WELCOME
Thank you for choosing us.
This guide will introduce you to the
features and functions of your new phone.
NOTE: Screen images and icons are simulated. Actual
display may vary. Instructions in this guide may
change depending on the software version on
your device. All procedures begin in portrait
mode, with phone open (flip open) unless
otherwise noted.
WELCOME

8
9
6 7
54
1
2
3
YOUR PHONE
4
FRONT AND BACK FEATURES
1. HEADSET
CONNECTOR
2. FRONT FACING
CAMERA
3. DISPLAY
4. MENU KEY
5. HOME KEY
6. BACK KEY
7. SEARCH KEY
8. EARPIECE
9. CAMERA LENS
AND FLASH
YOUR DEviCE

1
5
YOUR PHONE
4
3
2
SIDE FEATURES
1. VOLUME KEY
2. CHARGER/USB
CONNECTOR
3. HDMI PORT
4. POWER/LOCK
KEY
NOTE: The microSD card
slot is located
under the battery
cover.

YOUR PHONE
6
4G LTE SIM CARD INSTALLATION/
REMOVAL
When you subscribe to a 4G LTE cellular
network, you are provided with a plug-in
SIM card loaded with your subscription
details.
Installing the 4G LTE SIM Card
●Open the cover to the SIM Card slot
and carefully insert the 4G LTE SIM
card with the gold contact facing
down
microSD slot

7
YOUR PHONE
NOTE: Do not bend or scratch your 4G LTE SIM
Card. Avoid exposing your SIM Card to static
electricity, water or dirt.
Removing the 4G LTE SIM Card
●To remove the 4G LTE SIM card, turn off
your device. Then carefully slide the SIM
card out of the SIM card socket.

YOUR PHONE
8
NOTE: This device requires a SIM card. Please insert
the SIM card included in the package prior to
turning on the device. This SIM card will only
work with this device. Once the SIM card has
been inserted, do not remove!
If your SIM card is ever separated from the
device or damaged, your device will not
function. If you experience any issues with your
device, contact Customer Service at
888-944-9400 (or dialing 611 on Your U.S.
Cellular
®
handset) or visit your nearest U.S.
Cellular retail location.
SIM Card Limited Warranty
Subject to the exclusions contained below,
United States Cellular Corporation (“U.S.
Cellular
®
”) warrants to the original purchaser
(“You” or “Your”) of the handset with which the
SIM card was provided that the SIM card will be
free from defects in material and workmanship
for a period of one (1) year from the date You
purchased the handset (the “Warranty Period”).
This warranty is not transferable. Should a
defect appear during the Warranty Period,
U.S. Cellular will send a replacement SIM
card to Your address within the United States
without charge provided that you request the
replacement SIM card during or within thirty
(30) days following the Warranty Period by
calling U.S. Cellular Customer Service at
888-944-9400 (or dialing 611 on Your U.S.
Cellular handset) or by visiting a U.S. Cellular
retail store.

9
YOUR PHONE
REPLACEMENT OF THE SIM CARD AS
PROVIDED HEREIN IS YOUR EXCLUSIVE
REMEDY UNDER THIS LIMITED WARRANTY,
AND IS IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED INCLUDING, WITHOUT
LIMITATION, ANY WARRANTIES OF TITLE,
FITNESS FOR A PARTICULAR PURPOSE,
MERCHANTABILITY, NON-INFRINGEMENT
OR ARISING FROM COURSE OF DEALING OR
USAGE OF TRADE. NEITHER U.S. CELLULAR
NOR ANY OF ITS AFFILIATES OR RETAILERS
SHALL BE LIABLE TO YOU FOR ANY DIRECT,
INDIRECT, INCIDENTAL, SPECIAL, ECONOMIC,
EXEMPLARY, PUNITIVE OR CONSEQUENTIAL
DAMAGES (INCLUDING, WITHOUT LIMITATION,
LOSS OF DATA, LOSS OF REVENUE OR
PROFITS, DAMAGE TO PROPERTY OR LOSS OF
USE). IN NO EVENT SHALL U.S. CELLULAR’S,
ITS AFFILIATES’ OR RETAILERS’ LIABILITY TO
YOU OR ANY THIRD PARTY WITH RESPECT
TO THE SIM CARD EXCEED THE COST OF
REPLACING THE SIM CARD.
THIS LIMITED WARRANTY SHALL BE
CONSTRUED UNDER THE LAWS OF THE STATE
OF ILLINOIS, EXCLUDING ITS CONFLICTS
OF LAW PROVISIONS. SOME STATES AND
JURISDICTIONS DO NOT ALLOW LIMITATIONS
ON HOW LONG AN IMPLIED WARRANTY
LASTS, OR THE DISCLAIMER OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATIONS AND
DISCLAIMERS MAY NOT APPLY TO YOU.
No agent, employee, dealer, retailer,
representative or reseller is authorized to modify
or extend the terms of this Limited Warranty.

YOUR PHONE
10
BATTERY INSTALLATION/REMOVAL
Your device is powered by a rechargeable,
standard Li-Ion battery.
NOTE: Although the battery comes partially charged,
you must fully charge this battery before using
your device for the first time.
WARNING: Use only Samsung-approved charging
devices and batteries. Samsung accesories
are designed to maximize battery life. Using
other accessories may invalidate your
warranty and may cause damage.
Installing the Battery
Release Latch
1. Hold the device firmly and locate the
cover release latch.

2. Place your fingernail in the opening
and firmly “pop” the cover off the
device (similar to a soda can).
3. Slide the battery into the
compartment (3) so that the tabs on
the end align with the slots at the
bottom of the device, making sure
the connectors align.
4. Gently press down to secure the
battery (4).
5. Replace the battery cover by sliding
it back into place and snapping the
edges securely at all four corners.
Battery Insertion Battery Removal
11
YOUR PHONE

Removing the Battery
1. Place your fingernail in the opening
on the cover release latch and
firmly “pop” the cover off the device
(similar to a soda can).
2. Place your finger into the battery
groove.
3. Grip the battery at the top end (5)
and lift it up and out of the battery
compartment (6).
YOUR PHONE
12

13
YOUR PHONE
CHARGING YOUR BATTERY
Your device comes with a USB cable and
charging head to rapidly charge your
device from any 120/220 VAC outlet.
NOTE: Although the battery comes partially charged,
you must fully charge this battery before using
your device for the first time.
1. Connect the USB cable to the
charging head.
2. Plug the charging head into a
standard AC power outlet.
INCORRECT
CORRECT
CHARGING HEAD

YOUR PHONE
14
3. Insert the USB cable into the device’s
Power/USB connector. The device
turns on with the screen locked and
indicates both its charge state and
percent of charge.
4. Once complete, unplug the charging
head from the power outlet and
remove the USB cable from the
device.
INCORRECT
CORRECT

15
YOUR PHONE
TURNING YOUR DEVICE ON OR OFF
To power on your device:
XPress and hold
(Power/Lock) until the device turns
on.
To power off your device:
1. Press and hold
(Power/Lock) until the device
options screen appears.
2. Touch Power off.

PHONE FUNCTiONS
16
EXTENDING YOUR BATTERY LIFE
Active applications, light levels, Bluetooth
usage, and GPS functionality all act to
drain your battery. The following is a list
of helpful tips that can help conserve your
battery power:
●Deactivate the GPS when not needed.
Most applications using this function will
periodically query the GPS satellites for
your current location; each query drains
your battery.
●Do not wait until your battery is
completely depleted before charging
your device. Repeating this process of
a complete discharge and recharge can
over time reduce the storage capacity of
any battery.
●Turn Automatic application sync off.
DEviCE FUNCTiONS

17
PHONE FUNCTiONS
●Use the Power Control Widget to
deactivate hardware functions such as
Wi-Fi, Bluetooth, GPS, Synchronization
or LCD brightness setting.
●Check the Battery use screen to review
what features or functions have been
consuming your battery resources.
●Check the Running Services and close
any unnecessary applications.
●Use the Task Manager feature to end/
shutdown background applications
that are still running. These minimized
applications can, over time, cause your
device to “slow down”.
●Animated wallpapers use processing
power, memory, and more power.
Change your Live wallpaper to a non-
animated Wallpaper gallery or Gallery
image.
●Turn 4G LTE off when not in use.
●Reduce your backlight on time.
●Turn Bluetooth®off when not in use.
●Turn Wi-Fi off when not in use.

PHONE FUNCTiONS
18
LOCKING AND UNLOCKING YOUR
DEVICE
By default, the device screen locks when
the backlight turns off.
To unlock your device from the lock
screen:
XWith your device turned on, press
(Power/Lock) to wake the
display and sliding your finger across
the screen in any direction.
To lock your device screen:
XPress (Power/Lock).
The screen goes black.

19
PHONE FUNCTiONS
NOTIFICATION RINGTONES
Your device comes with a selection of
notification ringtones. Here’s how to
manage your preferences:
Selecting a ringtone
1. From the Home screen press
(Menu)gSettings () gSound
gNotification ringtone.
2. Touch a ringtone to hear a sample
and to select it.
3. Touch OK to save setting.
Setting ringtone to vibrate
To activate Vibrate, press the Volume key
(on the left side of your device) down, until
you feel the device vibrate. To resume
normal ringing, press the Volume key up.
