Samsung AM***KN4DEH User manual

Air conditioner
Installation manual
AM✴✴✴KN4DEH
•Thank you for purchasing this Samsung air conditioner.
•Before operating this unit, please read this manual carefully and retain it for future
reference.
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 1 2016-02-03 오전 11:14:43

2
English
Contents
Safety Information 3
Installation Procedure 5
Step 1 Checking and preparing accessories
Step 2 Choosing the installation location
Step 3 Optional: Insulating the body of the indoor unit
Step 4 Installing the indoor unit
Step 5 Purging inert gas from the indoor unit
Step 6 Cutting and flaring the pipes
Step 7 Connecting the assembly pipes to the refrigerant pipes
Step 8 Performing the gas leak test
Step 9 Insulating the refrigerant pipes
Step 10 Installing the drain hose and drain pipe
Step 11 Performing the drainage test
Step 12 Connecting the power and communication cables
Step 13 Setting the indoor unit addresses and the installation options
Appendix 40
Troubleshooting
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 2 2016-02-03 오전 11:14:43

3
English
Safety Information
WARNING
• Hazards or unsafe practices that may result in severe
personal injury or death.
CAUTION
• Hazards or unsafe practices that may result in minor
personal injury or property damage.
• Carefully follow the precautions listed below because
they are essential to guarantee the safety of the
equipment.
WARNING
• Always disconnect the air conditioner from the power
supply before servicing it or accessing its internal
components.
• Verify that installation and testing operations are
performed by qualified personnel.
• Verify that the air conditioner is not installed in an
easily accessible area.
General information
WARNING
• Carefully read the content of this manual before
installing the air conditioner and store the manual in
a safe place in order to be able to use it as reference
after installation.
• For maximum safety, installers should always
carefully read the following warnings.
• Store the operation and installation manual in a safe
location and remember to hand it over to the new
owner if the air conditioner is sold or transferred.
• This manual explains how to install an indoor unit
with a split system with two SAMSUNG units. The use
of other types of units with different control systems
may damage the units and invalidate the warranty.
The manufacturer shall not be responsible for
damages arising from the use of non compliant units.
• This product has been determined to be in compliance
with the Low Voltage Directive (2006/95/EC), and the
Electromagnetic Compatibility Directive (2004/108/
EC) and the Machinery Directive (2006/42/EC) of the
European Union.
• The manufacturer shall not be responsible for damage
originating from unauthorized changes or the
improper connection of electric and requirements set
forth in the “Operating limits” table, included in the
manual, shall immediately invalidate the warranty.
• The air conditioner should be used only for the
applications for which it has been designed: the
indoor unit is not suitable to be installed in areas
used for laundry.
• Do not use the units if damaged. If problems occur,
switch the unit off and disconnect it from the power
supply.
• In order to prevent electric shocks, fires or injuries,
always stop the unit, disable the protection switch
and contact SAMSUNG’s technical support if the unit
produces smoke, if the power cable is hot or damaged
or if the unit is very noisy.
• Always remember to inspect the unit, electric
connections, refrigerant tubes and protections
regularly. These operations should be performed by
qualified personnel only.
• The unit contains moving parts, which should always
be kept out of the reach of children.
• Do not attempt to repair, move, alter or reinstall the
unit. If performed by unauthorized personnel, these
operations may cause electric shocks or fires.
• Do not place containers with liquids or other objects
on the unit.
• All the materials used for the manufacture and
packaging of the air conditioner are recyclable.
• The packing material and exhaust batteries of the
remote controller(optional) must be disposed of in
accordance with current laws.
• The air conditioner contains a refrigerant that has
to be disposed of as special waste. At the end of its
life cycle, the air conditioner must be disposed of in
authorized centres or returned to the retailer so that
it can be disposed of correctly and safely.
Safety Information
Safety Information
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 3 2016-02-03 오전 11:14:43

4
Safety Information
English
Safety Information
Installing the unit
WARNING
IMPORTANT: When installing the unit, always remember
to connect first the refrigerant tubes, then the electrical
lines.
• Always disassemble the electric lines before the
refrigerant tubes.
• Upon receipt, inspect the product to verify that
it has not been damaged during transport. If the
product appears damaged, DO NOT INSTALL it and
immediately report the damage to the carrier or
retailer (if the installer or the authorized technician
has collected the material from the retailer.)
• After completing the installation, always carry out a
functional test and provide the instructions on how to
operate the air conditioner to the user.
• Do not use the air conditioner in environments with
hazardous substances or close to equipment that
release free flames to avoid the occurrence of fires,
explosions or injuries.
• Our units should be installed in compliance with the
spaces shown in the installation manual, to ensure
accessibility from both sides and allow repairs
or maintenance operations to be carried out. The
unit’s components should be accessible and easy to
disassemble without endangering people and objects.
For this reason, when provisions of the installation
manual are not complied with, the cost required to
access and repair the units (in SAFETY CONDITIONS,
as set out in prevailing regulations) with harnesses,
ladders, scaffolding or any other elevation system
will NOT be considered part of the warranty and will
be charged to the end customer.
Power supply line, fuse or circuit
breaker
WARNING
• Always make sure that the power supply is compliant
with current safety standards. Always install the air
conditioner in compliance with current local safety
standards.
• Always verify that a suitable grounding connection is
available.
• Verify that the voltage and frequency of the power
supply comply with the specifications and that the
installed power is sufficient to ensure the operation
of any other domestic appliance connected to the
same electric lines.
• Always verify that the cut-off and protection switches
are suitably dimensioned.
• Verify that the air conditioner is connected to the
power supply in accordance with the instructions
provided in the wiring diagram included in the
manual.
• Always verify that electric connections (cable entry,
section of leads, protections…) are compliant with
the electric specifications and with the instructions
provided in the wiring scheme. Always verify that all
connections comply with the standards applicable to
the installation of air conditioners.
• Devices disconnected from the power supply should
be completely disconnected in the condition of
overvoltage category.
CAUTION
Make sure that you earth the cables.
• Do not connect the earth wire to the gas pipe, water
pipe, lighting rod or telephone wire. If earthing is not
complete, electric shock or fire may occur.
Install the circuit breaker.
• If the circuit breaker is not installed, electric shock or
fire may occur.
Make sure that the condensed water dripping from the
drain hose runs out properly and safely.
Install the power cable and communication cable of
the indoor and outdoor unit at least 1m away from the
electric appliance.
Install the indoor unit away from lighting apparatus
using the ballast.
• If you use the wireless remote control, reception error
may occur due to the ballast of the lighting apparatus.
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 4 2016-02-03 오전 11:14:43

5
Installation Procedure
English
Installation Procedure
Installation Procedure
Do not install the air conditioner in following places.
• Place where there is mineral oil or arsenic acid. Resin
parts flame and the accessories may drop or water
may leak. The capacity of the heat exchanger may
reduce or the air conditioner may be out of order.
• The place where corrosive gas such as sulphuric acid
gas generates from the vent pipe or air outlet.
• The copper pipe or connection pipe may corrode and
refrigerant may leak.
• The place where there is a machine that generates
electromagnetic waves. The air conditioner may not
operate normally due to control system.
• The place where there is a danger of existing
combustible gas, carbon fibre or flammable dust.
• The place where thinner or gasoline is handled. Gas
may leak and it may cause fire.
Step 1 Checking and preparing
accessories
The following accessories are supplied with the indoor
unit. The type and quantity may differ, depending on the
specifications.
Insulation pipe (3 ea) Cable-tie (6 ea)
Drain hose (1 ea) Installation manual (1 ea)
Clamp (1 ea) User manual (1 ea)
Installation template (1 ea)
Step 2 Choosing the installation
location
Installation location requirements
• There must be no obstacles near the air inlet and
outlet.
• Install the indoor unit on a ceiling that can support its
weight.
• Maintain sufficient clearance around the indoor unit.
• Before installing the indoor unit, be sure to check
whether the chosen location is well-drained.
• The indoor unit must be installed such that it is
beyond public access and is not touchable by users.
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 5 2016-02-03 오전 11:14:44

6
Installation Procedure
Installation Procedure
English
Indoor unit dimensions
Category Ceiling type Open type
Front
1000
358
Ceiling opening dimension
960 (950 - 960)
Ceiling opening dimension
960 (950 - 960)
116
1050
883
Large
385
166
66
357
404
128
181 190
317
100 153 162
289
138
94
Small
385
166
66
357
404
128
181 190
233
100 153 162
205
138
94
Common
646
646
H1 →Large: 180, Small: 150
H2 →Large: 152, Small: 122
H2
942
787
80
ø100
H1
Ceiling type Open type
Model AM045KN4DEH*
AM056KN4DEH*
AM071KN4DEH*
AM090KN4DEH*
AM112KN4DEH*
AM128KN4DEH*
AM140KN4DEH*
Chassis Small Large
Net dimension
(W × D × H) mm 947 x 947 x 281 947 x 947 x 281 947 x 947 x 365
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 6 2016-02-03 오전 11:14:45

7
Installation Procedure
English
Net weight kg 21.0 21.0 24.0
Liquid pipe connection ø6.35 ø9.52 ø9.52
Gas pipe connection ø12.7 ø15.88 ø15.88
Drain hose connection mm Outer diameter : ø32, Inner diameter : ø26.5
Spacing requirements
A : 1500 mm or more
A
A
A
A
'H2' mm
Indoor unit
Obstruction
20 mm
1500 mm or more
10 mm
2500 mm or more
(Unit: mm)
Model AM045KN4DEH*
AM056KN4DEH*
AM071KN4DEH*
AM090KN4DEH*
AM112KN4DEH*
AM128KN4DEH*
AM140KN4DEH*
H2 261 261 345
CAUTION
• The indoor unit must be installed according to the
specified distances in order to permit accessibility
from each side, to guarantee correct operation,
maintenance, and repair of the unit.
The components of the indoor unit must be reachable
and removable under safe conditions for people and
the unit.
• Do not hold the discharge while carrying the indoor
unit to avoid the possibility of breakage.
• You must hold the hanger plate on the corner and
carry the indoor unit.
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 7 2016-02-03 오전 11:14:45

8
Installation Procedure
Installation Procedure
English
Step 3 Optional: Insulating the body
of the indoor unit
If you install a cassette type indoor unit on the ceiling
when temperature is over 27°C and humidity is over
80%, you must apply an extra 10 mm thick polyethylene
insulation or a similar type of insulation to the body of
the indoor unit.
Cut away the part where pipes are pulled out for the
insulating work.
A
Insulate the end of the pipe and some curved area by
using separate insulator.
NOTE
• A: Reference for the outer circumference of the unit
(When insulating the body of the indoor unit, use A as
the reference for its outer circumference.)
Indoor unit type and models Dimensions
All way cassette
type <S>
(947 x 947 x 281)
AM045KN4DEH*
AM056KN4DEH*
AM071KN4DEH*
AM090KN4DEH*
2610 x 130
All way cassette
type <L>
(947 x 947 x 365)
AM112KN4DEH*
AM128KN4DEH*
AM140KN4DEH*
2610 x 215
Step 4 Installing the indoor unit
When deciding on the location of the air conditioner the
following restrictions must be taken into account.
1 Determine the positions of the pipe and the drain
hose hole as shown in the pattern sheet, and drill the
hole with an inner diameter of 14 mm.
NOTE
• Since the diagram is made of paper, it may shrink
or stretch slightly due to temperature or humidity.
For this reason, before drilling the holes, be sure
to maintain the correct dimensions between the
markings.
2 Insert bolt anchors, use existing ceiling supports or
construct a suitable support as shown in figure.
Concrete
Hole in anchor
Hole in plug
Suspension bolt (M10) - eld supply
Insert
3 Install the suspension bolts, depending on the ceiling
type.
Ceiling support
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 8 2016-02-03 오전 11:14:46

9
Installation Procedure
English
CAUTION
• Make sure that the ceiling is strong enough to support
the weight of the indoor unit. Before hanging the
unit, test the strength of each attached suspension
bolt.
• If the length of the suspension bolt is more than 1.5
m, you are required to prevent vibration.
4 Screw eight nuts and washers to the suspension bolts,
making space for hanging the indoor unit.
CAUTION
• You must install all of the suspension rods.
• It is important to leave sufficient space in the false
ceiling to allow access for maintenance or repairs to
the drainage pipe connection, the refrigerant pipe
connection, or to remove the unit if necessary.
5 Hang the indoor unit to the suspension bolts between
two nuts. Screw the nuts to suspend the unit. Cut a
pad stopper and place it on the bracket at this time
1
2
2
6 Adjust the unit to the appropriate position, taking into
account the installation area for the front panel.
• Place the pattern sheet on the indoor unit.
• Adjust the space between the ceiling and the
indoor unit by using a dimension gauge.
• Fix the indoor unit securely after adjusting the
level of the unit by using a leveller.
• Remove the pattern sheet and install the front
panel.
11.5 mm
Indoor unit
Ceiling
Gauge of dimensions
Step 5 Purging inert gas from the
indoor unit
The indoor unit comes with nitrogen gas (inert gas)
charged at the factory. Therefore, all inert gas must be
purged before connecting the assembly piping.
Unscrew the pinch pipe at the end of each refrigerant
pipe.
Liquid side
Gas side
Insulator
NOTE
• To prevent dirt or foreign objects from getting into
the pipes during installation, do not remove the pinch
pipe completely until you are ready to connect the
piping.
Step 6 Cutting and flaring the pipes
1 Make sure that you have the required tools available:
pipe cutter, reamer, flaring tool, and pipe holder.
2 If you wish to shorten the pipes, cut them with a pipe
cutter, ensuring that the cut edge remains at a 90°
angle to the side of the pipe. Refer to the illustrations
below for examples of edges cut correctly and
incorrectly.
Pipe cutter
Pipe Oblique Rough Burr
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 9 2016-02-03 오전 11:14:46

10
Installation Procedure
Installation Procedure
English
3 To prevent any gas from leaking out, remove all burrs
at the cut edge of the pipe, using a reamer.
4 Slide a flare nut on to the pipe and modify the flare.
Pipe Flare
D
A
Flare
R 0.4 to 0.8 mm
D
L
90° ±2°
45° ±2°
Outer Diameter (D) Depth (A) Flare dimension (L)
Ø6.35 mm 1.3 mm 8.7 to 9.1 mm
Ø9.52 mm 1.8 mm 12.8 to 13.2 mm
Ø12.70 mm 2.0 mm 16.2 to 16.6 mm
Ø15.88 mm 2.2 mm 19.3 to 19.7 mm
Ø19.05 mm 2.2 mm 23.6 to 24.0 mm
5 Check that the flaring is correct, referring to the
illustrations below for examples of incorrect flaring.
Correct Inclined Damaged
Surface
Cracked Uneven
Thickness
Step 7 Connecting the assembly
pipes to the refrigerant pipes
There are two refrigerant pipes of different diameters :
• A smaller one for the liquid refrigerant.
• A larger one for the gas refrigerant. The inside of
copper pipe must be clean and has no dust.
1 Remove the pinch pipe on the pipes and connect the
assembly pipes to each pipe, tightening the nuts, first
manually and then with a torque wrench, a spanner
applying the following torque.
Torque
wrench
Flare nut
Spanner
Union
1
2
3
3
Outer Diameter (mm) Torque (N•m)
Ø6.35 14 to 18
Ø9.52 34 to 42
Ø12.70 49 to 61
Ø15.88 68 to 82
Ø19.05 100 to 120
(1 N•m=10kgf•cm)
NOTE
• If the pipes must be shortened, see Step 6 Cutting
and flaring the pipes on page 9.
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 10 2016-02-03 오전 11:14:47

11
Installation Procedure
English
2 Be sure to use an insulator thick enough to cover the
refrigerant tube to protect the condensate water on
the outside of the pipe falling onto the floor and to
improve the efficiency of the unit.
3 Cut off any excess foam insulation.
4 Make sure that there are no cracks or waves on the
bent area.
5 It would be necessary to double the insulation
thickness (10 mm or more) to prevent condensation
even on the insulator when if the installed area is
warm and humid.
6 Do not use joints or extensions for the pipes
connecting the indoor and outdoor units. The only
permitted connections are those for which the units
are designed.
CAUTION
• Connect the indoor and outdoor units using pipes
with flared connections (not supplied). For the lines,
use insulated, unwelded, degreased and deoxidized
copper pipe (Cu DHP type to ISO 1337 or UNI EN
12735-1), suitable for operating pressures of at least
4.2 MPa and for a burst pressure of at least 20.7
Mpa. Copper pipe for hydro-sanitary applications is
completely unsuitable.
• For sizing and limits (height difference, line length,
max. bends, refrigerant charge, etc.) see the outdoor
unit installation manual.
• All refrigerant connection must be accessible, in order
to permit either unit maintenance or removing it
completely.
• If the pipes require brazing, make sure that oxygen
free nitrogen (OFN) is flowing through the system.
• Nitrogen blowing pressure range is 0.02 to 0.05 MPa.
Step 8 Performing the gas leak test
To identify potential gas leaks on the indoor unit, inspect
the connection area of each refrigerant pipe using a leak
detector for R-410A.
Before recreating the vacuum and recirculating the
refrigerant gas, pressurize the whole system with
nitrogen (using a cylinder with a pressure reducer) at a
pressure above 4 MPa in order to immediately detect
leaks on the refrigerant fittings.
Made vacuum for 15 minutes and pressurising system
with nitrogen.
Liquid side
Gas side
Insulator
Step 9 Insulating the refrigerant
pipes
Once you have checked that there are no leaks in the
system, you can insulate the piping and hose.
1 To avoid condensation problems, place Acrylonitrile
Butadien Rubber separately around each refrigerant
pipe.
No gap
NBR
NOTE
• Always make the seam of pipes face upwards.
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 11 2016-02-03 오전 11:14:47

12
Installation Procedure
Installation Procedure
English
CAUTION
• The insulation has to be produced in full compliance
with European regulation EEC / EU 2037 / 2000
requiring the use of sheaths insulation without using
CFC and HCFC gases for health and the environment.
2 Wind insulating tape around the pipes and drain hose
avoiding compressing the insulation too much.
3 Finish wrapping insulating tape around the rest of the
pipes leading to the outdoor unit.
4 The pipes and electrical cables connecting the indoor
unit with the outdoor unit must be fixed to the wall
with suitable ducts.
Indoor unit
Insulation cover pipe
Insulation pipe
Be sure to overlap
the insulation.
CAUTION
• Install the insulation not to get wider and use the
adhesives on the connection part of it to prevent
moisture from entering.
• Wind the refrigerant pipe with insulation tape if it is
exposed to outside sunlight.
• Install the refrigerant pipe respecting that the
insulation does not get thinner on the bent part or
hanger of pipe.
• Add the additional insulation if the insulation plate
gets thinner.
Refrigerant pipe insulation
Hanger
Additional
insulation
a
a x 3
• Must fit tightly against body without any gap.
• All refrigerant connection must be accessible, in order
to permit either unit maintenance or removal.
5 Select the insulation of the refrigerant pipe.
• Insulate the gas side and liquid side pipe, noting
the insulation thickness that must differ according
to the pipe size.
• Standard: Less than an indoor temperature of
30°C, with humidity at 85%. If installing in a high
humidity environment, use one grade thicker
insulator by referring to the table below. If
installing in an unfavourable environment, use
thicker one.
• The heat-resistance temperature of the insulator
must be more than 120°C.
Pipe Pipe size
Insulation Type (Heating/Cooling)
Remarks
Standard
[30°C, 85%]
High humidity
[30°C, over 85%]
EPDM, NBR
Liquid
pipe
Ø6.35 to Ø9.52 9t ←
Internal temperature is
higher than 120°C
Ø12.7 to Ø50.80 13t ←
Gas pipe
Ø6.35 13t 19t
Ø9.52 to Ø25.40
19t
25t
Ø28.58 to Ø44.45 32t
Ø50.80 25t 38t
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 12 2016-02-03 오전 11:14:47

13
Installation Procedure
English
• When installing insulation in the places and
conditions below, use the same insulation that is
used for high humidity conditions.
<Geological condition>
High humidity locations such as shorelines, hot
springs, lake or riversides, and ridges (when part of
the building is covered by earth and sand)
<Operation purpose condition>
Restaurant ceiling, sauna, swimming pool etc.
<Building construction condition>
Ceilings frequently exposed to moisture and cooling
are not covered. For example, pipes installed at a
corridor of a dormitory and studio or near an exit
that opens and closes frequently.
Places (where the pipes are installed) that are highly
humid due to a lack of ventilation.
Step 10 Installing the drain hose and
drain pipe
1 Push the supplied drain hose as far as possible over
the drain socket.
2 Tighten the metal clamp as shown in the picture.
3 Wrap the supplied large sealing pad over the metal
clamp and drain hose to insulate and fix it with
clamps.
4 Insulate the complete drain piping inside the building
(field supply).
If the drain hose cannot be sufficiently set on a slope,
fit the hose with drain raising piping (field supply).
5 Push the drain hose up to insulation when connecting
the drain hose to drain socket.
Metal clamp Drain socket
Drain hose
Large seailng pad
Drain pipe
Be sure to bond the
drain hose and the
main pipe.
Drain hose
PVC Tube Joint
+ VP25 (OD: 32 mm, ID: 25 mm)
Drain pipe
CAUTION
Check that the indoor unit is level with the ceiling by
using the leveller.
• Install air ventilation to drain condensation smoothly.
Air ventilation
Ceiling
• If it is necessary to increase the height of the drain
pipe, install the drain pipe straight within 300 mm
from the drain hose port. If it is raised higher than
550 mm, there may be water leaks.
Band joint
300 mm
or less 20 mm or more
Drain hose
Ceiling
300 to 550 mm
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 13 2016-02-03 오전 11:14:48

14
Installation Procedure
Installation Procedure
English
• Do not give the hose an upward gradient beyond
the connection port. This will cause water to flow
backwards when the unit is stopped, resulting in
water leaks.
Under gradient
Ceiling
• Do not apply force to the piping on the unit side
when connecting the drain hose. The hose should not
be allowed to hang loose from its connection to the
unit. Fasten the hose to a wall, frame or other support
as close to the unit as possible.
Support pieces
1 to 1.5 m
1/100 or more
Ceiling
• Install horizontally.
Indoor unit
Be horizontal
Flexible hose
• Max. allowable aixs gap
Indoor unit
Max. 20 mm
• Max. allowable bending angle
Indoor unit
Max. 30˚
NOTE
• If a concentrated drain pipe is installed, refer to the
figure below.
Centralized horizontal drain
pipe
(more than 1/100 slope)
Main drain pipe
Full thread bolt hanger 1000 to 1500 mm
300 to
550 mm
200 mm
or more
Individual
air vent Main air vent
(must be installed)
• If 3 or more units are installed, install the main air
vent at the front of the farthest indoor unit from the
main drain pipe.
• To prevent water from flowing back to indoor units,
install an individual air vent at the top of each indoor
unit.
– The air vents should be T or 7 shaped to prevent
dust or foreign substances from entering.
– You may not need to install air vent if the
horizontal drain pipe is in proper slope.
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 14 2016-02-03 오전 11:14:49

15
Installation Procedure
English
Step 11 Performing the drainage test
1 Do a leak test at the connection part of the flexible
hose and the drain pipe:
a Connect a general hose to the connection part of
the flexible hose of the indoor unit, and pour in
some water.
Hose
Flexible hose
Water leakage
check part
b After pouring some water, reassemble the rubber
cap on the connection part of a flexible hose of
the indoor unit and firmly tighten it with a band
to prevent leakage.
c Check the leak test at the part where the adhesive
for the flexible hose and the drain pipe is used.
CAUTION
• The leak test must be performed for at least 24 hours.
2 Check the condensed water drainage:
a Pour about 2 litres of water into the indoor unit
drain pan as shown in the picture.
b When the electric cable connection is completed
• Turn on the indoor unit and outdoor unit.
• Operate in the Cool mode.
CAUTION
• Only in the Cool mode, you can check the correct
operation of the drain pump.
When the electric cable connection has not been
completed
• Remove the control box cover of the indoor unit.
• Connect the power supply (220V, 50 Hz) to the L
and N terminals.
• Reassemble the control box cover and turn on the
indoor unit.
CAUTION
• When the float switch is not detected due to
insufficient water on the drain pan, the drain
pump will not work.
• If the power supply is directly connected to the
L and N terminals, communication error message
might appear.
• After completing the drainage check, turn the
unit off and disconnect the power supply.
• Reassemble the control box cover.
c Check whether the drain pump works correctly.
d Check whether the drainage is performing
correctly at the end of the drain pipe.
e Check for leakage at the drain pipe and drain pipe
connection part.
f When leakage occurs, check whether the indoor
unit is level and check the drain hose connection
part, drainpipe connection part and drain pump
connection.
g When the drainage check is completed and the
condensed water remains on the drain pan,
remove the water.
Step 12 Connecting the power and
communication cables
Power and communication cable connection
• Before wiring work, you must turn off all power
source.
• Connect the power and communication cable among
the units within maximum length to set the voltage
drop under 10%.
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 15 2016-02-03 오전 11:14:49

16
Installation Procedure
Installation Procedure
English
• The auxiliary circuit breaker (ELCB, MCCB, ELB) should
be considered more capacity if many indoor units are
connected from one breaker.
• Connect F3, F4(for communication) to the
communication cable of the wired remote control.
• Tighten the electric wires with a proper tool within
the torque limit to connect and fix them firmly, and
then organize the wires to prevent outside pressure
being exerted on the covers and other parts. Failure
to do so may result in overheating, electric shock, and
fire.
Tightening torque (N•m)
M3.5 0.8 to 1.2
M4 1.2 to 1.8
• To protect the product from water and possible shock,
you should keep the power and the communication
cables of the indoor and outdoor units in the iron
pipe.
• Connect the power cable to the auxiliary circuit
breaker (ELCB, MCCB, ELB).
• Keep distances of 50mm or more between power
cable and communication cables.
• Power supply cords of parts of appliances for
outdoor use shall not be lighter than polychloroprene
sheathed flexible cord. (Code designation IEC:60245
IEC 57 / CENELEC: H05RN-F or IEC:60245 IEC 66 /
CENELEC: H07RN-F)
• Screws on terminal block must not be unscrewed with
thetorquelessthan12kgf•cm.
• When installing the indoor unit in a computer room,
use the double shielded (tape aluminum / polyester
braid + copper) cable of FROHH2R type.
F1 F2
1(L) 2(N)
F1 F2 F1 F2
F3 F4
1(L) 2(N) 1(L) 2(N)
MCCB
+ELB ELCB
or
Wired remote
control
Outdoor
unit
Indoor unit 1 Indoor unit 2 Indoor unit 3
Selecting the crimping terminal lug
1 Select the crimping terminal lug based on the norminal dimension of the power cable.
2 Cover the connection part of the power cable and crimping terminal lug to insulate it.
Silver solder
F E
L
D
d1
B
d2
t
B
2
R
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 16 2016-02-03 오전 11:14:49

17
Installation Procedure
English
Norminal
dimensions
for cable
(mm²)
Norminal
dimensions
for screw
(mm)
B D d1 E F L d2 t
Standard
dimension
(mm)
Allowance
(mm)
Standard
dimension
(mm)
Allowance
(mm)
Standard
dimension
(mm)
Allowance
(mm) Min. Min. Max.
Standard
dimension
(mm)
Allowance
(mm) Min.
1.5
46.6
± 0.2 3.4 +0.3
-0.2 1.7 ± 0.2 4.1 616 4.3 +0.2 00.7
4 8
2.5
46.6
± 0.2 4.2 +0.3
-0.2 2.3 ± 0.2 6 6 17.5 4.3 +0.2 00.8
48.5
4 4 9.5 ± 0.2 5.6 +0.3
-0.2 3.4 ± 0.2 6 5 20 4.3 +0.2 00.9
Specifications of the terminal blocks
AC power: M4 screw Communication: M3.5 screw
11
13
7.5 9.0
18
13.8
Power supply
(single phase) MCCB ELB
Min : 198V
Max : 242V XA XA, 30 mA
0.1 s
Power cable Earth cable Communication
cable
2.5 mm or more 2.5 mm² 0.75 to 1.5 mm²
Decide the power cable specification and maximum
length by formula 2.
1 Decide the capacity of ELB and MCCB by below
formula.
The capacity of ELB, MCCB X[A] = 1.25 X 1.1 X ΣAi
NOTE
• X : The capacity of ELB, MCCB
• ΣAi : Sum of rating currents of each indoor unit.
Rated currents
Model Rating current(A)
AM045KN4DEH* 0.18
AM056KN4DEH* 0.21
AM071KN4DEH* 0.25
AM090KN4DEH* 0.42
AM112KN4DEH* 0.41
AM128KN4DEH* 0.62
AM140KN4DEH* 0.75
2 Decide the power cable specification and maximum
length within 10% voltage drop among indoor units.
n
Coef×35.6×Lk
× ik) < 10% of input voltage[V]
∑ (
1000×Ak
k=1
NOTE
• Coef: 1.55
• Lk: Distance among each indoor unit[m], Ak: Power
cable specification[mm2]
• ik: Running current of each unit[A]
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 17 2016-02-03 오전 11:14:50

18
Installation Procedure
Installation Procedure
English
Example of Installation
TotalpowercablelengthL=100(m),Initialpull-incurrent=10[A],Runningcurrentofeachunits=1[A],Total10
indoor units were installed
or
10 [A]
ELCB
MCCB+ELB
9 [A] 1 [A]
0[m] 10[m] 20[m] 100[m]
Indoor unit 1 Indoor unit 2 Indoor unit 10
• Apply following equation.
n
Coef×35.6×Lk×ik
∑ ( ) < 10% of input voltage[V]
=1
1000×Ak
• Calculation
– Installing with 1 sort wire.
2.5 [mm2]2.5 [mm2]
-2.2 [V] -2.0 [V]
220 [V]
-(2.2+2.0+1.8+1.5+1.3+1.1+0.9+0.7+0.4+0.2)=-11.2 [V]
208.8 [V] : Applicable
Within 198V
to 242V
······· 2.5 [mm2] ·······
– Installing with 2 different sort wire.
4.0 [mm2]4.0 [mm2]
-1.4 [V] -1.2 [V]
220 [V]
-(1.4+1.2+1.8+1.5+1.3+1.1+0.9+0.7+0.4+0.2)=-10.5 [V]
209.5 [V] : Applicable
Within 198V
to 242V
······· 2.5 [mm2] ·······
Step 13 Setting the indoor unit
addresses and the installation options
You cannot set both of the indoor unit addresses and
the installation options in a batch: set both of them
respectively.
Common steps for setting the addresses and
options
AR-KH00E remote control (for 360 cassette only)
Temperature
button
Timer button
Wheel
Mode button
Setting the
option values
Entering the
mode for setting
the options
NOTE
• The remote control display may vary depending on
the model.
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 18 2016-02-03 오전 11:14:50

19
Installation Procedure
English
1 Enter the mode for setting the options:
a Remove the batteries from the remote control.
b While holding down the (Temp) and
(Timer) buttons simultaneously, insert the
batteries into the remote control.
c Make sure that you are entered to the mode for
setting the options:
2 Set the option values.
CAUTION
• The total number of available options are 24: SEG1 to
SEG24.
• Because SEG1, SEG7, SEG13, and SEG19 are the page
options used by the previous remote control models,
the modes to set values for these options are skipped
automatically.
• Set a 2-digit value for each option pair in the
following order: SEG2 and SEG3 →SEG4 and SEG5
→SEG6 and SEG8 →SEG9 and SEG10 →SEG11 and
SEG12 →SEG14 and SEG15 →SEG16 and SEG17 →
SEG18 and SEG20 →SEG21 and SEG22 →SEG23 and
SEG24
SEG1 SEG2 SEG3 SEG4 SEG5 SEG6
0XXXXX
SEG7 SEG8 SEG9 SEG10 SEG11 SEG12
1XXXXX
SEG13 SEG14 SEG15 SEG16 SEG17 SEG18
2XXXXX
SEG19 SEG20 SEG21 SEG22 SEG23 SEG24
3XXXXX
On (SEG1 to SEG12) Off (SEG13 to SEG24)
Take the steps presented in the following table:
Steps Remote control display
1 Set the SEG2 and SEG3 values:
a Set the SEG2 value by rotating the Wheel
counterclockwise until the value you want to set
appears on the remote control display. SEG2
b Set the SEG3 value by rotating the Wheel clockwise
until the value you want to set appears on the remote
control display.
SEG3
When you rotate the Wheel, values appear in the following order:
2 Press the (Mode) button. Cool and On appear on the remote control display.
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 19 2016-02-03 오전 11:14:51

20
Installation Procedure
Installation Procedure
English
Steps Remote control display
3 Set the SEG4 and SEG5 values:
a Set the SEG4 value by rotating the Wheel
counterclockwise until the value you want to set
appears on the remote control display. SEG4
b Set the SEG5 value by rotating the Wheel clockwise
until the value you want to set appears on the remote
control display.
SEG5
When you rotate the Wheel, values appear in the following order:
4 Press the (Mode) button. Dry and On appear on the remote control display.
5 Set the SEG6 and SEG8 values:
a Set the SEG6 value by rotating the Wheel
counterclockwise until the value you want to set
appears on the remote control display. SEG6
b Set the SEG8 value by rotating the Wheel clockwise
until the value you want to set appears on the remote
control display.
SEG8
When you rotate the Wheel, values appear in the following order:
6 Press the (Mode) button. Fan and On appear on the remote control display.
7 Set the SEG9 and SEG10 values:
a Set the SEG9 value by rotating the Wheel
counterclockwise until the value you want to set
appears on the remote control display. SEG9
b Set the SEG10 value by rotating the Wheel clockwise
until the value you want to set appears on the remote
control display.
SEG10
When you rotate the Wheel, values appear in the following order:
DVM360_AC_Indoor_IM_EU_Eng_EN.indb 20 2016-02-03 오전 11:14:52
