water has entered the product,
disconnect the power supply and contact the service center.
 Failure to do so may result in electric shock or re.
ENGLISH-7
01 PREPARATION
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 7 2015-08-03 오전 9:26:21

Safety precautions
FOR OPERATION CAUTION
Keep a distance of about 2m from other electric appliances such
as a TV, video or audio device etc.
 Failure to do so may result in reduced video quality or noise.
Leave a space greater than 5cm (15cm or more is recommended)
between the product and the wall.
 This product extracts air at the back to purify the air, therefore,
installing the product in the center of a room may be most
ecient. However, when installing the product against a wall,
allow a distance of at least 5cm (15cm or more is recommended)
between the product and the wall.
Do not spray volatile material such as insecticide onto the
product.
 As well as being harmful to humans, this may also result in
electric shock, re or a product malfunctions.
Do not tilt or turn the product upside down while the product is
connected to the wall outlet.
 Failure to do so may result in a malfunction or re.
Do not put the product into water.
 This may result in a product malfunction
Do not place the product on the edge of a desk or table.
Do not stand on top of the product or place objects (such as
laundry, lighted candles, lighted cigarettes, dishes, chemicals,
metal objects, etc.) on the product.
 This may result in electric shock, re, a product malfunction or
injury.
Do not operate the product with wet hands.
 This may result in electric shock.
ENGLISH-8
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 8 2015-08-03 오전 9:26:21

This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play
with the appliance.
For use in Europe : This appliance can be used by children aged from
8 years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
FOR CLEANING WARNING
Do not clean the product by spraying water directly onto it.
Do not use benzene, thinner, acetone or alcohol to clean the
product.
 This may result in discoloration, deformation, damage, electric
shock or re.
Disconnect the power supply and stop the fan operation before
cleaning the product.
 Failure to do so may result in electric shock or re.
ENGLISH-9
01 PREPARATION
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 9 2015-08-03 오전 9:26:21

Check before use
Installation status
Ensure that the following installation requirements have been satised.
 The product should be installed on an even, level oor.
 There should be no objects blocking the air intake and outlet.
 The installation site should be dry and there should be no inammable substances around it.
 The product should be installed at least 5 cm (15 cm is recommended) from the wall.
 Before using the product for the rst time and when replacing the integrated HEPA/deodorization lter, make sure to
remove the plastic packaging of the lter.
Power plug and power outlet
 Be sure to use a dedicated 220 - 240 V electrical outlet.
(When the power is applied, the product enters the standby state.)
 Unplug the power plug if it will not be used for a long period of time.
General information about the product
Be sure to install the lters before using the product and replace the lters when they start emitting a strange odor.
 This product is highly ecient for deodorizing household odors such as ammonia, as well as formaldehyde (the main
cause of sick building syndrome), VOCs etc. However, deodorization function of the air purier is eective when air is
penetrates through the lter. Therefore when there’s excessive odor in your room, ventilate the room rst and use the air
purier afterwards to eliminate remaining odors for more eective deodorization.
 If you operate the air purier without the lters, you cannot expect any air purication eect.
 If the lters are contaminated, the air purication performance will be degraded. If the lters are seriously dirty or emit a
bad odor or the airow from the product decreases signicantly, replace the lters.
Avoid operating the air purication system when cooking food that generates a strong odor such as sh.
 Otherwise, the lifetime of the deodorization lter may be signicantly decreased and the deodorization lter may
become contaminated by the odor.
 When the integrated HEPA/deodorization lter, is contaminated by surrounding odors and the odors can be smelt when
the air purication lter operates, please replace the lter as it has reached its end of life.
Please close the windows and doors when operating the product.
 Otherwise, the air purication performance is degraded.
 The main noxious gas that cannot be removed: Carbon monoxide (CO)
 Concentration level of carbon dioxide may increase if you operate the product for a long time with windows closed.
Therefore, ventilate the room regularly between use. When lter is saturated with just a weak odor, ventilating the room
will help get rid of saturated odor.
ENGLISH-10
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 10 2015-08-03 오전 9:26:21

Using the lters
 Before you use the product for the rst time, remove the plastic packaging from the integrated HEPA/deodorization lter.
 If you operate the air purier without the lters, you cannot expect any air purication eect.
 If the lter clean/replacement indicator ( ) is turned on, clean the Pre lter.
 If the lter clean/replacement indicator ( ) blinks, replace the integrated HEPA/deodorization lter.
(The integrated HEPA/deodorization lter removes ne, invisible particles, gas and odor particles from the air. Postponing
the lter replacement on the basis of a visual evaluation is not a desirable plan. The lter replacement cycle is the
maximum usage period of the lter. The actual replacement cycle may vary depending on the operating environment.)
 If a strange odor is coming from the product, the airow from the product becomes weak or the recommended
replacement cycle is reached, make sure to replace the integrated HEPA/deodorization lter.
 Cleaning the Pre lter frequently improves the performance of the air purier and helps keep the indoor air clean.
 For the installation order and how to install the lters, refer to the Replacing the lters section in the Cleaning and
Maintenance chapter.
 Before replacing the lters, make sure to turn o the power.
Removing the back cover of the product
Hold the left and right edges of the back cover, pull it forward slightly
(①) and then lift it up (②) to separate it.
Dust sensor
Odor sensor ①
②
Mounting the back cover of the product
Insert the hooks of the back cover into the
grooves at the bottom of the main body
(①) and press the edges of the back cover
so that it ts into 8 holes (②) of the main
body.
 If the hooks of the back cover is not
properly locked into the grooves, back
cover can not be assembled properly. ①
②
Back
cover
Specications
Model AX041HCVAUW series AX022HCVAND series
Dimensions (Width × Height × Depth) 362 mm X 478 mm X 213 mm 362 mm X 478 mm X 163 mm
Standard capacity 41 m222 m2
❋ The design and specications of the product are subject to change without notice for product improvement purposes.
ENGLISH-11
01 PREPARATION
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 11 2015-08-03 오전 9:26:22

Check the name of the components
Air Purier
AX041HCVAUW series
Front view
Rear view
Back cover
Dust sensor
Detects dust.
Odor sensor
Detects odors.
Air outlet
Output of puried air
Buttons and indicators
Air intake
Draws air into
the intake
The mounting sequence of the lters and the back cover
HEPA lter Deodorization
lter Pre lter Back cover
❋ Integrated HEPA/
deodorization lter
ENGLISH-12
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 12 2015-08-03 오전 9:26:22

AX022HCVAND series
Front view
Air outlet
Output of puried air
Buttons and indicators
Air intake
Draws air into
the intake
Rear view
Back cover
Dust sensor
Detects dust.
Odor sensor
Detects odors.
The mounting sequence of the lters and the back cover
HEPA lter Deodorization
lter Pre lter Back cover
❋ Integrated HEPA/
deodorization lter
ENGLISH-13
01 PREPARATION
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 13 2015-08-03 오전 9:26:23

Check the name of the components
Buttons on the control panel
Control panel
Cleanness indicator
Shows the current cleanness of the air.
Button lock
indicator
Filter clean/replacement indicator
Function indicators
Auto mode
indicator
Strong mode indicator
Weak mode indicator
Sleep mode indicator
Control panel buttons
Start/Stop button To turn the air purier on or o.
Mode button To select Auto, Strong, Weak or Sleep mode.
Filter reset button To reset the lter cleaning or replacement alarm
Lock button To set or release the button lock.
• Press the [ ] button on the control panel to start the operation. The indicators show the current operating
mode with the status.
• If you press a button, the corresponding indicator turns on with a ringing sound, indicating that the selected
function is selected.
NOTE
Cleanness indicator
• Shows the current cleanness of the air through the dust and odor sensors.
• The cleanness indicator operation
(Polluted) Red Orange Yellow Green Blue (Clean)
• Status of the cleanness indicator may change often or may not change for long time depending on the
surrounding environment. There is no problem with the product.
NOTE
ENGLISH-14
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 14 2015-08-03 오전 9:26:23

BASIC FUNCTION
Air purication operation
1 2
1 Press the button to start the air purier operation.
 The air purier turns on with a ringing sound.
 When the product turns on for the rst time, it starts operating in air purication mode (airow speed: Weak).
 If the power [ ] is turned o and then on again, the product operates base on the last settings.
 The cleanness indicator and the selected function indicator are selected.
2 Press the button to select an operating mode.
 Whenever this button is pressed, the mode changes in the following order: Weak Sleep Auto Strong.
 The cleanness indicator remains the same and the selected operating mode is turned on.
 When the unit is running in Auto mode, the air is automatically kept clean by the air purier regardless of the surrounding
dust and odors.
 If Sleep mode is selected, only the Sleep mode indicator is turned on (dimly).
Pre lter cleaning alarm function
If the lter clean/replacement indicator is turned on while the air purier is operating, clean the Pre lter and press and
hold the [ ] button for 3 seconds to reset the alarm.
• Once the lter clean/replacement indicator is turned on, it remains on until you press and hold the [ ] button
for 3seconds (until hearing a ringing sound) to reset the alarm.
NOTE
ENGLISH-15
02 BASIC FUNCTION
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 15 2015-08-03 오전 9:26:24

Integrated HEPA/deodorization lter replacement alarm function
If the lter clean/replacement indicator blinks while using the air purier, replace the integrated HEPA/deodorization
lter and hold the [ ] button for 3 seconds or longer to reset the alarm.
• Once the lter clean/replacement indicator is turned on, it remains on until you press and hold the [ ] button
for 3seconds (until hearing a ringing sound) to reset the alarm.
• If you change the lter due to a strange odor before the lter clean/replacement indicator blink, press and hold
the [ ] button for 3seconds (until hearing a ringing sound) to reset the alarm.
NOTE
Button lock function
This function prevents the button being pressed by mistake or by children.
The [ ] button locks the buttons.
 The [ ] button locks the buttons with a ringing sound when it is pressed for 3 seconds or longer.
 When the button lock function is selected, none of the buttons work.
 To unlock the buttons, press and hold the [ ] button for 3 seconds or longer again. The buttons are unlocked with a
ringing sound.
Sleep mode
This mode allows users to sleep comfortably in a pleasant, peaceful environment.
When the air purier is working, press the [ ] button to set Sleep mode.
 Whenever this button is pressed, the mode changes in the following order: Weak Sleep Auto Strong.
 The cleanness indicator is turned o and only the Sleep mode indicator is turned on dimly.
ENGLISH-16
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 16 2015-08-03 오전 9:26:24

Cleaning and maintenance
• Once the lter cleaning or replacement indicator is turned on, it remains on unless you press and hold
the [ ] button for 3 seconds (until hearing a ringing sound) to reset the alarm.
NOTE
Cleaning the exterior
 Dip a towel in warm water and wring it out before using it to clean the product.
 Use a cotton swab to remove dust in the grooves of the exterior panel.
• Do not wipe the control panel with an alkali detergent.
• Do not clean the surface of the air purier with sulfuric acid,
hydrochloric acid or organic solvent (thinner, kerosene, acetone,
etc.), or attach a sticker to the unit. This may damage the surface
of the product.
NOTE
Storing the product
 If the product is not going to be used for an extended period of time, put it into a box and store it in a dry, indoor site.
OTHERS
ENGLISH-17
03 OTHERS
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 17 2015-08-03 오전 9:26:24

Cleaning and maintenance
Cleaning the sensor
When the air purier is not operating, hold the left
and right edges of the back cover, pull it forward
slightly (①)and then lift it up (②)to separate it.
Carefully clean the lens and the odor sensor with a
cotton swap.
Dust sensor
Odor sensor
Insert the hooks of the back cover into the grooves at the bottom of the main body (①) and press the edges of the
back cover so that it ts into 8holes(②).
①
②
Dust sensor
lens
Odor
sensor
Back cover
②
①
• Do not clean the sensors using volatile substances (alcohol, acetone, etc.). Use only water.
• If the dust sensor lens or the odor sensor is contaminated by a foreign substance (dust), the cleanness indicator
of the air purier may be stuck in the polluted state. In this case, clean the sensors.
• Clean the sensors at least once every 6 months. However, cleaning period should be dierent depending on the
operating environment and the operating time. Therefore cleaning should be more often in places with lots of
dusts.
• Cleanness indicator on the control panel may not change from polluted state when the air purier is operating
in place with heavy dusts or smells that may be beyond its capability. (In this case, open the window to ventilate,
or use the air purier with appropriate capacity.)
• Do not use any spray type product near the air purier.
• Turn o the power when cleaning the sensors. If you clean the sensors while the power is on, misdetection may
occur from the sensor and the cleanness indicator may not work properly.
CAUTION
ENGLISH-18
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 18 2015-08-03 오전 9:26:25

Cleaning the Pre lter
 If the lter clean/replacement indicator ( ) is turned on, clean the Pre lter.
Clean the Pre lter under running water.
• If the lter is very dirty, clean the lter with a
warm neutral detergent solution.
Dry the lter completely in the shade.
• When you dry the Pre lter, do not dry it under
direct sunlight.
Pull the back cover forward by holding the left and
right edges of the cover. Remove the Pre lter by
pressing down the top clip of the lter with your nger.
Fit the Pre lter into the bottom holes and
then insert the top clip.
• Clean the Pre lter at least once every two weeks.
However, since the cleaning cycle is determined
by the operating environment and the operating
period, clean the lter more frequently when the
air purier is operating in a dusty environment.
• When the lter is heavily contaminated with
dust, it is advisable to clean the dust rst with a
vacuum cleaner followed by water.
NOTE
Insert the hooks of the back cover into the grooves
at the bottom of the main body (①) and press
the edges of the back cover so that it ts into
8holes(②).
Back
cover
②
①
ENGLISH-19
03 OTHERS
ACR_JUPITER-SI_MS_IB_04616A-02_EN.indd 19 2015-08-03 오전 9:26:26
