Samsung SGH-ZV40 User manual

UMTS TELEPHONE
SGH-ZV40
UMTS TELEPHONE CONTENTS
1. Safety Precautions
2. Specification
3. Product Function
4. Array course control
5. Exploded View and Parts List
6. MAIN Electrical Parts List
7. Block Diagrams
8. PCB Diagrams
9. Flow Chart of Troubleshooting
10. Reference data
11. Disassembly and Assembly
Instructions

CONTENTS
1. Safety Precautions
1-1. Repair Precaution...........................................................................1-1
1-2. ESD(Electrostatically Sensitive Devices) Precaution...........................1-2
2. Specification
2-1. GSM General Specification..............................................................2-1
2-2. GSM Tx Power Class......................................................................2-2
3. Product Function
4. Array course control
4-1. Downloading Binary Files................................................................4-2
4-2. Fre-requsite for Downloading..........................................................4-2
4-3. S/W Downloader Program...............................................................4-3
5. Exploded View and Parts List
5-1. Cellular phone Exploded View.........................................................5-1
5-2. Cellular phone Parts list.................................................................5-2
6. MAIN Electrical Parts List
7. Block Diagrams
8. PCB Diagrams

CONTENTS
9. Flow Chart of Troubleshooting
9-1. Power On.....................................................................................9-1
9-2. Initial ..........................................................................................9-3
9-3. Sim Part.......................................................................................9-4
9-4. Speaker Part................................................................................9-7
9-5. Microphone Part.............................................................................9-9
9-6. Key Data Input...........................................................................9-11
9-7. Receiver Part..............................................................................9-12
9-8. Back Light..................................................................................9-13
9-9. Key Back Light............................................................................9-15
9-10. Camera Part.............................................................................9-17
9-11. GSM Receiver............................................................................9-19
9-12. GSM Transmitter.......................................................................9-20
9-13. DCS Receiver............................................................................9-21
9-14. DCS Transmitter........................................................................9-22
9-15. PCS Receiver............................................................................9-23
9-16. PCS Transmitter........................................................................9-24
9-17. WCDMA Receiver.......................................................................9-25
9-18. WCDMA Transmitter...................................................................9-26
10. Reference data
11. Disassembly and Assembly Instructions
11-1. Disassemby...............................................................................11-1
11-2. Assembly...................................................................................11-5

SAMSUNG Proprietary-Contents may change without notice
1.  
1-1
This Document can not be used without Samsung's authorization
  
       
      
          
           
           
          
     
         
            
              
             
     
               
               
         
               
             

SAMSUNG Proprietary-Contents may change without notice
S 
1-2
This Document can not be used without Samsung's authorization
    
              
          
        
             
             
   
          
               
 
                   
         
                  
        

2. Specification
2-1
2-1. GSM General Specification
EGSM900 DCS1800 PCS1900 W-CDMA
Freq.
Band[MHz]
Uplink/Downlink
880~915
925~960 1710~1785 1805~1880 1850~1910 1930~1990 1920~1980 2110~2170
ARFCN range 0~124 &
975~1023 512~885 512~810 UL:9612~9888 DL:10562~10838
Tx/Rx spacing 45MHz 95MHz 80MHz 190MHz
Mod. Bit rate/
Bit Period 270.833kbps 3.692us 270.833kbps 3.692us 270.833kbps 3.692us 3.84Mcps
Time Slot
Period/Frame
Period
576.9us
4.615ms 576.9us 4.615ms 576.9us 4.615ms Frame length : 10ms
Modulation 0.3GMSK 0.3GMSK 0.3GMSK QPSK
HQPSK
MS Power 33dBm~5dBm 30dBm~0dBm 30dBm~0dBm 24dBm ~ - 50dBm
Power Class 4
(max +33dBm) 1 (max +30dBm) 1 (max +30dBm) 3 (max +24dBm)
Sensitivity -102dBm -100dBm -100dBm -106.7dBm
TDMA Mux 8 8 8
Cell Radius 35Km 2Km 2Km 2Km

Speclflcation
2-2
TX Power
control level PCS1800
030±3dBm
128±3dBm
226±3dBm
324±3dBm
422±3dBm
520±3dBm
618±3dBm
716±3dBm
814±3dBm
912±4dBm
10 10±4 dBm
11 8±4dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
TX Power
control level DCS1800
030±3dBm
128±3dBm
226±3dBm
324±3dBm
422±3dBm
520±3dBm
618±3dBm
716±3dBm
814±3dBm
912±4dBm
10 10±4 dBm
11 8±4dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
TX Power
control level GSM900
533±2dBm
631±2dBm
729±2dBm
827±2dBm
925±2dBm
10 23±2 dBm
11 21±2 dBm
12 19±2 dBm
13 17±2 dBm
14 15±2 dBm
15 13±2 dBm
16 11±3 dBm
17 9±3dBm
18 7±3 dBm
19 5±3 dBm
2-2. GSM Tx Power Class

SAMSUNG Proprietary-Contents may change without notice
3.  
3-1
This Document can not be used without Samsung's authorization
 
-Camera and camcorder
-Image editor
-MP3 player
-Phonebook
-Name card
-Multimedia Message Service (MMS)
-E-mail
-Voice recorder
-Bluetooth
-Get personal with photo caller ID
-Web browser
-Java
-Calendar

SAMSUNG Proprietary-Contents may change without notice
Product Function
3-2
This Document can not be used without Samsung's authorization

SAMSUNG Proprietary-Contents may change without notice
4. Array course control
4-1
This Document can not be used without Samsung's authorization
Test Jig (GH80-03307A)
RF Test Cable (GH39-00283A)
Test Cable (GH39-00397A)

SAMSUNG Proprietary-Contents may change without notice
Array course control
4-2
This Document can not be used without Samsung's authorization
Software Downloading
4-1. Downloading Binary Files
• Three binary files for downloading V804SS.
– VMSZT.bin : Modem binary for communication function
& Mocha binary for user interface and various application
– Rsrc_ZV40_VodafoneKK.cnt: Files need for each application
– Rsrc2.cnt : Power on/off animation
– FactoryFs_ZV40_VodafoneKK.bin : Default file system to be put into in
initial production
4-2. Pre-requsite for Downloading
• Downloader Program(FastMultiloader1.5.exe)
• V804SS Mobile Phone
• Data Cable
• Binary files

SAMSUNG Proprietary-Contents may change without notice
Array course control
4-3
This Document can not be used without Samsung's authorization
4-3. S/W Downloader Program
1. Boot the V804SS by pressing ‘Power ON key’ + ‘Number 9 key’ at the same time-
If you do properly, you can see the following message on sub LCD “DOWNLOAD
VODAKK 4.0”
2. Load the binary download program by executing the “FastMultiloader1.5.exe”
3. Select the check box what you want to download.

SAMSUNG Proprietary-Contents may change without notice
Array course control
4-4
This Document can not be used without Samsung's authorization
4. Select the binary file what you want to download
5. Now press the button ‘DownLoad’.
6. When downloading is complete, UE reboot automatically.
•If there is difference in FactoryFs.bin, UE will format file system automatically.
* Up to eight ports are supported.

SAMSUNG Proprietary-Contents may change without notice
5. Exploded View and Parts List
5-1
This Document can not be used without Samsung's authorization
5-1. Cellular phone Exploded View
QKP01
QME01
QCH01
QCK01
QFR01
QMP01
QCA02
QVK01
QMI01
QCR31
QAN02
QRF03
QMI04
QRE01
QRF04
QCR12
QRF10
QRF01
QBA01
QVO01
QFU01 QHI01
QCA01
QLC01
QMO01
QSP01
QFU02
QFL02
QFL01
QCR31
QSC01
QMW01
QMI03

SAMSUNG Proprietary-Contents may change without notice
Exploded view and Parts List
5-2
This Document can not be used without Samsung's authorization
Design LOC Discription SEC Code
QAN02 ANTENNA GH42-00785A
QBA01 BATTERY-1000MA, DARK WARM GRAY GH43-02482A
QCA01 UNIT-CAMERA 1/4" GH59-03184A
QCA02 UNIT-CAMERA KEY GH59-03015A
QCH01 ASSY MEC-HINGE CAMERA GH75-09535A
QCK01 PMO-CAMERA KEY GH72-29874A
QCR12 SCREW-MACHINE 6001-001530
QCR31 SCREW-MACHINE 6001-001795
QCR31 SCREW-MACHINE 6001-001795
QFL02 PMO-COVER CAM LOWER V2 GH72-31680A
QFR01 MEC-CASE FRONT GH75-09532A
QFU01 MEC-CASE UPPER GH75-09530A
QFU02 ASSY CASE-CAM UPPERV2 GH98-01512A
QKP01 ASSY MEC-KEYPAD(EU/SIL) GH75-09534A
QLC01 ELA ETC-LCD MODULE GH96-02169A
QME01 UNIT-DOME SHEET(MAIN) GH59-03017A
QMI01 MICROPHONE-ASSY-SGHE340 GH30-00199A
QMI03 RMO-RUBBER MIC GH73-06711A
QMO01 MOTOR DC-SPHV8400 GH31-00187A
QMP01 PBA MAIN-SGH-ZV40(VD2) GH92-02740A
QMW01 PCT-COVER MAIN WINDOW GH72-29869A
QRF01 MPR-TAPE RF SWITCH GH74-21757A
QRF03 PMO-COVER EAR JACK GH72-29877A
QRF04 MPR-TAPE COVER EAR JACK GH74-21758A
QSC01 RMO-RUBBER SCREW COVER L GH73-06708A
QSP01 SPEAKER 3001-001956
QVK01 UNIT-VOLUME KEY GH59-03016A
QVO01 PMO-VOLUME KEY GH72-29873A
QFL01 MEC-CASE LOWER GH75-09531A
QHI01 ASSY-HINGE-SGHZV40 GH98-00969A
QRE01 MEC-CASE REAR GH75-09533A
QMI04 RMO-RUBBER PMIC GH73-06713A
QRF10 PMO-COVER SD CARD GH72-29876A
5-2. Cellular phone Parts list

SAMSUNG Proprietary-Contents may change without notice
Exploded view and Parts List
5-3
This Document can not be used without Samsung's authorization
Discription SEC Code
CARD-WARRANTY 6801-001501
BAG PE 6902-000634
CBF INTERFACE-DATA LINK CABLE GH39-00444A
ADAPTOR-SGHD800 TA(EU) GH44-01060A
S/W CD-SGH-ZV40 SAMSUNG PC STU GH46-00239A
UNIT-EARPHONE(BLK) GH59-02499A
SPRING ETC-BATT LOCKER GH61-00120A
LABEL(P)-WATER SOAK GH68-02026A
LABEL(P)-WATER SOAK GH68-02026A
MANUAL USERS-VODA ENGLISH GH68-09843A
MANUAL USERS-VODA DUTCH GH68-09849A
LABEL(R)-MAIN(EU) GH68-10711A
MANUAL USERS-VODA QSG DUTCH GH68-11173A
BOX-UNIT(VODA) GH69-03907A
CUSHION-CASE(EU) GH69-03908A
PCT-COVER SUB WINDOW GH72-29868A
RMO-RUBBER PCB CON GH73-06710A
RMO-RUBBER LCD EMI GH73-07569A
MPR-REMOVE TAPE LCD GH74-13804A
MPR-BOHO VINYL LCD CONN GH74-15350A
MPR-TAPE FPCB DOUBLE GH74-16772A
MPR-TAPE REMOVE LCD GH74-18286A
MPR-TAPE MAIN LDI GH74-19992A
MPR-TAPE SUB LCD INS GH74-20485A
MPR-TAPE MAIN WINDOW GH74-21752A
MPR-TAPE FRONT PROTECTIOL GH74-21754A
MPR-TAPE PCB DOME A GH74-21755A
MPR-VINYL BOHO UPPER GH74-21776A
MPR-VINYL BOHO UPPER GH74-21776A
MPR-TAPE PCB DOME B GH74-23172A
MPR-TAPE LCD CON B GH74-24226A
MPR-TAPE ZIP CON GH74-24514A
MPR-TAPE PCB DOME C GH74-25278A
MPR-VINYL BOHO REAR GH74-25644A
MPR-VINYL BOHO MAIN WIN GH74-25645A
MPR-TAPE PCB CON GH74-25646A
MPR-SPONGE FPCB GH74-25722A
ASSY RUBBER-PCB CON GH98-01796A

SAMSUNG Proprietary-Contents may change without notice
Exploded view and Parts List
5-4
This Document can not be used without Samsung's authorization

SAMSUNG Proprietary-Contents may change without notice
6. MAIN Electrical Parts List
6-1
This Document can not be used without Samsung's authorization
Design LOC Discription SEC Code STATUS
AN100 NPR-ANTENNA CONTACT GH71-04302A SA
AN101 NPR-ANTENNA CONTACT GH71-04302A SA
AN400 ANTENNA-CHIP 4202-001134 SA
BAT500 BATTERY-LI(2ND) 4302-001130 SA
BTC401 HEADER-BATTERY 3711-006026 SA
C100 C-CER,CHIP 2203-005717 SA
C101 C-CER,CHIP 2203-005808 SA
C102 C-CER,CHIP 2203-005806 SA
C103 C-CER,CHIP 2203-005682 SA
C104 C-CER,CHIP 2203-002677 SA
C105 INDUCTOR-SMD 2703-002198 SA
C106 C-CER,CHIP 2203-006423 SA
C107 C-CER,CHIP 2203-005682 SA
C108 C-CER,CHIP 2203-005682 SA
C109 C-CER,CHIP 2203-006423 SA
C110 C-CER,CHIP 2203-005719 SA
C111 C-CER,CHIP 2203-006423 SA
C112 C-CER,CHIP 2203-005682 SA
C113 C-CER,CHIP 2203-005682 SA
C114 C-CER,CHIP 2203-006423 SA
C115 C-CER,CHIP 2203-006379 SA
C116 C-CER,CHIP 2203-006423 SA
C117 C-CER,CHIP 2203-005806 SA
C119 C-CER,CHIP 2203-005808 SA
C120 C-CER,CHIP 2203-006556 SA
C121 C-CER,CHIP 2203-005682 SA
C122 C-CER,CHIP 2203-005682 SA
C123 C-CER,CHIP 2203-006556 SA
C124 C-CER,CHIP 2203-005682 SA
C125 C-CER,CHIP 2203-005808 SA
C126 C-CER,CHIP 2203-006423 SA
C127 C-CER,CHIP 2203-000725 SA
C128 C-CER,CHIP 2203-005552 SA
C129 C-CER,CHIP 2203-006318 SA
C130 C-CER,CHIP 2203-000836 SA
C132 C-CER,CHIP 2203-006423 SA
C133 C-CER,CHIP 2203-006423 SA
C134 C-CER,CHIP 2203-005682 SA
C135 C-CER,CHIP 2203-000438 SA
C137 C-CER,CHIP 2203-006423 SA
C138 C-CER,CHIP 2203-006194 SA
C139 C-CER,CHIP 2203-005719 SA
C140 C-CER,CHIP 2203-006399 SA
C141 C-CER,CHIP 2203-006194 SA
C142 C-CER,CHIP 2203-005682 SA
C143 C-CER,CHIP 2203-006838 SA
C144 C-CER,CHIP 2203-006423 SA
C145 C-CER,CHIP 2203-005503 SA
C146 C-CER,CHIP 2203-002443 SA
C147 C-CER,CHIP 2203-005234 SA
C148 C-CER,CHIP 2203-005729 SA
C149 C-CER,CHIP 2203-006194 SA
C150 C-CER,CHIP 2203-006194 SA

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-2
This Document can not be used without Samsung's authorization
Design LOC Discription SEC Code STATUS
C151 C-CER,CHIP 2203-005729 SA
C152 C-CER,CHIP 2203-006194 SA
C153 C-CER,CHIP 2203-000311 SA
C154 C-CER,CHIP 2203-000438 SA
C155 C-CER,CHIP 2203-005682 SA
C156 C-CER,CHIP 2203-006137 SA
C157 C-CER,CHIP 2203-002677 SA
C158 C-CER,CHIP 2203-006665 SA
C201 C-CER,CHIP 2203-006838 SA
C206 C-CER,CHIP 2203-005682 SA
C207 C-CER,CHIP 2203-005736 SA
C208 C-CER,CHIP 2203-005682 SA
C209 C-CER,CHIP 2203-005806 SA
C210 C-CER,CHIP 2203-005682 SA
C211 C-CER,CHIP 2203-006120 SA
C212 C-CER,CHIP 2203-006194 SA
C213 C-CER,CHIP 2203-005736 SA
C214 C-CER,CHIP 2203-006423 SA
C215 C-CER,CHIP 2203-000438 SA
C217 C-CER,CHIP 2203-000725 SA
C218 C-CER,CHIP 2203-006194 SA
C219 C-CER,CHIP 2203-006121 SA
C223 C-CER,CHIP 2203-000940 SA
C224 C-CER,CHIP 2203-005682 SA
C225 C-CER,CHIP 2203-006556 SA
C226 C-CER,CHIP 2203-005736 SA
C227 C-CER,CHIP 2203-006423 SA
C228 C-CER,CHIP 2203-006423 SA
C229 C-CER,CHIP 2203-006305 SA
C230 C-CER,CHIP 2203-006423 SA
C231 C-CER,CHIP 2203-006305 SA
C232 C-CER,CHIP 2203-006194 SA
C233 C-CER,CHIP 2203-006194 SA
C234 C-CER,CHIP 2203-006423 SA
C235 C-CER,CHIP 2203-005806 SA
C237 C-CER,CHIP 2203-000330 SA
C239 C-CER,CHIP 2203-000330 SA
C300 C-CER,CHIP 2203-006194 SA
C301 C-CER,CHIP 2203-006194 SA
C302 C-CER,CHIP 2203-006194 SA
C303 C-CER,CHIP 2203-006194 SA
C304 C-CER,CHIP 2203-005806 SA
C305 C-CER,CHIP 2203-006194 SA
C306 C-CER,CHIP 2203-006194 SA
C307 C-CER,CHIP 2203-005806 SA
C308 C-CER,CHIP 2203-005806 SA
C309 C-CER,CHIP 2203-006562 SA
C310 C-CER,CHIP 2203-006423 SA
C311 C-CER,CHIP 2203-006423 SA
C312 C-CER,CHIP 2203-006423 SA
C313 C-CER,CHIP 2203-006423 SA
C314 C-CER,CHIP 2203-006423 SA
C315 C-CER,CHIP 2203-006423 SA

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-3
This Document can not be used without Samsung's authorization
Design LOC Discription SEC Code STATUS
C316 C-CER,CHIP 2203-006423 SA
C317 C-CER,CHIP 2203-006423 SA
C318 C-CER,CHIP 2203-006423 SA
C319 C-CER,CHIP 2203-006423 SA
C320 C-CER,CHIP 2203-006562 SA
C321 C-CER,CHIP 2203-006423 SA
C322 C-CER,CHIP 2203-006423 SA
C323 C-CER,CHIP 2203-006423 SA
C324 C-CER,CHIP 2203-006423 SA
C325 C-CER,CHIP 2203-006423 SA
C326 C-CER,CHIP 2203-006423 SA
C327 C-CER,CHIP 2203-006423 SA
C328 C-CER,CHIP 2203-006423 SA
C329 C-CER,CHIP 2203-006562 SA
C330 C-CER,CHIP 2203-006423 SA
C331 C-CER,CHIP 2203-006194 SA
C332 C-CER,CHIP 2203-006194 SA
C333 C-CER,CHIP 2203-005725 SA
C334 C-CER,CHIP 2203-005725 SA
C335 C-CER,CHIP 2203-006668 SA
C336 C-CER,CHIP 2203-006423 SA
C337 C-CER,CHIP 2203-006423 SA
C338 C-CER,CHIP 2203-005736 SA
C339 C-CER,CHIP 2203-005682 SA
C340 C-CER,CHIP 2203-005480 SA
C341 C-CER,CHIP 2203-006194 SA
C342 C-CER,CHIP 2203-006423 SA
C344 C-CER,CHIP 2203-000386 SA
C345 C-CER,CHIP 2203-005719 SA
C346 C-CER,CHIP 2203-006423 SA
C347 C-CER,CHIP 2203-005719 SA
C348 C-CER,CHIP 2203-006423 SA
C349 C-CER,CHIP 2203-005719 SA
C350 C-CER,CHIP 2203-006617 SA
C351 C-CER,CHIP 2203-006423 SA
C352 C-CER,CHIP 2203-006423 SA
C353 C-CER,CHIP 2203-006617 SA
C354 C-CER,CHIP 2203-006423 SA
C400 C-CER,CHIP 2203-006562 SA
C401 C-CER,CHIP 2203-005719 SA
C402 C-CER,CHIP 2203-005719 SA
C403 C-CER,CHIP 2203-005806 SA
C404 C-CER,CHIP 2203-006194 SA
C405 C-CER,CHIP 2203-006423 SA
C406 C-CER,CHIP 2203-006423 SA
C407 C-CER,CHIP 2203-006423 SA
C408 C-CER,CHIP 2203-006194 SA
C409 C-CER,CHIP 2203-006838 SA
C410 C-CER,CHIP 2203-006423 SA
C411 C-CER,CHIP 2203-006423 SA
C414 C-CER,CHIP 2203-005682 SA
C415 C-CER,CHIP 2203-006423 SA
C416 C-CER,CHIP 2203-006423 SA
