Samsung GALAXY Note 8.0 Assembly instructions

© Samsung Electronics Co., LTD | Confidential
HW Repair Guide
GT-N5100 (Galaxy Note 8.0)
March, 2013

2
© Samsung Electronics Co., LTD | Confidential
1. All functionality, features, specifications and other product
information provided in this document including, but not limited
to, the benefits, design, pricing, components, performance,
availability, and capabilities of the product are subject to change
without notice or obligation. Samsung reserves the right to make changes to this docume
nt and the product described herein, at anytime, without obligation on Samsung to provid
e notification of such change.
2. In data of our company, important management / technical information is included,
and if it is leaked, loss can happen in various aspect such as closing a technology gap,
increasing ability to respond.
Therefore, it is strictly prohibited from information leak or forwarding this material, and if
leak of management / technical information due to disobeying the law happens, it can be
severely punished in accordance with information protection rule of our company.
NOTICE

3
© Samsung Electronics Co., LTD | Confidential
Contents
1. Introduction of GALAXY Note 8
2. Service Guide
•RF calibration
•IMEI writing
•Block Diagram
3. Repair Guide
•Assembly & Disassembly
•Electronic Components
•SMD parts
•Trouble Shooting
4. Q&A

4
© Samsung Electronics Co., LTD | Confidential
Introduction of GALAXY Note 8.0
Specification
Item spec.
AP
1.6GHz Quad
Core(Exynos 4412)
OS
Android
JB
CP
XMM
6262(IMC), HSPA+ 21.1Mbps, HSUPA 5.76Mbps
Supported RF Bands
GSM
Quad(850, 900, 1800, 1900), UMTS Quad(850, 900, 1800, 1900)
Internal Memory
16GB NAND + 2GB RAM
External Memory
MicroSD
(up to 64GB)
Display
8” TFT
(1280 x 800)
Camera
5MP CMOS
+ 1.3MP CMOS
Sensor
Accelerometer,
Magnetic, Proximity, Light, Grip
Connectivity
BT 4.0, Wi
-Fi a/b/g/n
GPS
A
-GPS + GLONASS
Battery
4600mA
This model is the portable media Tablet device and it has 8 inches size.
So, it expected to replace the diary and it has S-pen, S-planner, S-Note, etc.

5
© Samsung Electronics Co., LTD | Confidential
RF calibration(1/3)
Please download the latest version of RF Calibration program on the PLM
System. (Daseul Launcher, Runtime and Model File)
Run Calibration program
Check the Calibration
and select correct file
Click the Extract
& Run button
Check the CAL Check and
select correct file
Click the Start button

6
© Samsung Electronics Co., LTD | Confidential
RF calibration(2/3)
Check the Calibration
Check the
System Config items
Click the
Model Information
Type the correct
H/W version
Check the connection port of
Phone, MSTS and Power Supply
Click the
Hardware Config
Click the
OK button

7
© Samsung Electronics Co., LTD | Confidential
Click the Start button and
connect the phone to Anyway Jig.
RF calibration(3/3)
The Result bar is changed to the GREEN
color if the calibration is Passed.

8
© Samsung Electronics Co., LTD | Confidential
IMEI Writing (1/3)
Please download the latest version of RF Calibration program on the PLM
System. (Daseul Launcher, Runtime and Model File)
Run Daseul program for IMEI writing.
Check the IMEI
and select correct file
Click the Extract
& Run button
Check the IMEI
Check and
select correct file
Click the Start button

9
© Samsung Electronics Co., LTD | Confidential
IMEI Writing (2/3)
Check the IMEI Write
and IMEI Check Check the
System Config items
Click the
Hardware
Config
Check the connection port of
Phone and Power Supply
Check the
OK button

10
© Samsung Electronics Co., LTD | Confidential
IMEI Writing (3/3)
Type the correct
IMEI number
Click the Model Info
Type the correct
Software, Hardware,
CSC, PDA and
SKU_CODE etc.
Click the Start button and
connect the phone to Anyway Jig.
The Status bar is changed to
GREEN color if IMEI writing is Passed

11
© Samsung Electronics Co., LTD | Confidential
Block Diagram

12
© Samsung Electronics Co., LTD | Confidential
Assembly & Disassembly Instruction
<Assembly>

13
© Samsung Electronics Co., LTD | Confidential
Assembly & Disassembly Instruction

14
© Samsung Electronics Co., LTD | Confidential
Assembly & Disassembly Instruction

15
© Samsung Electronics Co., LTD | Confidential
Assembly & Disassembly Instruction
<Disassembly>

16
© Samsung Electronics Co., LTD | Confidential
Assembly & Disassembly Instruction

17
© Samsung Electronics Co., LTD | Confidential
Assembly & Disassembly Instruction

18
© Samsung Electronics Co., LTD | Confidential
Electronic Components
SPK(L)
Module
Main Antenna
TSP connector
SIM card
socket
SD card socket/
Motor module
GH42-03975A
5M
CAM
1.3M
CAM
Receiver/
3.5pi Ear Jack/
Light-Proximity
sensor Module
Sub MIC/
Power-volume key/
IrDA Module
S-Pen
LCD connector
11pin sub PCB
(including SPK(R) connector
and Home key FPCB connector
SPK(R)/
Main MIC
Module
BT/WIFI/GPS
Antenna
(on the rear cover)
WACOM
connector
GH42-03977A
GH59-12911A
GH96-06106A
GH96-05974A
GH59-12906A
GH59-12908A
GH59-12907A
GH59-12910A
GH59-13117A
GH59-13124A
GH59-12919A
Home
key FPCB
GH59-13128A
GH98-25480A

19
© Samsung Electronics Co., LTD | Confidential
SMD parts (TOP side)
OSC200 2805-001098
Oscillator –26MHz
UME600 1107-002190
MoviNAND
U701 1203-007657
PMIC
UCD400 1205-004510
Audio CODEC
U1001 1204-003387
IrDA IC
Ant100, Ant101 3712-001375
Ant. Contact (for GSM, WCDMA) U900 1209-002142
Magnetic Sensor
U201 1205-004649
GPS IC (inside of shield-can)
HDC900 3708-002222
Connector (5M Camera)
U702 1203-006346
Reset IC

20
© Samsung Electronics Co., LTD | Confidential
SMD parts (Bottom side)
U106 1209-002006
Grip Sensor IC
U1008 1205-004674
WACOM IC
Ant202, Ant203 3712-001375
Ant. Contact (for BT, WIFI, GPS)
HDC500 3711-007173
Connector (SD card & Motor)
SLC1000 3708-003131
Connector (WACOM)
F100 2911-000236
Antenna Switch Module
U203 1205-004598
Bluetooth & WIFI IC
(inside of shield-can)
HDC1000 3711-006923
Connector(Power & Vol & IrDA)
HDC901 3711-006925
Connector (1.3M Camera)
HDC402 3711-007188
Connector (Receiver & Ear Jack
& Light-Proximity sensor)
U104 1203-007333
PAM DCDC
U705 1203-007321
IF PMIC
C1013 1205-004233
MHL IC
HDC400 3711-008347
Connector (SPK-L)
HDC300 3711-008347
Connector (SIM)
UCP600 0902-002996
Application Processor
BTC700 3711-008421
Connector (Battery)
UME300 1105-002212
Mobile DDR SDRAM
SLC900 3708-002781
Connector (TSP)
UCP300 1205-004511
Call Processor
PAM100 1201-003400
Power Amplifier Module
U105 1203-006801
Transceiver DCDC
OSC100 2801-005166
DCXO –26MHz
U100 1205-004515
Transceiver
F101 2910-000190
SAW Duplexer
U904 1205-004521
TSP IC
U901 1209-002153
Acc. Sensor
HDC800 3711-007295
Connector (LCD)
IFC500 3711-006843
Connector (11pin sub PCB)
