Samsung AR MRFQ Series User manual

Air conditioner
User manual/Installation manual
ARMRFQ
•Thank you for purchasing this Samsung air conditioner.
•Before operating this unit, please read this user manual carefully and retain it for future reference.
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 1 2017-01-20 오전 11:28:24

2
English
Contents
Safety Information 5
Safety Information 5
At a Glance 13
Indoor Unit Overview 13
Remote Control Overview 14
Inserting batteries
Remote Control Operation 15
Operation modes
Controlling temperature
Controlling fan speed
Controlling air flow direction
Power Smart Features 17
Cooling Operation 17
Cool mode
Dehumidifying Operation 17
Dry mode
Quick Smart Features 18
Auto mode
Fan mode
Turbo function
Display lighting function
Energy-Saving Features 20
Energy-Saving Operation 20
Timed on/Timed off function
good’sleep function
Cleaning and Maintenance 22
Cleaning at a Glance 22
Troubleshooting 24
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 2 2017-01-20 오전 11:28:25

3
English
Installation 28
Safety Information on Installation 28
Preparation 30
Step 1.1 Choosing the installation location
Step 1.2 Checking and preparing accessories and tools
Step 1.3 Drilling a hole through the wall
Step 1.4 Taping the pipes, cables, and drain hose
Indoor Unit Installation 34
Step 2.1 Connecting the cables (assembly cable)
Step 2.2 Optional: Extending the power cable
Step 2.3 Installing and connecting the drain hose
Step 2.4 Optional: Extending the drain hose
Step 2.5 Optional: Changing the direction of the drain hose
Step 2.6 Installing and connecting the assembly pipes to the refrigerant pipes (assembly pipe)
Step 2.7 Shortening or extending the refrigerant pipes (assembly pipe)
Step 2.8 Fixing the installation plate
Outdoor Unit Installation 40
Step 3.1 Fixing the outdoor unit in place
Step 3.2 Connecting the cables and the refrigerant pipes
Step 3.3 Evacuating the air
Step 3.4 Adding refrigerant
Installation Inspection 43
Step 4.1 Performing the gas leak tests
Step 4.2 Performing final check and trial operation
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 3 2017-01-20 오전 11:28:25

4
English
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
charger, headset, USB cable) should not be disposed of with other household waste at the end of their working
life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please
separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of
material resources.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product and its electronic accessories should not be mixed with other commercial wastes for disposal.
Correct disposal of batteries in this product
This marking on the battery, manual or packaging indicates that the batteries in this product should not be
disposed of with other household waste at the end of their working life. Where marked, the chemical symbols Hg,
Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC Directive
2006/66.
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 4 2017-01-20 오전 11:28:25

5
English
Safety Information
Safety Information
Before using your new air conditioner, please read this manual
thoroughly to ensure that you know how to safely and efficiently
operate the extensive features and functions of your new appliance.
Because the following operating instructions cover various models,
the characteristics of your air conditioner may differ slightly from
those described in this manual. If you have any questions, call your
nearest contact centre or find help and information online at www.
samsung.com.
WARNING
Hazards or unsafe practices that may result in severe personal
injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal
injury or property damage.
Follow directions. Do NOT attempt.
Make sure the machine is grounded to prevent electric shock.
Cut off the power supply. Do NOT disassemble.
FOR INSTALLATION
WARNING
Use a power cord with this product's power specifications
or higher and use the power cord for this appliance only. In
addition, do not use an extension cord.
• Extending the power cord may result in electric shock or fire.
• Do not use an electric transformer. This may result in electric
shock or fire.
Safety Information
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 5 2017-01-20 오전 11:28:25

6
English
Safety Information
• If the voltage/frequency/rated current condition is different,
it may cause fire.
The installation of this appliance must be performed by a
qualified technician or service company.
• Failing to do so may result in electric shock, fire, explosion,
problems with the product, or injury and may also void
warranty on the installed product.
Install an Isolation Switch next to the Air Conditioner (but
not on the panels of the Air Conditioner) and circuit breaker
dedicated to the air conditioner.
• Failing to do so may result in electric shock or fire.
Fix the outdoor unit firmly so that the electric part of the
outdoor unit is not exposed.
• Failing to do so may result in electric shock, fire, explosion,
or problems with the product.
Do not install this appliance near a heater, or inflammable material.
Do not install this appliance in a humid, oily or dusty location, in
a location exposed to direct sunlight and water (or rain). Do not
install this appliance in a location where gas may leak.
• This may result in electric shock or fire.
Never install the outdoor unit in a location such as on a high
external wall where it could fall.
• If the outdoor unit falls, it may result in injury, death or
property damage.
This appliance must be properly grounded. Do not ground the
appliance to a gas pipe, plastic water pipe, or telephone line.
• Failing to do so may result in electric shock, fire, and
explosion.
• Make sure to use a socket-outlet with ground.
Safety Information
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 6 2017-01-20 오전 11:28:25

7
English
Safety Information
CAUTION
Please cover the air conditioner with PE BAG after installation,
and remove it when you start to run air conditioner.
Install your appliance on a level and hard floor that can
support its weight.
• Failing to do so may result in abnormal vibrations, noise, or
problems with the product.
Install the drain hose properly so that water drains correctly.
• Failing to do so may result in water overflowing and
property damage. Avoid adding drain to waste pipes as
odours may arise in the future.
When installing the outdoor unit, make sure to connect the
drain hose so that draining is performed correctly.
• The water generated during heating by the outdoor unit may
overflow and result in property damage.
In particular, in winter, if a block of ice falls, it may result in
injury, death or property damage.
FOR POWER SUPPLY
WARNING
When the circuit breaker is damaged, contact your nearest
service centre.
Do not pull or excessively bend the power line. Do not twist
or tie the power line. Do not hook the power line over a metal
object, place a heavy object on the power line, insert the
power line between objects, or push the power line into the
space behind the appliance.
• This may result in electric shock or fire.
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 7 2017-01-20 오전 11:28:25

8
English
Safety Information
CAUTION
When not using the air conditioner for a long period of time or
during a thunder/lightning storm, cut the power at the circuit
breaker.
• Failing to do so may result in electric shock or fire.
FOR USING
WARNING
If the appliance is flooded, please contact your nearest service
centre.
• Failing to do so may result in electric shock or fire.
If the appliance generates a strange noise, a burning smell or
smoke, cut off the power supply immediately and contact the
nearest service centre.
• Failing to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.),
ventilate immediately without touching the power line. Do not
touch the appliance or power line.
• Do not use a ventilating fan.
• A spark may result in an explosion or fire.
To reinstall the air conditioner, please contact your nearest
service centre.
• Failing to do so may result in problems with the product,
water leakage, electric shock, or fire.
• Delivery service for the product is not provided. If you
reinstall the product in another location, additional
construction expenses and an installation fee will be charged.
Safety Information
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 8 2017-01-20 오전 11:28:26

9
English
Safety Information
• Especially, when you wish to install the product in an
unusual location such as in an industrial area or near the
seaside where it is exposed to salt in the air, please contact
your nearest service centre.
Do not touch the circuit breaker with wet hands.
• This may result in electric shock.
Do not turn the air conditioner off with the circuit breaker
while it is operating.
• Turning the air conditioner off and then on again with the
circuit breaker may cause a spark and result in electric shock
or fire.
After unpacking the air conditioner, keep all packaging
materials well out of the reach of children, as packaging
materials can be dangerous to children.
• If a child places a bag over its head, it may result in
suffocation.
Do not touch the air flow blade with your hands or fingers
during heating.
• This may result in electric shock or burns.
Do not insert your fingers or foreign substances into the air
inlet/outlet of the air conditioner.
• Take special care that children do not injure themselves by
inserting their fingers into the product.
Do not strike or pull the air conditioner with excessive force.
• This may result in fire, injury, or problems with the product.
Do not place an object near the outdoor unit that allows
children to climb onto the machine.
• This may result in children seriously injuring themselves.
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 9 2017-01-20 오전 11:28:26

10
English
Safety Information
Do not use this air conditioner for long periods of time in badly
ventilated locations or near infirm people.
• Since this may be dangerous due to a lack of oxygen, open a
window at least once an hour.
If any foreign substance such as water has entered the
appliance, cut off the power supply and contact the nearest
service centre.
• Failing to do so may result in electric shock or fire.
Do not attempt to repair, disassemble, or modify the appliance
yourself.
• Do not use any fuse (such as cooper, steel wire, etc.) other
than the standard fuse.
• Failing to do so may result in electric shock, fire, problems
with the product, or injury.
CAUTION
Do not place objects or devices under the indoor unit.
• Water dripping from the indoor unit may result in fire or
property damage.
Check that the installation frame of the outdoor unit is not
broken at least once a year.
• Failing to do so may result in injury, death or property
damage.
Max current is measured according to IEC standard for safety
and current is measured according to ISO standard for energy
efficiency.
Do not stand on top of the appliance or place objects (such as
laundry, lighted candles, lighted cigarettes, dishes, chemicals,
metal objects, etc.) on the appliance.
Safety Information
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 10 2017-01-20 오전 11:28:26

11
English
Safety Information
• This may result in electric shock, fire, problems with the
product, or injury.
Do not operate the appliance with wet hands.
• This may result in electric shock.
Do not spray volatile material such as insecticide onto the
surface of the appliance.
• As well as being harmful to humans, it may also result in
electric shock, fire or problems with the product.
Do not drink the water from the air conditioner.
• The water may be harmful to humans.
Do not apply a strong impact to the remote control and do not
disassemble the remote control.
Do not touch the pipes connected with the product.
• This may result in burns or injury.
Do not use this air conditioner to preserve precision
equipment, food, animals, plants or cosmetics, or for any other
unusual purposes.
• This may result in property damage.
Avoid directly exposing humans, animals or plants to the air
flow from the air conditioner for long periods of time.
• This may result in harm to humans, animals or plants.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, without supervision
or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to
ensure that they do not play with the appliance.
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 11 2017-01-20 오전 11:28:26

12
English
Safety Information
FOR CLEANING
WARNING
Do not clean the appliance by spraying water directly onto it.
Do not use benzene, thinner or alcohol to clean the appliance.
• This may result in discolouration, deformation, damage,
electric shock or fire.
Before cleaning or performing maintenance, cut off the power
supply and wait until the fan stops.
• Failing to do so may result in electric shock or fire.
CAUTION
Take care when cleaning the surface of the heat exchanger of
the outdoor unit since it has sharp edges.
• This should be done by a qualified technician. Please contact
your installer or service centre.
Do not clean the inside of the air conditioner by yourself.
• For cleaning inside the appliance, contact your nearest
service centre.
• When cleaning the filter, refer to the descriptions in the
‘Cleaning at a Glance’ section.
• Failing to do so may result in damage, electric shock or fire.
At a Glance
Safety Information
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 12 2017-01-20 오전 11:28:26

13
English
At a Glance
01 Air intake
02 Air filter
03 Air flow blade (up and down)
04 Air flow blade (left and right)
05 Display
06 Room temperature sensor
07 Remote control receiver
The actual product may differ slightly from the image depicted below.
Indoor Unit Overview
At a Glance
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 13 2017-01-20 오전 11:28:28

14
English
At a Glance
Remote Control Overview
01 Operation mode indicator
02 Set temperature indicator/Timer option
indicator
03 good'sleep indicator
04 Options indicator
05 Transmit indicator
06 Low battery indicator
07 Fan speed indicator
08 Settings indicator
09 Power button
10 Temperature button
11 Options button
12 Timer button
13 Direction button / Selection button
14 Vertical air swing button
15 Mode button
16 Fan speed button
17 Direct button
18 Settings button
19 SET button
NOTE
• The descriptions in this manual are primarily
made based on the remote control buttons.
• Although Heat / Clean are displayed on
the remote control display. they are not
available on this model.
Heat
Inserting batteries
two 1.5V AAA type batteries
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 14 2017-01-20 오전 11:28:29

15
English
At a Glance
Remote Control Operation
Operation modes
You can change the current mode between Auto, Cool, Dry and
Fan by pressing the button.
Controlling temperature
You can control the temperature in each mode as follows:
Mode Temperature control
Auto/Cool Adjust by 1 °C between 17 °C and 30 °C.
Dry Adjust by 1 °C between 17 °C and 30 °C.
Fan You cannot control the temperature.
NOTE
You can use the Cool and Dry modes in the following
conditions:
Mode Cool Dry
Indoor temperature
17 °C to 32 °C 10 °C to 32 °C
Outdoor temperature 18 °C to 43 °C 11 °C to 43 °C
Indoor humidity
80% or less
relative humidity _
• If the air conditioner operates in a high humidity
environment in the Cool mode for an extended period of
time, condensation may occur.
You can use the air conditioner easily by selecting a mode and then by controlling the
temperature, fan speed, and air direction.
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 15 2017-01-20 오전 11:28:29

16
English
At a Glance
Controlling fan speed
You can select the following fan speeds in each mode:
Mode Available fan speeds
Auto/Dry (Auto)
Cool/Fan (Auto), (Low), (Med), (High)
Controlling air flow direction
Keep the vertical air flow in a constant direction by stopping
the movements of the vertical air flow blade.
In operation ►
NOTE
• If you adjust the vertical air blade manually. It may not
close completely when you turn off the air conditioner.
Deflector rod
Horizontal air flow (manual)
Keep the horizontal air flow in a constant direction by
changing the directions of the horizontal air flow blades
manually.
CAUTION
• To prevent personal injury, make sure
that you change the directions of the
horizontal air flow blades after stopping
the movements of the vertical air flow
blade.
Power Smart Features
Remote control Operation
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 16 2017-01-20 오전 11:28:30

17
English
Power Smart Features
The smart and powerful cooling functions of the Samsung air conditioner keep an enclosed space
cool and comfortable.
Cooling Operation
Cool mode
Use the Cool mode to stay cool in hot weather.
► ► Select Cool.
NOTE
• For comfort, keep the temperature difference between the
indoor and outdoor air within 5 °C in the Cool mode.
• After selecting the Cool mode, select a function,
temperature, and fan speed that you want to apply.
– To cool your room quickly, select a low temperature and
a strong fan speed.
– To save energy, select a high temperature and a weak
fan speed.
Power Smart Features
Dry mode
Use the Dry mode in rainy or humid weather.
► ► Select Dry.
NOTE
• The lower the set temperature is, the greater the
dehumidifying capacity is. When the current humidity
seems to be high, adjust the set temperature to a low
temperature.
• You cannot use the Dry mode for heating. The Dry mode is
designed to produce a cooling side-effect.
The dehumidifying function of the Samsung air conditioner keeps an enclosed space dry and
comfortable.
Dehumidifying Operation
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 17 2017-01-20 오전 11:28:30

18
English
Power Smart Features
Auto mode
Use the Auto mode when you want the air conditioner to
automatically control the operation. The air conditioner will
provide the most comfortable atmosphere that it can.
► ► Select Auto.
NOTE
• When the indoor temperature seems to be higher or
lower than the set point, the air conditioner automatically
produces cool air to cool down the indoor temperature.
Fan mode
Use the Fan mode to run the air conditioner like a common
fan. The air conditioner provides a natural breeze.
► ► Select Fan.
NOTE
• If the air conditioner will not be used for an extended
period of time, dry the air conditioner by running it in the
Fan mode for 3 or 4 hours.
• The outdoor unit is designed not to operate in the Fan
mode to prevent cold air from entering through the unit.
This is a normal operation and not a fault with the air
conditioner.
There is a variety of extra functionality provided by the Samsung air conditioner.
Quick Smart Features
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 18 2017-01-20 오전 11:28:31

19
English
Power Smart Features
Turbo function
Use the Turbo function to quickly cool your room. This
function is the most powerful cooling function provided by
the air conditioner. You can select this function in the Cool
modes.
In the Cool mode ► ► ►
Select Turbo. ►
NOTE
• If you select the Turbo function while such functions as
good'sleep is running these functions are cancelled.
• You can change the air flow direction.
• You can change the set temperature and the fan speed.
Display lighting function
Use the Display lighting function to turn on or off the lighting
of the indoor unit display.
► ► Select Display. ►
NOTE
• The Display lighting function does not operate when the
indoor unit is turned off.
• If you change the current mode or funtion when the
Display lighting function is on, the Display lighting
function turns on.
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 19 2017-01-20 오전 11:28:31

20
English
Energy-Saving Features
Energy-Saving Operation
Timed on/Timed off function
Use the Timed on/Timed off to turn on or off the air
conditioner after the time that you set.
(Select On or Off among On, Off, and .) ►
(Set the on/off time.) ►
• Press the (Timer) button to change the current
function between On, Off, and (good’sleep).
NOTE
• You can set a time between 0.5 and 24 hours. Set the time
interval to 0.0 to cancel the Timed on/off function.
• After starting the Timed on function, you can change the
mode and the set temperature. You cannot change the set
temperature while the Fan mode is running.
• You cannot set the same time for both of the Timed on
and Timed off functions.
Combining Timed on and Timed off
When
the air
conditioner
is off
Example) Timed on: 3 hours, Timed off: 5 hours
The air conditioner turns on after 3 hours from
the moment you start Timed on/off, remains
on for 2 hours, then turns off automatically.
When
the air
conditioner
is on
Example) Timed on: 3 hours, Timed off: 1 hour
The air conditioner turns off after 1 hour from
the moment you start Timed on/off, then turns
on after 2 hours from the moment it is turned
off.
Energy-Saving Features
RAC MEDIA ODM 아프리카향 IBIM_EN_DB68-00000A-00.indb 20 2017-01-20 오전 11:28:32
