Samsung SGH-T200 User manual

SGH-T200
SERVICE
Manual
GSMTELEPHONECONTENTS
1.ElectricalPartsList
2.ExplodedViewsand PartsList
3.BlockDiagrams
4.PCB Diagrams
5.FlowChartofTroubleshooting
GSMTELEPHONE

SAMSUNG Proprietary-Contents may change without notice
1.SGH-T200 MAINElectricalPartsList
1-1
Level SEC Code Design LOC Descriptions
0 SGH-T200OBAXSP
2 GH71-00434A ANT1 NPR-ANT CONTACT SCH-X210,ST,T0.2,-,-
2 4302-001119 BAT1 BATTERY-LI(2ND) 3V,0.1MAH,-,-,3.1V,-
2 2203-005509 C101 C-CERAMIC,CHIP 330nF,+80-20%,10V,Y5V,TP,1005
2 2203-005503 C102 C-CERAMIC,CHIP 0.18nF,5%,25V,NP0,TP,1005
2 2203-005482 C103 C-CERAMIC,CHIP 100nF,10%,10V,X5R,TP,1005,-
2 2203-000386 C104 C-CERAMIC,CHIP 0.015nF,5%,50V,NP0,TP,1005
2 2203-000438 C106 C-CERAMIC,CHIP 1nF,10%,50V,X7R,TP,1005,-
2 2203-000812 C107 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2203-005482 C108 C-CERAMIC,CHIP 100nF,10%,10V,X5R,TP,1005,-
2 2203-005065 C109 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608
2 2203-000628 C110 C-CERAMIC,CHIP 0.022nF,5%,50V,NP0,TP,1005
2 2203-000812 C111 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2203-000311 C112 C-CERAMIC,CHIP 0.12nF,5%,50V,NP0,TP,1005
2 2203-005482 C113 C-CERAMIC,CHIP 100nF,10%,10V,X5R,TP,1005,-
2 2203-001124 C114 C-CERAMIC,CHIP 680pF,10%,50V,X7R,TP,1005,-
2 2203-000585 C116 C-CERAMIC,CHIP 220pF,10%,50V,X7R,TP,1005,-
2 2203-000425 C117 C-CERAMIC,CHIP 0.018nF,5%,50V,NP0,TP,1005
2 2301-001419 C118 C-FILM,CHIP 8.2nF,5%,16V,TP,2012,-
2 2203-000812 C119 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2203-000812 C121 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2203-000233 C122 C-CERAMIC,CHIP 0.1nF,5%,50V,NP0,TP,1005
2 2203-005482 C123 C-CERAMIC,CHIP 100nF,10%,10V,X5R,TP,1005,-
2 2203-000628 C125 C-CERAMIC,CHIP 0.022nF,5%,50V,NP0,TP,1005
2 2203-000233 C126 C-CERAMIC,CHIP 0.1nF,5%,50V,NP0,TP,1005
2 2203-000812 C127 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2203-005571 C128 C-CERAMIC,CHIP 10000NF,+80-20%,6.3V,Y5V,TP,2012
2 2203-005482 C130 C-CERAMIC,CHIP 100nF,10%,10V,X5R,TP,1005,-
2 2203-000386 C131 C-CERAMIC,CHIP 0.015nF,5%,50V,NP0,TP,1005
2 2203-000278 C132 C-CERAMIC,CHIP 0.01nF,0.5pF,50V,NP0,TP,1005
2 2203-000679 C133 C-CERAMIC,CHIP 0.027nF,5%,50V,NP0,TP,1005
2 2203-000679 C134 C-CERAMIC,CHIP 0.027nF,5%,50V,NP0,TP,1005
2 2203-005482 C135 C-CERAMIC,CHIP 100nF,10%,10V,X5R,TP,1005,-
2 2301-001512 C136 C-FILM,CHIP 3.3NF,5%,16V,TP,2012,-
2 2203-000940 C138 C-CERAMIC,CHIP 470pF,10%,50V,X7R,TP,1005,-
2 2203-000940 C139 C-CERAMIC,CHIP 470pF,10%,50V,X7R,TP,1005,-
2 2203-000812 C140 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2203-005482 C141 C-CERAMIC,CHIP 100nF,10%,10V,X5R,TP,1005,-
2 2203-002668 C143 C-CERAMIC,CHIP 0.0005nF,0.1pF,50V,NP0,TP,1005
2 2203-000628 C144 C-CERAMIC,CHIP 0.022nF,5%,50V,NP0,TP,1005
2 2203-002668 C145 C-CERAMIC,CHIP 0.0005nF,0.1pF,50V,NP0,TP,1005
2 2203-002668 C146 C-CERAMIC,CHIP 0.0005nF,0.1pF,50V,NP0,TP,1005
2 2203-002677 C149 C-CERAMIC,CHIP 0.75pF,0.1pF,50V,CH,TP,1005,-
2 2203-000812 C150 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2203-000812 C151 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005

SAMSUNG Proprietary-Contents may change without notice
1-2
SGH-T200 ElectricalPartsList
Level SEC Code Design LOC Descriptions
2 2203-002677 C152 C-CERAMIC,CHIP 0.75pF,0.1pF,50V,CH,TP,1005,-
2 2203-005234 C153 C-CERAMIC,CHIP 0.0012nF,0.25pF,50V,NP0,TP,1005
2 2203-000654 C201 C-CERAMIC,CHIP 270pF,10%,50V,X7R,TP,1005,-
2 2203-001239 C202 C-CERAMIC,CHIP 0.082nF,5%,50V,NP0,TP,1005
2 2203-005571 C203 C-CERAMIC,CHIP 10000NF,+80-20%,6.3V,Y5V,TP,2012
2 2203-000812 C204 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2203-000812 C205 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2203-000812 C206 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2203-000812 C207 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2203-001383 C208 C-CERAMIC,CHIP 0.0005nF,0.25pF,50V,NP0,TP,1005
2 2203-000278 C210 C-CERAMIC,CHIP 0.01nF,0.5pF,50V,NP0,TP,1005
2 2203-000812 C211 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2203-000278 C212 C-CERAMIC,CHIP 0.01nF,0.5pF,50V,NP0,TP,1005
2 2203-000812 C213 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2203-005061 C214 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2404-001105 C216 C-TA,CHIP 10UF,20%,6.3V,GP,TP,2012
2 2203-005061 C220 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005061 C221 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005061 C222 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005571 C223 C-CERAMIC,CHIP 10000NF,+80-20%,6.3V,Y5V,TP,2012
2 2203-005061 C224 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005061 C225 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005061 C226 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005061 C227 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005061 C228 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005061 C229 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005061 C230 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005061 C231 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005061 C232 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005061 C233 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005061 C234 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005061 C235 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005061 C302 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-000233 C304 C-CERAMIC,CHIP 0.1nF,5%,50V,NP0,TP,1005
2 2203-000359 C305 C-CERAMIC,CHIP 0.15nF,5%,50V,NP0,TP,1005
2 2203-005061 C306 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005509 C307 C-CERAMIC,CHIP 330nF,+80-20%,10V,Y5V,TP,1005
2 2203-005061 C308 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005482 C309 C-CERAMIC,CHIP 100nF,10%,10V,X5R,TP,1005,-
2 2203-005482 C310 C-CERAMIC,CHIP 100nF,10%,10V,X5R,TP,1005,-
2 2203-000679 C311 C-CERAMIC,CHIP 0.027nF,5%,50V,NP0,TP,1005
2 2203-000679 C312 C-CERAMIC,CHIP 0.027nF,5%,50V,NP0,TP,1005
2 2203-005065 C315 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608
2 2203-005482 C316 C-CERAMIC,CHIP 100nF,10%,10V,X5R,TP,1005,-
2 2203-005482 C317 C-CERAMIC,CHIP 100nF,10%,10V,X5R,TP,1005,-

SAMSUNG Proprietary-Contents may change without notice
SGH-T200 ElectricalPartsList
1-3
Level SEC Code Design LOC Descriptions
2 2203-005482 C320 C-CERAMIC,CHIP 100nF,10%,10V,X5R,TP,1005,-
2 2203-000254 C322 C-CERAMIC,CHIP 10nF,10%,16V,X7R,TP,1005,-
2 2203-005065 C401 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608
2 2203-005482 C402 C-CERAMIC,CHIP 100nF,10%,10V,X5R,TP,1005,-
2 2203-005065 C403 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608
2 2203-005509 C404 C-CERAMIC,CHIP 330nF,+80-20%,10V,Y5V,TP,1005
2 2203-005065 C405 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608
2 2203-005509 C406 C-CERAMIC,CHIP 330nF,+80-20%,10V,Y5V,TP,1005
2 2203-005065 C407 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608
2 2203-005061 C408 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-000254 C409 C-CERAMIC,CHIP 10nF,10%,16V,X7R,TP,1005,-
2 2203-000438 C410 C-CERAMIC,CHIP 1nF,10%,50V,X7R,TP,1005,-
2 2203-005482 C411 C-CERAMIC,CHIP 100nF,10%,10V,X5R,TP,1005,-
2 2404-001280 C501 C-TA,CHIP 220UF,20%,6.3V,LZ,TP,7132
2 2203-001412 C502 C-CERAMIC,CHIP 0.03nF,5%,50V,NP0,TP,1005
2 2203-001412 C503 C-CERAMIC,CHIP 0.03nF,5%,50V,NP0,TP,1005
2 2203-000812 C504 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2203-006113 C505 C-CERAMIC,CHIP 0.033NF,10%,50V,X7R,-,2012
2 2203-006113 C506 C-CERAMIC,CHIP 0.033NF,10%,50V,X7R,-,2012
2 2203-006090 C507 C-CERAMIC,CHIP 10000NF,10%,6.3V,X5R,TP,2012
2 2203-000438 C509 C-CERAMIC,CHIP 1nF,10%,50V,X7R,TP,1005,-
2 2203-000812 C510 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2203-000233 C512 C-CERAMIC,CHIP 0.1nF,5%,50V,NP0,TP,1005
2 2203-000233 C513 C-CERAMIC,CHIP 0.1nF,5%,50V,NP0,TP,1005
2 2203-006113 C514 C-CERAMIC,CHIP 0.033NF,10%,50V,X7R,-,2012
2 2203-006113 C515 C-CERAMIC,CHIP 0.033NF,10%,50V,X7R,-,2012
2 2203-000254 C519 C-CERAMIC,CHIP 10nF,10%,16V,X7R,TP,1005,-
2 2404-001086 C520 C-TA,CHIP 4.7uF,20%,6.3V,GP,TP,2012,-
2 2203-001432 C521 C-CERAMIC,CHIP 47nF,+80-20%,16V,Y5V,TP,1005
2 2404-001101 C522 C-TA,CHIP 1uF,20%,16V,GP,TP,2012,-
2 2203-005061 C525 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-006053 C527 C-CERAMIC,CHIP 1000NF,10%,10V,X5R,TP,1608
2 2404-001151 C530 C-TA,CHIP 33UF,20%,6.3V,LZ,TP,3216
2 2203-000812 C535 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2203-006053 C536 C-CERAMIC,CHIP 1000NF,10%,10V,X5R,TP,1608
2 2203-000940 C547 C-CERAMIC,CHIP 470pF,10%,50V,X7R,TP,1005,-
2 2203-005509 C549 C-CERAMIC,CHIP 330nF,+80-20%,10V,Y5V,TP,1005
2 2203-000438 C598 C-CERAMIC,CHIP 1nF,10%,50V,X7R,TP,1005,-
2 2203-000438 C599 C-CERAMIC,CHIP 1nF,10%,50V,X7R,TP,1005,-
2 2203-005061 C601 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-000278 C602 C-CERAMIC,CHIP 0.01nF,0.5pF,50V,NP0,TP,1005
2 2203-000254 C603 C-CERAMIC,CHIP 10nF,10%,16V,X7R,TP,1005,-
2 2203-005509 C604 C-CERAMIC,CHIP 330nF,+80-20%,10V,Y5V,TP,1005
2 2203-000654 C605 C-CERAMIC,CHIP 270pF,10%,50V,X7R,TP,1005,-
2 2203-001405 C606 C-CERAMIC,CHIP 22nF,+80-20%,25V,Y5V,TP,1005

SAMSUNG Proprietary-Contents may change without notice
1-4
SGH-T200 ElectricalPartsList
Level SEC Code Design LOC Descriptions
2 2203-005061 C607 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005061 C608 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-000438 C609 C-CERAMIC,CHIP 1nF,10%,50V,X7R,TP,1005,-
2 2203-005061 C610 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-005509 C611 C-CERAMIC,CHIP 330nF,+80-20%,10V,Y5V,TP,1005
2 2404-001151 C612 C-TA,CHIP 33UF,20%,6.3V,LZ,TP,3216
2 2203-000812 C613 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2404-001151 C614 C-TA,CHIP 33UF,20%,6.3V,LZ,TP,3216
2 2203-005061 C615 C-CERAMIC,CHIP 100nF,+80-20%,16V,Y5V,TP,1005
2 2203-000812 C616 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 2203-006053 C618 C-CERAMIC,CHIP 1000NF,10%,10V,X5R,TP,1608
2 2203-006053 C619 C-CERAMIC,CHIP 1000NF,10%,10V,X5R,TP,1608
2 2203-005144 C620 C-CERAMIC,CHIP 1000nF,10%,10V,X7R,TP,2012
2 2203-000812 C621 C-CERAMIC,CHIP 0.033nF,5%,50V,NP0,TP,1005
2 3705-001226 CN101 CONNECTOR-COAXIAL MCX,JACK,75MOHM,50OHM,0.45DB
2 3709-001187 CN401 CONNECTOR-CARD EDGE 6P,2.54MM,SMD-A,-
2 3710-001673 CN501 CONNECTOR-SOCKET 18P,1R,0.5mm,SMD-A,AUF
2 3711-005078 CN502 CONNECTOR-HEADER NOWALL,34P,2R,0.4MM,SMD-S,AU,BLK
2 3722-001456 CN601 JACK-PHONE 2P,2.6PI,AUF,BLK,-
2 0404-001189 D101 DIODE-SCHOTTKY HMPS-2825,15V,1MA,MINIPAK,TP
2 0401-001033 D301 DIODE-SWITCHING MCL4154,25V,200mA,M-MELF,TP
2 2703-002268 L101 INDUCTOR-SMD 8.2NH,10%,1.0X0.5X0.5MM
2 2703-002309 L102 INDUCTOR-SMD 82NH,5%,1.0X0.5X0.5MM
2 2703-002198 L103 INDUCTOR-SMD 10NH,5%,1.0X0.5X0.5MM
2 2703-002324 L104 INDUCTOR-SMD 10NH,5%,1.6X0.8X0.8MM
2 2703-002527 L105 INDUCTOR-SMD 1.5NH,0.3NH,1.6X0.8X0.8MM
2 2703-001229 L201 INDUCTOR-SMD 2.2uH,10%,1.6x0.8x0.8mm
2 2703-002451 L601 INDUCTOR-SMD 270NH,10%,1608
2 0604-001146 LED301 PHOTO-IRDA -,875NM,500MW,30DEG,TP
2 0601-001602 LED504 LED CHIP,BLUE,1.1X0.8MM,472.5NM
2 0601-001602 LED505 LED CHIP,BLUE,1.1X0.8MM,472.5NM
2 0601-001602 LED506 LED CHIP,BLUE,1.1X0.8MM,472.5NM
2 0601-001602 LED508 LED CHIP,BLUE,1.1X0.8MM,472.5NM
2 0601-001602 LED509 LED CHIP,BLUE,1.1X0.8MM,472.5NM
2 0601-001602 LED510 LED CHIP,BLUE,1.1X0.8MM,472.5NM
2 0601-001602 LED511 LED CHIP,BLUE,1.1X0.8MM,472.5NM
2 0601-001602 LED512 LED CHIP,BLUE,1.1X0.8MM,472.5NM
2 0601-001602 LED513 LED CHIP,BLUE,1.1X0.8MM,472.5NM
2 0601-001602 LED518 LED CHIP,BLUE,1.1X0.8MM,472.5NM
2 0601-001602 LED519 LED CHIP,BLUE,1.1X0.8MM,472.5NM
2 0601-001602 LED520 LED CHIP,BLUE,1.1X0.8MM,472.5NM
2 0601-001602 LED521 LED CHIP,BLUE,1.1X0.8MM,472.5NM
2 2801-004191 OSC201 CRYSTAL-SMD 19.5MHZ,10PPM,-,8.25PF,30OHM,TP
2 2801-003856 OSC301 CRYSTAL-SMD 0.032768MHZ,20PPM,28-ACP,7PF,65KOHM,TP
2 GH41-00335A PCB PCB-SGHT200 SGH-T200,FR-3,8L,-,1.0T,100X158,-,-,-,-

SAMSUNG Proprietary-Contents may change without notice
SGH-T200 ElectricalPartsList
1-5
Level SEC Code Design LOC Descriptions
2 0505-001464 Q201 FET-SILICON SI1305DL,P,8V,0.86A,0.28ohm,0.26W,SOT-3
2 0501-000225 Q202 TR-SMALL SIGNAL 2SC4617,NPN,200mW,EM3,TP,120-5
2 0505-001121 Q401 FET-GAAS 3441,20V,+-8V,3.3A,2000mW,TSOP-6,TP
2 0501-002356 Q503 TR-SMALL SIGNAL -,NPN,250MW,SOT-323,TP,250-630
2 0501-000162 Q505 TR-SMALL SIGNAL 2SA1576,PNP,200MW,SOT-323,TP,180-390
2 0504-000167 Q506 TR-DIGITAL RN1102,NPN,100MW,10K/10K,SSM,TP
2 0504-001012 Q511 TR-DIGITAL DTC114YE,NPN,150MW,10K/47K,EMT3,TP
2 2007-000172 R101 R-CHIP 10ohm,5%,1/16W,DA,TP,1005
2 2007-007142 R102 R-CHIP 10Kohm,1%,1/16W,DA,TP,1005
2 2007-000172 R104 R-CHIP 10ohm,5%,1/16W,DA,TP,1005
2 2007-000139 R105 R-CHIP 220ohm,5%,1/16W,DA,TP,1005
2 2007-007142 R106 R-CHIP 10Kohm,1%,1/16W,DA,TP,1005
2 2007-007142 R107 R-CHIP 10Kohm,1%,1/16W,DA,TP,1005
2 2007-000172 R111 R-CHIP 10ohm,5%,1/16W,DA,TP,1005
2 2007-001305 R112 R-CHIP 120ohm,5%,1/16W,DA,TP,1005
2 2007-007142 R113 R-CHIP 10Kohm,1%,1/16W,DA,TP,1005
2 2007-007142 R114 R-CHIP 10Kohm,1%,1/16W,DA,TP,1005
2 2007-007142 R115 R-CHIP 10Kohm,1%,1/16W,DA,TP,1005
2 2007-000982 R116 R-CHIP 5.6Kohm,5%,1/16W,DA,TP,1005
2 2007-001298 R117 R-CHIP 51ohm,5%,1/16W,DA,TP,1005
2 2007-000137 R119 R-CHIP 2Kohm,5%,1/16W,DA,TP,1005
2 2007-007142 R121 R-CHIP 10Kohm,1%,1/16W,DA,TP,1005
2 2007-007142 R122 R-CHIP 10Kohm,1%,1/16W,DA,TP,1005
2 2007-000145 R123 R-CHIP 6.2Kohm,5%,1/16W,DA,TP,1005
2 2007-007771 R124 R-CHIP 0OHM,5%,1/16W,DA,TP,1005
2 2007-007142 R125 R-CHIP 10Kohm,1%,1/16W,DA,TP,1005
2 2007-008117 R126 R-CHIP 2.7Kohm,1%,1/16W,DA,TP,1005
2 2007-000172 R127 R-CHIP 10ohm,5%,1/16W,DA,TP,1005
2 2007-000172 R128 R-CHIP 10ohm,5%,1/16W,DA,TP,1005
2 2007-000172 R129 R-CHIP 10ohm,5%,1/16W,DA,TP,1005
2 2007-001298 R130 R-CHIP 51ohm,5%,1/16W,DA,TP,1005
2 2007-007319 R131 R-CHIP 390ohm,1%,1/16W,DA,TP,1005
2 2007-007564 R132 R-CHIP 510ohm,1%,1/16W,DA,TP,1005
2 2007-007008 R133 R-CHIP 300OHM,5%,1/16W,DA,TP,1005
2 2007-000172 R134 R-CHIP 10ohm,5%,1/16W,DA,TP,1005
2 2007-001156 R135 R-CHIP 750ohm,5%,1/16W,DA,TP,1005
2 2007-007134 R136 R-CHIP 39Kohm,1%,1/16W,DA,TP,1005
2 2007-000172 R137 R-CHIP 10ohm,5%,1/16W,DA,TP,1005
2 2007-000070 R138 R-CHIP 0ohm,5%,1/16W,DA,TP,1608
2 2007-001298 R139 R-CHIP 51ohm,5%,1/16W,DA,TP,1005
2 2007-007771 R140 R-CHIP 0OHM,5%,1/16W,DA,TP,1005
2 2007-000140 R201 R-CHIP 1Kohm,5%,1/16W,DA,TP,1005
2 2007-000775 R202 R-CHIP 33Kohm,5%,1/16W,DA,TP,1005
2 2007-007771 R203 R-CHIP 0OHM,5%,1/16W,DA,TP,1005
2 2007-007092 R204 R-CHIP 1.1KOHM,5%,1/16W,DA,TP,1005

SAMSUNG Proprietary-Contents may change without notice
1-6
SGH-T200 ElectricalPartsList
Level SEC Code Design LOC Descriptions
2 2007-007771 R205 R-CHIP 0OHM,5%,1/16W,DA,TP,1005
2 2007-008275 R206 R-CHIP 30KOHM,1%,1/16W,DA,TP,1005
2 2007-000141 R209 R-CHIP 2.2Kohm,5%,1/16W,DA,TP,1005
2 2007-000162 R216 R-CHIP 100Kohm,5%,1/16W,DA,TP,1005
2 2007-000758 R217 R-CHIP 330Kohm,5%,1/16W,DA,TP,1005
2 2007-000162 R218 R-CHIP 100Kohm,5%,1/16W,DA,TP,1005
2 2007-000164 R220 R-CHIP 150Kohm,5%,1/16W,DA,TP,1005
2 2007-007014 R301 R-CHIP 51KOHM,5%,1/16W,DA,TP,1005
2 2007-007771 R302 R-CHIP 0OHM,5%,1/16W,DA,TP,1005
2 2007-000140 R304 R-CHIP 1Kohm,5%,1/16W,DA,TP,1005
2 2007-001290 R305 R-CHIP 24ohm,5%,1/16W,DA,TP,1005
2 2007-000170 R306 R-CHIP 1Mohm,5%,1/16W,DA,TP,1005
2 2007-007771 R307 R-CHIP 0OHM,5%,1/16W,DA,TP,1005
2 2007-000138 R310 R-CHIP 100ohm,5%,1/16W,DA,TP,1005
2 2007-000169 R312 R-CHIP 510Kohm,5%,1/16W,DA,TP,1005
2 2007-000148 R401 R-CHIP 10Kohm,5%,1/16W,DA,TP,1005
2 2007-000143 R402 R-CHIP 4.7Kohm,5%,1/16W,DA,TP,1005
2 2007-000143 R403 R-CHIP 4.7Kohm,5%,1/16W,DA,TP,1005
2 2007-007771 R404 R-CHIP 0OHM,5%,1/16W,DA,TP,1005
2 2007-001325 R405 R-CHIP 3.3Kohm,5%,1/16W,DA,TP,1005
2 2007-007771 R416 R-CHIP 0OHM,5%,1/16W,DA,TP,1005
2 2007-007771 R460 R-CHIP 0OHM,5%,1/16W,DA,TP,1005
2 2007-000174 R501 R-CHIP 47ohm,5%,1/16W,DA,TP,1005
2 2007-000140 R502 R-CHIP 1Kohm,5%,1/16W,DA,TP,1005
2 2007-007480 R503 R-CHIP 130Kohm,1%,1/16W,DA,TP,1005
2 2007-000140 R518 R-CHIP 1Kohm,5%,1/16W,DA,TP,1005
2 2007-000174 R519 R-CHIP 47ohm,5%,1/16W,DA,TP,1005
2 2007-000140 R523 R-CHIP 1Kohm,5%,1/16W,DA,TP,1005
2 2007-000148 R529 R-CHIP 10Kohm,5%,1/16W,DA,TP,1005
2 2007-000142 R530 R-CHIP 2.7Kohm,5%,1/16W,DA,TP,1005
2 2007-000140 R547 R-CHIP 1Kohm,5%,1/16W,DA,TP,1005
2 2007-000172 R549 R-CHIP 10ohm,5%,1/16W,DA,TP,1005
2 2007-000172 R550 R-CHIP 10ohm,5%,1/16W,DA,TP,1005
2 2007-000172 R551 R-CHIP 10ohm,5%,1/16W,DA,TP,1005
2 2007-000172 R552 R-CHIP 10ohm,5%,1/16W,DA,TP,1005
2 2007-000172 R553 R-CHIP 10ohm,5%,1/16W,DA,TP,1005
2 2007-007092 R602 R-CHIP 1.1KOHM,5%,1/16W,DA,TP,1005
2 2007-000159 R603 R-CHIP 56Kohm,5%,1/16W,DA,TP,1005
2 2007-000156 R604 R-CHIP 30Kohm,5%,1/16W,DA,TP,1005
2 2007-000156 R605 R-CHIP 30Kohm,5%,1/16W,DA,TP,1005
2 2007-000156 R606 R-CHIP 30Kohm,5%,1/16W,DA,TP,1005
2 2007-001325 R607 R-CHIP 3.3Kohm,5%,1/16W,DA,TP,1005
2 2007-008117 R609 R-CHIP 2.7Kohm,1%,1/16W,DA,TP,1005
2 2007-000140 R610 R-CHIP 1Kohm,5%,1/16W,DA,TP,1005
2 2007-000142 R611 R-CHIP 2.7Kohm,5%,1/16W,DA,TP,1005

SAMSUNG Proprietary-Contents may change without notice
SGH-T200 ElectricalPartsList
1-7
Level SEC Code Design LOC Descriptions
2 2007-000566 R613 R-CHIP 220Kohm,5%,1/16W,DA,TP,1005
2 2007-001292 R614 R-CHIP 33ohm,5%,1/16W,DA,TP,1005
2 2007-000140 R616 R-CHIP 1Kohm,5%,1/16W,DA,TP,1005
2 2007-001339 R618 R-CHIP 180Kohm,5%,1/16W,DA,TP,1005
2 2007-007771 R619 R-CHIP 0OHM,5%,1/16W,DA,TP,1005
2 2007-007200 R620 R-CHIP 2.4OHM,5%,1/16W,DA,TP,1005
2 2909-001186 U100 FILTER-DUPLEXER 942.5MHZ,897.5MHZ,4.0/1.1DB,TP,905-915M
HZ/25DB,-
2 1201-001926 U101 IC-OP AMP LMV722,LLP,TP,8P,2.5X3MM,DUAL,87DB,PLAS
TIC,5V,-,-40TO+85C,89DB,5.25V/US,25NA,2
2 1205-002218 U102 IC-TRANSCEIVER CX74017,LGA,64P,9X9MM,PLASTIC,3.3V,600M
W,-20TO+85C,TP,-
2 1201-001927 U103 IC-POWER AMP CX77304,LGA,16P,9.1X11.6MM,-,-,PLASTIC,
4.8V,-,-20TO+100C,-,-,-,-,-
2 4709-001144 U104 COUPLER-DIRECTION 897.5/1747.5MHZ,19DB/14DB,24DB,2X1.25X0.
95,TP
2 1204-002033 U201 IC-IF CIRCUIT CX20505,CABGA,104P,10X10MM,PLASTIC,4.8V,
-,-40TO+85C,TP,-
2 1009-001010 U301 IC-HALL EFFECT S/W
A3212ELH-SAMSUNG,SC-59A,3P,82MIL,TP,BIC
MOS,PLASTIC,3.5V,2MA,-40TO+85C,-,-,-,34
0K
2 1205-002219 U302 IC-DATA COMM./GEN. CX80501,UBGA,160P,12X12MM,PLASTIC,3.6V,
-,-35TO+85C,TR,BASEBAND PROCESSOR
2 1109-001242 U303 IC-ETC. MEMORY LRS1395,4MX16/4MX16/1MX16BIT,CSP,72P,11
X8MM,70NS,3V,10%,PLASTIC,-20TO+85C,50UA
2 1103-001185 U304 IC-EEPROM 24A2561,32Kx8Bit,TSSOP,8P,-,-,1.8V,-,PL
ASTIC,-25to+70C,1uA,CMOS,TR
2 0801-002294 U307 IC-CMOS LOGIC 7SH08,AND GATE,SSOP,5P,50MIL,S
2 1203-002689 U308 IC-POSI.FIXED REG. S-817,SC-82AB,4P,2X1.25MM,-,2.45/2.55V,
150MW,-40TO+85C,35MA,-,TP
2 1203-002688 U310 IC-POSI.FIXED REG. S-817,SC-82AB,4P,2X1.25MM,-,3.234/3.366
V,150MW,-40TO+85C,50MA,-,TP
2 1203-002691 U401 IC-POWER SUPERVISOR CX20460,LGA,48P,7X7MM,PLASTIC,3.15/4.5V,
1613MW,-40TO+85C,130MA,-,TP
2 0506-001052 U503 TR-ARRAY UMH9N,NPN,2,150MW,SC-88,TP,68-
2 1003-001519 U504 IC-MOTOR DRIVER LB1938T,MSOP-8,8P,119MIL,-,100MA,TP,-,1
0V,-30TO+85C,400MW,0.15V,-
2 1203-002054 U518 IC-VOLTAGE REGULATOR 5245,SOT-23-5,5P,64MIL,PLASTIC,2.94/3.0
6V,-,-40to+125C,100uA,-,TP
2 1203-002583 U519 IC-VOLTAGE REGULATOR MIC5219-3.3BMM,MSOP,8P,118MIL,PLASTIC,3.
3/+3.3V,-,-40TO+125C,500MA,-,TP
2 1204-001811 U603 IC-MELODY YMU759-QE2,QFN,32P,-,PLASTIC,6V,-,-20TO
+85C,TP,-

SAMSUNG Proprietary-Contents may change without notice
1-8
SGH-T200 ElectricalPartsList
Level SEC Code Design LOC Descriptions
2 0504-001071 U607 TR-DIGITAL UMD9N,NPN/PNP,150mW,4.7,UMT6,TP
2 0801-002774 U615 IC-CMOS LOGIC TC7MA138FK,3TO8DECORDER,VSSOP,16P,118MI
L,SINGLE,TP,PLASTIC,-,-,-,-40TO+85C,180
2 0801-002294 U616 IC-CMOS LOGIC 7SH08,AND GATE,SSOP,5P,50MIL,S
2 1405-001082 V501 VARISTOR 5.6V,20A,1x0.5x0.6mm,TP
2 1405-001082 V502 VARISTOR 5.6V,20A,1x0.5x0.6mm,TP
2 1405-001082 V503 VARISTOR 5.6V,20A,1x0.5x0.6mm,TP
2 1405-001082 V504 VARISTOR 5.6V,20A,1x0.5x0.6mm,TP
2 1405-001082 V505 VARISTOR 5.6V,20A,1x0.5x0.6mm,TP
2 1405-001082 V506 VARISTOR 5.6V,20A,1x0.5x0.6mm,TP
2 1405-001082 V507 VARISTOR 5.6V,20A,1x0.5x0.6mm,TP
2 1405-001082 V508 VARISTOR 5.6V,20A,1x0.5x0.6mm,TP
2 1405-001093 V509 VARISTOR 14V,20A,1x0.5x0.6mm,TP
2 1405-001082 V525 VARISTOR 5.6V,20A,1x0.5x0.6mm,TP
2 1405-001082 V526 VARISTOR 5.6V,20A,1x0.5x0.6mm,TP
2 1405-001093 V527 VARISTOR 14V,20A,1x0.5x0.6mm,TP
2 1405-001082 V528 VARISTOR 5.6V,20A,1x0.5x0.6mm,TP
2 1405-001082 V614 VARISTOR 5.6V,20A,1x0.5x0.6mm,TP
2 1405-001082 V615 VARISTOR 5.6V,20A,1x0.5x0.6mm,TP
2 0404-001157 ZD401 DIODE-SCHOTTKY RB160M-30,30V,1000MA,SOD-323,TR
2 0406-001104 ZD501 DIODE-TVS ESDA6V1-5W6,6.1/-/7.2V,100W,SOT-323-6L
2 0406-001104 ZD506 DIODE-TVS ESDA6V1-5W6,6.1/-/7.2V,100W,SOT-323-6L

SAMSUNG Proprietary-Contents may change without notice
2.SGH-T200 ExplodedViewand its Partslist
2-1
1.CellularphoneExplodedView
1
2
3
4
5
6
7
8
9
10
11
12
13
14
16
17
18
21
19
20
22
15

SAMSUNG Proprietary-Contents may change without notice
2-2
SGH-T200 Explodedviewand its Partlist
2.CellularphonePartslist
Location
NO.DescriptionSEC CODE Remark
1DUALWINDOWLCDGH72-03997B
2FOLDER UPPER GH75-01788C
3LCDGH07-00183A
4CONFPCB GH59-00479A
5MOTFPCB GH59-00503A
6FOLDER LOWER GH75-01787A
7LCDWINDOWGH72-03996A
8AUTOKEYGH75-01791A
9FRONTCOVER GH75-01786A
10 VOLUMEKEYGH75-01792A
11 KEYPADGH75-01798C
12 MAINPBAGH92-01387A
13 V/KEYASS'YGH59-00462A
14 METALDOMESHEETGH59-00370A
15 MICASS'YGH59-00536A
16 I/FCOVER GH73-00741L
17 SHIELDCANGH75-02716A
18 ANTENNAGH42-00202A
19 SCREWRFDUMMYGH73-01077A
20 SCREW6001-001155
21 REARCOVER GH75-01790A
22 BATTERYGH43-00679A700mA
GH43-00680A900mA

SAMSUNG Proprietary-Contents may change without notice
SGH-T200 Explodedviewand its Partlist
2-3
3.TestJig(GH80-00585A)
3-1.TestJigCable(GH39-00096A)3-2.RFJigCable(GH39-00140A)

SAMSUNG Proprietary-Contents may change without notice
2-4
SGH-T200 Explodedviewand its Partlist
M
ME EM MO O

SAMSUNG Proprietary-Contents may change without notice
3-1
3.SGH-T200BlockDiagrams
1.BlockDiagram

SAMSUNG Proprietary-Contents may change without notice
SGH-T200BlockDiagrams
3-2
2.RFBlockDiagram

SAMSUNG Proprietary-Contents may change without notice
SGH-T200BlockDiagrams
3-3
3.Receive BlockDiagram

SAMSUNG Proprietary-Contents may change without notice
SGH-T200BlockDiagrams
3-4
4.TransmitBlockDiagram

SAMSUNG Proprietary-Contents may change without notice
4-1
4.SGH-T200 PCB Diagrams
1.MainPCB TopDiagram
ANT1
BAT1
C103
C105
C106
C107
C108
C109
C110
C111
C113
C114
C116
C117
C118
C119
C120
C121
C123
C125
C126
C127
C128
C130
C131
C132
C133
C134
C135
C136
C138
C139
C140
C141
C143
C144
C145
C146
C147C148
C149
C152
C153
C201 C202
C203
C204
C205
C206 C207
C208
C210 C211
C212 C213
C214
C216
C220
C221
C222
C223 C224
C225
C226
C227
C228 C229 C230
C231
C232 C233
C234
C235
C301
C302
C303
C305
C306
C307
C308
C309
C310
C311
C312
C315
C316
C317
C320
C322
C401
C402
C403
C404
C405
C406
C407 C408
C409
C410
C411
C420
C501
C502
C503
C505 C506
C507
C509
C510
C512
C513
C514
C515
C519
C520
C521
C522
C525
C527
C530
C547
C598 C599
C601
C611
C612
C613
C614
C615
C616
C618
C619
C620
C621
CN101
CN401
CN501
CN502
CN601
D101
D301
H1
H2
H3
H4
H5
H6
L101
L102
L103
L104
L105
L201
L601
LED301
OSC201
OSC301
Q201
Q202
Q401
Q505
Q506
Q511
R102
R104
R105 R106
R111
R112
R116
R117
R119
R124
R127
R129
R131
R132
R133
R134
R135
R136 R137
R138
R139
R140
R201
R202
R203
R204
R205
R206
R209
R216 R217
R218
R220
R302
R304
R305
R306
R307
R310
R312
R315
R401
R402 R403
R404
R405
R416
R460
R461 R501 R502
R503
R529
R530
R547
R549
R602
R608
R609
R610
R611
R612
R613
R614
R616
R618
R619
R620
R624
R625
TCLK
TDI TDO TMS
TRST
U100
U102
U103
U104
U201
U302
U303
U304
U307
U308
U310
U401
U408
U503
U518
U519
U607
U615
U616
V501 V502
V509
V525
V526
V527
V528
V614
V615
WRITE_EN
ZD401
ZD501
ZD506

SAMSUNG Proprietary-Contents may change without notice
SGH-T200 PCB Diagrams
4-2
2.MainPCB BottomDiagram
*
0
1
2
3
4
5
6
7
8
9
C101
C102
C104
C112
C122
C150
C151
C304
C504
C533 C534
C535
C536
C548
C549
C550
C551
C602
C603
C604
C605
C606
C607
C608 C609
C610
CENTER
CLEAR
CN504
DOWN
END
KEY3
LED504
LED505
LED506
LED508
LED509
LED510
LED511
LED512
LED513
LED514
LED515
LED516 LED517
LED518
LED519
LED520
LED521
LED522
LED524
LED525
LED526
LEFT
MANU
MIC601
OK
Q503
R101
R107
R113
R114
R115 R121
R122
R123
R125
R126
R128
R130
R301
R518
R519
R522
R523
R524
R550
R551
R552
R553
R603
R604
R605
R606 R607
RIGHT
SEND
SH
TP208
TP301
U101
U301
U504
U603
UP
V503
V504
V505
V506
V507
V508

SAMSUNG Proprietary-Contents may change without notice
5.SGH-T200 FlowChartofTroubleshooting
5-1
1.PowerON
Checkthecurrent
consumptionmorethan
100mA
'POWER ON'doesnotwork
ChecktheVoltagemore
than3.3V
Downloadagain
ChargetheBattery
Checkthepin
26 ofU401(PMIC)is
morethan3.2VChecktothepathfromCN501 topin
26 ofU401
U401 pin33
=2.8VCheckthePMIC(U401)
Checkthepin10 of
U401 ishighChecktheCX805(U302)
Checktheinitial operation
END
No
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
No
