Samsung CBAAG-00036 User manual

World Wide Web
http://www.samsungmobileusa.com
http://www.samsungmobile.com
http://www.samsung.com/ca
http://www.samsung.com.br
Printed in Korea
Code No.:CBAAG-00036
03/2008. Rev. 1.2
WEP350.book Page 1 Friday, March 7, 2008 1:13 PM

English / Français /
Español / Português
WEP350.book Page 2 Friday, March 7, 2008 1:13 PM

English. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Français. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Português . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
WEP350.book Page 3 Friday, March 7, 2008 1:13 PM

1
English
Contents
Safety and usage information....................................................2
Your headset overview .............................................................3
Charging the headset ...............................................................4
Turning the headset on or off ....................................................5
Understanding various modes....................................................5
Pairing with your Bluetooth phone..............................................6
Using call functions..................................................................7
Safety approvals......................................................................8
UL certified travel adapter.........................................................9
Cautions...............................................................................10
Warranty and parts replacement..............................................11
Correct disposal of this product ...............................................12
Specifications........................................................................13
WEP350.book Page 1 Friday, March 7, 2008 1:13 PM

2
Bluetooth
®
is a registered trademark of the Bluetooth SIG, Inc.
worldwide. Bluetooth QD ID: B012997
• Never disassemble or modify your headset for any reason.
Doing this may cause the headset to malfunction or become
combustible. Bring the headset to an authorized service
center to repair it or replace the battery.
• When using your headset while driving, follow local
regulations in the country or region you are in.
• Avoid storage at high temperatures (above 50° C/122° F),
such as in a hot vehicle or in direct sunlight, as this can
damage performance and reduce battery life.
• Do not expose the headset or any of its supplied parts to
rain or other liquids.
Safety and usage information
At very high volumes, prolonged listening to the
headset can damage your hearing.
WEP350.book Page 2 Friday, March 7, 2008 1:13 PM

3
English
Your headset overview
If your headset responds slowly, stops responding, or
freezes, press the RESET button on the back of the
headset with a pointed tool.
Multi-Function
button
Volume
up button
RESET
button
Microphone
Earpiece
Volume
down button
Indicator
light
Earhook
WEP350.book Page 3 Friday, March 7, 2008 1:13 PM

4
1 Put the headset in the
charging case.
2 Plug the adapter into the
case's charging socket and the
outlet.
• When charging is complete,
the indicator light will appear
solid blue if the headset is off
or a blue light will flash if the
headset is on.
• During charging, the indicator light will appear solid red if
the headset is off or red and purple lights will flash if the
headset is on.
Charging the headset
Do not attempt to charge the headset with anything
other than the adapter provided.
Charging the headset will not disrupt the connection
to the phone. You can use your headset right after
removing the charging case.
Adapter
WEP350.book Page 4 Friday, March 7, 2008 1:13 PM

5
English
To turn the headset on, press and hold the Multi-function
button until the blue indicator light flashes 4 times.
To turn the headset off, press and hold the Multi-function
button until both blue and red indicator lights flash.
•
Standby mode : The headset is waiting for a call. The blue
indicator light flashes every 3 seconds.
•
Active mode : The headset has a call in progress. The blue
indicator light flashes every 8 seconds.
•
Pairing mode : The blue indicator light stays lit. You can
discover and connect to your headset on your phone.
•
Low battery mode : There is less than 10% of battery
power left. The red indicator light flashes. You must
recharge the battery.
Turning the headset on or off
Understanding various modes
WEP350.book Page 5 Friday, March 7, 2008 1:13 PM

6
1 Enter Pairing mode.
• Turn off your headset and press and hold the Multi-
function button until the blue indicator light remains lit
after blinking.
• If you turn it on for the first time, it proceeds into Pairing
mode immediately.
2 Search for and pair with your phone according to your
phone’s user guide. (Bluetooth PIN: 0000, 4 zeros)
• If the pairing is successful, the blue indicator light will
flash 10 times rapidly before entering Standby mode.
• If the blue indicator light remains lit, retry pairing.
Pairing with your Bluetooth phone
When the headset and the phone are paired, the
headset attempts to reconnect automatically each
time it turns on. Otherwise, press the Multi-function
button to reconnect.
WEP350.book Page 6 Friday, March 7, 2008 1:13 PM

7
English
Some functions may not be supported by your phone.
In Standby mode
Press the Multi-function button to:
• Answer an incoming call
• Redial the last number called
Press and hold Multi-function button to:
• Make a voice-activated call
• Reject an incoming call
Press and hold [+] and [-] at the same time to turn the
indicator light on or off.
In Active mode
Press the Multi-function button to:
• End a call
• Transfer a call from the phone to the headset
Press and hold Multi-function button to:
• Place a call on hold
• Answer a second call
• Retrieve a call on hold
Using call functions
WEP350.book Page 7 Friday, March 7, 2008 1:13 PM

8
Press [+] or [-] to adjust the volume.
Press and hold [+] or [-] to turn the microphone off or on.
FCC
FCC ID: A3LWEP350
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
The device and its antenna must not be co-located or operating
in conjunction with any other antenna or transmitter.
Users are not permitted to make changes or modify the device
in any way.
Changes or modifications not expressly approved by Samsung
will void the user’s authority to operate the equipment.
Safety approvals
WEP350.book Page 8 Friday, March 7, 2008 1:13 PM

9
English
Industry Canada
IC ID: 649E-WEP350
Operation is subject to the following two conditions: (1) This
device may not cause interference and (2) This device must
accept any interference, including interference that may cause
undesired operation of the device.
The term “IC:” before the certification/registration number only
signifies that registration was performed based on a Declaration
of Conformity indicating that Industry Canada technical
specifications were met. It does not imply that Industry Canada
approved the equipment.
The travel adapter for this headset has met UL 1310 safety
requirements. Please adhere to the following safety instructions
per UL guidelines.
FAILURE TO FOLLOW THE INSTRUCTIONS OUTLINED MAY LEAD
TO SERIOUS PERSONAL INJURY AND POSSIBLE PROPERTY
DAMAGE.
IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE
INSTRUCTIONS.
UL certified travel adapter
WEP350.book Page 9 Friday, March 7, 2008 1:13 PM

10
DANGER - TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS.
FOR CONNECTION TO A SUPPLY NOT IN THE U.S.A., USE AN
ATTACHMENT PLUG ADAPTOR OF THE PROPER
CONFIGURATION FOR THE POWER OUTLET.
THIS POWER UNIT IS INTENDED TO BE CORRECTLY
ORIENTATED IN A VERTICAL, HORIZONTAL, OR FLOOR MOUNT
POSITION.
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user’s authority
to operate the equipment. Only use approved batteries,
antennas and chargers. The use of any unauthorized
accessories may be dangerous and void the phone warranty if
said accessories cause damage or a defect to the phone.
Although your phone is quite sturdy, it is a complex piece of
equipment and can be broken. Avoid dropping, hitting, bending
or sitting on it.
Cautions
WEP350.book Page 10 Friday, March 7, 2008 1:13 PM

11
English
Samsung warrants this product as free of defects in material,
design and workmanship for the period of one year from the
original date of purchase. (Depending on your country, the
length of warranty may vary.)
If during the period of warranty this product proves defective
under normal use and service you should return the product to
the retailer from whom it was originally purchased or qualified
service center. The liability of Samsung and its appointed
maintenance company is limited to the cost of repair and/or
replacement of the unit under warranty.
• The warranty is limited to the original purchaser
• A copy of your receipt or other proof of purchase is required
for a proper warranty service
• The warranty is void if the serial number, date code label or
product label is removed, or if the product has been subject
to physical abuse, improper installation modification, or
repair by unauthorized third parties
• Specifically exempt from any warranty are limited-life
consumable components such as batteries and other
accessories
Warranty and parts replacement
WEP350.book Page 11 Friday, March 7, 2008 1:13 PM

12
• Samsung will not assume any responsibility for any loss or
damage incurred in shipping. All repair work on Samsung
products by unauthorized third parties voids any warranty
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature,
indicates that it should not be disposed with other
household wastes at the end of its working life.
To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate this from
other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they
purchased this product, or their local government office, for
details of where and how they can take this item for
environmentally safe recycling.
Business users should contact their supplier and check the
terms and conditions of the purchase contract. This product
should not be mixed with other commercial wastes for disposal.
Correct disposal of this product
WEP350.book Page 12 Friday, March 7, 2008 1:13 PM

13
English
Specifications
Item Specifications and description
Bluetooth Version 2.0
Support Profile Headset Profile, Hands-Free Profile
Operating range Up to 30 feet (10 meters)
Maximum Standby
time
Up to 100 hours*
Maximum Active
time
Up to 5 hours
*
*Depending on the phone type and usage, the actual time may
vary.
WEP350.book Page 13 Friday, March 7, 2008 1:13 PM

14
WEP350.book Page 14 Friday, March 7, 2008 1:13 PM

15
F
rança
i
s
Table des matières
Renseignements sur la sécurité et l'utilisation............................16
Aperçu de votre oreillette .......................................................17
Recharge de l'oreillette...........................................................18
Mise en marche et fermeture de l'oreillette................................19
Explication des différents modes..............................................19
Synchronisation de l'oreillette avec un téléphone Bluetooth .........20
Utilisation des fonctions d'appel...............................................21
Agréments de sécurité............................................................23
Adaptateur de voyage conforme aux normes UL.........................24
Mises en garde......................................................................25
Garantie et remplacement des pièces .......................................26
Mise au rebut appropriée du produit.........................................27
Caractéristiques techniques.....................................................28
WEP350.book Page 15 Friday, March 7, 2008 1:13 PM

16
Bluetooth
MD
est une marque déposée de Bluetooth SIG Inc. à
l'échelle mondiale. Bluetooth QD ID: B012997
• Ne jamais démonter ou modifier l'oreillette, quelle qu'en soit
la raison. Cela risquerait d'entraîner le dysfonctionnement
de l'oreillette ou de la rendre combustible. Veuillez vous
rendre dans un centre de service autorisé pour faire réparer
l'oreillette ou pour remplacer la pile.
• Lorsque vous utilisez votre oreillette en conduisant, veuillez
respecter les règles du pays ou de la région où vous vous
trouvez.
• Éviter de ranger l'oreillette dans des endroits à température
élevée (plus de 50 °C/122 °F), notamment dans un véhicule
stationné au soleil ou directement sous les rayons du soleil,
car cela pourrait nuire au fonctionnement et réduire la durée
de vie de la pile.
• Ne pas exposer l'oreillette ou ses accessoires à la pluie ou à
d'autres liquides.
Renseignements sur la sécurité et
l'utilisation
WEP350.book Page 16 Friday, March 7, 2008 1:13 PM

17
F
rança
i
s
L'utilisation prolongée de l'oreillette lorsque le
volume est très élevé peut endommager votre ouïe.
Aperçu de votre oreillette
Touche de
réduction du
volume
Écouteur
Microphone
Touche
multifonction
Touche
d'augmentation
du volume
Témoin
lumineux
Touche de
RÉINITIALISATION
Crochet
d'oreille
WEP350.book Page 17 Friday, March 7, 2008 1:13 PM
