INTRODUCTION
INTRODUCTION
SUPPORT
This guide provides you with the information
you need to get started. For more information
and additional support, please visit
www.t-mobile.com/support where you can:
●Register at my.t-mobile.com to check your
minutes, pay your bill, upgrade your phone, and
change your rate plan.
●Review your device’s User Manual and
troubleshooting FAQs.
●View the latest troubleshooting solutions in the
Support Forums or ask a question of your own.
You can also access account and device
information from:
1. From the Home screen, tap (Apps) g
(T-Mobile My Account).
2. If prompted, follow the on-screen information for
what’s new in the app.
3. Choose from an available category such as:
Account Info,Device Support,Notifications,
MobileLife FamilyWhere, and others.
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 3 3/28/2013 10:55:06 AM

DRAFT
Internal Use Only
INTRODUCTION
4
SERVICE
If you are a new T-Mobile®customer and your
service has not yet been activated, call Customer
Care at 1-800-937-8997 and a T-Mobile Activations
representative will assist you.
You will need the following information when
activating service:
●Your Service Agreement and the agent code on
your Agreement
●Your name, home address, home phone number,
and billing address
NOTE: For business and government accounts, please provide the
name of the organization, the address, and the tax ID.
●Your Social Security number, current driver’s
license number, and date of birth for credit check
purposes
●Your choice of T-Mobile rate plan and services
(see www.t-mobile.com for the latest plan
information)
●SIM serial number and IMEI number (located on
the box barcode label)
NOTE: By activating service, you acknowledge that you have read,
understand, and agree to be bound by each of T-Mobile’s
Terms and Conditions, and your Service Agreement.
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 4 3/28/2013 10:55:06 AM

DRAFT
Internal Use Only
5
YOUR DEVICE
YOUR DEVICE
FRONT AND BACK FEATURES
1. INDICATOR LIGHT
2. MENU KEY
3. HOME KEY
4. BACK KEY
5. DISPLAY
6. RECEIVER
7. FRONT-FACING
CAMERA
8. SENSORS
9. FLASH
10. CAMERA LENS
910
43
2
5
6
8 71
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 5 3/28/2013 10:55:09 AM

DRAFT
Internal Use Only
YOUR DEVICE
6
SIDE FEATURES
1. IR TRANSMITTER
2. HEADSET CONNECTOR
3. VOLUME KEY
4. MICROPHONE
5. CHARGER/ACCESSORY
JACK
6. SPEAKER
7. POWER/LOCK KEY
7
6
3
5
4
2 1
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 6 3/28/2013 10:55:11 AM

DRAFT
Internal Use Only
7
YOUR DEVICE
BATTERY INSTALLATION/REMOVAL
Your device is powered by a rechargeable, standard
Li-Ion battery. The battery, SIM card and SD card
are installed under the battery cover.
NOTE: Although the battery comes partially charged, you must fully
charge this battery before using your device for the first time.
WARNING: Use only Samsung-approved charging devices and
batteries. Samsung accessories are designed to
maximize battery life. Using other accessories may
invalidate your warranty and may cause damage.
IMPORTANT: Before removing or replacing the battery, make sure
the device is switched off. To turn the device off,
hold down the key until the Device options
screen displays, then tap Power off.
Caution!: Do not bend or twist the back cover excessively during
installation or removal. Doing so may damage the cover.
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 7 3/28/2013 10:55:11 AM

DRAFT
Internal Use Only
YOUR DEVICE
8
Removing the Battery Cover
1. Hold the device firmly and locate the cover
release latch (1).
2. Place your fingernail in the opening (2) and
firmly “pop” the cover off the device (similar
to a soda can)
3. Carefully remove the cover.
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 8 3/28/2013 10:55:12 AM

DRAFT
Internal Use Only
9
YOUR DEVICE
Installing and Removing the SIM Card
IMPORTANT: Before removing or replacing the SIM card, make
sure the device is switched off. To turn the device off,
hold down the key until the Device options
screen displays, then tap Power off.
This device uses a different type of SIM card called
a “micro SIM”. Other larger SIM cards will not
function or fit within this slot.
To install the micro SIM card:
1. Carefully slide the micro SIM card into the
socket until the card clicks into place.
2. Make sure that the card’s gold contacts face
into the device and that the upper-left angled
corner of the card is positioned as shown.
Incorrect
Correct
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 9 3/28/2013 10:55:12 AM

DRAFT
Internal Use Only
YOUR DEVICE
10
Installing the microSD Memory Card
Your device supports an optional (external) microSD
memory card for storage of media such as music,
pictures, video and other files.
NOTE: microSD memory cards include capacities of up to 2GB.
microSDHC™ memory card types can range from 4GB to
up to 32GB. microSDXC™ memory card types can include
capacities greater than 32GB.
NOTE: This device supports a memory card of up to a 64GB.
WARNING: Applications, personal settings and other stored data
may be lost or may not function properly if the memory
card is removed.
1. Remove the battery cover.
2. Locate the microSD card slot on the inside of
the device.
Correct
Incorrect
3. Orient the card with the gold strips facing down.
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 10 3/28/2013 10:55:13 AM

DRAFT
Internal Use Only
11
YOUR DEVICE
4. Carefully slide the microSD card into the card
socket until it clicks into place.
Installing the Battery
1. Slide the battery into the compartment (1) so
that the tabs on the end align with the slots
at the bottom of the phone, making sure the
connectors align.
2. Gently press down to secure the battery (2).
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 11 3/28/2013 10:55:13 AM

DRAFT
Internal Use Only
YOUR DEVICE
12
Removing the Battery
XGrip the battery at the top end (3) and lift it
up and out of the battery compartment (4).
Replacing the Battery Cover:
XPosition the battery cover over the battery
compartment and press down around the rim
of the device until you hear clicks and the
cover is secure.
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 12 3/28/2013 10:55:13 AM

DRAFT
Internal Use Only
13
YOUR DEVICE
CHARGING THE BATTERY
Your device is powered by a rechargeable Li-ion
battery. A wall charger, which is used for charging
the battery, is included with your device. Use only
approved batteries and chargers. Ask your local
T-Mobile dealer for further details.
IMPORTANT: Verify that the battery is installed prior to connecting
the wall charger. If both the wall charger is connected
and the battery is not installed, the handset will power
cycle continuously and prevent proper operation.
Failure to unplug the wall charger before you
remove the battery, can cause the device to become
damaged.
1. Connect the USB cable to the charging head.
2. Locate the Charger/Accessory jack.
Correct
Incorrect
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 13 3/28/2013 10:55:13 AM

DRAFT
Internal Use Only
YOUR DEVICE
14
3. Insert the USB cable into the device’s
Charger/Accessory jack.
Correct
Incorrect
4. Plug the charging head into a standard AC
power outlet. The device turns on with the
screen locked and indicates both its charge
state and percent of charge.
5. When charging is finished, first unplug the
charger’s power plug from the AC wall outlet,
then disconnect the charger’s connector from
the device.
NOTE: For the most efficient charging, consumers should use the
charger included in the box.
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 14 3/28/2013 10:55:14 AM

DRAFT
Internal Use Only
15
YOUR DEVICE
EXTENDING YOUR BATTERY LIFE
The following is a list of helpful tips that can help
conserve your battery power:
●Reduce your backlight on time.
●Turn Bluetooth®off when not in use.
●Turn Wi-Fi®off when not in use.
●Deactivate the GPS when not needed. Most
applications using this function will periodically
query the GPS satellites for your current location;
each query drains your battery.
●Do not wait until your battery is completely
depleted before charging your device. Repeating
this process of a complete discharge and
recharge can, over time, reduce the storage
capacity of any battery.
●Turn off Automatic application sync.
●Use the Power Saving feature to deactivate some
hardware and interface functions.
●Check the Running Services and close any
unnecessary applications.
●Use the Task manager feature to end/shutdown
background applications that are still running.
These minimized applications can, over time,
cause your device to “slow down”.
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 15 3/28/2013 10:55:14 AM

DRAFT
Internal Use Only
YOUR DEVICE
16
TURNING YOUR DEVICE ON OR OFF
Powering On Your Device
XPress and hold (Power/Lock) until
the device turns on. It searches for your
network and after finding it, you can make or
receive calls.
Powering Off Your Device
1. Press and hold the (Power/Lock)
until the Device options screen appears.
2. Tap (Power off).
Restarting Your Device
1. Press and hold the (Power/Lock)
until the Device options screen appears.
2. Tap (Restart).
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 16 3/28/2013 10:55:14 AM

DRAFT
Internal Use Only
17
YOUR DEVICE
LOCKING AND UNLOCKING YOUR DEVICE
By default, the device screen locks when the
backlight turns off.
To unlock your device from the lock screen:
XWith your device turned on, press
(Power/Lock) to wake the display and sliding
your finger across the screen in any direction.
To lock your device screen:
XPress (Power/Lock). The screen
goes black.
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 17 3/28/2013 10:55:14 AM

DRAFT
Internal Use Only
YOUR DEVICE
18
HOME SCREEN
Swipe your fingers left or right to view the entire
Home screen. You can customize the screen with
widgets and shortcuts to your favorite applications.
Status Bar
The Status bar appears at the top of your Home
screen. Icons indicating your device’s status and
new notification alerts appear on the Status bar.
1
2
3
1. NOTIFICATIONS AREA
2. STATUS BAR
3. STATUS AREA
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 18 3/28/2013 10:55:14 AM

DRAFT
Internal Use Only
19
YOUR DEVICE
CHARGING HEAD
Notification Screen
The Notification area indicates new message
events (data sync status, new messages, calendar
events, call status, etc). You can expand this area
to reveal the Notification screen that provides more
detailed information about the current on-screen
notification icons.
Opening the Notification Screen
1. In a single motion, touch and drag the Status
bar down to the bottom of the screen to open
the Notification screen (1).
2. Tap a notification entry to open the
associated application (2).
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 19 3/28/2013 10:55:14 AM

DRAFT
Internal Use Only
YOUR DEVICE
20
Accessing Additional Functions
In addition to notifications, this screen also provides
quick and ready access to device functions. These
can be quickly activated or deactivated.
Scrolling across a horizontal list of functions has
been enhanced with an accessible Grid view.
To activate the Grid view:
XFrom the Notification panel, tap (Open
Grid view) to display additional functions.
To minimize the Grid view:
XFrom the Notification panel, tap (Close
Grid view) to show only your primary
functions.
TMO_M919_English_GSG_MCK_PS_032713_F3-rev2.indd 20 3/28/2013 10:55:15 AM
