Samsung SGH-E250D User manual

GSM TELEPHONE
SGH-E250D_W
GSM TELEPHONE CONTENTS
1. Safety Precautions
2. Specification
3. Product Function
4. Array course control
5. Exploded View and Parts List
6. MAIN Electrical Parts List
7. Block Diagrams
8. PCB Diagrams
9. Flow Chart of Troubleshooting
10. Reference data
11. Disassembly and Assembly
Instructions

This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
Samsung Electronics Co.,Ltd.
2007. 12. Rev.1.0
ⓒ
Country Web Site
North America service.samsungportal.com
Latin America latin.samsungportal.com
CIS cis.samsungportal.com
Europe europe.samsungportal.com
China china.samsungportal.com
Asia asia.samsungportal.com
Mideast & Africa mea.samsungportal.com
GSPN (Global Service Partner Network)

SAMSUNG Proprietary-Contents may change without notice
1. Safety Precautions
1-1
This Document can not be used without Samsung's authorization
1-1. Repair Precaution
-Repair in Shield Box, during detailed tuning. Take specially care of tuning or test,
because specificity of cellular phone is sensitive for surrounding interference(RF noise).
-Be careful to use a kind of magnetic object or tool, because performance of parts is damaged by
the influence of magnetic force.
-Surely use a standard screwdriver when you disassemble this product, otherwise screw will be worn
away.
-Use a thicken twisted wire when you measure level.
A thicken twisted wire has low resistance, therefore error of measurement is few.
-Repair after separate Test Pack and Set because for short danger (for example an
overcurrent and furious flames of parts etc) when you repair board in condition of
connecting Test Pack and tuning on.
-Take specially care of soldering, because Land of PCB is small and weak in heat.
-Surely tune on/off while using AC power plug, because a repair of battery charger is dangerous
when tuning ON/OFF PBA and Connector after disassembling charger.
-Don't use as you pleases after change other material than replacement registered on SEC System.
Otherwise engineer in charge isn't charged with problem that you don't keep this rules.

SAMSUNG Proprietary-Contents may change without notice
Safety Precautions
1-2
This Document can not be used without Samsung's authorization
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Several semiconductor may be damaged easily by static electricity. Such parts are called by ESD
(Electrostatically Sensitive Devices), for example IC,BGA chip etc. Read Precaution below.
You can prevent from ESD damage by static electricity.
-Remove static electricity remained your body before you touch semiconductor or parts with
semiconductor. There are ways that you touch an earthed place or wear static electricity
prevention string on wrist.
-Use earthed soldering steel when you connect or disconnect ESD.
-Use soldering removing tool to break static electricity. , otherwise ESD will be damaged by
static electricity.
-Don't unpack until you set up ESD on product. Because most of ESD are packed by box and
aluminum plate to have conductive power,they are prevented from static electricity.
-You must maintain electric contact between ESD and place due to be set up until ESD is
connected completely to the proper place or a circuit board.

2. Specification
2-1
2-1. GSM General Specification
GSM900
Phase 1
EGSM 900
Phase 2
DCS1800
Phase 1 PCS1900
Freq.
Band[MHz]
Uplink/Downlink
890~915
935~960
880~915
925~960
1710~1785
1805~1880
1850~1910
1930~1990
ARFCN range 1~124 0~124 &
975~1023 512~885 512~810
Tx/Rx spacing 45MHz 45MHz 95MHz 80MHz
Mod. Bit rate/
Bit Period
270.833kbps
3.692us
270.833kbps
3.692us
270.833kbps
3.692us
270.833kbps
3.692us
Time Slot
Period/Frame
Period
576.9us
4.615ms
576.9us
4.615ms
576.9us
4.615ms
576.9us
4.615ms
Modulation 0.3GMSK 0.3GMSK 0.3GMSK 0.3GMSK
MS Power 33dBm~5dBm 33dBm~5dBm 30dBm~0dBm 30dBm~0dBm
Power Class 5pcl ~ 19pcl 5pcl ~ 19pcl 0pcl ~ 15pcl 0pcl ~ 15pcl
Sensitivity -102dBm -102dBm -100dBm -100dBm
TDMA Mux 8 8 8 8
Cell Radius 35Km 35Km 2Km -

Speclflcation
2-2
TX Power
control level GSM900
533±2dBm
631±2dBm
729±2dBm
827±2dBm
925±2dBm
10 23±2 dBm
11 21±2 dBm
12 19±2 dBm
13 17±2 dBm
14 15±2 dBm
15 13±2 dBm
16 11±3 dBm
17 9±3dBm
18 7±3 dBm
19 5±3 dBm
TX Power
control level DCS1800
030±3dBm
128±3dBm
226±3dBm
324±3dBm
422±3dBm
520±3dBm
618±3dBm
716±3dBm
814±3dBm
912±4dBm
10 10±4 dBm
11 8±4dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
TX Power
control level PCS1800
030±3dBm
128±3dBm
226±3dBm
324±3dBm
422±3dBm
520±3dBm
618±3dBm
716±3dBm
814±3dBm
912±4dBm
10 10±4 dBm
11 8±4dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
2-2. GSM Tx Power Class

SAMSUNG Proprietary-Contents may change without notice
3. Product Function
3-1
This Document can not be used without Samsung's authorization
Main Function
-SlimSlide Design Intenna
-VGA Camera
-Bluetooth V.2.0
-Stereo Bluetooth Headset
-Mobile Tracker & SOS Messaging
-Large 2.0" 65K Color TFT Display
-SMS/MMS/E-Mail
-WAP 2.0 / Java MIDP 2.0
-MP3,AAC,MP4,3GPPDecoding
-Video Recording and Messaging
-GSM/GPRS Class 10
-Triple Band(GSM900/DCS,PCS)
-64 Poly
-Speaker Phone
-Voice Clarity

SAMSUNG Proprietary-Contents may change without notice
Product Function
3-2
This Document can not be used without Samsung's authorization

SAMSUNG Proprietary-Contents may change without notice
4. Array course control
4-1
This Document can not be used without Samsung's authorization
Software Adjustments
RF CABLE (GH39-00397A)
Power Supply Cable
Serial Cable(CSA LL64151-A)
Test Jig (GH80-03306A) Test Cable (GH39-00499A)

SAMSUNG Proprietary-Contents may change without notice
Array course control
4-2
This Document can not be used without Samsung's authorization
Software Downloading
4-1. Pre-requsite for Downloading
• Downloader Program(OneNAND Downloder V1.0 Lite For PNX5230.exe)
• E250 Mobile Phone
• Data Cable
• Binary file, TFS file
4-2. S/W Downloader Program
■Load the binary download program by executing the
“OneNAND Downloder V1.0 Lite For PNX5230.exe”
1. Select the connected serial port and the rate of speed
2. Select the check box, the mode you want to download.
- if the binary file wanted, check only 'BIN'
- if the tfs file wanted, check only 'TFS'
- if all the files wanted, check 'BIN+TFS'
1
2

SAMSUNG Proprietary-Contents may change without notice
Array course control
4-3
This Document can not be used without Samsung's authorization
3. Select the file(s) what you want to download

SAMSUNG Proprietary-Contents may change without notice
Array course control
4-4
This Document can not be used without Samsung's authorization

SAMSUNG Proprietary-Contents may change without notice
5. Exploded View and Parts List
5-3
This Document can not be used without Samsung's authorization
5-1. Cellular phone Exploded View
QFU01
QKP02
QKP01
QMW01
QME03
QME02
QFR01
QCW01
QCA05
QCR17
QSC05
QSC06
QSP01
QMO01
QLC01
QCA01
QSD01
QHI01
QIF01
QFL01
QFR02
QME01
QBR04
QMI03
QMI01
QAN02
QMP01
QRE01
QSC13
QRF01
QBA00
QCR03
QBA01
QVO01
QCR03
QME11

SAMSUNG Proprietary-Contents may change without notice
Exploded View and Parts List
5-2
This Document can not be used without Samsung's authorization
Design LOC Description SEC CODE
QAN02 INTENNA-SGH E250 GH42-00985A
QBA00 ASSY CASE-BATTERY GH98-03586A
QBA01 INNER BATTERY PACK-750MAH,BLK, GH43-02483A
QBR04 ASSY BRACKET-KEYPAD GH98-05531A
QCA01 CAMERA MODULE GH59-03619A
QCA05 PMO-DECO MIRROR GH72-34243A
QCR03 SCREW-MACHINE 6001-001811
QCR03 SCREW-MACHINE 6001-001811
QCR17 SCREW-MACHINE 6001-001460
QCW01 PCT-COVER WINDOW CAMERA GH72-34247A
QFL01 ASSY CASE-SLIDE LOWER GH98-02260A
QFR01 ASSY CASE-F/C+S/L GH98-02261A
QFR02 ASSY CASE-FRONT GH98-03548A
QFU01 ASSY CASE-SLIDE UPPER(VOD) GH98-03300A
QHI01 ASSY HINGE-PUSH ROD GH98-03165A
QIF01 PMO-COVER IF GH72-34244A
QKP01 ASSY KEYPAD-MAIN(EU/SIL) GH98-02264A
QKP02 ASSY KEYPAD-SUB(VOD/SIL) GH98-03535A
QLC01 ELA ETC-E250LCD MODULE GH96-02628B
QME01 KEY FPCB-MAIN KEY PBA GH59-04760A
QME02 DOME SHEET-10KEY(SUB) GH59-05007A
QME03 MEA-SLIDER FPCB KIT(E250D) GH97-08172A
QME11 ASSY ETC-LCD SUB PBA GH59-04854A
QMI01 MICROPHONE-ASSY GH30-00309A
QMI03 RMO-RUBBER MIC GH73-08308A
QMO01 MOTOR DC-SGHZV30 GH31-00177A
QMP01 PBA MAIN-SGHE250W GH92-04085A
QMW01 ASSY COVER-WINDOW MAIN(VODA) GH98-03536A
QRE01 ASSY CASE-REAR GH98-05532A
QRF01 MPR-TAPE RF SHEET GH74-27453A
QSC05 RMO-RUBBER SCREW SLIDE L GH73-08309A
QSC06 RMO-RUBBER SCREW SLIDE R GH73-08310A
QSC13 RMO-RUBBER SCREW REAR GH73-08311A
QSD01 PMO-COVER M SD GH72-34245A
QSP01 SPEAKER 3001-002213
QVO01 ASSY KEY-VOLUME GH98-03940A
5-2. Cellular phone Parts List

SAMSUNG Proprietary-Contents may change without notice
Exploded View and Parts List
5-3
This Document can not be used without Samsung's authorization
Description SEC CODE
ADAPTOR-SGHE690,SIL,EU,A_TYPE GH44-01361B
EARPHONE-20P,EARPHONE,SIL,B-TY GH59-03848B
LABEL(R)-WATER SOAK GH68-09361A
LABEL(R)-WATER SOAK GH68-09361A
RMO-RUBBER SIM GH73-08686A
ICT SHIELD-COVER RF GH70-02506A
MPR-INSU TAPE GH74-27455A
MPR-INSU TAPE GH74-27456A
MPR-TAPE LABEL GH74-28874A
MPR-SPONGE GH74-29496A
MPR-VINYL BOHO MAIN GH74-30340A
MPR-VINYL BOHO SUB KEYPAD GH74-31218A
TAPE-S-UPPER GH74-34678A
MPR-ELEC TAPE GH74-27495A
MPR-GASK TAPE GH74-28782A
MPR-REMOVE TAPE LCD GH74-13804A
MPR-TAPE GH74-27509A
MPR-ELEC TAPE GH74-27457A
TAPE GASK GH74-18462A
LABEL(R)-WATER SOAK GH68-09361A
MANUAL USERS-VODA GERMAN GH68-13908A
MANUAL USERS-QSG VODA GERMAN GH68-14004A
BAG PE 6902-000634
LABEL(P)-UNIT SEAL GH68-00518B
LABEL(R)-MAIN(VODA_W) GH68-17334A
CUSHION-CASE(VODA) GH69-05067A
BOX-UNIT(VOD) GH69-05072A

SAMSUNG Proprietary-Contents may change without notice
6. MAIN Electrical Parts List
6-1
This Document can not be used without Samsung's authorization
SEC Code Design LOC Description STATUS
0403-001547 ZD401 DIODE-ZENER SA
0406-001190 ZD302 DIODE-TVS SA
0406-001201 ZD600 DIODE-TVS SA
0406-001208 ZD500 DIODE-TVS SA
0406-001235 ZD201 DIODE-TVS SA
0406-001240 ZD601 DIODE-TVS SA
0406-001254 ZD402 DIODE-TVS SA
0406-001254 ZD501 DIODE-TVS SA
0406-001254 ZD502 DIODE-TVS SA
0406-001254 ZD505 DIODE-TVS SA
0406-001254 ZD506 DIODE-TVS SA
0406-001254 ZD602 DIODE-TVS SA
0406-001254 ZD603 DIODE-TVS SA
0801-002237 U302 IC-CMOS LOGIC SA
0801-002237 U601 IC-CMOS LOGIC SA
0801-003185 U600 IC-CMOS LOGIC SA
1108-000080 UME301 IC-MCP SA
1201-002576 U103 IC-POWER AMP SA
1201-002689 U500 IC-AUDIO AMP SA
1203-003737 U401 IC-POSI.FIXED REG. SA
1203-003737 U402 IC-POSI.FIXED REG. SA
1203-003737 U404 IC-POSI.FIXED REG. SA
1203-003737 U405 IC-POSI.FIXED REG. SA
1203-004382 U403 IC-POWER SUPERVISOR SA
1204-002688 U501 IC-DEMODULATOR SA
1205-002942 U102 IC-TRANSCEIVER SA
1205-003082 UCP200 IC-COMM. CONTROLLER SA
1205-003283 U106 IC-TRANSCEIVER SA
1404-001221 VR600 THERMISTOR-NTC SA
2007-000140 R103 R-CHIP SA
2007-000140 R209 R-CHIP SA
2007-000143 R110 R-CHIP SA
2007-000143 R201 R-CHIP SA
2007-000148 R101 R-CHIP SA
2007-000148 R204 R-CHIP SA
2007-000148 R205 R-CHIP SA
2007-000148 R208 R-CHIP SA
2007-000148 R213 R-CHIP SA
2007-000148 R525 R-CHIP SA
2007-000152 R603 R-CHIP SA
2007-000162 C615 R-CHIP SA
2007-000162 R301 R-CHIP SA
2007-000162 R523 R-CHIP SA
2007-000162 R610 R-CHIP SA
2007-000162 R611 R-CHIP SA
2007-000162 R612 R-CHIP SA
2007-000170 R104 R-CHIP SA
2007-000170 R212 R-CHIP SA
2007-000170 R214 R-CHIP SA
2007-000171 L100 R-CHIP SA
2007-000171 R202 R-CHIP SA
2007-000171 R228 R-CHIP SA
2007-000171 R304 R-CHIP SA

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-2
This Document can not be used without Samsung's authorization
SEC Code Design LOC Description STATUS
2007-000172 R506 R-CHIP SA
2007-000172 R509 R-CHIP SA
2007-000758 R218 R-CHIP SA
2007-000758 R223 R-CHIP SA
2007-000758 R416 R-CHIP SA
2007-000758 R608 R-CHIP SA
2007-001292 R511 R-CHIP SA
2007-001292 R512 R-CHIP SA
2007-001303 R308 R-CHIP SA
2007-001319 R215 R-CHIP SA
2007-001319 R217 R-CHIP SA
2007-001333 R402 R-CHIP SA
2007-001333 R403 R-CHIP SA
2007-001333 R501 R-CHIP SA
2007-001333 R514 R-CHIP SA
2007-001333 R529 R-CHIP SA
2007-001339 R503 R-CHIP SA
2007-002796 R206 R-CHIP SA
2007-002796 R507 R-CHIP SA
2007-002796 R508 R-CHIP SA
2007-003001 R524 R-CHIP SA
2007-007014 R303 R-CHIP SA
2007-007014 R309 R-CHIP SA
2007-007107 R418 R-CHIP SA
2007-007107 R602 R-CHIP SA
2007-007142 R415 R-CHIP SA
2007-007142 R419 R-CHIP SA
2007-007142 R505 R-CHIP SA
2007-007142 R613 R-CHIP SA
2007-007317 R413 R-CHIP SA
2007-007318 R408 R-CHIP SA
2007-007334 R502 R-CHIP SA
2007-007489 R105 R-CHIP SA
2007-007528 R513 R-CHIP SA
2007-007528 R516 R-CHIP SA
2007-007528 R518 R-CHIP SA
2007-007528 R519 R-CHIP SA
2007-007573 R400 R-CHIP SA
2007-008055 R302 R-CHIP SA
2007-008055 R604 R-CHIP SA
2007-008055 R606 R-CHIP SA
2007-008137 R411 R-CHIP SA
2007-008354 R401 R-CHIP SA
2007-008516 R601 R-CHIP SA
2007-008542 R409 R-CHIP SA
2007-009157 R407 R-CHIP SA
2007-009168 R605 R-CHIP SA
2007-009212 R607 R-CHIP SA
2203-000233 C106 C-CER,CHIP SA
2203-000233 C107 C-CER,CHIP SA
2203-000233 C114 C-CER,CHIP SA
2203-000233 C115 C-CER,CHIP SA
2203-000233 C116 C-CER,CHIP SA

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-3
This Document can not be used without Samsung's authorization
SEC Code Design LOC Description STATUS
2203-000233 C125 C-CER,CHIP SA
2203-000233 C128 C-CER,CHIP SA
2203-000233 C129 C-CER,CHIP SA
2203-000233 C310 C-CER,CHIP SA
2203-000233 C311 C-CER,CHIP SA
2203-000233 U603 C-CER,CHIP SA
2203-000254 C211 C-CER,CHIP SA
2203-000254 C501 C-CER,CHIP SA
2203-000254 C532 C-CER,CHIP SA
2203-000278 C105 C-CER,CHIP SA
2203-000278 C110 C-CER,CHIP SA
2203-000278 C113 C-CER,CHIP SA
2203-000278 C117 C-CER,CHIP SA
2203-000278 C540 C-CER,CHIP SA
2203-000278 C544 C-CER,CHIP SA
2203-000278 C546 C-CER,CHIP SA
2203-000278 C551 C-CER,CHIP SA
2203-000330 C517 C-CER,CHIP SA
2203-000330 C518 C-CER,CHIP SA
2203-000386 C508 C-CER,CHIP SA
2203-000386 C541 C-CER,CHIP SA
2203-000386 C542 C-CER,CHIP SA
2203-000425 C215 C-CER,CHIP SA
2203-000425 C222 C-CER,CHIP SA
2203-000425 C416 C-CER,CHIP SA
2203-000425 C417 C-CER,CHIP SA
2203-000425 C605 C-CER,CHIP SA
2203-000628 C537 C-CER,CHIP SA
2203-000679 C515 C-CER,CHIP SA
2203-000679 C516 C-CER,CHIP SA
2203-000679 C538 C-CER,CHIP SA
2203-000812 C119 C-CER,CHIP SA
2203-000812 C202 C-CER,CHIP SA
2203-000812 C213 C-CER,CHIP SA
2203-000812 C604 C-CER,CHIP SA
2203-001239 C132 C-CER,CHIP SA
2203-001259 C548 C-CER,CHIP SA
2203-002443 C539 C-CER,CHIP SA
2203-002668 L108 C-CER,CHIP SA
2203-002709 C123 C-CER,CHIP SA
2203-002709 C126 C-CER,CHIP SA
2203-002709 C135 C-CER,CHIP SA
2203-002709 C602 C-CER,CHIP SA
2203-003054 C543 C-CER,CHIP SA
2203-005050 C104 C-CER,CHIP SA
2203-005050 C122 C-CER,CHIP SA
2203-005050 C509 C-CER,CHIP SA
2203-005050 C549 C-CER,CHIP SA
2203-005288 C101 C-CER,CHIP SA
2203-005288 C108 C-CER,CHIP SA
2203-005288 C109 C-CER,CHIP SA
2203-005288 C120 C-CER,CHIP SA
2203-005393 C547 C-CER,CHIP SA

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-4
This Document can not be used without Samsung's authorization
SEC Code Design LOC Description STATUS
2203-005393 C550 C-CER,CHIP SA
2203-005395 C511 C-CER,CHIP SA
2203-005395 C512 C-CER,CHIP SA
2203-005395 C521 C-CER,CHIP SA
2203-005395 C522 C-CER,CHIP SA
2203-005395 L107 C-CER,CHIP SA
2203-005444 C507 C-CER,CHIP SA
2203-005444 C545 C-CER,CHIP SA
2203-005482 C118 C-CER,CHIP SA
2203-005482 C127 C-CER,CHIP SA
2203-005482 C134 C-CER,CHIP SA
2203-005482 C201 C-CER,CHIP SA
2203-005482 C203 C-CER,CHIP SA
2203-005482 C204 C-CER,CHIP SA
2203-005482 C205 C-CER,CHIP SA
2203-005482 C206 C-CER,CHIP SA
2203-005482 C208 C-CER,CHIP SA
2203-005482 C209 C-CER,CHIP SA
2203-005482 C212 C-CER,CHIP SA
2203-005482 C214 C-CER,CHIP SA
2203-005482 C221 C-CER,CHIP SA
2203-005482 C307 C-CER,CHIP SA
2203-005482 C309 C-CER,CHIP SA
2203-005482 C312 C-CER,CHIP SA
2203-005482 C428 C-CER,CHIP SA
2203-005482 C513 C-CER,CHIP SA
2203-005482 C514 C-CER,CHIP SA
2203-005482 C519 C-CER,CHIP SA
2203-005482 C520 C-CER,CHIP SA
2203-005482 C531 C-CER,CHIP SA
2203-005483 C502 C-CER,CHIP SA
2203-005717 C612 C-CER,CHIP SA
2203-005717 C613 C-CER,CHIP SA
2203-005736 C412 C-CER,CHIP SA
2203-006048 C130 C-CER,CHIP SA
2203-006048 C536 C-CER,CHIP SA
2203-006208 C216 C-CER,CHIP SA
2203-006208 C304 C-CER,CHIP SA
2203-006208 C404 C-CER,CHIP SA
2203-006208 C409 C-CER,CHIP SA
2203-006208 C410 C-CER,CHIP SA
2203-006208 C427 C-CER,CHIP SA
2203-006208 C614 C-CER,CHIP SA
2203-006257 C400 C-CER,CHIP SA
2203-006257 C405 C-CER,CHIP SA
2203-006257 C407 C-CER,CHIP SA
2203-006257 C408 C-CER,CHIP SA
2203-006257 C411 C-CER,CHIP SA
2203-006257 C413 C-CER,CHIP SA
2203-006257 C420 C-CER,CHIP SA
2203-006260 C503 C-CER,CHIP SA
2203-006260 C505 C-CER,CHIP SA
2203-006260 C534 C-CER,CHIP SA

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-5
This Document can not be used without Samsung's authorization
SEC Code Design LOC Description STATUS
2203-006260 C535 C-CER,CHIP SA
2203-006324 C421 C-CER,CHIP SA
2203-006361 C425 C-CER,CHIP SA
2203-006361 C426 C-CER,CHIP SA
2203-006423 C301 C-CER,CHIP SA
2203-006423 C302 C-CER,CHIP SA
2203-006423 C305 C-CER,CHIP SA
2203-006423 C422 C-CER,CHIP SA
2203-006423 C533 C-CER,CHIP SA
2203-006423 C603 C-CER,CHIP SA
2203-006562 C210 C-CER,CHIP SA
2203-006562 C303 C-CER,CHIP SA
2203-006562 C306 C-CER,CHIP SA
2203-006562 C308 C-CER,CHIP SA
2203-006562 C401 C-CER,CHIP SA
2203-006562 C402 C-CER,CHIP SA
2203-006562 C403 C-CER,CHIP SA
2203-006562 C406 C-CER,CHIP SA
2203-006562 C414 C-CER,CHIP SA
2203-006562 C415 C-CER,CHIP SA
2203-006562 C424 C-CER,CHIP SA
2203-006562 C429 C-CER,CHIP SA
2203-006562 C430 C-CER,CHIP SA
2203-006562 C504 C-CER,CHIP SA
2203-006562 C506 C-CER,CHIP SA
2203-006562 C606 C-CER,CHIP SA
2203-006824 C131 C-CER,CHIP SA
2203-006825 C432 C-CER,CHIP SA
2203-006838 C100 C-CER,CHIP SA
2203-006838 C102 C-CER,CHIP SA
2203-006838 C103 C-CER,CHIP SA
2203-006842 C111 C-CER,CHIP SA
2203-006901 C431 C-CER,CHIP SA
2404-001226 TA503 C-TA,CHIP SA
2404-001377 TA500 C-TA,CHIP SA
2404-001377 TA501 C-TA,CHIP SA
2404-001381 TA502 C-TA,CHIP SA
2404-001430 TA400 C-TA,CHIP SA
2404-001496 TA100 C-TA,CHIP SA
2404-001506 TA504 C-TA,CHIP SA
2703-001231 L504 INDUCTOR-SMD SNA
2703-001285 L505 INDUCTOR-SMD SA
2703-001673 L506 INDUCTOR-SMD SA
2703-001726 L105 INDUCTOR-SMD SA
2703-001749 C112 INDUCTOR-SMD SA
2703-001749 L110 INDUCTOR-SMD SA
2703-002208 L101 INDUCTOR-SMD SA
2703-002208 L106 INDUCTOR-SMD SA
2703-002314 L102 INDUCTOR-SMD SA
2703-002608 L103 INDUCTOR-SMD SA
2703-002608 L104 INDUCTOR-SMD SA
2703-003113 L400 INDUCTOR-SMD SA
2801-004339 OSC400 CRYSTAL-SMD SA
