Samsung YP-R1JCS User manual

YP-R1
Thank you for purchasing this Samsung
product. To receive a more complete
service, please register your product at
www.samsung.com/register
MP3 Player
user manual
imagine the possibilities

Using this manual
• Some of the contents in this manual may differ from your
MP3 player depending on the firmware installed. Some
of the contents may be changed without prior notice.
• To view the special features of your MP3 player, see
"Special features of your MP3 player."
• To view troubleshooting, see "Troubleshooting."
Icons used in this manual
Icon Description
Note
Notes, usage tips, or additional information
Caution
Safety warnings and precautions
< > Menu names or text on the screen ;
for example: <Yes>

1
Safety
information
This manual describes how
to properly use your new
MP3 player. Read it carefully
to avoid damaging the player
and injuring yourself. Pay
particular attention to the
following serious warnings.
PROTECT YOURSELF
• Do not disassemble, repair, or modify this product on your own.
• Do not get the product wet or drop it in water. If the product gets wet, do not
switch it on because you could get an electric shock.
• Do not use the product during a thunderstorm, as it may cause malfunction or
a risk of electric shock.
• Do not use the earphones while you are driving a bicycle, automobile or
motorcycle.
It can cause a serious accident, and furthermore, is prohibited by law in some
areas.
Using the earphones while walking or jogging on a road, in particular, on a
crosswalk can lead to a serious accident.
• For your safety, make sure the earphone cable does not get in the way of your
arm or other surrounding objects while you are taking exercise or a walk.
• Do not place the product in damp, dusty, or sooty areas because these
environments could lead to fire or electric shock.
• Do not use the product if the screen is cracked or broken. Broken glass
or acrylic could cause injury to your hand or face. Bring the product to a
Samsung service center to replace the screen. Damage caused by careless
handling will void the warranty.

2
Safety information
PROTECT YOURSELF
• Using earphones or headphones for an extended
time may cause serious damage to your hearing.
If you are exposed to sound louder than 85db
for an extended time, you may adversely affect
your hearing. The louder the sound is, the more
seriously damaged your hearing may be (an
ordinary conversation is between 50 to 60 db and
road noise is approximately 80 db).
You are strongly advised to set the volume level to
medium (the medium level is usually less than 2/3
of the maximum).
• If you feel a ringing in the ear(s), lower the volume
or stop using the earphones or headphones.
• Battery shall not be exposed to excessive heat
such as sunshine, fire or the like.
PROTECT YOUR MP3 PLAYER
• Do not leave the player in temperatures above
35° C (95° F), such as a sauna or a parked car.
• Do not cause excessive impact on the player by
dropping it.
• Do not place heavy objects on top of the player.
• Prevent any foreign particles or dust from entering
into the product.
• Do not place the product near magnetic objects.
• Be sure to backup important data. Samsung is not
responsible for data loss.
• Use only accessories provided by or approved by
Samsung.
• Do not spray water on the product. Never clean
the product with chemical substances such as
benzene or thinner, as it may cause fire, electric
shock or deteriorate the surface.
• Failure to follow these instructions may lead to
physical injuries or damage to the player.
• When printing this user manual, we recommend
that you print in color and check “Fit to Page” in the
print option for better viewing.

Special features of your MP3 player
Listen to true three-
dimensional sound with
the Samsung Digital
Natural Sound engine
(DNSe™)
Be a cool DJ and mix
music with your own
beats in Beat DJ
Customise your main
menu screen at your
fingertip
Add your favourite
widgets to the main menu
screen
No more complicated
buttons! Control your
player with one simple
touch
Listen to music with the
mini player while viewing
pictures or documents
Easily create Bluetooth
connections with a
single motion

Contents
6
Use basic functions
7
What's included
8
Your MP3 player
9
Charge the battery
11
Turn your player on and lock the
touch screen
12
Use the touch screen
14
Use the main menu screens
15
Change the menu style
15
Select a wallpaper
16
Organise your favourite menus
18
Use widgets
18
Add widgets to a main menu screen
19
Widget list
21
Use the quick tray and menu tray
22
Use the mini player
23
Enter text
23
Enter text using the virtual keyboard
24
Enter text with the smart finger feature
25
Connect your player to a TV
26
Manage media files
27
Download media files
27
Supported file formats and PC
requirements
28
Download files with EmoDio
29
Download files using your player as a
removable disk
31
Search for files
32
Delete files
33
Play video and music
34
Video
34
Play video files
37
Use the video options
38
Music
38
Listen to music
42
Search for a music file
42
Create playlists
44
Use the music options
45
Beat DJ

48
Use additional
applications
49
Pictures
49
View pictures
50
Use the picture menus
51
Texts
51
View text files
53
Use the text options
54
FM Radio
54
Listen to the FM radio
56
Save radio stations
57
Use the FM radio options
58
Flash Player
59
Games
60
Bluetooth
60
Find and register other Bluetooth-
enabled devices
61
Connect Bluetooth-enabled devices
62
Use call functions (hands-free)
64
Transfer files
65
Use the Bluetooth options
65
Information for using Bluetooth
67
Datacasts
68
Voice REC
69
Address Book
Contents
70
Customise settings
71
Settings
72
Sound settings
72
Display settings
73
Language settings
73
Time settings
73
System settings
76
Appendix
77
Maintenance of your player
78
Troubleshooting
80
Specifications
82
Correct disposal of this product
(Waste Electrical & Electronic
Equipment)
82
Correct disposal of batteries in
this product
83
License
84
Contact Samsung World Wide

What's included .................................................................7
Your MP3 player.................................................................8
Charge the battery .............................................................9
Turn your player on and lock the touch screen..................11
Use the touch screen.........................................................12
Use the main menu screens ..............................................14
Use widgets .......................................................................18
Use the quick tray and menu tray......................................21
Use the mini player.............................................................22
Enter text ............................................................................23
Connect your player to a TV ..............................................25
Use basic functions
Learn to perform basic operations with your player.

7
What's
included
Check your product box for the following items:
MP3 player Earphones USB cable
Note
• The items supplied with your player may appear different from the illustrations in this
manual.
• You can obtain additional accessories from your local Samsung dealer.

8
Your M P3
player
Microphone
USB connection port
Volume button
(volume down)
Volume button
(volume up)
Power/lock button
Touch screen
Earphones
jack
Accessories hook
Reset hole
If your player is frozen
or unresponsive, insert
a pointed object (such
as the point of a pen)
into the reset hole. The
system will be initialized.

9
C h a r g e t h e
battery
Charge the battery before
you use your player for the
first time or when you have
not used it for a long time.
Caution
The rechargeable battery
incorporated in this product is not
user replaceable. For information
on its replacement, please
contact your service provider.
Connect the large end of the USB cable (with the triangle facing up) to the
USB connection port at the bottom of your player.
Connect the small end of the USB cable to the USB port of a PC.
<USB connected>
<>: Charging
<>: Fully charged
When the battery is fully charged, unplug the USB cable from your player
and the PC.
Charging time About 3 hours

Use basic functions > Charge the battery 10
About batteries
• Charge and store the battery at 5˚ C~35˚ C (41˚ F~95˚ F).
• Do not charge the battery for more than 12 hours or leave the
battery fully discharged for a long time. Doing so may shorten
the battery life.
• Depending on how you use your player, actual battery life may
vary and may be shorter than specified.
Note
• The charging time may differ depending on your PC’s
capabilities.
• If you want to charge the battery on your laptop, make
sure that the laptop's battery is full or the laptop is plugged
into a power source.
• The player can only be charged by connecting to your
PC with the USB cable. Do not use a separate USB AC
Adapter as it may not charge the battery or allow proper
operation of the player.

11
Turn your
player on
and lock the
touch screen
Turn your player on or off
Press and hold to
turn your player on or off.
Note
If you do not use your player for
5 minutes, it will automatically
turn off.
Lock or unlock the touch screen
Lock the touch screen to prevent any unwanted operations while listening to music or playing
videos.
Press to lock or
unlock the touch screen.
Note
• When the touch screen is
locked, will appear at the
top of the screen.
• You can also set your player
to lock the touch screen and
buttons. See page 74.

12
Use the
touch screen
Learn how to use the touch
screen and browse or
select items.
Your player’s touch screen lets you easily select items or perform functions. Tap the touch
screen using your fingertip.
Caution
To avoid damaging the touch screen, do not press too hard with your fingertips or use pointed
objects to touch the screen.
Note
• Tap only one area of the touch screen at a time. Your player will not recognise your input
when you tap two or more areas simultaneously.
• Keep the touch screen dry. Humidity and liquids may lower the recognition of the touch
screen.
• For best results, do not use any protective films on the touch screen and do not allow
accessories to cover the touch screen.
• The touch screen may not properly recognise inputs when you tap the screen with gloves,
dirty fingers, fingernails, or sharp instruments such as ballpoint pens.

Use basic functions > Use the touch screen 13
Dragging
To move an item on the screen or browse items, tap and hold
your finger on the screen and drag your finger.
To move to the next screen or flip pages, quickly drag your finger
in the desired direction.
Drag an item to
a location
y
ou want
D
rag
f
rom t
h
e
b
ottom
t
o t
h
e to
p
to scro
ll
u
p
o
n th
e
li
st
Q
uickly dra
g
ri
g
ht to
l
e
f
t to
pl
a
y
t
h
e next
fil
e
d
ur
i
n
g
p
l
ay
b
ac
k
Tapping
To select a menu or option, tap the screen once with your finger.
You can also open the quick tray or menu tray by tapping the
screen.

14
Use the main
menu screens
Learn to move between
the main menu screens,
change the menu style or
wallpaper, and organise
your favourite menus.
The main menu screens consist of menu icons and widget icons.
Menu icons
Widgets
Note
To return to a main menu screen while using a function, tap and hold at the bottom of the
screen.

Use basic functions > Use the main menu screens 15
Change the menu style
In the main menu, tap at the bottom of the
screen.
Tap <Style> from the menu tray.
Tap <or >to select a style you want.
Tap <OK> to save the style.
Select a wallpaper
In the main menu, tap and hold an empty space.
Tap an image from the file list.
Tap <OK> to save the wallpaper image.

Use basic functions > Use the main menu screens 16
Organise your favourite menus
Your player has three main menu screens by default. You can
add two more screens, and add menu icons that you frequently
use to a menu screen or delete them from the menu screen.
In the main menu, tap at the bottom of the
screen.
Tap <Icon> from the menu tray.
Add or delete menu icons from the menu list.
When you are finished, tap <OK>.
Add a menu icon
Drag a menu icon from the menu list to a main menu screen.
Menu list
t
Delete a menu icon
Drag a menu icon from a main menu screen to the menu list.

Use basic functions > Use the main menu screens 17
Relocate a menu icon
Tap <V> to close the menu list and position the menu icon
anywhere on the screen.
Note
To move a menu icon to a new main menu screen, drag the
icon to the edge of the screen.

18
Use widgets
You can use functional and
decorative widgets.
Widgets are user friendly
shortcuts to commonly
used menus allowing you to
add to a main menu screen.
Add widgets to a main menu screen
In the main menu, tap at the bottom of the screen.
Tap <Widget> from the menu tray.
Add or delete widgets from the widget list.
■For adding or deleting widgets, see "Organise your favourite menus" on page 16.
■For information about widgets, see "Widget list" on page 19.
When you are finished, tap <OK>.
