Samsung AX34R3020WW User manual

Air purier
User manual
AX34R3020WW
ꞏ Thank you for purchasing this Samsung air purier.
ꞏBefore operating this unit, please read this user manual carefully and retain it for future reference.

2
Directory
Safety Precautions 3
Conrmations before use 9
Accessories / Product specication 9
Checking the air purier 10
Main body 10
Display and buttons 11
Disassembling the lter 12
Assembling the lter 13
Using the air purier 15
Turning the power on/off / Fan speed / Sleep mode / Filter reset function / 15
Lock function / Checking the air cleanness 16
Cleaning and maintenance 17
Clean and dry pre lter / 17
Cleaning the exterior of the air purier / Cleaning the sensors 18
Cleaning the air outlet / Grille removal and assembling 19
Others 20
Troubleshooting 20
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories
(e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of
their working life. To prevent possible harm to the environment or human health from uncontrolled waste
disposal, please separate these items from other types of waste and recycle them responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local
government ofce, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product and its electronic accessories should not be mixed with other commercial wastes for disposal.
For information on Samsung’s environmental commitments and product-specic regulatory obligations,
e.g. REACH, WEEE, Batteries, visit: www.samsung.com/uk/aboutsamsung/sustainability/environment/our-
commitment/data/

3
Safety Precautions
Safety Precautions
Safety Precautions
These safety precautions are for owner’s safety and preventions of property
damage. Therefore, please read this manual thoroughly before using your
product.
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property
damage.
Follow directions.
Do NOT attempt.
Unplug the power plug from the wall socket.
Do NOT disassemble.
FOR INSTALLATION
WARNING
Plug the power cord into a wall
socket with the power specications
of the product or higher and use the
socket for this appliance only. Also,
do not extend the power cord on
your own.
·Sharing a wall socket with other
appliances using a multi outlet power
strip or extending the power cord may
result in electric shock or re.
·Do not use an electric transformer. It
may result in electric shock or re.
·If the voltage/frequency/rated current
condition is different, it may cause
electric shock or re.
Do not install this appliance near a heater, inammable material. Do
not install this appliance in a humid, oily or dusty location, in a location
exposed to direct sunlight and water (rain drops). Do not install this
appliance in a location where gas may leak.
·Failure to do so may result in electric shock or re.

4
Safety Precautions
CAUTION
The appliance should be installed in a place where the power cord of the
product can be easily pulled out.
·Failure to do so may result in electric shock or re due to electric leakage.
Install your appliance on a level and hard oor that can support its weight.
·Failure to do so may result in abnormal vibrations, noise, or problems
with the product.
When installing the appliance, allow
enough space around the appliance.
·Space between both sides of the
product and the wall: At least 60
cm or more, Space in front of the
product: 25 cm or more
·If enough space for air intake is not
provided, purifying capacity may
deteriorate.
·Make sure obstacles such as a
curtain do not block air inlet or
outlet of the appliance.
When installing the product, make sure that no heavy objects are on the
power cord (or cable).
·Failure to do so may result in electric shock or re.
For power supply
WARNING
Remove all foreign substances such as dust or water from the power plug
terminals and contact points using a dry cloth on a regular basis.
·Failure to do so may result in electric shock or re.
When plugging in the appliance, the power plug should face downward.
·If the power plug faces in the opposite direction, the electric wires within
the cable may be damaged and this may result in electric shock or re.
When the product, power plug or power cord is damaged, contact your
nearest service center.
If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualied persons in order to avoid a hazard.
These instructions shall also be available in an alternative format, e.g. on a
website.
Safety Precautions

5
Safety Precautions
Plug the power plug into the wall socket rmly. Do not use a damaged
power plug, damaged power cord or loose wall socket.
·Failure to do so may result in electric shock or re.
When unplugging the product, do not pull the power cord. Grip the power
plug, and then pull the power plug.
·Failure to do so may result in electric shock or re.
Do not pull or excessively bend
the power cord. Do not twist or tie
the power cord. Do not hook the
power line over a metal object,
place a heavy object on the power
cord, insert the power line between
objects, or push the power cord into
the space behind the appliance.
·This may result in electric shock or
re.
CAUTION
When the air purier will not be used for a long period of time or during a
thunder or lightning storm, disconnect the power supply.
·Failure to do so may result in electric shock or re.
It is dangerous when the power cable gets damaged, therefore contact a
service center or qualied experts for the repair.
Before cleaning or repairing the appliance, unplug the appliance.
For operation
WARNING
If the appliance is ooded, turn off the appliance and contact a service
center.
·Failure to do so may result in electric shock or re.
If the appliance generates a strange noise, a burning smell or smoke,
disconnect the power supply immediately and contact a service center.
·Failure to do so may result in electric shock or re.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate
immediately without touching the appliance or power cord and contact a
service center or a qualied technician.
·Do not use a ventilating fan.
·If there is a spark, explosion or re may occur.

6
Safety Precautions
Do not unplug the appliance during operation.
·When plugging the appliance in again, ame may occur and it may result
in electric shock or re.
When a repair is needed, contact the service center.
·Failure to do so may result in a product malfunction, water leakage,
electric shock or re.
Do not touch the power plug with
wet hands.
·This may result in electric shock.
Do not apply a force to or pull the
product using excessive force.
·This may result in re, injury, or a
problem with the product.
After unpacking the air purier, keep all packaging materials out of the
reach of children.
·If a child places a bag over its head, it may suffocate.
Do not insert your ngers or a foreign substances into the air outlet while
product is operating.
·Take special care that children do not injure themselves by inserting their
ngers into the product.
Safety Precautions

7
Safety Precautions
Do not place an object near the
product that makes it possible for
children to climb onto the machine.
·The child could fall and injure
themselves or the product may fall
over and injure the child.
If water has entered the power supply module, unplug the power cable and
dry the product completely before use.
·Failure to do so may result in electric shock or re.
Do not put other foreign materials such as metal into the product.
·This may result in electric shock or injury.
Do not place heavy objects on the product.
·Failure to do so may result in a product malfunction or noise.
If a foreign substance such as water has entered the product, disconnect
the power supply and contact the service center.
·Failure to do so may result in electric shock or re.
Do not attempt to repair, disassemble, or modify the product yourself.
·Do not use a fuse (such as copper, steel wire, etc.) other than a standard
fuse.
·Failure to do so may result in electric shock, re, a product malfunction or
injury.
CAUTION
Keep a distance of about 2 m from other electric appliances such as a TV,
video or audio device etc.
·Failure to do so may result in reduced video quality or noise.
Leave enough space between the product and a wall.
·Space between both sides of the product and the wall: At least 60 cm or
more, Space in front of the product: 25 cm or more
·This products is designed to take the room air from the front side of the
product for purifying process. Therefore, make sure there is no obstacles
in front of the product and near air intake and outlet.
Do not stand on top of the product or place objects (such as laundry, lighted
candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the
product.
·This may result in electric shock, re, a product malfunction or injury.

8
Safety Precautions
Do not tilt or turn the product upside down while the product is connected
to the wall outlet.
·Failure to do so may result in a malfunction or re.
Do not spray volatile material such as insecticide onto the product.
·As well as being harmful to humans, this may also result in electric shock,
re or a product malfunction.
Do not put the product into water.
·This may result in a product malfunction.
Do not operate the product with wet hands.
·This may result in electric shock.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
For use in Europe: This appliance can be used by children aged from 8
years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by children
without supervision.
For cleaning
WARNING
Do not clean the product by spraying water directly onto it. Do not use
benzene, thinner, acetone or alcohol to clean the product.
·This may result in discoloration, deformation, damage, electric shock or
re.
Disconnect the power supply and stop the fan operation before cleaning
the product.
·Potential risk of electric shock or re.
CAUTION
Unplug the power plug before cleaning the product.
Safety Precautions
Safety Precautions

9
Conrmations before use
Conrmations before use
Accessories
Pre lter 1EA
2-in-1 lter 1EA
(Deodorization Filter+Dust
Collecting Filter)
User manual 1 EA
Product specication
Dimension of the product is based on maximum value of the measurement.
Measurement may vary depending on the side.
For product improvement purposes, design and specications of the product are
subject to change without prior notice.
Model & Name AX34R3020WW
Product dimension (W*H*D) 350 mm*540 mm*350 mm
Effective area 34 m²
Conrmations before use

10
Checking the air purier
Main body
Checking the air purier
01 Air outlet
02 Display and buttons
03 Air inlet/ front panel
04 Handle (at the rear side)
05 Dust sensor
06 Gas sensor
07 2-in-1 lter (Deodorization
Filter+Dust Collecting Filter)
08 Pre lter
Check air purier
Dust
07
08
01
02
05
06
04
03
