Samsung AC BN DCH Series User manual

Airconditioner
Installation manual
AC***BN*DCH
• Thank you for purchasing this Samsung air conditioner.
• Before operating this unit, please read this manual carefully and retain it for future reference.

2English
Contents
Safety Information 3
Installation Procedure 5
Step 1 Checking and preparing accessories 5
Step 2 Choosing the installation location 5
Step 3 Optional: Insulating the body of the indoor unit 12
Step 4 Installing the indoor unit 12
Step 5 Purging inert gas from the indoor unit 14
Step 6 Cutting and flaring the pipes 14
Step 7 Connecting the assembly pipes to the refrigerant pipes 15
Step 8 Performing the gas leak test 16
Step 9 Insulating the refrigerant pipes 17
Step 10 Installing the drain hose and drain pipe 19
Step 11 Performing the drainage test 20
Step 12 Optional: Installing external controller 21
Step 13 Connecting the power and communication cables 21
Step 14 Optional: Extending the power cable 23
Step 15 Setting additional functions of wired remote control 24
Step 16 Optional : Setting the Emergency Temperature Output (ETO) function 28
Step 17 Setting the indoor unit option code with wired remote controller 30
Step 18 Setting indoor unit addresses and installation options with wired remote controller 30
Step 19 Optional :Setting the indoor unit addresses and the installation options with wireless remote controller32
Appendix 42
Troubleshooting 42
IMPORTANT
ࣞƟ˵ϑΧθͱʒЇʀϩ˵ɇϑɵʪʪʒʪϑ˝ʪʒɇʒɇЇ˙ɇʀϩЇθʪʒϩͱʪʪϩkĘkŵǽƊƟŵʀθϩʪθɇ˙ͱθʪʪθ˝цʪ˙ѣʀʪʀци˵ʪɇϩʀ˵ʪʒиϩ˵
ɇΧΧθͱΧθɇϩʪʀͱʀͱΧͱʪϩϑ࢒²ͱиʪЭʪθࡨΧθͱΧʪθθʪ˙θ˝ʪθɇϩʀ˵ɇθ˝ʪɇʒΧθͱΧʪθɇθѤͱиɇθʪʀθϩʀɇϩͱɇʀ˵ʪЭʪθɇϩʪʒʀɇΧɇʀϩцɇʒ
ʪ˙ѣʀʪʀц࢒Ãϑϩɇɇϩͱͱ˙ϩ˵ϑΧθͱʒЇʀϩϑ˵ͱЇʒ˙ͱͱиϩ˵ʪɇЇ˙ɇʀϩЇθʪθࣴϑθʪ˙θ˝ʪθɇϩʀ˵ɇθ˝˝ɇʒɇθѤͱиϑϩθЇʀϩͱϑ࢒ɇЇθʪ
ϩͱʀͱѣθΧθͱΧʪθʀ˵ɇθ˝ʪɇʒɇθѤͱиɇцθʪʒЇʀʪʪʪθ˝цʪ˙ѣʀʪʀцɇʒϑ˵ͱθϩʪʪαЇΧʪϩ˙ʪ࢒

3
English
Safety Information
California Proposition 65 Warning (US)
WARNING
Cancer and Reproductive Harm - www.P65Warnings.
ca.gov.
WARNING
• Hazards or unsafe practices that may result in severe
personal injury or death.
CAUTION
• Hazards or unsafe practices that may result in minor
personal injury or property damage.
• Carefully follow the precautions listed below because
they are essential to guarantee the safety of the
ʪαЇΧʪϩ࢒
WARNING
• Always disconnect the air conditioner from the power
supply before servicing it or accessing its internal
components.
• Verify that installation and testing operations are
Χʪθ˙ͱθʪʒɵцαЇɇ˙ʪʒΧʪθϑͱʪ࢒
• Verify that the air conditioner is not installed in an
easily accessible area.
General information
WARNING
• Carefully read the content of this manual before installing
the air conditioner and store the manual in a safe place in
order to be able to use it as reference after installation.
• ͱθɇуЇϑɇ˙ʪϩцࡨϑϩɇʪθϑϑ˵ͱЇʒɇиɇцϑʀɇθʪ˙Їцθʪɇʒ
the following warnings.
• Store the operation and installation manual in a safe location
and remember to hand it over to the new owner if the air
conditioner is sold or transferred.
• This manual explains how to install an indoor unit with a split
system with two SAMSUNG units. The use of other types
of units with different control systems may damage the
units and invalidate the warranty. The manufacturer shall
not be responsible for damages arising from the use of non
compliant units.
• The manufacturer shall not be responsible for damage
originating from unauthorized changes or the improper
ʀͱʪʀϩͱͱ˙ʪʪʀϩθʀɇʒθʪαЇθʪʪϩϑϑʪϩ˙ͱθϩ˵ϩ˵ʪ
“Operating limits” table, included in the manual, shall
immediately invalidate the warranty.
• The air conditioner should be used only for the applications
forwhich it has been designed: the indoor unit is not suitable
to be installed in areas used for laundry.
• Do not use the units if damaged. If problems occur, switch the
unit off and disconnect it from the power supply.
• In order to prevent electric shocks, fires or injuries, always
stop the unit, disable the protection switch and contact
ƊđƊƸĘࣴϑϩʪʀ˵ʀɇϑЇΧΧͱθϩ˙ϩ˵ʪЇϩΧθͱʒЇʀʪϑϑͱʪࡨ˙
the power cable is hot or damaged or if the unit is very noisy.
• Always remember to inspect the unit, electric connections,
refrigerant tubes and protections regularly. These operations
ϑ˵ͱЇʒɵʪΧʪθ˙ͱθʪʒɵцαЇɇ˙ʪʒΧʪθϑͱʪͱц࢒
• The unit contains moving parts, which should always be kept
out of the reach of children.
• Do not attempt to repair, move, alter or reinstall the unit. If
performed by unauthorized personnel, these operations may
cause electric shocks or fires.
• UͱͱϩΧɇʀʪʀͱϩɇʪθϑиϩ˵αЇʒϑͱθͱϩ˵ʪθͱɵʪʀϩϑͱϩ˵ʪ
unit.
• All the materials used for the manufacture and packaging of
the air conditioner are recyclable.
• The packing material and exhaust batteries of the remote
controller(optional) must be disposed of in accordance with
current laws.
• The air conditioner contains a refrigerant that has to be
disposed of as special waste. At the end of its life cycle, the
air conditioner must be disposed of in authorised centres or
returned to the retailer so that it can be disposed of correctly
and safely.
• ǮʪɇθΧθͱϩʪʀϩЭʪʪαЇΧʪϩࣔϑЇʀ˵ɇϑϑɇ˙ʪϩц˝ͱЭʪϑࡨ˝ͱ˝˝ʪϑࡨ
and headgear) during installation and maintenance works.
Installation/repair technicians may be injured if protective
ʪαЇΧʪϩϑͱϩΧθͱΧʪθцʪαЇΧΧʪʒ࢒
Installing the unit
WARNING
IMPORTANT: When installing the unit, always remember
to connect first the refrigerant tubes, then the electrical
lines.
• Always disassemble the electric lines before the
refrigerant tubes.
• Upon receipt, inspect the product to verify that
it has not been damaged during transport. If the
product appears damaged, DO NOT INSTALL it and
immediately report the damage to the carrier or
retailer (if the installer or the authorized technician has
collected the material from the retailer.)
Safety Information

4English
Safety Information
Safety Information
• After completing the installation, always carry out a
functional test and provide the instructions on how to
operate the air conditioner to the user.
• Do not use the air conditioner in environments with
˵ɇіɇθʒͱЇϑϑЇɵϑϩɇʀʪϑͱθʀͱϑʪϩͱʪαЇΧʪϩϩ˵ɇϩ
release free flames to avoid the occurrence of fires,
explosions or injuries.
• Excessive indoor humidity or clogged condensate
drain lines may cause water to drip from indoor units.
Do not install the indoor unit where dripping could
result in damage to property, such as above electronic
ʪαЇΧʪϩͱθͱϩ˵ʪθϑʪϑϩЭʪϑϩθЇʪϩϑ
• Our units should be installed in compliance with the
spaces shown in the installation manual, to ensure
accessibility from both sides and allow repairs or
maintenance operations to be carried out. The
ЇϩࣴϑʀͱΧͱʪϩϑϑ˵ͱЇʒɵʪɇʀʀʪϑϑɵʪɇʒʪɇϑцϩͱ
disassemble without endangering people and objects.
ͱθϩ˵ϑθʪɇϑͱࡨи˵ʪΧθͱЭϑͱϑͱ˙ϩ˵ʪϑϩɇɇϩͱ
ɇЇɇɇθʪͱϩʀͱΧʪʒиϩ˵ࡨϩ˵ʪʀͱϑϩθʪαЇθʪʒϩͱ
ɇʀʀʪϑϑɇʒθʪΧɇθϩ˵ʪЇϩϑࣔƊkƟǽAĮĘUÃƟÃĮĘƊࡨ
as set out in prevailing regulations) with harnesses,
ladders, scaffolding or any other elevation system will
NOT be considered part of the warranty and will be
charged to the end customer.
• Auxiliary devices which may be a potential ignition
source shall not be installed in the duct work.
• The air conditioner contains a refrigerant that has
to be disposed of as special waste. At the end of its
life cycle, the air conditioner must be disposed of in
authorized centers or returned to the retailer so that it
can be disposed of correctly and safely.
• AC***BNLDCH indoor unit is intended for free-air
discharge or for connection to a duct supplying only
one room. Improper installation could contribute to
the spread of smoke or flame in the event of a fire.
Powersupply line, fuse or circuit
breaker
WARNING
• Always make sure that the power supply is compliant
with current safety standards. Always install the air
conditioner in compliance with current local safety
standards.
• Always verify that a suitable grounding connection is
available.
• Ǥʪθ˙цϩ˵ɇϩϩ˵ʪЭͱϩɇ˝ʪɇʒ˙θʪαЇʪʀцͱ˙ϩ˵ʪΧͱиʪθ
supply comply with the specifications and that the
installed power is sufficient to ensure the operation of
any other domestic appliance connected to the same
electric lines.
• Always verify that the cut-off and protection switches
are suitably dimensioned.
• Verify that the air conditioner is connected to the
power supply in accordance with the instructions
provided in the wiring diagram included in the manual.
• Always verify that electric connections (cable entry,
section of leads, protections…) are compliant with
the electric specifications and with the instructions
provided in the wiring scheme. Always verify that all
connections comply with the standards applicable to
the installation of air conditioners.
• Devices disconnected from the power supply should
be completely disconnected in the condition of
overvoltage category.
• Be sure not to perform power cable modification,
extension wiring, and multiple wire connection.
– It may cause electric shock or fire due to poor
connection, poor insulation, or current limit override.
– Ǯ˵ʪʪуϩʪϑͱиθ˝ϑθʪαЇθʪʒʒЇʪϩͱΧͱиʪθʪ
damage, refer to "Step 14 Optional: Extending the
power cable" in the installation manual.
CAUTION
Make sure that you earth the cables.
• Do not connect the earth wire to the gas pipe, water
pipe, lighting rod or telephone wire. If earthing is not
complete, electric shock or fire may occur.
Install the circuit breaker.
• If the circuit breaker is not installed, electric shock or
fire may occur.
Make sure that the condensed waterdripping from the
drain hose runs out properly and safely.
Install the powercable and communication cable of
the indoor and outdoor unit at least1m away from the
electric appliance.
Install the indoor unit away from lighting apparatus
using the ballast.
• If you use the wireless remote control, reception error
may occur due to the ballast of the lighting apparatus.
Do not use the indoorunit forpreservation of food
items, plants, equipment, and art works. This may cause
deterioration of theirquality.
Do not install the indoorunit if it has any drainage
problem.

5
Installation Procedure
English
Installation Procedure
Step1 Checking and preparing
accessories
The following accessories are supplied with the indoor unit. The
ϩцΧʪɇʒαЇɇϩϩцɇцʒ˙˙ʪθࡨʒʪΧʪʒ˝ͱϩ˵ʪϑΧʪʀ˙ʀɇϩͱϑ࢒
User manual (1) Installation manual (1)
Clamp hose (1) Flexible hose (1)
Insulation drain (1) Thermal insulation
sponge A (1)
Cable-tie
(AC***BNLDCH : 4EA,
AC***BNHDCH : 8EA)
Thermal insulation
sponge B (1)
Rubber (4) Thermal insulation
sponge C (1)
Reducer(1)
Step 2 Choosing the installation location
Installation location requirements
• There must be no obstacles near the air inlet and outlet.
• Install the indoor unit on a ceiling that can support its weight.
• Maintain sufficient clearance around the indoor unit.
• Before installing the indoor unit, be sure to check whether
the chosen location is well-drained.
• The indoor unit must be installed such that it is beyond public
access and is not touchable by users.
CAUTION
Do not install the airconditioner in following places.
• The place where there is mineral oil or arsenic acid. Resin
parts flame and the accessories may drop or water may leak.
The capacity of the heat exchanger may reduce or the air
conditioner may be out of order.
• The place where corrosive gas such as sulfurous acid gas
generates from the vent pipe or air outlet. The copper pipe or
connection pipe may corrode and refrigerant may leak.
• The place where there is a machine that generates
electromagnetic waves. The air conditioner may not operate
normally due to control system.
• The place where there is a danger of existing combustible
gas, carbon fiber or flammable dust.
• The place where thinner or gasoline is handled. Gas may leak
and it may cause fire.

6
Installation Procedure
Installation Procedure
English
Spacing requirements
ƊΧɇʀʪθʪαЇθʪʪϩϑ˙ͱθϑϩɇɇϩͱইϑʪθЭʀʪ࢒
Construction Standard for Inspection opening
ϑΧʪʀϩͱͱΧʪ˝ϑθʪαЇθʪʒ˙ͱθϑʪθЭʀʪɇʒЇϩθʪΧɇʀʪʪϩ࢒
ߛࣕÃ˙ϩ˵ʪʀʪ˝ϑɇ˝θʒϩцΧʪࡨɇϑΧʪʀϩͱͱΧʪ˝ϑͱϩθʪαЇθʪʒ࢒
ߜࣕÃ˙ϩ˵ʪʀʪ˝ϑΧɇϑϩʪθɵͱɇθʒࡨɇϑΧʪʀϩͱͱΧʪ˝ϑθʪαЇθʪʒ࢒Ɵ˵ʪϑіʪͱ˙ϩ˵ʪͱΧʪ˝иЭɇθцɵɇϑʪʒͱϩ˵ʪ˵ʪ˝˵ϩϑʒʪϩ˵ʪ
ceiling.
a. Height is more than 1.64ft (0.5m): Only “B” [Inspection for PBA] is applied.
ɵ࢒²ʪ˝˵ϩϑʪϑϑϩ˵ɇߛ࢒ߠߞ˙ϩࣔߚ࢒ߟࣕࡧ9ͱϩ˵࣯ࣰইࣰ9ࣰɇθʪɇΧΧʪʒ࢒
ʀ࢒࣯ࣰইࣰ9ࣰɇθʪϑΧʪʀϩͱͱΧʪ˝࢒
0.79 inch (20 mm) or more
Unit Width(W)
"A"=W+3.94 inch (100 mm)
Unit Depth(D)
"B"=19.69 inch (500 mm)
0.79 inch (20 mm) or more
• You must have 0.79 inch (20 mm) or more space between the ceiling and the bottom of indoor unit to prevent transmission of noise and
vibration from the unit into the space.
• It is possible to install the unit at an height of between 7.2~8.2 ft (2.2~2.5m ) from the ground,
if the unit has a duct with a well defined
lenght [11.81inch (300 mm) or more], to avoid fan motor blower contact.
• If you install the cassette or duct type indoor unit on the ceiling with humidity over 80%, you must apply extra 0.39 inch (10mm) of
polyethylene foam or other insulation with similar material on the body of the indoor unit.

7
Installation Procedure
English
AC009BNLDCH/AC012BNLDCH
No. Name Description
01 øαЇʒΧΧʪʀͱʪʀϩͱ Ø1/4 inch ( 6.35 mm )
02 Gas pipe connection Ø3/8 inch (9.52mm)
03 Drain pipe connection 3/4 inch (OD 1.05 inch (26.67 mm ))
04 Power supply connection
05 Air discharge flange
06 Suction flange Air filter
07 Hook M8~M10
30.16(766)
20-Ø0.14(3.5)
4.96(126) 1.38(35) 5.75(146) 6.10(155) 5 .12(130) 1.38(35) 5.47(139)
37.21(945)
0.79(20)
0.51(13)
0.31(7.8)
7.82(199)
2.80(71) 3.94(100)
1.30(33) 10.83(275) 6.93(176) 10.83(275)
30.63(778)
31.73(806)
17.32(440)
12.45(316)
7X3.94=27.56 (7X100=700)
29.32(742)
35.43(900)
0.90(22.9)
5.89(150) 0.73(19)
3.94(100)
0.79(20)
17.32(440)
35.43(900)
39.37(1000)
19.69(500)
07
06
04
02 01 03
05
Unit : inch(mm)
(Air around)
(Air outlet duct flange)
(Suspension position)
Discharge side Suction side
(Suspension position)
Inspection hole

8
Installation Procedure
Installation Procedure
English
Unit : inch(mm)
AC018BNLDCH
38.03(966)
8.58(218) 1.38(35) 2.76(70) 12.72(323) 2.83(72) 1.38(35) 8.39(213)
10.83(275) 10.83(275)
10.83(275)
5.12(130)
38.50(978)
39.61(1006)
45.08(1145)
0.79(20)
0.51(13)
0.31(7.8)
7.82(199)
2.80(71) 3.94(100)
0.33(8.3)
17.32(440)
12..44(316)
17.32(440)
43.31(1100)
43.31(1100)
47.24(1200)
37.09(942)
9x3.94=35.43(9x100=900)
24-Ø0.14(3.5)
3.94(100)
0.75(19)5.91(150)
0.90(22.9)
19.69(500)
07
04
06
05
02 01 03
(Air outlet duct flange)
(Suspension position)
Discharge side Suction side
(Suspension position)
inspection hole
(Air around)
No. Name Description
01 øαЇʒΧΧʪʀͱʪʀϩͱ Ø1/4 inch (6.35 mm)
02 Gas pipe connection Ø1/2 inch (12.70 mm)
03 Drain pipe connection 3/4 inch (OD 1.05 inch (26.67 mm ))
04 Power supply connection
05 Air discharge flange
06 Suction flange Air filter
07 Hook M8~M10

9
Installation Procedure
English
Unit : inch(mm)
AC009BNHDCH/AC012BNHDCH
No. Name Description
01 øαЇʒΧΧʪʀͱʪʀϩͱ Ø1/4 inch (6.35 mm)
02 Gas pipe connection Ø3/8 inch (9.52 mm)
03 Drain pipe connection 3/4 inch (OD 1.05 inch (26.67 mm ))
04 Power supply connection
05 Air discharge flange
06 Suction flange Air filter
07 Hook M8~M10
7. 2 8 ( 1 8 5 )
6.22(158)
5.75(146)
27.56(700)
7x3.94=27.56(7x100=700)
32.17(817)
33.46(850)
22-Ø0.13(3.2)
35.43(900)
23.78(604)
27.56(700)
19.69(500)
33.46(850)
37.40(950)
8.66(220)
2x3.54=7.09(2x90=180)
9.84(250)
8.39(213)
4.92(125)
13.39(340)
07
06
05
02 01
03 04
Inspection hole
(Air outlet duct flange)
(Suspension position)
Discharge side Suction side
(Air around)
(Suspension position)
hole

10
Installation Procedure
Installation Procedure
English
7. 2 8 ( 1 8 5 )
6.22(158)
5.83(148)
27.56(700)
23.78(604)
11x3.94=43.31(11x100=1100)
45.94(1167)
47.24(1200)
30-Ø0.13(3.2)
49.21(1250)
27.56(700)
19.69(500)
47.24(1200)
51.18(1300)
8.66(220)
2x3.54=7.09(2x90=180)
9.84(250)
8.39(213)
4.92(125)
13.39(340)
07
06
05
02 01
03 04
Inspection hole
(Air outlet duct flange)
(Suspension position)
Discharge side Suction side
hole
(Suspension position)
Unit : inch(mm)
AC018BNHDCH/ AC024BNHDCH/ AC030BNHDCH
(Air around)
No. Name
Description
AC018BNHDCH AC024BNHDCH AC030BNHDCH
01 øαЇʒΧΧʪʀͱʪʀϩͱ
Ø1/4 inch (6.35 mm) Ø3/8 inch (9.52 mm)
02 Gas pipe connection
Ø1/2 inch (12.70mm) Ø5/8 inch (15.88 mm)
03 Drain pipe connection 3/4 inch (OD 1.05 inch (26.67 mm))
04 Power supply connection
05 Air discharge flange
06 Suction flange
07 Hook M8~M10

11
Installation Procedure
English
Unit : inch(mm)
AC036BNHDCH/AC042BNHDCH/AC048BNHDCH
19.69(500)
51.18(1300)
55.12(1400)
27.56(700)
7.28(185)
6.30(160)
5.75(146)
27.56(700)
23.78(604)
11x3.94=43.31(11x100=1100)
49.92(1268)
51.18(1300)
53.15(1350)
30-Ø0.13(3.2)
10.63(270)
11.81(300)
8.39(213)
4.92(125)
13.39(340)
2x4.53=7.06(2x115=230)
02 01
0403
07
06
05
Inspection hole
(Air outlet duct flange)
(Suspension position)
Discharge side Suction side
hole
(Suspension position)
(Air around)
No. Name Description
01 øαЇʒΧΧʪʀͱʪʀϩͱ Ø3/8 inch (9.52 mm)
02 Gas pipe connection Ø5/8 inch (15.88 mm)
03 Drain pipe connection 3/4 inch (OD 1.05 inch (26.67 mm ))
04 Power supply connection
05 Air discharge flange
06 Suction flange Air filter
07 Hook M8~M10

12
Installation Procedure
Installation Procedure
English
Step 3 Optional: Insulating the body of
the indoorunit "$#%
Thickness: more than 0.39 inch
(
10mm
)
Indoor
Unit
AC009BNLDCH
AC012BNLDCH AC018BNLDCH
35.43X17.32X7.83
(900X440X199)
43.31X17.32X7.83
(1100X440X199)
A
35.43X7.83
(900X199)
43.31X7.83
(1100X199)
B
35.43X7.83
(900X199)
43.31X7.83
(1100X199)
C
17.32X7.83
(440X199)
17.32X7.83
(440X199)
D
17.32X7.83
(440X199)
17.32X7.83
(440X199)
Front/
Back
Insulate the front and back side in proper size at
the same time when insulating the suction duct
and discharge duct.
Unit: inch(mm)
Indoor
Unit
AC009BNHDCH
AC012BNHDCH
AC018BNHDCH
AC024BNHDCH
AC030BNHDCH
AC036BNHDCH
AC042BNHDCH
AC048BNHDCH
33.46X27.56X9.84
(850X700X250)
47.24X27.56X9.84
(1200X700X250)
51.18X27.56X11.81
(1300X700X300)
A33.46X27.56
(850X700)
47.24X27.5
(1200X700)
51.18X27.56
(1300X700)
B33.46X27.56
(850X700)
47.24X27.5
(1200X700)
51.18X27.56
(1300X700)
C27.56X9.84
(700X250)
27.56X9.84
(700X250)
27.56X11.81
(700X300)
D27.56X9.84
(700X250)
27.56X9.84
(700X250)
27.56X11.81
(700X300)
Front/
Back
Insulate the front and back side in proper size at the
same time when insulating the suction duct and
discharge duct.
Unit: inch(mm)
NOTE
• Insulate the end of the pipe and some curved area by using
separate insulator.
• Insulate the discharge and suction part at the same time
when you insulate connection duct.
Step 4 Installing the indoorunit
When deciding on the location of the air conditionerwith the
owner, the following restrictions must be taken into account
1 Place the pattern sheet on the ceiling at the spot where you want
to install the indoor unit.
NOTE
• Since the diagram is made of paper, it may shrink or stretch
ϑ˝˵ϩцʒЇʪϩͱϩʪΧʪθɇϩЇθʪͱθ˵Їʒϩц࢒ͱθϩ˵ϑθʪɇϑͱࡨ
before drilling the holes maintain the correct dimensions
between the markings.
2 Insert bolt anchors. Use existing ceiling supports or construct a
suitable support as shown in figure.
Concrete
Suspension bolt (M8) - field supply
Insert
Hole in anchor
Hole in plug
θͱϩ
Back

13
Installation Procedure
English
3 Install the suspension bolts depending on the ceiling type.
CAUTION
• Ensure that the ceiling is strong enough to support the weight
of the indoor unit. Before hanging the unit, test the strength
of each attached suspension bolt.
• If the length of suspension bolt is more than 4.92 ft
(
1.5m
)
,
ϩϑθʪαЇθʪʒϩͱΧθʪЭʪϩЭɵθɇϩͱ࢒
• If this is not possible, create an opening on the false ceiling in
ͱθʒʪθϩͱɵʪɇɵʪϩͱЇϑʪϩϩͱΧʪθ˙ͱθϩ˵ʪθʪαЇθʪʒͱΧʪθɇϩͱϑ
on the indoor unit.
4 Screw eight nuts to the suspension bolts making space for
hanging the indoor unit.
NOTE
• You must install all the suspension rods.
5 Hang the indoor unit to the suspension bolts between two nuts.
CAUTION
• Piping must be laid and connected inside the ceiling when
suspending the unit. If the ceiling is already constructed,
lay the piping into position for connection to the unit before
placing the unit inside the ceiling.
6 Screw the nuts to suspend the unit.
7 Adjust level of the unit by using measurement plate for all 4
sides.
CAUTION
• ͱθΧθͱΧʪθʒθɇɇ˝ʪͱ˙ʀͱʒʪϑɇϩʪࡨ˝Эʪɇߚ࢒ߛߛߢʀ˵
(
3mm
)
slant to the left or right side of the unit which will be
connected with the drain hose, as shown in the figure. Make a
tilt when you wish to install the drain pump, too.
• When installing the indoor unit, make sure it is not tilted
toward front or b ack side.
CAUTION
• Noise will increase 3~6 dB(A) when the air flow enters from
the bottom side (Only for AC***BNLDCH indoor unit product).
θͱи
When the drain hose is installed to the right.
Drain hose port
0.118inch(3mm)
Ceiling support
Pad stopper
Bracket

14
Installation Procedure
Installation Procedure
English
Step 5 Purging inert gas from the indoor
unit
θͱ˙ɇʀϩͱθцϩ˵ʪЇϩϑϑЇΧΧʪʒɇʒϑʪϩиϩ˵ɇΧθʪࣞʀ˵ɇθ˝ʪͱ˙
nitrogen gas. (inert gas) Therefore, all inert gas must be purged
before connecting the assembly piping.
Unscrew the pinch pipe at the end of each refrigerant pipe.
Result : All inert gas escapes from the indoor unit.
AC***BNLDCH
Gas refrigerant port
øαЇʒθʪ˙θ˝ʪθɇϩΧͱθϩ
AC***BNHDCH
Gas refrigerant port
øαЇʒθʪ˙θ˝ʪθɇϩΧͱθϩ
NOTE
• The designs and shape are subject to change according to the
model.
• To prevent dirt or foreign objects from getting into the pipes
during installation, do NOT remove the pinch pipe completely
until you are ready to connect the piping.
CAUTION
• Connect the indoor and outdoor units using pipes with flared
ʀͱʪʀϩͱϑࣔͱϩϑЇΧΧʪʒࣕ࢒ͱθϩ˵ʪʪϑࡨЇϑʪϑЇɇϩʪʒࡨЇиʪʒʪʒࡨ
degreased and deoxidized copper pipe (Cu DHP type to ISO 1337
or UNI EN 12735-1), suitable for operating pressures of at least
4200kPa and for a burst pressure of at least 20700kPa. Copper
pipe for hydro-sanitary applications is completely unsuitable.
• ͱθϑі˝ɇʒϩϑࣔ˵ʪ˝˵ϩʒ˙˙ʪθʪʀʪࡨʪʪ˝ϩ˵ࡨɇу࢒
bends, refrigerant charge, etc.) see the outdoor unit
installation manual.
• All refrigerant connection must be accessible, in order to permit
either unit maintenance or removing it completely.
Step 6 Cutting and flaring the pipes
1 đɇʪϑЇθʪϩ˵ɇϩцͱЇ˵ɇЭʪϩ˵ʪθʪαЇθʪʒϩͱͱϑɇЭɇɇɵʪ࢒ࣔΧΧʪʀЇϩϩʪθࡨ
reamer, flaring tool and pipe holder)
2 If you wish to shorten the pipes, cut it with a pipe cutter, taking
care to ensure that the cut edge remains at a 90° angle with the
side of the pipe. Refer to the illustrations below for examples of
edges cut correctly and incorrectly.
90°
90
Pipe cutter
Pipe ĮɵαЇʪŵͱЇ˝˵9Їθθ
3 To prevent any gas from leaking out, remove all burrs at the cut
edge of the pipe, using a reamer.
4 Slide a flare nut on to the pipe and modify the flare.
D
A
90° ±2°
D
L
45° ±2°
Pipe ɇθʪ
R 0.016 to 0.032 inch
(R 0.4 to 0.8 mm)

15
Installation Procedure
English
OuterDiameter (D) Depth (A) Flare dimension (L)
Ø1/4 (6.35) 0.051 (1.3) 0.34~0.36 ( 8.7~9.1 )
Ø3/8 (9.52) 0.071 (1.8) 0.50~0.52 ( 12.8~13.2 )
Ø1/2 ( 12.70 ) 0.079 (2.0) 0.64~0.65 ( 16.2~16.6 )
Ø5/8 ( 15.88 ) 0.087 (2.2) 0.76~0.78 ( 19.3~19.7 )
Ø3/4( 19.05 ) 0.087 (2.2) 0.93~0.94 ( 23.6~24.0 )
Unit: inch(mm)
5 Check that the flaring is correct, referring to the illustrations
below for examples of incorrect flaring.
Correct Inclined Damaged
Surface Cracked Uneven
Thickness
CAUTION
• Ã˙ϩ˵ʪΧΧʪϑθʪαЇθʪɵθɇі˝ʪϑЇθʪϩ˵ɇϩĮĘࣔĮуц˝ʪθʪʪ
Nitrogen) is flowing through the system.
• Nitrogen blowing pressure range is 0.02 ~ 0.05MPa.
Step 7 Connecting the assembly pipes to
the refrigerant pipes
There are two refrigerant pipes of different diameters :
• ϑɇʪθͱʪ˙ͱθϩ˵ʪαЇʒθʪ˙θ˝ʪθɇϩ
• A larger one for the gas refrigerant
• Ɵ˵ʪϑʒʪͱ˙ʀͱΧΧʪθΧΧʪЇϑϩɵʪʀʪɇই˵ɇϑͱʒЇϑϩ
1 Remove the pinch pipe on the pipes and connect the assembly
pipes to each pipe, tightening the nuts, first manually and then
иϩ˵ɇϩͱθαЇʪиθʪʀ˵ࡨɇϑΧɇʪθɇΧΧц˝ϩ˵ʪ˙ͱͱи˝ϩͱθαЇʪ࢒
2
3
3
1
Spanner
Union
ƟͱθαЇʪиθʪʀ˵
ɇθʪЇϩ
Outer Diameter Torque
mm inch N•m lbf.ft
Ø6.35 1/4 14 to 18 10.3 to 13.3
Ø9.52 3/8 34 to 42 25.1 to 31.0
Ø 12.70 1/2 49 to 61 36.1 to 45.0
Ø 15.88 5/8 68 to 82 50.2 to 60.5
Ø 19.05 3/4 100 to 120 73.8 to 88.5
(1 N•m=10 kgf•cm)
NOTE
• If the pipes must be shortened refer to page 14,
Step 6 Cutting and flaring the pipes
• Ɵ˝˵ϩʪϩ˵ʪЇϩϑϩͱϩ˵ʪϑΧʪʀ˙ʪʒϩͱθαЇʪϑ࢒Ã˙ͱЭʪθϩ˝˵ϩʪʪʒࡨ
the nuts could be broken so refrigerant may leak.

16
Installation Procedure
Installation Procedure
English
2 Be sure to use insulator which is thick enough to cover the
refrigerant tube to protect the condensate water on the outside
of pipe falling onto the floor and the efficiency of the unit will be
better.
3 Cut off any excess foam insulation.
4 Be sure that there must be no crack orwave on the bended area.
5 It would be necessary to double the insulation thickness[0.39
inch (10mm) or more] to prevent condensation even on the
insulator when if the installed area is warm and humid.
6 Do not use joints or extensions for the pipes that connect the
indoor and outdoor unit. The only permitted connections are
those forwhich the units are designed.
AC***BNLDCH
Gas refrigerant port
Drain hose connection port
øαЇʒθʪ˙θ˝ʪθɇϩΧͱθϩ
AC***BNHDCH
Gas refrigerant port
Drain hose connection port
øαЇʒθʪ˙θ˝ʪθɇϩΧͱθϩ
NOTE
• The designs and shape are subject to change according to the
model.
Step 8 Performing the gas leak test
Pressure check the refrigerant system using high pressure
nitrogen in order to detect basic refrigerant leaks. Before
performing the vacuum process and releasing the factory R-410A
charge into the refrigerant pipes, it is the responsibility of the
installer to pressurize the whole system with nitrogen (using a
cylinder with pressure reducer) at a pressure above 580.2 psi(4
Mpa) (gauge).
AC***BNLDCH
Gas refrigerant port
øαЇʒθʪ˙θ˝ʪθɇϩΧͱθϩ
AC***BNHDCH
øαЇʒθʪ˙θ˝ʪθɇϩΧͱθϩ
Gas refrigerant port
Insulator

17
Installation Procedure
English
Step 9 Insulating the refrigerant pipes
Once you have checked that there are no leaks in the system, you
can insulate the piping and hose.
1 To avoid condensation problems, place Acrylonitrile Butadien
Rubber separately around each refrigerant pipe.
No gap
NBR
NOTE
• Always make the seam of pipes face upwards.
2 Wind insulating tape around the pipes and drain hose avoiding
compressing the insulation too much.
Insulation cover pipe
Insulation pipe
Be sure to overlap the insulation.
Indoor unit
CAUTION
• Be sure to wrap insulation tightly without any gaps.
3 ϑ˵иθɇΧΧ˝ϑЇɇϩ˝ϩɇΧʪɇθͱЇʒϩ˵ʪθʪϑϩͱ˙ϩ˵ʪΧΧʪϑ
leading to the outdoor unit.
4 The pipes and electrical cables connecting the indoor unit with
the outdoor unit must be fixed to the wall with suitable ducts.
CAUTION
• Make sure that all refrigerant connection must be accessible
for easy maintenance and detachment.
• Install the insulation not to get wider and use the adhesives
on the connection part of it to prevent moisture from
entering.
• Wind the refrigerant pipe with insulation tape if it is exposed
to outside sunlight.
• Install the refrigerant pipe respecting that the insulation does
not get thinner on the bent part or hanger of pipe.
• Add the additional insulation if the insulation plate gets
thinner.
Additional insulation
Hanger
Refrigerant
pipe insulation
a x 3
a
5 Select the insulation of the refrigerant pipe.
• ÃϑЇɇϩʪϩ˵ʪ˝ɇϑϑʒʪɇʒαЇʒϑʒʪΧΧʪࡨͱϩ˝ϩ˵ʪ
insulation thickness that must differ according to the pipe
size.
• Standard: Less than an indoor temperature of
ߢߠএࣔߝߚএAࣕ ,
with humidity at 85%. If installing in a high humidity
environment, use one grade thicker insulator by referring to
the table below. If installing in an unfavourable environment,
use thicker one.
• The heat-resistance temperature of the insulator must be
more than
ߜߞߢএࣔߛߜߚএAࣕ .

18
Installation Procedure
Installation Procedure
English
Pipe Outer diameter
Insulation Type (Cooling, Heating)
Remarks
General
[86°F(30°C), 85%]
High humidity
[86°F(30°C), over 85%]
EPDM, NBR
mm inch mm inch mm inch
øαЇʒΧΧʪ
6.35~9.52 1/4~3/8 93/893/8
The internal temperature is
˵˝˵ʪθϩ˵ɇߜߞߢএࣔߛߜߚএAࣕ
12.7~50.80 1/2~2 13 1/2 13 1/2
Gas pipe
6.35 1/4 13 1/2 19 3/4
9.52~25.4 3/8~1 19 3/4 25 1
28.58~44.45 1 1/8~1 3/4 19 3/4 32 1 1/4
50.8 2 25 1 38 1 1/2
• When installing insulation in the places and conditions below, use the same insulation that is used for high humidity conditions.
<Geological condition>
High humidity locations such as shorelines, hot springs, lake or riversides, and ridges (when part of the building is covered by earth and sand)
<Operation purpose condition>
Restaurant ceiling, sauna, swimming pool etc.
<Building construction condition>
Aʪ˝ϑ˙θʪαЇʪϩцʪуΧͱϑʪʒϩͱͱϑϩЇθʪɇʒʀͱͱ˝ɇθʪͱϩʀͱЭʪθʪʒ࢒ͱθʪуɇΧʪࡨΧΧʪϑϑϩɇʪʒɇϩɇʀͱθθʒͱθͱ˙ɇʒͱθϩͱθцɇʒϑϩЇʒͱͱθʪɇθɇ
ʪуϩϩ˵ɇϩͱΧʪϑɇʒʀͱϑʪϑ˙θʪαЇʪϩц࢒
Places (where the pipes are installed) that are highly humid due to a lack of ventilation.

19
Installation Procedure
English
Step10 Installing the drain hose and drain
pipe
1 Push the supplied drain hose as far as possible over the drain
socket.
2 Tighten the metal clamp as shown in the picture.
3 Wrap the supplied large sealing pad over the metal clamp and
drain hose to insulate and fix it with clamps.
4 Insulate the complete drain piping inside the building (field
supply).If the drain hose cannot be sufficiently set on a slope, fit
the hose with drain raising piping (field supply).
5 Push the drain hose up to insulation when connecting the drain
hose to drain socket.
A-A’
Steel ring of drain hose
Joint of drain hose
Drain hose Drain hose
уиϩ˵AɇɵʪࣞƟʪ
Wrap thermal sleeve hose
Indoor unit
Reducer
Without the drain pump
1 Install horizontal drainpipe with a slope of 1/100 or more and fix
it by hanger space of 3.28~4.92ft(1~1.5m).
2 Install U-trap at the end of the drainpipe to prevent a nasty smell
to reach the indoor unit.
3 Do not install the drainpipe to upward position. It may cause
water flow back to the unit.
3.28~4.92ft
(1~1.5m)
Horizontal drainpipe
more than 1/100 slope
Ceiling
Hanger
ʪуɵʪ˵ͱϑʪ
With the drain pump
1 The drain pipe should be installed within 11.81inch(300mm) to
21.65inch(550mm) from the flexible hose and then lift down
0.79inch(20mm) or more.
2 Install horizontal drainpipe with a slope of 1/100 or more and fix
it by hanger space of 3.28~4.92ft(1~1.5m).
3 Install the air vent in the horizontal drainpipe to prevent water
flow back to the indoor unit.
NOTE
• You may not need to install it if there were proper slope in the
horizontal drainpipe.
4 The flexible hose should not be installed upward position, it may
cause water flow back to the indoor unit.

20
Installation Procedure
Installation Procedure
English
Centralized drainage without the drain pump
1 Install horizontal drainpipe with a slope of 1/100 or more and fix
it by hanger space of 3.28~4.92ft(1~1.5m).
2 Install U-trap at the end of the drainpipe to prevent a nasty smell
to reach the indoor unit.
3.94inch(100mm)
or more
Ceiling Horizontal drainpipe
more than 1/100 slope
Centralized drainage with the drain pump
1 Install main air vent at the front of the farthest indoor unit from
the main drain when installed indoor units are more than 3.
2 You may need to install individual air vent to prevent water flow
back at the top of each indoor unit drainpipe.
Main drainpipe
Hanger
Main air vent
Centralized horizontal drainpipe
(more than 1/100 slope)
21.65inch
(550mm) or less
3.28~4.92ft
(1~1.5m)
Individual
air vent
Step11 Performing the drainage test
Prepare a little water about 0.53 gallons(2 liters).
1 Loosen screws and take out the side cover plate.
2 Pourwater into the indoor unit as shown in figure.
NOTE
• Drainage test should be done after installation has been
finished. To avoid water overflow from the indoor unit
because the drain tube is blocked.
AC***BNLDCH
AC***BNHDCH
࢟Ɵ˵ʪʒʪϑ˝ϑɇʒϑ˵ɇΧʪɇθʪϑЇɵʪʀϩϩͱʀ˵ɇ˝ʪɇʀʀͱθʒ˝ϩͱ
the model.
3 Confirm that the water flows out through the drain hose.
4 When the drain pump is installed, operate the unit as
cooling mode and check a drain pump pumping.
5 Check drain water drops at the end of the drain pipe.
6 Make sure there is no water leak at the drainage.
7 Reinstall the side cover plate.
