Samsung AC TN4P Series User manual

Airconditioner
Usermanual
AC***TN4P**
࡛Thankyou forpurchasing this Samsung airconditioner.
࡛Before operating this unit, please readthis usermanual carefullyand retain it forfuture
reference.
DB68-09062A-00

2English
SafetyInformation 3
Safety Information 3
AtaGlance 12
IndoorUnit Overview 12
Operation Features 13
Operating temperature and humidity 13
CleaningandMaintenance 14
Cleaning and Maintaining 14
Cleaning the indoorunit exterior 14
Cleaning the outdoorunit heat exchanger 14
Cleaning the airfilter 15
Periodical maintenance 17
Troubleshooting 18
Contents
CorrectDisposal ofThis Product
(WasteElectrical&ElectronicEquipment)
(Applicableincountrieswithseparatecollection systems)
This marking on the product, accessories orliterature indicatesthat the product and its electronic
accessories (e.g. charger, headset, USB cable) should not be disposed of with otherhouseholdwaste at the
end of theirworking life. To prevent possible harm tothe environment orhuman health from uncontrolled
waste disposal, please separate these items from othertypes ofwaste and recyclethem responsiblyto
promote the sustainable reuse of material resources.
Household users should contact eitherthe retailerwhere theypurchased this product, ortheirlocal
government office, fordetails ofwhere and howthey can take these itemsforenvironmentallysafe
recycling.
Business users should contact theirsupplierand check the terms and conditions of the purchase contract.
This product and its electronic accessories should not be mixedwith othercommercialwastes fordisposal.

3
English
SafetyInformation
Before usingyournewairconditioner, please read this manual thoroughlyto
ensure thatyou knowhowto safely and efficientlyoperate the extensive features
and functions ofyournewappliance.
Because thefollowing operating instructions covervarious models, the
characteristics ofyourairconditionermaydifferslightlyfromthose described in
this manual. Ifyou have anyquestions, callyournearest contact centre orfind
help and information online at www.samsung.com.
WARNING
Hazards orunsafe practicesthat mayresult in severe personal injuryordeath.
CAUTION
Hazards orunsafe practicesthat mayresult in minorpersonal injuryorproperty
damage.
Followdirections.
Do NOTattempt.
Make sure the machine is groundedto prevent electric shock.
Cut-off the powersupply.
Do NOTdisassemble.
FORINSTALLATION
WARNING
Usethepowerlinewiththepowerspecificationsoftheproductorhigher
andusethepowerlineforthisapplianceonly.Inaddition,donotusean
extensionline.
࡛Extendingthe powerline mayresult in electric shock orfire.
࡛Do not use an electric transformer. This mayresult in electric shock orfire.
࡛If thevoltage/frequency/rated current condition is different, it maycause
fire.
SafetyInformation

4English
SafetyInformationSafetyInformation
SafetyInformation
Theinstallationofthisappliancemustbeperformedbyaqualified
technicianorservicecompany.
࡛Failing to do so mayresult in electric shock,fire, explosion, problemswith
the product, orinjury.
Installaswitchandcircuitbreakerdedicatedtotheairconditioner.
࡛Failing to do so mayresult in electric shock orfire.
Fixtheoutdoorunitfirmlysothattheelectricpartoftheoutdoorunitis
notexposed.
࡛Failing to do so mayresult in electric shock orfire.
Donotinstallthisappliancenearaheater,inflammablematerial.Do
notinstallthisapplianceinahumid,oilyordustylocation,inalocation
exposedtodirectsunlightandwater(raindrops).Donotinstallthis
applianceinalocationwheregasmayleak.
࡛This mayresult in electric shock orfire.
Neverinstalltheoutdoorunitinalocationsuchasonahighexternalwall
whereitcouldfall.
࡛If the outdoorunit falls, it mayresult in injury, death orpropertydamage.
Thisappliancemustbeproperlygrounded.Donotgroundtheapplianceto
agaspipe,plasticwaterpipe,ortelephoneline.
࡛Failure to do so mayresult in electric shock, fire, an explosion, orother
problemswith the product.
࡛Neverplug the powercord into a socket that is not grounded correctlyand
make sure that it is in accordancewith local and national codes.
CAUTION
Installyourapplianceonalevelandhardfloorthatcansupportitsweight.
࡛Failing to do so mayresult in abnormalvibrations, noise, orproblemswith
the product.
Installthedrainhoseproperlysothatwaterisdrainedcorrectly.
࡛Failing to do so mayresult inwateroverflowing and propertydamage.
Avoid adding draintowaste pipes as odours mayarise in the future.

5
English
SafetyInformation
Theproductshallbe storedin aroomwithno ignitionsources
(e.g.openflames,gasappliance,electricheater,etc.).
࡛Notethat the refrigerant has no odour.
Wheninstallingtheoutdoorunit,makesuretoconnectthedrainhoseso
thatdrainingisperformedcorrectly.
࡛Thewatergenerated during the heating operation in the outdoorunit may
overflowand result in propertydamage.
In particular, inwinter, if a block of ice falls, it mayresult in injury, death or
propertydamage.
Donotinstalltheproductinaplacewherethermo-hygrostatisneeded
(suchasserverroom,machineryroom,computerroom,etc.)
࡛Those places do not provide guaranteed operation condition ofthe
product therefore performance can be poorin these places.
FORPOWERSUPPLY
WARNING
Whenthecircuitbreakerisdamaged,contactyournearestservicecentre.
Donotpullorexcessivelybendthepowerline.Donottwistortiethepower
line.Donothookthepowerlineoverametalobject,placeaheavyobject
onthepowerline,insertthepowerlinebetweenobjects,orpushthepower
lineintothespacebehindtheappliance.
࡛This mayresult in electric shock orfire.
CAUTION
Whennotusingtheairconditionerforalongperiodoftimeorduringa
thunder/lightningstorm,cutthepoweratthecircuitbreaker.
࡛Failing to do so mayresult in electric shock orfire.

6English
SafetyInformationSafetyInformation
SafetyInformation
FORUSING
WARNING
Iftheapplianceisflooded,pleasecontactyournearestservicecentre.
࡛Failing to do so mayresult in electric shock orfire.
Iftheappliancegeneratesastrangenoise,aburningsmellorsmoke,
unplugthepowerplugimmediatelyandcontactyournearestservice
centre.
࡛Failing to do so mayresult in electric shock orfire.
Incaseofamalfunction,immediatelystopoperationoftheairconditioner
anddisconnecttheentirepowersystem.Thenconsulttheauthorized
servicepersonnel.
Intheeventofagasleak(suchaspropanegas,LPgas,etc.),ventilate
immediatelywithouttouchingthepowerline.Donottouchtheappliance
orpowerline.
࡛Do not use aventilating fan.
࡛Aspark mayresult in an explosion orfire.
Toreinstalltheairconditioner,pleasecontactyournearestservicecentre.
࡛Failing to do so mayresult in problemswith the product,waterleakage,
electric shock, orfire.
࡛Adeliveryservice forthe product is not provided. Ifyou reinstallthe
product in anotherlocation, additional construction expenses and an
installation feewill be charged.
࡛Especially,when youwish to install the product in an unusual location
such as in an industrial area ornearthe seasidewhere it is exposedto salt
in the air, please contactyournearest service centre.

7
English
SafetyInformation
Donottouchthecircuitbreakerwithwethands.
࡛This mayresult in electric shock.
Donotturntheairconditioneroffwiththecircuitbreakerwhileitis
operating.
࡛Turning the airconditioneroff and then on againwith the circuit breaker
maycause a spark and result in electric shock orfire.
Afterunpackingtheairconditioner,keepallpackagingmaterialswell
outofthereachofchildren,aspackagingmaterialscanbedangerousto
children.
࡛If a child places a bag overits head, it mayresult in suffocation.
Donottouchthefrontpanelwithyourhandsorfingersduringtheheating
operation.
࡛This mayresult in electric shock orburns.
Donotinsertyourfingersorforeignsubstancesintotheoutletwhentheair
conditionerisoperatingorthefrontpanelisclosing.
࡛Take special care that children do not injure themselves byinserting their
fingers intothe product.
Donotinsertyourfingersorforeignsubstancesintotheairinlet/outletof
theairconditioner.
࡛Take special care that children do not injure themselves byinserting their
fingers intothe product.
Donotstrikeorpulltheairconditionerwithexcessiveforce.
࡛This mayresult in fire, injury, orproblemswith the product.
Donotplaceanobjectneartheoutdoorunitthatallowschildrentoclimb
ontothemachine.
࡛This mayresult in children seriouslyinjuring themselves.

8English
SafetyInformationSafetyInformation
SafetyInformation
Donotusethisairconditionerforlongperiodsoftimeinbadlyventilated
locationsornearinfirmpeople.
࡛Since this maybe dangerous due to a lack of oxygen, open awindowat
least once an hour.
Donotusemeanstoacceleratethedefrostoperationortoclean,other
thanthoserecommendedbySamsung.
Donotpierceorburn.
Beawarethatrefrigerantsmaynotcontainanodour.
Ifanyforeignsubstancesuchaswaterhasenteredtheappliance,cutthe
powerbyunpluggingthepowerplugandturningthecircuitbreakeroff
andthencontactyournearestservicecentre.
࡛Failing to do so mayresult in electric shock orfire.
Donotattempttorepair,disassemble,ormodifytheapplianceyourself.
࡛Do not use anyfuse (such as copper, steelwire, etc.)otherthan the
standardfuse.
࡛Failing to do so mayresult in electric shock,fire, problemswith the
product, orinjury.
CAUTION
Donotplaceobjectsordevicesundertheindoorunit.
࡛Waterdripping fromthe indoorunit mayresult in fire orpropertydamage.
Checkthattheinstallationframeoftheoutdoorunitisnotbrokenatleast
onceayear.
࡛Failing to do so mayresult in injury, death orpropertydamage.
MaxcurrentismeasuredaccordingtoIECstandardforsafetyandcurrentis
measuredaccordingtoISOstandardforenergyefficiency.

9
English
SafetyInformation
Whentheairconditionerdoesnotoperateproperlyforcoolingorheating,
thereisapossibilityofrefrigerantleakage.Ifanyleakage,stopoperation,
ventilatetheroom,andconsultyourdealerimmediatelyforrecharging
refrigerant.
Therefrigerantisnotharmful.However,ifitcomesincontactwithfire,it
maygenerateharmfulgasesandthereisriskoffire.
Duringtransportationoftheindoorunit,thepipelinesshallbecovered
withbracketsforprotection.Donotmovetheproductwithholdingthe
pipelines.
࡛It maycause gas leakage.
Donotinstalltheproductinashiporavehicle(suchasacampervan).
࡛Salt,vibration orotherenvironmental factormaycause the product
malfunction, electric shock orfire.
Donotstandontopoftheapplianceorplaceobjects(suchaslaundry,
lightedcandles,lightedcigarettes,dishes,chemicals,metalobjects,etc.)
ontheappliance.
࡛This mayresult in electric shock,fire, problemswith the product, orinjury.
Donotoperatetheappliancewithwethands.
࡛This mayresult in electric shock.
Donotsprayvolatilematerialsuchasinsecticideontothesurfaceofthe
appliance.
࡛Aswell as being harmful to humans, it mayalso result in electric shock,
fire orproblemswith the product.
Donotdrinkthewaterfromtheairconditioner.
࡛Thewatermaybe harmful to humans.
Donotapplyastrongimpacttotheremotecontrolleranddonot
disassembletheremotecontroller.

10 English
SafetyInformationSafetyInformation
SafetyInformation
Donottouchthepipesconnectedwiththeproduct.
࡛This mayresult in burns orinjury.
Donotcutorburntherefrigerantcontainerorpipings.
Donotpointtheairdirectiontothefireplaceorheater.
Donotusethisairconditionertopreserveprecisionequipment,food,
animals,plantsorcosmetics,orforanyotherunusualpurposes.
࡛This mayresult in propertydamage.
Avoiddirectlyexposinghumans,animalsorplantstotheairflowfromthe
airconditionerforlongperiodsoftime.
࡛This mayresult in harm to humans, animals orplants.
Thisapplianceisnotintendedforusebypersons(includingchildren)with
reducedphysical,sensoryormentalcapabilities,orlackofexperience
andknowledge,unlesstheyhavebeengivensupervisionorinstruction
concerninguseoftheappliancebyapersonresponsiblefortheirsafety.
Childrenshouldbesupervisedtoensurethattheydonotplaywiththe
appliance.
FORCLEANING
WARNING
Donotcleantheappliancebysprayingwaterdirectlyontoit.Donotuse
benzene,thinner,alcoholoracetonetocleantheappliance.
࡛This mayresult in discoloration, deformation, damage, electric shock or
fire.
Beforecleaningorperformingmaintenance,unplugtheairconditioner
fromthewallsocketandwaituntilthefanstops.
࡛Failing to do so mayresult in electric shock orfire.
