Get started.
All you need to know to get going.

Welcome
Thanks for joining Sprint in our efforts
to make our world a better place. We’re
committed to developing technologies
that give you the ability to get you what
you want when you want it, faster than
ever before. This booklet introduces
you to the basics of getting started with
Sprint and your new Samsung Reclaim™.
The full User Guide for your phone, along
with instructional videos and tutorials, can
be found at sprint.com/reclaimsupport.
Only on the Now Network TM.
© 2009 Sprint. Sprint and the
logo are trademarks of Sprint.
Other marks are property of
their respective owners.

Get Your Phone Ready
Insert the Battery
1. Remove the battery compartment cover on the back of
the phone by pressing down and sliding it in the
direction of the arrow on the cover and then lifting the
battery compartment cover up and off.
2. Insert the battery into the battery compartment
and gently press down until it clicks into place.
3. Replace the battery cover.
Charge the Battery
1. Plug the phone charger into an outlet.
2. Plug the other end of the charger into the phone’s
charger or accessory jack.
Turn the Phone On
• Pressandhold to turn the phone on.
Switch to Spanish Menus
1. Highlight and press > Settings >
Display > Language.
2. Highlight Español and press .

Activate Your Phone
• IfyoupurchasedyourphoneataSprintStore,itis
probably activated and ready to use.
• Ifyoureceivedyourphoneinthemail,anditisanew
Sprintaccountoranewphonenumber,yourphoneis
designed to activate automatically when you first turn it
on.Toconrmyouractivation,makephonecall.
• Ifyoureceivedyourphoneinthemailandyouare
switching numbers from a previous Sprint phone to the
newphone,youneedtogoonlinetoactivatethe
number on your new phone.
• Fromyourcomputer’sWebbrowser,goto
sprint.com/activate and complete the onscreen
instructions to activate your phone.
 Whenyouhavenished,makeaphonecalltoconrm
your activation. If your phone is still not activated or you
donothaveaccesstotheInternet,contactSprint
Customer Service at 1-888-211-4727 for assistance.
Activate Your Phone

Make Your First Call
Make Your First Phone Call
1. Enter a phone number using your keypad. (If you make
amistakewhiledialing,press to erase.)
2.Press .
3.Whenyou’renished,press .

Navigate Your Phone
Introducing Sprint One Click
Sprint One Click brings all your favorite features to your
fingertips on your Samsung Reclaim™.
This easy-to-use design lets you access features
such as MESSAGING ,SPRINT NAVIGATION ,
GOOGLE ,FACEBOOK ,MYSPACE ,
BEST OF GREEN and the INTERNET all
without having to leave the main screen. It also gives
you at-a-glance access to personalized information
“bubbles” when you’re on the Home screen.

Get to Know the Main Screen
• Carousel – The bottom row of tiles,oricons,onyour
main screen. The carousel gives you instant access to
your favorite features.
 Tohighlightatile,pressthenavigationkeyright
or left to move the carousel. The center tile is the
highlighted tile. (The Home tile is highlighted in the
illustrationabove,displayingtheHomescreen.)
 Tohighlightanoptionaboveatile,pressthenavigation
key up or down to select it.
• Bubbles – The “at-a-glance” information windows
available when the Home screen is displayed.
 Toaccessthephone’smainmenu,highlight and
press .
Bubbles
Navigation
Key
Left
Softkey
Tiles
Carousel
Menu/OK
Key
Right
Softkey

Navigate Your Phone
Personalize Your Home Screen
Add up to eight “bubbles” to your Home screen to
display the information you want at a glance.
1. Highlight and press OPTIONS (left softkey) >
Personalize Home Screen > Add a Bubble.
2. Highlight a bubble (such as Date and Time ,News
,Weather ,SportsNews ,Finance ,or
Horoscope ) and press ADD(leftsoftkey).Followthe
instructions to customize your selection.
• Tousethebubbles,pressthenavigationkeyupor
downtohighlightabubble,andthenpress to
display more information.
Personalize Your Carousel
 Yourphone’scarouselholdsupto15tiles.Add,
remove,andrearrangetilesasoftenasyoulike.
Formoreinformation,seeSection 2B: Navigating the
Main Screen in your User Guide.
Learn More
Use the built-in Tutorial to learn all you need to know
about Sprint One Click. Highlight and press
OPTIONS (left softkey) > Tutorial.

Set Up YourVoicemail
All unanswered calls are automatically transferred to
yourvoicemail,evenifyourphoneisinuseorturned
off. You should set up your voicemail and personal
greeting as soon as your phone is activated. Always use
a passcode to protect against unauthorized access.
1. Press and hold .
2. Followthesystempromptstocreateyourpasscode
and record your name and greeting.
Retrieve YourVoicemail
 Fromyourphone:
1. UsingOneTouchMessageAccess,press
and hold .
2. Otherwise,usethemenukeystohighlight and
press > Messages > Voicemail > Call Voicemail.
 Fromanyotherphone:
1. Dial your wireless phone number.
2. Whenyourvoicemailanswers,press*.
3. Enter your passcode.
Voicemail

Select Ringer Types for Voice Calls
and Messages
1. Highlight and press > Settings > Sounds >
RingerType > Incoming Calls,andthenselect
Contact Entries or Unknown Numbers. (A list of
ringer type categories will be displayed.)
-or-
Highlight and press > Settings > Sounds >
RingerType > Messages,andthenselectVoicemail,
Text Message,orPicture Mail. (You will see a list of
ringer type categories.)
2.Selectacategory(forexample,Ring Tones,Melodies,
or My Stuff),andthenuseyournavigationkeytoscroll
through the available ringers. A sample ringer will
sound as you highlight each option.
3. Press to assign a ringer.
Get New Ringers
1. Highlight and press > My Stuff > Ringers >
Get New Ringers. (The browser starts and displays the
Ringers menu.)
2. Use your navigation key and keypad to search through
availableringers.Whenyoundoneyouwant,
highlight it and press .
3. Tomakeapurchase,highlightBuyandpress
(Your phone automatically downloads the ringer.)
Settings

4. Whenthedownloadisnished,selectanoption
tocontinue:
• Listen to listen to the ringer.
• SetAsto assign the ringer to a call or message type
or to a specific contact.
• Shop to browse for other items to download.
Note:Additionalchargesmayapply,butsomearefree.
Adjust the Phone’s Volume Settings
1. Highlight and press > Settings > Sounds >
Volume.
2. Select Ringer,Earpiece,Headset,Speakerphone,or
Advanced....
3. Usingthenavigationkey,chooseavolumeleveland
press .
Set Phone to Vibrate
• Press the side volume button down in standby mode
until you see “Vibrate All” on the screen.
Set Phone to Vibrate with Ringer
1. Press the side volume button up or down in standby
mode until a volume setting appears on the screen.
2. Press VIB ON (left softkey). (If you have already
checkedtheoption,pressingVIB ON [left softkey]
again deselects the option.)
Set Phone to Silence All
• Press the side volume button down in standby mode
until you see “Silence All” on the screen.

Save a Phone Number
1. Enter a phone number and press OPTIONS (right
sofkey) > Save.
2. Select New Entry tocreateanewcontact,orExisting
Entry to save the number to an existing contact.
3. Select a category for the number (such as Mobile,
Home,Work,Pager,Fax,orOther),enteranamefor
theentry,andaddanyotherinformationyouwishto
store to the contact.
4. Press and then press DONE (left softkey).
Retrieve a Phone Number
1. Highlight and press > Contacts.
2. Useyournavigationkeytoscrollthroughtheentries,or
use your keypad to enter the first few letters of the
contact entry.
3. Todisplayanentry,highlightitandpress .
4. Tocalltheentry’sdefaultphonenumber,highlightit
and press .
Note: You can also display the Contacts list by pressing
CONTACTS (right softkey) in standby mode.
Contacts

Assign a Speed Dial Number
1. Add a phone number to a new or to an existing
Contacts entry.
-or-
Select a Contacts entry and press to display the
Contact Details page.
2. Highlight the desired number and press OPTIONS
(right softkey) > Set Speed Dial.
3. Select an available (unassigned) speed dial location
and press ASSIGN (right softkey) or press .
Create a Group
1. Highlight and press > Contacts.
2. Press OPTIONS (right softkey) > New Group to create
a new Group category.
3. Read the onscreen information and press START
(left softkey).
4. Add multiple entries (two or more) to your new group
by highlighting a name from the list and pressing .
This action places a check mark alongside the name.
5. Press CONTINUE (left softkey) and enter a name for
the new group.
6. Press SAVE (left softkey) to assign the selected entries
to the new group.

Pictures & Video
Take a Picture
1. Highlight and press > Photos > Camera to
activate the phone’s camera. (You can also press the
camera button.)
2. Usingyourdisplayasaviewnder,aimthecameralens
atyoursubject,andpress or the camera button.
3. Press toreturntoCameramode,orpressOPTIONS
(rightsoftkey)toexploreotheroptions,including
sending the picture using Sprint Picture Mail.
Record a Video
1. Highlight and press > Photos > Camcorder to
activate the video camera.
2. Select VideoMail or LongVideo.
3. Usingthephone’sdisplayscreenasaviewnder,
aimthelensatyoursubject,andpress ,orthe
camera button to begin recording.
4. Press or the camera button to stop recording.
5. Press OPTIONS(rightsoftkey)toexploreoptions,
including sending the video using Sprint Picture Mail.
Note: The keyboard must be open to activate Camera or
Camcorder mode.

View Pictures and Videos
1. Highlight and press > Photos > My Albums >
In Phone or Memory Card.
2. Use your navigation key to view and scroll through the
pictures and videos.
Choose Settings
1. Highlight and press > Photos >
Settings and Info.
2. Selectoneofthefollowingoptions:
• Auto Save to to choose between Phone and Card
as the default location to save pictures or videos.
• Status Bar to select whether the Status Bar is
displayed onscreen when the camera/camcorder
is active.
• Account Info to display your current Picture Mail
account settings via an online connection.

Send a Text Message
1. Press > Messages > Send Message >
Text Message.
–or–
Press .
2. Selectarecipientfromrecentmessages,orselectGo
to Contactstoselectarecipientfromyourcontacts,or
press NEW ADDR. (right softkey) to enter a phone
number or email address by hand.
3. Enter a wireless phone number or email address. If
prompted,pressCONTINUE (left softkey).
4. UseyourkeypadoryourQWERTYkeyboardtoentera
message or press OPTIONS (right softkey) to choose
from preset messages or emoticons.
5. Press SEND (left softkey).
Messaging

Send a Picture orVideo
1. Highlight and press > Messages >
Send Message > Picture Mail.
2. Select Go to Contacts or NEW ADDR (right softkey) to
entertherecipients,andpress .
3. Use the navigation key to select from In Phone,
Memory Card,Online Albums,Take New Picture Take
New Video, or Text Only.
4. Highlight the picture or video you wish to send and
press .
5. Followtheonscreenprompts.Youcanselectasubject,
and add a text or audio message if you wish.
6. Press SEND (left softkey) to send the picture.

Manage Your Account
Online: www.sprint.com
• makeapayment,seeyourbills,enrollin
online billing
• checkminuteusageandaccountbalance
• seeormodifythedetailsofyourSprintserviceplan
• getdetailedinstructionsanddownloadcontent
From Your Sprint Phone
• press to check minute usage and
account balance
• press to make a payment
• press to access a summary of your Sprint
service plan or get answers to other questions
From Any Other Phone
• SprintCustomerService:Dial1-800-Sprint1
(1-800-777-4681)
• BusinessCustomerService:Dial1-800-927-2199

Total Equipment Protection
The protection you need so you can be worry free
Shouldanythinghappentoyourphone,you’llhave
a worry-free way to ensure that you get connected
again soon.
• Coverage includes:
Loss,Theft,Routinemaintenance,Physicalorliquid
damage,Mechanicalorelectricalproblems,Failure
from normal wear and tear.
• For more information:
See the Total Equipment Protection brochure
available at any participating retail location or go
to www.sprint.com/tep for more details. To enroll
within 30 days of activation call 1-800-584-3666.
Total Equipment Protection is a service provided by Asurion
ProtectionServices,LLC,ContinentalCasualtyCompany’s(a
CNAcompany)licensedagentforthecustomersofSprint.
Sprint 411
Dial411fornationwidelistings,movieshowtimes,
restaurantreservations,drivingdirectionsand
more. Spanish-speaking operators are available.
See www.sprint.com for pricing and more details.
Helpful Sprint Information

ForYour Phone
• ThisGet Started Guide to get you up and running.
• Features Guide –Get the most from the services and
features available on your new Sprint phone.
• User Guide –View the comprehensive User Guide to
the Reclaim ™.
• Web –Go to sprint.com/reclaimsupport to download
the latest version of the User Guide,andtoaccess
instructionalvideos,tutorials,andotherresources.
For the Environment
Recycle your old phone safely and conveniently using
the addressed recycling envelope packaged with your
new phone. Visit sprint.com/recycle for more details.
Visit sprint.com/begin to discover all you can do
with your phone and Sprint service. Explore all your
options,ndwaystopersonalizeyourexperience,
even vote for your favorite features. It’s a whole
new beginning.
Resources
sprint.com/begin
