Samsung HM1100 User manual

Headset
HM1100

English...................................................................................1
Français...............................................................................25
Italiano.................................................................................49
Ελληνικά..............................................................................73
Nederlands..........................................................................99

English
1
Getting started
Your headset overview ......................................................................... 4
Button functions.................................................................................... 5
Charging the headset ........................................................................... 6
Wearing the headset ............................................................................ 8
Using your headset
Turning the headset on or off................................................................ 9
Pairing and connecting the headset ................................................... 10
Pairing via the Active pairing feature .................................................. 13
Using call functions............................................................................. 14
Appendix
Frequently asked questions................................................................ 18
Warranty and parts replacement ........................................................ 20
Correct disposal of this product.......................................................... 21
Correct disposal of batteries in this product ....................................... 22
Specications ..................................................................................... 23
Contents
English

2
Please read this manual before operating your headset, and keep it for further
reference.
Images used in this user manual may differ in appearance from the actual product.
Copyright
Copyright © 2010 Samsung Electronics
This user manual is protected under international copyright laws.
No part of this user manual may be reproduced, distributed, translated, or transmitted in
any form or by any means, electronic or mechanical, including photocopying, recording, or
storing in any information storage and retrieval system, without the prior written permission
of Samsung Electronics.
Trademarks
• SAMSUNG, and the SAMSUNG logo are registered trademarks of Samsung
Electronics.
• Bluetooth
®
is a registered trademark of the Bluetooth SIG, Inc. worldwide.
More information about Bluetooth is available at www.bluetooth.com.
• All other trademarks and copyrights are the property of their respective owners.

English
3
Safety information
To prevent injury to yourself and others or damage to your device, read the safety information about
your device before using the device.
• Comply with all safety warnings and regulations regarding mobile device usage while operating
a vehicle.
• Donotdisassemble,modify,orrepairyourdevice.Anychangesormodicationstoyourdevice
can void your manufacturer’s warranty. If your device needs servicing, take your device to a
Samsung Service Centre.
• Do not bite or suck the device. Children or animals can choke on small parts.
• Do not store your device in very hot or very cold areas. It is recommended to use your device at
temperatures from 5 °C to 35 °C. Extreme temperatures can damage the device and reduce the
charging capacity and life of your device and battery.
• Do not use your device while it is charging or touch your device with wet hands.
• Keep your device dry. Humidity and liquids may damage the parts or electronic circuits in your
device. Water damage to your device can void your manufacturer’s warranty.
• Do not use your device outdoor during a thunderstorm. Doing so may result in electric shock or
device malfunction.
Excessive exposure to loud sounds can cause hearing damage. Exposure to loud
sounds while walking may distract your attention and cause an accident.

4
Getting started
This section explains what to remember for the proper use of your Bluetooth headset.
Your headset overview
• Make sure you have the following items with your headset: travel adapter,
ear rubbers, earhook and user manual.
• The items supplied with your headset may vary depending on your region.
Volume button
Talk button Earhook
Power switch
Indicator light
Charger jack
Earpiece
Microphone

English
5
Button functions
Button Function
Power
switch Slide the switch to turn the headset on or off.
Talk
• Press and hold to enter Pairing mode.
• Press to make or answer a call.
• Press to end a call.
Volume
• Press to adjust the volume.
• Press and hold to turn the microphone on or off.
• In Pairing mode, press and hold the Volume up button
to turn the Multi-point feature on.
• In Pairing mode, press and hold the Volume down
button to turn the Multi-point feature off.
You can hear a beep when the volume level of the headset reaches to the lowest
or highest level.

6
Charging the headset
This headset has a rechargeable internal battery which is non-removable. Ensure
thatyoufullychargethebatterybeforeusingtheheadsetforthersttime.
1Plug the small end of the travel adapter into the charger jack.
2Plug the large end of the travel adapter into a power outlet.
During charging, the indicator light will turn red. If charging does not begin,
unplug the travel adapter and plug it in again.
3When the headset is fully charged, the indicator light changes to blue. Unplug
the travel adapter from the power outlet and the headset.

English
7
• Use only a Samsung-approved travel adapter. Unauthorised travel adapters may
cause an explosion or damage to the headset.
• The battery will gradually wear out while charging or discharging because it is
a consumable part.
• When a call come in while charging, disconnect your headset from the travel
adapter and answer the call.
• To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The charger should remain close to the electric socket
and easily accessible while charging.
• The socket-outlet shall be installed near the equipment and shall be easily
accessible.
When the battery charge gets low
Theheadsetbeepsandtheindicatorlightashesred.Rechargethebattery.Ifthe
headset powers off during a call, the call will be automatically transferred to the phone.
Checking the battery level
At the same time, press and hold the Volume down and the Talk button. Depending
onthebatterylevel,theindicatorlightashes5timesinoneofthefollowingcolours:
Battery level Indicator light colour
Above 80% Blue
80 ~20% Violet
Below 20% Red

8
Wearing the headset
Place the headset on your ear. Depending on what ear you are going to wear the
headset, simply adjust the ear hook accordingly.
Handle the headset properly to improve performance
• Do not block the device’s internal antenna. The human body can interfere with
a Bluetooth signal.
• If you usually use your mobile phone with your right hand, wear the headset
on your right ear.
• Avoid coming in contact with the internal antenna of a headset or mobile
for a better performance.
▲Left ▲Right

English
9
Using your headset
This section explains how to turn the headset on, pair and connect to the phone,
and use various functions.
• Activated functions and features may differ depending on the phone type.
• Some devices, especially those that are not tested or approved by Bluetooth SIG,
may be incompatible with your headset.
Turning the headset on or off
• To turn the headset on, slide up the power switch. The blue indicator light
ashes4times.
• To turn the headset off, slide down the power switch. The indicator light turns off
after the blue indicator light changes to red.

10
Pairing and connecting the headset
Pairing will create a unique and encrypted wireless link between two Bluetooth
enabled devices, such as a Bluetooth phone and a Bluetooth headset.
To use the headset with other Bluetooth devices, the devices must be paired.
When trying to pair the two devices, keep the headset and the phone reasonably
close together. After pairing, you can connect the two devices.
Pairing and connecting the headset with a phone
1Enter Pairing mode.
• Turn on your headset and press and hold the Talk button until the blue
indicator light stays lit.
• Ifyouturnontheheadsetforthersttime,itproceedsintoPairingmode
immediately.
2Activate the Bluetooth feature on your phone and search for the headset
(see your phone’s user manual).
3Select the headset (HM1100) from the list of devices found by your phone.
4 Enter the Bluetooth PIN (0000, 4 zeros) to pair and connect the headset
to your phone.

English
11
Your headset supports the Simple Pairing feature which allows the headset to be
paired with a phone without requesting a PIN. This feature is available for phones
that are compliant with Bluetooth version 2.1 or higher.
The headset also can be paired via the Active pairing feature, see page 13.
Connecting with two Bluetooth phones
With the Multi-point feature activated, your headset can be connected with two
Bluetooth phones at the same time.
1 AfterconnectingwiththerstBluetoothphone,pressandholdtheTalkbutton
until the blue indicator light stays lit.
2Press and hold the Volume up button to activate the Multi-point feature.
3Activate the Bluetooth feature on the second Bluetooth phone and search
for the headset (see your phone’s user manual).
4Select the headset (HM1100) from the list of devices found by the second
Bluetooth phone.
5Enter the Bluetooth PIN (0000, 4 zeros) to connect the headset to the phone.
6 ReconnecttotheheadsetfromtherstBluetoothphone.

12
When the headset connects to two Bluetooth phones, some phones may not connect
to the headset as the second Bluetooth phone.
Disconnecting the headset
To disconnect the headset from your phone,
• Turn off the headset.
• Use the Bluetooth menu on your phone.
Reconnecting the headset
You can set the headset automatically to reconnect to the recently connected
phones each time you turn it on.
To reconnect to the two most recently connected phones
Activate the Multi-point feature. Press and hold the Volume up button in Pairing
modeuntiltheblueindicatorlightashestwice.
To reconnect to only the most recently connected phone
Deactivate the Multi-point feature. Press and hold the Volume down button
inPairingmodeuntiltheredindicatorlightashestwice.
If the headset does not automatically attempt to reconnect,
• Press the Talk button.
• Use the Bluetooth menu on your phone.

English
13
Pairing via the Active pairing feature
With the Active pairing feature, your headset can automatically search for a Bluetooth
phone and try to make a connection with it.
This feature is available for mobile phones, but the phone’s Bluetooth visibility option must
be set to on.
1Turn on the headset.
2Press and hold the Talk button to enter Pairing mode.
3Press and hold the Talk button until the violet indicator light turns on.
The headset will switch to Active Pairing mode, search a Bluetooth phone
within range, and attempt to pair with it.
• Ensure the phone you wish to connect to is within range of the headset. Place
the headset and phone close to each other to avoid pairing with other devices.
• The Bluetooth phone you want to connect with must not be paired with other
devices. If the phone is already connected to another device, end the connection
and restart the Active pairing feature.
• This feature may be unavailable depending on the some PDAs.

14
Using call functions
Available call functions may vary by the phone.
Making a call
Redialling the last number
Press the Talk button to redial the last number of the most recently connected phone.
Press the Talk button twice to redial the last number of the other phone, see page 11.
For some phones, pressing the Talk button opens the call log list. Press the Talk
button again to dial the selected number.
Dialling a number by voice
PressandholdtheTalkbuttonandsayaname.Youcandialanumberoftherst
phone.

English
15
Answering a call
Press the Talk button to answer a call when you hear incoming call tones.
When two calls from the two connected phones come in, you can answer the call
oftherstphone.
Ending a call
Press the Talk button to end a call.
Rejecting a call
Press and hold the Talk button to reject a call when a call comes in.
When two calls from the two connected phones come in, you can reject the call of
therstphone.
ThisfunctionisavailableonlyontheHands-Freeprole.Formoreinformation,
see your phone’s user manual.

16
Using options during a call
You can use the following functions to control your call during a call.
Adjusting the volume
Press the Volume up or down button to adjust the volume.
Muting the microphone
Press and hold the Volume up or down button to turn the microphone off so that
the person with whom you are speaking cannot hear you. When the microphone
is turned off, the headset beeps at regular intervals. Press and hold the Volume up
or down button again to turn the microphone back on.
Transferring a call from the phone to the headset
Press the Talk button to transfer a call from the phone to the headset.
Placing a call on hold
Press and hold the Talk button to place the current call on hold.
ThisfunctionisavailableonlyontheHands-Freeprole.Formoreinformation,
see your phone’s user manual.

English
17
Answering a second call
• PresstheTalkbuttontoendtherstcallandanswerasecondcallofthesame
phone when you hear call waiting tones.
• PressandholdtheTalkbuttontoplacetherstcallonholdandanswer
a second call of the same phone when you hear call waiting tones.
• To switch between the current call and the held call, press and hold the Talk
button.
ThisfunctionisavailableonlyontheHands-Freeprole.Formoreinformation,
see your phone’s user manual.
Answering a new call of the second phone
• PresstheTalkbuttontoendtherstcallandanswerasecondcalloftheother
phone when you hear call waiting tones.
• PressandholdtheTalkbuttontoplacetherstcallonholdandanswer
a second call of the other phone when you hear call waiting tones.
• To switch between the current call and the held call, press and hold the Talk
button.
ThisfunctionisavailableonlyontheHands-Freeprole.Formoreinformation,
see your phone’s user manual.

18
Appendix
Frequently asked questions
Will my headset work
with laptops, PCs, and
PDAs?
Your headset will work with devices that support
yourheadset’sBluetoothversionandproles.
Forspecications,seepage23.
Why do I hear static
or interference while
on a call?
Appliances such as cordless phones and wireless
networking equipment may cause interference, which
usually sounds like static. To reduce any interference,
keep the headset away from other devices that use
or produce radio waves.
Will my headset
interfere with my car’s
electronics, radio,
or computer?
Yourheadsetproducessignicantlylesspowerthan
a typical mobile phone. It also only emits signals that are
in compliance with the international Bluetooth standard.
Therefore, you should not expect any interference with
standard consumer-grade electronics equipment.
