Samsung Galaxy J1 User manual

DRAFT
FOR INTERNAL USE ONLY
SMARTPHONE
User Manual
Please read this manual before operating your device
and keep it for future reference.
This document is watermarked because certain important information in the document has not yet been verified.
This document has been sent to you as a draft and for informational purposes only.
The document should only be used for internal purposes and may not be distributed outside of the company.
Distributing the document outside of the company could result in legal exposure to the company if the preliminary,
unverified information in the draft turns out to be inaccurate.

DRAFT
FOR INTERNAL USE ONLY
i
Legal Notices
Warning: This product contains chemicals known
to the State of California to cause cancer and
reproductive toxicity. For more information, please call
1-800-SAMSUNG (726-7864).
Intellectual Property
All Intellectual Property, as defined below, owned by
or which is otherwise the property of Samsung or its
respective suppliers relating to the SAMSUNG Phone,
including but not limited to, accessories, parts, or
software relating there to (the “Phone System”), is
proprietary to Samsung and protected under federal
laws, state laws, and international treaty provisions.
Intellectual Property includes, but is not limited to,
inventions (patentable or unpatentable), patents, trade
secrets, copyrights, software, computer programs, and
related documentation and other works of authorship.
You may not infringe or otherwise violate the rights
secured by the Intellectual Property. Moreover,
you agree that you will not (and will not attempt to)
modify, prepare derivative works of, reverse engineer,
decompile, disassemble, or otherwise attempt to
create source code from the software. No title to or
ownership in the Intellectual Property is transferred to
you. All applicable rights of the Intellectual Property
shall remain with SAMSUNG and its suppliers.
Open Source Software
Some software components of this product
incorporate source code covered under GNU General
Public License (GPL), GNU Lesser GeneralPublic
License (LGPL), OpenSSL License, BSD License and
other open source licenses. Toobtain the source code
covered under the opensource licenses, please visit:
http://opensource.samsung.com.
Disclaimer of Warranties;
Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS
WARRANTY CONTAINED ON THE WARRANTY
PAGE ENCLOSED WITH THE PRODUCT, THE
PURCHASER TAKES THE PRODUCT “AS IS”, AND
VZW_J100V_ENG_UM_OCD_TN_040715_R2

DRAFT
FOR INTERNAL USE ONLY
ii
SAMSUNG MAKES NO EXPRESS OR IMPLIED
WARRANTY OF ANY KIND WHATSOEVER WITH
RESPECT TO THE PRODUCT, INCLUDING BUT
NOT LIMITED TO THE MERCHANTABILITY OF THE
PRODUCT OR ITS FITNESS FOR ANY PARTICULAR
PURPOSE OR USE; THE DESIGN, CONDITION OR
QUALITY OF THE PRODUCT; THE PERFORMANCE
OF THE PRODUCT; THE WORKMANSHIP OF THE
PRODUCT OR THE COMPONENTS CONTAINED
THEREIN; OR COMPLIANCE OF THE PRODUCT
WITH THE REQUIREMENTS OF ANY LAW, RULE,
SPECIFICATION OR CONTRACT PERTAINING
THERETO. NOTHING CONTAINED IN THE
INSTRUCTION MANUAL SHALL BE CONSTRUED
TO CREATE AN EXPRESS OR IMPLIED WARRANTY
OF ANY KIND WHATSOEVER WITH RESPECT TO
THE PRODUCT. IN ADDITION, SAMSUNG SHALL
NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND
RESULTING FROM THE PURCHASE OR USE OF THE
PRODUCT OR ARISING FROM THE BREACH OF THE
EXPRESS WARRANTY, INCLUDING INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS
OF ANTICIPATED PROFITS OR BENEFITS.
Modification of Software
SAMSUNG IS NOT LIABLE FOR PERFORMANCE
ISSUES OR INCOMPATIBILITIES CAUSED BY YOUR
EDITING OF REGISTRY SETTINGS, OR YOUR
MODIFICATION OF OPERATING SYSTEM SOFTWARE.
USING CUSTOM OPERATING SYSTEM SOFTWARE
MAY CAUSE YOUR DEVICE AND APPLICATIONS
TO WORK IMPROPERLY. YOUR CARRIER MAY
NOT PERMIT USERS TO DOWNLOAD CERTAIN
SOFTWARE, SUCH AS CUSTOM OS.
Samsung KNOX™
Samsung Knox™ is Samsung’s security platform and
is a mark for a Samsung device tested for security
with enterprise use in mind. Additional licensing fee
may be required. For more information about Knox,
please refer to:
www.samsung.com/us/knox. [030115]

DRAFT
FOR INTERNAL USE ONLY
iii
Samsung Electronics America
(SEA), Inc
Address:
85 Challenger Road
Ridgefield Park,
New Jersey 07660
Phone:
1-800-SAMSUNG (726-7864)
Internet Address:
www.samsung.com
©2015 Samsung Electronics America, Inc.
Samsung, Galaxy, Galaxy Note, S Pen, Multiwindow,
and SHealth are registered trademarks of
SamsungElectronics Co., Ltd.
Do you have questions about your
Samsung Mobile Device?
For 24 hour information and assistance, we offer a
new FAQ/ARS System (Automated Response System)
at: www.samsung.com/us/support
The actual available capacity of the internal memory is
less than the specified capacity because the operating
system and default applications occupy part of the
memory. The available capacity may change when you
upgrade the device.
Nuance®, VSuite™, T9®Text Input, and the Nuance logo
are trademarks or registered trademarks of Nuance
Communications, Inc., or its affiliates in the United
States and/or other countries.
ACCESS®and NetFront™are trademarks or registered
trademarks of ACCESS Co., Ltd. in Japan and other
countries.
The Bluetooth®word mark, figure mark (stylized “B
Design”), and combination mark (Bluetooth word mark
and “B Design”) are registered trademarks and are
wholly owned by the Bluetooth SIG.

DRAFT
FOR INTERNAL USE ONLY
iv
microSD™and the microSD logo are Trademarks of the
SD Card Association.
Openwave®is a registered Trademark of
Openwave,Inc.
Google, the Google logo, Android, the Android logo,
Google Play, Gmail, Google Mail, Google Maps,
Google Music, Google Hangouts, Picasa, Play
Newsstand, YouTube, and other marks are trademarks
of Google Inc.
Wi-Fi is a registered trademark of the WirelessFidelity
Alliance, Inc.
Swype and the Swype logos are trademarks of Swype,
Inc.
Online Legal Information
The online version of the Health/Safety and Warranty
guide for your device can be found at:
English
www.samsung.com/us/Legal/Phone-HSGuide
Spanish
www.samsung.com/us/Legal/Phone-HSGuide-SP
The online version of the End User Licensing
Agreement for your device can be found online at:
www.samsung.com/us/Legal/SamsungLegal-EULA3.

DRAFT
FOR INTERNAL USE ONLY
v
Table of Contents
Getting Started............................................................1
Front View .........................................................................2
Back View .........................................................................4
Assemble Your Device ...................................................6
Set Up Your Device.......................................................10
Secure Your Device ......................................................11
Set Up Accounts on Your Device ..............................12
Know Your Device...................................................13
Home Screen .................................................................14
Status Bar .......................................................................20
Touchscreen Navigation ..............................................22
Notification Panel ..........................................................24
Enter Text ........................................................................26
Calling.............................................................................29
Make and Answer Calls ...............................................30
Applications.................................................................36
Apps Screen...................................................................37
Google Applications .....................................................40
Verizon Applications .....................................................43
Calculator........................................................................45
Calendar..........................................................................46
Camera and Video ........................................................47
Chrome............................................................................51
Clock................................................................................52
Contacts ..........................................................................54
Email ................................................................................61
Emergency Alerts ..........................................................63
Gallery .............................................................................64
Help..................................................................................67
Memo ...............................................................................68
Message+........................................................................69
Messages........................................................................72
Music Player...................................................................75
My Files ...........................................................................77
Video Player ...................................................................80
Voice Recorder..............................................................82

DRAFT
FOR INTERNAL USE ONLY
vi
Settings..........................................................................83
How to Use Settings.....................................................84
Airplane Mode................................................................85
Wi-Fi and Wi-Fi Direct...................................................86
Bluetooth.........................................................................90
Data Usage .....................................................................93
More Settings.................................................................94
Sound and Notification ............................................. 100
Display Settings.......................................................... 104
Wallpaper Settings..................................................... 107
Lock Screen................................................................ 108
Storage ......................................................................... 110
Battery .......................................................................... 113
Ultra Power Saving Mode......................................... 114
Applications................................................................. 115
Easy Mode................................................................... 120
Location Services ...................................................... 121
Security Settings........................................................ 123
Accounts ...................................................................... 126
Language and Input Settings................................... 128
Backup and Reset...................................................... 131
Date and Time Settings............................................. 133
Accessibility ................................................................ 134
Printing ......................................................................... 136
Help............................................................................... 137
About Your Device ..................................................... 138
System Updates ......................................................... 139

DRAFT
FOR INTERNAL USE ONLY
Getting Started
Learn about your mobile
device hardware, assembly
procedures, and how to get
started using your new device.

DRAFT
FOR INTERNAL USE ONLY
2Front View
Getting Started
Front View
Recent apps
Power/Lock key
Front camera
Back
Status light
Earpiece
Volume keys
Home
Proximity and
light sensors

DRAFT
FOR INTERNAL USE ONLY
3Front View
Getting Started
Here are some key features on the
front and sides of your device.
• Back: Tap to return to the previous screen, or to
close a dialog box, menu, or keyboard.
• Earpiece: Listen to a call.
• Front camera: Take pictures and record videos of
yourself.
• Home: Press to return to the Home screen. Activate
the Fingerprint security feature.
• Power/Lock key: Press and hold to turn the device
on or off. Press to lock or wake up the screen.
Press and hold to turn the device off or restart it, or
for quick access to Airplane mode and Emergency
mode.
• Proximity and light sensors: Detects the presence
of objects near the device.
• Recent apps: Tap to display recent apps, or touch
and hold for home screen options.
• Status light: Displays red when charging or the
battery is low, blue when a notification has arrived
or you are voice recording, and green when fully
charged.
• Volume keys: Press to adjust the volume of your
device’s sounds and audio.

DRAFT
FOR INTERNAL USE ONLY
4Back View
Getting Started
Back View
USB charger/Accessory port
Flash
Headset jack
Rear camera
Speaker
Microphone
Microphone

DRAFT
FOR INTERNAL USE ONLY
5Back View
Getting Started
Here are some key features found on
the back and sides of your device.
• Flash: Illuminate subjects in low-light environments
when taking a photo or recording video.
• Headset jack: Connect an optional headset.
• Heart Rate Sensor: When using the S Health
app, this sensor measures your heart rate via your
fingertip.
• Microphone: Records audio and detects voice
commands.
• Rear camera: Take pictures and record videos.
• Speaker: Plays music and other sounds.
• USB charger/Accessory port: Connect the
Charger/USB cable (included), and other optional
accessories (not included).

DRAFT
FOR INTERNAL USE ONLY
6Assemble Your Device
Getting Started
Assemble Your Device
This section helps you to assemble
your device.
Remove the Back Cover
1. Remove the back cover using the slot on the side
of your phone.
2. Lift the cover up and to the right of the phone.
Warning: Do not bend or twist the back cover
excessively. Doing so may damage the cover.
Install the SIM Card
When you subscribe to a cellular network, you are
provided with a plug-in SIM card. During activation,
your SIM card will be loaded with your subscription
details, such as your PIN, available optional services,
and other features.
Warning: The plug-in SIM card information and its
contacts can be easily damaged by scratching or
bending, so be careful when handling, inserting, or
removing the card. Keep all SIM cards out of reach of
small children.

DRAFT
FOR INTERNAL USE ONLY
7Assemble Your Device
Getting Started
►Carefully slide the SIM card into the SIM card slot.
Make sure that the card’s gold contacts face into
the device and that the upper-left angled corner of
the card is positioned as shown.
Caution: If the card is not inserted correctly, the device
will not detect the SIM card. Re-orient the card and place
it back into the slot if the SIM is notdetected.
Install a Memory Card
You can install an optional microSD or microSDHC
memory card (not included) to expand available
memory space.
Note: A memory card can be installed at any time; it is
not necessary to install it prior to using the device.
For more information on installing a memory card, see
“Install a Memory Card” on page 110.
Install the Battery
1. Insert the battery into the opening on the back of
the phone, making sure the connectors align.
2. Gently press down to secure the battery.

DRAFT
FOR INTERNAL USE ONLY
8Assemble Your Device
Getting Started
Replace the Back Cover
1. Place the back cover onto the back of the phone
and press down.
2. Press along the edge of the back cover until you
have a secure seal.
Charge the Battery
Note: For fastest charging times, use the Adaptive
Fast Charging charger that came with your phone. This
charger provides faster charging only when connected to
devices that support Adaptive Fast Charging.
Caution: Use only Samsung-approved charging devices.
Samsung accessories are designed to maximize
battery life. Using other accessories may invalidate your
warranty and may cause damage.

DRAFT
FOR INTERNAL USE ONLY
9Assemble Your Device
Getting Started
1. Insert the USB cable into the port.
2. Connect the USB cable to the charging head, and
then plug the charging head into a standard outlet.
3. When charging is complete, unplug the charging
head from the outlet and remove the USB cable
from the device.
When to Charge the Battery
When the battery is weak and only a few minutes of
operation remain, the device sounds a warning tone at
regular intervals.
In this condition, your device conserves its remaining
battery power by dimming the screen.
When the battery level becomes too low, the device
automatically turns off.
►For a quick check of your battery level, view the
battery charge indicator located in the upper-right
corner of your device’s display. A solid color ( )
indicates a full charge.
You can also choose to display a percentage value.
Viewing a percentage value can provide a better
idea of the remaining charge on the battery. For
more information, see “Battery” on page 113.

DRAFT
FOR INTERNAL USE ONLY
10 Set Up Your Device
Getting Started
Set Up Your Device
Turn Your Device On and Off
Turn the Device On
►Press and hold the Power/Lock key until the
device starts up.
Turn the Device Off
1. Press and hold the Power/Lock key until the
Device options menu displays.
2. Tap Power off.
Welcome Screen
The first time you turn your device on, the Welcome
Screen displays. It will guide you through the basics of
setting up your device.
Follow the prompts to choose a default language,
connect to a Wi-Fi network, set up accounts, choose
location services, learn about your device’s features,
and more.

DRAFT
FOR INTERNAL USE ONLY
11 Secure Your Device
Getting Started
Secure Your Device
Use your device’s screen lock
features to secure your device.
Lock the Device
By default, the device locks automatically when the
screen times out.
►To lock the device, press the Power/Lock key.
Unlock the Device
The default Screen lock on your device is Swipe.
►To unlock your device, press the Power/Lock key
or Home key, and then touch and drag your finger
across the screen.
Set Up a Secure Screen Lock
The default Screen lock is Swipe, which offers no
security. To choose a more secure screen lock, see
“Set a Screen Lock” on page 108.

DRAFT
FOR INTERNAL USE ONLY
12 Set Up Accounts on Your Device
Getting Started
Set Up Accounts on Your Device
Google Account
Your new device uses your Google Account to
fully utilize its Android features, including Gmail,
GoogleHangouts, and the Google Play Store.
When you turn on your device for the first time, set
up your existing Google Account, or create a new
GoogleAccount.
– or –
To create a new Google Account or set up your
Google Account on your device at any time, use
Accounts settings. Formore information, see
“Accounts” on page 126.
►From a Home screen, tap Apps > Settings>
Accounts > Add account > Google.
Samsung Account
Create a Samsung account, for access to Samsung
content and apps on your device.
When you turn on your device for the first time, set
up your existing Samsung account, or create a new
Samsung account.
– or –
To create a new Samsung account or set up your
Samsung account on your device at any time,
use Accounts settings. Formore information, see
“Accounts” on page 126.
►From a Home screen, tap Apps > Settings>
Accounts > Add account > Samsungaccount.

DRAFT
FOR INTERNAL USE ONLY
Know Your Device
Learn some of the key
features of your mobile
device, including the screens
and icons, as well as how to
navigate the device and enter
text using the keyboard.
Warning: Please note that a touch screen
responds best to a light touch from the pad
of your finger or a non-metallic stylus. Using
excessive force or a metallic object when
pressing on the touch screen may damage the
tempered glass surface and void the warranty.
