Samsung AEX160EDEHA User manual

Refer to the service manual in the GSPN(see the rear cover) for the more information.
ECO HEATING SYSTEM CONTENTS
ECO HEATING SYSTEM
OUTDOOR UNIT HYDRO UNIT
1. Precautions
2. Product Specifications
3. Disassembly and Reassembly
4. Troubleshooting
5. PCB Diagram
6. Wiring Diagram
7. Schematic Diagram
8. Reference Sheet
Model : AEX160EDEHA
AEX140EDEHA
AEX125EDEHA
AEX160EDGHA
AEX140EDGHA
AEX125EDGHA
AEX100EDEHA
AEX060EDEHA
AEN160YDEHA
AEN160YDGHA
AEN080YDEHA
RC160MHXGA_SM_E_34513A(1)_co.indd 1  

Contents
1. Precautions..............................................................................................................................................3
1-1 Precautions for the Service..........................................................................................................................................3
1-2 Precautions related to static electricity and PL...................................................................................................3
1-3 Precautions for the Safety............................................................................................................................................4
1-4 Precautions for handling a system containing refrigerants .........................................................................5
1-5 Precautions for the brazing .........................................................................................................................................5
1-6 Precautions for charging refrigerants.....................................................................................................................5
2. General Overview ................................................................................................................................6
2-1 Features of the System ..................................................................................................................................................6
2-1-1 Key features of the EHS(SPLIT).........................................................................................................................7
2-2 Product Specifications...................................................................................................................................................8
2-2-1 Outdoor Unit............................................................................................................................................................8
2-3 Specifications of optional items.............................................................................................................................11
2-3-1 Accessories.............................................................................................................................................................11
3. Disassembly and Reassembly......................................................................................................................... 12
3-1 Hydro unit.........................................................................................................................................................................13
3-2 Outdoor Unit...................................................................................................................................................................21
4. Troubleshooting............................................................................................................................................................. 37
4-1 Wired remote controller.............................................................................................................................................37
4-2 Troubleshooting by symptoms ..............................................................................................................................40
4-2-1 Communication error after finishing Tracking ......................................................................................40
4-2-2 EEPROM circuit failure.......................................................................................................................................41
4-3 Hydro unit(Mono)........................................................................................................................................................42
4-3-1 EEPROM error .....................................................................................................................................................42
4-3-2
:
Error due to abnormal data of Wired remote controller thermistor value ............................43
4-3-3 : Error due to abnormal data of Water outlet thermistor value...............................44
4-3-4
: Error due to abnormal data of DHW tank thermistor value ...................................45
4-3-5 Water pump & flow switch OFF...................................................................................................................46
4-3-6 Water pump & flow switch ON ....................................................................................................................47
4-3-7 Hydro unit temperature sensor(open/short)........................................................................................48
4-3-8 Communication error after finishing Tracking(Hydro unit)............................................................49
4-4 Items to check before diagnostics .......................................................................................................................50
4-4-1 Test run mode and view mode....................................................................................................................50
4-4-2 Troubleshooting for outdoor unit..............................................................................................................51
RC160MHXGA_SM_E_34513A(1)_1~3.indd 1 

Contents
4-5 Troubleshooting by symptoms .............................................................................................................................53
4-5-1 Communication error after finishing tracking (E202)........................................................... 53
4-5-2 Time out (1min.) of communication error between MAIN PBA and INV. PBA (E203) ............ 54
4-5-3 Temperature sensor error (E221, E231, E251, E320 ) ...................................................................... 55
4-5-4 Fan error (E458, E475) ............................................................................................................................. 56
4-5-5 Compressor error (E461, E467) ............................................................................................................ 58
4-5-6 Current trip error (E462, E463) ............................................................................................................. 59
4-5-7 IPM(IGBT module) over current error (E464)................................................................................. 60
4-5-8 DC-link voltage under/over error (E466) ......................................................................................... 62
4-5-9 GAS leak error(E554) ................................................................................................................................ 63
4-5-10 The other errors....................................................................................................................................... 64
4-5-11 In case of heating at the cooling mode or coolin g at the heating mode....................... 65
4-5-12 Outdoor unit is not powered on – Initial diagnosis.................................................................. 67
4-5-13 Outdoor unit power supply error..................................................................................................... 68
5. PCB Diagram
.................................................................................................................................................................... 69
5-1 Hydro unit ........................................................................................................................................................ 69
5-2 Outdoor Unit................................................................................................................................................... 70
5-3 Parts List........................................................................................................................................................... 75
6. Wiring Diagram ................................................................................................................ 89
6-1 Hydro unit ........................................................................................................................................................ 89
6-2 Outdoor Unit................................................................................................................................................... 90
7. Schematic Diagram ........................................................................................................ 92
7-1 Hydro unit ........................................................................................................................................................ 92
7-2 Outdoor Unit................................................................................................................................................... 94
8. Reference Sheet ............................................................................................................... 95
8-1 Index for Model Name ................................................................................................................................ 95
8-1-1 Outdoor Unit ......................................................................................................................................... 95
8-2 Refrigerant Circuit Diagram .......................................................................................................................96
RC160MHXGA_SM_E_34513A(1)_1~3.indd 2 

Samsung Electronics 3
1. Precautions
1-1 Precautions for the Service
O Use the standard parts when replacing the electric parts.
– Confirm the model name, rated voltage, rated current of the electric parts.
O When repairing the equipment, connection of the harness parts must be firm and solid.
– A loose connection may cause noise or other malfunction.
O When assembling and disassembling the equipment while it is laid down, lay it on soft cloth.
– Otherwise it may scratch the back of the exterior of the product.
O Remove dust or dirt completely from the housing block, wiring block and service parts during repair.
– This helps prevent the danger of fire caused by tracking or short circuit.
O Fasten the valve caps of service valves and charging valves of outdoor unit as much as possible using adjustable wrenches.
O Check the status of the components’ assembly after repair service.
– The status must be the same as before the repair service.
1-2 Precautions related to static electricity and PL
OThe PCB power supply block is susceptible to static electricity. Therefore, care must be taken during repair or measuring
while the power is on.
– Wear insulation gloves for PCB repair or measuring.
OCheck whether the installation location is at least two meters away from other electronic products such as TV, video, or
audio.
– Otherwise, the video quality might be degraded or noise might be generated.
ODo not let end users repair the products themselves.
– Unauthorized disassembly might cause electric shock or fire.
RC160MHXGA_SM_E_34513A(1)_1~3.indd 3 

Precautions
4Samsung Electronics
1-3 Precautions for the Safety
ODo not pull any electric wires and do not touch an auxiliary power switch with a wet hand.
– There is a danger of electric shock or fire.
OIn case any wire or power plug has been damaged, replace it to eliminate any possible danger.
ODo not bend the power cord by force and do not put any heavy object on the power cord.
– There is a danger of electric shock or fire.
ODo not use multi socket.
– There is a danger of electric shock or fire.
OGround the product if necessary.
– Be sure to ground the product if there is any danger of electric leakage due to water or moisture.
OBe sure to turn off the auxiliary power switch or pull out the power plug during replacement or repair of electric parts.
– There is a danger of electric shock.
OIn case the product will not be in use for a long time, the battery of remote control should be kept separately.
– Leakage of inside fluid can cause break down of remote control.
O
The installation must be done by the manufacturer or its service agent or a similar qualified person in order to avoid a hazard.
– Installation by an unqualified person may cause a water leakage, electric shock or fire and so on.
O The electric work must be done by service agent or similarly qualified persons according to national wiring regulations and use
only rated cable.
– If the capacity of the power cable is insufficient or electric work is not properly completed, electric shock or fire may occur.
O Use only rated parts and tools.
– If you don't use the rated parts and tools, it can cause trouble with the air conditioner and bring about injury.
O If any gas or impurities except R410A refrigerant come into the refrigerant pipe, serious problem may occur and it may cause
injury.
O Leak test must be done using only Nitrogen(NO 2 )gas.
O R410A refrigerant is used for EHS.
– When using R410A, moisture or foreign substances may affect to the capacity and reliability of the product.Safety precautions
must be taken when installing the refrigerant pipe.
– The design pressure of the unit is 4.1MPa. Select appropriate material and thickness according to the regulations.
– R410A is a quasi-azeotrope of two refrigerants.
Make sure to charge liquid one when adding refrigerant.
If you charge gaseous refrigerant, it may affect the capacity and reliability of the product as a result of change formation of the
refrigerant.
RC160MHXGA_SM_E_34513A(1)_1~3.indd 4 

Precautions
Samsung Electronics 5
1-4 Precautions for handling a system containing refrigerants
All system containing refrigerants shall be removed under regional regulations prior to the disposal to
prevent the potential health and environmental consequences.
OHarmful for human body
– When emitted liquid refrigerant contacts human body, contacted area may get frostbite, blister or become numb.
If refrigerant leaks in airtight area, lack of oxygen may cause suffocation. When refrigerant is heated, it may generate harmful gas.
OPrecautions for handling container
– Do not apply shock or heat to the refrigerant container.
1-5 Precautions for the brazing
OClear any dangerous or inflammable materials in surrounding environment.
OMake sure to empty the remaining refrigerant in the product or pipe before brazing.
– Brazing with the refrigerant still remaining in the product or pipe may cause poor result and generate harmful gas. Furthermore,
pressure of the refrigerant may increase and cause damage to the leaking part. This may lead harmful refrigerant and oil to spurt
out which can be dangerous for service personnel.
OUse nitrogen gas to get rid of the oxide forming during brazing.
– Using other type of gas may cause damage to the product or the exterior.
1-6 Precautions for charging refrigerants
OAdd quantity of the refrigerant using a scale and perform a test operation with S-net.
– Product performance may decrease if you add excessive amount of refrigerant.
ODo not charge refrigerants while heating the container up.
– The container may get damaged by the heat and result in explosions.
ODo not operate the product without pressure switch(for product protection) and sensor.
– If there are any internal blockage, high refrigerant pressure increase may damage the product or exterior.
RC160MHXGA_SM_E_34513A(1)_1~3.indd 5 

6Samsung Electronics
2. General Overview
2-1 Features of the System
POWER SAVING
EHS(Eco Heating System) considers the trend in air conditioner use. It optimizes the
energy efficiency of loads ranging from partial to full. It achieves an excellent energy
effect for the users of the air conditioner.
Samsung patented compressor
Samsung has been researching and developing compressors since the 70's.
It has developed power saving compressors for more than thirty years.
The EHS(Eco Heating System) compressor adopts a double-rotor BLDC compressor with permanent magnets made by Samsung.
Electricity for the compressor rotor is obtained from a neodium-iron-boron permanent magnetic material (boron magnet can attract iron
material weighing 1000 times its own weight.) It strengthens the rotary moment of the compressor to maximize the entire efficiency of the
compressor.
BLDC electricity
“Permanent magnet,” strong magnetic rotor
Double rotor compression cylinder
Nd-Fe-B Neodium-Iron-Boron magnet
SAMSUNG's double-rotor compressor has the upper and lower rotors designed symmetrically.
The double rotor in symmetry can remove vibrations caused by the eccentric design of the cylinder.
2 rotors balancing the rotary moment
Centered symmetry
Upper rotor
Permanent magnet rotor
Lower cylinder
Upper cylinder
Lower rotor
High efficiency heat exchanger
EHS(Eco Heating System) uses new multiple-teeth screw pipes with a diameter of 8 mm to improve the heat exchangeability of the pipe by
30.8%.
The water-friendly aluminum foil in the heat exchanger uses the G-fin patent design to improve the efficiency of heat exchange by 13%.
DC fan electricity
The EHS(Eco Heating System) outdoor machine uses DC fan electricity. The rotational speed of electricity is 100 RPM to 1050 RPM with
step-free control. The electrical efficiency is improved by about 33% compared to AC electricity.
Efficiency
Multiple-teeth screw pipes General screw pipes
RC160MHXGA_SM_E_34513A(1)_1~3.indd 6 

General Overview
Samsung Electronics 7
Quiet night
EHS(Eco Heating System)'s outdoor machine can be set to quiet nighttime operation mode. The outdoor machine executes quiet operation
(sleeping mode) after six hours. After 12 hours, it returns to the previous mode automatically.
Environment load
change curves
Temperature change curve
Max temperature
Noise change curve
(sleeping mode) After 6 hours
Start Stop
1 hour of quiet operation
2-1-1 Key features of the EHS(SPLIT)
Q Easy installation
No need to install the refrigerant lines in the system. Users can run the system after connecting water pipes only.
Q Integrated Heating & Cooling system
Plate Heat exchanger is a integral part in heating & cooling system. For user’s convenience, PHE is integrated into the system.
This concept will help space saving and lower costs for pipe line reduction.
Q Running Costs-Reduction of Up to 33.3%
Samsung EHS, known for its world class efficiency (12kW floor heating system with COP of 4.60), can reduce 33.3% of your run-
ning costs as compared to a gas boiler.
Q High Performance at Low Temperature
Samsung EHS is made up of an inverter compressor optimally operated according to the outdoor temperature, offering heating
performance of 90% at -10°C and reliable frost protection at -20°C.
RC160MHXGA_SM_E_34513A(1)_1~3.indd 7 

8Samsung Electronics
2-2 Product Specifications
2-2-1 Outdoor Unit
Item
AEX160EDGHA AEX140EDGHA AEX125EDGHA
3phase 16kW 3phase 14kW 3phase 12.5kW
Image Outdoor unit
Capacity (95%↑)
Heating 1 W 16,000 14,000 12,500
Heating 2 W 15,000 13,000 11,500
Cooling 1 W 17,400 16,200 15,000
Cooling 2 W 13,300 12,300 11,300
POWER CONSUMPTION
(110%↓)
Heating 1 W 3,720 3,110 2,660
Heating 2 W 4,410 3,710 3,195
Cooling 1 W 6,000 5,150 4,350
Cooling 2 W 5,420 4,730 4,110
Running Current
(110%↓)
Heating 1 A 5.8 4.9 4.2
Heating 2 A 6.9 5.8 5.0
Cooling 1 A 9.4 8.1 6.8
Cooling 2 A 8.5 7.4 6.4
Power Supply Ø,V,Hz 3 / 380-415 / 50 3 / 380-415 / 50 3 / 380-415 / 50
COP/EER (95%↑)
Heating 1 W/W 4.30 4.50 4.70
Heating 2 W/W 3.40 3.50 3.60
Cooling 1 W/W 2.90 3.15 3.45
Cooling 2 W/W 2.45 2.60 2.75
Refrigerant Charge g, type 2,800 R410A 2,800 R410A 2,800 R410A
Set Dimensions
(W*H*D)
Net mm 940X1,420X330 940X1,420X330 940X1,420X330
Gross mm 995X1,548X426 995X1,548X426 995X1,548X426
Weight (Net/Gross) kg 98 / 108 98 / 108 98 / 108
Noise Cooling Cond.1/2 dB(A) 61 60 59
Heating Cond.1/2 dB(A) 60 59 59
Operation
range
Cooling ℃10~46 10~46 10~46
Heating ℃-20~35 -20~35 -20~35
RC160MHXGA_SM_E_34513A(1)_1~3.indd 8 

General Overview
Samsung Electronics 9
Product Specifications (cont.)
Item AEX160EDEHA AEX140EDEHA AEX125EDEHA AEX100EDEHA AEX060EDEHA
1phase 16kW 1phase 14kW 1phase 12.5kW 1phase 10kW 1phase 5.8kW
Image Outdoor unit
Capacity (95%↑)
Heating 1 W 16,000 14,000 12,500 10,000 5800
Heating 2 W 15,000 13,000 11,500 9,500 5300
Cooling 1 W 17,400 16,200 15,000 9,100 6670
Cooling 2 W 13,300 12,300 11,300 7,100 4900
POWER
CONSUMPTION
(110%↓)
Heating 1 W 3,720 3,110 2,660 2,220 1220
Heating 2 W 4,410 3,710 3,195 2,750 1490
Cooling 1 W 6,000 5,150 4,350 2,890 1905
Cooling 2 W 5,420 4,730 4,110 2,730 1810
Running Current
(110%↓)
Heating 1 A 16.3 13.7 11.7 9.7 5.7
Heating 2 A 19.4 16.3 14.0 12.1 7.0
Cooling 1 A 26.4 22.6 19.1 12.7 8.8
Cooling 2 A 23.8 20.8 18.1 12.0 8.1
Power Supply Ø,V,Hz 1 / 220-240 / 50 1 / 220-240 / 50 1 / 220-240 / 50 1 / 220-240 / 50 1 / 220-240 / 50
COP/EER (95%↑)
Heating 1 W/W 4.30 4.50 4.70 4.50 4.75
Heating 2 W/W 3.40 3.50 3.60 3.45 3.56
Cooling 1 W/W 2.90 3.15 3.45 3.15 3.5
Cooling 2 W/W 2.45 2.60 2.75 2.60 2.7
Refrigerant Charge g, type 2,800 R410A 2,800 R410A 2,800 R410A 2,000 R410A 1,200 R410A
Set Dimensions
(W*H*D)
Net mm 940X1,420X330 940X1,420X330 940X1,420X330 940X998X330 880X638X310
Gross mm 995X1,548X426 995X1,548X426 995X1,548X426 995X1,096X426 1024X750X414
Weight
(Net/Gross) kg 98 / 108 98 / 108 98 / 108 74 / 82 48 / 53
Noise Cooling Cond.1/2 dB(A) 61 60 59 59 54
Heating Cond.1/2 dB(A) 60 59 59 57 53
Operation
range
Cooling ℃10~46 10~46 10~46 10~46 10~46
Heating ℃-20~35 -20~35 -20~35 -20~35 -20~35
5&0+;*$B60B(B$BaLQGG 

General Overview
10 Samsung Electronics
NO DIVISION UNIT AEN160YDGHA AEN160YDEHA AEN080YDEHA
1 POWER SOURCE V/㎐3P, 380-415~, 50Hz 1P, 220-240V~, 50Hz 1P, 220-240V~, 50Hz
2"POWER CONSUMPTION
(Pump 3 Step, 110%↓)" W151 151 132
3"Running Current
(Pump 3 Step, 110%↓)" A0.234 0.691 0.604
4"MAX Current
(Pump 3 Step+Backup Heater 2 Step)" A 9.55 28.2 18.9
5 Sound Pressure Cooling dB(A) 35 35 35
Heating dB(A) 35 35 35
6"Dimensions
(WxHxD)"
Net mm 850 x 510 x 315 850 x 510 x 315 850 x 510 x 315
Gross mm 1024 x 412 x 564 1024 x 412 x 564 (1024x426x564)
7 Weight Net kg 48 48 45
Gross kg 58 58 55
8"Connecting Pipe
[Refrigerant]"
Liquid Inch 3/8" 3/8" 3/8"
Gas Inch 5/8" 5/8" 5/8"
9"Connecting Pipe
[Water]"
Liquid Inch BSPP male 1 1/4" BSPP male 1 1/4" BSPP male 1 1/4"
Gas Inch BSPP male 1 1/4" BSPP male 1 1/4" BSPP male 1 1/4"
10 Remote Controller CODE DB93-09348A DB93-09348A DB93-09348A
11 E LCB for Hydro unit - SG-52NH, 40A SG-52NH, 40A SG-52NH, 30A
for DHW tank - SG-52NH, 20A SG-52NH, 20A SG-52NH, 20A
12 Magnet Contactor Spec. - CMC-25C,2P, 3EA, 25A CMC-25C,2P, 3EA, 25A CMC-25C,2P, 3EA, 25A
13 Water Pump
Model name - RS 25/8 RS 25/8 RS 25/7
Input W 200 200 180
Running Current A 0.76 0.76 0.76
14 Heat Exchanger Type - Brazing plate Brazing plate Brazing plate
No. of Plate ea 72 72 48
15 Electric Heater
Type - Sheath Sheath Sheath
Input power W 6,000 6,000 4,000
Thermostat ℃65 65 65
Thermal Fuse ℃94 94 94
16 Flow Switch Set Point LPM 16 ± 1.5 16 ± 1.5 12 ± 1.5
17 "Expansion
Vessel"
Type - SBR, diaphram SBR, diaphram SBR, diaphram
Volume Liter 8.0 8.0 8.0
18 Pressure Relief valve Size Inch BSPP male 1/2" BSPP male 1/2" BSPP male 1/2"
Relief Pressure bar 2.9 2.9 2.9
19 Air purge valve Size Inch BSPP male 3/8" BSPP male 3/8" BSPP male 3/8"
20 Service valve
(附件） Size Inch BSPP male 1 1/4" BSPP male 1 1/4" BSPP male 1 1/4"
21 Total Water Volume Liters 5.5 5.5 5.0
RC160MHXGA_SM_E_34513A(1)_1~3.indd 10 

Samsung Electronics 11
Item Description Code No. Q’ty Remark
Cap Drain DB63-10355C 3
Essential Offer
(Outdoor Unit)
Drain Plug DB67-00806A 1
Rubber Leg DB73-20134A 4
ASSY TUBE MUFFLER DB96-18020A 1
ASSY-INSTALLATION
MANUAL (Outdoor Unit) DB68-03207A 1
ASSY-USER
MANUAL DB68-03238A 1
Essential Offer
(Hydro unit)
ASSY-INSTALLATION
MANUAL DB68-03239A 1
Pattern sheet DB98-32365A 1
service valve DB96-13833A/B 1
wall mounting bracket DB61-04402A 1
remote controller wire DB93-08797B 1
ASSY THEMISTOR-WATER TANK DB95-04326A 1
Cover controller DB63-02634A 1
2-3 Specifications of optional items
2-3-1 Accessories
RC160MHXGA_SM_E_34513A(1)_1~3.indd 11 

12 Samsung Electronics
QHand Tool sets
3. Disassembly and Reassembly
Item Remark
+Screw Driver
Adjustable wrench
–Screw Driver
Nipper
Electric Motion Driver
L-Wrench
Torque Lench
Latchet Lench
RC160MHXGA_SM_E_34513A(1)_1~3.indd 12 

Samsung Electronics 13
No Parts Procedure Remark
1 Panel 1) Remove 4 cover screws from the Hydro Unit.
(Use + Screw Driver)
2 Controller
&
Manometer
1) Remove 3 screws from it.
(Use + Screw Driver)
2) Remove pressure sensor by adjustable wrench.
(Use adjustable wrench-230kgf·cm)
3) Pull the manometer out.
4) Pull the LED display up and out.
3-1 Hydro Unit
QAEN160YD䭑/AEN080YD䭑
Be sure that the power switch is in the “OFF” and the power source cord shall be unplugged prior to disassembly and reassembly works.
RC160MHXGA_SM_E_34513A(1)_1~3.indd 13 

Disassembly and Reassembly
14 Samsung Electronics
No Parts Procedure Remark
5) Remove the connector from the PCB board.
6) Remove the upper case of the controller.
7) Remove 5 screws. Set a side the drain pan
and hydro unit.
RC160MHXGA_SM_E_34513A(1)_1~3.indd 14 

Disassembly and Reassembly
Samsung Electronics 15
No Parts Procedure Remark
3 Water Pump 1) Remove 4 screws. (Use + Screw Driver)
2) Remove the cabi-control top.
3) Remove the flow switch and connector.
4) Remove a pipe from the backup Heater.
(Use adjustable wrench-380kgf·cm)
Use the Torque Wrench when you
assemble it.
RC160MHXGA_SM_E_34513A(1)_1~3.indd 15 

Disassembly and Reassembly
16 Samsung Electronics
No Parts Procedure Remark
5) After removing insulation material, remove
the Thermostat.
6) Remove 2 screws. (Use + Screw Driver)
7) Remove 2 screws. (Use + Screw Driver)
8) Pull the water pump & pipes up, out.
RC160MHXGA_SM_E_34513A(1)_1~3.indd 16 

Disassembly and Reassembly
Samsung Electronics 17
No Parts Procedure Remark
4 Expansion Vessle 1) Remove the tube of the expansion vessel
and the backup heater by adjustable wrench.
(Use adjustable wrench-150kgf·cm)
Use the Torque Wrench when you
assemble it.
2) Remove 2 screws. (Use + Screw Driver)
3) After removing the nut. Pull the bracket out.
4) Pull the expansion vessel up, out.
5 Plate Heat
Exchanger
1) Remove 4 insulations.
RC160MHXGA_SM_E_34513A(1)_1~3.indd 17 

Disassembly and Reassembly
18 Samsung Electronics
No Parts Procedure Remark
2) Remove 4 Thermostats.
3) Remove the Thermostat conector on the
PCB of the Control box.
4) Remove the pipe from the Backup Heater.
(Use adjustable wrench-380kgf·cm)
Use the Torque Wrench when you
assemble it.
5) Remove 6 screws. (Use + Screw Driver)
6) Pull the PHE out of the unit.
RC160MHXGA_SM_E_34513A(1)_1~3.indd 18 

Disassembly and Reassembly
Samsung Electronics 19
No Parts Procedure Remark
6 Control Box 1) Remove 4 Thermostats. Set a side the terminal
block and PBA case. (Use + Screw Driver)
2) Remove Conectors.
3) Remove 3 screws. (Use + Screw Driver)
4) Pull the cabi-control bottom out by pushing
as indicated diretion.
5&0+;*$B60B(B$BaLQGG 
