Samsung AR AVHZ Series User manual

Air conditioner
User manual
AR**AVHZ***
• Thank you for purchasing this Samsung air conditioner.
• Before operating this unit, please read this manual carefully and retain it for future reference.
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 1RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 1 2021-04-12 오후 4:31:182021-04-12 오후 4:31:18

2
English
Contents
Safety Information 4
Safety Information 4
At a Glance 11
Indoor Unit Overview 11
Display 11
Remote Control Overview 12
Replacing the remote control batteries 12
Remote Control Operation 13
Selecting an operation mode 13
To set the temperature • To adjust the fan speed • To adjust the airflow direction 14
Smart Features 15
Power Smart Features 15
Auto mode • Cool mode 15
Dry mode • Fan mode 16
Variety Smart Features 17
Fast function 17
Eco function 18
Quiet function • Beep function 19
Auto clean function 20
Display lighting function 22
Time scheduling 23
Timed on/ Timed off function 23
good'sleep function 24
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 2RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 2 2021-04-12 오후 4:31:182021-04-12 오후 4:31:18

3
English
Cleaning and Maintenance 25
Schedule 25
Cleaning 26
Appendix 28
Troubleshooting 28
Appendix 30
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic
accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste
at the end of theirworking life. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate these items from other types of waste and recycle them
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailerwhere they purchased this product, or their local
government office, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract.
This product and its electronic accessories should not be mixed with other commercial wastes for disposal.
Correct disposal of batteries in this product
This marking on the battery, manual or packaging indicates that the batteries in this product should not
be disposed of with other household waste at the end of theirworking life. Where marked, the chemical
symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference
levels in EC Directive 2006/66.
(Aplicável somente ao Brasil)
Pilhas e baterias, após seu uso, não devem ser jogadas em lixo comum. Para evitar riscos à saúde humana e
ao meio ambiente, realize o descarte ambientalmente adequado, em um Serviço Autorizado Samsung.
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 3RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 3 2021-04-12 오후 4:31:182021-04-12 오후 4:31:18

4
Safety Information
English
Safety InformationSafety Information
Safety Information
WARNING: Read This Manual
Read and follow all safety information and instructions before installation, use, or maintenance of this
appliance. Incorrect installation, use, or maintenance of this appliance can result in death, serious injury, or
property damage. Keep these instructions with this appliance. This manual is subject to change. For the latest
version, visit www.samsung.com.
Because the instructions in this manual covervarious models, the characteristics of your air conditioner may
differ slightly from those described. If you have any questions, please contact your service provider or visit
www.samsung.com.
Notices and notes
To make you aware of safety messages and highlighted information, we use the following notices and notes
throughout this manual:
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property damage.
IMPORTANT
Information of special interest
NOTE
Supplementary information that may be useful
Safety Information
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 4RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 4 2021-04-12 오후 4:31:182021-04-12 오후 4:31:18

5
English
Safety InformationSafety Information
The user and installer guides should be read carefully.
The user and installer guides should be read carefully.
FOR GENERAL
This appliance is not intended foruse by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible fortheir safety. Children
should be supervised to ensure that they do not play with the appliance.
FOR INSTALLATION
WARNING
Use a power cord with this product's power specifications or higher and use the power cord for this
appliance only. In addition, do not use an extension cord.
• Extending the power cord may result in electric shock or fire.
• Do not use an electric transformer. This may result in electric shock or fire.
• If the voltage/frequency/rated current condition is different, it may cause fire.
The installation of this appliance must be performed by a qualified technician orservice company.
• Failing to do so may result in electric shock, fire, explosion, problems with the product, or injury
and may also void warranty on the installed product.
Install an Isolation Switch next to the Air Conditioner (but not on the panels of the Air Conditioner)
and circuit breaker dedicated to the air conditioner.
• Failing to do so may result in electric shock or fire.
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 5RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 5 2021-04-12 오후 4:31:182021-04-12 오후 4:31:18

6
Safety Information
English
Safety InformationSafety Information
Fix the outdoor unit firmly so that the electric part of the outdoorunit is not exposed.
• Failing to do so may result in electric shock, fire, explosion, or problems with the product.
Do not install this appliance near a heater, or inflammable material. Do not install this appliance in a
humid, oily or dusty location, in a location exposed to direct sunlight and water (or rain). Do not install
this appliance in a location where gas may leak.
• This may result in electric shock or fire.
Never install the outdoor unit in a location such as on a high external wall where it could fall.
• If the outdoor unit falls, it may result in injury, death or property damage.
This appliance must be properly grounded. Do not ground the appliance to a gas pipe, plastic, water
pipe, or telephone line.
• Failing to do so may result in electric shock, fire, and explosion.
• Make sure to use a socket-outlet with ground.
CAUTION
Install your appliance on a level and hard floor that can support its weight.
• Failing to do so may result in abnormal vibrations, noise, or problems with the product.
Install the drain hose properly so that water drains correctly.
• Failing to do so may result in water overflowing and property damage. Avoid adding drain to
waste pipes as odours may arise in the future.
When installing the outdoor unit, make sure to connect the drain hose so that draining is performed
correctly.
• The water generated during heating by the outdoor unit may overflow and result in property
damage.
In particular, in winter, if a block of ice falls, it may result in injury, death or property damage.
Do not install the product in a place where thermo-hygrostat is needed (such as server room,
machinery room, computer room, etc.)
• Those places do not provide guaranteed operation condition of the product therefore
performance can be poor in these places.
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 6RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 6 2021-04-12 오후 4:31:182021-04-12 오후 4:31:18

7
English
Safety InformationSafety Information
FOR POWER SUPPLY
WARNING
When the circuit breakeris damaged, contact your nearest service centre.
Do not pull or excessively bend the power line. Do not twist or tie the power line. Do not hook the
power line over a metal object, place a heavy object on the powerline, insert the power line between
objects, or push the power line into the space behind the appliance.
• This may result in electric shock or fire.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
CAUTION
When not using the air conditioner for a long period of time or during a thunder/lightning storm, cut
the power at the circuit breaker.
• Failing to do so may result in electric shock or fire.
FOR USING
WARNING
If the appliance is flooded, please contact your nearest service centre.
• Failing to do so may result in electric shock or fire.
If the appliance generates a strange noise, a burning smell or smoke, cut off the power supply
immediately and contact the nearest service centre.
• Failing to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without touching
the power line. Do not touch the appliance or power line.
• Do not use a ventilating fan.
• A spark may result in an explosion or fire.
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 7RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 7 2021-04-12 오후 4:31:182021-04-12 오후 4:31:18

8
Safety Information
English
Safety InformationSafety Information
To reinstall the air conditioner, please contact your nearest service centre.
• Failing to do so may result in problems with the product, water leakage, electric shock, or fire.
• Delivery service for the product is not provided. If you reinstall the product in another location,
additional construction expenses and an installation fee will be charged.
• Especially, when you wish to install the product in an unusual location such as in an industrial
area or near the seaside where it is exposed to salt in the air, please contact your nearest service
centre.
Do not touch the circuit breakerwith wet hands.
• This may result in electric shock.
Do not turn the airconditioner off with the circuit breakerwhile it is operating.
• Turning the air conditioner off and then on again with the circuit breaker may cause a spark and
result in electric shock or fire.
After unpacking the air conditioner, keep all packaging materials well out of the reach of children, as
packaging materials can be dangerous to children.
• If a child places a bag over its head, it may result in suffocation.
Do not touch the airflow blade with your hands or fingers during heating.
• This may result in electric shock or burns.
Do not insert your fingers or foreign substances into the air inlet/outlet of the airconditioner.
• Take special care that children do not injure themselves by inserting their fingers into the
product.
Do not strike orpull the air conditionerwith excessive force.
• This may result in fire, injury, or problems with the product.
Do not place an object nearthe outdoor unit that allows children to climb onto the machine.
• This may result in children seriously injuring themselves.
Do not use this air conditioner for long periods of time in badly ventilated locations ornear infirm
people.
• Since this may be dangerous due to a lack of oxygen, open a window at least once an hour.
If any foreign substance such as water has entered the appliance, cut off the power supply and
contact the nearest service centre.
• Failing to do so may result in electric shock or fire.
Do not attempt to repair, disassemble, ormodify the appliance yourself.
• Do not use any fuse (such as copper, steel wire, etc.) other than the standard fuse.
• Failing to do so may result in electric shock, fire, problems with the product, or injury.
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 8RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 8 2021-04-12 오후 4:31:182021-04-12 오후 4:31:18

9
English
Safety InformationSafety Information
CAUTION
Do not place objects or devices underthe indoor unit.
• Water dripping from the indoor unit may result in fire or property damage.
Check that the installation frame of the outdoorunit is not broken at least once a year.
• Failing to do so may result in injury, death or property damage.
To prevent personal injury, make sure that you change the directions of the horizontal airflowblades
after stopping the movements of the vertical airflowblade. (In case of adjusting the horizontal airflow
manually)
Do not install the product in a ship or a vehicle (such as a campervan).
• Salt, vibration or other environmental factor may cause the product malfunction, electric shock or
fire.
Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted
cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
• This may result in electric shock, fire, problems with the product, or injury.
Do not operate the appliance with wet hands.
• This may result in electric shock.
Do not spray volatile material such as insecticide onto the surface of the appliance.
• As well as being harmful to humans, it may also result in electric shock, fire or problems with the
product.
Do not drink the water from the air conditioner.
• The water may be harmful to humans.
Do not hit, shake, drop, orattempt to disassemble the remote control.
When replacing the remote control batteries, keep them out of the reach of infants.
• If an infant eats batteries, contact a doctor immediately.
When replacing the remote control batteries, be careful not to get the battery fluid on yourskin.
• Battery fluid is harmful to humans.
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 9RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 9 2021-04-12 오후 4:31:182021-04-12 오후 4:31:18

10
Safety Information
English
Safety InformationSafety Information
Do not touch the pipes connected with the product.
• This may result in burns or injury.
Do not use this air conditioner to preserve precision equipment, food, animals, plants or cosmetics, or
for any other unusual purposes.
• This may result in property damage.
Avoid directly exposing humans, animals or plants to the airflowfrom the air conditioner for long
periods of time.
• This may result in harm to humans, animals or plants.
FOR CLEANING
WARNING
Do not clean the appliance by spraying waterdirectly onto it. Do not use benzene, thinner or alcohol
to clean the appliance.
• This may result in discolouration, deformation, damage, electric shock or fire.
Before cleaning or performing maintenance, cut off the powersupply and wait until the fan stops.
• Failing to do so may result in electric shock or fire.
CAUTION
Take care when cleaning the surface of the heat exchanger of the outdoor unit since it has sharp
edges.
• This should be done by a qualified technician. Please contact your installer or service centre.
Do not clean the inside of the air conditioner byyourself.
• For cleaning inside the appliance, contact your nearest service centre.
• When cleaning the filter, refer to the descriptions in the 'Cleaning' section.
• Failing to do so may result in damage, electric shock or fire.
• Make sure to prevent any injury from sharp edges of the surface when handling the heat
exchanger.
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 10RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 10 2021-04-12 오후 4:31:192021-04-12 오후 4:31:19

11
English
At a GlanceAt a Glance
Indoor Unit Overview
The appearance of the actual product may differ slightly from the image below.
01
03
02
04
05
06
08
07
01 Air intake
02 Air filter
03 Front panel
04 Airflow blade (up and down)
05 Airflow blade (left and right)
06 Power button/Remote control receiver
07 Room temperature sensor
08 Display
Display
01
02 03
01 Temperature indicator (numeric)
Filter reset indicator ( )
Auto clean indicator ( )
02 Timer indicator
good’sleep indicator
03 Eco indicator
At a Glance
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 11RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 11 2021-04-12 오후 4:31:192021-04-12 오후 4:31:19

12
English
At a GlanceAt a Glance
Remote Control Overview
08
09
07
01
05
06
15
16
17
19
20
02
03
04
10
11
12
18
13
14
01 Set temperature indicator
02 Timer option indicator
03 Operation mode indicator
04 Options indicator
05 Low battery indicator
06 Transmit indicator
07 Fan speed indicator
08 Vertical air swing indicator
09 Horizontal air swing indicator
10 Power button
11 Temperature button
12 Timer button
13 Fan speed button
14 Direction button/Selection button
15 Vertical air swing button
16 Mode button
17 Fast/Eco button
18 Horizontal air swing button
• The horizontal air swing function is not available
for this model. Horizontal airflow can be adjusted
manually.
19 Options/Clean button
20 SET button/Temperature type button(℃↔℉)
NOTE
• Although Heat, Purify,
(Horizontal air swing), Direct,Indirect and
Usage appear on the remote control display, they
are not available on this model.
Replacing the remote control batteries
Two 1.5V AAA batteires
Most operating instructions in this manual require using the remote control.
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 12RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 12 2021-04-12 오후 4:31:192021-04-12 오후 4:31:19

13
English
At a GlanceAt a Glance
Selecting an operation mode
To change the current mode between Auto, Cool, Dry, Fan press the
(Mode) button.
NOTE
You can use the Cool, Dry modes in the following operation range.
Mode Cool Dry
Indoor temperature 16 °C to 32 °C 18 °C to 32 °C
Outdoor temperature 16 °C to 46 °C 16 °C to 46 °C
Indoor humidity Relative humidity of
80% or less ¹⁾ _
¹⁾ If the air conditioner operates in Cool mode in a high-humidity
environment for an extended period of time, condensation may occur.
You can switch between Celsius and Fahrenheit indications on the
remote control.
▶Press and hold for 3 or more seconds.
NOTE
• The temperature indications on the indoor unit are not switched.
• This function is canceled when the remote control batteries are
replaced. In this case, run this function again.
You can use the air conditioner easily by selecting a mode and then by controlling the temperature, fan
speed, and air direction.
Remote Control Operation
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 13RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 13 2021-04-12 오후 4:31:192021-04-12 오후 4:31:19

14
Remote Control Operation
English
At a GlanceAt a Glance
To set the temperature
To control the temperature in each mode, press the (Temperature)
button:
Mode Temperature control
Auto/Cool Adjust by 1 ℃ from 16 ℃ to 30 ℃.
Dry Adjust by 1 ℃ from 18 ℃ to 30 ℃.
Fan No temperature control.
To adjust the fan speed
Select from the following fan speeds in each mode:
Mode Available fan speeds
Auto/Dry (Auto)
Cool/Fan (Auto), (Low), (Med), (High),
(Turbo)
To adjust the airflow direction
Keep the airflow in a constant direction by stopping the movements
of the vertical airflow blades.
In operation ▶
NOTE
• If you adjust the vertical airflow blade manually, it may not close
completely when you turn off the air conditioner.
• Always use the remote control to adjust the airflow blades. Do
not move the blades by hand. They may not operate normally.
• You cannot control the vertical airflow direction in Cool mode
when the good'sleep function is on.
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 14RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 14 2021-04-12 오후 4:31:202021-04-12 오후 4:31:20

15
English
Smart FeaturesSmart Features
Power Smart Features
Smart Features
Auto mode
Use Auto mode to perform the powerful cooling function to
automatically reach the desired temperature. When the difference
between the room temperature and the set temperature decreases,
the air conditioner controls the fan speed and airflow direction.
▶ ▶ Select Auto.
NOTE
• When the room temperature is higher than the set temperature,
the air conditioner automatically produces cool air.
• When the room temperature is lower than the set temperature,
the air conditioner automatically produces warm air.
Cool mode
Use Cool mode to stay cool in hot weather.
▶ ▶ Select Cool.
NOTE
• For comfort, keep the temperature difference between the indoor
and outdoor air within 5℃.
• After selecting Cool mode, select the desired function,
temperature, and fan speed.
‒To cool more quickly, select a lower temperature and a faster
fan speed.
‒To save energy, select a higher temperature and a slower fan
speed.
‒As the room temperature nears the set temperature, the
compressor motor will slow down to save energy.
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 15RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 15 2021-04-12 오후 4:31:202021-04-12 오후 4:31:20

16
Power Smart Features
English
Smart FeaturesSmart Features
Dry mode
Use Dry mode in rainy or humid weather.
▶ ▶ Select Dry.
NOTE
• The proper set temperature range for dehumidifying operation is
24 to 26 ℃. If you feel that the current humidity seems high, use
a lower set temperature.
Fan mode
Use Fan mode to run the air conditioner like a floor fan, providing a
breeze without cooling.
▶ ▶ Select Fan.
NOTE
• If the air conditioner will not be used for an extended period
of time, run it in Fan mode for 3 to 4 hours to dry the internal
components.
• The outdoor unit does not operate in Fan mode. This is normal
and not a fault with the air conditioner.
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 16RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 16 2021-04-12 오후 4:31:202021-04-12 오후 4:31:20

17
English
Smart FeaturesSmart Features
Variety Smart Features
Fast function
Use the Fast function to quickly cool your room. This function is the
most powerful cooling function provided by the air conditioner. You
can select this function in Cool mode.
In Cool mode ▶
NOTE
• You can change the airflow direction, but you cannot change the
set temperature and the fan speed.
• Selecting the Fast function cancels the Eco, good'sleep, and Quiet
functions.
• You can also start the Fast function from the Options menu:
In Cool mode ▶▶ ▶
Select Fast. ▶
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 17RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 17 2021-04-12 오후 4:31:202021-04-12 오후 4:31:20

18
Variety Smart Features
English
Smart FeaturesSmart Features
Eco function
Use the Eco function to reduce electricity consumption while staying
cool. You can select this function in Cool mode.
In Cool mode ▶
NOTE
• When the Eco function starts, the pattern appears on the
remote control for a few seconds and vertical air swing begins.
• You can change the set temperature, airflow direction, and fan
speed.
• The allowed set temperatures while the Eco function is on are:
Mode Minumum set
temperature
Maximum set
temperature
Cool 24 ℃ 30 ℃
• If you change the set temperature to be outside the allowed range
for the current mode, the set temperature is automatically reset to
be within the range.
• When you turn off the Eco function, the air swing continues. Use
the
(Vertical air swing) button to turn it off.
• Selecting the Eco function cancels the good'sleep, Fast, and Quiet
functions.
• You can also start the Eco function from the Options menu:
In Cool mode ▶▶ ▶
Select Eco. ▶
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 18RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 18 2021-04-12 오후 4:31:212021-04-12 오후 4:31:21

19
English
Smart FeaturesSmart Features
Quiet function
Use the Quiet function to reduce the unit’s operating noise. You can
select this function in Cool mode.
In Cool mode ▶▶ ▶
Select Quiet. ▶
NOTE
• You can change the set temperature and the airflow direction,
but you cannot change the fan speed.
• Selecting the Quiet function cancels the Eco, good'sleep, and Fast
functions.
Beep function
Use the Beep function to turn on or off the beep that sounds when
you press a button on the remote control.
▶ ▶ Select Beep. ▶
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 19RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 19 2021-04-12 오후 4:31:212021-04-12 오후 4:31:21

20
Variety Smart Features
English
Smart FeaturesSmart Features
Auto clean function
Use the Auto clean function if the indoor unit produces odors.
Activating Auto clean
To activate Auto clean, press the (Options) button for at least 3
seconds.
The indoor unit display shows:
If the air conditioner is off, Auto clean starts immediately. If the
air conditioner is running, Auto clean starts as soon as the air
conditioner turns off.
NOTE
• You can also activate Auto clean from the Options menu:
▶ ▶ Select Clean. ▶
• Once Auto clean is selected, it is always activated whenever the
air conditioner turns off.
• Auto clean runs for10 to up to 30 minutes depending on internal
dry conditions. The indoor unit display shows the cleaning
progress from 1% to 99%.
• If you start another function while Auto clean is progressing, Auto
clean pauses and will resume when the other function stops.
• When Auto clean completes, the air conditioner turns off.
• Auto clean does not run after Fan mode.
RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 20RAC078-00_IB_21Y AR9500T CO SEDA_AZ_EN-WEB_.indd 20 2021-04-12 오후 4:31:212021-04-12 오후 4:31:21
