SRD-470D
DISPLAY
Video Inputs 4 Composite video 0.5-1 Vpp, 75 ohm automatic termination
Resolution NTSC : 704 x 480 / PAL : 704 x 576
Live
Frame Rate NTSC : 120fps / PAL : 100fps
Resolution NTSC : 704 x 480 / PAL : 704 x 576
Multi Screen Display
1 / 4 / PIP
PERFORMANCE
Operating System Embedded Linux
Recording
Compression H.264
Record Rate
NTSC : Up to 120fps@704 x 480 / PAL : Up to 100fps@704 x 576
NTSC : Up to 120fps@704 x 240 / PAL : Up to 100fps@704 x 288
NTSC : Up to 120fps@352 x 240 / PAL : Up to 100fps@352 x 288
Mode
NTSC : Manual, Schedule (Continuous / Event), Event (Pre / Post), Time lapse (0.9 / 1.9 / 3.8 / 7.5 / 15 / 30fps)
PAL : Manual, Schedule (Continuous / Event), Event (Pre / Post), Time lapse (0.8 / 1.6 / 3.1 / 6.2 / 12.5 / 25fps)
Overwrite Modes Continuous
Pre-alarm Up to 30sec (5, 10, 20, 30sec)
Post-alarm Up to 6hour (5,10, 20, 30sec, 1, 3, 5, 10, 20min, 1, 2, 3, 4, 5, 6hour)
Search &
Playback
Search Mode
Date/Time, Event, Back up, Pos, Motion (*All search include preview function)
Playback Function Fast forward / backward, Slow forward / backward, Step forward / backward
Network
Transmission Speed
CIF 120/100fps
Bandwidth
Up to 6Mbps, Unlimited (6M) / 2 / 1.5 / 1Mbps / 800 / 600 / 500 / 400 / 300 / 200 / 100 / 50kbps
Bandwidth Control Selectable
Stream H.264 (4CIF / 2CIF / CIF selectable)
Max. Remote Users Search 3 / Live unicast 10 / Live multicast 20
Protocol Support TCP/IP, DHCP, PPPoE, SMTP, NTP, HTTP, DDNS, RTP, RTSP
Monitoring NET-i viewer, SmartViewer, Webviewer
Smart Phone
Smart Phone Android, i-Phone
Protocol Support RTSP/RTP (UDP), CGI, HTTP
Transmission Speed Wi-Fi : CIF Max. 4fps (Single channel) / CIF Max. 4fps (Quad channel)
3G : CIF Max. 4fps (Single channel) / CIF Max. 4fps (Quad channel)
Max. Remote Users Live 1
Storage
Internal HDD Up to 1 SATA HDDs
DVD Writer (Back up)
Yes
USB (Back up) 3 USB ports
File Format (Back up)
AVI, BU (DVR player), EXE (Include player)
Security
Password Protection
1 Admin, 10 Group, 20 User per 1 group, User can be assigned authority for function
Data Authentication Watermark
INTERFACE
Monitors
VGA 1 VGA (800 x 600, 1024 x 768, 1280 x 1024)
Main Composite 1 BNC, 1.0 Vp-p, 75 ohm
Spot Composite Digital spot (1 BNC, 1 Vp-p, 75 ohm), support multi screen and camera title
Loop Outputs 4
Audio
Inputs / Output 4CH line in / 1CH line out
Compression ADPCM
Sampling Rate 16KHz
Alarm Inputs / Output Terminal 4 inputs (NO/NC) / Terminal 4 relay outputs (NO/NC),
Rating : 30V DC / 2A, 125V AC / 0.5A
Remote Notification Notification via e-mail
Connections
Ethernet 1 RJ-45 10/100/1000 Base-T
Serial Interface RS-232/RS-485 for PTZ, Samsung system keyboard
USB USB 2.0, 2 ports
Application Support Mouse, Remote controller
Protocol Support Samsung-T/E, Pelco-D/P, Panasonic, Phillips, AD,
DIAMOND, ERNA, KALATEL,VCL TP, Vicon
GENERAL
Electrical
Input Voltage / Current
100 ~ 240V AC ±10%, 50/60Hz, 55watt
Power Consumption
Max. 36W (With 1x HDD)
Environmental Operating Temperature / Humidity
+0°C ~ +40°C (+32°F ~ +104°F) / 20% ~ 85% RH
Mechanical Dimensions (WxHxD)
215.0 x 88.0 x 352.0mm (8.46" x 3.46" x 13.86")
Weight (With hard disks)
Approx. 3Kg (6.61 lb)
Language
Korean, Japanese, Chinese, English, French, German, Spanish, Italian, Russian,
Polish, Czech, Turkish, Netherlands, Portuguese, Swedish, Danish, Thailandais,
Rumanian, Serbian, Croatian, Hungarian, Greek (22 Language)
215.0 (8.46")
352.0 (13.86")
88.0 (3.46")10.5 (0.41")
11.1 (0.44")
215.0 (8.46")
352.0 (13.86")
88.0 (3.46")10.5 (0.41")
11.1 (0.44")
Dimensions Unit : mm (inch)
SRD-470D
4CH 4CIF H.264 Real-time Digital Video Recorder
Key Features
• 4CH 4CIF real-time DVR
• 4CIF resolution real-time recording capability
• SATA HDD support (Internal Max. HDD x 1)
• DVD-RW
• Support for smart phone
H.264 120fps(N)
100fps(P)
4CH
Technical Specifications
