Samsung AR TSFA Series User manual

Air conditioner
Installation manual
AR**TSFA*** / AR**TSFY***
࡛Thank you for purchasing this Samsung air conditioner.
࡛Before operating this unit, please read this user manual carefully and retain it for future
reference.

2
English
Contents
Safety Information 3
Safety Information 3
Installation 6
Preparation 6
Step 1-1 Viewing the typical installation 6
Step 1-2 Verifying model numbers 7
Step 1-3 Choosing the installation location 8
Step 1-4 Unpacking 11
Step 1-5 Preparing materials and tools 12
Indoor Unit Installation 14
Step 2-1 Attaching the mounting bracket to the wall 14
Step 2-2 Drilling the wall penetration 14
Step 2-3 Connecting the refrigerant pipes 15
Step 2-4 Connecting the power and communication cables 16
Step 2-5 Optional: Extending the power cable 17
Step 2-6 Connecting the drain hose 18
Step 2-7 Taping the pipes, cables, and drain hose 19
Outdoor Unit Installation 20
Step 3-1 Mounting the outdoor unit 20
Step 3-2 Connecting the cables and the pipes 21
Installation Inspection and Testing 22
Step 4-1 Performing a drain leak test 22
Step 4-2 Performing pressure tests using nitrogen 22
Step 4-3 Evacuating the system 23
Step 4-4 Adding refrigerant (if needed) 24
Step 4-5 Preparing the system for commissioning 24
Step 4-6 Commissioning the unit 24
Step 4-7 Performing final checks and trial operation 25
Sub PCB installation(optional) 27

3
English
Safety Information
WARNING: Read This Manual
࡛Read and follow all safety information and instructions before installation, use, or maintenance of this appliance.
Incorrect installation, use, or maintenance of this appliance can result in death, serious injury, or property damage.
Keep these instructions with this appliance. This manual is subject to change. For the latest version,
visit www.samsunghvac.com.
This manual explains how to install a split-system, ductless unit using matched indoor and outdoor units. The manufacturer shall
not be responsible for damages arising from the use of non-compatible units.
For information on compatible units and unit specifications, see the submittal document for the applicable model, available at
www.samsunghvac.com:
࡛Submittal AR09TSFACWKXCV/AR09TSFABWKNCV
࡛Submittal AR12TSFACWKXCV/AR12TSFABWKNCV
࡛Submittal AR18TSFACWKXCV/AR18TSFABWKNCV
࡛Submittal AR24TSFACWKXCV/AR24TSFABWKNCV
࡛Submittal AR09TSFABWKXCV/AR09TSFABWKNCV
࡛Submittal AR12TSFABWKXCV/AR12TSFABWKNCV
࡛Submittal AR18TSFABWKXCV/AR18TSFABWKNCV
࡛Submittal AR24TSFABWKXCV/AR24TSFABWKNCV
࡛Submittal AR09TSFYBWKXCV/AR09TSFYBWKNCV
࡛Submittal AR12TSFYBWKXCV/AR12TSFYBWKNCV
࡛Submittal AR18TSFYBWKXCV/AR18TSFYBWKNCV
࡛Submittal AR24TSFYBWKXCV/AR24TSFYBWKNCV
Because the instructions in this manual cover various models, the characteristics of your air conditioner may differ slightly from
those described. If you have any questions, please contact your service provider or visit www.samsunghvac.com.
This device complies with Industry Canada license exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and (2) this device must accept any interference received, including
interference that may cause undesired operation. This Class B digital apparatus complies with Canadian ICES-003.
This equipment complies with FCC and IC RSS- 102 radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 23.62 inch (600mm) between the radiator & your body. Any
changes or modifications not expressly approved by the manufacturer could void manufacturer’s warranty.
This product has been designed and manufactured to meet ENERGY STAR criteria for
energy efficiency when matched with appropriate coil components.
However, proper refrigerant charge and proper air flow are critical to achieve rated
capacity and efficiency. Installation of this product should follow the manufacturer’s
refrigerant charging and air flow instructions.
Failure to confirm proper charge and air flow may reduce energy efficiency and shorten
equipment life.
Safety Information

4
Safety Information
English
Safety Information
Safety Information
Notices and notes
To make you aware of safety messages and highlighted information, we use the following notices and notes throughout this
manual:
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property damage.
IMPORTANT
Information of special interest
NOTE
Supplementary information that may be useful
FOR GENERAL
California Proposition 65 Warning (US)
WARNING:
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
WARNING
The installation and testing of this appliance must be performed by a qualified technician.
࡛The instructions in this manual are not intended as a substitute for proper training or adequate experience in the safe
installation of the appliance.
Always install the air conditionerin compliance with current local, state, and federal safety standards.

5
English
Safety Information
General information
࡛The air conditioner should be used only for the applications for which it has been designed: the indoor unit is not
suitable to be installed in areas used for laundry.
Installation of the product
࡛Our units must be installed in compliance with the spaces indicated in the installation manual to ensure either
accessibility from both sides or ability to perform routine maintenance and repairs. The units’ components must be
accessible and that can be disassembled in conditions of complete safety either for people or things. For this reason,
where it is not observed as indicated into the Installation Manual, the cost necessary to reach and repair the unit (in
safety, as required by current regulations in force) with slings, trucks, scaffolding or any other means of elevation won’t
be considered in-warranty and will be charged to end user.
Power supply line, fuse, or circuit breaker
࡛Be sure not to perform power cable modification, extension wiring, and multiple wire connection.
ࣞIt may cause electric shock or fire due to poor connection, poor insulation, or current limit override.
ࣞWhen extension wiring is required due to power line damage, refer to "Step 2-5 Optional: Extending the power cable"
in the installation manual.

6
Preparation
English
Installation
Step 1-1 Viewing the typical installation
A typical installation will be similar to the one shown below.
The actual units may look different from
the images depicted here.
Evaporator/
fancoil (indoor)
Maximum pipe height
Maximum pipe length
Refrigerant lines,
electric, and drain
Compressor/
condenser
(outdoor)
Unit : ft(m)
Model Pipe length Pipe height
Minimum Maximum Standard for factory charge Maximum
**09*******
**12******* 9.8(3) 65.6(20) 24.6(7.5) 49.2(15)
**18*******
**24******* 9.8(3) 98.4(30) 24.6(7.5) 65.6(20)
CAUTION
Outdoor Unit
Outer wall
Indoor Unit
Cut insulation to have
rainwater drained
Make a U-trap (A) on the pipe (which is connected to
the indoor unit) at outerwall and cut the bottom part of
the insulation (about 10 mm) to prevent rainwaterfrom
getting inside through the insulation.
CAUTION
Make at least one round to
reduce noise and vibration.
Preparation

7
English
Installation
Step 1-2 Verifying model numbers
Check the model numbers on the boxes to make sure that the indoor and outdoor units are compatible with each other.
For compatible units, see the model’s submittal document, listed on page 3.
Nominal capacity (BTU/hour) Indoor unit model number Outdoorunit model number
9000 AR09TSFABWKNCV AR09TSFACWKXCV
12000 AR12TSFABWKNCV AR12TSFACWKXCV
18000 AR18TSFABWKNCV AR18TSFACWKXCV
21000 AR24TSFABWKNCV AR24TSFACWKXCV
9000 AR09TSFABWKNCV AR09TSFABWKXCV
12000 AR12TSFABWKNCV AR12TSFABWKXCV
18000 AR18TSFABWKNCV AR18TSFABWKXCV
21000 AR24TSFABWKNCV AR24TSFABWKXCV
9000 AR09TSFYBWKNCV AR09TSFYBWKXCV
12000 AR12TSFYBWKNCV AR12TSFYBWKXCV
18000 AR18TSFYBWKNCV AR18TSFYBWKXCV
22000 AR24TSFYBWKNCV AR24TSFYBWKXCV

8
Preparation
English
Installation
Step 1-3 Choosing the installation
location
If using a multi system, install as described in the
installation manual supplied with the outdoor unit.
WARNING
࡛Verify that a dedicated circuit breaker and a disconnect
switch of the appropriate sizes for the air conditioner
are preinstalled and available for use. See the submittal
document for the model, listed on page 3.
࡛Verify that the voltage and frequency of the power
supply comply with the rated voltage as defined on the
unit name plate.
࡛Verify that a suitable grounding connection is available.
࡛Do not install this appliance in an environment
containing hazardous substances or close to equipment
that releases open flames.
࡛Do not install this appliance near a heater or flammable
material.
CAUTION
࡛The manufacturer shall not be responsible for damage
occurring as a result of the wrong voltage being
applied to this air conditioner.
࡛The indoor and outdoor units must be installed in
compliance with minimum clearances to ensure that
both units are accessible from both sides and can be
maintained or repaired. Insufficient clearance may
reduce product performance, generate excessive noise,
and reduce the life of some unit components.
IMPORTANT
࡛Any changes or modifications to the installation
described in this manual that are not expressly
approved by the manufacturer could void the
manufacturer’s warranty.
To determine where to locate the indoor and outdoor units,
you must survey the entire site and consider many variables.
The goal is to select locations that complywith all safety
precautions while also minimizing the total effort involved.
Indoor unit location requirements
WARNING
࡛Do not install the unit in a humid, oily, or dusty location
or in a location exposed to direct sunlight, water, or
rain.
࡛Make sure that the wall can support the unit weight.
Examine the area that the customerwants to be air
conditioned. Consider the following:
࡛What wall location will meet minimum clearances and
provide optimal product performance?
࡛Will the wall provide adequate support for the unit
weight (wall with stud construction or concrete)? If
applicable, where are the studs?
࡛Where will you place the wall penetration for
routing the piping bundle (consisting of power and
communication cables, refrigerant pipes, and the drain
hose) through the wall to the outdoor unit? Will the
hole intersect any plumbing or wires in the wall?
࡛Is the location as close as possible to where the outdoor
unit will be installed, to minimize the length of piping
and cables?
࡛Will the condensate drain inside the room, through the
wall penetration to the outdoor unit, or be connected to
a condensate pump?
NOTE
࡛This manual covers a typical gravity-drain installation
where the drain hose is routed to the outdoor unit
through a hole in the wall.

9
English
Installation
Minimum clearances for the indoor unit
Ceiling
4 inch
(100 mm)
5 inch
(125 mm)
5 inch
(125 mm)
Wall
Outdoorunit location requirements
Examine the area where the outdoor unit could be located.
Consider the following:
࡛What location will meet minimum clearances and
provide optimal product performance?
࡛Is there an existing level and hard foundation, such as
a concrete pad, that will support the unit weight and
produce minimal vibration? Installation on uneven
ground may result in abnormal vibrations, noise, or
problems with the unit.
࡛Does the unit need to be mounted on the wall?
࡛Where are the dedicated circuit breaker and disconnect
switch located? How will you connect them to the unit?
࡛How will you route the piping bundle from the indoor
unit? Is the location as close as possible to where the
indoor unit will be installed, to minimize the length of
piping and cables?
࡛Will the unit be sheltered from the wind? In a
high-wind area, you may need to build a protective
fence around the unit.
࡛Where will the condensate drain?
WARNING
࡛The drain location must allow condensate to drain
properly and prevent ice from forming on the unit in
winter. If a block of ice falls from the unit, it may result
in death, serious injury, or property damage. Improper
or inadequate draining may result in water overflowing
and property damage.
CAUTION
࡛Do not connect the drain hose to existing waste pipes
as odors may arise.
Installation on an exteriorwall
If the outdoor unit must be installed on an exterior wall, you
will need an L-bracket to support the unit. This bracket is not
included with the unit.
WARNING
࡛The wall must be capable of supporting the weight
of both the L-bracket and the outdoor unit. If the unit
falls, it may result in crushing, electric shock, fire, or
explosion that could cause death, severe personal
injury, or property damage.
Installation Guide at the seashore
Make sure to follow below guides when installing at the
seashore.
1 Do not install the product in a place where it is directly
exposed to sea water and sea breeze.
ࣞMake sure to install the product behind a structure
(such as building) that can block see breeze.
ࣞEven when it is inevitable to install the product in
seashore, make sure that product is not directly
exposed to sea breeze by installing a protection wall.
2 Consider that the salinity particles clinging to the external
panels should be sufficientlywashed out.
3 Because the residual water at the bottom of the outdoor
unit significantly promotes corrosion, make sure that the
slope does not disturb drainage.
ࣞKeep the floor level so that rain does not accumulate.
ࣞBe careful not to block the drain hole due to foreign
substance.
4 When product is installed in seashore, periodically clean it
with water to remove attached salinity.
5 Make sure to install the product in a place that provides
smooth water drainage. Especially, ensure that the base
part has good drainage.
6 If the product is damaged during the installation or
maintenance, make sure to repair it.

10
Preparation
English
Installation
7 Check the condition of the product periodically.
ࣞCheck the installation site every 3 months and
perform anti-corrosion treatment such as R-Pro
supplied by SAMSUNG (Code : MOK-220SA) or
commercial water repellent grease and wax, etc.,
based on the product condition.
ࣞWhen the product is to be shut down for a long
period of time, such as off-peak hours, take
appropriate measures like covering the product.
8 If the product installed within 1640.4 ft (500 m) of
seashore, special anti-corrosion treatment is required.
࢜ťʪɇϑʪʀͱϩɇʀϩцͱЇθͱʀɇƊđƊƸĘθʪΧθʪϑʪϩɇϩЭʪ˙ͱθ
further details.
Sea breeze
Sea breeze
Sea
Sea
Outdoor
unit
Outdoor
unit
Outdoor
unit
Sea breeze
Protection wall
Sea
Outdoor
unit
Outdoor unit
࡛Protection wall should be constructed with a solid
material that can block the sea breeze and the height
and width of the wall should be 1.5 times larger
than the size of the outdoor unit. (You must secure
ͱθʪϩ˵ɇߤߤ߫ߨ࢏ߨ˙ϩ࣑ߩߢߢ࣒ͱ˙ϑΧɇʀʪɵʪϩиʪʪϩ˵ʪ
protection wall and the outdoor unit for air circulation.)
Minimum clearances for the outdoor unit
Legends:
Wall
Minimum clearance in inch (mm)
23.6
(600)
11.8
(300)
Air flow direction
Top view Side view
Examples for installing one outdoor unit:
Unit: inch (mm)
11.8
(300)
59
(1500)
11.8
(300)
5.9
(150)
23.6
(600)
78.74
(2000)
59
(1500)
19.6
(500)
11.8
(300)
59
(1500)
11.8
(300)
