Samsung Yepp YP-35 User manual

Connecting the USB cable
1Plug one end of the USB cable into the USB port
on the PC.
2Connect the opposite end of the USB cable to the
USB cable port on the bottom of the yepp.
● If you disconnect the USB cable from your PC while
implementing a command or initializing during USB driver
installation, your PC may not function correctly.
● The yepp will automatically turn on.
3USB driver is installed with a message saying that
it is searching for a new device. You may not see
the display screen during installation. Go to the
device manager to check that installation
has been successfully completed.
4
Upon installation of the USB driver
"SAMSUNG YP-35”
will appear in the
[System Properties] ➝ [Device Manager].
➤Before connecting yepp to PC, make sure to install USB driver.
Location of Controls
Playing Music
Stopping Music
When you press the button, the yepp logo appears and a music/voice file is played.
When you press the button while playing, the music stops. If no buttons are pressed within 10
seconds (changes depending on settings), the yepp automatically powers off.
●
You can also turn off the power by pressing and holding the button.
21
USB connect cable
Earphone Jack
Neck strap Hook
SRS Button
Display
Hold Switch
USB Cable Connection Port
Battery Cover
Play/Stop/Pause/
Forward/Backward Button
MENU/Loop Repeating/
Mode/Volume Button
Microphone
➡
YP-35 Quick Guide
Quick-35 2/26/04 11:39 AM Page 2

Downloading/Uploading files
1Turn on the yepp and connect it to your PC.
2Open Windows Explorer on PC.
3Select the file to save and drag-and-drop it into the removable disk icon.
The saved files will be played in file name order.
If you want to change the order, please change the file name.
(In numerical, alphabetical order)
NN
NNoo oott ttii iicc ccee ee :: ::
●The “WRITING/READING” message will appear during file download or upload. Disconnecting the
USB cable while “WRITING/READING” is displayed may cause malfunction of the unit.
●Files within a user created folder can only be played in Music Mode.
●The order of music files displayed in Windows Explorer may differ from the play order on your
device.
Disconnecting the USB cable
1Double-click on the green arrow in the taskbar on the bottom right of the
window. Disconnect the USB cable.
2Select the USB device, and then press the [Stop] button.
After completing file transmission, you must disconnect the cable in the following way:
3 4
➡
AH68-01505A (Rev 0.0)
Quick-35 2/26/04 11:39 AM Page 4
