Samsung SINGLE AC MNMSEH/EU Series Instruction manual

SINGLE
Technical
Data Book
SINGLE MSP Duct for Europe
(R410A, HP)
Model : AC∗∗∗MNMSEH/EU(Indoor Unit) , AC∗∗∗MXASEH/EU(Outdoor Unit)

2
History
Version Modification Date Remark
Ver.1.0 Release Single TDB for Europe 17.01.03
Ver.1.1Modify the SCOP data from 3.85 W/W to 3.8 W/W 17.08.04

3
Contents
1. Nomenclature 4
2. Line-up 6
3. Specification 7
4. Summary Table 9
5. Capacity Table 11
6. Dimensional Drawing 13
7. Center of Gravity 20
8. Electrical Wiring Diagram 23
9. Sound Data 28
10. Fan Characteristics 32
11. Capacity Correction 36
12. Operation Range 38
13. Piping Diagram 39
14. Installation 41
15. Accessory 75

1. Nomenclature
4
Indoor Unit
(1) Classification
AC CAC
(2) Capacity
X 1/10 kW (3 digits)
(3) Version
H2014
J2015
K2016
M2017
(4) Product Type
NIndoor Unit
XOutdoor Unit
(5) Product Notation
11 Way Cassette
N4 Way Cassette (600x600)
44 Way Cassette, 360 Cassette
LLSP Duct
MMSP Duct
CCeiling
JConsole
AA3050 (Wall Mounted)
(6) Feature
FFlagship
SStandard
DDeluxe
PPremium
(7) Rating Voltage
E
(8) Mode
H
1. Nomenclature
Model Name
AC
(1)
052
(2)
M
(3)
N
(4)
M
(5)
S
(6)
E
(7)
H
(8)
EU
Buyer
1. Nomenclature

5
1. Nomenclature
Outdoor Unit
(1) Classification
AC CAC
(2) Capacity
X 1/10 kW (3 digits)
(3) Version
H2014
J2015
K2016
M2017
(4) Product Type
NIndoor Unit
XOutdoor Unit
(5) Product Notation
AInv+Side+General Temp
(6) Feature
FFlagship
SStandard
DDeluxe
PPremium
(7) Rating Voltage
E
(8) Mode
H
Model Name
AC
(1)
052
(2)
M
(3)
X
(4)
A
(5)
S
(6)
E
(7)
H
(8)
EU
Buyer

2. Line-up
6
Indoor Units
Model
Capacity (kW)
5.2 7.1 10.0 12.0
MSP Duct
Outdoor Units
Type Capacity (kW)
5.2 7.1 10.0 12.0
1Phase
2. Line-up

7
3. Specification
Model Name Indoor Unit AC052MNMSEH/EU AC071MNMSEH/EU AC100MNMSEH/EU AC120MNMSEH/EU
Outdoor Unit AC052MXASEH/EU AC071MXASEH/EU AC100MXASEH/EU AC120MXASEH/EU
System
Mode -   
Performance Capacity
Cooling
(Min/Std/Max)
kW 0.95 / 5.00 / 6.00 1.75 / 6.80 / 8.00 2.00 / 9.50 / 12.00 2.90 / 12.00 / 14.00
Btu/h 3,230 / 17,000 /
20,400
5,950 / 23,000 /
27,200
6,800 / 32,000 /
40,800
9,860 / 40,000 /
47,600
Heating
(Min/Std/Max)
kW 0.66 / 5.50 / 6.60 1.20 / 7.50 / 9.00 2.00 / 10.80 / 12.00 2.75 / 13.00 / 17.00
Btu/h 2,244 / 18,700 /
22,400
4,080 / 25,500 /
30,600
6,800 / 36,700 /
40,800
9,350 / 44,000 /
57,800
Power
Power Input
Cooling (Min/Std/Max) kW 0.28 / 1.86 / 2.62 0.34 / 2.30 / 2.65 0.54 / 3.30 / 4.95 0.72 / 4.40 / 5.55
Heating (Min/Std/Max) kW 0.21 / 1.64 / 2.65 0.28 / 2.35 / 3.85 0.41 / 3.20 / 4.80 0.60 / 3.75 / 5.95
Current Input
Cooling (Min/Std/Max) A 1.6 / 8.5 / 11.6 2.0 / 10.5 / 11.7 3.2 / 14.7 / 21.8 4.0 / 19.5 / 24.5
Heating (Min/Std/Max) A 1.4 / 7.6 / 11.0 1.8 / 10.4 / 17.0 2.4 / 14.2 / 21.0 3.2 / 16.6 / 27.0
Current MCA A16.5 23.5 25.5 2 7. 5
MFA A 18.2 25 28 30
Efficiency
EER Cooling W/W 2.69 2.96 2.97 2.73
COP Heating W/W 3.35 3.19 3.38 3.47
SEER (Cooling Energy Grade) W/W 5.50 5.50 5.50 5.10
SCOP (Heating Energy Grade) W/W
3.8 3.8 3.8 3.8
Pdesignh kW 2.2 3.5 5.0 7.4
Piping
Connections
Liquid Pipe
Type Flare connection Flare connection Flare connection Flare connection
 6.35 6.35 9.52 9.52
 1/4 1/4 3/8 3/8
Gas Pipe
Type Flare connection Flare connection Flare connection Flare connection
 12.7 15.88 15.88 15.88
 1/2 5/8 5/8 5/8
Heat Insulation -Both liquid and gas
pipes
Both liquid and gas
pipes
Both liquid and gas
pipes
Both liquid and gas
pipes
Piping length
(ODU-IDU)
Standard m5555
Max. m 30 50 50 50
Elevation m 20 30 30 30
Chargeless m 5 5 30 30
Wiring
connections
Power Source Wire mm2----
Communication wire mm2Min. 0.75 Min. 0.75 Min. 0.75 Min. 0.75
Remark -F1, F2 F1, F2 F1, F2 F1, F2
Power supply intake -
Both indoor and
outdoor unit
Both indoor and
outdoor unit
Both indoor and
outdoor unit
Both indoor and
outdoor unit
Refrigerant
Type - R410A R410A R410A R410A
Factory Charging kg 1.2 1.5 2.5 3.0
 2.5 3.13 5.22 6.3
Indoor
Unit
Power Supply  1, 2, 220-240, 50 1, 2, 220-240, 50 1, 2, 220-240, 50 1, 2, 220-240, 50
Heat
Exchanger
Type - Fin & Tube Fin & Tube Fin & Tube Fin & Tube
Material Fin -Al Al Al Al
Tube - Cu Cu Cu Cu
Fan
Type - Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Quantity EA 2 2 2 2
Air Flow Rate High/Mid/Low
CMM 15 / 14.2 / 13.5 18 / 15.8 / 13.5 29 / 24.5 / 20 34 / 29 / 24.5
l/s 250 / 237 / 225 300 / 263 / 225 483.33 / 408.33 /
333.33
566.67 / 483.33 /
408.33
External Static
Pressure Min/Std/Max mmAq 3/3/15 3/3/15 4/4/15 5.2/5.2/15
Pa 29.4/29.4/147.1 29.4/29.4/147.1 39.2/39.2/147.1 51.0/29/147.1
Fan Motor Output W x n 150 x 1 150 x 1 150 x 1 200 x 1
Drain Drain Pipe  VP-25(OD32, ID25) VP-25(OD32, ID25) VP-25(OD32, ID25) VP-25(OD32, ID25)
Sound
Sound Pressure Level High/Mid/Low/(Silent) dB(A) 31/28/25 33/30/27 35/32/29 37/34/31
Sound Power Level dB(A) 55 57 62 64
External
Dimension
Net Weight kg 30.0 30.0 33.0 47. 8
Shipping Weight kg 34.5 34.5 3 7. 2 54.5
Net Dimensions (WxHxD) mm 1150 x 260 x 480 1150 x 260 x 480 1150 x 320 x 480 1200 x 360 x 650
Shipping Dimensions (WxHxD) mm 1419 x 340 x 594 1419 x 340 x 594 1419 x 400 x 594 1456 x 440 x 778
Casing Material - EGI Steel Plate EGI Steel Plate EGI Steel Plate EGI Steel Plate
Control System Infrared remote control -   
Control System Wired remote control -
MWR-WE10N
MWR-WE11N
MWR-WE10N
MWR-WE11N
MWR-WE10N
MWR-WE11N
MWR-WE10N
MWR-WE11N
Drain Pump Drain Pump -----
Max. lifting Height / Displacement mm / Liter/h ----
3. Specification

3. Specification
8
Model Name Indoor Unit AC052MNMSEH/EU AC071MNMSEH/EU AC100MNMSEH/EU AC120MNMSEH/EU
Outdoor Unit AC052MXASEH/EU AC071MXASEH/EU AC100MXASEH/EU AC120MXASEH/EU
Indoor
Unit
Additional
Accessories
Drain Pump
External Model -----
Internal Model - MDP-M075SGU1D MDP-M075SGU1D MDP-M075SGU1D MDP-M075SGU2D
Max. lifting Height /
Displacement
mm / Liter/h 750/24 750/24 750/24 750/24
Air Filter -Removable /
Washable
Removable /
Washable
Removable /
Washable
Removable /
Washable
Virus Doctor -----
Outdoor
Unit
Power Supply  1, 2, 220-240, 50 1, 2, 220-240, 50 1, 2, 220-240, 50 1, 2, 220-240, 50
Heat
Exchanger
Type - Fin & Tube FMC Fin & Tube Fin & Tube
Material Fin -Al Al Al Al
Tube - Cu Al Cu Cu
Fin Treatment - Anti-Corrosion  Anti-Corrosion Anti-Corrosion
Compressor
Model Name UG9TK3150FE4 UG4T200FUAE4 UG8T300LNBJU UG5TK1450FJXSG
Output kW 1.423 1.788 2.818 4.189
Oil Type - POE POE PVE PVE
Initial charge cc 500 650 1200 1700
Fan
Type - Propeller Propeller Propeller Propeller
Discharge direction - Front Front Front Front
Quantity EA 1 1 1 1
Air Flow Rate CMM 31 51 58 78
l/s 516.67 850 966.67 1,300
Fan Motor Type - BLDC Motor BLDC Motor BLDC Motor BLDC Motor
Output W x n 39 x 1 95 x 1 95 x 1 125 x 1
Sound
Sound Pressure
Level
Cooling dB(A) 48 49 52 54
Heating dB(A) 48 51 54 56
Sound Power Level dB(A) 64 65 69 70
External
Dimension
Net Weight kg 3 7. 5 53.0 69.2 7 7. 0
Shipping Weight kg 40.5 5 7. 2 74.0 82.0
Net Dimensions (WxHxD) mm 790 x 548 x 285 880 x 798 x 310 880 x 967 x 320 940 x 998 x 330
Shipping Dimensions (WxHxD) mm 926 x 640 x 384 1023 x 911 x 413 1047 x 1045 x 415 995 x 1096 x 426
Casing Material Body - EGI Steel Plate EGI Steel Plate EGI Steel Plate EGI Steel Plate
Operating
Temp. Range
Cooling     
Heating     
NOTE
Specification may be subject to change without prior notice.
Specification comply with EN14511.
1) Capacities are based on (Equivalent refrigerant piping 5m, Level differences 0m);
- Cooling : Indoor temperature 27°C DB, 19°C WB / Outdoor temperature 35°C DB, 24°C WB
- 
2) Sound power level is an absolute value that a sound source generates.
Sound power level is based on cooling operation.
Sound pressure level is a relative value, depending on the distance and acoustic environment.
Sound values are obtained in an anechoic room.
Sound values of multi combination are theoretical values based on sound results of individual installed units.
3) These products contain R410A(GWP=2,088) which is fluorinated greenhouse gas.
In case you want to know more information regarding capacity and correction, please refer to capacity table
TDB on pvi.samsung.com site.

9
4. Summary Table
Indoor Units
Performance Characteristics
Model Code
Net
Weight
(kg)
Capacity
Fan Speed Airflow
(CMM)
Sound Pressure Level
(dBA)
Sound Power Level
(dBA)
Cooling
(kW)
Heating
(kW)
AC052MNMSEH 30.0
Max. 6.0 6.6  15.0 31 55
Std. 5.0 5.5 Mid. 14.2 28 -
Min. 0.95 0.66 Low 13.5 25 -
AC071MNMSEH 30.0
Max. 8.0 9.0  18.0 33 57
Std. 6.8 7. 5 Mid. 15.8 30 -
Min. 1.75 1.2 Low 13.5 27 -
AC100MNMSEH 33.0
Max. 12.0 12.0  29.0 35 62
Std. 9.5 10.8 Mid. 24.5 32 -
Min. 2.0 2.0 Low 20.0 29 -
AC120MNMSEH 47. 8
Max. 14.0 1 7.0  34.0 37 64
Std. 12.0 13.0 Mid. 29.0 34 -
Min. 2.9 2.75 Low 24.5 31 -
NOTE
Sound data is based on cooling operation.
Electric Characteristics
Model Outdoor Unit Input Current (Amperes) Power Supply
Indoor Unit Outdoor Unit Rated Voltage range Outdoor Unit Indoor Unit Total MCA(A) MFA(A)
Hz Volts Min. Max. Cooling Heating
AC052MNMSEH AC052MXASEH 50 220 to 240 198 264 13 13 3.5 16.5 16.5 18.2
AC071MNMSEH AC071MXASEH 50 220 to 240 198 264 20 20 3.5 23.5 23.5 25
AC100MNMSEH AC100MXASEH 50 220 to 240 198 264 22 22 3.5 25.5 25.5 28
AC120MNMSEH AC120MXASEH 50 220 to 240 198 264 24 24 3.5 2 7. 5 2 7. 5 30
NOTE
MCA : Minimum circuit amperes
MFA : Maximum fuse amperes
 
4. Summary Table

4. Summary Table
10
Outdoor Units
Performance Characteristics
Capacity Model Code Net Size
(WxHxD , mm)
Net Weight
(kg)
Airflow
(CMM)
Sound Pressure Level(dBA) Sound Power Level
(dBA)
kW Cooling Heating
5.2  790 x 548 x 285 3 7. 5 31 48 48 64
7.1  880 x 798 x 310 53.0 51 49 51 65
10  880 x 967 x 320 69.2 58 52 54 69
12  940 x 998 x 330 7 7. 0 78 54 56 70
NOTE
Sound power level is based on cooling operation.

11
5. Capacity Table
(1) AC052MNMSEH/EU+AC052MXASEH/EU
5. Capacity Table
Cooling 
Outdoor
Temperature
(℃, DB)
Indoor Temperature (℃, DB / WB)
20 / 14 22 / 16 25 / 18 27 / 19 28 / 20 30 / 22 32 / 24
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW
-15 4.9 3.9 1.33 5.1 4.0 1.36 5.3 4.1 1.39 5.5 4.2 1.41 5.6 4.2 1.43 5.9 4.2 1.44 6.2 4.1 1.47
21 4.6 3.7 1.40 4.9 3.8 1.43 5.1 3.9 1.46 5.3 4.0 1.49 5.4 4.0 1.50 5.6 4.0 1.52 5.9 3.9 1.55
35 4.4 3.5 1.75 4.7 3.6 1.79 4.9 3.7 1.82 5.0 3.9 1.86 5.1 3.8 1.88 5.4 3.8 1.90 5.6 3.7 1.94
46 3.8 3.4 1.58 4.0 3.5 1.61 4.1 3.6 1.64 4.3 3.7 1.67 4.3 3.6 1.69 4.6 3.6 1.71 4.8 3.5 1.74
50 2.9 2.7 1.40 3.0 2.8 1.43 3.2 2.8 1.46 3.3 2.9 1.49 3.3 2.9 1.50 3.5 2.9 1.52 3.7 2.8 1.55
NOTE
Capacities are based on following conditions; Refrigerant pipe length : 5m / Level difference : 0m.
Heating TC : Total Capacity, PI : Power Input
Outdoor
Temperature
(℃, DB)
Indoor Temperature (℃, DB)
16 18 20 21 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
-20 3.9 2.17 3.8 2.15 3.8 2.13 3.8 2.11 3.7 2.09 3.7 2.07
-15 4.9 2.51 4.8 2.48 4.8 2.46 4.7 2.44 4.7 2.41 4.6 2.39
-5 5.5 2.34 5.4 2.32 5.4 2.30 5.3 2.27 5.3 2.25 5.2 2.23
05.7 2.01 5.7 1.99 5.6 1.97 5.6 1.95 5.5 1.93 5.4 1.91
75.6 1.67 5.6 1.66 5.5 1.64 5.4 1.62 5.4 1.61 5.3 1.59
24 7. 3 1.92 7. 2 1.90 7. 2 1.89 7.1 1.87 7.0 1.85 6.9 1.83
(2) AC071MNMSEH/EU+AC071MXASEH/EU
Cooling 
Outdoor
Temperature
(℃, DB)
Indoor Temperature (℃, DB / WB)
20 / 14 22 / 16 25 / 18 27 / 19 28 / 20 30 / 22 32 / 24
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW
-15 6.6 5.3 1.65 7.0 5.4 1.68 7. 3 5.6 1.71 7. 5 5.8 1.75 7.6 5.7 1.77 8.0 5.7 1.78 8.4 5.5 1.82
21 6.3 5.0 1.73 6.6 5.2 1.77 6.9 5.3 1.80 7.1 5.5 1.84 7. 3 5.4 1.86 7.6 5.4 1.88 8.0 5.3 1.91
35 6.0 4.7 2.16 6.3 4.8 2.21 6.6 4.9 2.25 6.8 5.1 2.30 6.9 5.0 2.32 7. 3 5.0 2.35 7.6 4.9 2.39
46 5.1 4.6 1.95 5.4 4.7 1.99 5.6 4.9 2.03 5.8 5.0 2.07 5.9 5.0 2.09 6.2 4.9 2.11 6.5 4.8 2.15
50 3.9 3.4 1.73 4.1 3.5 1.77 4.3 3.6 1.80 4.4 3.7 1.84 4.5 3.7 1.86 4.7 3.6 1.88 5.0 3.6 1.91
NOTE
Capacities are based on following conditions; Refrigerant pipe length : 5m / Level difference : 0m.
Heating TC : Total Capacity, PI : Power Input
Outdoor
Temperature
(℃, DB)
Indoor Temperature (℃, DB)
16 18 20 21 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
-20 5.3 3.12 5.2 3.09 5.2 3.06 5.1 3.02 5.1 2.99 5.0 2.96
-15 6.7 3.60 6.6 3.56 6.5 3.53 6.5 3.49 6.4 3.45 6.3 3.42
-5 7. 5 3.36 7.4 3.32 7.4 3.29 7. 3 3.26 7. 2 3.22 7.1 3.19
0 7.8 2.88 7.7 2.85 7.7 2.82 7.6 2.79 7. 5 2.76 7. 4 2.74
77.7 2.40 7. 6 2.37 7. 5 2.35 7. 4 2.33 7.4 2.30 7. 3 2.28
24 9.9 2.76 9.8 2.73 9.8 2.70 9.7 2.68 9.6 2.65 9.5 2.62

5. Capacity Table
12
(3) AC100MNMSEH/EU+AC100MXASEH/EU
Cooling 
Outdoor
Temperature
(℃, DB)
Indoor Temperature (℃, DB / WB)
20 / 14 22 / 16 25 / 18 27 / 19 28 / 20 30 / 22 32 / 24
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW
-15 9.3 7. 4 2.36 9.8 7. 6 2.41 10.2 7.8 2.46 10.5 8.1 2.51 10.7 8.0 2.53 11.2 7.9 2.56 11.8 7.7 2.61
21 8.8 7.0 2.48 9.3 7. 2 2.54 9.7 7. 5 2.59 10.0 7.7 2.64 10.2 7. 6 2.67 10.7 7. 5 2.69 11.2 7.4 2.75
35 8.4 7.0 3.11 8.8 7. 2 3.17 9.2 7. 5 3.23 9.5 7. 7 3.30 9.7 7.6 3.33 10.2 7. 5 3.37 10.7 7. 4 3.43
46 7.1 6.4 2.80 7. 5 6.6 2.85 7.8 6.8 2.91 8.1 7.0 2.97 8.2 6.9 3.00 8.6 6.8 3.03 9.1 6.7 3.09
50 5.5 5.1 2.48 5.8 5.2 2.54 6.0 5.4 2.59 6.2 5.6 2.64 6.3 5.5 2.67 6.6 5.4 2.69 6.9 5.3 2.75
NOTE
Capacities are based on following conditions; Refrigerant pipe length : 5m / Level difference : 0m.
Heating TC : Total Capacity, PI : Power Input
Outdoor
Temperature
(℃, DB)
Indoor Temperature (℃, DB)
16 18 20 21 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
-20 7.6 4.24 7. 5 4.20 7. 5 4.16 7. 4 4.12 7. 3 4.08 7. 2 4.04
-15 9.6 4.90 9.5 4.85 9.4 4.80 9.3 4.75 9.2 4.70 9.1 4.66
-5 10.8 4.57 10.7 4.52 10.6 4.48 10.5 4.44 10.4 4.39 10.3 4.35
0 11.2 3.92 11.1 3.88 11.0 3.84 10.9 3.80 10.8 3.76 10.7 3.73
711.0 3.26 10.9 3.23 10.8 3.20 10.7 3.17 10.6 3.14 10.5 3.10
24 14.3 3.75 14.2 3.72 14.0 3.68 13.9 3.64 13.8 3.61 13.6 3.57
(4) AC120MNMSEH/EU+AC120MXASEH/EU
Cooling 
Outdoor
Temperature
(℃, DB)
Indoor Temperature (℃, DB / WB)
20 / 14 22 / 16 25 / 18 27 / 19 28 / 20 30 / 22 32 / 24
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW
-15 11.7 9.3 3.15 12.3 9.6 3.21 12.8 9.9 3.28 13.2 10.2 3.34 13.5 10.1 3.38 14.2 10.0 3.41 14.9 9.8 3.48
21 11.1 8.9 3.31 11.7 9.1 3.38 12.2 9.4 3.45 12.6 9.7 3.52 12.9 9.6 3.56 13.5 9.5 3.59 14.2 9.3 3.66
35 10.6 8.8 4.14 11.2 9.0 4.23 11.6 9.3 4.31 12.0 9.6 4.40 12.2 9.5 4.44 12.9 9.4 4.49 13.5 9.2 4.58
46 9.0 8.1 3.73 9.5 8.3 3.80 9.9 8.6 3.88 10.2 8.8 3.96 10.4 8.7 4.00 10.9 8.7 4.04 11.5 8.5 4.12
50 6.9 6.4 3.31 7. 3 6.6 3.38 7. 6 6.8 3.45 7.8 7. 0 3.52 8.0 6.9 3.56 8.4 6.9 3.59 8.8 6.7 3.66
NOTE
Capacities are based on following conditions; Refrigerant pipe length : 5m / Level difference : 0m.
Heating TC : Total Capacity, PI : Power Input
Outdoor
Temperature
(℃, DB)
Indoor Temperature (℃, DB)
16 18 20 21 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
-20 8.0 4.82 7.9 4.77 7.8 4.73 7.7 4.68 7. 6 4.63 7.6 4.58
-15 10.5 5.51 10.4 5.45 10.3 5.40 10.2 5.35 10.1 5.29 10.0 5.24
-5 11.7 5.66 11.6 5.61 11.4 5.55 11.3 5.49 11.2 5.44 11.1 5.39
0 13.7 4.40 13.5 4.36 13.4 4.31 13.3 4.27 13.1 4.23 13.0 4.18
7 13.3 3.83 13.1 3.79 13.0 3.75 12.9 3.71 12.7 3.68 12.6 3.64
24 14.9 4.36 14.7 4.32 14.6 4.28 14.4 4.23 14.3 4.19 14.1 4.15

13
6. Dimensional Drawing
Indoor Units
6. Dimensional Drawing
AC052/071MNMSEH
Units : mm [inches]
1150
[ 45-1/4 ]
1284
[ 50-9/16 ]
403
[ 15-7/8 ]
348
[ 13-11/16 ]
135 x 6 = 810
5
4
321
[ 5-5/16 x 6 = 31- 7/8 ]
1186
[ 46-11/16 ]
511
[ 20-1/8 ]
480
[ 18-3/4 ]
397
[ 15-5/8 ]
260
[ 10-1/4 ]
90
[ 3-9/16 ]
500[ 9-11/16 ] or More
(Service Space)
480[ 18-7/8 ] or More
(Service Space)
23 [ 7/8 ] 77 [ 3-1/16 ]
117 [ 4-5/8 ]
No. Name Description
AC052MNMSEH AC071MNMSEH
1Liquid pipe connection 
2Gas pipe connection  
3Drain pipe connection VP-25(OD32, ID25)
4Power supply & Communication wiring conduit
5 

6. Dimensional Drawing
14
Indoor Units
AC100MNMSEH
Units : mm [inches]
1150
[ 45-1/4 ]
1186
[ 46-11/16 ]
500[ 9-11/16 ] or More
(Service Space)
480[ 18-7/8 ] or More
(Service Space)
520
[ 20-1/2 ]
480
[ 18-3/4 ]
397
[ 15-5/8 ]
1284
[ 50-9/16 ]
135 x 6 = 810
[ 5-5/16 x 6 = 31-7/8 ]
403
[ 15-7/8 ]
348
[ 13-11/16 ]
23 [ 7/8 ] 107 [ 4-1/4 ]
157 [ 6-3/16 ]
320
[ 12-5/8 ]
125
[ 4-15/16 ]
5
4
3 2 1
No. Name Description
1Liquid pipe connection 
2Gas pipe connection 
3Drain pipe connection VP-25(OD32, ID25)
4Power supply & Communication wiring conduit
5 

15
6. Dimensional Drawing
Indoor Units
AC120MNMSEH
Units : mm [inches]
500[ 9-11/16 ] or More
(Service Space)
650[ 25-5/8 ] or More
(Service Space)
1334
[ 52-1/2 ]
351
[ 13-13/16 ]
27 [ 1-1/16 ] 122 [ 4-13/16 ] 137 [ 5-3/8 ]
406
[ 16 ]
480
[ 18- 7/8 ]
1200
[ 47-1/4 ]
1236
[ 48-5/8 ]
690
[ 27-3/16 ]
650
[ 25-5/8 ]
200
[ 7-7/8 ]
360
[ 14-3/16 ]
534
[ 21-1/16 ]
550 [ 2 ]
4
3
2 1
6x150=900
[ 6x5-7/8=35-7/16 ]
No. Name Description
1Liquid pipe connection 
2Gas pipe connection 
3Drain pipe connection VP-25(OD32, ID25)
4Power supply & Communication wiring conduit
5 

6. Dimensional Drawing
16
Outdoor Units
AC052MXASEH
Units : mm [inches]
852
[ 33-9/16 ]
790
13[ 1/2 ]
[ 1-1/16 ]
26
[ 13-1/2 ]
343
[ 12-3/8 ]
317
[ 10-7/16 ]
266
3
[ 10-3/16 ]
259
[ 1-5/16 ]
34
[ 3-5/16 ]
85
[ 24-1/16 ]
612
[ 7 ]
177 [ 1-5/16 ]
33
A
A
SECTION A-A
[ 31-1/8 ]
285
[ 11-1/8 ]
548
[ 21-9/16 ]
149
1
2
[ 5-7/8 ]
124
[ 4-7/8 ]
181
[ 7-1/8 ]
170
[ 6-11/16 ]
No. Name Description
1Refrigerant liquid pipe 
2Refrigerant gas pipe 
3

17
6. Dimensional Drawing
Outdoor Units
AC071MXASEH
Units : mm [inches]
281
[ 11-1/16 ]
660
[ 26 ]
111
[ 4-3/8 ]
880
[ 34-5/8 ]
934
[ 35-3/4 ]
310
[ 12-3/16 ]
113
[ 4-7/16 ]
372
[ 14-5/8 ]
110
[ 4-5/16 ]
58
[ 2-1/4 ]
30 [ 1-3/16 ]
272
1
3
2
[ 10-11/16 ]
144
[ 5-11/16 ]
364
[ 14-5/16 ]
340
[ 13-3/8 ]
31
[ 1-5/16 ]
184
[ 7-5/16 ]
31 [ 1-5/16 ]
73
[ 2-15/16 ]
51
[ 2-1/16 ]
15 [ 5/8 ]
15 [ 5/8 ]
213
[ 8-3/8 ] 798
[ 31-7/16 ]
364
[ 14-5/16 ]
360
[ 14-3/16 ]
No. Name Description
1Refrigerant liquid pipe 
2Refrigerant gas pipe 
3

6. Dimensional Drawing
18
AC100MXASEH
Units : mm [inches]
880
[ 34-5/8 ]
364
[ 14-5/16 ]
645
[ 25-3/8 ]
221
[ 8-11/16 ]
271
[ 10-11/16 ]
265
1
2
3
4
[ 10-7/16 ]
110
[ 4-5/16 ]
340
[ 13-3/8 ]
152
[ 6 ]
228
[ 9 ]
965
[ 38 ]
36 [ 1-7/16 ]
41 [ 1-5/8 ]
320
[ 12-5/8 ]
No. Name Description
1Refrigerant liquid pipe 
2Refrigerant gas pipe 
3Power & Communication wiring Conduits 
4 Connect with the provided drain plug
Outdoor Units

19
6. Dimensional Drawing
Outdoor Units
AC120MXASEH
Units : mm [inches]
940
[ 37 ]
313
[ 12-5/16 ]
24 [ 15/16 ]
330
25
998 [ 39-5/16 ]
55
5
1
52
106
Detail for Service valve position
2
495
[ 19-1/2 ]
[ 2-1/16 ]
[ 4-3/16 ]
4
3
4
63
4
3
88
165
18396
37
294 218
30
30
620
60
238
328
384
75
30
55
55
95
95
80
30
22
67
55
80
[ 3-1/2 ]
[ 6-1/2 ]
[ 7-3/16 ]
[ 11-9/16 ]
[ 1-7/16 ]
[ 8-9/16 ]
[ 1-3/16 ]
[ 3-13/16 ]
[ 24-3/8 ]
[ 2-3/8 ]
[ 9-3/8 ]
[ 12-7/8 ]
[ 15-1/8 ]
[ 2-15/16 ]
17
[11/16 ]
[1-3/16 ]
[ 1-3/16 ]
[ 2-3/16 ]
[ 2-3/16 ]
[ 3-3/4 ]
[ 3-3/4 ]
[ 1-3/16 ]
[7/8 ]
[2-5/8 ]
[2-3/16 ]
[3-1/8 ]
[ 3-1/8 ]
[ 1 ]
[ 13 ]
No. Name Description
1Refrigerant liquid pipe 
2Refrigerant gas pipe 
3Piping intake knockout hole Front / Side / Rear / Bottom
4Power wiring conduit 
5Communication wiring conduit 
6 Connect with the provided drain plug

7. Center of Gravity
20
7. Center of Gravity
Indoor Units
Units : mm [inches]
A
B
C
D
E
F
Model A B C D E F

 1150 570 260 135 480 255
 1150 570 320 165 480 255
 1200 590 360 190 650 345
