Samsung SMT-W6100 User manual

i

ii

iii
IMPORTANT NOTICE CONCERNING EMERGENCY 911 SERVICES
Your service provider, not the manufacturer of the equipment, is responsible for the provision
of phone services through this equipment. Any services provided through this equipment are
not intended to replace or be a substitute for primary line voice services or Plain Old
Telephone Service (“POTS”) and are not meant to provide Automatic Number Identification or
Automatic Location Information capabilities associated with emergency 911 or E911 services.
Check with your service provider to determine whether emergency 911 or E911 services are
offered as part of your plan. Even where emergency 911 services are offered as part of your
plan, the service will not work properly if you move the equipment to a different location
from your registered location. You should also be aware that phone services (including 911)
will not work in the event of either a failure of your internet service or in the event of a
power outage. You must inform any other persons who may use this equipment of the
limitations of 911 and E911 emergency services. It is strongly recommended that you always
maintain an alternate means of reaching a 911 operator in case of an emergency. The
manufacturer, distributor and service provider shall not be liable for, and expressly disclaim,
any direct or indirect damages, claims, losses, expenses, liabilities, actions, risks, or harms
arising out of or related to the services provided through this equipment, including without
limitation, emergency 911 or E911 services.
All Rights Reserved. Copyright © 2006

iv
The use, disclosure, modification, transfer, or transmittal of this work for any purpose, in any form, or
by any means, without the written permission of the copyright holder, is strictly forbidden.
Disclaimer
The content of this manual is subject to change without notice and should not be construed as a
commitment by the manufacturer, distributor, or service provider. This manual is furnished for
informational use only and the manufacturer, distributor, or service provider assumes no responsibility
for any errors or inaccuracies that may appear herein.

v
My VoiceLine Account Information
Fill in the form below to keep a record of your VoiceLine account information.
VoiceLine Information
VoiceLine Phone Number:
Account Number:
PIN:
VoiceMail Access Number:

vi
Table of Contents
INTRODUCTION........................................................................................ 1
PACKAGE CONTENTS ................................................................................ 2
SETTING UP THE SAMSUNG SMT-W6100 ................................................ 3
Preparing for Setup.............................................................................................3
Learning the SMT-W6100 Phone Layout.............................................................4
Key Description ..................................................................................................................5
Display ................................................................................................................7
Display Layout....................................................................................................................7
Icon (Display) Description.................................................................................................8
Dimming Mode.................................................................................................................10
Clock Mode .......................................................................................................................10
Backlight...........................................................................................................10
Service Light .....................................................................................................11
GETTING STARTED ................................................................................. 12
Before You Start................................................................................................12
Setting Up the Charger ....................................................................................................12
Technical Data..................................................................................................................12
Installing/Removing/Charging the Battery......................................................13
Installing the Battery.......................................................................................................13
Removing the Battery......................................................................................................14

vii
Low Battery Indicator......................................................................................................15
Recharging the Phone......................................................................................................15
Preparing the Samsung SMT-W6100 to Make Calls..........................................15
PLACING CALLS ...................................................................................... 17
Understanding Local Dial Plans.........................................................................17
Making Calls......................................................................................................18
Calling within Your Area Code (Using a U.S. Dial Plan)..................................................18
Calling within North America (Using a U.S. Dial Plan) ...................................................18
Calling International Destinations (Using a U.S. Dial Plan) ...........................................18
USING VOICEMAIL ................................................................................. 20
Recording a Personal Greeting .........................................................................20
Listening to VoiceMail Messages.......................................................................21
From Your Samsung SMT-W6100 ...................................................................................21
From the Web...................................................................................................................22
Remotely From any Touch-Tone Phone..........................................................................23
MANAGING YOUR ACCOUNT AT THE VOICELINE ACCOUNT CENTER... 25
CUSTOMER SUPPORT ............................................................................. 26
TROUBLESHOOTING............................................................................... 27
FAQS........................................................................................................ 32
VOICELINE CALLING FEATURES ............................................................ 34
END USER WARRANTY ........................................................................... 40

1
Introduction
VoiceLine allows you to use your existing broadband Internet connection and wireless access point
to receive calls and make local, long distance, and international calls – all at incredibly low rates.
Instead of relying on the traditional telephone network, VoiceLine securely transmits phone calls
over the Internet, at rates much lower than traditional phone companies can offer.
Just follow the simple installation instructions, and when you pick up the phone a few minutes later,
it will be ready to make calls! No need to dial an access number or an account number. Just make
calls all over the world!
This Guide will walk you through the set-up process and explain everything you need to know to
begin using the VoiceLine service.

2
Package Contents
 1 Samsung SMT-W6100 Wi-Fi Phone
 1 5-volt power adapter & cradle-style charger
 1 CD-ROM with user’s guide
 1 VoiceLine Getting Started Guide

3
Setting Up the Samsung SMT-W6100
This section provides step-by-step instructions for installing the Samsung SMT-W6100.
Preparing for Setup
Before you begin the setup process, you will need to have any 802.11b org wireless access point that
is connected to a broadband Internet connection. If encryption is turned on, you will need to know
the encryption key that is set on your access point.

4
Learning the SMT-W6100 Phone Layout
The following figure shows the main
elements of your phone.
Volume keys
Left Sof
t
Send Ke
y
Navigation Keys
Right Soft Key
End/Power Key
Microphone
Speaker
LCD Screen Headset
Connection Hole
Key Loc
k
mode Ke
y
Operator Servic
e
Key
Dial Keys
Q
uiet Mode Ke
y
Reserved
i ke
y
Speakerphone Key
Cancel Ke
y

5
Key Description
Key(s) Description
,
Soft keys
Perform the functions indicated by the text above them, on the bottom line of the
display.
Navigation Keys
(up/down/left/right)
In Menu Mode: Scroll through the menu options.
In Idle Mode:
- Left key checks voicemails.
Browser Home Page
key
Press and hold this button to connect to your browser homepage.
Send key
Makes or answers a call.
In Idle Mode, accesses the call log list.
In Menu Mode, selects a menu function or stores information that you have
entered, such as a name in the phone or SIM memory.
Cancel/Back/
Correction key
Deletes characters from the display.
When pressed and held in Idle Mode, quickly accesses the New memo screen.
In Menu Mode, returns to previous menu.

6
Button Description
End key
Ends a call.
When pressed and held, switches the phone on or off.
In menu Mode, cancels your input and returns to Idle Mode.
When pressed and held in Idle Mode, quickly accesses your voice mail server.
~ Enter numbers, letters and some special characters.
, Used for various purposes in different functions.
When pressed and held while entering a phone number, * key insert ‘P’(pause.
The number before ‘P’ means the dialing number and the number after ‘P’ means
the DTMF digit after call set-up is completed.
When pressed and held in Idle Mode, the #key enters or exits the Quiet Mode and
*key enters the Key Lock Mode.
Volume keys (On the left side of the phone)
During a call, adjust the earpiece volume.
In Idle Mode, adjust the key tone volume.
i Key
Converts into Internet-Radio mode.
Speakerphone Key
Converts into speakerphone mode.

7
Display
Display Layout
The display has three areas:
Area Description
First line Displays various icons. See ‘Icon Description’ section of this guide.
Middle lines Display messages, instructions and any information that you enter, such as
number to be dialed.
Last line Shows the functions currently assigned to the two soft keys.
Icons
T
ext and
g
raphic area
Soft keys Indications

8
Icon (Display) Description
Icon Features
Shows the received signal strength.
The more the number of bars, the stronger the signal.
Appears when a call is in progress.
Appears when you are out of a service area. When it displays, you cannot make
or receive calls.
Appears when you have new or unchecked voice messages.
When a message is received.
Appears when you have new or unchecked multimedia messages.
Appears when you are retrieving a multimedia message.
Appears when you set the alarms to ring at a specified time.
Appears when you set the alert type for incoming calls to Vibration or Vibration
then melody.

9
Icon Features
Appears when the Quiet Mode is active.
Appears when your phone is connected to the Access Point.(You can not make a
call yet).
Appears when the phone is registered to the network.
You can make or receive calls.
Appears in speaker phone mode.
Appears when your phone is logged in the presence server.
Shows the level of your battery. The more bars you see, the more power you
have left.

10
Dimming Mode
If you don’t press any key in a given period of time which you can set in the Backlight menu
option (Menu 6.2.3), the backlight turns to dim to save the power. Press any key to awake
the display from the Dimming Mode.
Clock Mode
If you don’t press any key in a minute after dimming of the display, the display goes into
the Clock Mode to save the power. Press any key to awake the display from the Clock Mode.
Backlight
The display and the keypad are illuminated by a backlight. When you press any key, the
backlight illuminates. It turns off if you don’t press any key within a given period of time,
depending on the Backlight menu option.

11
Service Light
The service light’s activity depends on the Service light menu
option.
The operation (On/Off) of service light is selectable from the
Settings menu (6.4.5).
Service Light

12
GETTING STARTED
Before You Start
Setting Up the Charger
After having decided where to install the charger:
• Put the adapter’s jack into the round plug of the charger.
• Put the adapter in a 100/220 V plug.
Technical Data
The adapter and the charger have the following working values:
100/240 VAC, 50/60 Hz 150 mAAdapter 5.0 VDC 700 mA
Charger 5.0 VDC 700 mA
