Contents
11. Precautions ........................................................................................................................................... 1-1
1-1 Installing the air conditioner .......................................................................................................... 1-1
1-2 Power supply and circuit breaker ............................................................................................... 1-1
1-3 During operation ................................................................................................................................ 1-1
1-4 Disposing of the unit ........................................................................................................................ 1-2
1-5 Others .................................................................................................................................................... 1-2
12. Product Specifications.............................................................................................................. 2-1
2-1 The Feature of Product .................................................................................................................. 2-1
2-2 Name of Each Part ........................................................................................................................... 2-2
2-3 Product Specifications .................................................................................................................... 2-4
2-4 The Comparative Specifications of Product .......................................................................... 2-6
2-5 Accessory Specifications 2-7
13. Alignment and Adjustments................................................................................................. 3-1
3-1 Setting up option switches ............................................................................................................
............................................................................................................
3-1
3-2 Setting Option Setup Method ...................................................................................................... 3-3
14. Disassembly and Reassembly........................................................................................... 4-1
4-1 Indoor Unit ........................................................................................................................................... 4-1
4-2 Outdoor Unit ........................................................................................................................................ 4-10
15. Exploded Views and Parts List......................................................................................... 5-1
5-1 Indoor Unit ........................................................................................................................................... 5-1
5-2 Outdoor Unit ......................................................................................................................................... 5-4
16. Electrical Parts List....................................................................................................................... 6-1
17. Wiring Diagram.................................................................................................................................. 7-1
7-1 Indoor Unit ........................................................................................................................................... 7-1
7-2 Outdoor Unit ......................................................................................................................................... 7-3
18. Schematic Diagram....................................................................................................................... 8-1
8-1 Indoor Unit ........................................................................................................................................... 8-1
8-2 Outdoor Unit ......................................................................................................................................... 8-3
24121A(1)_1 1/28/05 6:17 AM Page 1

24121A(1)_1 1/28/05 6:17 AM Page 2
Contents
19. Circuit Descriptions ..................................................................................................................... 9-1
9-1 PCB Circuit Descriptions................................................................................................................. 9-1
9-2 Refrigerating Cycle Diagram ......................................................................................................... 9-4
10. PCB Diagram .......................................................................................................................................10-1
10-1 Indoor Unit ......................................................................................................................................... 10-1
10-2 Outdoor Unit....................................................................................................................................... 10-4
11. Operating Instruction and Installation........................................................................11-1
11-1 Main Function .................................................................................................................................... 11-1
11-2 Wireless Remote Control-Buttons and Display................................................................... 11-4
12. Troubleshooting ...............................................................................................................................12-1
12-1 Operation Specification................................................................................................................. 12-1
12-2 Troubleshooting................................................................................................................................ 12-4
12-3 Sequence for trouble diagnosis................................................................................................. 12-6
13. Block Diagram....................................................................................................................................13-1
13-1 Indoor Unit ......................................................................................................................................... 13-1
13-2 Outdoor Unit....................................................................................................................................... 13-2
14. Reference Sheet...............................................................................................................................14-1
14-1 Index for Model Name................................................................................................................... 14-1
14-2 Refrigerant Pressure during the Charging............................................................................ 14-2
14-3 Pressure & Capacity mark........................................................................................................... 14-2
14-5 Q & A for Non-trouble..................................................................................................................... 14-3
14-4 The abbreviated technology words & the definition of technology terms ............. 14-2
14-6 Cleaning Your Air Conditioner .................................................................................................... 14-6
14-7 Installation........................................................................................................................................... 14-7
14-8 Installation Diagram of Indoor Unit and Outdoor Unit...................................................... 14-8

1-1Samsung Electronics
1. Precautions
1-1 Installing the air conditioner
● Users should not install the air conditioner by themselves.
Ask the dealer or authorized company to install the air conditioner except the window-type air conditioner in U.S.A and Canada.
● If you don’t install the air conditioner properly, it may cause a fire, a water leakage or an electric shock.
● You must install the air conditioner according to the national wiring regulations and safety regulations.
● Install the indoor unit higher than 2.5m from the floor to avoid the injury caused by the operation of the fan.
(except the window-type air conditioner)
● The manufacturer is not responsible for any accidents or injury caused by an incorrect installation.
● When installing the built-in type air conditioner, keep all electric cables such as the power cable and the connection cord in pipes,
ducts, or cable channels to protect them from the danger of impact or any other incidents.
1-2 Power supply and circuit breaker
● If the power cord of the air conditioner is damaged, it must be replaced by the manufacturer or a qualified person in order to
avoid a hazard.
● The air conditioner must be plugged into an independent circuit if applicable or connect the power cable to the auxiliary circuit
breaker.
An all pole disconnection from the power supply must be incorporated in the fixed wiring with a contact opening of >3mm.
● Do not extend an electric cord to the air conditioner.
● The air conditioner must be plugged in after you complete the installation.
1-3 During operation
Do not repair the air conditioner at your discretion.
It is recommended to contact a service center directly.
Never spill any kind of liquid on the air conditioner.
If this happens, turn off the air conditioner and contact an authorized service center.
24524(1)_1 56/10/3 7:06 PM Page 1-1
Do not spray any kind of liquid into the indoor unit. If this happens,
turn off the air conditioner and contact a service center.

Samsung Electronics1-2
1-5 Others
● Never store or load the air conditioner upside down or sideways to prevent the damage to the compressor.
● Young children or infirm persons should be always supervised when they use the air conditioner.
● Max current is measured according to IEC standard for safety.
● Current is measured according to ISO standard for energy efficiency.
1-4 Disposing of the unit
● Before throwing out the air conditioner, remove the batteries from the remote control.
● When you dispose of the air conditioner, consult your dealer. If pipes are removed incorrectly, refrigerant may blow out and
cause air pollution. When it contacts with your skin, it can cause skin injury.
● The package of the air conditioner should be recycled or disposed of properly for environmental reasons.
24524(1)_1 56/10/3 7:06 PM Page 1-2
1-3 During operation(cont.)
Make sure that the air conditioner is well ventilated at all times:
Do not place a cloth or other materials over it.
Remove the batteries if you don’t use the remote control
for a long time. (If applicable)
Use the remote control within 7 meters from the indoor unit.
(If applicable)
Do not insert anything between the airflow blades to prevent damage
of the inner fan and consequent injury.
Keep children away from the air conditioner.
Do not place any obstacles in front of the air conditioner.

2-1Samsung Electronics
2. Product Specifications
2-1 The Feature of Product
Auto Changeover
Long Lasting Outdoor Unit
Anti Corrosion Cabinet & Heat Exchanger are applied.
Free Installation
4 directions piping installation are possible.
Various useful functions
-Long piping : Max.30m
24121A(1)_1 1/28/05 6:17 AM Page 2-1

Samsung Electronics2-2
(Unit : mm)
2-2 Name of Each Part
2-2-1 Indoor Unit
Air flow blade(right/left)
Air flow blade(up/down)
Air filter
Front grille
Remote control
sensor
Defrosting indicator
Filter sign indicator
Fan indicator
Auto indicator
Timer indicator
Operation indicator
On/Off button
45
50
240
200
650
197
922
1,000
Back side
Pipe outlet (bottom side)
Drain hose outlet
Wiring hole
Air intake hole (Ø50)
The figures are shown in this instruction may differ from yours depending on the model.
24121A(1)_1 1/28/05 6:17 AM Page 2-2

Product Specifications
2-3Samsung Electronics
2-2-2 Outdoor Unit
 FH18BTX1/FC24BTVX
(Unit : mm)
Air Inlet(Rear)
Connetion Valve
FC18BTVX
Note : If the heat exchanger in the outdoor unit gets dusty, cooling efficiency may fall.
So clean the heat exchanger with water when it becomes dirty. However, be careful when you
wash the surface of the heat exchanger because it is very sharp.
(Unit : mm)

24121A(1)_1 1/28/05 6:17 AM Page 2-4
Samsung Electronics2-4
2-3 Product Specifications
24121A(1)_1 1/28/05 6:17 AM Page 2-4
Model Indoor unit FH18BTA1 FC18BTVA FC18BTVA
Outdoor unit FH18BTX1 FC18BTVX FC18BTVX
General
Cooling Capacity ISO Kcal/hr 4,284 4,284 5,796
W/hr 4,980 4,980 6,740
Btu/hr 17,000 17,000 23,000
SASO Kcal/hr 3,880 3,906 5,292
W 4,510 4,542 6,155
Btu/hr 15,400 15,500 21,000
Heating Capacity Kcal/hr 5,040 - -
W/hr 5,860 - -
Btu/hr 20,000 - -
Input Power Cooling(ISO) W 1,900 1,900 2,700
Cooling(SASO) W 2,220 2,200 3,000
Heating W 1,900 - -
Running Current Cooling(ISO) A 8.8 8.8 12.5
Cooling(SASO) A 10.3 10 14
Heating A 8.8 - -
Starting Current Cooling/Heating A 75 75 75
Power Supply
EER ISO Kcal/W 2.255 2.255 2.15
W/W 2.622 2.622 2.5
Btu/W 8.947 8.947 8.52
SASO Kcal/W 1.739 1.775 1.76
W/W 2.022 2.064 2.05
Btu/W 6.9 7.045 7
COP Heating Kcal/W 2.65 - -
W/W 3.083 - -
Btu/W 10.52 - -
18~30/18~30 18~30 18~30
F - - -
Refrigerant Control EEV Capillary Capillary
Refrigerant Charge g, type 1450,R22 1150,R22 1400,R22
Indoor
Fan Motor Power W 120 66 120
Model - OSM-414SAC(S319) OSM-
304SAC(S318) OSM-414SAC(S319)
Running Current A 0.64 0.31 0.64
Capacitor uF 6 3 6
Fan Type - Sirocco Sirocco Sirocco
Q’ty used/Diameter EA/mm 2 2 2
RPM Cooling(H/M/L) rpm 1320/1220/1120±50 1020/920/820±50 1320/1220/1120±50
Heating(H/M/L) rpm 1320/1220/1120±50 1020/920/820±50 1320/1220/1120±50
Air Circulation CMM 15.3/14.0/12.8 12.6/11.3/10.0 15.3/14.0/12.8
Noise Level(H/M/L) DB 51/49/47 45/43/41 51/49/47
Dimension(net) mm 1000*200*650 1000*200*650 1000*200*650
Weight(net) kg 22 22 22
°C

24121A(1)_1 1/28/05 6:17 AM Page 2-5
2-5Samsung Electronics
Product Specifications
24121A(1)_1 1/28/05 6:17 AM Page 2-5
Model Indoor unit FH18BTA1 FC18BTVA FC18BTVA
Outdoor unit FH18BTX1 FC18BTVX FC18BTVX
Outdoor
Compressor Type Rotary Rotary Rotary
Quantity EA 1 1 1
Model 48D190ITBEH 48D190ITBEH 55A260ITAEM
Maker SAMSUNG SAMSUNG SAMSUNG
Capacity uF 45uF/450VAC 45uF/450VAC 50uF/450VAC
OLP Type Inside
Fan Motor Power W 140 90 245
Model - YDK95-60/YGN60-6 YDK95-45 YDK120-93-6B
Running Current A 0.65 0.4 1.1
Capacitor uF 4 2.5 4
Fan Type - Propeller
Q’ty used/Diameter EA/mm 1/420 1/420 1/460
RPM Cooling(H/M/L) rpm 960±50 950±50 900±50
Heating(H/M/L) rpm 930±50 - -
Noise Level(H/M/L) DB 61 61 61
Dimension(net) mm 880*648*310 790*548*285 880*648*310
Weight(net) kg 55 39 55
Other
Pipe OD Size Liquid mm/inch 6.35/1/4” 6.35/1/4” 6.35/1/4”
Gas mm/inch 12.7/1/2” 12.7/1/2” 15.88/5/8”
Connection Method Flare
Between Height m 15
Pipe Length m 30

24121A(1)_1 1/28/05 6:17 AM Page 2-8
Samsung Electronics2-6
2-4 The Comparative Specifications of Product
22.0kg
67.0kg
1,000x200x650mm
880x310x648mm
50dB↓
61/62dB↓
Detachable Display
Net Weight Indoor Unit
Outdoor Unit
Outer Dimension Indoor Unit
(WxDxH) Outdoor Unit
Noise Indoor Unit
Outdoor Unit(C/H)
Indoor Display
Item
Indoor
Unit
Outdoor
Unit
FH18BT*1 FH18BT
22.0kg
67.0kg
1,000x200x650mm
880x310x648mm
47dB↓
57dB↓
-
Detachable Display
Design
24121A(1)_1 1/28/05 6:17 AM Page 2-8
Design

24121A(1)_1 1/28/05 6:17 AM Page 2-10
Item Descriptions Q'TYCode-No. Remark
2-5 Accessory Specifications
2-5-1 Accessories
24121A(1)_1 1/28/05 6:17 AM Page 2-10
2-7Samsung Electronics
Indoor
Unit
Outdoor
Unit
Remote Controller Holder DB61-00204A 1
Remote Control DB93-00251G 1
Batteries for Remote Control DB47-90024A 2
User's Manual DB98-27502A 1
Installation Manual DB98-27501A 1
Bracket wall DB61-01351A 2
Nut Flare 1
Nut Flare 1
Rubber Leg DB73-20134A 4
DB60-30010A
DB60-30010D
(FC24BTX1)
(FC24BTX1)
OWNER'SINSTRUCTIONS
MANUALDEINSTRUCCIONES
ISTRUZIONIPERL'USO
MANUALDEINSTRUÇÕES
MANUELD'UTILISATION
GEBRAUCHSANWEISUNG
Splut-typeRoomAirConditioner
AireacondicionadodomésticosistemaSplit
Condizionatored'ariaperambientiadunitàSeparate
AparelhodearcondicionadotipoSplit
Climatiseurdetypeséparé
Geteilteraumklimaanlage
OWNER'SINSTRUCTIONS
MANUALDEINSTRUCCIONES
ISTRUZIONIPERL'USO
MANUALDEINSTRUÇÕES
MANUELD'UTILISATION
GEBRAUCHSANWEISUNG
Splut-typeRoomAirConditioner
AireacondicionadodomésticosistemaSplit
Condizionatored'ariaperambientiadunitàSeparate
AparelhodearcondicionadotipoSplit
Climatiseurdetypeséparé
Geteilteraumklimaanlage

3. Alignment and Adjustments
3-1 Setting up option switches
You should display that how many indoor units are connected to the outdoor unit.
Refer to the table below, then turn the arrow to appropriate position.
■Rotary Switch
0 or 1
2
3
4
5
6
7
8
One
Two
Three
Four
Five
Six
Seven
Eight
9
A
B
C
D
E
F
-
Nine
Ten
Eleven
Twelve
Thirteen
Fourteen
Fifteen
-
Switch No. Number of indoor
unit(s) Switch No. Number of indoor unit(s)
■KEY ■Display
K1 K3K2
CHECK
MODE
DISPLAY
MODE
RESET
K4
DIS 1 DIS 2
ITEM NO. CURRENT DATA DISPLAY
Rotary switchKey
Display
24121A(1)_1 1/28/05 6:17 AM Page 3-1
Samsung Electronics3-1

Alignment and Adjustments
Samsung Electronics 3-2
Function
Number
of press times
1
2
3
4
✳ Use the K1 only for heat pump models.
K1
(Displayed on SEG 3, 4)
Adding refrigerant at
heating mode
Test operation at
heating mode
End
-
K2
(Displayed on SEG 3, 4)
Adding refrigerant at
cooling mode
Test operation at
cooling mode
Pump Down for recovery
of refrigerant
End
K3
(Displayed on SEG 3, 4)
Reset
-
-
-
K4
(Displayed on SEG 3, 4)
Displays data
-
-
-
■Summary of KEY functions
■Reading data indicated on the display
K1
K2
K3
K4
1
2
3
1
2
3
4
1
2
3
4
5
6
7
8
9
10
Adding refrigerant for heat pump models
Test operation for heat pump models
End
Adding refrigerant for cooling only models
Test operation for cooling only models
Pump Down for recovery of refrigerant
End
Reset
Discharge temperature of compressor
Temperature of outdoor heat exchanger
Outdoor temperature
Step of electronic expansion valve
(0 step : all closed, 480 step : all open)
Temperature of evaporator
Indoor temperature
Stopping view mode & display communication data
110 °C
38 °C
34 °C
120STEP
(12 x 10)
-2 °C
12 °C
22 °C
KEY Number of
press Item Example
Display Meaning
24121A(1)_1 1/28/05 6:17 AM Page 3-2

3-2 Setting Option Setup Method
ex) Option No. :
Step 1 : Enter the Option Setup mode.
1st Take out the batteries of remote control.
2nd Press the temp. button simultaneously and
insert the battery again.
3rd Make sure the remote control display shown as .
Step 2 : Enter the Option Setup mode and select your option according to the following procedure.
1
2
3
4
5
6
1
2
The default value is .
Otherwise, push the button to .
Every time you push the button, the display panel reads or
repeatedly.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
3
4
5
6
✳Setting is not required if you must
a value which has a default.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
24121A(1)_1 1/28/05 6:18 AM Page 3-3
Samsung Electronics3-3

Alignment and Adjustments
Samsung Electronics 3-4
7
8
9
10
11
12
7
8
Press button, then the default value is .
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
✳Setting is not required if you must
a value which has a default.
9
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
10
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
11
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
12
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
Step 3 : Upon completion of the selection, check you made right selections.
Press the Mode Selection key, to set the display part to and check the display part.
The display part shows .
Press the Mode Selection key, to set the display part to and check the display part.
The display part shows .
Step 4 : Pressing the ON/OFF button ( )
When pressing the operation ON/OFF key with the direction of remote control for unit, the sound ''Ding'' or ''Diriring'' is
heard and the OPERATION ICON( ) lamp of the display is flickering at the same time, then the input of option is
completed. (If the diriring sound isn't heard, try again pressing the ON/OFF button.)
Step 5 : Unit operation test-run
First, Remove the battery from the remote control.
Second, Re-insert the battery into the remote control.
Third, Press ON/OFF button( ) with the direction of remote control for set.
•Error Mode
1st If all lamps of indoor unit are flickering, Plug out, plug in power plug again and press ON/OFF key to retry.
2nd If the unit is not working properly or all lamps are continuously flickering after setting the option code, see if the correct option code
is set up for its model.
24121A(1)_1 1/28/05 6:18 AM Page 3-4

Alignment and Adjustments
3-5 Samsung Electronics
REMOCON
MODEL SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 SEG7 SEG8 SEG9 SEG10 SEG11 SEG12
FH18BT*1
FC18BTV
FC24BTV
035400190000
035400190000
0 3 5 4 0 0 1 C 0 0 0 0
OPTION ITEMS
24121A(1)_1 1/28/05 6:18 AM Page 3-5

MEMO
24121A(1)_1 1/28/05 6:18 AM Page 3-25
3-6Samsung Electronics

Samsung Electronics4-1
4. Disassembly and Reassembly
4-1 Indoor Unit
Stop operation of the air conditioner and remove the power cord before repairing the unit.
No Parts Procedure Remark
1 Electrical
Part
1) Open the Grille by pressing 3 position.
(center and both side)
2) Detach the Air Inlet Grille.
3) Open the Cover of Component Electrical
Box by removing 3 screws.
(center and both side)
24121A(1)_1 1/28/05 6:18 AM Page 3-6

Disassembly and Reassembly
4-2Samsung Electronics
No Parts Procedure Remark
2Fan
&
Motor
1) Detach the screw and untie earth
wire of Motor.
2) Disconnect of housing of Motor Wire.
3) Disconnect the Capacitor Wire.
24121A(1)_1 1/28/05 6:18 AM Page 3-7
