Samsung Ubigate iBG1000 User manual

COPYRIGHT
This manual is proprietary to SAMSUNG Electronics Co., Ltd. and is protected by copyright.
No information contained herein may be copied, translated, transcribed or duplicated for any
commercial purposes or disclosed to the third party in any form without the prior written consent of
SAMSUNG Electronics Co., Ltd.
TRADEMARKS
Ubigate iBG1000 is a registered trademark of SAMSNUG Electronics.
All other company and product names may be trademarks of the respective companies with which
they are associated.
This manual should be read before the installation and operation, and the operator should
correctly install and operate the product by using this manual.
This manual may be changed for the system improvement, standardization and other technical reasons
without prior notice.
If you have a question for the content of manual or want to obtain further information on the updated
manual, please contact the homepage below.
Homepage: http://www.samsungdocs.com
©2008~2010 SAMSUNG Electronics Co., Ltd. All rights reserved.

Ubigate iBG1000 System Description
© SAMSUNG Electronics Co., Ltd. I
GENERAL USER INFORMATION
Radio Frequency Interference
This equipment has been tested and found to comply with the limits for a
Class Adigital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at user’s own expense.
FCC Requirements
This equipment, Ubigate iBG1000, complies with Part 68 of the FCC rules
and the requirements adopted by the ATCA. On the bottom of this equipment
is a label that contains, among other information, a product identifier in the
format US: A3LIS00BiBG1000. If requested, this number must be provided
to the telephone company.

GENERAL USER INFORMATION
II © SAMSUNG Electronics Co., Ltd.
Unauthorized Modifications
Any changes or modifications performed on this equipment that are not
expressly approved in writing by SAMSUNG ELECTRONICS, CO., LTD.
could cause non-compliance with the FCC rules and void the user’s authority
to operate the equipment.
Allowing this equipment to be operated in such a manner as to not
provide for proper answer supervision is a violation of Part 68 of the
FCC’s rules.
Telephone Connection Requirement
A plug and jack used to connect this equipment to the premises wiring and
telephone network must comply with the applicable FCC Part 68 rules and
requirements adopted by the ATCA. A compliant telephone cord and modular
plug is provided with this product. It is designed to be connected to a
compatible modular jack that is also compliant. See installation instructions
for details.
FCC Part 68
This equipment complies with Part 68 of the FCC rules. The FCC Part 68
label is located on the bottom chassis panel. This label contains the FCC
Registration Number and Ringer Equivalence Number (REN) for this
equipment. If requested, this information must be provided to your telephone
company.
Incidence of Harm
If this equipment, Ubigate iBG1000,causes harm to the telephone network,
the telephone company will notify you in advance that temporary discontinuance
of service may be required. But if advance notice isn’t practical, the telephone
company will notify the customer as soon as possible. Also, you will be advised
of your right to file a complaint with the FCC if you believe it is necessary.

Ubigate iBG1000 System Description/Ed.02
© SAMSUNG Electronics Co., Ltd. III
Service Center
If trouble is experienced with Ubigate iBG1000, please contact your local
office of SAMSUNG ELECTRONICS, CO., LTD. for repair or warranty
information. If the trouble is causing harm to the telephone network, the
telephone company may request that you remove the equipment from the
network until the problem is resolved.
Field Repairs
Only technicians certified on Ubigate iBG1000, are authorized by SAMSUNG
ELECTRONICS, CO., LTD. to perform system repairs. Certified technicians
may replace modular parts of a system to repair or diagnose trouble.
Defective modular parts can be returned to SAMSUNG ELECTRONICS, CO.,
LTD. for repair.
General
Connection to party line service is subject to state tariffs. Contact the state
public utility commission, public service commission or corporation
commission for information.
Electrical Safety Advisory
Parties responsible for equipment requiring AC power should consider
including an advisory notice in their customer information suggesting the
customer use a surge arrestor. Telephone companies report that electrical
surges, typically lightning transients, are very destructive to customer terminal
equipment connected to AC power sources. This has been identified as a
major nationwide problem.

GENERAL USER INFORMATION
IV © SAMSUNG Electronics Co., Ltd.
Safety Warning
High touch current earth connection is essential before making
telecommunication network connection.
Energy Hazard-careful treatment is needed.
Every wire for communication should be larger than 26 AWG.
Double pole/neutral fusing.
Underwriters Laboratories
Ubigate iBG1000 system has been tested to comply with safety standards in
the United States and Canada. This system is listed with Underwriters
Laboratories. The cUL Mark is separately shown on the label.
The following statement from Underwriters Labs applies to Ubigate iBG1000
System:
1. Separation of TNV and SELV - Pluggable A:
Instruction: The separate protective earthing terminal provided on this
product shall be permanently connected to earth.
2. Separation of TNV and SELV - Pluggable B:
Instruction: Disconnect TNV circuit connector (s) before disconnecting
power.

Ubigate iBG1000 System Description/Ed.02
© SAMSUNG Electronics Co., Ltd. V
3. Warning to service personnel:
CAUTION: Double pole/neutral fusing
4. Telephone line cord:
CAUTION: To reduce the risk of fire, use only No. 26 AWG or larger
(e.g., 24 AWG) UL Listed or CSA Certified Telecommunication Line
Cord
5. Leakage currents due to ringing voltage - Earthing installation
instructions: 1. A supplementary equipment earthing conductor is to be
installed between the product or system and earth, that is, in addition to
the equipment earthing conductor in the power supply cord.
2. The supplementary equipment earthing conductor may not be smaller
in size than the unearthed branch-circuit supply conductors.
The equipment earthing conductor is to be connected to the product at
the terminal provided, and connected to earth in a manner that will retain
the earth connection when the power supply cord is unplugged.
The connection to earth of the supplementary earthing conductor shall be
in compliance with the appropriate rules for terminating bonding
jumpers in Part K of Article 250 of the National Electrical Code,
ANSI/NFPA 70 and Article 10 of Part 1 of the Canadian Electrical Code,
Part 1, C22.1. Termination of the supplementary earthing conductor is
permitted to be made to building steel, to a metal electrical raceway
system, or to any earthed item that is permanently and reliably connected
to the electrical service equipment earthed.
3. Bare, covered, or insulated earthing conductors are acceptable.
A covered or insulated conductor must have a continuous outer finish
that is either green, or green with one or more yellow stripes.
6. Safety Instructions-Rack Mount ‘Rack Mount Instructions-
The following or similar rack-mount instructions are included with the
installation instructions:
A) Elevated Operating Ambient-If installed in a closed or multi-unit rack
assembly, the operating ambient temperature of the rack environment
may be greater than room ambient. Therefore, consideration should be
given to installing the equipment in an environment compatible with the
maximum ambient temperature (Tma) specified by the manufacturer.

GENERAL USER INFORMATION
VI © SAMSUNG Electronics Co., Ltd.
B) Reduced Air Flow-Installation of the equipment in a rack should be
such that the amount of air flow required for safe operation of the
equipment is not compromised.
C) Mechanical Loading-Mounting of the equipment in a rack should
be such that a hazardous condition is not achieved due to uneven
mechanical loading.
D) Circuit Overloading-Consideration should be given to the
connection of the equipment to the supply circuit and the effect that
overloading of the circuits might have on overcurrent protection
and supply wiring. Appropriate consideration of equipment
nameplate ratings should be used when addressing this concern.
E) Reliable Earthing-Reliable earthing of rack-mounted equipment should
be maintained. Particular attention should be given to supply
connections other than direct connections to the branch circuit (e.g., use
of power strips).’

Ubigate iBG1000 System Description
© SAMSUNG Electronics Co., Ltd. VII
INTRODUCTION
Purpose
Ubigate iBG1000™ System Description describes general information for
Ubigate iBG1000 hardware and software.
Document Content and Organization
This description is composed of three Chapters, one Annex, the Abbreviation,
and the Index.
CHAPTER 1. Introducing Ubigate iBG1000
Ubigate iBG1000 Overview
Product Specifications
Ubigate iBG1000 Software Features and Licenses
CHAPTER 2. Hardware Overview
Ubigate iBG1000 Chassis
Ubigate iBG1000 Boot Sequence
Ubigate iBG1000 Top Side
Ubigate iBG1000 Rear Side
Port Numbering

INTRODUCTION
VIII © SAMSUNG Electronics Co., Ltd.
CHAPTER 3. Software Overview
Management Plane
Control Plane
Packet Forwarding Plane
ANNEX A. Cable Specifications
Describes cable specifications.
ANNEX B. Open Source Announcement
Open source announcements for this product.
ABBREVIATION
Describes the acronyms used in this description.
INDEX
Index provides main searching keywords to be found.
Conventions
The following types of paragraphs contain special information that must be
carefully read and thoroughly understood. Such information may or may not
be enclosed in a rectangular box, separating it from the main text, but is
always preceded by an icon and/or a bold title.
NOTE
Indicates additional information as a reference.

Ubigate iBG1000 System Description/Ed.02
© SAMSUNG Electronics Co., Ltd. IX
Information for Product and Technical Support
For questions regarding the product and technical supports:
http://www.samsungnetwork.com
Revision History
EDITION DATE OF ISSUE REMARKS
00 03. 2008. First edition
01 06. 2008. Revised for port name printing changes
02 08. 2010. Modified Open SourceAnnouncement

INTRODUCTION
X© SAMSUNG Electronics Co., Ltd.
This page is intentionally left blank.

Ubigate iBG1000 System Description
© SAMSUNG Electronics Co., Ltd. XI
TABLE OF CONTENTS
GENERAL USER INFORMATION I
Radio Frequency Interference........................................................................................I
FCC Requirements.........................................................................................................I
Safety Warning.............................................................................................................IV
Underwriters Laboratories ............................................................................................IV
INTRODUCTION VII
Purpose.......................................................................................................................VII
Document Content and Organization...........................................................................VII
Conventions................................................................................................................VIII
Information for Product and Technical Support.............................................................IX
Revision History............................................................................................................IX
CHAPTER 1. Introducing Ubigate iBG1000 1-1
Ubigate iBG1000 Overview..............................................................................................1-1
Main Features, Functions and Benefits ......................................................................1-1
Branch Office Configuration Example.........................................................................1-2
Product Specifications ....................................................................................................1-4
Ubigate iBG1000 Specifications .................................................................................1-4
Interfaces....................................................................................................................1-5
Memory.......................................................................................................................1-6
Power Supply .............................................................................................................1-7
Ventilation...................................................................................................................1-7
Real-Time Clock.........................................................................................................1-7
Ubigate iBG1000 Software Features and Licenses.......................................................1-8
Switch/Router Features..............................................................................................1-8
Security Features .......................................................................................................1-9

TABLE OF CONTENTS
XII © SAMSUNG Electronics Co., Ltd.
CHAPTER 2. Hardware Overview 2-1
Ubigate iBG1000 Chassis................................................................................................2-2
Ubigate iBG1000 Boot Sequence....................................................................................2-3
Ubigate iBG1000 Top Side...............................................................................................2-4
Ubigate iBG1000 Rear Side .............................................................................................2-6
Console Port...............................................................................................................2-6
Auxiliary Port...............................................................................................................2-6
Port Numbering ................................................................................................................2-7
iBG1000 Port Numbering............................................................................................2-8
CHAPTER 3. Software Overview 3-1
Management Plane...........................................................................................................3-1
SNMP .........................................................................................................................3-1
MIB Information...........................................................................................................3-1
Community-based Authentication ...............................................................................3-1
User-Based Security Model (USM).............................................................................3-2
View-based Access Control Model (VACM)................................................................3-2
TRAPS........................................................................................................................3-2
Command Line Interface (CLI)....................................................................................3-3
Web GUI (HTTP Server).............................................................................................3-4
Control Plane....................................................................................................................3-5
Unicast Routing Protocols...........................................................................................3-5
Multicast Routing Protocols ........................................................................................3-6
WAN Protocols............................................................................................................3-7
Packet Forwarding Plane...............................................................................................3-10
ANNEX A. Cable Specifications A-1
Console Port Cable .........................................................................................................A-1
Auxiliary Port Cable ........................................................................................................A-2
Ethernet Cable.................................................................................................................A-3
T1/E1 Cable......................................................................................................................A-4

Ubigate iBG1000 System Description/Ed.02
© SAMSUNG Electronics Co., Ltd. XIII
ANNEX B. Open Source Announcement B-1
ABBREVIATION I
A ~ G ..............................................................................................................................I
H ~ Q.............................................................................................................................II
R ~ W ...........................................................................................................................III
INDEX I
A ~ S...............................................................................................................................I
T ~ W.............................................................................................................................II

TABLE OF CONTENTS
XIV © SAMSUNG Electronics Co., Ltd.
LIST OF FIGURES
Figure 1.1 Branch office deployment example .........................................................1-3
Figure 1.2 Power Supply..........................................................................................1-7
Figure 1.3 Ventilation................................................................................................1-7
Figure 2.1 Isometric View.........................................................................................2-2
Figure 2.2 Ubigate iBG1000 Top View......................................................................2-4
Figure 2.3 Ubigate iBG1000 Rear View ...................................................................2-6
Figure 2.4 iBG1000 Port Numbering........................................................................2-8
Figure 3.1 iBG-DM Management Network Diagram.................................................3-4
Figure A.1 Console Port Cable................................................................................ A-1
Figure A.2 Auxiliary Port Cable................................................................................ A-2
Figure A.3 Ethernet LAN Interface Cable ................................................................ A-3
Figure A.4 T1/E1 WAN Interface Cable................................................................... A-4

Ubigate iBG1000 System Description
© SAMSUNG Electronics Co., Ltd. 1-1
CHAPTER 1. Introducing Ubigate
iBG1000
Chapter1 describes Ubigate iBG1000 overview and specifications.
Ubigate iBG1000 Overview
Main Features, Functions and Benefits
Ubigate iBG1000 router is a Wide Area Network (WAN) router. It is a 1U
router that supports multi-protocol routing on WAN/LAN interfaces.
Using built-in encryption engine, Ubigate iBG1000 can provide IPSec Virtual
Private Network (VPN).
Here are highlights of Ubigate iBG1000’s features.
Performance and Scalability
150 Kpps Routing Capacity
Maximum 4 T1/E1 and 2 FE UTP ports
Simple but Powerful Management
Customers can manage all aspects of routing, switching, and security from a
single Web-Graphic User Interface (GUI).
Read-only remote management enables service providers a quick view of
the router for easy troubleshooting of Customer Premises Equipment (CPE).

CHAPTER 1. Introducing Ubigate iBG1000
1-2 © SAMSUNG Electronics Co., Ltd.
Versatility
WAN: Clear-Channel/Channelized T1/E1, Integrated Service Digital
Network (ISDN), Frame Relay, Multi-link Frame Relay (MFR), Point to
Point Protocol (PPP), Multi-Link PPP (MLPPP), and PPP over Frame Relay
LAN: 100 Mbps Metro Ethernet, Virtual Local Area Network (VLAN), and
802.1q
QoS: DiffServ, Auto QoS, Link Fragmentation and Interleaving (LFI), Low-
Latency Queuing (LLQ) and Frame Relay PVC Queuing
Rock-Solid but Flexible Security
IPSec, Generic Routing Encapsulation (GRE), Layer 2 Tunneling Protocol
(L2TP), Triple Data Encryption Standard (3DES)/Advanced Encryption
Standard (AES), and Content Filtering
Branch Office Configuration Example
Employing full routing capabilities as well as integrated security, Ubigate
iBG1000 eliminates a need for many separate network devices at customer
sites. In addition, remote management features of Ubigate iBG1000 allow you
to graphically configure, monitor or troubleshoot Ubigate iBG1000 as a
managed CPE device with ease. With Ubigate iBG1000 on your side, you will
boost your revenue while providing a right solution to your customers.
Customer may increase productivity for its mobile executives, improved
contact center operations, and facilitated expansion and acquisitions.

Ubigate iBG1000 System Description/Ed.02
© SAMSUNG Electronics Co., Ltd. 1-3
In Figure 1.1, iBG1000 in Branch office is shown to provide features of a
router, a firewall, and a VPN concentrator in a single device.
Figure 1.1 Branch office deployment example
Branch Office
DMZ Server
Internet
HQ
T1/E1 or Metro Ethernet
T1/E1 or Metro Ethernet
VPN
Firewall
Computer
Ubigate iBG1000

CHAPTER 1. Introducing Ubigate iBG1000
1-4 © SAMSUNG Electronics Co., Ltd.
Product Specifications
Ubigate iBG1000 Specifications
The following table lists specifications for Ubigate iBG1000.
Item Specification
Router Memory - Typical: 512 MB
- Maximum: 1 GB
Internal Storage SD Memory: 1 GB
Boot Flash 2 MB
AC Power Adapter - Input Voltage: 100~240 V
- Frequency: 50~60 Hz
- Power Consumption: 24 W
High Temperature (Operating) 104˚F (+40˚C)
Low Temperature (Operating) 32˚F (0˚C)
High Temperature (Non-Operating) 158˚F (+70˚C)
Low Temperature (Non-Operating) -13°F (-25˚C)
Humidity (Operating) 5 to 95%, non-condensing
Dimension (H × W × D) - Height: 1.75-inch (44.45 mm)
- Width: 10.24-inch (260 mm)
- Depth: 7.48-inch (190 mm)
Weight 1 Kg
Altitude 0 to 13,123 ft (0 to 4, 018 m)
Regulatory & Safety Compliance - MIC Type Approval/EMC Registration
- IEC 60950-1/EN 60950-1/UL 60950-1
- EN 55022/EN 55024/EN 61000-3-2/
EN 61000-3-3
- FCC Part 15 Class A
- FCC Part 68
