Samsung SM-A810F User manual

SM-A810F
Mobile Device CONTENTS
1. Safety Precautions
2. Specification
3. Product Function
4. Exploded View and Parts list
5. MAIN Electrical Parts List
6. Level 1 Repair
7. Level 2 Repair
8. Level 3 Repair
9. Reference data
Notice: All functionality, features, specifications,
and other product information provided in this
document, including but not limited to, benefits,
design, pricing, components, performance,
availability, and capabiliti-es of the product are
subject to change without notice. Samsung
reserves the right to alter this doc-ument or the
product described herein at anytime, without
obligation to provide notification of such
changes.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
1. Safety Precautions
1-1. Repair Precaution
Before attempting any repair or detailed tuning, shield the device from RF noise or static
electricity discharges.
Use only demagnetized tools that are specifically designed for small electronic repairs,
as most electronic parts are sensitive to electromagnetic forces.
Use only high quality screwdrivers when servicing products. Low quality screwdrivers can
easily damage the heads of screws.
Use only conductor wire of the properly gauge and insulation for low resistance, because of the low margin
of error of most testing equipment.
We recommend 22-gauge twisted copper wire.
Hand-soldering is not recommended, because printed circuit boards (PCBs) can be easily
damaged, even with relatively low heat. Never use a soldering iron with a power rating of
more than 100 watts and use only lead-free solder with a melting point below 250°C (482°F).
Prior to disassembling the battery charger for repair, ensure that the AC power is disconnected.
Always use the replacement parts that are registered in the SEC system. Third-party replacement parts
may not function properly.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
1. Safety Precautions
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Many semiconductors and ESDs in electronic devices are particularly sensitive to static discharge and can
be easily damaged by it. We recommend protecting these components with conductive anti-static bags
when you store or transport them.
Always use an anti-static strap or wristband and remove electrostatic buildup or dissipate
static electricity from your body before repairing ESDs.
Ensure that soldering irons have AC adapter with ground wires and that the ground wires are properly
connected.
Use only desoldering tools with plastic tips to prevent static discharge.
Properly shield the work environment from accidental electrostatic discharge before opening
packages containing ESDs.
The potential for static electricity discharge may be increased in low humidity environments,
such as air-conditioned rooms. Increase the airflow to the working area to decrease the
chance of accidental static electricity discharges.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
2-1. GSM General Specification
GSM850 EGSM 900 DCS1800 PCS1900 WCDMA
2100 WCDMA 1900 WCDMA 900 WCMDA 850
Freq.
Band[MHz]
Uplink/
Downlink
824~849
869~894 880~915 925~960 1710~1785
1805~1880 1850~1910 1930~1990 1922~1977 2112~2167 1852~1907 1932~1987 880~915
925~960 824~849 869~894
ARFCN
range 128~251 0~124
& 975~102
3 512~885 512~810
UL:
9612~9888
DL:
10562~10838
UL:
9262~9538
DL:
9662~9938
UL:
2712~2863
DL:
2937~3088
UL:
4132~4233
DL:
4357~4458
Tx/Rx
spacing 45MHz 45MHz 95MHz 80MHz 190MHz 80MHz 45MHz 45MHz
Mod. Bit
rate/
Bit Period
270.833kb
ps
3.692us
270.833kb
ps
3.692us
270.833kb
ps
3.692us
270.833kb
ps
3.692us 3.84Mcps 3.84Mcps 3.84Mcps 3.84Mcps
Time Slot
Period/
Frame
Period
576.9us
4.615ms 576.9us 4.615ms 576.9us 4.615ms 576.9us 4.615ms
FrameLength:
10ms
Slotlength:
0.667ms
FrameLength:
10ms
Slotlength:
0.667ms
FrameLength:
10ms
Slotlength:
0.667ms
FrameLength:
10ms
Slotlength:
0.667ms
Modulation 0.3GMSK 0.3GMSK 0.3GMSK 0.3GMSK QPSKHQPSK QPSKHQPSK QPSKHQPSK QPSKHQPSK
MS Power 33dBm~5dB
m 33dBm~5dB m 30dBm~0dB m 30dBm~0dB m 24dBm~ -50dBm 24dBm~ -50dBm 24dBm~ -50dBm 24dBm~ -50dBm
Power
Class 5pcl ~ 19pcl 5pcl ~ 19pcl 0pcl ~ 15pcl 0pcl ~ 15pcl 3(max+24dB m) 3(max+24dB m) 3(max+24dB m) 3(max+24dB m)
Sensitivity -102dBm -102dBm -100dBm -100dBm -106.7dBm -106.7dBm -106.7dBm -106.7dBm
TDMA Mux 8 8 8 8 8 8 8 8
Cell
Radius 35Km 35Km 2Km 2Km 2Km 2Km 2Km 2Km

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
2-2. GSM Tx Power Class
TX Power
control level GSM850 TX Power control level EGSM900 TX Power control level DCS1800 TX Power control level PCS1900
5 33±2 dBm 5 33±2 dBm 0 30±3 dBm 0 30±3 dBm
6 31±2 dBm 6 31±2 dBm 1 28±3 dBm 1 28±3 dBm
7 29±2 dBm 7 29±2 dBm 2 26±3 dBm 2 26±3 dBm
8 27±2 dBm 8 27±2 dBm 3 24±3 dBm 3 24±3 dBm
9 25±2 dBm 9 25±2 dBm 4 22±3 dBm 4 22±3 dBm
10 23±2 dBm 10 23±2 dBm 5 20±3 dBm 5 20±3 dBm
11 21±2 dBm 11 21±2 dBm 6 18±3 dBm 6 18±3 dBm
12 19±2 dBm 12 19±2 dBm 7 16±3 dBm 7 16±3 dBm
13 17±2 dBm 13 17±2 dBm 8 14±3 dBm 8 14±3 dBm
14 15±2 dBm 14 15±2 dBm 9 12±4 dBm 9 12±4 dBm
15 13±2 dBm 15 13±2 dBm 10 10±4 dBm 10 10±4 dBm
16 11±3 dBm 16 11±3 dBm 11 8±4 dBm 11 8±4 dBm
17 9±3dBm 17 9±3dBm 12 6±4 dBm 12 6±4 dBm
18 7±3 dBm 18 7±3 dBm 13 4±4 dBm 13 4±4 dBm
19 5±3 dBm 19 5±3 dBm 14 2±5 dBm 14 2±5 dBm
15 0±5 dBm 15 0±5 dBm

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
2-3. LTE General Specification
LTE Band1 LTE Band3 LTE Band5 LTE Band7 LTE Band8 LTE Band 20
Freq.
Band[MHz]
Uplink/
Downlink
1920~1980
2110~2170 1710~1785 1805~1880 824~849 869~894 2500~2570 1805~1880 2500~2570 1805~1880 704~716 734~746
ARFCN range
UL:
18000~18599
DL:
0~599
UL:
19200~19950
DL:
1805~1880
UL:
20400~20649
DL:
2400~2649
UL:
20750~21449
DL:
2750~3449
UL:
21450~21799
DL:
3450~3799
UL:
24150~24449
DL:
6150~6449
Tx/Rx spacing 190MHz 95MHz 45MHz 120MHz 45MHz 41MHz
Channel
Bandwidth 60 MHz 75 MHz 25 MHz 70 MHz 35 MHz 30 MHz
Modulation QPSK,16/64Q
AM QPSK,16/64Q AM QPSK,16/64Q AM QPSK,16/64Q AM QPSK,16/64Q AM QPSK,16/64Q AM
MS Power
(MPR) -35~25.7 dBm -35~25.7 dBm -35~25.7 dBm -35~25.7 dBm -35~25.7 dBm -35~25.7 dBm
Sensitivit
(QPSK)
(BW 10MHz) -94 dBm -92 dBm -92 dBm -95dBm -95dBm -95dBm
Cell Radius >5Km >5Km >5Km >5Km >5Km >5Km

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
3. Operation Instruction and Installation
Main Function
Item Description
OS Android V6.0.1 (Marshmallow)
RF
2G : 850/900/1800/1900
3G : 850/900/1900/2100
LTE : Band 1/3/5/7/8/20
Battery 3,300mAh
Base Band Exynos7420 S5E7420(2.1GHz Octa)
Other RF GPS, Glonass, BT 4.1, USB 2.0, WIFI 802.11 a/b/g/n(2.4+5GHz)
Camera 16 MP Rear, 8.0 MP Front
LCD 5.7” FHD OCTA, 1980×1080
RAM 3GB RAM +328GB eMMC
Sensor Accelerometer, Proximity, Fingerprint, Geomagnetic, RGB
Accessory
Charger: 5V/2A, 9V/1.67A
Data cable:2.7pi, 4Pin
Earphone : 3.5pi

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
4. Exploded View and Parts List
4-1. Cellular phone Exploded View

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
Design LOC SEC CODE Description
0401-001110 D9007 DIODE-SWITCHING
0404-001250 D7000,D7001,D7003 DIODE-SCHOTTKY
0406-001413 ZD8005 DIODE-TVS
0406-001505 ZD9014 DIODE-TVS
0406-001592 U8004,ZD7001,ZD8006 DIODE-TVS
0406-001592 ZD8010,ZD8011,ZD8012 DIODE-TVS
0406-001592 ZD8015,ZD9002,ZD9003 DIODE-TVS
0406-001592 ZD9004 DIODE-TVS
0406-001623 D9000,D9001 DIODE-TVS
0406-001642 ZD8013,ZD8014 DIODE-TVS
0406-001682 U7008,U7009 DIODE-TVS
0406-001690 D9002,D9003,D9004 DIODE-TVS
0406-001690 D9005,D9006 DIODE-TVS
0406-001709 ZD8007,ZD8008,ZD8009 DIODE-TVS
0406-001717 ZD9005,ZD9006,ZD9007 DIODE-TVS
0406-001717 ZD9008,ZD9009,ZD9010 DIODE-TVS
0406-001717 ZD9013,ZD9017 DIODE-TVS
0406-001733 ZD7000 DIODE-TVS
0505-003234 TR7000,TR9000 FET-SILICON
0505-003529 TR7001 FET-SILICON
0601-003541 LED7000 LED
0902-003144 UCP500 IC
0903-002171 U9008 IC
1001-001650 U3003 IC
1001-001835 U4038 IC
1001-001964 U2022 IC
1001-001971 U1023 IC
1001-001972 U1014 IC
1001-001981 U1021 IC
1001-002002 U1012 IC
1003-002769 U4042 IC
1009-001066 U9013 IC
1201-003790 PAM4000 IC
1201-003832 PAM1001 IC
1201-003943 PAM1002 IC
1201-004006 PAM1000 IC
1201-004027 U8000 IC

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
1203-008472 U7001 IC
1203-008477 U7000 IC
1203-008478 U3001 IC
1203-008507 U7003 IC
1203-008603 U9011 IC
1203-008605 U7010 IC
1203-008693 U1018 IC
1203-008716 U7006 IC
1203-008717 U9007 IC
1205-005248 U8001 IC
1205-005271 UCP300 IC
1205-005310 U4016 IC
1205-005372 U4039 IC
1205-005485 U3002 IC
1205-005529 U8003 IC
1205-005680 U4044 IC
1209-002452 U9005 IC
1404-001664 TH7000 THERMISTOR
1404-001724 TH5000,TH5001,TH7001 THERMISTOR
1404-001734 TH3000 THERMISTOR
1405-001395 VR9002,VR9003 VARISTOR
1405-001404 VR5000 VARISTOR
1405-001415 VR1006 VARISTOR
1405-001425 VR1000,VR1003,VR1004 VARISTOR
1405-001425 VR1005,VR1007,VR1009 VARISTOR
1405-001425 VR1010,VR2000,VR2001 VARISTOR
1405-001425 VR2002,VR2003,VR2004 VARISTOR
1405-001425 VR2005,VR4002,VR4003 VARISTOR
1405-001425 VR9001 VARISTOR
1405-001428 VR4004 VARISTOR
1405-001429 VR9004 VARISTOR
2007-003015 R7023,R7032,R8020 R-CHIP
2007-003015 R8022 R-CHIP
2007-007310 R5047,R5067 R-CHIP
2007-007315 R3001,R3002,R3010 R-CHIP
2007-007489 R3009 R-CHIP
2007-007573 R3003 R-CHIP
2007-007588 R4006 R-CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2007-007741 R3018,R3022,R3025 R-CHIP
2007-007741 R3026,R3028,R3029 R-CHIP
2007-007741 R4004,R5001,R5002 R-CHIP
2007-007741 R5004,R5006,R5013 R-CHIP
2007-007741 R5015,R5048,R7000 R-CHIP
2007-007741 R7022,R7031,R8000 R-CHIP
2007-007741 R8013,R8017,R8029 R-CHIP
2007-007741 R9005,R9012,R9015 R-CHIP
2007-007942 R7029 R-CHIP
2007-007946 R7030 R-CHIP
2007-008026 R8011,R8012 R-CHIP
2007-008043 R3021 R-CHIP
2007-008210 R1001,R5056 R-CHIP
2007-008211 R9022 R-CHIP
2007-008420 R8014 R-CHIP
2007-008531 R5022 R-CHIP
2007-008542 C8077 R-CHIP
2007-008582 R1002,R1003 R-CHIP
2007-008587 R8015,R8016 R-CHIP
2007-008774 R9025,R9026,R9027 R-CHIP
2007-008774 R9028,R9029,R9030 R-CHIP
2007-008798 R7001 R-CHIP
2007-008800 R3005,R3006,R3007 R-CHIP
2007-008800 R3008,R3012,R3013 R-CHIP
2007-009111 R8028 R-CHIP
2007-009155 R8018 R-CHIP
2007-009157 R5016,R5017,R5018 R-CHIP
2007-009157 R5020,R5024,R5025 R-CHIP
2007-009157 R5026,R5049,R5050 R-CHIP
2007-009157 R5051,R7003,R7006 R-CHIP
2007-009157 R7012,R7014,R7015 R-CHIP
2007-009157 R7021,R8023,R8024 R-CHIP
2007-009157 R9002 R-CHIP
2007-009171 R3011,R7020 R-CHIP
2007-009212 R5033,R5034,R5045 R-CHIP
2007-009212 R5046,R8001,R8003 R-CHIP
2007-009212 R8004,R8019,R8021 R-CHIP
2007-009212 R8025,R8026,R9007 R-CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2007-009315 R8002 R-CHIP
2007-009352 R3014,R9001,R9003 R-CHIP
2007-009352 R9004 R-CHIP
2007-009402 R7019,R7026 R-CHIP
2007-009408 R5027,R5028,R5031 R-CHIP
2007-009408 R5032,R5037,R5038 R-CHIP
2007-009408 R5039,R5040,R5041 R-CHIP
2007-009408 R5042,R5043,R5044 R-CHIP
2007-009408 R5073,R5074,R5075 R-CHIP
2007-009408 R5076,R9000,R9017 R-CHIP
2007-009408 R9018,R9019,R9020 R-CHIP
2007-009793 R5055,R8035 R-CHIP
2007-009801 R3020,R7013 R-CHIP
2007-009805 R1000,R1004 R-CHIP
2007-009866 R5023,R7002,R7005 R-CHIP
2007-009866 R7007,R7009,R7017 R-CHIP
2007-009866 R7018 R-CHIP
2007-009920 R3016,R3017,R5058 R-CHIP
2007-009920 R5060,R5063,R5064 R-CHIP
2007-009920 R5065,R5068 R-CHIP
2007-009969 R7010,R7011,R8006 R-CHIP
2007-010029 R7027 R-CHIP
2007-010202 R4000,R4001,R4002 R-CHIP
2007-010202 R4003,R9010,R9011 R-CHIP
2007-010202 R9013,R9014 R-CHIP
2007-010685 R5008,R7004,R9009 R-CHIP
2007-011043 R5057 R-CHIP
2007-011648 R7028 R-CHIP
2007-012197 R7016 R-CHIP
2203-000254 C4022 C-CERAMIC,CHIP
2203-000386 C4077 C-CERAMIC,CHIP
2203-000654 C4076 C-CERAMIC,CHIP
2203-001153 C4068,C4081 C-CERAMIC,CHIP
2203-001239 C7116 C-CERAMIC,CHIP
2203-005446 C1157 C-CERAMIC,CHIP
2203-005659 C4072,C4078 C-CERAMIC,CHIP
2203-005682 C1084,C4039,C8029 C-CERAMIC,CHIP
2203-005682 C8045,C8066,C8067 C-CERAMIC,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-005682 C9042 C-CERAMIC,CHIP
2203-005717 C7119,C9005,C9013 C-CERAMIC,CHIP
2203-005725 C1115,C1158,C4031 C-CERAMIC,CHIP
2203-005725 C5068,C7033,C9000 C-CERAMIC,CHIP
2203-005725 C9056 C-CERAMIC,CHIP
2203-005726 C1113 C-CERAMIC,CHIP
2203-005727 C4014,C4055,C4056 C-CERAMIC,CHIP
2203-005727 C5000 C-CERAMIC,CHIP
2203-005729 C5001,C8025,C8026 C-CERAMIC,CHIP
2203-005731 C8049,C8051,C8060 C-CERAMIC,CHIP
2203-005731 C8062 C-CERAMIC,CHIP
2203-005732 C8027,C8028,C8050 C-CERAMIC,CHIP
2203-005732 C8052,C8074,C8075 C-CERAMIC,CHIP
2203-005734 C8063,C8065 C-CERAMIC,CHIP
2203-005736 C1006,C1017,C1061 C-CERAMIC,CHIP
2203-005736 C1062,C1063,C1075 C-CERAMIC,CHIP
2203-005736 C1087,C1123,C1142 C-CERAMIC,CHIP
2203-005736 C1145,C1148,C1153 C-CERAMIC,CHIP
2203-005736 C1159,C1162,C2001 C-CERAMIC,CHIP
2203-005736 C2003,C2004,C2008 C-CERAMIC,CHIP
2203-005736 C2009,C2012,C2025 C-CERAMIC,CHIP
2203-005736 C2028,C2030,C2031 C-CERAMIC,CHIP
2203-005736 C2038,C2040,C4019 C-CERAMIC,CHIP
2203-005736 C4035,C4089,C4094 C-CERAMIC,CHIP
2203-005736 C4095,C9041,L2017 C-CERAMIC,CHIP
2203-005736 L2018 C-CERAMIC,CHIP
2203-005777 C1134,C1139,C1140 C-CERAMIC,CHIP
2203-005777 C2036,C4041 C-CERAMIC,CHIP
2203-005779 C4015 C-CERAMIC,CHIP
2203-005789 C1036,C1091,C1112 C-CERAMIC,CHIP
2203-005789 C1149,C1161,C4044 C-CERAMIC,CHIP
2203-005789 C4083,C4097 C-CERAMIC,CHIP
2203-005792 C1052,C1114 C-CERAMIC,CHIP
2203-005806 C1083 C-CERAMIC,CHIP
2203-006120 C4091 C-CERAMIC,CHIP
2203-006121 C1015 C-CERAMIC,CHIP
2203-006123 C4096 C-CERAMIC,CHIP
2203-006187 C1043 C-CERAMIC,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-006194 C1021,C3072,C9051 C-CERAMIC,CHIP
2203-006305 C4032,C4037,C4082 C-CERAMIC,CHIP
2203-006305 C4085 C-CERAMIC,CHIP
2203-006318 C2017 C-CERAMIC,CHIP
2203-006348 C7105 C-CERAMIC,CHIP
2203-006379 C8047 C-CERAMIC,CHIP
2203-006399 C3043,C8071,C8073 C-CERAMIC,CHIP
2203-006400 C1085,C2005,C3039 C-CERAMIC,CHIP
2203-006400 C3040,C3053,C3059 C-CERAMIC,CHIP
2203-006400 C3068,C4006,C4036 C-CERAMIC,CHIP
2203-006400 C4070,C5071,C5072 C-CERAMIC,CHIP
2203-006400 C7087,C7098,C8055 C-CERAMIC,CHIP
2203-006423 C1038,C1059,C1069 C-CERAMIC,CHIP
2203-006423 C1076,C1081,C1082 C-CERAMIC,CHIP
2203-006423 C2039,C3006,C3007 C-CERAMIC,CHIP
2203-006423 C3009,C3010,C3012 C-CERAMIC,CHIP
2203-006423 C3047,C3050,C3057 C-CERAMIC,CHIP
2203-006423 C3058,C3060,C4001 C-CERAMIC,CHIP
2203-006423 C4010,C4011,C4013 C-CERAMIC,CHIP
2203-006423 C4062,C5070,C5074 C-CERAMIC,CHIP
2203-006423 C6009,C6010,C6011 C-CERAMIC,CHIP
2203-006423 C6012,C6013,C6016 C-CERAMIC,CHIP
2203-006423 C6017,C6019,C6022 C-CERAMIC,CHIP
2203-006423 C6023,C6025,C6026 C-CERAMIC,CHIP
2203-006423 C6027,C6028,C7009 C-CERAMIC,CHIP
2203-006423 C7014,C7015,C7103 C-CERAMIC,CHIP
2203-006423 C8012,C8013,C8014 C-CERAMIC,CHIP
2203-006423 C8015,C8016,C8046 C-CERAMIC,CHIP
2203-006423 C8054,C9025,C9026 C-CERAMIC,CHIP
2203-006423 C9027,C9028,C9029 C-CERAMIC,CHIP
2203-006423 C9034,C9046,C9047 C-CERAMIC,CHIP
2203-006423 C9048,C9049,C9055 C-CERAMIC,CHIP
2203-006556 C4005 C-CERAMIC,CHIP
2203-006562 C7102,C7106 C-CERAMIC,CHIP
2203-006604 C9053 C-CERAMIC,CHIP
2203-006665 C2022 C-CERAMIC,CHIP
2203-006668 C3069,C3071,C5073 C-CERAMIC,CHIP
2203-006707 C4042,C4043,C4046 C-CERAMIC,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-006707 C4047,C4090 C-CERAMIC,CHIP
2203-006712 C8061,C8064 C-CERAMIC,CHIP
2203-006839 C3003,C3004,C3008 C-CERAMIC,CHIP
2203-006839 C3013,C3014,C3028 C-CERAMIC,CHIP
2203-006839 C3065,C3067,C7008 C-CERAMIC,CHIP
2203-006839 C8003,C8007,C8008 C-CERAMIC,CHIP
2203-006839 C8048 C-CERAMIC,CHIP
2203-006841 C9021 C-CERAMIC,CHIP
2203-006846 C1128 C-CERAMIC,CHIP
2203-006872 C3066,C9001 C-CERAMIC,CHIP
2203-006979 C3042,C3044,C3046 C-CERAMIC,CHIP
2203-006979 C3049,C3052,C3056 C-CERAMIC,CHIP
2203-007143 C1023 C-CERAMIC,CHIP
2203-007210 C4016,C4023,C4024 C-CERAMIC,CHIP
2203-007210 C9031 C-CERAMIC,CHIP
2203-007269 C9035,C9037 C-CERAMIC,CHIP
2203-007270 C7107 C-CERAMIC,CHIP
2203-007271 C7006,C7007,C7010 C-CERAMIC,CHIP
2203-007271 C7013,C7017,C7031 C-CERAMIC,CHIP
2203-007271 C7034,C7036,C7038 C-CERAMIC,CHIP
2203-007271 C7040,C7041,C7042 C-CERAMIC,CHIP
2203-007271 C7043,C7046,C7048 C-CERAMIC,CHIP
2203-007271 C7049,C7051,C7100 C-CERAMIC,CHIP
2203-007271 C8005,C8030,C8033 C-CERAMIC,CHIP
2203-007271 C8042 C-CERAMIC,CHIP
2203-007279 C1138,C7002,C7003 C-CERAMIC,CHIP
2203-007317 C4008,C4026,C4029 C-CERAMIC,CHIP
2203-007317 C6015,C7019,C7074 C-CERAMIC,CHIP
2203-007317 C7075,C7084,C7085 C-CERAMIC,CHIP
2203-007317 C8002,C8009,C8031 C-CERAMIC,CHIP
2203-007317 C8032,C8034,C8035 C-CERAMIC,CHIP
2203-007317 C8037,C8053,C8072 C-CERAMIC,CHIP
2203-007317 C9002,C9033,C9050 C-CERAMIC,CHIP
2203-007369 C4018,C7112,C7113 C-CERAMIC,CHIP
2203-007369 C7114,C7115,C8038 C-CERAMIC,CHIP
2203-007369 C8039,C8043,C8044 C-CERAMIC,CHIP
2203-007391 C4017,C7032,C8036 C-CERAMIC,CHIP
2203-007392 C7090,C7108,C7111 C-CERAMIC,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-007393 C1022,C1072,C4027 C-CERAMIC,CHIP
2203-007393 C7012,C7088,C7099 C-CERAMIC,CHIP
2203-007403 L1108 C-CERAMIC,CHIP
2203-007449 C1071,C3011,C3015 C-CERAMIC,CHIP
2203-007449 C3016,C3018,C3019 C-CERAMIC,CHIP
2203-007449 C3020,C3021,C3022 C-CERAMIC,CHIP
2203-007449 C3023,C3024,C3025 C-CERAMIC,CHIP
2203-007449 C3027,C3029,C3048 C-CERAMIC,CHIP
2203-007449 C3055,C3070,C4000 C-CERAMIC,CHIP
2203-007449 C4002,C4003,C4004 C-CERAMIC,CHIP
2203-007449 C4009,C4012,C4025 C-CERAMIC,CHIP
2203-007449 C4053,C4054,C4059 C-CERAMIC,CHIP
2203-007449 C4065,C4067,C5006 C-CERAMIC,CHIP
2203-007449 C5007,C5008,C5009 C-CERAMIC,CHIP
2203-007449 C5010,C5011,C5012 C-CERAMIC,CHIP
2203-007449 C5021,C5022,C5034 C-CERAMIC,CHIP
2203-007449 C5037,C5057,C5058 C-CERAMIC,CHIP
2203-007449 C5059,C5060,C5061 C-CERAMIC,CHIP
2203-007449 C5062,C5063,C5064 C-CERAMIC,CHIP
2203-007449 C5065,C5066,C5075 C-CERAMIC,CHIP
2203-007449 C6000,C6001,C6002 C-CERAMIC,CHIP
2203-007449 C6003,C6004,C6005 C-CERAMIC,CHIP
2203-007449 C6006,C6007,C6008 C-CERAMIC,CHIP
2203-007449 C6018,C6020,C6021 C-CERAMIC,CHIP
2203-007449 C7052,C7055,C7056 C-CERAMIC,CHIP
2203-007449 C7067,C7080,C7097 C-CERAMIC,CHIP
2203-007449 C8000,C8001,C8006 C-CERAMIC,CHIP
2203-007449 C8010,C8011,C8021 C-CERAMIC,CHIP
2203-007449 C8022,C8023,C8024 C-CERAMIC,CHIP
2203-007449 C8040,C8041,C8078 C-CERAMIC,CHIP
2203-007449 C9003,C9004,C9020 C-CERAMIC,CHIP
2203-007449 C9022,C9030,C9040 C-CERAMIC,CHIP
2203-007449 C9043,C9044,C9045 C-CERAMIC,CHIP
2203-007456 C7018 C-CERAMIC,CHIP
2203-007474 C8076,C9007,C9008 C-CERAMIC,CHIP
2203-007474 C9010 C-CERAMIC,CHIP
2203-007503 C4064 C-CERAMIC,CHIP
2203-007634 C7104 C-CERAMIC,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-007775 C7089 C-CERAMIC,CHIP
2203-007781 C8004,C9032,C9036 C-CERAMIC,CHIP
2203-007781 C9038 C-CERAMIC,CHIP
2203-007795 C3005,C3031,C3032 C-CERAMIC,CHIP
2203-007795 C3033,C3041,C3045 C-CERAMIC,CHIP
2203-007795 C3051,C3054,C4051 C-CERAMIC,CHIP
2203-007795 C5033,C6014,C7061 C-CERAMIC,CHIP
2203-007796 C3035,C3036,C3037 C-CERAMIC,CHIP
2203-007796 C3038,C3062,C8058 C-CERAMIC,CHIP
2203-007796 C8059,C9016 C-CERAMIC,CHIP
2203-008097 C7094,C8017 C-CERAMIC,CHIP
2203-008242 C3017,C3026,C3064 C-CERAMIC,CHIP
2203-008242 C4007,C4028,C4030 C-CERAMIC,CHIP
2203-008242 C5014,C5015,C5020 C-CERAMIC,CHIP
2203-008242 C5035,C5036,C5041 C-CERAMIC,CHIP
2203-008242 C5042,C5043,C5044 C-CERAMIC,CHIP
2203-008242 C5045,C5046,C5047 C-CERAMIC,CHIP
2203-008242 C5049,C5050,C5051 C-CERAMIC,CHIP
2203-008242 C5052,C5053,C5054 C-CERAMIC,CHIP
2203-008242 C5055,C5056,C5067 C-CERAMIC,CHIP
2203-008242 C7000,C7001,C7020 C-CERAMIC,CHIP
2203-008242 C7021,C7022,C7023 C-CERAMIC,CHIP
2203-008242 C7024,C7025,C7026 C-CERAMIC,CHIP
2203-008242 C7027,C7028,C7029 C-CERAMIC,CHIP
2203-008242 C7030,C7053,C7054 C-CERAMIC,CHIP
2203-008242 C7057,C7058,C7063 C-CERAMIC,CHIP
2203-008242 C7064,C7068,C7069 C-CERAMIC,CHIP
2203-008242 C7070,C7079,C7081 C-CERAMIC,CHIP
2203-008242 C7082,C7083,C7086 C-CERAMIC,CHIP
2203-008242 C7117,C9006,C9009 C-CERAMIC,CHIP
2203-008242 C9017 C-CERAMIC,CHIP
2203-008243 C7093 C-CERAMIC,CHIP
2203-008572 C8018,C8019,C8020 C-CERAMIC,CHIP
2203-008654 C7091 C-CERAMIC,CHIP
2203-008860 C1020,C1080,C1086 C-CERAMIC,CHIP
2203-008860 C4066,C7109,C9014 C-CERAMIC,CHIP
2203-008860 C9023,C9039 C-CERAMIC,CHIP
2203-009064 C5002,C5003,C5024 C-CERAMIC,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-009064 C5025,C5031,C5039 C-CERAMIC,CHIP
2203-009167 C4074,C4080 C-CERAMIC,CHIP
2203-009328 C3034,C5032,C7011 C-CERAMIC,CHIP
2203-009328 C9054 C-CERAMIC,CHIP
2203-009537 C3030,C5040,C5048 C-CERAMIC,CHIP
2203-009537 C7016,C7037,C7039 C-CERAMIC,CHIP
2203-009537 C7044,C7045,C7047 C-CERAMIC,CHIP
2203-009537 C7050,C7059,C7060 C-CERAMIC,CHIP
2203-009537 C7062,C7065,C7066 C-CERAMIC,CHIP
2203-009537 C7071 C-CERAMIC,CHIP
2203-009618 C7092 C-CERAMIC,CHIP
2203-009732 C7077,C7078 C-CERAMIC,CHIP
2203-009733 C1129,C3000,C3001 C-CERAMIC,CHIP
2203-009733 C3002,C7004,C7005 C-CERAMIC,CHIP
2203-009733 C7035,C7072,C7073 C-CERAMIC,CHIP
2203-009733 C7095,C7096,C7110 C-CERAMIC,CHIP
2203-009733 C7118 C-CERAMIC,CHIP
2203-009734 C7076 C-CERAMIC,CHIP
2409-001369 TA4000,TA7000 C-Tantal
2703-002176 L4024 INDUCTOR-SMD
2703-002900 L2003,L2030 INDUCTOR-SMD
2703-002951 L4011 INDUCTOR-SMD
2703-002953 L1073 INDUCTOR-SMD
2703-002958 L1046,L4025,L8014 INDUCTOR-SMD
2703-002959 L1084,L8025 INDUCTOR-SMD
2703-002960 L8010,L8012,L8015 INDUCTOR-SMD
2703-002960 L8016 INDUCTOR-SMD
2703-002999 L1111 INDUCTOR-SMD
2703-004012 L2014,L2020,L2027 INDUCTOR-SMD
2703-004013 L1010,L1089,L2010 INDUCTOR-SMD
2703-004014 L1050,L1055,L1059 INDUCTOR-SMD
2703-004014 L1105 INDUCTOR-SMD
2703-004018 C2026 INDUCTOR-SMD
2703-004030 L1083 INDUCTOR-SMD
2703-004034 L1002,L1004,L1047 INDUCTOR-SMD
2703-004034 L2012,L2015,L4002 INDUCTOR-SMD
2703-004034 L4017 INDUCTOR-SMD
2703-004036 L1026 INDUCTOR-SMD

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2703-004038 C2007,L1049,L1076 INDUCTOR-SMD
2703-004038 L1093,L2019,L2025 INDUCTOR-SMD
2703-004286 L1021,L1056,L1065 INDUCTOR-SMD
2703-004286 L1079 INDUCTOR-SMD
2703-004287 L4030 INDUCTOR-SMD
2703-004288 C1101,C1130,L1048 INDUCTOR-SMD
2703-004288 L1094,L2006 INDUCTOR-SMD
2703-004290 L4031 INDUCTOR-SMD
2703-004295 L1036,L1069,L1096 INDUCTOR-SMD
2703-004295 L2001,L2016,L8021 INDUCTOR-SMD
2703-004298 L1060 INDUCTOR-SMD
2703-004328 L1022,L1088,L1107 INDUCTOR-SMD
2703-004366 L4013 INDUCTOR-SMD
2703-004367 L1033,L1034,L1092 INDUCTOR-SMD
2703-004367 L2021 INDUCTOR-SMD
2703-004368 L1039,L1061,L1062 INDUCTOR-SMD
2703-004368 L1091,L1095,L1106 INDUCTOR-SMD
2703-004369 L4029 INDUCTOR-SMD
2703-004371 L9013 INDUCTOR-SMD
2703-004597 L8023,L8024 INDUCTOR-SMD
2703-004763 C1131,L1054,L1064 INDUCTOR-SMD
2703-004853 L1003 INDUCTOR-SMD
2703-004862 L4007,L4028 INDUCTOR-SMD
2703-004901 L7007,L7012 INDUCTOR-SMD
2703-004914 L4023 INDUCTOR-SMD
2703-004947 L8001 INDUCTOR-SMD
2703-004976 L2004 INDUCTOR-SMD
2703-005066 L1044,L7000 INDUCTOR-SMD
2703-005067 L7001,L7003,L7005 INDUCTOR-SMD
2703-005067 L7008,L7009,L7013 INDUCTOR-SMD
2703-005067 L7014,L7015,L7016 INDUCTOR-SMD
2703-005085 C2010 INDUCTOR-SMD
2703-005087 L1019,L1038,L1052 INDUCTOR-SMD
2703-005087 L1053,L1070,L1082 INDUCTOR-SMD
2703-005087 L4012,L4016 INDUCTOR-SMD
2703-005117 L9004,L9014 INDUCTOR-SMD
2703-005118 L9005 INDUCTOR-SMD
2703-005136 L7019 INDUCTOR-SMD

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2703-005219 L8003,L8004 INDUCTOR-SMD
2703-005225 L3000,L3001,L3002 INDUCTOR-SMD
2703-005225 L3003,L3004,L7017 INDUCTOR-SMD
2703-005226 L7002,L7004,L7006 INDUCTOR-SMD
2703-005226 L7010,L7011 INDUCTOR-SMD
2703-005366 L1015 INDUCTOR-SMD
2703-005555 L4021,L4022 INDUCTOR-SMD
2801-005345 OSC5000 CRYSTAL-UNIT
2801-005393 OSC7000 CRYSTAL-UNIT
2801-005406 OSC4000 CRYSTAL-UNIT
2802-001287 OSC4002 OSCILLATOR
2805-001113 OSC4001 OSCILLATOR
2809-001411 TCX3000 OSCILLATOR
2901-001690 C3073,C3074,C3075 FILTER-EMI
2901-001690 C3076,C3077,C3078 FILTER-EMI
2901-001690 C5016,C5017,C5018 FILTER-EMI
2901-001690 C5019,C5023,C5028 FILTER-EMI
2901-001690 C5029,C5030,C5038 FILTER-EMI
2904-002123 F2000 FILTER
2904-002257 F1002,F2001 FILTER-SAW
2904-002266 F2003 FILTER-SAW
2904-002314 F4002 FILTER-SAW
2904-002350 F1003 FILTER-SAW
2904-002355 F4003,F4004 FILTER-SAW
2910-000253 DUF1000 FILTER
2911-000414 F1000 FILTER
2911-000415 DUF2000 FILTER
3003-001233 MIC8000,MIC8001 MIC-CONDENSOR
3301-001917 L8007 CORE-FERRITE
3301-002122 L1040,L1041 CORE-FERRITE
3301-002228 L8000 CORE-FERRITE
3301-002236 L2028,L8011,L8013 CORE-FERRITE
3301-002236 L8017,L8018,L8019 CORE-FERRITE
3301-002236 L9002,L9003 CORE-FERRITE
3301-002237 L1018,L2000,L4000 CORE-FERRITE
3301-002237 L4008,L4009,L8002 CORE-FERRITE
3301-002239 L1025 CORE-FERRITE
3301-002241 L4005 CORE-FERRITE
